Univerzalne konvencionalne rezkalne stroje za orodja, X-hod 0–399 mm nakup rabljenega (140)

Stanje: dober (rabljeno), Leto izdelave: 1995, Macmon M 100 E universal milling machine with 3-axis Elesta-Heidenhain digital readout from a training department. Fixed table, SK 40 spindle taper. Good, ready-to-use condition; can be demonstrated under power by arrangement. Tsdpfxev Azb Ns Anpsd

Stanje: rabljeno, Leto izdelave: 1970, Pokrov FP1, strojna orodna frezalna naprava Strojna orodna frezalna naprava, proizvajalec Deckel Tip/model: FP1 Stanje: rabljeno Leta 2026 geometrijsko obnovljeno, na voljo je geometrijski protokol Letnik: približno 1970 Naprava je bila v celoti razstavljena, temeljito očiščena, geometrijsko obnovljena in ponovno prebarvana. Nato je bila strokovno ponovno sestavljena in opravljeno celovito funkcionalno testiranje. Geometrija naprave je bila preverjena in nastavljena. Na voljo je protokol testiranja v skladu s standardom DIN 8615. Med deli so bili tudi nastavljeni klinasti trakovi in obnovljena črpalka za hladilno tekočino. Tehnični podatki Poti gibanja X/Y/Z: 300 / 150 / 340 mm Hod vretena: 60 mm, navpično Tjdez A Tn Iepfx Anped Vpenjalna konica: MK 4 Območje hitrosti vrtenja: 40 do 2.000 1/min, dvostopenjski motor, prestave Stopnje hitrosti vrtenja: 16 hitrosti Podajanje v 16 stopnjah: 10 do 500 mm/min Moč pogona: dvostopenjski motor, približno 1,0 / 1,4 kW Napetost: 380 V / 50 Hz Skupna priključna moč: približno 1,9 kW Površina za pritrditev: 600 x 210 mm Maksimalna obremenitev mize: približno 150 kg Potreba prostora (ŠxVxG): približno 1.100 x 1.000 x 1.500 mm Teža: približno 750 kg Predmet povpraševanja: stroški transporta v individualni ponudbi.

Stanje: zelo dobro (rabljeno), Funkcionalnost: popolnoma funkcionalen, Oprema: dokumentacija / priročnik, Universal milling machine Deckel FP1 with 3-axis digital readout RSF 2006 Complete Overhaul - TOP Condition Technical Data: >> Machine No. 53819/08 >> Fixed angle table Tjdpfx Anevb Ud Uepsd >> Spindle speed: 40 - 2000 rpm >> Power feed on 2 axes >> Drive power: 1 / 1.5 kW >> Travel X/Y/Z: 300/150/340 mm >> Vertical and horizontal quill - SK40 >> Spindle brake >> Drawbar type: S20x2 >> Weight approx. 700 kg Accessories and Equipment: >> 3-axis digital readout by RSF Elektronik >> Coolant system >> Machine feet About the machine: For sale is a Deckel FP1 universal milling machine in very good condition. The Deckel has very little backlash and all feed screws run smoothly. An oil change was performed. The FP1 underwent a complete overhaul by Huttelmaier in 2006 and has been used only sparingly since then. The RSF digital readout makes operation easier and even more precise. Take the opportunity to inspect and test-run this machine under power on site.

Stanje: dober (rabljeno), Leto izdelave: 1988, Deckel FP1 Aktiv with 3-axis Heidenhain digital readout, fixed table, SK 40 spindle taper, S20x2 spindle mount. Good, ready-to-use condition; can be demonstrated under power by prior arrangement. Tsdpfx Anork Aaajped

Stanje: rabljeno, Univerzalni rezkalni stroj DECKEL FP1 Pomik X: 300 mm Pomik Y: 150 mm Pomik Z: 300 mm Horizontalno + vertikalno vreteno Stožec CM4 DECKEL Hitrost vretena: od 40 do 2000 vrt/min Glava nagibna v vodoravni smeri Vreteniški motor: 2 hitrosti Motor: 1,5 kW Podajalniki: X - Z avtomatski / Y ročni Dobavljeno brez mize, samo z enim univerzalnim vpenjalom s 4 so-koncentričnimi čeljustmi Ø 140 mm Napetost: 380 V Širina: 1200 mm Globina: 1200 mm Skupna višina: 1600 mm Teža: cca 900 kg Tsdpfsz Nx Axsx Anpod

