Vrtalno-rezalni stroji nakup rabljenega (103)

Stanje: kot nova (razstavni stroj), Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, Tischgröße: 1120 x 280 mm T-Nuten im Tisch: 3 x 16 mm Längsverfahrweg des Tisches: 600 mm Querverfahrweg des Tisches: 250 mm Vertikalverfahrweg: 360 mm Spindeldrehung: +/-45° Abstand zwischen Tischebene und Spindelstirnfläche: 230–630 mm Maximale Spindeldrehzahl (vertikal): 108–2400 U/min Maximale Spindeldrehzahl (horizontal): 90–2000 U/min Spindelkonus: ISO 40 Spindelhub: 120 mm Leistung: 2,2/2,2 kW (V/H Spindel) Abmessungen: 1700 x 1450 x 2245 mm (B x T x H) Kdodoybb T Hepfx Af Teg Gewicht: ca. 1350 Kg Zubehör: - 3-achsiges SINO Bahnmesssystem - 3-stelliger x Spindelvorschub - 200-mm-Maschinenschraubstock - 45° drehbare Spindelkopfkonsole - Drehbare Konsole - Drehbarer Maschinentisch - 2 x Reduzierstück (ISO40/MK3, ISO40/MK2) - Bohrkopf mit Spannschaft, Durchmesser 3 – 16 mm - 2 Stück von horizontaler Frässpindel - 1 Stück von 15-teiligen Spannfutterset, Durchmesser 2 – 20 mm - Aufspannsatz - Arbeitsleuchte - Kühlwassersystem

Stanje: rabljeno, Leto izdelave: 1996, x-pomik 5000 mm y-pomik 2500 mm Velikost mize 2.000 x 2.500 mm Obremenitev mize 20.000 kg B-os (miza) (0,001º) mm w-os 2000 mm Kedpfsx Ak E Tjx Af Tsdg z-os 800 mm Hitri pomik 10.000 mm/min Vpenjanje ISO 50 Hitrost vrtenja 0–2.000 o/min Glavni pogonski motor 37 kW Navor 12–183 o/min Notranje dovajanje hladilne tekočine vključeno Ročno kolo HEIDENHAIN HR-410 Skupna potrebna moč 74 kW Teža stroja ca. 35 t -Nizka hitrost: 12–732 o/min -Visoka hitrost: 733–2.000 o/min -Hitrost pri konstantnem navoru: 12–183 o/min -Hitrost pri konstantni moči: 183–2.000 o/min

Stanje: rabljeno, Leto izdelave: 2009, x-travel: 3,000 mm y-travel: 2,500 mm z-travel: 2,475 mm w-axis: 800 mm Rotary table: Juaristi MG-12 Rotary table surface: 2,000 x 2,500 mm T-slots: 11 T-slot width: 170 mm Table load capacity: 8,000 kg Table rotation (B-axis): 0.001° CNC control: HEIDENHAIN iTNC-530 Quill diameter: 130 mm Spindle speed: 3,000 rpm Tool holder: ISO 50 DIN 69871/1-B Swiveling: +/- 2.5° Spindle motor: 30 kW Gear stages: 2 Speeds: 0–2,500 rpm Kjdpfxsu D I R Dj Af Tedg Boring spindle: D’ANDREA UT5-800-S mm/min Diameter: 800 mm Cross travel: 250 mm Tool changer: 30 positions Internal coolant supply: 20 bar Chip conveyor: included Handwheel: HEIDENHAIN HR-420 Machine weight: approx. 45 t Space requirements: approx. 9,800 x 7,320 x 5,500 mm - RENISHAW RMP-60

Stanje: zelo dobro (rabljeno), Control system: Heidenhain TNC 124 Travel X/Y/Z: 450/260/120 mm W-axis travel: 450 mm Clamping surface (L x W): 770 x 320 mm Permissible table load: 100 kg Distance table – spindle nose (min.–max.): 0–110–560 mm Feed rate X/Y: 1–2000 mm/min Quick-change tool system: SF 32 Stepless speed range: 100–9200 rpm Kdjdpfx Afeipmmue Tog Drive power: 5 kW Required space (W x D x H): 1500 x 1480 x 2330 mm

