Nord-Lackierkabine24 GmbH

Stanje: novo, Leto izdelave: 2026, obratovalne ure: 1 h, Funkcionalnost: popolnoma funkcionalen, skupna višina: 3.450 mm, skupna dolžina: 7.000 mm, skupna širina: 5.400 mm, volumenski pretok: 25.000 m³/h, vrsta vhodnega toka: trifazni, skupna masa: 3.200 kg, delovna širina: 2.750 mm, trajanje garancije: 12 meseci, teža obdelovanca (maks.): 3.500 kg, notranja višina: 2.750 mm, notranja dolžina: 6.900 mm, nosilnost: 3.500 kg, notranja širina: 3.900 mm, ogrevalna zmogljivost: 213 kW (289,60 KM), filtrirna površina: 25 m², moč: 15 kW (20,39 KM), Oprema: dokumentacija / priročnik, kabina, nujno zaustavitev, osvetlitev, ⭐⭐⭐⭐⭐ Ventis Nexus 250 – Professional Paint Booth for Automotive Applications Reliable. Efficient. Designed for daily workshop use. ⭐ Brand new VENTIS paint booth for the price of an approx. 15-year-old used unit. You’re investing not in uncertainties, but in a modern, future-proof solution with comprehensive, verifiable documentation compliant with BImSchG, 31st BImSchV (VOC), TA Luft, ATEX, as well as CE conformity and manufacturer’s warranty. ❌ No inherited liabilities ❌ No costly retrofits ❌ No approval risks ✔ Standards-compliant spray booth with predictable operating and energy costs ⚙️ Technical Specification & Airflow Management The Ventis Nexus 250 is a fully enclosed spray booth with a complete vertical downdraft airflow system. Supply air is evenly introduced into the workspace through a full-surface ceiling plenum and directed vertically downward. This design complies with the requirements of DIN EN 16985 (formerly DIN EN 12215), ensuring homogeneous airflow with no dead zones. Supply and exhaust fans are direct-driven and controlled via frequency inverters, which allows the air volume to be precisely adapted to each mode of operation. The technical ventilation system meets all occupational safety and regulatory requirements for spray paint booths, ensuring stable process conditions. 🧼 Filtration System & Emissions Control The filtration system is engineered for fully compliant operation in accordance with BImSchG, 31st BImSchV, and TA Luft. 🔹 Supply Air Filtration: Multi-stage ceiling filters with diffusion media minimize the introduction of dust and particulates into the painting process. 🔹 Exhaust Air Filtration: High-efficiency filter stages reliably capture paint mist and particulate emissions. The configuration supports compliance with typical permit requirements for dust emissions, as well as, depending on application, TA Luft limits for organic substances in collected exhaust air (e.g. ≤ 50 mg total carbon per m³). ✔ Suitable for VOC-regulated operations ✔ Supports emission reduction strategies in line with 31st BImSchV 🔥 Heating Systems & Energy Concepts The Ventis Nexus 250 features modular construction and can be equipped with various heating systems according to customer requirements: ⚡ Gas heating (natural gas / LPG) ⚡ Oil heating ⚡ Electric heating systems Bjdex Tiz Djpfx Abhecu ⚡ Hybrid heating solutions Optional connection to external heat sources, e.g., central heating systems or industrial heat generators, is available. ♻️ Energy Efficiency & Environmental Protection Ventis places special emphasis on sustainable solutions: ✔ Ready for heat recovery (recuperation) from exhaust air ✔ Reduced energy consumption during drying cycles ✔ Option to integrate photovoltaic systems or other renewable energy sources ✔ Support for compliance with TA Luft and VOC requirements 🧱 Construction, Operation & Service Insulated sandwich panels (EPS, optionally PIR or mineral wool) with galvanized roof structure, designed for intensive, continuous professional use. 📐 Internal dimensions: approx. 7,000 × 4,000 × 2,750 mm 🌬️ Airflow capacity: approx. 25,000 m³/h 🚚 Delivery time: approx. 8–10 weeks 🛠️ Professional installation and commissioning within the EU 📄 Assistance with permits and technical documentation 🛡️ Manufacturer’s warranty: 12 months

Stanje: novo, Leto izdelave: 2026, obratovalne ure: 1 h, Funkcionalnost: popolnoma funkcionalen, skupna višina: 4.350 mm, skupna dolžina: 8.000 mm, skupna širina: 6.400 mm, volumenski pretok: 35.000 m³/h, vrsta vhodnega toka: trifazni, skupna masa: 3.800 kg, delovna širina: 3.500 mm, trajanje garancije: 12 meseci, teža obdelovanca (maks.): 4.200 kg, notranja višina: 3.500 mm, notranja dolžina: 7.900 mm, nosilnost: 4.200 kg, notranja širina: 4.900 mm, ogrevalna zmogljivost: 290 kW (394,29 KM), filtrirna površina: 32 m², moč: 22 kW (29,91 KM), Oprema: dokumentacija / priročnik, kabina, nujno zaustavitev, osvetlitev, ⭐⭐⭐⭐⭐ Ventis Nexus 350 – Professional Paint Booth for Vans & Buses Large-Format. Powerful. Engineered for Commercial Vehicles. ⭐ Brand-new VENTIS paint booth at the price of an approximately 15-year-old pre-owned system. You invest not in uncertainties, but in a modern, future-proof solution with complete, verifiable documentation in accordance with BImSchG, 31st BImSchV (VOC), TA Luft, ATEX, as well as CE conformity and manufacturer’s warranty. ❌ No legacy issues ❌ No costly retrofitting ❌ No approval risks Bsdpox Tiwrofx Abhecu ✔ Compliant paint booth for professional multi-shift operations ⚙️ Technical Specification & Applications The Ventis Nexus 350 is a large-format spray-paint booth, specifically designed for vans, panel vans, and buses. The spacious working volume, increased airflow capacity, and robust construction make it the ideal solution for body and refinishing shops in the commercial vehicle sector. The booth is designed for intensive, continuous professional operation and complies with current EU directives and German approval requirements. 🌬️ Airflow – From Ceiling Downwards The Ventis Nexus 350 operates with complete downdraft airflow, optimized for tall vehicles and long bodies. Supply air is evenly distributed across a full-area ceiling plenum and directed vertically downward. This design complies with DIN EN 16985 (formerly DIN EN 12215), ensuring even airflow over roof, side, and rear surfaces. 🧼 Filtration System & Emissions Control The filtration system is designed for approval-compliant operation in accordance with BImSchG, 31st BImSchV, and TA Luft. 🔹 Supply Air Filtration: Multi-stage ceiling filters with diffusion media reduce dust and particle ingress, ensuring reproducible surface quality. 🔹 Exhaust Air Filtration: High-performance filter stages reliably separate paint overspray and particulate emissions. The design supports compliance with emission limits for dust and, depending on application, with TA Luft thresholds for organic compounds in collected exhaust air (e.g., ≤ 50 mg total carbon per m³). ✔ Suitable for VOC-regulated operations ✔ Supports emission reduction strategies in accordance with 31st BImSchV 🔥 Heating Systems & Energy Concepts The Ventis Nexus 350 is modular and can be fitted with various heating systems to match customer requirements: ⚡ Gas heating (natural gas / LPG) ⚡ Oil heating ⚡ Electric heating systems ⚡ Hybrid heating solutions Optional connection to external heat sources is possible. Upon request, the system can be prepared or equipped for heat recovery (recuperation) from exhaust air. Integration into photovoltaic or other energy concepts is also feasible, reducing operating costs and meeting environmental requirements. 🧱 Construction, Operation & Service Insulated sandwich panels (EPS, optionally PIR or mineral wool) with galvanized roof structure, designed for high airflow and intensive usage. 📐 Internal dimensions: approx. 8,000 × 5,000 × 3,500 mm 🌬️ Airflow capacity: approx. 35,000 m³/h ⚙️ Total fan output: 22 kW 🛠️ Professional assembly & commissioning within the EU 📄 Support with approvals and technical documentation 🛡️ Manufacturer’s warranty: 12 months

