Pivovarski obrati nakup rabljenega (89)

Stanje: rabljeno, Funkcionalnost: popolnoma funkcionalen, Brewery fermenter in good condition, 1500 hl capacity, 2 units available. Iiedpfx Aswr Ew Eobxsc

Stanje: rabljeno, 2-vessel brewhouse (beraplan, 1997) made of stainless steel, mounted on a stainless steel frame with a working platform. The brewing system consists of the following components: - Mash/wort kettle, steam-heated, equipped with propeller agitator, mash-in nozzle, CIP head, and 4 hop dosing containers. - Lauter tun with slotted, milled false bottom, agitator, spray heads, and spent grain pump - Whirlpool as a freestanding stainless steel tank (gross volume: 48 hl, manufacturer: C. Gresser, 1978) Iedey Tiytspfx Abxsic - Two-stage plate heat exchanger (GEA Ecoflex) as wort cooler with wort aeration - Hydrometer station - Operator console (Siemens) with buttons and screen for visualization of the brewing process - Control cabinet with S5 module and various additional control and regulation elements - Various other pipelines, pumps, valves, measuring and control technology Machine (supplement): Stainless steel brewhouse with a cast wort capacity of 35 hl, year of manufacture approx. 1978 - 1997 Cast wort capacity: 3,500 l Operation / control: Simatic S5-100U Equipment: Mash/wort kettle; lauter tun; whirlpool; wort cooler; wort aeration; hydrometer station; operator console; control cabinet; various pipelines, pumps, valves, measuring and control technology

Leto izdelave: 2007, stanje: rabljeno, Valjasto-konični fermentacijski rezervoar z dvema plaščnima hladilnima conama in eno hladilno cono v stožcu. Stroj (dodatek): pokončen hlajeni rezervoar iz nerjavečega jekla Prostornina: 9.200 l Maks. nadtlak: 1 bar Temperaturno območje: 50 °C Dolžina: 2.000 mm Višina: 4.713 mm Material: nerjavno jeklo 1.4571, 1.4404, 1.4301 Namestitev / pozicija: stoji na 3 nogah Iijdpfx Absy N Edyjxoc Oprema: 2 plaščni hladilni coni, 1 stožčna hladilna cona, nosilec za lestev

Leto izdelave: 1991, stanje: rabljeno, Skladiščni rezervoar, izoliran, izdelan iz nerjavnega jekla, hlajen z glikolom. Stroj (dodatek): dvostenski rezervoar (možna ohladitev) Kapaciteta: 1300 l Širina: 1300 mm Iiedpfx Ajy N Edtsbxjc Višina: 2300 mm Oblika: ploščato-konična Upravljanje / kontrola: ročno Material: nerjavno jeklo 1.4301 Položaj: stoječe Osnovna konstrukcija: na 4 nogah Oprema: dvostenski s popolnim plaščnim hlajenjem, pipica za vzorčenje, priključek za cevovod; Priključki: iztok DN50, hladilna cev DN20