Stanje: zelo dobro (rabljeno), Leto izdelave: 1995, Funkcionalnost: popolnoma funkcionalen, High-precision drilling and milling machine Fehlmann Model Picomax 51 CNC Heidenhain TNC 360, very good condition, CE compliant Hthrgw39X Technical data: >> Year of manufacture: 1995 >> Travel X/Y/Z: 420 / 240 / 120 mm Kdjdpfsuxprlex Af Tjg >> W-axis travel: 450 mm >> Clamping surface (L x W): 730 x 280 mm >> Maximum table load: 75 kg >> Distance table – spindle nose: 0 – 560 mm >> Feed rate X/Y: 1 – 7200 mm/min >> Feed rate Z: 1 – 3600 mm/min >> Tool quick-change system SF 32 >> Stepless speed range up to 9,200 rpm >> Drive power: 4 kW >> Space requirement approx. (W x D x H): 2.0 x 1.5 x 2.4 m >> Fourth axis dividing head About the machine: For sale is a high-precision drilling and milling machine, Fehlmann model Picomax 51 CNC, in very good condition and CE compliant. It is equipped with a Heidenhain TNC 360 path control system. Programming is especially easy thanks to the user-friendly Heidenhain plain text dialog. HEIDENHAIN TNCs are workshop-oriented path controls that allow you to program milling and drilling operations directly on the machine in an intuitive plain text dialog. Tool holders (see photos) are included. Mechanically and electrically tested. Take advantage of the opportunity to view and test this machine under power on site.

Stanje: zelo dobro (rabljeno), Leto izdelave: 2001, Funkcionalnost: popolnoma funkcionalen, High-Precision Drilling and Milling Machine Fehlmann Model Picomax 54 Heidenhain TNC 310 Very good condition Technical Data: >> Year of manufacture: 2001 >> Travel X/Y/Z: 500 / 250 / 160 mm >> Travel W: 480 mm >> Clamping surface (L x W): 885 x 320 mm >> Permissible table load: 250 kg >> Distance table - spindle nose: 0 – 605 mm >> Feed rate X/Y: 1 – 2000 mm/min >> Feed rate Z: 1 – 1200 mm/min >> Tool quick-change system SF 32 >> Stepless speed range: 9200 rpm Kdsdpfxsukf Nce Af Tjg >> Drive power: 5 kW >> Space requirement (W x D x H): 1850 x 2550 x 2400 mm About the machine: Offered here is a high-precision drilling and milling machine Fehlmann Model Picomax 54 in very good condition. It is equipped with a Heidenhain TNC 310 contouring control. The program setup is particularly simple thanks to the user-friendly Heidenhain plain text dialog. HEIDENHAIN TNCs are workshop-friendly contouring controls that allow you to program conventional milling and drilling operations directly on the machine using the easy-to-understand plain text dialog. The machine runs very smoothly even at maximum spindle speeds. Mechanically and electrically tested. Take the opportunity to inspect and test this machine under power at our site.

Stanje: novo, SERRMAC TCS E TC Drill-Milling Machine (Cross Table) New "CE Marked" 3 years warranty Automatic feed High-efficiency transmission with electronic speed variator via vector inverter. Tool cooling system Tapping via inverter, complete with digital RPM counter Spindle shaft with thread for CM4 tool clamping Cross table dimensions: 800 x 255 mm Drilling capacity in steel R50: ø 50 mm Tapping capacity in steel R50: M26 Spindle taper: CM4 Spindle travel: 145 mm Quill diameter: 72 mm Automatic feed, 3 speeds: 0.05 – 0.1 – 0.2 rpm Kdedpfxjfh Si Us Af Tog Automatic feed with electromagnetic clutch, 3 speeds: 0.05 – 0.1 – 0.2 mm/rev Prismatic column Cross table Inverter drive I Spindle speed: 45 – 2150 rpm Motor power (380 V – 50 Hz): 3 kW T-slot size: 14 mm Cross table, manual X-axis travel: 585 mm Cross table, manual Y-axis travel: 240 mm Dimensions (h x w x d), at column: 1,986 x 1,340 x 1,280 mm Weight: 780 kg