Stanje: novo, Leto izdelave: 2026, Funkcionalnost: popolnoma funkcionalen, skupna višina: 2.550 mm, skupna dolžina: 2.430 mm, skupna širina: 2.330 mm, volumenski pretok: 1.000 m³/h, vrsta vhodnega toka: Klimatska naprava, skupna masa: 1.200 kg, trajanje garancije: 12 meseci, moč: 1 kW (1,36 KM), Oprema: dokumentacija / priročnik, kabina, nujno zaustavitev, osvetlitev, ⭐⭐⭐⭐⭐ Ventis Paint Mixing Lab – Professionelle Farbmischkabine Saubere Luft | Sichere Handhabung | Werkstattintegration ⚡ Professionelle Farbmischkabine für Karosseriewerkstätten und industrielle Lackierbetriebe ⚡ Kontrollierte Belüftung für sicheres Mischen und Handling von Lacken ⚡ Kompakte Bauweise – ideal zur Integration mit Lackierkabinen und Arbeitsvorbereitungsstationen ⚡ CE-konforme Lösung für professionelle Werkstattumgebungen 🔑 Hauptvorteile ✔ Kontrollierter Luftstrom für sicheres Farbmischen ✔ Effektive Abführung von Dämpfen und luftgetragenen Schadstoffen ✔ Verbesserte Arbeitssicherheit und Lackqualität ✔ Kompakte, modulare Konstruktion ✔ Für den täglichen, professionellen Werkstatteinsatz konzipiert 📐 Maße & Elektrische Daten Außenmaße: 2330 × 2430 × 2550 mm Stromversorgung: 220 / 380 V Installierte Leistung: ca. 0,5 kW 🌬️ Belüftung & Filtration Das Ventis Paint Mixing Lab verfügt über ein spezielles Belüftungssystem, das eigens für Farbmischvorgänge entwickelt wurde. Axialventilator: 370 W Hocheffiziente Filteranlage Kontinuierliche Absaugung von Dämpfen und luftgetragenen Partikeln Das gewährleistet: - Saubere Luft im Arbeitsbereich - Reduzierte Exposition gegenüber schädlichen Stoffen - Einhaltung professioneller Sicherheitsanforderungen in Werkstätten 🧱 Bauweise EPS-isolierte Wandpaneele, pulverbeschichtete Stahloberfläche Robuste Ausführung für den Werkstatteinsatz Leicht zu reinigende Innenflächen 🚪 Zugang Türdurchgang: 1800 mm Komfortabler Zugang für Personal und Material 💡 Beleuchtung Integrierte LED-Beleuchtung (16 W) Klare, gleichmäßige Ausleuchtung für sicheres und präzises Arbeiten Bcjdpfx Abex Thbvohju 🖥️ Anwendung ✔ Farbmischungen ✔ Materialvorbereitung ✔ Lagerung und Handhabung von Lacken und Beschichtungen Als dedizierter Mischraum konzipiert, reduziert Kontamination und verbessert den Arbeitsfluss zwischen Vorbereitungs- und Lackierbereich. 🛡️ Zertifizierung & Garantie ✔ CE-zertifiziert ✔ Herstellergarantie 🚚 Lieferung & Montage ✔ Lieferung als Komplettsystem ✔ Fachgerechte Montage und Inbetriebnahme möglich ✔ Integrationsunterstützung für bestehende Lackierkabinen und Vorbereitungsstationen 📩 Kontaktieren Sie uns für Verfügbarkeit, Optionen und ein individuelles Angebot. Das Ventis Paint Mixing Lab ist das ideale Modul für Werkstätten, die Sicherheit, Sauberkeit und Effizienz im Lackierprozess erhöhen möchten.

Stanje: novo, Leto izdelave: 2026, Funkcionalnost: popolnoma funkcionalen, skupna dolžina: 7.000 mm, skupna širina: 4.000 mm, volumenski pretok: 12.500 m³/h, vrsta vhodnega toka: trifazni, skupna masa: 1.800 kg, delovna širina: 4.000 mm, trajanje garancije: 12 meseci, notranja višina: 3.000 mm, notranja dolžina: 7.000 mm, filtrirna površina: 25 m², moč: 10 kW (13,60 KM), Oprema: dokumentacija / priročnik, nujno zaustavitev, osvetlitev, ⭐⭐⭐⭐⭐ Ventis Prep-Station – Profesionalna pripravljalna postaja Čist pretok zraka | Učinkovita priprava | Integracija v delavnico ⚡ Profesionalna pripravljalna postaja za brušenje, maskiranje in pripravo površin ⚡ Zasnovana za vsakodnevno uporabo v avtoličarskih delavnicah in centrih za popravilo karoserije ⚡ Optimiziran pretok zraka za odsesavanje prahu in zagotavljanje čistih delovnih pogojev ⚡ Modularna zasnova – enostavna povezava z lakirnimi kabinami in delavnicami ⚡ Rešitev skladna z zahtevami EU za profesionalna okolja 🔑 Ključne prednosti ✔ Čist in nadzorovan pretok zraka v pripravljalnem območju ✔ Učinkovito odsesavanje prahu in delcev ✔ Izboljšani delovni pogoji in kakovost površin pred lakiranjem ✔ Manjša kontaminacija, ki se prenese v lakirno kabino ✔ Kompaktna, modularna zasnova ✔ Prilagojena za intenzivno, vsakodnevno uporabo v delavnici 🌬️ Koncept pretoka zraka in prezračevanja Ventis Prep-Station je zasnovana za zagotavljanje stabilnega, usmerjenega pretoka zraka na delovnem območju, kar učinkovito odstranjuje prah od brušenja in druge leteče delce. Bcsdpfex Tg Syjx Abhsu - Optimiziran pretok skozi delovno območje - Učinkovito odsesavanje prahu in ostankov priprave - Čistejše okolje za operaterje in okoliške prostore Sistem omogoča: - višjo kakovost površin pred lakiranjem - manj popravkov in manj kontaminacij v lakirni kabini 🧱 Konstrukcija in zasnova - Robustna jeklena konstrukcija primerna za delavniška okolja - Modularna konfiguracija – možne enojne ali več-postajne postavitve - Prilagojeno za fleksibilno montažo in prihodnje nadgradnje 🧼 Filtracijski sistem Večstopenjski filtracijski sistem za učinkovito zajemanje prahu: - Primarni filtri za grobe delce - Finejša filtracija za zračni prah - Enostaven dostop za vzdrževanje in menjavo filtrov - Zagotavlja čist izpušni zrak in skladnost z delavniškimi standardi 💡 Razsvetljava - Vgrajena LED razsvetljava - Svetla, enakomerna in brez senc - Izboljšana vidljivost med brušenjem in pripravljalnimi deli 🖥️ Krmilni sistem - Enostavna in zanesljiva upravljalna plošča - Kontrola prezračevanja in razsvetljave - Prilagojeno za vsakodnevno uporabo v delavnici 📐 Konfiguracija in možnosti - Enojne ali več-postajne pripravljalne postaje - Integracija z lakirnimi kabinami in mešalnicami - Prilagojene dimenzije in postavitve po naročilu - Izbirne zaporne stene in različne konfiguracije pretoka zraka 🚚 Dostava in montaža ✔ Strokovna vgradnja in zagon na lokaciji ✔ Podpora pri integraciji v obstoječe delavnice ✔ EU-skladna dokumentacija 🛡️ Garancija in podpora ✔ 12-mesečna garancija proizvajalca ✔ Tehnična podpora in servis v EU

