Obdelovalni centri s prečnim mizo nakup rabljenega (177)

Stanje: zelo dobro (rabljeno), Obdelovalni center Morbidelli Author 444 Ksdpfxoxpumbe Ah Djnc 4 osi 4400 x 1300 mm

Stanje: rabljeno, 4-osno CNC obdelovalni center SCM CNC Tech Z 27 Delovno območje: 2650 x 1240 mm Pomik X-Y: 2995 x 1385 mm Dolžina pomika osi Z: 200 mm Prehodna višina: 180 mm TV-delovna miza Avtom. menjalec orodij za 8 orodij Horizontalna rezkalna enota za rezkanje in utore (enota za ključavnični okvir) Orodni vpenjalni sistem HSK Avtomatsko centralno mazanje Vektorska rotacijska os 0 – 360 stopinj Kotni prenos MIMATIC HSK 63 F Knodpfjxg I Efjx Ah Doc Dodatni omejevalnik desno z valjčno progo Laserska naprava Letnik 2005 Stroj je FUNKCIONALEN / iz male delavnice – razdrtje podjetja Stroj je v uporabi in ga je mogoče kadar koli ogledati pri prodajalcu Posredovanje po naročilu stranke Iz lokacije

Stanje: zelo dobro (rabljeno),

Stanje: rabljeno, SCM Tech 99L Machining Center Transport dimensions: Ksdotxdqcopfx Ah Dsnc 4,800 x 2,300 x 2,600 mm – Weight: 2,800 kg

Stanje: zelo dobro (rabljeno), Leto izdelave: 2019, obratovalne ure: 278 h, Max. workpiece size for re-milling X = 3620 mm; Maximum travel distances: X = 3865 mm Minimum room height 3.20 m Machining in Y and Z Y = 1600 mm; Max. panel width 2000 mm Maximum workpiece height 300 mm (measured from upper edge of vacuum suction cup 125 mm) MACHINE OPERATION SOFTWARE CAMPUS V7 Plus CAD/CAM software, 1 x license incl. CabinetControl Base and material removal simulation 1 software license secured by dongle for the machine CabinetControl Base: Software for furniture design and production CAMPUS V7 PLUS: Software for CNC processing centers Knedpfx Aexfaf Uoh Djc ADDITIONAL MODULE HIGH-SPEED MILLING Control Siemens industrial PC control Handheld controller for remote operation of the machine MILLING HEAD 5-axis head 7840, power: 12 kW n(max.) = 0–24,000 rpm, infinitely variable Gimbaled; C-axis +/- 360° rotatable, A-axis +/- 180° rotatable Liquid cooling (cooling unit included) with HSK-F 63 tool holder Max. tool weight: 6 kg Milling tools: max. Ø 200 mm Saw blades: max. Ø 350 mm with optional 7886 pick-up changer DRILLING UNIT Pressure booster to increase standard pressure from 6 to 8 bar Drilling unit 7881, 24 spindles Drive power 3.0 kW, incl. saw unit 18 vertical spindles, individually selectable L-shaped arrangement, 11+2 in X, 6 in Y direction, 32 mm pitch n (max.) 1,000–5,710 rpm, infinitely variable 6 horizontal spindles 2 double drill spindles in X direction 1 double drill spindle in Y direction including saw unit Integrated saw unit for sawing/grooving in X direction n(max.) 1,000–7,330 rpm, infinitely variable MACHINE TABLE Machine table: 6 consoles, pneumatically clamped, movable in X direction Display and assignment of consoles and suction cups in the software 2 side stops field A and D, 2 large-area buttons for clamping and releasing workpieces, 2 tape measure displays for positioning the consoles in X, referenced to stop field A/D, tape measure displays for suction cups on each console in Y, referenced to the rear stop STOPS 2 additional machining fields in front for 6 consoles (4-field machining) 4 pneumatically controlled stops per field, including 1 stop per console and one side stop in X direction per field FEEDING AIDS 4 pneumatically liftable and lowerable feeding aids for easy handling of heavy parts TOOL CHANGER Tool changer 7996, 18-position magazine (carousel) travels automatically in X direction Traveling tool changer 7886, 1-position saw blade magazine Specially designed for large saw blade diameters up to 350 mm Pick-up system installed on the gantry, pneumatic Max. tool Ø: 350 mm Tool changer 7892, 16-position linear pick-up VACUUM PUMP 140 m³/h dry-running compressor LED light for the machining area. SAFETY OPTIONS Safety enclosure according to CE standard Protective fence on the side and rear CONFIGURATION VARIANTS AND ACCESSORIES LUBRICATION Automatic central lubrication Gantry extension – ideal for 4-field machining and large workpieces 2 controlled pneumatic modules for up to 5 frame clamping elements per field (A/D) Each module can control up to 5 frame clamping elements simultaneously. Simultaneous opening/closing of connected clamping elements; includes foot pedal for operation, max. 2 per field A and D can be ordered OPTIONAL: LASER – laser pointer, consisting of two laser pointers for positioning the vacuum suction cups.

