Portalske rezkalne stroje nakup rabljenega (147)

Stanje: dober (rabljeno), Leto izdelave: 2003, potovalna razdalja osi X: 13.000 mm, pomik osi Y: 4.500 mm, pomik po osi Z: 1.000 mm, največja hitrost vretena: 30.000 obr/min, razdalja med stojali: 6.500 mm, nos vretena: HSK A63, X-axis: 13,000 mm Y-axis: 4,500 mm Z-axis: 1,000 mm Distance between columns: 6,500 mm C-axis: 190º A-axis: 110º Rapid traverse XYZ: 15,000 mm/min Kedpfstt I Sfex Aqqolt Rapid traverse AC: 10 rpm CNC control: Siemens 840D Spindle mount: HSK A63 Spindle speed: 30,000 rpm Spindle power: 20 kW Tool changer: 20 positions Torrestool tables: 16 units X-axis: 11,500 mm Y-axis: 3,500 mm Z-axis: 750 mm Country of origin: Spain Machine dimensions (L x W x H): 19,000 x 11,000 x 6,770 mm Machine weight: 70,000 kg The Torresmill Gantry is a 5-axis CNC milling and drilling machine, specially designed for machining aeronautical materials (composite, aluminum, titanium, steel, etc.). The Torresmill Gantry combines perfectly with the Torrestool universal clamping system, ensuring flexibility and reduced cycle times.

Stanje: dober (rabljeno), Leto izdelave: 2004, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 3.750 mm, pomik osi Y: 1.870 mm, pomik po osi Z: 700 mm, skupna dolžina: 9.000 mm, dolžina mize: 4.000 mm, širina mize: 1.650 mm, skupna širina: 3.500 mm, največja hitrost vretena: 6.000 obr/min, skupna višina: 3.500 mm, razdalja med stojali: 2.300 mm, največja hitrost vrtenja: 6.000 obr/min, skupna masa: 30.000 kg, Oprema: vrtilna hitrost brezstopenjsko nastavljiva, X-os: 3.750 mm Y-os: 1.870 mm Z-os: 700 mm CNC krmiljenje: Heidenhain iTNC 530 Vpenjalna glava: ISO 50 Obrati vretena: 6.000 min⁻¹ Menjalnik orodij: 30 mest Dimenzija mize: 4.000 x 1.650 mm Razmak med stebri: 2.100 mm Opremljen z: - Kotna rezkalna glava Klsdpfxoyac T Ej Aqqjt - Tipalna sonda - Notranje hlajenje vretena - Dvojni odstranjevalci ostružkov - Hladilna naprava - Navodila za uporabo Država porekla: Tajvan Dimenzije stroja (DxŠxV): 9.000 x 3.500 x 4.000 mm +/- Teža stroja: 30.000 kg

Stanje: rabljeno, Leto izdelave: 2008, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 3.150 mm, pomik osi Y: 1.850 mm, pomik po osi Z: 1.000 mm, hitrost pomika os X: 30 m/min, hitrost podajanja osi Y: 30 m/min, hitrost podajanja os Z: 24 m/min, največja hitrost vretena: 24.000 obr/min, vrtilni moment: 87 Nm, CNC Fidia C20 Kodpfx Asyw Tddeqqjlt WORKING AREA X-axis longitudinal travel: 3,150 mm Y-axis transverse travel: 1,850 mm Z-axis vertical travel: 1,000 mm MAXIMUM AXIS SPEED X and Y axes rapid traverse: 30 m/min Z axis rapid traverse: 24 m/min WORKPIECE TABLE Clamping surface: 3,000 x 1,600 mm Maximum permissible load: 5,000 kg/m² T-slots: - 8 longitudinal H12 + 1 H8 - Width: 22 mm - Pitch: 160 mm ELECTROSPINDLE: Maximum power (S6 60%): 55 kW Spindle speed range: 240 ÷ 24,000 rpm Constant power range: 6,000 ÷ 24,000 rpm Maximum torque: 87.5 Nm Tool holder: HSK – A63 C-axis stroke: ± 200° C-axis speed: 2,000 °/min C-axis offset from spindle axis: 75 mm A-axis stroke: +95° / -110° A-axis speed: 2,000 °/min Max. distance spindle nose – table surface: 1,175 mm Machine equipped with: • 24-position tool magazine • Remote electronic handwheel • HMS head calibration system • Various auxiliary equipment supplied with the machine • Operation and maintenance manual and CE declaration of conformity