Stanje: novo, Leto izdelave: 2026, obratovalne ure: 1 h, Funkcionalnost: popolnoma funkcionalen, skupna višina: 3.450 mm, skupna dolžina: 7.000 mm, skupna širina: 5.400 mm, volumenski pretok: 25.000 m³/h, vrsta vhodnega toka: trifazni, skupna masa: 3.200 kg, delovna širina: 2.750 mm, trajanje garancije: 12 meseci, teža obdelovanca (maks.): 3.500 kg, notranja višina: 2.750 mm, notranja dolžina: 6.900 mm, nosilnost: 3.500 kg, notranja širina: 3.900 mm, ogrevalna zmogljivost: 213 kW (289,60 KM), filtrirna površina: 25 m², moč: 15 kW (20,39 KM), Oprema: dokumentacija / priročnik, kabina, nujno zaustavitev, osvetlitev, ⭐⭐⭐⭐⭐ Ventis Nexus 250 – Profesionalna avtomobilska lakirna kabina Zanesljiva. Učinkovita. Zasnovana za vsakodnevno delavnico. ⚡ Profesionalna popolna downdraft lakirna kabina za kleparske delavnice in centre za popravilo vozil ⚡ Inženirsko zasnovana za stabilen pretok zraka, čiste delovne pogoje in optimizirane obratovalne stroške ⚡ Načrtovana in dobavljena v skladu z EU veljavnimi predpisi 🔑 Ključne prednosti ✔ Popoln downdraft pretok zraka – dosledna kakovost barve in izvrsten nadzor pršenja ✔ Ventilatorji z neposrednim pogonom (DDF) in regulacijo preko frekvenčnega regulatorja – manjša poraba energije in vzdrževanja ✔ Stabilen pretok zraka v vseh načinih delovanja ✔ Konstrukcija iz izolacijskih sendvič panelov – toplotna stabilnost in zmanjšanje hrupa ✔ Zasnovano za intenzivno profesionalno uporabo vsak dan 🌬️ Koncept pretoka zraka – popolni downdraft Nexus 250 deluje v popolni downdraft konfiguraciji. Čist, filtriran zrak se dovaja skozi stropno difuzorsko komoro in enakomerno usmerja navzdol v delovno območje. Onesnažen zrak se odvaja preko visoko učinkovitega izpušnega sistema, kar zagotavlja: - enakomeren pretok zraka - manj onesnaženosti s prahom - visokokakovostni premaz 🔧 Ventilatorji in nadzor pretoka zraka Pretok zraka ustvarjajo visoko učinkoviti ventilatorji z neposrednim pogonom (DDF), ki jih digitalno uravnavajo frekvenčni pretvorniki (VFD). Prednosti: Bsdpfx Asx Tg Nfsbhscu - natančna regulacija pretoka zraka - manjša poraba energije - nižja raven hrupa - brez jermenov = manj mehanske obrabe in izpadov delovanja 🧱 Konstrukcija in izolacija Paneli-sendviči z izolirnim jedrom EPS za energijsko učinkovito delovanje Streha iz pocinkanega, proti koroziji odpornega jekla Vzdržljiva konstrukcija, primerna za zahtevna delavniška okolja 🔥 Ogrevalni sistem Nexus 250 je opremljen z integriranim ogrevalnim sistemom z gorilnikom Riello 40 G20, ki zagotavlja: - enakomerno razporeditev toplega zraka - stabilne pogoje za sušenje - krajši časi sušenja 🎨 Načini delovanja ✔ Način barvanja – popolni downdraft za čisto aplikacijo ✔ Način sušenja – reguliran pretok in temperatura za učinkovito sušenje 🧼 Filtracijski sistem Stropni dovodni filter z difuzijsko medijo Visoko učinkoviti izpušni filtri za zajemanje pršenja in zračnih delcev Čist izpušni zrak pred izpustom v okolje 🚪 Vrata, osvetlitev in dostop Štiridelna sprednja vrata iz aluminija s steklom – širok dostop in izvrstna preglednost Stranska tehnična servisna vrata za vzdrževanje Integrirana LED razsvetljava za svetlo in enakomerno osvetlitev 📐 Dimenzije in tehnični podatki Notranje dimenzije: pribl. 7.000 × 4.000 × 2.750 mm Zmogljivost pretoka zraka: pribl. 25.000 m³/h ➕ Opcijska oprema 15" HMI kontrolni panel na dotik Alternativna izolacija: PIR ali mineralna volna Integracija s pripravljalnimi postajami ali mešalnicami Pripravljeno za vgradnjo škarjastega dvigala v tla 🚚 Dobava in montaža ✔ Proizvodnja po naročilu ali dobava po dogovoru (8–10 tednov) ✔ Strokovna montaža in zagon po vsej EU ✔ Podpora pri dovoljenjih in dokumentaciji vključena 🛡️ Garancija in podpora ✔ 12-mesečna garancija proizvajalca ✔ Tehnična podpora in servis v EU 📩 Kontaktirajte nas za razpoložljivost, dobavni rok, možnosti konfiguracije in pripravo individualne ponudbe. Z veseljem vam svetujemo ter pripravimo rešitev, prilagojeno vaši delavnici.