Stanje: rabljeno, Leto izdelave: 2021, Traverse paths (X, Y, Z): 4062, 2,922, 660 mm Number of spindles, vertical drilling head: 13 pcs. Number of spindles, horizontal drilling head: 6 pcs. Number of tools: 27 pcs. Number of milling units: 1 pc. Working area: 3200 x 1500 x 200 mm Motor power: 12 kW CNC control: BECKHOFF MASTERWOOD Project 385 (Winner) ----- Exhibition machine, year of manufacture 2021, available immediately with manufacturer’s new machine warranty! 5-axis CNC machining center in portal design, suitable for interior fittings, doors, stairs, optionally expandable with solid wood clamps for frame processing and arched windows Brief summary: ----- Working area: Knodpfx Asxmk Atsh Dsc X = 3200 mm; Y = 1500 mm; Z = 200 mm 1 piece 5-axis high-performance spindle, 12 kW, with HSK 63 F interface 1 piece fixed drilling head with 19 spindles with 7 individually selectable vertical drilling spindles in X-direction with 6 individually selectable vertical drilling spindles in Y-direction with 2 double horizontal drilling spindles in X-direction and 1 double horizontal drilling spindle in Y-direction Saw unit integrated in drilling head 27 tool change positions: Carousel tool changer with 22 positions and 102 mm center distance linear 5-position tool magazine for large tool diameters Original SCHMALZ tubeless worktable. Console table with 6 beams/traverses Workpiece lifting device Automatic measurement device for tool length. 12 pcs. original Schmalz vacuum cups 114 x 140 mm, height = 125 mm 1 pc. Becker vacuum pump, 100 m³/h 1 pc. chip conveyor belt Construction software Masterwork: 2D-Wop for standard panel processing/interior fittings, arch segments, doors Master 3D Level 2: for more complex operations, optionally expandable for full 5-axis interpolation Prepared for the use of solid wood clamps (arches), clamps offered as an option if required later Technical specifications according to the attached, detailed description ----- Total price in this configuration ex stock Oberkochen: on request! ----- Freight and commissioning on request! Options for frame production/arched elements with surcharges: ----- Reference ring for mounting chip guide elements on 5-axis electrospindles with HSK 63F interface: €410.00 Basic kit for clamping arched elements - 6 pneumatic clamps with two movements for arched components: €7,090.00 (technical data according to manufacturer - no guarantee!) Chip guide elements, price per piece: €460.00 All prices quoted are net, plus VAT. (technical data according to manufacturer - no guarantee!)

Stanje: dober (rabljeno), Leto izdelave: 2016, obratovalne ure: 14.000 h, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: AA2/004582, potovalna razdalja osi X: 3.120 mm, pomik osi Y: 1.320 mm, število osi: 5, Prodamo zelo dobro ohranjeni 5-osni CNC stroj SCM M100. Knedpexpt U Rsfx Ah Djc Ne prodajamo iz nuje, ampak ker smo naročili nov stroj z drugimi zahtevami. - vključno s priseski - brez orodij - vključno z nameščeno pihalno šobo (pri obsežnem rezkanju MDF pozitivno vpliva na obrabo orodja) Več podrobnosti na zahtevo.