Stanje: novo, Fervi T052/400VDA Column Drilling and Milling Machine. Available for immediate delivery unless sold. Equipped with automatic quill feed, selectable spindle rotation direction, and belt drive. Rack and pinion spindle with capacity 1 ÷ 13 mm, B16 taper; MT 3 spindle with through hole; milling cutter attachment MT 3 ø 27 mm; integrated coolant system. Drilling capacity with pilot hole: Ø 32 mm Milling capacity with indexable cutter: Ø 76 mm Ksdpjh Dbbgjfx Af Todg Milling capacity: Ø 20 mm Head travel: 405 mm Morse taper: MT 3 Spindle to column distance: 205 mm Maximum spindle axis to table distance: 700 mm Quill stroke: 130 mm Manual vertical feed graduation: 0.05 mm Quill diameter: Ø 75 mm

Stanje: pripravljen za uporabo (rabljen), CNC posteljna rezkalna stroj SECMU model C6 Velikost mize: 2200 x 700 mm Pomik X: 2000 mm Pomik Y: 1200 mm Pomik Z: 1000 mm ATC: 60 orodij Kompletno z univerzalno rezkalno glavo Kdsdexdduwspfx Af Tjg

Stanje: zelo dobro (rabljeno), Leto izdelave: 2002, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 540 mm, pomik osi Y: 240 mm, največja hitrost vretena: 1.650 obr/min, hitrost vretena (min.): 45 obr/min, nosilec vretena: MK 4, globina grla: 350 mm, poteza s peresom: 130 mm, skupna dolžina: 1.250 mm, skupna višina: 1.900 mm, širina mize: 225 mm, skupna širina: 1.100 mm, dolžina mize: 800 mm, zmogljivost vrtanja: 40 mm, nos vretena: MK-4, nazivna moč: 2,2 kW (2,99 KM), Drilling/milling machine, drilling capacity Ø 40 mm, 2-speed motor 1.9/2.2 kW, table size 800x225 mm, spindle speed 45-1650 rpm, stepless variator, MK-4, machine lamp, motorized table lift, automatic feed, fine adjustment, depth stop, coolant system, dimensions 1250x1100x1900 mm, weight approx. 600 kg. Kodpfx Afewt Swzs Tsdg

Stanje: zelo dobro (rabljeno), Leto izdelave: 2011, Funkcionalnost: popolnoma funkcionalen, največja hitrost vretena: 2.340 obr/min, hitrost vretena (min.): 32 obr/min, nosilec vretena: MK 4, globina grla: 293 mm, premer tulec: 72 mm, poteza s peresom: 145 mm, skupna dolžina: 1.340 mm, skupna višina: 2.050 mm, širina mize: 225 mm, skupna širina: 1.280 mm, dolžina mize: 800 mm, zmogljivost vrtanja: 50 mm, nazivna moč: 2,2 kW (2,99 KM), Drilling/milling machine with digital readout on 3 axes, drilling capacity Ø 50 mm, motor 2.2/3.0 kW, table size 800x225 mm, spindle speed 32-2340 rpm infinitely variable, MK-4, electric thread cutting device, machine lamp, coolant system, dimensions 1340x1280x2050 mm, weight approx. 780 kg. Kdsdown E Sbepfx Af Teg

Stanje: rabljeno, Leto izdelave: 2025, Premer vrtalne vretena: 130 mm Priključni stožec: ISO 50-7388/1 Premer rezkalne vretena: 200 mm Enosmerni motor: 22 kW Hitrost vretena: 10-1600 obr/min Hitri pomik osi: 6000 m/min z-os: 800 mm y-os: 2100 mm x-os: 3000 mm w-os: 1500 mm Velikost mizne plošče: 1250 x 1500 mm Kdedpfxsyacn Ne Af Tsg Največja nosilnost mize: 10.000 kg kW Hitrost vrtenja v hitrem pomiku: 3,5

