Univerzalne konvencionalne rezkalne stroje za orodja, X-hod 0–399 mm nakup rabljenega (117)

Stanje: dober (rabljeno), Leto izdelave: 1980, Deckel FP1 Aktiv with 3-axis Heidenhain digital readout, 2 active axes, fixed table, SK 40 spindle taper, S20x2 spindle mounting. Good, fully operational condition; can be demonstrated under power by prior arrangement. Dedpoumcmqsfx Afqocr

Stanje: dober (rabljeno), Leto izdelave: 1980, številka stroja/vozila: 4038, potovalna razdalja osi X: 290 mm, pomik osi Y: 150 mm, pomik po osi Z: 330 mm, montažni premer: 40 mm, dolžina mize: 600 mm, širina mize: 210 mm, največja hitrost vrtenja: 2.000 obr/min, vrtljajska hitrost (min.): 40 obr/min, skupna masa: 700 kg, CONDITION & NOTES: Dodewxpxmspfx Afqjcr - This is an active path-controlled tool milling machine

Stanje: novo, Technical data: Fixed angle table: Clamping surface of the fixed angle table: 800 x 400 mm Max. table load: 200 kg Working spindle: Tool holder horizontal and vertical: ISO 40 Main drive motor power / 100% duty cycle: 2.2 kW Vertical milling head: Spindle speed range, stepped: (12) 50 - 2000 rpm Quill stroke: 100 mm Swivel range: +/- 90° Travel: X-axis automatic/manual: 385/400 mm Y-axis automatic/manual: 185/200 mm Z-axis automatic/manual: 365/380 mm Feeds: Dcjdped R S Ndefx Afqsr Feed range: 0-650 mm/min Number of feeds: infinitely variable Rapid traverse: 1000 mm/min Features: - Machine accuracy according to DIN 8615 - 3-axis digital readouts FAGOR® Innova (option) - Spindle run-out max. 0.005 mm, incl. inspection record according to DIN 8615 (roller bearings by SKF®/NSK®) - Vertical milling head can be swivelled out for horizontal milling (without disassembly) - All critical machine components, e.g. machine base, table, milling head, housing etc., are made from stress-relieved MEEHANITE® quality cast iron (FC 30), heavily ribbed to provide maximum stability and working accuracy. All guideways are coated with TURCITE®-B - All machined surfaces in the work area, such as ways, table surfaces, T-slots, etc., are hardened and precision ground - The powerful drive transmits the main motor's power via belt to the gearbox - All axes have their own DC servo motors, allowing sensitive, infinitely variable adjustment of feed speed Standard equipment: - DC servo motors for all X/Y/Z axes, incl. electromagnetic brake - Rigid box table - Original Ganter Norm® safety handwheels - Chip collecting tray - Backlash-free HIWIN® precision ball screws on all X/Y/Z axes - Main spindle gear transmission - Safety devices according to CE or better: - Spindle guard with multiple micro limit switches, adjustable (enclosure available as an option) - Two emergency stop buttons (1 x machine base, 1 x control panel) - Mechanical Ganter Norm® safety handwheels on all axes - Electromagnetic spindle brake (for immediate spindle stop) - Electrical overload protection for all axes - Electrical equipment by SIEMENS®, BALLUFF® - Brake system prevents table from dropping - Three reducer sleeves SK 40 to MK 1, 2, 3 - Collet chuck with holder to DIN 2080 incl. collet set (Ø 6, 8, 10, 12, 16, 20, 25 mm) - Drawbar - Horizontal milling arbor (Ø27 mm) - Automatic central lubrication - Stainless steel telescopic cover for Z-axis guideway in working area - Machine lamp - Coolant system integrated in machine base - Inspection record according to DIN 8615 - Operating tools - Machine according to CE - Operating manual, spare parts list, including electrical diagrams, etc.

Stanje: pripravljen za uporabo (rabljen), Deckel FP 1 Milling Machine Travel distance X-axis: 300 mm Travel distance Y-axis: 160 mm Travel distance Z-axis: 340 mm Spindle taper: SK 40 with drawbar thread Feed X-axis: 290 mm Weight: approx. 940 kg (with pallet) Space requirement: 1300 mm x 1200 mm x 1800 mm (L x W x H) Dimensions with pallet: 1400 mm x 1400 mm x 2000 mm (L x W x H) Dedpfx Afjuvih Heqjcr You are welcome to visit for an inspection. We can also organize affordable shipping for you! You will receive a proper invoice. For foreign customers, a net invoice can also be issued. A valid VAT ID number is required. Subject to prior sale. Visit our shop and check out our other offers as well. The specified company names and trademarks are the property of their respective owners and are used for identification and description purposes only. Deviations from the technical data and errors in the item description can occur and are reserved.