Stanje: zelo dobro (rabljeno), Funkcionalnost: popolnoma funkcionalen, Universal Milling Machine Deckel FP1 with 3-axis Heidenhain Digital Readout, Original Condition!!! Technical Data: >> Machine No. 56560/08, year of manufacture approx. 1975 >> Fixed angle table >> Spindle speed: 40 - 2000 rpm >> Feed on 2 axes >> Drive power: 1 / 1.5 kW >> Travel X/Y/Z: 300/150/340 mm >> Vertical quill SK40 and horizontal quill SK40 >> Drawbar system: S20x2 >> Weight approx. 700 kg Ecvf9Jfv9 Accessories and Equipment: >> 3-axis Heidenhain digital readout >> Coolant system About the machine: Tedpsu Nvxmjfx Anpsd Offered here is a universal milling machine Deckel FP1 in very good original condition. The Deckel has minimal backlash in the handwheels and all spindles move smoothly. An oil change has been carried out. Mechanically and electrically checked. The Heidenhain digital readout makes operation easier and even more precise. Take the opportunity to view and test the Deckel under power on site.

Stanje: dober (rabljeno), Leto izdelave: 1990, 1 rabljena univerzalna orodna frezalna strojna oprema Proizvajalec Deckel, tip FP 5 CC Letnik izdelave 1990 Nadzorni sistem Dialog 11 Hod v smeri osi X: 800 mm Hod v smeri osi Y: 600 mm Hod v smeri osi Z: 550 mm Število vrtljajev vretena: 25–6.300 vrt/min Tedpfx Anoz S Ubcjpsd Nastavek za orodje: SK 40 Moč pogona: približno 12 kW Masa stroja: približno 5000 kg

Stanje: zelo dobro (rabljeno), Leto izdelave: 1984, Funkcionalnost: popolnoma funkcionalen, Oprema: dokumentacija / priročnik, Universal milling machine Deckel FP1 with 3-axis active digital display TNC 113 Heidenhain and infinitely variable feed – Excellent CONDITION Technical Data: >> Year of manufacture: 1984 Machine no.: 2102-2601 >> Swivelling, tilting, and rotating table >> Spindle speed: 40 – 2000 rpm >> Infinitely variable feed on 3 axes >> Rapid traverse on 3 axes >> Drive power: 1.5 / 1.9 kW Todpfju Racrox Anpod >> Spindle brake >> Travel X/Y/Z: 300/160/340 mm >> Vertical milling head adjustable on spindle carrier by 100 mm >> Vertical and horizontal quill – SK40 >> Draw-in system S20x2 >> Weight: approx. 800 kg Accessories and Features: >> 3-axis digital display Heidenhain TNC113 >> Coolant system >> Operating manual, spare parts list About the machine: Offered is a universal milling machine Deckel FP1, year 1984, in excellent condition. The machine has very little backlash and all lead screws move smoothly. Even at maximum spindle speeds, the milling machine runs very quietly. This newer FP1 model features infinitely variable feed on all three axes and also has rapid traverse in these axes. A major advantage is the active 3-axis digital readout. With this Heidenhain control, you can enter measurements that the machine will approach automatically. The FP1 was housed in a training workshop and was only occasionally used. An oil change has been carried out. The machine has been mechanically and electrically inspected. The Heidenhain digital readout makes operation easier and even more precise. Take the opportunity to view and test the machine under power on site.