Stanje: zelo dobro (rabljeno), potovalna razdalja osi X: 11.000 mm, pomik osi Y: 4.500 mm, pomik po osi Z: 1.250 mm, skupna dolžina: 25.200 mm, dolžina mize: 10.000 mm, širina mize: 4.500 mm, skupna širina: 11.200 mm, skupna višina: 5.500 mm, obremenitev mize: 30.000 kg, razdalja od središča mize do nosu vretena: 1.500 mm, WALDRICH COBURG MULTITECH 3500 FT GANTRY MILLING MACHINE WITH MOVING CROSSBEAM CNC Siemens Sinumerik 840 D TABLES (No. 2): Mounting width: 3,000 mm Front table mounting length: 4,500 mm Rear table mounting length: 4,500 mm Mounting length with coupled tables: 10,000 mm T-slots in longitudinal direction: 28 mm/H8 Slot spacing: 250 mm Max. load on front table: 20,000 kg Max. load on rear table: 20,000 kg Max. load with coupled tables: 30,000 kg Clear width between uprights: 3,500 mm Clear height between table and spindle nose of vertical spindle unit VS 125 C/150: 1,500 mm TRAVELS: Table, longitudinal (X axis): -Table 1: 5,000 mm -Table 2: 5,000 mm -Coupled: 11,000 mm Milling and drilling unit, horizontal (Y axis): 4,500 mm Spindle slide, vertical (Z axis): 1,250 mm Crossbeam (W axis): 1,000 mm MILLING/DRILLING UNIT TYPE M4: Drive power: 45 kW Milling and drilling unit speeds: -1st range: 5-1,300 rpm -2nd range: 40-6,000 rpm Automatic indexing of horizontal spindle units in 1° steps from 0–360° AUTOMATIC TOOL CHANGER FOR TOOLS AND MACHINING UNITS ROBOT: -Double gripper for tool change on vertical and horizontal spindle units -Double gripper for changing machining units on milling and drilling unit Tool flange diameter: 97.5–125 mm Max. tool weight: 50 kg Max. machining unit weight: 750 kg RACK-TYPE TOOL MAGAZINE: Number of racks: 4 Total number of tool stations: 192 Total number of machining unit stations: 4 Tool holders according to DIN 69871 ISO 50 Distance between stations: 140 mm Max. tool diameter in all stations stocked: 135 mm Max. tool diameter: -Standard: 250 mm -With direct feed by shuttle cart: 315 mm Max. tool length: -Standard: 375 mm -In the uppermost row of the magazine: 600 mm OVERALL DIMENSIONS: Total machine length: 25,200 mm Total machine width: 11,200 mm Total machine height from floor: 5,500 mm EQUIPPED WITH: -No. 01 vertical spindle ISO 50 length 300 mm -No. 01 vertical spindle ISO 50 length 450 mm -No. 02 90° heads -Part probing with Renishaw probe Kodsydmkvopfx Aqqolt USED MACHINE

Stanje: dober (rabljeno), Leto izdelave: 2017, obratovalne ure: 9.380 h, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 4455, numerically controlled machining center max. panel sizes: 4,000 x 2,300 mm 1 Kuka KR420R3300 robot 1 Kuka KR200L140 robot 1 Kuka KRL140-3Comp robot conveyor belt for scrap metal removal Ruwac Zone 22 extraction system Kedpfx Aer E D Eaeqqolt