Stanje: zelo dobro (rabljeno), HEIDENHAIN TNC-310 Travel paths: 500 x 260 x 480 mm (+ quill 160 mm) Cross-table: 880 x 320 mm Equipped with manual handwheels Kdsdpofrbtdofx Af Tjg Spindle speeds: 100–9,000 rpm Various accessories MARCELS MASCHINEN CH

Stanje: rabljeno, Leto izdelave: 1984, Teža 1,4 t Št. stroja: 227 Kodpfx Afenl Nq Hj Todg dobro splošno stanje: da

Stanje: dober (rabljeno), Leto izdelave: 1981, Ref. No.: 10447 Manufacturer: SKODA Model: WD 200 Year of manufacture: 1981 Retrofit: 2010 Control type: CNC CNC control: SIEMENS SINUMERIK 840D Warehouse location: Halberstadt Country of origin: Germany Kjdpox Sw Ezofx Af Tjdg X-axis travel: 9000 mm Y-axis travel: 4000 mm Z-axis travel: 1450 mm W-axis: 2000 mm Bed width: 2000 mm Bed height: 550 mm Spindle diameter: 200 mm Quill travel: 1600 mm Rotary table (L x W): 4000 x 4000 mm Table load capacity: 80,000 kg Clamping area: 3000 x 3000 mm Spindle speed: 257 – 2570 rpm Spindle taper: 120 Automatic feeds: 342 mm/rev Stepless spindle speeds: 1.5 – 630 rpm Max. torque at boring spindle: 20,000 Nm Rapid traverse: 16,000 m/min Spindle motor power: 9.8 – 35.5 kW Total power requirement: 75 kW Drilling depth: 2000 mm Vertical movement of spindle head on column: 3150 mm Cross movement of column on bed: 4000 mm Lowest position of spindle axis above bed: 1100 mm Spindle speed during quill feed forward: 1.6 – 300 max. rpm Stepless drilling feeds (spindle, quill): 1.6 – 1600 mm/min Stepless milling feeds (spindle head vertical, column horizontal): 1.6 – 1600 mm/min Machine length: 11,350 mm Machine width: 5,450 mm Machine height: 7,350 mm Machine weight approx.: 65 t Additional information: Thread cutting: 22 metric threads, pitch range 0.5 – 12 mm 32 Whitworth threads, pitch range 28 – 1 (TPI) Accessories: - Tool console - 1 set of operating tools - Discharge and clamping wedges for spindle - Grease gun - 1 set of spare parts for electrical equipment - Base plate for clamping - Steady rest with electrical equipment The machine can be inspected under power by appointment.

Stanje: rabljeno, Leto izdelave: 1971, Technical Details: Max. face turning diameter: approx. Ø 900 mm Spindle speed: 12.5 - 2000 / 24 steps rpm Faceplate speed: 8 - 190 / 12 steps rpm Feed rates (faceplate): 0.03 - 3 mm/step Rapid traverse (all axes): 2000 / 4000 mm/min Tool holder (work spindle): ISO 50 / SK50 Clamping area (table): 700 x 800 mm Table rotation: 360° Cross traverse of drilling table: 800 mm Max. table load: 1500 kg Total power requirement: approx. 11.0 kW Machine weight: approx. 7800 kg Dimensions (L x W x H): approx. 3.0 x 2.0 x 2.6 m Control cabinet dimensions: 1800 x 400 x 1950 mm Faceplate Ø: 420 mm Faceplate slide travel: 180 mm Max. face turning diameter: approx. 900 mm Longitudinal travel of column: 700 mm Vertical travel of spindle headstock: 700 mm Feed drive of column, spindle headstock and clamping table: - In spindle operation: 0.20 - 10 mm/rev, 34 steps - In faceplate operation: 0.16 - 16 mm/rev, with steps Kdjdpfx Afsu Idtpj Tsg Equipment: Optical precision measuring system/Heidenhain linear scale for X/Y/Z/C-table axes Hydraulics Machine feet/base plates Operator panel with pendant arm