Stanje: novo, Leto izdelave: 2026, obratovalne ure: 1 h, Funkcionalnost: popolnoma funkcionalen, skupna višina: 6.200 mm, skupna dolžina: 15.150 mm, skupna širina: 7.400 mm, volumenski pretok: 55.000 m³/h, vrsta vhodnega toka: trifazni, skupna masa: 8.200 kg, delovna širina: 6.000 mm, trajanje garancije: 12 meseci, teža obdelovanca (maks.): 12.000 kg, obratovalni tlak: 8 letvica, notranja višina: 5.500 mm, notranja dolžina: 15.000 mm, notranja širina: 6.000 mm, dolžina elektro omare: 15.000 mm, potreba po zraku: 500 m³/h, obratovalna temperatura: 80 °C, delovna višina: 5.500 mm, vhodna napetost: 380 V, ogrevalna zmogljivost: 448 kW (609,11 KM), moč: 52 kW (70,70 KM), Oprema: dokumentacija / priročnik, kabina, nujno zaustavitev, osvetlitev, ⭐⭐⭐⭐⭐ Ventis TITAN 550 – Industrijska in transportna lakirna komora Težka izvedba | Integrirano ogrevanje | DDF ventilatorji z VFD regulacijo ⚡ Profesionalna industrijska lakirna komora za tovornjake, avtobuse, prikolice in velike komponente ⚡ Zasnovana za neprekinjeno obratovanje v težkih pogojih ⚡ Integriran industrijski sistem ogrevanja že v osnovni opremi ⚡ Velik pretok zraka s preciznim elektronskim upravljanjem ⚡ EU-skladna rešitev za profesionalne delavnice 🔑 Ključne prednosti ✔ Ekstra prostorna delovna notranjost ✔ Popolno navpično zračenje za enakomerno kakovost nanosa ✔ Integrirano ogrevanje – serijsko ✔ Direktno gnani ventilatorji (DDF) z variabilnimi frekvenčnimi pogoni (VFD) ✔ Nižja poraba energije in manj vzdrževanja v primerjavi s sistemi z jermenskim pogonom ✔ Robustna izolirana jeklena konstrukcija ✔ Prilagojeno za večizmensko industrijsko uporabo 📐 Dimenzije Zunanje (D × Š × V): 15.150 × 7.400 × 6.200 mm Notranje (D × Š × V): 15.000 × 6.000 × 5.500 mm Napajanje: 380/400 V | 50–60 Hz | 3 faze 🌬️ Ventilacijski sistem – DDF + VFD Visoko zmogljiv industrijski prezračevalni sistem na osnovi direktno gnanih ventilatorjev (DDF) v kombinaciji z VFD regulacijo. Dovodni ventilatorji: 4 × 7,5 kW (DDF) Izpušni ventilatorji: 2 × 11 kW (DDF) Prednosti: - brez jermenov ali škripcev - natančna regulacija pretoka zraka - nižji hrup in manjša poraba energije - mehki zagon/ustavljanje in daljša življenjska doba komponent Zagotavlja stabilen pretok zraka, učinkovito izločanje overspraya in enakomerno kakovost premaza na velikih površinah. 🔥 Sistem ogrevanja Integriran industrijski ogrevalni sistem za velike volumne zraka. Gorilniki: 2 × Riello G20 Izmenjevalnik toplote: SUS304 nerjavno jeklo, 1,5 mm Bcjdpfx Absx Tf I Toheu Maks. temperatura pečenja: 80°C Ogrevalna zmogljivost: 20°C → 60°C v cca. 8–10 min Ogrevalne kabine izolirane z mineralno volno 🧱 Konstrukcija in pristop 75 mm EPS izolirane sendvič plošče 0,5 mm pocinkana jeklena obloga Glavna vrata: štirikrilna zložljiva, 5.000 × 5.000 mm Servisna vrata: 800 × 2.000 mm 💡 Osvetlitev in filtracija LED osvetlitev: strop in stranske stene, svetlo in brez senc Večstopenjski filtrirni sistem: - Primarni filter: >10 μm (≈83%) - Stropni filter: >4 μm (≈98%) - Stenski izpušni filter: steklena vlakna (≈70%) 🖥️ Krmilni sistem Inteligentna krmilna omara Integrirano upravljanje prezračevanja (VFD), ogrevanja, osvetlitve Načini lakiranja in sušenja Zaščita pred preobremenitvijo in izpadom faze 🚚 Dobava in podpora ✔ Profesionalna montaža in zagon po celotni EU ✔ Podpora pri dovoljenjih in tehnični dokumentaciji ✔ Tovarniška garancija in servis v EU 📩 Kontaktirajte nas za razpoložljivost, dobavni rok in individualno ponudbo. Ventis TITAN 550 je namenjen kupcem, ki zahtevajo največji prostor, natančen nadzor pretoka zraka in zanesljivo ogrevanje že v osnovi.