Stanje: zelo dobro (rabljeno), Funkcionalnost: popolnoma funkcionalen, Univerzalna frezalna strojnica Deckel FP1 s 3-osnim aktivnim digitalnim prikazovalnikom TNC 113 Heidenhain in brezstopenjskim podajanjem, v zelo dobrem STANJU, z dodatno opremo, v skladu s standardi CE. Tehnični podatki: >> Letnik izdelave 1992, številka stroja 2102-7007 >> Fiksna nagibna miza >> Število vrtljajev: 40 - 2000 vrt/min >> Brezstopenjsko podajanje v 3 osi >> Hitri hod v 3 osi >> Moč pogona: 1,5 / 1,9 kW Tedpfx Anszl Ebbeped >> Zavora vretena >> Hodi osi X/Y/Z: 300/160/340 mm >> Navpična frezalna glava, pomična za 100 mm na nosilcu vretena >> Vertikalni in horizontalni konus - SK40 >> Sistem vpenjanja M16 >> Teža približno 800 kg Dodatna oprema in izvedba: >> 3-osni digitalni prikazovalnik Heidenhain TNC113 >> Sistem za hlajenje >> Strojniška luč >> Navodila za uporabo, seznam rezervnih delov >> Vpenjalne glave za orodja, strojna sponka, protinadzorni element O stroju: Ponujamo univerzalno frezalno strojnico Deckel FP1 v zelo dobrem stanju, v skladu s standardi CE. Stroj ima zelo malo zračnosti in vsa vretena se enostavno premikajo. Tudi pri najvišjih obratih stroj deluje zelo mirno. Posebnost je, da je omarica stroja povezana z vtičnico. To olajša tudi transport stroja. Pri tem novejšem modelu FP1 je podajanje v treh osi brezstopenjsko nastavljivo, poleg tega ima stroj hitri hod v teh osi. Velika prednost je aktivni 3-osni digitalni prikazovalnik. S tem Heidenhainovim sistemom numeričnega nadzora lahko vnesete mere, na katere se bo stroj samodejno nastavil. FP1 je bila v izobraževalnem podjetju, kjer so jo uporabljali le občasno. Izvedena je bila menjava olja. Stroj je bil mehansko in električno preverjen. Zahvaljujoč digitalnemu prikazovalniku Heidenhain je delo lažje in še natančnejše. Izkoristite priložnost in si oglejte in preizkusite ta stroj na licu mesta.

Stanje: zelo dobro (rabljeno), Funkcionalnost: popolnoma funkcionalen, Univerzalni rezkalni stroj Deckel FP1 z digitalnim prikazovalnikom za 3 osi K&C, brezstopenjska podaja, svetlo siva barva, v skladu s standardi CE, odlično stanje. Tehnični podatki: >> Letnik proizvodnje 1980, št. stroja 2101-1423 >> Trdna nagibna miza >> Število vrtljajev: 40 - 2000 vrt/min >> Brezstopenjska podaja po dveh osi >> Moč pogona: 1,5 / 1,9 kW >> Zavora vretena >> Hitri hod >> Hodi po osi X/Y/Z: 300/160/340 mm >> Navpična rezkalna glava, pomična po nosilcu vretena (100 mm) >> Navpični in vodoravni vpenjalni stožci - SK40 >> Sistem vpenjanja M16 >> Teža približno 700 kg Dodatna oprema in izvedba: >> Digitalni prikazovalnik za 3 osi K&C, novo nameščen z garancijo proizvajalca in navodilom za uporabo. Prikazovalnik: nastavljanje referenčnih in nulnih točk, vnašanje koordinat, preklapljanje med mm in palci, absolutne ali inkrementalne koordinate, funkcijo kroga, vrstice lukenj, funkcije rezkanja po krogu itd. >> Sistem za hlajenje >> Luč za stroj >> Navodila za uporabo, seznam rezervnih delov >> Vpenjalne priprave, primež, proti-primež Tedpfx Aozl Uz Denpod O stroju: Ponujamo univerzalen rezkalni stroj Deckel FP1, v skladu s standardi CE, v zelo dobrem stanju. Stroj ima zelo malo zračnosti in vsa vretena se lahko premikajo z lahkoto. Vsi zložljivi pokrovi so novi. Pri tem novejšem modelu FP1 je podaja po dveh osi brezstopenjsko nastavljiva, stroj pa ima tudi hitri hod. Izvedena je bila menjava olja. Stroj je bil mehansko in električno pregledan. Nova digitalna enota podjetja K&C olajša delo in omogoča še natančnejše rezultate. Izkoristite priložnost in stroj oglejte ter preizkusite na licu mesta.