Leto izdelave: 2013, stanje: rabljeno, Complete production and bottling plant from a brewpub, consisting of the following components: 1. Milling section: grist mill with malt intake hopper and tubular chain conveyor system for milled malt. 2. Brewhouse: 2-vessel brewhouse (Kaspar Schulz, built 2013) as a brew block with copper-clad stainless steel vessels. Wort cooling via a freestanding plate heat exchanger (API Heat Transfer, built 2013) with downstream wort aeration. Also included is a hot water tank (Kaspar Schulz, 2013) with insulation and heating jacket. 3. Fermentation and maturation cellar: 4 cylindroconical fermentation and maturation tanks (Kaspar Schulz, built 2013) with a gross volume of 12 hl each and a maximum overpressure of 3 bar. 3 cylindroconical fermentation and maturation tanks (Kaspar Schulz, 2013) with a gross volume of 25 hl each and a maximum overpressure of 3 bar. The temperature for these 7 cylindroconical fermentation and maturation tanks is controlled via a central control panel. In addition, there are 2 further cylindroconical fermentation and maturation tanks (Kaspar Schulz, built 2013) with a gross volume of 14.7 hl each and a maximum pressure of 3 bar. Temperature control for these two tanks is managed by a separate control cabinet. 4. Bright beer cellar / serving cellar: 5 upright bright beer tanks (Kaspar Schulz, 2013) with dished heads, each with a gross capacity of 10.5 hl and a maximum pressure of 3 bar. 5. Filling: siphon filler/glass bottle filler (JS Maschinen) with 6 filling heads. Keg interior and exterior washer (Scheuer) with spray nozzles in a stainless steel housing and a caustic tank in the base frame. Keg filling station with taps for direct filling of kegs from the bright beer tanks. 6. Utility equipment: Refrigeration system (Hafner-Muschler, 2013) as an ice water storage unit with refrigerant R404a and 3 refrigeration compressors. Oil-free reciprocating air compressor (Kaeser, 2013) with a maximum operating pressure of 10 bar, as well as refrigerant air dryer (Kaeser, 2013). Air separator (AST) as nitrogen generator with adjacent nitrogen pressure tank. Machine (additional): complete brewery installation with copper-clad brewhouse. Brew length (wort per batch): 10 hl Equipment: grist mill, malt conveyor system, 2-vessel stainless steel brewhouse (copper-clad), wort cooling unit, hot water tank, 9 CCTs (4 x 12 hl, 3 x 25 hl, 2 x 14.7 hl), bright beer tanks (5 x 10.5 hl), siphon filler, keg washer, keg filling station, compressed air system, refrigeration system, N2 generator. Iodpjy Nm I Hofx Abxeic

Stanje: rabljeno, Decoction process Machine (additional details): Mash vessels with copper domes and hop dosing device, whirlpool, and wort cooling unit Iiedpfx Ajvcqufsbxec Brew length: 150 hl per brew Operation / Control: ProLeit / Siemens S7 Material: Brew vessel copper-clad Features: Mash/wort kettle, lauter tun, hop dosing tank, kettle vapor condenser system, whirlpool, wort cooler, various pumps and fittings

Leto izdelave: 1991, stanje: rabljeno, The Filtrox Cross Flow Microfilter operates with a maximum transmembrane pressure of 6 bar (0 °C - 95 °C) and a filtrate volume of 4.5 - 7 hl/h, with a filtration area of 26.4 m². Two circulation pumps (20 kW each) move the unfiltered medium through the loop. Includes a 16 hl agitated tank for cleaning purposes. Machine (special feature): Yeast beer recovery 1987-1991 Capacity: 7 hl/h Permissible operating pressure: 10 bar Permissible operating temperature: 85 °C Iijdevcq Daepfx Abxjc Filtration area: 26 m² Current: 4.85/2.8 A Voltage: 220/380 V Frequency: 50 Hz Operation / Control: Simatic S5 Equipment: 8 ceramic membrane modules (total filtration area 26.4 m²); high-pressure pump; 16 hl cleaning tank with agitator; various pipelines, valves, measuring and control technology

Leto izdelave: 2000, stanje: rabljeno, Nizko stožčasti inox fermentacijski tank za približno 40 hl neto prostornine. Stroj (dodatno): hladilni tank Bruto prostornina: 4219 l Dovoljena delovna temperatura: 20 °C Isdpfx Ajw Td D Eobxeic Dolžina: 2000 mm Širina: 2000 mm Višina: 1800 mm Material: nerjaveče jeklo Oprema: revizijska odprtina na plašču, pršilna glava s cevjo za pršenje in slepa kapica DN 25, iztočni ventil, Pt 100 za avtomatsko regulacijo temperature, višinsko nastavljive cevne noge; magnetni ventil za regulacijo temperature

Leto izdelave: 1979, stanje: rabljeno, Centrifugal high-performance diatomaceous earth filter with buffer tank, DE dosing vessel, and peristaltic pump. Machine (addition): Diatomaceous earth filter Capacity approx.: 110 hl/h Tank volume: 1,550 l Iodpfxevcqmbs Abxoic Operating pressure: 9 bar Operating temperature: 100 °C Operation / Control: Control cabinet with operating buttons Material: Stainless steel Features: Diatomaceous earth dosing vessel, 14.26 hl; peristaltic pump Peripheral equipment: Buffer tank, container