Stanje: novo, Leto izdelave: 2024, Morbidelli M200 CNC-CONTROLLED MACHINING CENTER - C.E. safety regulations - Morbidelli m200 3715x1620 Z250 - 400V EU - Frequency 50 Hz - PRO-SPACE safety devices - Panel passage Y 2200 mm - Retractable protection belts Kedpfxeu Illmj Ah Denc - "TECPAD wired" remote control with 7" touchscreen display - Tool changer TRB14 (version Y=1620) - Tool changer FAST14 - 1 vacuum pump, capacity 250/300 m³/h at 50/60 Hz - Central optimized extraction nozzle on rear boring head - Drilling unit with pneumatic vertical positioning (single Z-axis) - RO.AX F31LTC drilling unit - Extraction hood for drilling unit - Drilling unit with inverter - Pressure booster - 5-axis unit "Prisma 5" version "KT" - Extraction hood for 5-axis electrospindle - 7-position extraction hood for 5-axis electrospindle - Device for liquid cooling (air type) - 6 "TV FLEXMATIC" work tables 1600 - Conveyor belt for chip and offcut removal for X=3710mm - Removable chip collection container at the end of the machine frame - Tool length measurement sensor - 4 loading aid devices H=75 1600 - Front stops H=75 for 6 supports - 12 x fixed suction cups 145x145 H=75 mm - 6 x rotating suction cups 145x55 H=75 mm - Preparation for clamping cylinders for 6 supports TV FLEX / TV FLEXDRIVE / TV FLEXMATIC - Maestro connect: Service contract for 1 year (gateway "plug&play" kit included) - SCM DIGITAL SOLUTIONS: MAESTRO CONNECT - Human-machine interface software (HMI) MAESTRO ACTIVE - Machine interface software Maestro lab - Hardware key for Maestro - Additional hardware key for Maestro (for USB slot) - Mobile operator console "eye-M TOP" - TELESOLVE remote maintenance via Internet - Mobile control unit with 6.5m cable length - S-N-D 3-position selector switch - MACHINE LANGUAGE: German - incl. delivery, 3 days preliminary training, 1 week installation and instruction - The new machine is still in its original packaging

Stanje: rabljeno, Leto izdelave: 2007, Used machine Year of manufacture: 2007 Nesting system with grid table Table working area: 5000 x 1240 mm Travel path X-axis: 5665 mm Travel path Y-axis: 1650 mm Travel path Z-axis: 325 mm Max. machining height: 135 mm Equipped with milling unit type 7933, 11 kW motor (S6) HSK 63, water-cooled With C-axis With 18-position rotary tool changer Kjdpfswka Ipox Ah Dsnc With vacuum pump, 250 m³ With handheld control unit With central lubrication system With minimum quantity lubrication system Availability: short notice Location: Röllbach

Stanje: rabljeno, Leto izdelave: 2004, Funkcionalnost: popolnoma funkcionalen, moč vretenovega motorja: 6.600 W, število mest v zalogovniku orodij: 7, 3-OSNI STROJ PUMPA ZRAKA 100 M3 SNAGA MOTORA ELEKTROSPINDLE 6,6 kW ISO 30 prihvat Glodalo + Agregat Pila Broj svrdla (horizontalni + vertikalni) 10 + 4 Spremnik alata 7 komada Automatsko podmazivanje - NE Knsdpfxjwhvwne Ah Dsc MONITOR 15" SOFTWARE XILOG PLUS Koristi WINDOWS XP Stroj radi kod Prodavatelja, video stroja u radu dostupan na e-mail zahtjev

