Univerzalne konvencionalne rezkalne stroje za orodja, X-hod 0–399 mm nakup rabljenega (128)

Stanje: rabljeno, številka stroja/vozila: 2819-0517, x-axis travel: 300 mm y-axis travel: 300 mm z-axis travel: 400 mm (340 mm with apron) Clamping surface: 390 x 620 mm / chip tray Spindle speed: 40–2500 rpm Feed range: 0.2–3600 mm/min Rapid traverse: 4.0 m/min Control: Contour 3 – 3D Path Control System Spindle taper: SK40 Quill stroke: 60 mm Swiveling head +/-: 90° Spindle drive motor: 2.0 kW Bwedocxxp Tjpfx Aqtst Total power requirement: 1.6 / 2.0 kW Machine weight approx.: 1.3 t Space requirement approx.: 1.8 x 1.8 x 1.8 m Universal milling machines from Deckel have proven themselves for decades in mold, tool, and machine construction. CNC-controlled tool milling machine with Contour 3 control, vertical head swivels +/- 90° with 60 mm quill stroke, horizontal spindle, feeds and rapid traverse on 3 axes, hydraulic tool clamping, automatic central lubrication, coolant system, emergency stop button, chip guard enclosure with chip tray, separate control cabinet. The machine is in good condition.

Stanje: rabljeno, številka stroja/vozila: 28670, x-travel: approx. 400 mm y-travel: 150 mm z-travel: 340 mm Clamping surface: 600 x 210 mm T-slots: 4 T-slot width: 12 mm Bsdpfx Aqjcxxlijtewt Spindle speeds: 20 - 2000 rpm Speed range - vertical: 60 - 1200 rpm Speed range - horizontal: 95 - 1900 rpm Spindle speed steps: 12 Feed range: 10 - 500 mm/min Feed steps: 10 Spindle taper: MK 4 Quill stroke vertical: 60 mm Total power requirement: 1.7 kW Machine weight approx.: 0.8 t Required space approx.: 0.9 x 1.05 x 1.55 m

Stanje: rabljeno, številka stroja/vozila: 2880, x-axis travel: 290 mm y-axis travel: 120 mm z-axis travel: 350 mm Table clamping surface: 690 x 175 mm Spindle taper: SK40 Bwodpfxocxxnto Aqtet Number of spindle speeds: 17 Feed range: 42 - 680 mm/min Number of feed rates: 14 Spindle speed range: 50 - 2240 rpm Approx. machine weight: 0.6 t Universal tool milling machine with swiveling vertical head +/- 90°, double-pole switchable spindle drive with clockwise and counter-clockwise rotation. The machine is equipped with handwheels on all 3 axes, rapid traverse via crank handle in the x-direction, electric feed in x-direction, feed rates adjustable via change gears, overhead arm for horizontal milling, three-position cam switch in x-direction for automated processes, emergency stop in the control panel, and main switch for safety.

Stanje: delavnici obnovljeno (rabljeno), Leto izdelave: 1990, Univerzalni rezkalni stroj Znamka: DECKEL Model: FP 1 Aktiv Letnik: 1990 - preizkušen v delavnici Serijska številka: 2102-5866 Tip rezkalne glave: 2171 Številka rezkalne glave: 4613 Geometrijski prevzem s preizkusnim protokolom Pribor: Bodpfx Aex It Rxeqtowt - 3-osni aktivni digitalni prikazovalnik HEIDENHAIN TNC 113 z aktivno funkcijo v X-, Y- in Z-osi - Univerzalna miza 590 x 250 mm (T-utori: 12 mm) - Vertikalna rezkalna glava SK 40 z vijačnim navojem S 20 x 2 - Brez hladilne naprave možnost naknadne vgradnje - Električna centralna mazalna naprava - Navodila za uporabo Rabljeno kot vidno, brez garancije Stroj ustreza tehničnemu stanju časa izdelave.

Stanje: delavnici obnovljeno (rabljeno), Leto izdelave: 1990, Univerzalni rezkalni stroj Znamka: DECKEL Model: FP 1 Aktiv Letnik: 1990 - preizkušen v delavnici Serijska številka: 2102-5866 Tip rezkalne glave: 2171 Številka rezkalne glave: 4613 Geometrijski prevzem s preizkusnim protokolom Pribor: - 3-osni aktivni digitalni prikazovalnik HEIDENHAIN TNC 113 z aktivno funkcijo v X-, Y- in Z-osi - Univerzalna miza 590 x 250 mm (T-utori: 12 mm) - Vertikalna rezkalna glava SK 40 z vijačnim navojem S 20 x 2 - Brez hladilne naprave možnost naknadne vgradnje - Električna centralna mazalna naprava - Navodila za uporabo Bwjdpfjx S Edlsx Aqtot Rabljeno kot vidno, brez garancije Stroj ustreza tehničnemu stanju časa izdelave.

