Eisele Lms 1 nakup rabljenega (106)

Stanje: rabljeno, Leto izdelave: 1994, Tehnični podatki: Premer žaginega lista: 450 mm Število vrtljajev: 2820 min⁻¹ Največja dolžina reza: 5000 mm Najmanjša dolžina reza: 240 mm Potreben zračni tlak: 6-8 bar Gtsdpsu Nigksfx Afqjt Premer izvrtine žaginega lista: 32 mm Kot reza v obe smeri: 45+90° Priključek za stisnjen zrak: 6–8 bar Skupna priključna moč: pribl. 4,6 kW Teža stroja pribl.: 1,1 t Dimenzije stroja (D x Š x V): pribl. 6,05 x 1,49 x 1,79 m Dodatne značilnosti stroja: - Vpenjalna naprava: pnevmatska, vertikalna in horizontalna - Pnevmatska naprava za meglenje - Višinsko nastavljive noge stroja - Materialne podpore pomične skupaj z žago - Dvoročno upravljanje - Števec kosov Premer reza v skladu s tabelo reznim diagramom, saj je odvisen od hitrosti in žaginega lista. Hitrost rezanja pri 2820 obr./min in premeru lista Ø = 66 m/sec. Oprema: - 2 rezervna žagina lista

Stanje: dober (rabljeno), Leto izdelave: 1967, Krožna žaga za kovino tip LMS I - Leto izdelave: 1967 - 380 Voltov - 1450 obr/min; 2950 obr/min Gsdpfx Ajxa Hkmsfqott - 1,8 kW

Stanje: dober (rabljeno), Leto izdelave: 2008, Schnittbereich rund | Sawing capacity round | 115 mm Max. Sägeblattdurchmesser | Max. saw blade diameter | 350 mm Schnittbereich rechteck | Sawing capacity rectangular | 200 x 70 mm Schnittbereich quadrat | Sawing capacity square | 105 x 105 mm Sägeaggregat | Sawing unit power | 6.5/8 kW Drehzahl der Sägewelle | Speed on sawing shaft | 1700/3400 rpm Maximale Vorschublänge | Maximum feed length | 9999 mm Kürzeste Vorschublänge | Shortest feed length | 10 mm Gewicht | Weight | 2300 kg Ausstattung / Equipment: - BEHRINGER SPS Steuerung / BEHRINGER PLC control - Micro-Sprüheinrichtung / Micro-spray lubrication system - Gesteuerte Nullkante / Controlled zero-point - Schnittspalterweiterung / Cutting width extension - Maschinenleuchte / Machine light Gsdperz Rw Rofx Afqott - Vertikale Hauptspannung / Vertical main clamping - Rücklaufsperre / Non-return device - Absauganlage vorbereitet – (Keller Absaugeinheit ist nicht Bestandteil der Lieferung) / Extraction system prepared – (Keller extraction unit not included in delivery) - Rollenbahn Zulauf ca. 5000 mm Marke Eigenbau / Roller conveyor infeed approx. 5000 mm, custom-made

Leto izdelave: 1967, Stanje: rabljeno, številka stroja/vozila: 9317, Saw blade Ø: 275 mm Cutting range at 90°: 120 x 75 mm Cutting range at 45°: 90 x 65 mm Saw blade speed: 2,000 rpm Drive motor: 380 V, 1.1 kW Gtedpeb N Eicjfx Afqjt Space requirement: 700 x 900 x 1,000 mm

Stanje: rabljeno, Leto izdelave: 1989, Saw blade diameter: 350 mm Cutting diameter: 115 mm Cutting range at 90 degrees: flat 200 x 80 mm Speed: 1700/3400 rpm Saw blade size: 350 x 3.3 x 40 mm Motor: 400 Volt Total power requirement: 1.8 / 2.6 kW Weight: approx. 600 kg Dimensions (L x W x H): 1000 x 850 x 1500 mm - In tested condition - machine video - ?v=k-VA1e8rSJI Features: - Semi-automatic aluminium circular saw - Pneumatic material clamping - Infinitely variable adjustment of saw head lowering speed Gtedpfjxabw Uox Afqjt - Machine table with mitre adjustment - Machine base