Stanje: dober (rabljeno),

Stanje: dober (rabljeno), Leto izdelave: 1995, Universal tool milling machine Deckel FP 1 – several machines available, see pictures Model: FP 1 3-AXIS Heidenhain digital readout Dcjdpfx Ajtdcfhofqer Price: from €9,500 excl. VAT Technical data: X-travel: 300 mm Y-travel: 150 mm Z-travel: 340 mm Clamping surface: 600 x 210 mm T-slots: 5 T-slot width: 12 mm Spindle speed range (vertical): 250 – 2000 rpm Spindle speed range (horizontal): 40 – 315 rpm Working spindle speed steps: 8 Feed range: 10 – 500 mm/min Feed steps: 8 Quill stroke: 60 mm Spindle taper: SK 40 Dimensions/Weight: 1235 x 1160 x 1800 mm / approx. 800 kg

Leto izdelave: 1976, Stanje: dober (rabljeno), Deckel FP1 tool milling machine, equipped with 3-axis Heidenhain digital readout. The machine was overhauled by FPS several years ago. Features a fixed table and SK 40 spindle taper, both vertical and horizontal. Accessories include various collets and arbor holders, steady rest, and more. The machine is in good, ready-to-use condition; however, the paintwork shows signs of wear. Can be demonstrated under power by prior arrangement. Djdpfxsrhzcue Afqjcr

Stanje: zelo dobro (rabljeno), Leto izdelave: 1992, Funkcionalnost: popolnoma funkcionalen, Oprema: dokumentacija / priročnik, Universal Milling Machine Deckel FP1 with 3-Axis Active Digital Readout TNC 113 Heidenhain and Infinitely Variable Feed, in Excellent Condition, CE Compliant Technical Data: >> Year of manufacture: 1992, Machine No. 2102-6209 >> Fixed angle table (freshly planed) >> Spindle speed: 40 - 2000 rpm >> Infinitely variable feed on 3 axes >> Rapid traverse on 3 axes >> Drive power: 1.5 / 1.9 kW Djdpfxexdi Ive Afqecr >> Spindle brake >> Travel distances X/Y/Z: 300/160/340 mm >> Vertical milling head on spindle slide, adjustable by 100 mm >> Vertical and horizontal quill – SK40 >> Drawbar system M16 >> Weight approx. 800 kg Accessories and Features: >> 3-axis digital display Heidenhain TNC113 >> Coolant system >> Machine lamp >> Operating manual, spare parts list About the Machine: Offered here is a Deckel FP1 universal milling machine, CE compliant, in very good condition. The machine exhibits minimal backlash and all spindles move smoothly. The milling machine operates very quietly even at maximum speeds. A special feature is that the electrical cabinet is connected to the machine via a plug, which makes transportation easier. In this newer FP1 model, the feed on all three axes is infinitely variable, and there is also rapid traverse on these axes. A major advantage is the active 3-axis digital readout. With this Heidenhain positioning control, you can enter the dimensions and the machine will automatically approach them. This FP1 was used in a training workshop and was only occasionally operated. An oil change has been carried out. Mechanically and electrically tested. The Heidenhain digital readout facilitates your work and delivers even higher accuracy. Take advantage of the opportunity to view and test this machine on site under power.

Stanje: dober (rabljeno), Skladiščna številka: 3010 Proizvajalec: Deckel Številka stroja: 31488 Tip / Model: FP 1 Pomiki x-y-z: 300 - 150 - 340 mm Miza: 600 x 200 mm Območje vrtljajev: 40 do 2.000 obr/min Vreteno: MK 40 Pomiki: 16 do 500 mm/min Priključna moč: 1 / 1,5 kW Dodatki/Oprema: digitalni prikaz Elesta Stanje: dobro Dedpfx Afsw D N Thjqjcr Teža: 0,8 t Dimenzije: 800 x 1.000 x 1.800 mm