Stanje: zelo dobro (rabljeno), Leto izdelave: 2016, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 4.000 mm, pomik osi Y: 2.200 mm, pomik po osi Z: 1.100 mm, dolžina mize: 4.500 mm, širina mize: 2.500 mm, največja hitrost vretena: 22.000 obr/min, CNC Heidenhain iTNC 640 WORKING AREA X-axis longitudinal travel: 4,000 mm Y-axis transverse travel: 2,200 mm Z-axis vertical travel: 1,100 mm Maximum interpolated feed rate: 50 m/min WORKTABLE Kljdpfx Aeyv In Isqqet Dimensions: 4,500 x 2,500 mm Height: 300 mm Load capacity: 15 T/m² T-slots for workpiece clamping: 28 mm DIN 650 (H12), complete with leveling pads. T-slot direction aligned parallel to the Y-axis movement. UNIVERSAL CONTINUOUS POSITIONING HEAD FOR ELECTROSPINDLE Automatic universal head indexed at 360,000 positions (every 0.001°). Rotational movement is driven by direct drive motors and controlled by the CNC as a positioning axis. Automatic tool clamping. Allows for 10° undercuts. Internal cooling system for bearings and axis motors. Rotation range C-axis: +/- 270° Rotation range A-axis: +/- 185° Maximum rotation speed of axes: 30 rpm Maximum working torque on A/C axes: 450 Nm Clamping torque on axes: 1,400 Nm Spindle output power (S1/S6): 22/33 kW Spindle output torque (S1/S6): 84/128 Nm Maximum spindle speed: 22,000 rpm Constant power speed range: 3,000 to 18,000 rpm Constant torque speed range: 10 to 3,000 rpm Tool holder: HSK – A63 DIN 69893 ELECTROSPINDLE HSK – A100 WITH SEMI-AUTOMATIC CHANGE SYSTEM: Spindle output power (S1/S6): 37/43 kW Spindle output torque (S1/S6): 140/165 Nm Maximum spindle speed: 15,000 rpm Constant power speed range: 2,500 to 12,000 rpm Constant torque speed range: 10 to 2,500 rpm Tool holder: HSK – A100 DIN 69893 55-POSITION CHAIN TOOL MAGAZINE, HSK - A100 / HSK – A63: Floor-mounted fixed chain magazine located at the rear of the machine, enclosed for operator safety, with a vertical tool change arm and automatic tool preparation. "Fixed position" management. Hydraulic axis locking Total tools: 55 Tool type: HSK-A63 DIN 69893 Tools: 30 Maximum tool diameter: 90 mm Maximum tool diameter with adjacent slots free: 160 mm Maximum tool length: 300 mm Maximum tool weight: 10 kg Tool type: HSK-A100 DIN 69893 Tools: 25 Maximum tool diameter: 100 mm Maximum tool diameter with adjacent slots free: 160 mm Maximum tool length: 450 mm Maximum tool weight: 20 kg REQUIRED CONNECTIONS: Maximum installed power: 177 kVA Maximum required current: 235 A Machine equipped with: • Remote electronic handwheel Heidenhain HR550 • High-pressure water and air through spindle • Semi-automatic electrospindle change, with HSK – A63 and HSK – A100 interfaces • Assorted tooling included • Renishaw probe • BLUM laser presetter • AUTOCAL automatic head calibration system • Visormax remote monitoring subscription • Electrical cabinet air conditioner • Cooling system for all axes and the electrospindle • User and maintenance manual and CE declaration of conformity