Leto izdelave: 2000, Stanje: rabljeno, Max. saw blade diameter: 350 mm Gtedpfxsw Ddzte Afqst Pneumatic material clamps Micro-spraying device Saw table swivels in both directions

Leto izdelave: 1998, Stanje: rabljeno, Longitudinal saw for cutting aluminium profiles with feed pusher, in very good condition Max. cutting length: 700 mm Max. cutting height: 130 mm Max. saw blade diameter: 450 mm Maximum feed length of material pusher: 6,200 mm The unit is dismantled and stored at our warehouse Gsdpfxewx I Hvs Afqett Further technical data available on request

Stanje: novo, Disponible sur stock / Livraison rapide ! Vitesse de rotation 17/34 tr/min. Pour lames de scie jusqu’à 350 mm de diamètre. Gsdpfx Aellvpwsfqott Avec moteur triphasé à commutation de pôles, 1,4/1,9 kW, bâti stationnaire avec dispositif de refroidissement intégré et tiroir à copeaux. Plage de coupe : Plat 90° 170 x 100 mm Plat 45° 120 x 100 mm Plat 30° 85 x 100 mm (uniquement à droite) Carré 90° 100 mm Carré 45° 95 mm Carré 30° 85 mm (uniquement à droite) Rond 90° 120 mm Rond 45° 120 mm Rond 30° 100 mm (uniquement à droite) Données techniques : Longueur 895 mm Largeur 665 mm Hauteur 1750 mm Poids 300 kg Hauteur de table 900 mm Options : Convoyeurs à rouleaux et systèmes de mesure de longueur (photo = exemple, disponibles en version manuelle ou automatisée, selon accord) Nous vous recommandons notre concentré de liquide de refroidissement éprouvé pour scies « Eisele » (depuis des décennies), notre huile de microspray (pour machines équipées d’un système de microspray), ainsi que des lames de scie circulaire et des rubans de scie de haute qualité pour répondre à vos besoins spécifiques. N’hésitez pas à nous demander un devis sans engagement !

Leto izdelave: 2004, Stanje: rabljeno, Technical details: Saw blade diameter: 450 mm Cutting diameter: 150 mm Saw blade bore: 50 mm Saw blade diameter: 400 - 450 mm Saw blade speeds: 6 / 12 / 24 / 45 rpm Cutting range at 90 degrees, square: 140 x 140 mm Cutting range at 90 degrees, round: 150 mm Cutting range at 90 degrees, flat: 400 x 30 / 345 x 70 / 300 x 95 mm Table size: Ø 700 mm Rotating table: 360 degrees Clamping pressure: 30 bar Electrical specification - voltage/frequency: 400 / 50 V/Hz Total power requirement: 3.6 kW Machine weight approx.: 1600 kg Machine dimensions: 1.5 x 1.0 x 2.35 m Gtedpfx Afou Nit Reqjt CIRCULAR SAW SEMI-AUTOMATIC - PROFILE CIRCULAR SAWING MACHINE - UNDERFLOOR SAW for cutting materials such as solid steel, pipes, and profiles within the specified cutting area. Cutting speed depends on the material to be cut. Circular saw with hydraulic material clamping (adjustable clamping pressure) Mitre adjustment +30° to -90° Fitted with electro-hydraulic controls Hydraulic pump 2.2 kW; 23 l/min Coolant system integrated in machine base Piece counter

Stanje: zelo dobro (rabljeno), Leto izdelave: 1966, I am selling a German-made circular saw, Eisele brand, model VMS II, in good condition. Gsdpfxovbwfns Afqstt