Stanje: rabljeno, Weight approx.: 450 kg Dimensions (LxWxH): 1250 x 1350 x 1550 mm Y-travel: 300 mm Tedpfxsrgvbpe Anpsd Z-travel: 200 mm X-travel: 350 mm Speed range: 80–2200 rpm Table size: 600 x 200 mm Description: - Coolant system - Machine lamp - Including machine vise Speeds: 80 – 2200 (8) rpm Tool holder: DIN 2078 ISO30 (drawbolt M12) Working area: 300 x 200 x 350 mm Table: 600 x 200 mm Rapid traverse X/Y: 1200 mm/min Quill stroke: 45 mm Max. feed force: 1600 Nm Spindle motor: 1.1 / 1.4 kW Vertical table: 600 x 200 mm Distance vertical milling spindle – milling table: 20 – 370 mm Distance horizontal milling spindle – milling table: 84 – 434 mm Feed in X axis (stepless): 20 – 200 mm/min Length: 1250 mm Width: 1350 mm Height: 1550 mm Weight: 450 kg

Stanje: dober (rabljeno), x-hod 300 mm y-hod 160 mm z-hod 360 mm Skupna potrebna moč 1 kW Teža stroja cca 0,8 t Tedpfx Ajw U Shhjnpjd različni kompleti za graviranje

Stanje: dober (rabljeno), Leto izdelave: 1990, Macmon M 100 E universal milling machine with 2-axis Elesta-Heidenhain digital readout, from a training department. Features a fixed table and SK 40 spindle taper. The machine is in good, ready-to-use condition and can be demonstrated under power by arrangement. Tedpfx Anjrazzrepsd

Stanje: zelo dobro (rabljeno), Leto izdelave: 1987, obratovalne ure: 800 h, Stroj za obdelavo površin s frézo, model FP 5 A Contour 3, v odličnem stanju, z veliko dodatno opremo, zadnjih 20 let ni bil v uporabi. Tjdpfx Anjz Afdwjpjd

Stanje: zelo dobro (rabljeno), Deckel FP1 AKTIV (3-Axis Aktiv) Machine No.: 2102-3240 Year of manufacture: approx. 1988 Travel distances: X: 300 mm Y: 150 mm Z: 330 mm Table size: 600 x 210 mm Spindle taper: SK 40 - S20x2 Spindle speed: 40-2000 rpm Motor power: 1.6 and 2 kW Power supply: 380 Volt, 50 Hz Equipment/Accessories: - Heidenhain 3-axis Aktiv digital display, Type TNC 113 - Infinitely variable feed on X, Y and Z axes - Quill travel on vertical milling head: 60 mm - Vertical milling head tiltable and extendable 100 mm horizontally - Coolant system (coolant tank in machine base) - Documentation - Centralized lubrication - Machine vise - Various tool holders/collets/tools Required installation space (L x W x H): 1350 x 1100 x 1700 mm Weight: 850 kg The machine has been cosmetically refurbished and technically inspected. Videos showing the geometry can be provided upon request. Backlash Y-axis: 0.1mm Backlash X-axis: 0.2mm Backlash Z-axis: 0.15mm Runout horizontal spindle: 0.001mm Runout vertical spindle: 0.001mm Deviation parallelism Y-axis: 0.002mm (measuring length 150mm) Deviation parallelism X-axis: 0.01mm (measuring length 300mm) Videos demonstrating the geometry measurement can be provided upon request. The following parts have been renewed: - Gears in the horizontal head replaced and gear shaft newly mounted - New guide cover Z-axis + various add-on parts - Machine reconditioned - New LEDs installed - Y-axis chain tensioner overhauled Tsdpfx Aoyll A Tjnpsd - Reference point programming checked - Function test carried out