Stanje: dober (rabljeno), Leto izdelave: 1996, številka stroja/vozila: 337794, Offre 25367 Données techniques : - Capacité de perçage : 25 mm Kdjdpfxex Tq Irj Af Tjg - Capacité taraudage : M 16 - Cône de broche de perçage avec écrou de serrage : CM 3 - Vitesses de broche de perçage : 100 / 205 / 330 / 420 tr/min 665 / 850 / 1375 / 2775 tr/min - Unité de perçage réglable en hauteur par manivelle - Distance min. / max. entre table et broche de perçage/fraisage : 60 / 390 mm - Course de broche : 130 mm - Réglage fin de la descente de broche par volant - Déport de broche de perçage : 260 mm - Unité de perçage/fraisage inclinable à gauche et à droite de 45° - Table à coordonnées avec 3 rainures en T : 580 x 240 mm - Course de table : Axe X 415 mm / Axe Y 155 mm - Étau-machine - Entraînement : 400 V / 0,65 / 0,9 kW - Encombrement env. : L 900 x H 1800 x P 700 mm - Poids env. : 270 kg

Stanje: dober (rabljeno), 1 x menjalno vrtalno-rezalni stroj Arboga UFB 3008 lepa stroj iz manjše orodjarne. Hitrosti: 100 - 3200 obr/min v 8 stopnjah / 2 preko motorja Vpenjanje: MK 3 Miza: 240 x 580 mm Dodatki: 1 x vrtalna glava 1 - 16 mm 1 x glava za rezanje navojev 4 x svedri MK 3 1 x primež 1 x delilna glava s 3-čeljustnim vpenjalom Stroj je možno pregledati pod napetostjo. Kedsx Rpxdopfx Af Tedg

Stanje: novo, Drilling capacity in steel (diameter): 13.0 mm X-travel: 300 mm Y-travel: 130 mm Speed: 100 - 2500 rpm Throat depth: 165 mm Kodexabb Hopfx Af Tsdg Spindle taper: MT 3 Table size: 490 x 120 mm Milling cutter diameter: 30.0 mm Motor: 230 Volt Total power requirement: 0.75 kW Machine weight approx. 50 kg Space requirement approx. 520 x 500 x 740 mm Description: - Brushless DC motor - Ensures optimal torque in the lower speed range - Dovetail guideways on X, Y, and Z axes - Backlash-free adjustable via gib strip - Milling head swivels both sides for angle drilling, bevel milling, etc. - Quill adjustment via handle, fine adjustment via handwheel - Precisely ground cross table with T-slots - Maintenance-free 500 W drive motor runs smoothly - Infinitely variable speed control for adaptation to the workpiece - Individually lockable guides ensure a clean milling finish Scope of delivery: - Geared drill chuck 1 - 13 mm / B16 - Drill chuck arbor MT 3 / B16 - Drawbar M12 - Height-adjustable safety guard - Operating wrench

Stanje: novo, Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, Tischgröße 800 x 240 mm Arbeitsfläche 730 x 210 mm „T“-Nutgröße auf dem Tisch 14 (M12) Drehzahlbereich 75 – 3200 U/min Bohrkapazität im Guss 45 mm Bohrleistung in Stahl 32 mm Längsbewegung (X) 560 mm Querbewegung (Y) 190 mm Vertikaler Verfahrweg (Z) 350 mm Werkzeughalter ISO40/Morze 4 Spindel-Säulen-Abstand 460 mm Abstand zwischen Spindelnase und Tischoberfläche: 445 mm Spindelhub 120 mm Gesamthöhe der Maschine in oberer Z-Position: 1450 mm Die Spindel ist im Bereich von +/-90° verstellbar Antriebsleistung 1,1/1,5 / 400 V Maschinengewicht 480 kg Abmessungen: 1280 x 960 x 2100 mm Zubehör: - Gewindeschneidfunktion - 3-achsiges Anzeigersystem - Y+Z-Achsenabdeckungen - ISO40 Bohrfutteradapter - Eingebauter digitaler Tiefenmesser - Automatischer stufenloser Vorschub und Eilgang auf der X-Achse - Motorisiertes Heben und Senken des Spindelstochs - Halogenlampe - Maschinenfuß aus Guss Die Maschine ist fabrikneu und war nie in Produktion. Kdodexz D Npepfx Af Tsg