Stanje: pripravljen za uporabo (rabljen), Fraiseuse universelle Deckel FP 2 NC TNC 320 / 321 Courses : x - 300 mm | y - 300 mm | z - 400 mm Vitesse en continu : 31,5 - 5000 tr/min Avances : 2-4000/min Avance rapide : 4000/min Porte-outil : SK 40 Course de la broche : 80 mm Poids de la machine : 1350 kg Vous pouvez volontiers venir voir la machine sur place. Nous pouvons organiser pour vous une expédition économique ! Vous recevrez une facture conforme. Pour les clients étrangers, une facture nette peut être établie, à condition d’avoir un numéro de TVA intracommunautaire valide. Sous réserve de vente préalable. Dsdoxfkm Aopfx Afqocr Visitez notre boutique et découvrez également nos autres offres. Les noms des sociétés et les marques mentionnés sont la propriété de leurs détenteurs respectifs et servent uniquement à l’identification et à la description des produits. Des écarts dans les données techniques ou des erreurs dans la description de l’article peuvent survenir et restent réservés.

Stanje: rabljeno, Universal tool milling machine DECKEL Type FP 1 Universal milling machine Machine No. 2101 - Year of manufacture: 1979 Manual travel X: 300 mm | Y: 160 mm | Z: 330 mm Table size: 600 x 210 mm Dsdpfxsr U St Ue Afqecr Spindle mounting: SK 40 - S20x2 Spindle speed: 40-2000 rpm, 16 steps Feed on X and Y axes: 5 to 500 mm/min. Rapid traverse: 1200 mm/min. Motor power: 1.5 and 1.9 kW, pole-changeable Power supply: 380 Volt, 50 Hz - Infinitely variable feed in X and Z axes - Spindle speed via 2 motor speeds and 8 gear steps - Quill travel on the vertical milling head: 60 mm - Vertical milling head tiltable and extendable horizontally by 100 mm - Fixed angle table, 600 x 210 mm - Coolant system integrated in the machine base - Separate control cabinet included - Original chip tray for installation on machine base - Electrical diagrams included Required space (L x W x H): 1350 x 1100 x 1700 mm Weight: 770 kg Good condition

Stanje: dober (rabljeno), Dimenzija mize: cca 600 x 150 mm Dsdsxq Taiopfx Afqecr X/Y/Z pomik: cca 300 / 130 / 300 mm Vpenjanje vretena: W20 Teža: cca 600 kg Gladko gibljive osi, zelo malo zračnosti. Nagibna miza avtomatski pomik po X-osi motorna zavora Število obratov 100 do 2000 min⁻¹ Pozor: Podatki na tej strani so pridobljeni in sestavljeni po najboljših močeh, vendar njihova točnost ni zagotovljena. Zato to ne predstavlja ponudbe ali pogodbe, zato vam priporočamo, da vse pomembne podatke preverite. Finančne informacije DDV/marža: Marža: Prikazana cena je z DDV (DDV ni odbiten za podjetja).

Stanje: dober (rabljeno), Leto izdelave: 1995, Macmon M 100 E universal milling machine with 3-axis Elesta-Heidenhain digital readout from a training department. Fixed table, SK 40 spindle taper. Good, ready-to-use condition; can be demonstrated under power by arrangement. Dsdpfx Aev Azb Nefqjcr

Leto izdelave: 1992, Stanje: novo,

Stanje: dober (rabljeno), Skladiščna številka: 3009 Proizvajalec: Deckel Serijska številka: 37036 Tip / Model: FP 1 Pomiki x-y-z: 300 - 150 - 340 mm Miza: 600 x 200 mm Območje vrtljajev: 40 do 2.000 obr/min Vpenjalni stožec: MK 4 Pomiki: 16 do 500 mm/min Priključek: 1 / 1,5 kW Oprema/dodatki: digitalni prikazovalnik Heidenhain Stanje: dobro Dcsdpfx Afowy Dl Reqsr Teža: 0,8 t Dimenzije: 800 x 1.000 x 1.800 mm

Stanje: zelo dobro (rabljeno), Leto izdelave: 2002, Funkcionalnost: popolnoma funkcionalen, Control: 3-axis active path control, Heidenhain TNC 123 Spindle speed: 40 – 2000 rpm, geometrically stepped direct drive with 16 gear stages for maximum torque/milling performance Feed rate: 5 to 500 mm/min, infinitely variable Rapid traverse: 1.2 m/min Quill: Extendable quill, vertical stroke 60 mm, SK40, M16 drawbolt thread Dcedpjv Nqu Esfx Afqer Axes: X/Y/Z 300/160/340 mm Swivel table: 600 x 210 mm, max. load 200 kg