Stanje: dober (rabljeno), Leto izdelave: 2009, številka stroja/vozila: 10014344, Ponudba 25481 Tehnični podatki: - Premer žaginega lista do 350 mm - Pomik žaginega lista preko ročnega ročaja - Največja odprtina pnevmatskega primeža: 205 mm Gsdpfx Afsx Tqnfeqjtt - Območje rezanja - pri premeru žaginega lista 350 mm: - pri 90° okroglo: 120 mm - štirikotno: 110 mm - ploščato do 200 x 90 mm ali 140 x 110 mm - pri 45° okroglo: 100 mm - ploščato: 100 x 100 mm - Nastavljiv kot reza: levo do 45° - desno do 45° - 30° - 2 hitrosti vrtenja žaginega lista: 17 in 34 1/min - Pogon: 400 V / 1,4 / 1,9 kW - Priključek za zrak: 6 – 8 bar - Mikro razpršilo – naprava za hlajenje - Potreben prostor: pribl. Š 850 x V 1750 x G 950 mm - Teža: pribl. 400 kg

Stanje: dober (rabljeno), Leto izdelave: 1989, Funkcionalnost: omejena funkcionalnost, številka stroja/vozila: 8138, vrsta vhodnega toka: trifazni, vhodna napetost: 400 V, ❇️ Pressta Eisele AKF – Notching Mill / Notching Machine | Very Good Condition | Fully Functional | UVV Inspected For sale is a robust Pressta Eisele AKF notching mill from the metal and window construction sector. The machine is overall in very good, well-maintained, and fully operational condition. It was in active use until recently. A valid UVV/safety inspection is available (see badge/photos). ⚠️ Important Note: The pneumatic hoses on this machine show age-related material fatigue. ➡️ Recommendation: Replace the pneumatic hoses before commissioning (manageable effort). On-site inspection and function test are possible at any time. ⸻ ❇️ Machine • Manufacturer: Pressta Eisele • Model: AKF • Machine no.: 8138 • Year of manufacture: 1989 • Made in W.-Germany • Application: Notching of profiles in metal and window construction ⸻ ❇️ Features & Specifications • Heavy, low-vibration machine body • High-performance motor • Pneumatic feed and clamping functions • Sturdy worktable with clamping options • Protective covers included • Foot pedal operation • Maintenance-friendly design ⸻ ❇️ Condition • Mechanics and electrics: fully functional • Well-maintained overall condition • Note: Pneumatic hoses should be replaced due to age (see above) ⸻ ❇️ Dimensions • External dimensions (approx.): H 137 cm × W 99 cm × D 97 cm Gtodpfx Aex Rpfqjfqjt ⸻ ❇️ Terms • Sale on behalf of a customer • Invoice with VAT shown possible • Location: 72229 Rohrdorf • Loading by overhead crane on site possible • Delivery available by arrangement and at cost ⸻ ❇️ Price • Net price: €1,700 negotiable plus VAT ⸻ If interested, feel free to get in touch – viewing and test run possible by arrangement. ⸻ ⚠️ I am offering additional machines and accessories for window, metal, and workshop operations in my other listings. ‼️ Please also take a look at my other offers – it's worth it!

Leto izdelave: 1999, Stanje: rabljeno, Saw blade diameter vertical and horizontal: 500 mm Max. profile height: 280 mm Max. notch width: 300 mm Max. notch height: 185 mm Max. notch depth: 185 mm Gsdpfx Aovmz R Sjfqjtt Material stop swivels with locking points and digital display Notch height motorized adjustment with digital display Motorized angle adjustment with digital display Hydropneumatic material feed via two-hand operation Pneumatic material clamps Coolant lubrication

Stanje: novo, Primeren za številna področja uporabe, posebej tudi za fotovoltaično in avtomobilsko industrijo. Ponujamo vam popolnoma avtomatske krožne žage in celotna žagalna središča serij "Profilma", "KS" in "SW" z največjim premerom žaginega lista do 650 mm. Nakladalni in razkladalni sistemi so prilagojeni vašim potrebam. Učinkovit odsesovalni sistem z ločevalnikom oljne megle dopolnjuje udobje. Gtsdox E U Dnspfx Afqot Povprašajte nas – skupaj bomo našli optimalno rešitev za vašo proizvodnjo!