Stanje: novo, Leto izdelave: 2026, obratovalne ure: 1 h, Funkcionalnost: popolnoma funkcionalen, skupna višina: 3.450 mm, skupna dolžina: 7.000 mm, skupna širina: 5.400 mm, volumenski pretok: 30.000 m³/h, vrsta vhodnega toka: trifazni, skupna masa: 3.200 kg, delovna širina: 2.750 mm, trajanje garancije: 12 meseci, teža obdelovanca (maks.): 3.500 kg, notranja višina: 2.750 mm, notranja dolžina: 6.900 mm, nosilnost: 3.500 kg, notranja širina: 3.900 mm, ogrevalna zmogljivost: 290 kW (394,29 KM), filtrirna površina: 25 m², moč: 18 kW (24,47 KM), Oprema: dokumentacija / priročnik, kabina, nujno zaustavitev, osvetlitev, ⭐⭐⭐⭐⭐ Ventis Nexus 300 – Profesionalna avtomobilska lakirna kabina Zanesljiva. Učinkovita. Prilagojena vsakodnevni uporabi v delavnici. ⚡ Profesionalna popolnoma spodnja prezračevalna lakirna kabina za karoserijske delavnice in centre za ličanje vozil ⚡ Inženirsko zasnovana za stabilen pretok zraka, čiste delovne pogoje in optimizirane obratovalne stroške ⚡ Načrtovana in dobavljena v skladu s predpisi EU 🔑 Ključne prednosti ✔ Popolnoma spodnji pretok zraka – dosledna kakovost lakiranja in odlična kontrola pršenja ✔ Ventilatorji s direktnim pogonom (DDF) in frekvenčno regulacijo (VFD) – manjša poraba energije in vzdrževanja ✔ Stabilen pretok zraka v vseh delovnih režimih ✔ Konstrukcija iz izolativnih sendvič panelov – toplotna stabilnost in zmanjšan hrup ✔ Prilagojena za intenzivno profesionalno uporabo vsak dan 🌬️ Koncept pretoka zraka – Popolni spodnji tok (Full Downdraft) Nexus 300 deluje v konfiguraciji popolnega spodnjega toka. Čist, filtriran zrak se dovaja preko stropne perforirane komore in enakomerno usmerja navzdol skozi delovno območje. Zrak, onesnažen s prahom, se izsesa skozi visoko-učinkovit izhodni filtrirni sistem, kar omogoča: - uniformen pretok zraka - manjšo kontaminacijo s prahom - visoko kakovost lakirane površine 🔧 Ventilatorji in nadzor pretoka zraka Pretok zraka zagotavljajo visoko učinkoviti ventilatorji z direktnim pogonom (DDF), digitalno krmiljeni preko frekvenčnih pretvornikov (VFD). Prednosti: - natančna regulacija pretoka zraka - zmanjšana poraba energije - nižje ravni hrupa - brez jermenov = manj mehanske obrabe in zastojev 🧱 Konstrukcija in izolacija Izolativni sendvič paneli z EPS jedrom za energetsko učinkovito delovanje Streha iz protikorozijsko zaščitenega pocinkanega jekla Vzdržljiva konstrukcija, primerna za zahtevna delavniška okolja 🔥 Ogrevalni sistem Nexus 300 je opremljen z integriranim ogrevalnim sistemom z gorilnikom Riello RG5S, ki omogoča: - enakomerno distribucijo toplega zraka - stabilne pogoje za sušenje - krajši čas sušenja 🎨 Delovni načini ✔ Način lakiranja – popolni spodnji pretok zraka za čisto aplikacijo ✔ Način sušenja – reguliran pretok zraka in temperatura za učinkovito sušenje 🧼 Filtrirni sistem Stropna sesalna filtracija z difuzijsko tekstilijo Visoko učinkoviti izhodni filtri za zajem pršenja barve in prašnih delcev Čist izhodni zrak pred izpustom 🚪 Vrata, osvetlitev in dostop Štirikrila zastekljena sprednja vrata iz aluminija – širok dostop in odlična preglednost Stranska tehnična vrata za servisiranje Integrirana LED osvetlitev za svetlo in enakomerno osvetlitev 📐 Dimenzije in tehnični podatki Notranje dimenzije: cca 7.000 × 4.000 × 2.750 mm Kapaciteta pretoka zraka: cca 30.000 m³/h Bcedpfx Abex Tc Dxjhju ➕ Opcijska oprema 15'' HMI zaslonska nadzorna plošča na dotik Alternativna izolacija: PIR ali mineralna volna Integracija s predpripravnimi postajami ali mešalnicami Priprava na vgradnjo škarjastih dvižnih miz v tla 🚚 Dobava in montaža ✔ Izdelava po naročilu ali na zalogi (8–10 tednov) ✔ Strokovna montaža in zagon po vsej EU ✔ Podpora pri pridobivanju dovoljenj in dokumentaciji 🛡️ Garancija in podpora ✔ Tovarniška garancija 12 mesecev ✔ EU-tehnična podpora in servis 📩 Kontaktirajte nas za razpoložljivost, dobavni rok, možnosti konfiguracije in individualno ponudbo. Z veseljem vam svetujemo in pripravimo rešitev, prilagojeno vaši delavnici.

Stanje: dober (rabljeno), Leto izdelave: 2016, Funkcionalnost: popolnoma funkcionalen, Lakirna linija za usnje, delovna širina 1800 mm, z infrardečim sušilnikom, pralnikom zraka in hladilnikom. Bodpfox S Er Nsx Abhscu

Stanje: rabljeno, Leto izdelave: 2003, Funkcionalnost: popolnoma funkcionalen, Installation pour peinture liquide KRAUTZBERGER TECHNIQUE DE PULVÉRISATION avec unité de coalescence RODAP SR 185, année 2003 Installation de peinture liquide d'occasion pour le revêtement de surface de pièces métalliques (par ex. quincaillerie décorative/pièces en série). L'installation comprend la technologie de pulvérisation de Krautzberger ainsi qu'une unité de coalescence/séparation RODAP SR 185 pour le traitement/séparation (par ex. récupération du brouillard de pulvérisation, selon la configuration). Sont également inclus dans la livraison : chariots de pulvérisation et divers portiques de suspension pour une prise en charge flexible des pièces et la production en série. Domaine d'application : Peinture liquide / revêtement par pulvérisation de pièces et ensembles métalliques. Portée de la livraison : Technologie de pulvérisation Krautzberger + RODAP SR 185 + chariots de pulvérisation + portiques de suspension (divers). Visite : sur rendez-vous (possibilité de mise sous tension). Bcjdpfx Abjx Sqtroheu Démontage/chargement : à la charge de l'acheteur ou sur accord.

Stanje: rabljeno, Leto izdelave: 2003, Funkcionalnost: popolnoma funkcionalen, skupna višina: 4.000 mm, skupna dolžina: 7.100 mm, skupna širina: 8.100 mm, temperatura: 80 °C, ogrevalna zmogljivost: 116 kW (157,72 KM), Oprema: kabina, Komplette Nasslackieranlage mit Vorbereitungszone, Nasslackierkabine, Mischraum, Trocknungsofen und Abnahmezone. Anlage ist noch in Diest zu besichtigen. Weitere Details im Anhang oder auf Anfrage. - Abmessungen: LxBxH = 8.100 x 7.100 x 4.000 mm außen und 8.000 x 7.000 x 3.950 mm innen. - Höhe bis Unterkante der Schiene = 3.740 mm, gemessen ab Fußbodenniveau. - Mit gemeinsamer Schiebetür zur Lackierkabine. - Schiebetüren als Ofenausgang: BxH = 1.200 x 3.800 mm, ausgestattet mit 1 Fenster, 2 Flügel. Bcsdpfx Abex H Rhroheu - Notausgangstür mit Fenster in der Seitenwand: BxH = 800 x 1.900 mm, selbstschließend mit Türpumpe und Spanner. Die Notausgangstür ist mit großvolumigen, sehr elastischen EPDM-Dichtungen ausgestattet. - Wandtyp: Vertikale, doppelwandige Sandwich-Paneele gefüllt mit Mineralwolle, Stärke 55 mm. Inklusive: Beleuchtung, Lüftungsgruppe, Schaltschrank und ein komplettes Monorailsystem durch die gesamte Anlage bis in die Abnahmezone.