Stanje: rabljeno, Keyway slotting head, slotting head suitable for milling machine DECKEL Type FP 2 Serial No. 2211 / 1895 Dovetail width: approx. 76 - 88 mm Dovetail height: approx. 14.5 mm Dovetail length: 320 mm Distance from dovetail front edge to centre of gear: approx. 235 mm Stroke length: max. 80 mm Number of strokes: max. 210 double strokes/min Tool holder: square 16 x 16 mm with clamping plate - Stroke length adjustable via eccentric adjustment - Drive from machine gearbox, within dovetail guide (as with the standard vertical head) - This slotting head is inserted into the dovetail guide in place of the standard vertical milling head (installation in place of the vertical head / milling head) - Drive gear in slotting head: 39 teeth, gear width 16 mm, presumably 20° pressure angle - Slotting head can be rotated 360° on the flange plate, angle scale +/- 35° Dcedpfswbi Rbsx Afqor Weight: 32 kg Very good condition DECKEL FP1 has a pressure angle of 15° on the drive gear DECKEL FP2 + FP3 have a pressure angle of 20° on the drive gear

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 1978, številka stroja/vozila: 32392, Table clamping surface: 560 x 240 mm X-axis travel: 300 mm y-axis travel: 275 mm z-axis travel: 200 mm Spindle taper: ISO 40 Spindle speeds: 40 - 2000 rpm Operating voltage: 380 V Total power requirement: 1.1 kW Required space: 1200 x 1100 x 1700 mm Weight: approx. 750 kg Dcodpfx Asd Tfciofqer

Leto izdelave: 1974, Stanje: skoraj kot novo (rabljeno), As-new Deckel FP1 universal milling machine, overhauled by FPS, featuring 3-axis Heidenhain digital readout, adjustable swivel table, and SK 40 spindle taper. Equipped with spindle brake. Accessories include tailstock and various collets. The machine is in excellent, ready-to-operate condition and can be demonstrated under power by arrangement. Djdpfx Aeq A Icqefqscr

Stanje: Okvarjen nosilec rezervnih delov (rabljen), Okvarjen gravirni stroj Deckel Dodpfx Afsw H Rdtjqjcr

Stanje: rabljeno, Leto izdelave: 1980, X-axis travel: 300 mm Y-axis travel: 160 mm Z-axis travel: 340 mm Tool holder: SK40 Spindle speed: 40-2000 rpm Control: Aktiv HEIDENHAIN Table size: 600 x 210 mm Total power requirement: 2 kW Machine weight: approx. 0.73 t Dsdpfew A Ap Hjx Afqscr Space requirements: approx. 1200 x 1100 x 1600 mm (LxWxH) - Power feed in X and Z axes - Röhm vice - Coolant system - Several tool holders and clamping devices - Operating manual

Leto izdelave: 1987, Stanje: dober (rabljeno), Mikron WF2SA tool milling machine with 3-axis Heidenhain Aktiv digital readout. Fixed angle table, SK 40 spindle taper. In operational condition. The machine can be demonstrated under power by prior arrangement. Dcodpoqttt Tjfx Afqsr

Stanje: dober (rabljeno), Leto izdelave: 1989, Deckel FP1 Aktiv with 3-axis Heidenhain digital readout, fixed table, SK 40 M16 spindle taper. Good, operational condition. Can be demonstrated under power by arrangement. Djdetp Nyfepfx Afqscr

Stanje: dober (rabljeno), Leto izdelave: 1981, Deckel FP3L Aktiv with 3-axis Heidenhain Aktiv digital readout, fixed table, vertical milling head, SK 40 spindle taper and S20x2 spindle mount. In good, operational condition. Can be demonstrated under power by prior arrangement. Djdpfxewg S Nkj Afqocr

Stanje: dober (rabljeno), Leto izdelave: 1980, Deckel FP1 Aktiv milling machine with 3-axis Heidenhain digital readout, tilting table. SK 40 spindle taper. Good operational condition, can be demonstrated under power by prior arrangement. Djdpfx Aowg S I Tofqocr