Stanje: dober (rabljeno), Acera F3 Rezkalni stroj vrhunske kakovosti. Motor in menjalnik delujeta brezhibno. Ni nobene dodatne opreme razen tiste, ki je vidna na slikah. Bwsdpfxer Ixpdo Aqtst Lahko se naloži na europrikolico in se organizira prevoz po vsej Evropi.

Leto izdelave: 1978, stanje: zelo dobro (rabljeno), Macmon M 100 D tool milling machine with 3-axis Fagor digital readout, from training department. Features a fixed table and SK 40 spindle taper. Accessories include various collets and milling arbors. The machine is in very good, ready-to-use condition and can be demonstrated under power by appointment. Bwedpfjhtfubsx Aqtst

Stanje: zelo dobro (rabljeno), Leto izdelave: 1992, Funkcionalnost: popolnoma funkcionalen, Oprema: dokumentacija / priročnik, Universal Milling Machine Deckel FP1 with 3-Axis Active Digital Readout TNC 113 Heidenhain and Infinitely Variable Feed, in Excellent Condition, CE Compliant Technical Data: >> Year of manufacture: 1992, Machine No. 2102-6209 >> Fixed angle table (freshly planed) >> Spindle speed: 40 - 2000 rpm >> Infinitely variable feed on 3 axes >> Rapid traverse on 3 axes >> Drive power: 1.5 / 1.9 kW >> Spindle brake >> Travel distances X/Y/Z: 300/160/340 mm >> Vertical milling head on spindle slide, adjustable by 100 mm >> Vertical and horizontal quill – SK40 >> Drawbar system M16 >> Weight approx. 800 kg Accessories and Features: >> 3-axis digital display Heidenhain TNC113 >> Coolant system Bwjdpfx Aexdi Ivoqtet >> Machine lamp >> Operating manual, spare parts list About the Machine: Offered here is a Deckel FP1 universal milling machine, CE compliant, in very good condition. The machine exhibits minimal backlash and all spindles move smoothly. The milling machine operates very quietly even at maximum speeds. A special feature is that the electrical cabinet is connected to the machine via a plug, which makes transportation easier. In this newer FP1 model, the feed on all three axes is infinitely variable, and there is also rapid traverse on these axes. A major advantage is the active 3-axis digital readout. With this Heidenhain positioning control, you can enter the dimensions and the machine will automatically approach them. This FP1 was used in a training workshop and was only occasionally operated. An oil change has been carried out. Mechanically and electrically tested. The Heidenhain digital readout facilitates your work and delivers even higher accuracy. Take advantage of the opportunity to view and test this machine on site under power.

Stanje: rabljeno, Leto izdelave: 1989, Universal tool milling machine Brand: DECKEL Model: FP 1 Aktiv Year of manufacture: 1989 – workshop tested Machine no.: 2102-5561 Bwodpfsr En Dyjx Aqtot Milling head type: 2171 Milling head number: 4393 Geometric acceptance with inspection protocol Accessories: - 3-axis active digital readout HEIDENHAIN TNC 113 with active function on X, Y, and Z axes - Fixed table 600 x 210 mm (T-slot: 12 mm) - Vertical milling head SK 40 with draw thread S 20 x 2 - Coolant device - Central lubrication, electric - Operating manual Used, sold as seen, without warranty The technical condition of the machine corresponds to the standard of its year of manufacture.

Stanje: rabljeno, Deckel rezkalni stroj FP1 s 3-osnim digitalnim prikazovalnikom 380V 120-1900 vrt./min Bedpfx Aqjy Ddd Ustewt Pomik osi X: 300 mm Pomik osi Y: 150 mm Pomik osi Z: 340 mm Vpenjalo za orodje: MK 4 z vpenjalnim navojem S 20 x 2 Tip rezkalne glave: vertikalna rezkalna glava Tip mize: fiksna miza Vpenjalna površina mize: 600 x 210 mm Velikost T-utora: 12 mm Pomik osi X: 290 mm Pomik osi Y: 150 mm Pomik osi Z: 330 mm Teža: 700 kg Deckel rezkalni stroj FP1