Stanje: zelo dobro (rabljeno), Leto izdelave: 2009, Bernardo FM 45 V Drilling and Milling Machine The FM 45 V drilling and milling machine offers an excellent price-performance ratio thanks to its standard quill feed. The dovetail guide on the gear head ensures maximum precision and stability. Drilling capacity in steel: 32 mm Drilling capacity in cast iron: 40 mm Throat: 260 mm Spindle speed: (12) 50 - 2520 rpm Spindle taper: MT 4 Quill stroke: 120 mm Quill feed: (3) 0.12 / 0.19 / 0.26 mm/rev Table size: 820 x 240 mm Distance spindle / table: 40 - 485 mm Travel (x / y): 550 / 190 mm Vertical adjustment of milling head: 400 mm T-slot size: 14 mm T-slot spacing: 55 mm Motor output S1 100%: 0.85 / 1.1 kW (400 V) Motor input S6 40%: 1.1 / 1.5 kW (400 V) Machine dimensions (W x D x H): 1150 x 850 x 1450 mm Approx. weight: 285 kg Standard features include automatic quill feed and thread cutting device Kdsdpfx Afevutw Ho Tog Large speed range 50 - 2520 rpm (12 steps) Dovetail guideways for x, y, and z axes, adjustable via gib strips Versatile applications: slot milling, face milling, boring, etc. Heavy-duty, large cross table, precision-ground surface Milling: quill feed via handwheel Drilling: quill feed via handwheel High-quality aluminum motor, designed for continuous operation Sturdy and vibration-free cast iron construction Quick and easy speed changes using shift lever Tilting milling head for angle drilling, bevel milling, etc. Location: Ex-stock 54634 Bitburg - Available at short notice -

Stanje: novo, Leto izdelave: 2025, Heavy, robust cast construction High running smoothness due to ground, oil-bath lubricated gearbox gears Right-/left-hand rotation Automatic quill feed with manual fine adjustment Motorized positioning of the Z-axis Motorized table feed of the X-axis Coolant system Machine lamp Gear head swivels ± 60° Adjustable gib strips Heavy-duty hand-scraped dovetail column guide for maximum stability and precision Height-adjustable, large protective shield with microswitch Drill depth stop Digital position display DRO 5 Drilling / tapping function Heavy, large dimension cross table, precisely surface-machined with T-slots and adjustable gib strips Sturdy cast machine base with chip tray Single-stage quality industrial electric motor Wide speed range from 60 - 2,760 rpm via 2 steplessly adjustable speeds Dimensions and weights Length approx. 1600 mm Width/Depth approx. 930 mm Height approx. 2110 mm Weight approx. 495 kg Drilling/milling capacity Max. cutter head size: 63 mm Max. shank cutter size: 26 mm Drilling capacity (steel S235JR): 24 mm Continuous drilling capacity (steel S235JR): 20 mm Electrical data Connection voltage: 230 V Network frequency: 50 Hz Electrical connection Total connected load: 1.5 kW Milling table (horizontal) Length: 800 mm Width: 240 mm Distance vertical spindle – milling table max.: 420 mm T-slot size: 14 mm Number of T-slots: 3 T-slot spacing: 80 mm Standards and approvals Standard: DIN EN 55011 EMC class: C2 Travel X-axis manual: 560 mm Y-axis manual: 195 mm Z-axis manual: 350 mm X-axis automatic: 480 mm Vertical spindle Reach: 258 mm Spindle mounting: MT 4 Speed range: 60 – 2,760 rpm Number of speed ranges: 2 Ksdpog U Uv Uofx Af Tjdg Speed control: electronic Drawbar: M 16 Swivel range of milling head Z – X plane: ± 45° Quill diameter: 75 mm Quill stroke: 120 mm Location: Available from stock 54634 Bitburg - immediately available -