Leto izdelave: 1988, stanje: rabljeno, Cylindroconical 965 hl Fermentation and Storage Tank – coolable, 1 x cone cooling, 3 x shell cooling. - Swiveling cone - Stainless steel - Insulated - Short standing skirt base - Cleaning air fitting with safety valve - Vacuum valve 12 tanks available, can be purchased individually or as a partial quantity. Iodpfxevcqnlo Abxeic Machine (additional): Outdoor tanks for liquid storage; years of manufacture: 1988–1991 Capacity: 96,450 l Operating pressure: 2 bar Length: approx. 12,400 mm Width: approx. 3,950 mm Height: approx. 3,950 mm Material: Stainless steel 1.4301 Orientation / Position: Vertical Base construction: Short standing skirt Equipment: 12 tanks; cooling: 1 x cone cooling, 3 x shell cooling; swiveling cone; insulation; cleaning air fitting with safety valve; vacuum valve; temperature measurement Weight: 6,220 kg

Leto izdelave: 1979, stanje: rabljeno, Machine (additional): Wort cooler Capacity: 150 hl/h Pressure: 6 bar Max. temperature: 100 °C Length: 2550 mm Width: 900 mm Height: 2000 mm Iodpfx Ajvcqtzebxoic Material: Stainless steel Base design: Mounted on frame Features: 2-stage, connection sizes: DN65 (wort, water) and DN80 (ice water) Periphery: Wort aeration, mixing pump, booster pump (water) Weight: 1080 kg

Leto izdelave: 1985, stanje: rabljeno, Pressure Tank Cellar with 4 upright 32,400 L stainless steel pressure tanks and double-seat valve solution at the operating level. The tanks are cooled with ice water. Iodpovcqynefx Abxjic Machine (Additional): 4 pressure tanks Diameter per tank: 2,550 mm Total height per tank: 7,360 mm Cooling surface per tank: 25 m² Permitted operating overpressure: 3 bar Tank volume: 32,400 L Length: 12 m Width: 4 m Height: 7.5 m Material: Stainless steel 1.4301 Equipment: Tank cleaning device with spray head, safety valve, pressure gauge, cleaning air valve combination; sampler, level indicator with flaps, outlet flap, pressure tank documentation and drawings available Periphery: Inlet and outlet piping via double-seat valves Weight: 2,585 kg

Leto izdelave: 1991, stanje: rabljeno, Fermentation tanks with two dished heads. - 4 tanks, each with a gross capacity of 5,200 liters (52 hl) - 2 tanks, each with a gross capacity of 7,900 liters (79 hl) Machine (addition): upright stainless steel tanks Total capacity: 79 hl storage tank, 2 units Iiodpsvcqzxsfx Abxoc Operating pressure: 0 bar Operating temperature: 20 °C Width: approx. 1,400 mm Height: approx. 4,100 mm Material: stainless steel 1.4310 Orientation/Position: upright Base construction: 4 x tubular legs with dished ends Equipment features: manway, lateral; CIP line; outlet valve (disc valve)

Stanje: rabljeno, Brewing plant with a cast wort volume of 20 hl, consisting of the following components: 1. Milling unit (Joh. Albrecht, 2000, 500 kg/h) with mill, malt hopper, floor scale, grist conveyor, and control cabinet 2. 3-vessel compact brewhouse with insulated stainless steel vessels featuring copper tops, lauter tun with spindle station, and control cabinet 3. Fermentation and storage cellar with 4 × open fermenters (Joh. Albrecht, 1999, 25 hl), 1 × fermentation tank (Nerb, 2002, 50 hl, 0.99 bar), 5 × storage tanks (Joh. Albrecht, 1999, 44 hl, 0.99 bar), and 6 × storage tanks (Joh. Albrecht, 1999, 22 hl, 0.99 bar). All tanks equipped with double-jacket cooling. 4. Pressurized tank cellar with 2 × pressure tanks (Speidel, 2021, 86 hl, 3 bar), 1 × pressure tank (INOX, 2018, 67 hl, 3 bar), and 4 × pressure tanks (Joh. Albrecht, 1999, 12 hl, 2.5 bar). All tanks have double-jacket cooling. 5. Keg washing and filling machine (BTB Multimat MT/2, 1997, 17–20 kegs/h) 6. Cooling unit as ice water generator (Joh. Albrecht, 1999, cooling capacity 14.5 kW) 7. Steam generator with water softening unit (Jumag, 2000, 224 kg/h steam, oil-fired) 8. 40 hl hot water tank (Joh. Albrecht, 1999), heatable, with control cabinet Do you only require part of the equipment? Sale is handled via brokerage. Partial sales may be possible – simply enquire and submit an offer. Iisdpswgc Udsfx Abxjc Additional info: Cast wort volume 20 hl, years of manufacture 1997–2021 Wort cast volume: 20 hl Equipment: Milling unit; 3-vessel compact brewhouse; fermenters; fermentation, storage, and pressure tanks; keg system; cooling unit; steam generator, hot water tank, CO₂ liquid gas tank