Stanje: rabljeno, Leto izdelave: 1973, x-axis travel: 290 mm y-axis travel: 170 mm z-axis travel: 310 mm Bwsdpfxstqqn Rs Aqtst Table clamping surface: 600 x 215 mm Spindle taper: SK 40 Spindle speeds: 50 - 2500 rpm Feeds: 9 - 450 mm/min Quill stroke: 70 mm Total power requirement: 1.8 kW Machine weight approx.: 860 kg Machine dimensions (L x W x H): 1.06 x 1.05 x 1.33 m Accessories: Vertical head with extendable quill, fixed table, counter bearing, coolant system

Stanje: delavnici obnovljeno (rabljeno), Leto izdelave: 1976, Universal Tool Milling Machine Make: DECKEL Bwsdpfjmhfrrex Aqtjt Model: FP 1 Year of manufacture: 1976 - overhauled, newly painted, RAL7035 light grey / RAL7012 basalt grey / RAL5008 grey blue Machine no.: 52860/08 Milling head no.: 7296/80 Warranty: 12 months single-shift from delivery on the mechanical components overhauled by us. Electrical and electronic components are excluded, as these have only undergone a functional test. For machines located outside our Northern Bavaria sales region, travel expenses are to be borne by the customer. Geometric acceptance test with test protocol included. Accessories: - 3-axis digital readout FAGOR Innova 30i-M, new - Fixed table 600 x 210 mm (T-slot: 12 mm) - Vertical milling head SK 40 with drawbar thread S 20 x 2 - Coolant system - Operating manual Used, sold as seen The machine corresponds technically to the state of the art at the time of manufacture.

Stanje: novo, Leto izdelave: 2025, dolžina podajanja os X: 300 mm, dolžina pomika po osi Y: 165 mm, dolžina podajanja os Z: 280 mm, potovalna razdalja osi X: 310 mm, pomik osi Y: 170 mm, pomik po osi Z: 330 mm, poteza s peresom: 70 mm, največja hitrost vretena: 2.600 obr/min, hitrost vretena (min.): 40 obr/min, skupna masa: 730 kg, Dear Sir or Madam, We are pleased to offer you the Macmon M100 NC milling machine. This is a true all-rounder for training and small batch production environments. The Macmon combines a conventional machine base with a Heidenhain TNC128 CNC path control, making this model an absolute must-have in certain work areas. Best of all: With a footprint of just one square meter, this machine fits into any workshop! Standard Technical Specifications: • Heidenhain TNC 128 controller (integrated in the control panel) • Ribbed cast construction with hardened and ground guideways on the column and support • Swiveling vertical head, 360° rotation • Extendable quill, stroke 70 mm • Removable vertical head for switching between vertical and horizontal milling • Prism guides on all axes • Ground leadscrew on all axes • Mechanical tool clamping for both vertical and horizontal spindles • Tool holder ISO 40 for tools according to DIN 2080 AT 3 with draw thread S 20 x 2 or M 16 • Fixed angle table 215 x 600 mm, T-slots 4 x 12 H7 (spacing 45 mm) • Vertical clamping surface 195 x 640 mm, T-slots 2 x 12 H7 (spacing 90 mm) • HEIDENHAIN direct linear measuring systems, resolution 0.001 mm • Positioning accuracy 0.02 mm, repeatability 0.005 mm • Horizontal milling unit, console, and end support • Chip tray, blue RAL 5019 • Painted blue RAL 5019, grey RAL 7035 • 1 operating manual • 1 CD with TNC 128 programming instructions • 1 inspection protocol and basic circuit diagram • 1 oil hand press • With counter bearing, running bushing ø 16 mm (slide bearing) for milling arbor length 230 mm • Machine lamp • Chip guard (required safety device according to EN 13128 for EU countries) Bwedpfxox H Nw So Aqtet

Stanje: rabljeno, Leto izdelave: 1976, x-travel 350 mm y-travel 150 mm z-travel 340 mm Table clamping surface 600 x 210 mm Spindle taper SK 40 Spindle speeds 40 - 2000 rpm Feeds 5 - 500 mm/min Rapid traverse 1.2 m/min Total power requirement 1.9 kW Bwodpfowwwr Eex Aqtet Machine weight approx. 0.7 t - Machine from training workshop - Accessories: fixed table, vertical head with extendable quill, 3-axis HEIDENHAIN digital readout, various short and long arbors, various collets, original DECKEL tool cabinet