Stanje: novo, Distance between spindle and table: 470 mm Total power requirement: 2.2 kW Approx. weight: 1,200 kg Dimensions (LxWxH): Length 2,400 mm, Width/Depth 2,160 mm, Height 2,300 mm Spindle speed: 60–4,200 rpm - Heavy-duty design made from high-quality Meehanite cast iron - High rotational accuracy thanks to tapered roller bearings, measured at less than 0.01 mm in the quill - Stepless speed control - Forward/reverse operation for thread cutting - X and Z axes with adjustable 55° dovetail guideways - Y-axis with flat guideway - Drilling-milling head tiltable ±45° - Coolant system - Forward and reverse operation - Automatic quill feed, 3-step (0.04 – 0.15 mm/rev) - Motorized feed in X, Y, and Z axes - Precision microfeed - Milling spindle with precision bearings - Mechanical spindle brake - Drilling depth scale and stop - Cross table with T-slots and coolant groove - Centralized lubrication - Height-adjustable safety shield with microswitch for optimal operator protection from flying chips and parts - Robust and large cross table, precision-machined surface with T-slots MF 4-B: - Cross table load capacity: 300 kg - Large travel distance: X / Y / Z axis 740 mm / 330 mm / 320 mm Dimensions and weights Length: 2,400 mm Width/Depth: 2,160 mm Kdsdpfx Afod H Hhzs Tjg Height: 2,300 mm Weight: 1,200 kg Drilling and milling capacity Max. face mill diameter: 76 mm Max. shank cutter diameter: 25 mm Drilling capacity in steel (S235JR): 24 mm Continuous drilling capacity in steel (S235JR): 20 mm Electrical connection Total connected load: 3 kW Supply voltage: 400 V Phase(s): 3 Ph Current type: AC Mains frequency: 50 Hz Horizontal table Length: 254 mm Width: 1,370 mm Max. vertical spindle-table distance: 405 mm T-slot size: 16 mm Number of T-slots: 3 T-slot spacing: 63 mm Max. load capacity: 300 kg Horizontal spindle Overhang: 0–420 mm Coolant system Coolant pump drive power: 90 W Motor(s) Vertical spindle normal operating power: 2.2 kW Standards and approvals Standard: DIN EN 55011 EMC class: C2 Travel X-axis manual: 820 mm Y-axis manual: 410 mm Z-axis manual: 400 mm X-axis automatic: 740 mm Y-axis automatic: 330 mm Z-axis automatic: 320 mm Vertical spindle Overhang: 0–420 mm Spindle mount: ISO 40 DIN 2080 Speed range: 60–4,200 rpm Number of speed ranges: 2 Speed regulation control: mechanically stepless Swivel range milling head X-Y plane: 90° Swivel range milling head Z-X plane: 45° Quill diameter: 86 mm Quill stroke: 127 mm Quill feed: 0.04/0.08/0.15 mm/rev Milling head travel Z-axis: 470 mm VPE: 1

Stanje: novo, Leto izdelave: 2025, Our ZX7045 B1 milling and drilling machine is designed for drilling, tapping, reaming, boring, and enlarging holes up to 45/40 mm in cast iron, as well as tapping up to M12 mm. The ZX7045 B1 version comes standard with automatic spindle feed and an efficient cooling system, providing not only excellent performance but also optimal working conditions. With a milling capacity of up to 80 mm width, slotting up to 22 mm, and the ability for face cutting and milling, this milling and drilling machine becomes an indispensable tool for a variety of applications. Product Features HEAVY, STABLE CAST IRON CONSTRUCTION AUTOMATIC SPINDLE FEED MILLING HEIGHT ADJUSTED ON THE SUPPORT, NOT THE COLUMN ADDITIONAL LIQUID COOLING SOLID CROSS TABLE WITH PRECISELY GROUND SURFACE DOVETAIL GUIDEWAYS QUIET OPERATION THANKS TO GROUND GEARS LEFT AND RIGHT ROTATION SWIVEL HEAD +/- 90° ADJUSTABLE HEAD HEIGHT Machine base available as an optional extra TECHNICAL DATA: DRILLING CAPACITY IN STEEL: 32 mm DRILLING CAPACITY IN CAST: 45 mm FACE MILLING CUTTER DIAMETER: 80 mm END MILL DIAMETER: 28 mm SPINDLE SPEEDS: 50, 95, 100, 180, 190, 355, 360, 655, 710, 1260, 1310, 2520 rpm (6/12) SPINDLE TAPER: MT 4 SPINDLE TRAVEL: 125 mm (AUTOMATIC FEED) TABLE DIMENSIONS: 820 mm x 240 mm BASE DIMENSIONS: 580 x 600 mm MAX. DISTANCE SPINDLE TO TABLE: 445 mm DISTANCE SPINDLE TO COLUMN: 260 mm X/Y/Z AXIS TRAVEL: 515/175/430 mm QUILL FEED RATE: 0.12; 0.18; 0.25 mm/rev HEAD SWIVEL RANGE LEFT/RIGHT: 90° Kdsdpfxsvxth Hs Af Tjg MOTOR POWER: 1.8 kW / 2.5 HP VOLTAGE: 400 V WEIGHT: 350 kg