Stanje: rabljeno, Leto izdelave: 2018, Funkcionalnost: popolnoma funkcionalen, Prebijalni stroj, skoraj nerabljen, teža: 8500 kg. K lotu spada jeklena omara z vsebino. Vsebina vključuje orodje, rezervne dele in razno drobno opremo. Bcsdpfxoxzpvuo Abhou

Stanje: rabljeno, Leto izdelave: 1999, 1999 CM System D8 Zračni transporter (verižni lakirni sistem) za premikanje stolov ali podobnih izdelkov, obešenih na kavlje. Skupna dolžina 600 tekočih metrov. Kompletna oprema vključuje 2 rotacijski skodelici z diskom, električne omare, kavlje in različno opremo kot na fotografiji. Bedpfx Abexywnijhjcu Vlečna skupina: 2 motorizirani enoti Caterpillar srednjega tipa Delovna hitrost: min/max 0,9 m/min Moč motorja: 2 KM + 2 KM Veriga D8 s koluti premera 37 mm: 600 m Raven tir po meri: 531 m Horizontalni zavoji 90° r=500 mm: 91 kos Horizontalni zavoji 30° r=500 mm: 6 kos Vertikalni zavoji 30° r=500 mm: 26 kos Razmak med kavlji: 0,80 m

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2016, obratovalne ure: 10 h, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 20700114-2016, leto zadnje generalne obnove: 2025, Oprema: dokumentacija / priročnik, Batna črpalka naprodaj zaradi presežka opreme. Bcedpfsxyt T Ujx Abhsu Uporabljena je bila le za brizganje štirih vhodnih vrat z vodno osnovno pokrivno barvo, praktično kot nova! Brez pištole. Servis in deli so brez težav na voljo pri Hendrichs, Eupen ali B&M.

Stanje: rabljeno, Leto izdelave: 1999, 1999 CM System D8 Zračni transporter (lakirna veriga) za premikanje stolov ali podobnih izdelkov, barvanih na kljukah. Linearni metri: 80. Pogonska skupina: lahek motoriziran Caterpillar Delovna hitrost: min/maks 0,9 m/min Moč motorja: 2 HP Razvitje verige D8 in valji d. 37: 80 m Ravnalna tirnica po meri: 72 m Vodoravni zavoji 90° r=500 mm: 10 kosov Razmak kljuk: 0,80 m Bedpfxexyi Uus Abhscu Prostor, potreben za transport: 5 prostih metrov na tovornjaku

Stanje: novo, Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, skupna dolžina: 5.000 mm, skupna širina: 3.500 mm, skupna višina: 2.950 mm, notranja višina: 2.650 mm, notranja dolžina: 4.900 mm, notranja širina: 3.400 mm, Oprema: kabina, Vehicle Spray Booth The vehicle spray booth is a fundamental piece of equipment for paint repair technology. It allows paintwork to be carried out under safe and comfortable conditions while minimizing negative impacts on both the surrounding area and the environment. Technical specifications: - External dimensions: 5000 (+ air supply unit 1350 × 2900 mm) × 3500 × 2950 mm - Drive-through gate: 3000 × 2600 mm (triple-winged) - Service door: 700 × 2000 mm - Structure: made from steel sheet - Heat exchanger: standard steel - Panels: steel panels with mineral wool insulation in the walls Booth wall structure: - Thickness: 50 mm - Filling: EPS polystyrene - Colour: white Booth floor: - Booth mounted directly on floor / concrete slab Double ceiling: - Outer ceiling panel - Full-length plenum above the ceiling area for supply air Air exchange system: - Supply air system: - Jet turbine 4 kW – 2 units - Air capacity: 26,000 m³/h - Exhaust air system: - Jet turbine 5.5 kW – 1 unit - Air capacity: 18,000 m³/h Lighting: - 8 side lamps - Ceiling lighting: 24 LED fluorescent tubes Air heating system: - Single-stage oil burner Riello model 40 G20 - Burner control: manual - Heat-up time: 8–15 minutes Filtration system: Bsdpfsxnpczox Abhocu - Double-layer filter structure - High-performance air purification system with up to 99% filter efficiency

Stanje: novo, Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, skupna dolžina: 7.000 mm, skupna širina: 4.000 mm, skupna višina: 3.130 mm, notranja višina: 2.700 mm, notranja dolžina: 6.900 mm, notranja širina: 3.900 mm, Oprema: kabina, An automotive spray booth is a fundamental piece of equipment for refinishing technology, enabling painting operations to be carried out safely and comfortably while minimizing their negative impact on the immediate surroundings and the environment. Specifications: - External dimensions: 7000x4000x3130 mm - Internal dimensions: 6900x3900x2700 mm - Entrance gate: 3000x2600 mm (three-leaf) - Service door: 640x1800 mm - Structure: standard steel - Heat exchanger: standard steel - Panels: EPS polystyrene - Total power: 7kW - Installation: indoor use only Spray booth wall construction: - Wall thickness: 50 mm - Core: EPS polystyrene - Colour: white Bsdpfxexnbf Ue Abhjcu Spray booth base: - The booth is installed directly on the floor/screed - Booth intended for indoor installation only Double roof: - Upper external layer - Corrugated steel sheet panels - Internal structure - Partially latticed Air change system (supply system): - Jet fan 5.5kW – 1 unit - Airflow capacity: 20,000 m³/h - Belt-driven transmission - No air recirculation control Lighting (Side lights): - Side lamps: 20 units - No possibility to fit top lighting Air heating system: Single-stage Riello G10 oil burner 54-120 kW - Burner control: manual - Heat-up time: 20 minutes Booth access: Main door: - Dimensions: 3200x2600 mm - Three-leaf door system Service door: - Booth fitted with a service door - Equipped with pressure locks Booth filtration: - Intake: Pre-filter Ceiling filter: Primary (high-flow) filtration Filter specifications: - Weight: 600g/m³ - Thickness: 50 mm - Airflow: 900m³/h - Collection efficiency: 97% - Air velocity: 0.25m/s - Dust holding capacity: 650g/m³ - Max. temp.: 100°C - Filtration class (EN 779): M5 - Fire resistance (DIN 53438): F1

Stanje: novo, Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, skupna višina: 5.850 mm, skupna dolžina: 12.125 mm, skupna širina: 5.150 mm, skupna masa: 8.000 kg, trajanje garancije: 12 meseci, notranja višina: 5.000 mm, notranja dolžina: 12.000 mm, notranja širina: 5.000 mm, Oprema: kabina, osvetlitev, PAINT SPRAY BOOTH 12x5x5M EZ Series Model: - LED ceiling lighting - LED side lighting - RIELLO oil burner - Four fans, including: - 2x supply air fans - 2x exhaust air fans TECHNICAL SPECIFICATIONS: - External dimensions: 12125x5150x5850 mm - Internal dimensions: 12000x5000x5000 mm - Entrance gates: 4000x4800 mm (2 units, four-winged, with reinforced hinges) - Additionally, a BOX measuring 1650 mm x 8000 mm must be taken into account – can be positioned on the right or left side. - Construction: galvanized steel frame structure - Heat exchanger: high-quality stainless steel - Panels: filled with mineral wool - Drive-on ramps – 2 units - Fully grated floor The reinforced frame structure prevents vibrations and the air surge effect from the main supply air duct. Double-layered roof design: - Outer top layer - Inner truss construction with V600 ceiling filter Air circulation system: - Supply air system: jet turbine 7.5 kW – 2 units - Exhaust air system: jet turbine 7.5 kW – 2 units Air filter system: - Pre-filter captures particles >10 μm - Ceiling filter captures particles >5 μm - Floor filter: Paint Stop - Activated carbon filter Lighting: - Ceiling lighting: 52 LED fluorescent tubes (14 slanted fixtures, each with 4 tubes) - Side lighting: 26 LED panels integrated in the right, left, and rear walls Burner: Riello – 2 units, Oil model 40 G20, approx. 200,000 Kcal/h - Heat exchanger: high-quality stainless steel - Heating-up time: 8–15 min. (max. 80°C) Bcodpfx Ajxm U Exobhsu Optional equipment: - Boxes on the booth roof - Insulated roof - Pass-through doors - Water wall - Paint finish according to RAL color chart - EX version (explosion-proof) available