Leto izdelave: 2000, stanje: rabljeno, Inoks fermentacijski tank s cca 20 hl neto prostornine; hlajenje z dvojnim plaščem na obodu in dnu; plitko stožčasta oblika; tlačno nerezervoar; stalno zavarjeno izoliran. Stroj (dodatno): hlajen rezervoar Bruto prostornina: 2422 l Dovoljena obratovalna temperatura: 20 °C Dolžina: 1700 mm Širina: 1700 mm Višina: 2000 mm Material: nerjaveče jeklo Oprema: kontrolna odprtina na obodu, pralna glava s cevjo in slepim pokrovom DN 25, izpustna loputa, termometer in Pt 100 za avtomatsko regulacijo temperature, po višini nastavljive cevne noge; magnetni ventil za regulacijo temperature. Iiodpfow Td Drex Abxec

Leto izdelave: 1999, stanje: rabljeno, 3-naprava kompaktni varilni sistem za 20 hl iztoka Stroj (dodatno): 20 hl kompaktna pivovarna Količina vrenja: 2000 l Dolžina: 2600 mm Širina: 5000 mm Ijdpfx Aow U A T Ijbxeic Višina: 4500 mm Upravljanje / krmiljenje: Ročno upravljanje s programatorjem ogrevanja "Barbie und Kühner 7600" Material: Nerjaveče jeklo / baker Osnovna konstrukcija: Posode za kuhanje nameščene na okvirno konstrukcijo Oprema: Mastni/kuhalni kotel, filtrirni kotel, predtokovna posoda/whirlpool, merilna postaja, nerjaveča elektro omarica s krmiljenjem, okvir iz nerjavečega jekla z upravljalnim podestom, stopnice, cevovod, črpalke in armature

Leto izdelave: 1999, stanje: rabljeno, 4 stoječi fermentacijski rezervoarji s plaščno hlajenjem Stroj (dodatek): stoječi, hladilni rezervoarji iz nerjavečega jekla Vsebina: 2500 l Dolžina: 1600 mm Širina: 1600 mm Višina: 1717 mm Upravljanje / Krmiljenje: ročno Material: nerjaveče jeklo 1.4301 Položaj: prostostoječ Isdexwy Slopfx Abxoic Osnovna konstrukcija: cilindrični rezervoar, odprt na vrhu, s kvadratnimi cevmi na kalotah Oprema: plaščno hlajenje, avtomatski ventil z uravnavanjem temperature, sredinski spodnji izpust z zaporno loputo

Leto izdelave: 2019, stanje: rabljeno, consisting of: - Grist mill - Mash/Wort kettle/whirlpool - Lauter tun - Hot water tank - Wort cooler - Wort aeration - Siemens touch screen - 4 x fermentation tanks - 8 x storage tanks with jacket cooling - Chilled water tank - Mobile beer pump - Rapid steam generator - 2 bottle fillers + 1 Fillmatic can filler - Bottle filler A. Gruber Iiodpfxsvcqk He Abxsc Machine (additional information): 5 hl brewery with grist mill, compact brewhouse, fermentation tanks, storage tanks Wort output: 500 l Wort cooler capacity: 750 l/h Wort cooling time: 40 min. Material: brew kettles, hot water, fermentation, and storage tanks made of stainless steel 1.4301 Basic construction: brewhouse as a complete unit on a base frame. Cylindrical, free-standing fermentation tanks. Horizontal storage tanks in two tiers within a stainless steel frame. Equipment: Mobile grist mill, mash/wort kettle, lauter tun, hot water tank, wort cooling and aeration system with independent control, remote operation possible. 4 fermentation tanks, 8 horizontal storage tanks with temperature control, pumps, hoses, bottle and can fillers, bottle washer, ice water tank, rapid steam generator.