Stanje: novo, Leto izdelave: 2025, Order today the CORMAK ZX 7550 CW – a compact universal milling machine, ideal for toolrooms and maintenance departments. This highly versatile machine is ready for immediate operation, available directly from stock. Discover the specifications that make the ZX 7550 CW stand out in the marketplace: Machine Features - Automatic Table Feed on X and Y Axes: Achieve precision and efficiency with automatic table feed in two directions. Obtain excellent results with minimal effort. - Mechanical Table Feed on Z Axis: Benefit from innovative Z-axis feed, allowing fast, precise material processing. Reduce work time without compromising quality. - Heavy-Duty Cast Iron Frame: The robust machine construction ensures stability and longevity. The heavy cast iron casting guarantees machining precision and repeatability. - Massive Cross Table with Precisely Ground Surface: Manufactured with attention to detail, the cross table features a precisely ground surface for exceptionally smooth material finishing. - Dovetail Guideways on All 3 Axes: Innovative dovetail guideways provide maximum movement precision in all three axes. Achieve high accuracy without compromise. - Quiet Operation Thanks to Ground Gears: Operate with minimal noise. Thanks to ground gears, the machine runs smoothly and quietly, ensuring operator comfort. - Left and Right Spindle Rotation: Adapt the operation to your needs. The machine features bidirectional spindle rotation for greater flexibility in material processing. - +/- 90° Swiveling Head: Rotate the head in any direction. The +/- 90° swivel head allows for versatile application, adapting the machine to a wide range of projects. The CORMAK ZX 7550 CW is not just a milling machine – it’s a tool built to meet even the most demanding challenges. Order today and discover excellence in material machining! Specifications: Max. drilling diameter: 50 mm Max. horizontal milling length: 100 mm Max. vertical milling diameter: 25 mm Max. thread cutting diameter: M16 Max. boring diameter: 120 mm Spindle taper: ISO 40 Spindle speed range and number (vertical, 50Hz): 115–1750 rpm (8 steps) Spindle speed range and number (horizontal, 50Hz): 60–1350 rpm (9 steps) Distance spindle–column: 200–700 mm Distance spindle–table: 100–480 mm Spindle travel: 120 mm Table size: 1000×240 mm Table travel: 600×230 mm Table feed: 24–720 mm/min (8 steps) Spindle feed: 0.015, 0.08, 0.25 mm/rev Number/width/pitch T-slots: 5 / 14 mm / 44 mm Motor (Vertical/Horizontal): 0.85–1.5 / 1.5 kW Overall dimensions: 1120×1060×2035 mm Weight: 970 kg Equipment (depending on version): Kjdpfeud Icqex Af Tjdg - 3-axis digital readout SINO - ISO 40/Morse reduction sleeves - Drill chuck 1–16 mm - EC Declaration of Conformity - Machine vice L – 160 mm - Milling arbor with pair of collet chucks for end mills - Horizontal arbor support/steady rest - Long milling arbors - Basic tools - 24V halogen lighting system - Coolant system - Operating manual in English