Stanje: novo, Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, skupna višina: 3.500 mm, skupna dolžina: 7.050 mm, skupna širina: 4.100 mm, volumenski pretok: 36.000 m³/h, temperatura: 80 °C, vhodna napetost: 380 V, ogrevalna zmogljivost: 250 kW (339,91 KM), Oprema: kabina, osvetlitev, Paint and Drying Booth It is the centerpiece of your entire painting operation: the combined paint and drying booth. Bcodpfx Aoxa H Ewjbhou (Alternatively, also available as a separate paint booth with a dedicated dryer). Here, we rely on full-surface ceiling filters and, optionally, full-surface floor extraction with drive-over grating panels or wall extraction at a position of your choice. If you want to further increase the efficiency of the system beyond heat recovery and stepless control via frequency converter, we are pleased to offer you a sectional control system. This allows you, during repair painting or partial loading of the booth (for example, if you only wish to paint add-on parts), to activate exclusively the section in which the components are located. This way, you can operate with a lower air volume without sacrificing quality, thus saving energy and ultimately real money. Please contact us—we will be happy to demonstrate these options to you. Do you have any questions or suggestions? We are gladly at your service.

Stanje: novo, Powder Coating Systems For years, powder coating has been evolving continuously as an alternative to wet painting, and especially recently, it has gained significant importance due to its lower environmental impact, as it does not generate solvent or paint sludge emissions. In particular, the ability to recover unused powder enables especially high efficiency levels. For users, powder coating has the advantage of providing an extremely durable and corrosion-resistant finish that is considerably more impact-resistant than conventional paint. Additionally, reworking, such as grinding or drilling coated parts, poses no problem and will not cause the coating to flake off. Pony Luxury Coating powder coating systems therefore deliver tangible benefits: they are efficient, environmentally friendly, and—true to our tradition—exceptionally flexible. We achieve this through a range of different plant types. Manual Powder Coating Systems Manual powder coating installations are the ideal solution for complex and challenging workpieces. With skilled personnel, there is continuous adaptation to changing circumstances and product sizes. Flexibility is paramount, and these systems also offer a cost-effective entry into the world of powder coating. Large-Capacity Powder Spray Booths No matter how large or demanding your workpieces are—our systems are even larger! Due to the high loads involved in commercial and utility vehicle applications, powder coating has established itself as the ideal solution here. To accommodate ever-larger components, we offer large-capacity powder coating booths that, combined with manual application, place no limits on workpiece size and, when used in conjunction with conveyor systems, can handle any dimension. Bcodpfx Aboxa Hzxshsu Automatic Powder Coating Systems If your operation requires high throughput and speed, an automated powder coating installation is your ideal solution. Coupled with conveyor systems, light curtains enable precise part detection and, therefore, exact dosing of powder for optimal efficiency. Of course, we also offer systems equipped with lifting stations and robots to handle even the most complex components. Powder Curing Ovens & Flash-Off Dryers The perfect finishing touch for any powder coating process: the curing oven. Our ovens, built to the highest insulation standard, extend our system-wide efficiency to this crucial stage. Detailed temperature control also allows use as a flash-off dryer to dry components after pretreatment. Temperatures of up to 250°C are possible, making these ovens suitable for use as tempering ovens—for example, with hot-dip galvanized parts. Of course, classic use as a powder curing oven is straightforward; optimal air distribution and a visualized control panel prevent overbaking and even enable simultaneous curing of different color shades. Questions or suggestions? We are always happy to help!

Stanje: novo, Oprema: kabina, Stationary small parts spray booth Dixi █████ Coating small parts perfectly & evenly. The extraction system ensures perfect results in the smallest spaces. Optionally equipped with a turntable or wheel mount, as well as a compact yet powerful extraction unit, it is ideally suited for processing small workpieces and rims. The side walls effectively limit overspray distribution, allowing work to be carried out in confined spaces without contaminating adjacent areas. Bodpfx Asxa Hx Rjbhscu Additionally, integrated lighting can be installed. Thanks to its low weight and minimal connection requirements, it can be relocated to a new site in a very short time, maintaining your operational flexibility at all times. The system is delivered fully pre-assembled and Your benefits Thanks to its compact design, flexible dimensions and adaptable accessories, a wide range of applications is possible without any issues. The sophisticated modular system requires little space, making it suitable for use in all types of rooms. The various filter media and filter stages ensure highly efficient operation and make filter changes a matter of just a few minutes. Application and safety Processing both water-based and solvent-based coatings is guaranteed thanks to the use of ATEX-approved explosion-proof motors. Optionally also suitable for glue spraying. The large filter surface ensures uniform extraction.

Stanje: rabljeno, Leto izdelave: 2024, Please find below information regarding our powder coating and wet painting line, which we commissioned last year in the Izmir Free Trade Zone. The plant is used for bicycle coating. Its dimensions are 680 × 680 × 2100 mm (L × W × H). Plant components: 1. 5-stage washing system, 2-stage plate heat exchanger, and heated stainless steel sheet 316 1.1. Water drying tunnel with reversing function, 135 m 1.2. Control panel 1.3. Medium-sized overhead conveyor 2.1. Labelling oven and conveyor belt, 75 m 2.2. Labelling area with air-conditioned roof and conveyor 3.1. Powder coating line, 135 m 3.2. Powder curing oven with 2 reversing functions 3.3. Powder coating booths are not owned by us, Wagner 2 powder coating booths 3.4. Medium-sized overhead conveyor 4.1. Wet painting line 4.2. Powder curing oven 4.3. Wet paint curing oven Bcsdpfsxa Expsx Abhou 4.4. Ventilation 4.5. 4 wet paint booths 4.6. 2 air-conditioned mixing rooms 4.7. 290 m conveyor 5.1. Labelling system, 90 m 5.2. Air-conditioned room on the roof The new price of the system was €2,800,000.00. This is a fully automatic powder and wet painting line. Individual purchase is possible as well. If you are interested, we would be pleased to provide further information.