Leto izdelave: 2007, Stanje: rabljeno, Technical Details: Saw blade diameter: Ø 400 - 450 mm Saw blade bore: Ø 50 mm Spindle speeds: 6 / 12 / 24 / 48 (2-step) rpm Motor speeds: 1400 / 2800 rpm Cutting capacity at 90 degrees – round: Ø 150 mm Cutting capacity at 90 degrees – square: 140 x 140 mm Cutting capacity at 90 degrees – flat: 400x30 / 345x70 / 300x95 mm Table size: Ø 700 mm Rotating table: 360° Compressed air connection: 6 - 8 bar Total power requirement: 3.6 kW Machine weight approx.: 1,900 kg Machine dimensions: D: 1.5 x W: 1.0 x H: 2.35 m SEMI-AUTOMATIC CIRCULAR SAW – PROFILE CIRCULAR SAWING MACHINE – UNDERFLOOR SAW Profile circular saw with two-hand operation For cutting materials such as solid steel, pipes and profiles within the given cutting range. Cutting speed adjustable based on the material/type of workpiece. Mitre settings: 30° – 45° – 90° Saw blade feed rate adjustable Operating pressure/clamping pressure: 50 bar / 30 bar, adjustable Hydraulic pump: 2.2 kW Coolant system with pump Minimum quantity lubrication Piece counter Gtsdpfx Aju Nimqefqet Operation via control panel / two-hand control

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2024, Overhauled: 2024 Year of manufacture: 1994-2000 Saw blade: 560 mm Motor power: 6.5 / 8.0 kW Rotation speed: 1,500/3,000 rpm Cutting speed: 2,100 – 4,200 m/min Saw height adjustment: electronic Gtsdpfx Asuiy Hrofqot Working range (square): max. 170 x 170 mm Working range (flat): max. 300 x 150 mm Working range (round): max. 200 mm Saw feed rate: 0 – 40 mm/s, continuously adjustable Cut length: 5-950 mm (extension to 9,999 mm via multiple stroke) Feed speed (max.): 500 mm/s Weight: approx. 1,900 kg Dimensions (LxWxH): 2,200 mm x 2,700 mm x 1,950 mm The machine is in as-new technical and visual condition following a completed retrofit. Thanks to its equipment and design, the machine is highly efficient and versatile for a wide range of applications. The programmed HMI control system ensures easy and highly profitable operation of the plant. The soundproof cabin minimizes noise emissions to a very low level. The machine is fully overhauled at our premises according to customer specifications. Among others, the following components are renewed: - Conversion to Siemens S7 PLC control - Conversion to Siemens HMI operator interface - Replacement of the ball screw spindle - Replacement of servo motor and servo drive - New electrical components - New pneumatic lines - New pneumatic components - Overhaul or replacement of all pneumatic cylinders - Renewal of valve terminal - Optimization of extraction performance - Overhaul of the minimum quantity lubrication system - Replacement of general wear parts - Overhaul of the cabin Additional machine features: - Soundproof enclosure - Kerf expansion (for high-quality cut surfaces without return marks) - Fully electronic height adjustment Warranty: Unless otherwise agreed upon, we provide a 6-month warranty for our systems on all parts overhauled or replaced by us. Labor costs and wear parts are excluded from the warranty. Optional (available on request): - Bar clamping device for parallel sawing of multiple workpieces - Flat magazine for automatic loading of pre-materials up to 6 meters in length - Roller conveyors for pre-material - Reinforced 18.0 kW (frequency-controlled) motor - Delivery and installation at your facility - Training for your personnel

Stanje: dober (rabljeno), Commission trolley, tiered trolley, paint drying trolley, compartment transport trolley, transport trolley, window profile trolley, - Quantity: 1 commission trolley available Gsdsb Hw Dbopfx Afqott - Overall length: 1750 mm - Overall depth: 1020 mm - Overall height: 1670 mm - Bottom support: 720 mm - Support height: 1400 mm - Weight: 62 kg