Stanje: rabljeno, Leto izdelave: 1989, X-axis travel: 350 mm y-axis travel: 200 mm z-axis travel: 350 mm Table clamping surface: 700 x 280 mm Spindle taper: SK 40 Spindle speeds: 150 - 1660 rpm Feed rates: 25 - 285 mm/min Rapid traverse: 1 m/min Quill stroke: 80 mm Head swivels: +/- 45° Total power requirement: 3 kW Machine weight: approx. 1.2 t Bodpfx Aqsvzhidjtewt Machine dimensions (L x W x H): 1.27 x 1.1 x 1.65 m Accessories: swivelling vertical head with extendable quill, fixed table, universal table, rotary indexing table 250 mm diameter, dividing head with 3-jaw chuck 135 mm diameter, tailstock, various milling arbors, drill chuck, coolant system

Stanje: dober (rabljeno), 1 used universal tool milling machine Make: Deckel Model: FP 1 Year of manufacture: 1982 Technical specifications: X-axis travel: 300 mm Y-axis travel: 160 mm Z-axis travel: 340 mm Spindle taper: SK 40 Bwedpfxern I Rzj Aqtot Table size: 600 x 210 mm Spindle speeds: 40–2000 rpm Machine weight approx.: 1 t Space requirement approx.: 1.6 x 1.3 x 1.8 m

Stanje: rabljeno, Leto izdelave: 1978, X-travel 300 mm y-travel 160 mm z-travel 340 mm Clamping surface of table 600 x 210 mm Spindle taper SK 40 Spindle speeds 40 - 2000 rpm Bwsdpfxowl N R No Aqtst Feeds 5 - 500 mm/min Rapid traverse 1.2 m/min Total power requirement 1.9 kW Machine weight approx. 0.7 t - Machine from training workshop - Accessories: fixed table, vertical head with extendable quill, digital readout on 3 axes HEIDENHAIN, counter bearing, various short and long milling arbors, various collets, original DECKEL tool cabinet

Stanje: delavnici obnovljeno (rabljeno), Univerzalni orodjarski rezkalni stroj Znamka: harich (DECKEL) Model: A (FP 1) Prenovljen s CE Geometrijski prevzem s preizkusnim protokolom Z garancijo Dodatna oprema: Bedodvdc Ijpfx Aqtowt - 3-osni digitalni prikaz FAGOR Innova 30i-M - Fiksna ali univerzalna miza - Vertikalna rezkalna glava SK 40 - Naprava za hlajenje - Navodila za uporabo CE in varnostna oprema: - Nova strojna elektrika s krmilno omarico - Elektronsko nadzorovan pokrov na vertikalni rezkalni glavi - Zaščitni pokrov vpenjala z električnim varovanjem - Pogonski motor z zavorno funkcijo - Kontrolna plošča z gumbom za nujno ustavitev, sprostitev, zagon in ustavitev - Nova dokumentacija za stroj in krmilno omarico - Izjava o skladnosti CE

Stanje: dober (rabljeno), Funkcionalnost: popolnoma funkcionalen, dolžina podajanja os X: 300 mm, dolžina pomika po osi Y: 160 mm, dolžina podajanja os Z: 340 mm, For sale: Conventional milling machine from Deckel, model FP1 Due to the compact size of the machine, it is ideal for quick jobs in areas with limited space. The machine is fully functional. Technical data: Travel (X-axis): 300 mm Travel (Y-axis): 160 mm Travel (Z-axis): 340 mm Tool holder: SK40 Spindle speed: 40–2000 rpm Control: Conventional Table size: 600 x 210 mm Total power requirement: 2 kW Machine weight: approx. 0.73 t Required space (LxWxH): approx. 1200 x 1100 x 1600 mm Bwedpougv Hvjfx Aqtjt Loading and shipping can be organized Europe-wide upon request. Prices are quoted excluding VAT. Inspection possible by appointment. Please contact us—our team looks forward to assisting you. Trade-in or exchange possible! Machinery purchase & sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES, AND MORE Do you require a high-quality yet affordable metalworking machine for your production? Or are you looking to sell your own machine? For further information or contact options, please visit our website.

Stanje: delavnici obnovljeno (rabljeno), Leto izdelave: 1987, Universal milling machine Brand: DECKEL Model: FP 1 Aktiv Year of manufacture: 1987 – overhauled, newly painted, RAL 7035 light grey / RAL 7012 basalt grey Machine no.: 2102-3429 with warranty geometric inspection with test report Bsdpfxjhtrd Ie Aqtjwt Accessories: - 3-axis digital readout HEIDENHAIN TNC 113 with active function for X, Y, and Z axes - Fixed table 600 x 210 mm (T-slot: 12 mm) - Vertical milling head SK 40 with drawbar thread S 20 x 2 - Coolant system - Centralized lubrication, electric - Operating manual - used, as seen -