Stanje: kot nova (razstavni stroj), Funkcionalnost: popolnoma funkcionalen, The Format4 creator 950 in a wide range of equipment variants – your CNC machine for custom woodworking challenges. Efficient CNC machining at a fair price: this principle is central to the creator series of machines. All models feature attractive equipment packages with cutting-edge CNC technology and can be individually configured to suit specific requirements. The creator 950 is not only an easy and safe entry into the world of CNC, but also serves to relieve your CNC machining centers. Your benefits at a glance: - Powerful CNC technology on just 5 m² of installation space - All-inclusive: 4-sided formatting as standard - Ready to go: Maximum productivity without setup times - No need for pod and rail positioning - Suitable for applications ranging from interior outfitting to door production - Traditional top-down machining – simple loading - Intuitive operation via control panel - User-friendly software - Optimum extraction results - High-end performance at the best price in every configuration - Cabinet machining possible with Lamello Clamex-P Additional equipment: - C19: 2nd reference stop cylinder for long workpieces - C71: Folding support tables front and rear – roller table - C198: Pick-up station for tool and aggregate changes - C200: 4-position linear changer for use with aggregates - C233: Lifting bracket for crane transport - C490: F4design (incl. 3-axis postprocessor) - 800: E-Learning F4Design Working area Creator: Travel distance axis X = 1475 mm (clamp) Y = 1550 mm Z = 225 mm Working field X = 3500 mm (infinite) or 130 kg maximum load Y = 950 mm Z = 80 mm maximum workpiece thickness Equipped with: - High-performance PC - 24” LED color display - Keyboard, mouse, and mouse pad - 1 USB interface Kodpju Eg A Uofx Ah Dsnc

Stanje: rabljeno, Leto izdelave: 2019, Technical details in the attached .pdf document - Longitudinal travel X-axis: 2700 mm Knsdpjxdw D Eefx Ah Doc - Usable travel X-axis (spindle only – unit A): 1900 mm - Usable travel X-axis (sander only – unit B): 2050 mm - Usable travel X-axis (milling unit only – unit C): 2050 mm - Usable travel X-axis (chisel only – unit D): 1500 mm - Usable travel X-axis (saw blade only – unit E): 1750 mm - Usable travel X-axis (sander only – unit F): 1500 mm - Usable travel X-axis with all units: 1500 mm - Cross travel Y-axis: 380 mm - Cross travel V-axis: 720 mm - Vertical travel Z-axis: 630 mm - B-axis stroke (electrospindle): +/- 90° - A-axis rotation (rotary table): infinite - Dimensions: 4000 x 3100 x 2500 mm - Installed power: 65 kW - Compressed air: 6 bar - Power supply: 380 Volt, 3 phase / 50 Hz.

Stanje: novo, Leto izdelave: 2022, Travel ranges (X,Y,Z) 6735 x 1930 x 245 mm Number of spindles vertical drilling head: 0 pcs. Number of spindles horizontal drilling head: 0 pcs. Number of tools: 39 pcs. Extraction nozzle diameter: 2x 250 mm Number of milling units: 2 pcs. Year of manufacture: 2022 Speed: 18,000 / 24,000 rpm Compressed air connection: 7 bar Motor power: 16.5 / 19.2 kW Pump capacity: 250 m³/h Control system: BH660 CNC Machining Centre BIESSE Rover B 1967 – BRAND NEW / STOCK MACHINE in original packaging! Working area: X = 6735 mm Y = 1930 mm Z = 245 mm with modules H = 74 mm Z = 290 mm with modules H = 29 mm (milling operation) Workpiece pass-through in Y: 1930 mm, with a thickness up to 60 mm on modules H = 74 mm; 1880 mm, with a thickness over 60 mm on modules H = 74 mm. Double-Y axis for 5-axis and 4-axis spindle (enables tool change during hidden time) Safety system with bumper and light barriers – 3-sided safety enclosure Uninterruptible power supply (UPS) 10 traverses – 30 base carriages Multiple clamping area automatic table positioning FPS HyperClamp clamping system 3 alignment rows 8 loading aids 250 m³/h vacuum pump Chip conveyor belt 5-axis spindle with 16.5 kW – 18,000 rpm Deflector preparation Unit interface 4-axis spindle with 19.2 kW PeakPower – 24,000 rpm C-axis Kedpfxexf Dwzs Ah Donc separate Y-axis for 5-axis and 4-axis no drilling head! Turret changer travelling with 4-axis, with 8 positions Front turret changer for 5-axis, with 8 positions Saw pickup front for 5-axis Chain changer rear with 22 positions (Photo is for illustration purposes only!) BRAND NEW MACHINE IN ORIGINAL PACKAGING! Full manufacturer’s warranty! Installation, training, service: By official BIESSE dealer in Austria! HANDL Maschinen GesmbH & Co KG Trauseneggerdamm 5 4600 Wels