Stanje: dober (rabljeno), Leto izdelave: 1981, Deckel FP1 Aktiv with 3-axis Heidenhain digital readout, 2 active axes, fixed table, SK 40 spindle taper, S20x2 spindle mounting. Good, fully operational condition; can be demonstrated under power by prior arrangement. Tjdpfx Ajuvgnqenpod

Stanje: zelo dobro (rabljeno), Leto izdelave: 2001, Orodni rezkalni stroj Macmon M 100 NC Tedsx Hga Depfx Anped Hitrost brezstopenjsko nastavljiva, Vpenjalni stožec SK 40 Sistem za hlajenje Navodila za uporabo

Stanje: dober (rabljeno), Leto izdelave: 1980, Deckel FP1 Aktiv with 3-axis Heidenhain digital readout, 2 active axes, fixed table, SK 40 spindle taper, S20x2 spindle mounting. Good, fully operational condition; can be demonstrated under power by prior arrangement. Todpsumcmqefx Anpsd

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2019, A Deckel FP2 universal tool milling machine, completely overhauled in 2019, is available. Travel range X/Y/Z: 400mm/200mm/400mm, table dimensions X/Y: 700mm/330mm, spindle speed: 2000 rpm, tool holder: SK40, machine dimensions X/Y/Z: approx. 1600mm/1400mm/1600mm, weight: approx. 1250kg. An on-site inspection is possible. Tjdpfx Aevf Iy Denpjd

Stanje: zelo dobro (rabljeno), Funkcionalnost: popolnoma funkcionalen, Universal Milling Machine Deckel FP1 with 3-Axis Heidenhain TNC 113 Digital Readout and Infinitely Variable Feed – Excellent Condition, CE Compliant Technical Data: - Year of manufacture: 1990 Machine no.: 2102-5046 - Fixed angle table - Spindle speed: 40 – 2000 rpm - Infinitely variable feed in 3 axes - Rapid traverse in 3 axes - Drive power: 1.5 / 1.9 kW - Spindle brake Todpfszbb E Aox Anpsd - Travel (X/Y/Z): 300/160/340 mm - Vertical milling head adjustable on spindle carrier by 100mm - Vertical quill and horizontal quill – SK40 - Drawbar system S20x2 - Weight: approx. 800 kg Accessories and Equipment: - 3-Axis Heidenhain TNC 113 Digital Readout - Coolant system - Machine lamp - Operating manual & spare parts list About the machine: Offered here is a universal milling machine Deckel FP1, CE compliant and in excellent condition. The machine has very little backlash and all spindles move smoothly. Even at maximum speeds, the milling machine runs very quietly. On this newer FP1 model, the feed is infinitely variable in all three axes, and rapid traverse is also available on them. A major advantage is the active 3-axis digital readout. With the Heidenhain TNC 113 control, you can input dimensions and let the machine automatically travel to those positions. This FP1 was used in a training workshop and was only operated occasionally. Oil has been changed. The machine has been mechanically and electrically tested. The Heidenhain digital readout makes working easier and more precise. Take the opportunity to inspect and test the machine on site under power.

Stanje: dober (rabljeno), Deckel FP1 frezarka, wyprodukowana w Niemczech przez Friedrich Deckel AG, Monachium. Maszyna jest sprawna i w pełni operacyjna. Tsdpsw Amaisfx Anped W celu uzyskania dodatkowych informacji prosimy o kontakt.