Stanje: dober (rabljeno), Airless brizgalna naprava, lakirni aparat, Spraypack, naprava za brizganje barve, sistem za brizganje barve, lakirna črpalka, elektrostatična brizgalna naprava, airless kompletni sistem, pnevmatske batne črpalke, airless visokotlačna črpalka, zračni motor, AIR MOTOR -Proizvajalec: Wagner, Airless brizgalna naprava Tip: 33-70 s transportnim vozičkom in brizgalno pištolo -Maksimalni pretok materiala: 12,6 l/min Bodpfxow U T Ate Abhecu -Vhodni zračni tlak: max. 8 bar, delovni tlak max. 264 bar -Posamezne komponente: glejte fotografije -Dimenzije: 830/680/V1140 mm -Teža: 50 kg

Stanje: novo, Leto izdelave: 2025, skupna višina: 982 mm, skupna dolžina: 4.000 mm, skupna širina: 1.100 mm, volumenski pretok: 18.000 m³/h, trajanje garancije: 12 meseci, Suction wall with 18,000 m³/h MAX power consumption 5 kW/h Electric motor 4 kW Bcjdpfx Abjwz Ic Noheu Air unit 18,000 m³/h Nicotra ADH 400 The full description can be found in the attachment to this listing.

Stanje: novo, Leto izdelave: 2025, skupna višina: 4.000 mm, skupna dolžina: 7.000 mm, skupna širina: 3.000 mm, trajanje garancije: 24 meseci, temperatura: 80 °C, potreba po zraku: 36.000 m³/h, vhodna napetost: 380 V, ogrevalna zmogljivost: 345 kW (469,07 KM), moč: 40 kW (54,38 KM), gorivo: utekočinjeni naftni plin (LPG), poraba energije: 40 kWh, izolacijski material: Mineralwolle, debelina izolacije: 50 mm, nazivna moč: 345 kW (469,07 KM), Oprema: osvetlitev, MAIN SPECIFICATION Our spray booths are designed to meet all necessary requirements for paint application, including air filtration, extraction, lighting, and a controlled environment. All processes inside the booth are managed via a PLC system, ensuring consistent adherence to set values. OPERATING PRINCIPLES OF THE BOOTH Processes inside the booth are controlled via an operator panel, which manages the following steps: PAINTING PROCESS During painting, 100% fresh air is drawn from outside, passed through front filters, and directed into the plenum chamber at ambient temperature. The air is then expelled through the extraction unit. Floor filters (paint stop filters) capture paint particles, and the air passes through final exhaust filters before being released. FLASH-OFF PROCESS After painting, the booth continues to run for approximately 15 minutes to extract residual solvents and thinners. During this phase, fresh air from outside continues to circulate within the booth. DRYING PROCESS In this phase, 80% of the air circulating through the booth is heated to 60°C and supplied into the booth through a distribution system. As approximately 20% of the solvent is released during drying, it is expelled together with this air. Industrial coatings are typically cured at 60°C, but booth temperature can be adjusted via the operator panel as needed. COOLING PROCESS After the 30-minute drying phase, the heating coil is deactivated from the operator panel, the pneumatic damper closes, and the extraction system restarts. During the 5-minute cooling phase, fresh air from outside circulates in the booth, after which the system shuts down automatically. Bsdpfx Ajwzmcbjbhecu ELECTRICAL AND ELECTRONIC EQUIPMENT These control panels manage the functions and operation of all machinery and equipment inside the booth. The panel is made of durable galvanized sheet metal and steel sections and is fully enclosed to protect against dust and moisture. Electrical devices and control panel: • The control panel contains essential components such as circuit breakers, fuses, signal lamps, thermal relays, contactors, and connectors. • Heat-resistant cables are used for the command and control connections between the control panel and motors or other electrical equipment. • Electrical wiring is designed to allow for relocation of the booth if required. • Operating equipment uses 380 V 50 Hz, while control devices use 220 V. • The booth operating time can be monitored on the electronic panel for easy maintenance tracking. • Temperature and timer settings for flash-off, intermediate drying, and final drying can be easily programmed to the required values on the electronic control panel’s digital display. • Users can monitor and adjust drying times via the heating thermostat and timer relay.

Stanje: novo, Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, skupna višina: 5.600 mm, skupna dolžina: 11.200 mm, skupna širina: 5.100 mm, vrsta vhodnega toka: trifazni, trajanje garancije: 24 meseci, notranja višina: 4.970 mm, notranja dolžina: 11.000 mm, temperatura: 80 °C, notranja širina: 5.000 mm, potreba po zraku: 52.000 m³/h, vhodna napetost: 380 V, ogrevalna zmogljivost: 250 kW (339,91 KM), moč: 45 kW (61,18 KM), gorivo: utekočinjeni naftni plin (LPG), vhodna frekvenca: 50 Hz, poraba energije: 45 kWh, debelina izolacije: 50 mm, nazivna moč: 250 kW (339,91 KM), najv. debelina jeklene pločevine: 2 mm, Oprema: osvetlitev, * Air Treatment Unit: Bodjwzl Hxjpfx Abhocu The air treatment unit is a circulation system that supplies the cabin with filtered fresh air and extracts used air during the painting process. It heats the air to 60°C, mixes the exhausted air with 10% fresh air via an automatic multi-damper system, and reheats the air before recirculating it into the cabin. The air is heated by a burner and a heat exchanger, both made of high-grade 304 stainless steel and housed in the fresh air unit. During painting, the air is filtered twice (by pre-filters and ceiling filters) before entering the cabin. The polluted air is also filtered twice (inlet and exhaust filters) before leaving the exhaust unit. Air treatment units are insulated like the sidewalls to minimize heat loss and are protected against possible vibration and noise by rubber seals on the covers. The exhaust air is regulated by a damper in the exhaust duct, contributing to the control of the cabin’s internal pressure. *OPERATING PRINCIPLES OF THE CABIN:* The processes in the cabin are controlled via a control panel, which manages the following steps: *PAINTING PROCESS:* During painting, 100% fresh air is drawn in from outside and passed through the front filters before reaching the plenum at ambient temperature. The air is then discharged via the exhaust unit. Floor filters (paint stop) capture paint particles, and the air passes through the final exhaust filters before being released. *FLASH-OFF PROCESS:* After painting, the cabin runs for another 15 minutes to expel residual solvents and thinners. Fresh air from outside circulates in the cabin during this phase. *DRYING PROCESS* In this phase, 80% of the air flowing through the cabin is heated to 60°C and delivered into the cabin via a plenum. Since 20% of the solvent is released during drying, the solvent is expelled with this air. Industrial paints are typically dried at 60°C; however, the cabin temperature can be adjusted via the control panel as needed. *COOLING PROCESS:* After the 30-minute drying phase, the coil is deactivated via the control panel, the pneumatic damper closes, and the extraction system restarts. During the 5-minute cooling phase, fresh air from outside circulates into the cabin, and afterwards, the system stops automatically. ELECTRICAL AND ELECTRONIC EQUIPMENT: These control panels manage the functions and operation of the machines and devices integrated into the cabin. The control panel is made of durable galvanized sheet metal and steel profiles and is fully enclosed to protect against dust and moisture. Electrical Equipment and Switch Panels: • The control panel contains essential components such as contact breakers, fuses, indicator lights, thermal relays, contactors, and connectors. • Heat-resistant cables are used for command and control connections between the control panel and motors or other electrical devices. • The electrical wiring is designed to allow cabin relocation, if necessary. • Operating devices use 380 V 50 Hz, while control devices use 220 V.