Stanje: rabljeno, Leto izdelave: 2006, Numerical control XP 600 Working area in the X-axis: 3060 mm Working area in the Y-axis: 1140 mm Working area in the Z-axis: 160 mm Number of working zones: 2 Bar worktable Number of adjustable bars for suction cup support: 6 Number of pneumatic Bakelite bars for panel lifting (?): [please verify] 2 adjustable suction cups per bar, each with vacuum sealing for panel fixation during machining 1 vertical electrospindle with C-axis, 12 kW motor Tool change system with 10 positions, located at the machine drilling head, cone type: ISO 30 Drilling head BH19L with 18 spindles, configured as follows: Knodpfxjv Aacfj Ah Doc - 7 vertical on the X-axis - 6 vertical on the Y-axis - 4 horizontal on the X-axis - 2 horizontal on the Y-axis - 1 independent saw blade unit for grooving in the X-axis Front photocell guard and safety system Automatic lubrication system (?) Climate control system for cooling and cleaning the machine control unit Vacuum pump: 250 m³/h TECHNICAL DETAILS MUST BE VERIFIED

Stanje: rabljeno, Leto izdelave: 2005, Used machine Kjdowlwn Njpfx Ah Donc Year of manufacture: 2005 Technical data: - Base machine 555 - Workpiece support with 8 consoles, pneumatically clamped - Drilling unit 7968, 18 vertical drilling spindles with 32 mm pitch, individually selectable, T-layout, 12 in X-axis and 6 in Y-axis, max. drilling diameter 35 mm (depending on panel thickness), spindle stroke: 70 mm, rotation direction: alternating right-left, n=4725 rpm steplessly adjustable, 2 horizontal drilling units in X direction, 1 horizontal drilling unit in Y direction - Saw unit 7946, 3.5 kW, pneumatically swiveling 90°, n = 5300 rpm, tool holder A Ø = 200 mm, I Ø = 30 mm, B = max. 3.5 mm, sawing/grooving in X and Y direction - Milling unit 7935 with 6 kW spindle, water cooled - Milling unit 7982 for lock case milling - Tool changer 7996, 18-position magazine (disc type) - Vacuum pump with 140 m³/h - Handheld control device - PC control with TwinCAM WOP system - Siemens control Availability: short term Storage location: Poland

Stanje: rabljeno, max. workpiece length 4400 mm milling spindle: 1 unit main motor: 19.2 kW control: Beckhoff CNC machining centre MASTERWOOD 4 WIN ---- Specially designed for efficient and flexible production of wooden windows and doors HIGHLIGHTS: - Various tool magazines for optimum tool configuration - Simultaneous loading with 4 workpieces - Patented clamping system for optimal workpiece machining - CNC-controlled worktable with automatic positioning of beams and clamps - Automatic reclamping for switching between exterior and interior profiling - INTEGRATED window construction software, i.e. the machine does not need to (but can, of course) be controlled externally from the office by sector-specific software - Powerful 19.2 kW main motor with HSK-63 E Please note that this stock machine is located at our facility in Oberkochen and already comes equipped with many useful options. Tooling available for prompt delivery upon request! Request a quotation and see for yourself the unbeatable price-performance ratio! VIDEO of the machine available upon request! You will also find the technical description of the machine as a PDF document attached. Knodot Tqxzopfx Ah Dec We would be happy to take your used machine in trade at a fair price! Matching stationary or mobile extraction units available on request! (see e.g. #5674 NESTRO NE 300) Suitable compressor on request! (#5997 Kaeser Aircenter SM 15) (Technical specifications as per manufacturer – subject to change!)