Stanje: rabljeno, Leto izdelave: 1982, x-travel: 300 mm y-travel: 160 mm z-travel: 340 mm Infinitely variable feeds: 5–500 mm/min Rapid traverse: 1,200 mm/min Spindle speeds: 40 – 2,000 rpm Tool holder: Standard taper 40 Table length: 600 mm Table width: 120 mm Operating voltage: 380 V Frequency: 50 Hz Rated current: 13 A Machine weight approx.: 0.75 t Space required approx.: 1.8 x 1.5 x 1.8 m DESCRIPTION Machine includes: Active 3-axis digital readout HEIDENHAIN Documentation Bwodpfx Aqjvvnfuotjt (Measuring) jaws Vice, etc.

Stanje: rabljeno, Univerzalna rezkalna stroj z aktivnim digitalnim prikazom DECKEL tip FP 1 Univerzalni rezkalni stroj Št. stroja: 2102 - 3351 Letnik: 1986 Hodi poti X: 300 mm Y: 150 mm Z: 330 mm Velikost mize: 600 x 210 mm Vretena pritrditev: SK 40 - S20x2 Hitrost vretena: 40-2000 vrt/min, 16 stopenj Podajalna hitrost: 5 do 500 mm/min Hitri prehod: 1200 mm/min Moč motorja: 1,6 in 2 kW, sprememba števila polov Napajanje: 380 V, 50 Hz - Aktivni digitalni prikaz za 3 osi HEIDENHAIN tip TNC 113 - Brezstopenjsko podajanje preko servomotorja v osi X, Y in Z - Hitrost vretena preko 2 hitrosti motorja in 8 stopenj menjalnika - Pinolni pomik na navpični rezkalni glavi 60 mm - Navpična rezkalna glava nagibna in 100 mm vodoravno izvlečna - Fiksna kotna miza 600 x 210 mm - Hladilna naprava v osnovi stroja Bsdpfx Aqjyxy Swotswt - Samostojna elektro omara - Originalna posoda za ostružke za montažo na osnovo stroja - Navodila za uporabo, elektro shema, seznam rezervnih delov v PDF formatu Potreben prostor D x Š x V: 1350 x 1100 x 1700 mm Teža: 830 kg V dobrem stanju

Stanje: generalkompletno obnovljen (rabljeno), Leto izdelave: 1978, Universal tool milling machine Make: DECKEL Model: FP 1 with infinitely variable feed Year of manufacture: approx. 1975 – partially overhauled, newly painted, RAL7035 light grey / RAL7012 basalt grey / RAL5012 light blue with warranty Bwsdpfodf E H Aox Aqtst Geometric acceptance with test protocol Accessories: - 3-axis digital readout FAGOR Innova 30i-M, new - Fixed table 600 x 250 mm (T-slot: 12 mm) - Vertical milling head ISO 40 with drawbar thread S 20 x 2 - Coolant device - Operating manual - used, as seen -

Stanje: rabljeno, x-travel 700 mm y-travel 250 mm z-travel 300 mm Table size 1000 x 230 mm Spindle taper ISO 40 Spindle speeds 35–1500 rpm Total power requirement 3.0 kW Machine weight approx. 1.4 t Dimensions (L x W x H) 1.55 x 1.4 x 1.65 m Universal milling machine Bwodpov T Nqyefx Aqtst - Huron-type head - Mounting fixture for Huron head - Horizontal steady rest - Documentation - Coolant system - Machine feet

Stanje: rabljeno, Leto izdelave: 1989, x-hod 600 mm Bwedpfjy Nnw Nex Aqtot y-hod 450 mm z-hod 400 mm Velikost mize 850 x 440 mm Vreteno SK 40 Krmiljenje HEIDENHAIN TNC 355 Menjalnik orodij 32 pozicij Hitrosti vretena 20 - 4000 obr/min Moč motorja vretena 5,9 kW Hod vretena 80 mm Pomiki - vzdolžno/prečno/navpično 1 - 2000 mm/min Sila podajanja x/y/z 7200 N Hitri hod vzdolžni in prečni 10 m/min Hitri hod navpični 10 m/min Skupna potrebna moč 12 kW Teža stroja cca 3 t Pribor: NC-delilna glava (=4. os) proizvajalca WALTER s 3-čeljustnim vpenjalom premera 160 mm, nagibna vertikalna glava z hidravličnim vpenjalnikom orodij in izvlečno pinolo, fiksna miza, različni držalci orodij, elektronski ročni upravljalec, naprava za hlajenje.