Stanje: delavnici obnovljeno (rabljeno), Leto izdelave: 1984, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 300 mm, pomik osi Y: 150 mm, pomik po osi Z: 340 mm, poteza s peresom: 80 mm, največja hitrost vretena: 2.000 obr/min, hitrost vretena (min.): 40 obr/min, dolžina mize: 210 mm, širina mize: 600 mm, skupna višina: 1.750 mm, skupna dolžina: 1.400 mm, skupna širina: 1.600 mm, največja hitrost vrtenja: 2.000 obr/min, vrtljajska hitrost (min.): 40 obr/min, skupna masa: 850 kg, obremenitev mize: 200 kg, trajanje garancije: 3 meseci, Stroj bol v roku 2026 nami dielňou kompletne/čiastočne repasovaný a je vo výbornom stave. Počas čiastočnej repasácie bol nainštalovaný nový brzdový motor. Ovládanie 3-osové aktívne digitálne odčítavanie HEIDENHAIN TNC 113 Otáčky 40–2000 ot./min, geometricky stupňovaná priama prevodovka s 18 rýchlostnými stupňami pre maximálny krútiaci moment/frézovací výkon Posuv 5 až 500 mm/min, plynulo nastaviteľný Rýchloposuv 1,2 m/min Tsdpeyi Amwsfx Anpjd Pinola Výsuvná pinola, vertikálne 80 mm, SK40 s upínacím závitom M16, voliteľne: so závitom na pílu DECKEL S20 x 2 Výsuvná pinola horizontálne cca 100 mm Osi X/Y/Z 300/150/340 mm Stôl Pevný uhlový stôl 600 x 210 mm Maximálne zaťaženie stola 200 kg Vybavenie • Vertikálne a horizontálne vreteno • Frézovacia hlava manuálne naklápateľná +/- 90° • Harmonikový kryt osi Z Voliteľné príslušenstvo • Vanička na triesky • Pracovné osvetlenie • Univerzálny stôl • Otočný stôl • Dlabací nadstavec • Deliaca hlava • Protiľahlý držiak • atď.

Stanje: rabljeno, Universal tool milling machine DECKEL Type FP 1 Universal milling machine Machine No. 2101 - Year of manufacture: 1979 Manual travel X: 300 mm | Y: 160 mm | Z: 330 mm Table size: 600 x 210 mm Spindle mounting: SK 40 - S20x2 Spindle speed: 40-2000 rpm, 16 steps Feed on X and Y axes: 5 to 500 mm/min. Rapid traverse: 1200 mm/min. Tjdpsr U St Uefx Anped Motor power: 1.5 and 1.9 kW, pole-changeable Power supply: 380 Volt, 50 Hz - Infinitely variable feed in X and Z axes - Spindle speed via 2 motor speeds and 8 gear steps - Quill travel on the vertical milling head: 60 mm - Vertical milling head tiltable and extendable horizontally by 100 mm - Fixed angle table, 600 x 210 mm - Coolant system integrated in the machine base - Separate control cabinet included - Original chip tray for installation on machine base - Electrical diagrams included Required space (L x W x H): 1350 x 1100 x 1700 mm Weight: 770 kg Good condition

Leto izdelave: 1997, stanje: dober (rabljeno), Macmon M 100 RE tool milling machine with 3-axis Heidenhain digital readout from the training department, rigid table, SK 40 spindle taper. Accessories: electric spindle guard, various collets and milling arbors. Good, ready-to-use condition, can be demonstrated under power by appointment. Tsdpfshgmmzsx Anpod

Stanje: rabljeno, Leto izdelave: 1998, STIMIN Oradea FUS-22-2M, univerzalni stroj za obdelavo z orodjem Univerzalni stroj za obdelavo z orodjem STIMIN Oradea Tjdpezxhndsfx Anpsd Tip/model: FUS-22-2M Stanje: Rabljen Letnik: 1998 Tehnični podatki: Gib X-osi: 300 – 320 mm Gib Y-osi: 240 – 270 mm Gib Z-osi: 300 – 310 mm Vpenjalna glava: SK 40 / ISO 40 Število vrtljajev vretena: 45 – 2.240 1/min (v 18 stopnjah) Hod vretena: 60 mm (ročno nastavljivo) Površina za vpenjanje: 670 x 320 mm Maksimalna obremenitev mize: pribl. 75 – 150 kg (odvisno od izvedbe mize) Podi (X/Y/Z): 12,5 – 630 mm/min Hitri pod: pribl. 1.200 mm/min Moč motorja vretena: 1,5 kW – 2,0 kW Skupna priključna moč: pribl. 2,5 – 3,0 kW (400 V / 50 Hz) Potreben prostor (D x Š x V): pribl. 1.200 x 1.100 x 1.620 mm Artikl po povpraševanju: Stroški transporta v individualni ponudbi.