Stanje: zelo dobro (rabljeno), Leto izdelave: 2012, Funkcionalnost: popolnoma funkcionalen, SPM2 - 2600 - 2600 Can be inspected during ongoing operation. Training available upon request. - Automatic panel feed - Lift table 2600 x 6000 Units: - SPM-FF6-23U Finger jointing cutter 6 kW, max. 23,170 rpm - SPM-KSK3 4-axis circular saw unit, 3 kW, 220 mm saw blade - SPM-5F 5-axis milling unit, 6.0 kW (special motor 24,000 rpm – 5-axis unit) Ksdpfeu H Uqcjx Ah Denc - SPM-IJ Ink marking system – HP InkJet system Component discharge: - SPM-SHP-6000 special lift table, panel removal 2600 x 6000 - Access protection discharge area

Stanje: zelo dobro (rabljeno), Leto izdelave: 2021, 5-osni obdelovalni center BIESSE Rover 1632 v odličnem stanju. Knjdpfexp Rx Hex Ah Doc

Stanje: rabljeno, Leto izdelave: 2008, številka stroja/vozila: AP 194 J4, potovalna razdalja osi X: 1.800 mm, pomik osi Y: 1.600 mm, pomik po osi Z: 700 mm, dolžina podajanja os X: 1.200 mm, dolžina pomika po osi Y: 1.200 mm, dolžina podajanja os Z: 600 mm, moč polirne enote: 7.500 W, 5-axis machining center Balestrini IDEA 2 Axis travel range: X - 30,000 mm Y - 1,600 mm Z - 700 mm Working area: X - 2,000 mm Y - 2 x 500 mm Z - 600 mm Spindle power: 7.5 kW Option to split the table widthwise 2x vacuum pumps included 4-position spindle Tool magazine - 4 positions Enclosed machine roof for dust extraction Windows XP Listed price is net Disassembly is the responsibility of the customer Kodewrb Tpepfx Ah Djnc

Stanje: dober (rabljeno), Obdelovalni center HOMAG BAZ 723 58/18/FC 4-osni CNC portal s 2 premičnima mizama in enoto za lepljenje robov Knedpfx Asxc Ir Reh Dsc

Stanje: rabljeno, Leto izdelave: 2004, Rabljeni stroj Leto izdelave: 2004 Stanje: Preverjena funkcionalnost Oprema in tehnični podatki: Rezkalna enota 6 kW, vodno hlajena Vpenjalo orodja HSK 63 F Število vrtljajev 1.000 - 18.000 min⁻¹ Menjalnik orodja: 6-kratni, stranski Vrtalna glava: 9 navpičnih vrtalnih vreten na 32 mm raster Horizontalno vrtalno vreteno: 1+1 Vertikalno vrtalno vreteno: 1+1 Kodexpla Sjpfx Ah Djnc Utorska žaga v X-smeri Krmiljenje: Twin CAM 32 Vakuumska črpalka 100 cbm/h Vključno z vakuumskimi priseski Pomiki osi: X-os: 2.685 mm Y-os: 1.095 mm Z-os: 140 mm Postavitvene mere: 5.200 x 2.843 x 1.855 mm Teža: pribl. 3.500 kg Razpoložljivost: po dogovoru Lokacija skladišča: Emsland

Stanje: novo, max. workpiece length 4400 mm milling spindle 1 unit main motor 19.2 kW CNC machining center MASTERWOOD 4 WIN with automatic loading and unloading ----- Specially designed for efficient and flexible production of wooden windows and doors HIGHLIGHTS: - Various tool magazines for optimal tooling setup - Simultaneous loading of up to 6 workpieces - Patented clamping system for optimal workpiece machining - CNC-controlled worktable with automatic positioning of beams and clamps - Automatic reclamping for switching between external and internal profiling - INTEGRATED window manufacturing software; the machine does not have to (but can optionally) be operated via external industry-specific software from the office - Powerful 19.2 kW HSK-63 E motor - Loading and unloading conveyor - Additional table for arched window and door leaf processing Ksdpfx Asd Nv Dceh Dsnc Request a quote and see for yourself this unbeatable value for money! VIDEO of the machine attached! The technical description of the machine can be found in the PDF document on the right. We would also be pleased to take your used machine in part exchange at a fair price! (Technical data according to manufacturer – subject to change!)