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 1989, Premer žaginega lista: 350 mm Območje rezanja: pri 90° in 45° okroglo: 120 mm pri 90° ploščato: 170 x 100 mm pri 45° ploščato: 120 x 100 mm pri 90° kvadrat: 100 mm pri 45° kvadrat: 95 mm 2 hitrosti vrtenja žaginega lista: 17/34 obr/min Pogon motor: 400 V, 2/2,6 kW Teža: 425 kg Potrebni prostor: 900 x 800 x 1800 mm Gtodpfexln Ukjx Afqjt

Stanje: zelo dobro (rabljeno), Leto izdelave: 1999, O F F E R We can offer you, subject to prior sale and errors excepted, ex stock, without obligation: EISELE Circular Saw Machine for Straight and Mitre Cuts Gtedpfox A H Rrjx Afqet Model: VMS 370 Year of manufacture: 2000 _____ Maximum saw blade diameter: 370 mm Cutting capacity: Tubes approx.: Ø 130 mm Flat material: 200 x 100 / 140 x 100 mm Solid material, square: 120 mm Mitre cuts may achieve slightly reduced cutting dimensions, up to a maximum of 140 mm. Manual vertical saw carriage stroke: approx. 200 mm Saw blade speeds: 17–34 rpm Saw blade drive approx.: 2 / 2.6 kW Total drive power: approx. 3 kW — 380 V — 50 Hz Weight: approx. 500 kg Accessories/Special equipment: • Saw head adjustable for mitre cuts at 30° / 45° / 90°, scale indicated • Pole-changing three-phase motor with max. 2.6 kW power • Manual carriage feed with long, adjustable lever • Manual workpiece vice, jaw width approx. 120 mm • Integrated coolant system with chip collection tray • Roller table material feed, approx. 2,000 mm • New saw blade installed, 2 spare saw blades included • Electrical system recently renewed Ideal machine for metal fabrication and locksmith workshops. Condition: very good – demonstration ready – very smooth running Delivery: ex stock – as inspected Payment: strictly net – upon receipt of invoice We look forward to receiving your order. We also have further, larger EISELE cold circular saws and other (band/hacksaw/cold circular) saws in stock. Further sawing machines available at all times – please enquire.

Stanje: zelo dobro (rabljeno), Leto izdelave: 2007, Complete saw line consisting of loading unit, fully automatic circular saw, and unloading unit Suitable for a wide range of applications, especially in the photovoltaic and automotive industries. Loading Unit: Horizontal loading magazine, model HLM 4-strand timing belt conveyor 6 compartments, each 285mm wide, for profile storage; max. material height as per saw cutting range, round material max. diameter 130 mm 3 sliding rails between the belts as additional support Profile length min. 2,700 mm, max. 6,500 mm Saw: Fully automatic circular saw Pressta-Eisele model PROFILMA 510 E-SA Saw blade diameter max. 500 mm Continuously adjustable speed Hydropneumatic saw blade feed, continuously adjustable from rear to front Control: Siemens S7-300 with touchscreen Reversing device with 5-fold stroke up to max. 5,000 mm Electric material feed 3 – 1,000 mm (single stroke) Cutting slot extension on both sides Pneumatic unloading pusher Waste flap after the saw for offcuts / remnants Cut-off length: profile-dependent, from 8 mm Menzel minimum quantity lubrication Clamping pressure regulation Gjdpfx Aexvbvvjfqett 2 extraction nozzles for chip extraction Unloading: Table area: 1,500 mm x 2,500 mm Pneumatic cross pusher

Leto izdelave: 2011, Stanje: rabljeno, Technical Details: Saw blade diameter: Ø 400 - 500 mm Gsdpfx Afsu Niuhjqjtt Saw blade bore: Ø 50 mm Saw blade speed: 6 - 70 / stepless rpm Cutting capacity at 90 degrees, round: Ø 140 mm Cutting capacity at 90 degrees, square: 140 x 140 mm Cutting capacity at 90 degrees, flat: 400 x 30 / 345 x 70 / 300 x 95 mm Table size (LxW): 620 x 670 mm Height above floor: 1000 mm Total power requirement: 8 kW Machine weight approx.: 1170 kg The machine is currently located in the technical department. CIRCULAR SAW SEMI-AUTOMATIC – PROFILE CIRCULAR SAWING MACHINE Profile circular saw with two-hand control For sawing of materials: solid steel, pipes, and profiles within the specified cutting ranges. Cutting speed varies depending on the material/workpiece to be sawn Clamping pressure: 30 bar Clamping stroke (Ø x stroke): 100 x 160 mm Hydraulic pump Operation via control panel / two-hand operation Coolant system with pump