Stanje: rabljeno, Stoječi rezervoar iz nerjavečega jekla z nagibnim pokrovom in stranskim iztokom. Stroj (dodatno): stoječi rezervoar iz nerjavečega jekla. Bruto prostornina: 1055 l. Dolžina: 1,40 m. Širina: 1,40 m. Višina: 1,30 m. Material: nerjaveče jeklo. Položaj: stoječe. Oprema: nagibni pokrov, stranski iztok. Iisdpfx Abow Tbwpexsc

Leto izdelave: 1988, stanje: rabljeno, Machine (Additional Information): Stainless steel tanks with temperature control Iiodpsvcqg Isfx Abxoc Total capacity (gross): 904 hl Material: Stainless steel Equipment: 3 fermentation tanks (1 x 554 hl, 2 x 175 hl), 1 yeast tank (37 hl), integrated temperature control system (Nerb)

Leto izdelave: 1980, stanje: rabljeno, Tank vehicle – semi-trailer with pressure tank designed for beer transport; the semi-trailer was manufactured in 2012. Capacity: 25,250 liters Iodpfx Asvcqlkebxsic Operating overpressure: 3 bar Tank volume: 25,250 liters

Leto izdelave: 1991, stanje: rabljeno, Machine (additional): Stainless steel tanks for wheat beer fermentation Total capacity (gross): 465 hl Equipment: 2 upright tanks (1 x approx. 150 hl, 1 x approx. 160 hl), 1 horizontal tank (155 hl), 1 mobile yeast vat, dedicated temperature control system Isdevcq Dgopfx Abxoic

Stanje: rabljeno, Leto izdelave: 2001, Insulated, cylindrical-conical stainless steel tanks with two cooling jackets (zone cooling) and cone cooling. Most recently used as beer storage tanks with a usable volume of 150 hl. Iijdpfx Aovu Tvvsbxec Machine (additional info): Standing, coolable, insulated stainless steel tanks Gross volume: 15,260 l Pressure rating: 0.99 bar Maximum operating temperature: 20°C Cooling surface: 6.95 m² Length: 2.52 m Width: 2.52 m Material: Stainless steel Base construction: Leg-supported shell Features: Insulation, tank fittings Weight: 2,100 kg

Leto izdelave: 1999, stanje: rabljeno, 5 stoječih skladiščnih rezervoarjev z plaščnim hlajenjem Stroj (dodatek): stoječi, hladljivi rezervoarji iz nerjavnega jekla Iiodpfx Abow Tlp Asxec Vsebina: 4400 l Maks. tlak: 0 bar Dolžina: 1600 mm Širina: 1600 mm Višina: 2920 mm Upravljanje / Krmiljenje: ročno Material: nerjavno jeklo 1.4301 Položaj / Lokacija: prostostoječe Osnovna konstrukcija: cilindrični rezervoar z izbočenimi dnom in kvadratnimi cevmi za noge na kalotah Oprema: pršilna krogla, sodni aparat, manometer, 1 plaščna hladilna cona, merilna cev za prikaz vsebine, roč, termometer in vzorčevalnik v plašču, ročni ventil za regulacijo hlajenja, iztok na sredini dna

Leto izdelave: 1992, stanje: rabljeno, Stroj (dodatek): 6 hladilnih rezervoarjev Kapaciteta: 164 hl Obratovalni nadtlak: 0 bar Širina: ca 2,05 m Višina: ca 6,2 m Iodpfow Tmqzox Abxoic Položaj / postavitev: Pokončno Osnovna konstrukcija: Na nogah Oprema: Človekova odprtina, 2 hladilni coni, ventil za vzorčenje, varnostni ventil z indikatorjem tlaka, vakuumski ventil.