Stanje: rabljeno, Leto izdelave: 2003, številka stroja/vozila: AP 133 D3, 5-axis machining center Balestrini IDEA 2 Axis travel range: X - 1500 mm Y - 1200 mm Z - 700 mm Working range: X - 100 mm Y - 2x500 mm Z - 600 mm Spindle power: 7.5 kW Table can be divided along its width 2 vacuum pumps included 4-position spindle Windows 2000 operating system Price stated is net Dismantling is the responsibility of the buyer Knjdowrb Uaspfx Ah Doc

Stanje: rabljeno, Leto izdelave: 2013, max. workpiece length: 5,130 mm Milling spindle: 1 unit Main motor: 18 kW Format 4 profit H30L e-motion CNC machining center ----- - Includes window tools and existing units - Includes Felder window construction software "Flash Frame" and existing programming - Machine from a small business, in very well-maintained condition, with low operating hours Machine can be inspected in operation until early December 2025! Technical Specifications: ----- Working dimensions: X: 5,130 mm Y: 1,360 mm Z: 130 mm Traverse paths: X: 6,050 mm Y: 1,790 mm Z: 280 mm - 4-axis milling spindle: 18 kW HSK F63 with liquid cooling, 1,000 - 24,000 rpm - Drilling head DH 20 6H1S: Vertical drilling unit with 14 spindles (9 spindles in X-direction, 5 spindles in Y-direction, groove saw in X-direction) - Carousel tool changer with 24 tool positions. Max. tool diameter 240 mm Max. tool height 370 mm - Side pick-up station for 2 tools/units Max. tool diameter 270 mm Max. tool height 270 mm - Moving pick-up station for chip deflector - Automatic table: 8 workpiece supports, e-motion position-controlled - Vacuum pump 90 m3/h - 6 double insert aids, x-motion or e-motion - Chip conveyor belt - Double straight line laser, line laser for arched processing - Handheld terminal for remote axis control - Includes all existing solid wood clamps and vacuum pads, as well as horizontal clamps - Automatic central lubrication - CE safety equipment - Software: "Flash Frame", software for window and frame planning "WOODFLASH" Program editor with CAD function 3D simulator with collision check for Woodflash on the machine - Tools: Wooden windows IV 68, IV 78, IV 92 Front door IV 68, IV 78 Lift-slide doors IV 68, IV 78, IV 92 Balcony door IV 68, IV 78 Knjdpfsxgu N Dox Ah Dsc Sale of tools in their current condition, scope, and with accessories as presently available. Note regarding window section drawings, tool diagrams, tool system listings: Company Engelfried does not guarantee that the tools actually available correspond to the specified or drawn systems. (technical specifications according to manufacturer – no guarantee!)

Stanje: novo, Maximum workpiece length: 3200 or 5100 mm Milling spindle: 1 unit Main motor: 12 kW Control: Beckhoff CNC Number of axes: 5 units Masterwood Project 385 CNC machining center 5-axis CNC machining center in gantry design, suitable for: Arched windows, doors, mullion and transom constructions, interior fittings, staircases Brief summary: ----- Working area: X = 3200 mm (optional 5100 mm); Y = 1500 mm; Z = 200 mm 1 x high-performance 5-axis spindle, 12 kW, with HSK 63 F interface 1 x fixed-installed drilling head with 19 spindles: • 7 individually selectable vertical drilling spindles in X-direction • 6 individually selectable vertical drilling spindles in Y-direction • 2 double horizontal drilling spindles in X-direction Kjdpfjd N Rt Tjx Ah Donc • 1 double horizontal drilling spindle in Y-direction Saw aggregate integrated in drill head 27 tool changer positions: • Carousel tool changer with 22 positions, 102 mm pitch • Linear tool magazine with 5 positions for large tool diameters Console table with 6 traverse beams Workpiece lifting device 6 special clamps for round window and door components 24 vacuum clamps for panels and interior fittings 1 vacuum pump, 100 m³/h 1 chip conveyor 1 remote control Construction software Masterwork: • 2D-WOP for standard panel machining / interior fittings, arched windows, doors Master 3D Level 2: • For more complex machining operations • Optionally upgradable for fully interpolating 5-axis machining Freight and installation within Germany Technology and services as per attached detailed description ----- Total price in this configuration: on request! ----- Optional extras with additional charges: ----- Working length 5,100 mm instead of 3,200 mm Including increased number of consoles and clamping elements Surcharge: €7,500.00 plus VAT Additional carousel tool changer with 16 positions, 102 mm pitch Surcharge: €6,500.00 plus VAT See attached PDF for detailed description. More options available on request! (Technical details according to manufacturer – without guarantee!)