Stanje: zelo dobro (rabljeno), Leto izdelave: 2021, dolžina podajanja os X: 4.225 mm, dolžina pomika po osi Y: 530 mm, dolžina podajanja os Z: 410 mm, hitrost pomika os X: 80 m/min, hitrost podajanja osi Y: 30 m/min, hitrost podajanja os Z: 30 m/min,

Stanje: novo, Za obdelavo vseh standardnih aluminijastih okenskih profilnih sistemov kot so Schüco, Hueck, Heroal, Reynolds itd. Godpshmfyhofx Afqott Univerzalna uporaba zaradi dvakrat nastavljivih prebijalnih teles Za vogalne spojke z dimenzijo utora od 25–60 mm in premikom profilne komore 0–40 mm Neomejeno po višini nastavljivi tipala, prebijalna rezila in vstavki prislonov Tipala in prebijalna telesa so opremljena z lestvicami Vgradni prislon za enostavno vstavljanje profilov, samodejno nastavljiv ob pomiku proti profilu Hidravlična blokada prislona Pnevmatski stiskalni postopek prek vzvodnega sistema zagotavlja sinhron prebijalni postopek 2 pnevmatska vpenjalna cilindra za pritrditev profilov 2 ekscentrična diska za pozicioniranje okvirjev 2 zložljivi podporni roki za profile Upravljanje preko 2 nožnih ventilov Vključno s standardnimi orodji

Stanje: rabljeno, Technical Details: Saw Blade Diameter: 400 mm Cutting Diameter: 140 mm Saw Blade Bore: 50 mm Saw Blade Speeds: 6 / 12 / 24 / 48 rpm Cutting Capacity at 90° (round): Ø 140 mm Cutting Capacity at 90° (square): 130 x 130 mm Cutting Capacity at 90° (flat): 370 x 30 / 315 x 70 / 265 x 95 mm Table Size: Ø 700 mm Table Rotatable: 360 degrees Clamping Pressure: 8 - 30 bar Electrical Specification - Voltage/Frequency: 400 / 50 V/Hz Compressed Air Connection: 6 - 8 bar Total Power Requirement: 3.6 kW Approx. Machine Weight: 1,170 kg Machine Dimensions: D: 1.5 x W: 1.0 x H: 2.35 m Gtodpfx Afeu Niuzjqst CIRCULAR SAW SEMI-AUTOMATIC - PROFILE CIRCULAR SAW MACHINE - UNDERFLOOR SAW For cutting materials: solid steel, tubes, and profiles within the specified cutting range. Cutting speed depends on the material/workpiece to be processed. Mitre cuts from 30° to 90° Operation via control panel and two-hand operation Material clamping (opening width) adjustable with return stroke Saw blade feed rate adjustable Supplied without coolant system

Stanje: novo, Popolnoma avtomatsko žaganje in štancanje ali vrtanje v eni napravi! Za različna področja uporabe, predvsem pa za fotovoltaiko in avtomobilsko industrijo! Za uporabo z žaginimi listi Ø 500 ali 550 mm, z obračalnim mehanizmom do največje dolžine reza 4000 mm Avtomat za žaganje in štancanje Profilma 502 ST-V • za aluminijaste in plastične profile • za rezanje na dolžino in štancanje na osnovi modela Profilma 502 • popolnoma avtomatsko upravljanje Gedpfxsx Haftj Afqjtt in Avtomat za žaganje in vrtanje Profilma 502 BG • za aluminijaste in plastične profile • rezanje na dolžino, vrtanje in rezanje navojev do 4 profilov hkrati • popolnoma avtomatsko upravljanje