Stanje: zelo dobro (rabljeno), Leto izdelave: 2018, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 6.000 mm, pomik osi Y: 2.700 mm, pomik po osi Z: 1.500 mm, hitrost podajanja osi Y: 50 m/min, dolžina mize: 6.000 mm, skupna širina: 3.000 mm, največja hitrost vretena: 22.000 obr/min, hitro pomikanje X-os: 50 m/min, hitri pomik os Y: 50 m/min, hitri pomik na osi Z: 50 m/min, nos vretena: hsk 100, CNC Heidenhain iTNC 640 WORKING AREA X-axis longitudinal travel: 6,000 mm Y-axis transverse travel: 2,700 mm Z-axis vertical travel: 1,500 mm Maximum interpolated axes speed: 50 m/min WORKTABLE Dimensions: 6,000 x 3,000 mm Height: 300 mm Load capacity: 15 T/m² T-slots for workpiece fixing: 28 mm, DIN 650 (H12), complete with leveling screws. T-slots direction parallel to Y-axis movement. UNIVERSAL HEAD WITH CONTINUOUS POSITIONING, ELECTROSPINDLE HOLDER Automatic universal head indexed to 360,000 positions (every 0.001°). Rotation movement driven by direct drive motors and controlled by CNC as positioning axes. Automatic tool clamping. Allows for a 10° undercut. Internal cooling system for bearings and axis motors. C-axis rotation range: +/- 270° Kedoyvtt Njpfx Aqqjlt A-axis rotation range: +/- 185° Maximum axis rotation speed: 30 rpm Maximum available torque on A/C axes: 450 Nm Axis clamping torque: 1,400 Nm Spindle available power (S1/S6): 22/33 kW Spindle available torque (S1/S6): 84/128 Nm Maximum spindle speed: 22,000 rpm Constant power speed range: 3,000 to 18,000 rpm Constant torque speed range: 10 to 3,000 rpm Tool holder: HSK-A63 DIN 69893 HSK-A100 ELECTROSPINDLE WITH SEMI-AUTOMATIC REPLACEMENT SYSTEM: Spindle available power (S1/S6): 37/43 kW Spindle available torque (S1/S6): 140/165 Nm Maximum spindle speed: 12,000 rpm Constant power speed range: 2,500 to 12,000 rpm Constant torque speed range: 10 to 2,500 rpm Tool holder: HSK-A100 DIN 69893 CHAIN TOOL MAGAZINE FOR 55 TOOLS, HSK-A100 / HSK-A63: Floor-mounted fixed chain magazine located at the rear of the machine, enclosed for operator protection, equipped with arm for vertical tool change, with automatic tool preparation. "Fixed position" management. Axis clamping by hydraulic control Total tools: 55 Tool type: HSK-A63 DIN 69893 Tools: 30 Max tool diameter: 90 mm Max tool diameter with adjacent free slots: 160 mm Max tool length: 300 mm Max tool weight: 10 kg Tool type: HSK-A100 DIN 69893 Tools: 25 Max tool diameter: 100 mm Max tool diameter with adjacent free slots: 160 mm Max tool length: 450 mm Max tool weight: 20 kg REQUIRED CONNECTIONS: Maximum installed power: 177 kVA Maximum required current: 235 A Machine complete with: • Remote Heidenhain HR550 electronic handwheel • High-pressure coolant (water and air) through the spindle • Semi-automatic electrospindle change with HSK-A63 and HSK-A100 adapters • Wide range of tooling included with the machine • Renishaw probe • BLUM laser presetter • AUTOCAL automatic head calibration system • Visormax subscription for remote monitoring • Electrical cabinet air conditioning unit • Axis and electrospindle cooling system • User and maintenance manual and CE declaration of conformity

Stanje: rabljeno, Leto izdelave: 1996, Funkcionalnost: omejena funkcionalnost, CNC Gantry Milling Machine (Milling/Turning Center) | Manufacturer: DÖRRIES SCHARMANN | Model: 4FZT | Year of manufacture: 1996 A high-performance gantry milling machine designed for the machining of large workpieces. Main areas of application are the milling and turning of large, complex workpieces. The machine can be inspected under power by appointment. Condition: As per year of manufacture, partial overhaul required. This is a very high-quality machine, therefore absolutely worthy of modernization/complete overhaul – highly recommended. TECHNICAL DATA: Main dimensions: - Machine width: 13,230 mm - Machine height above floor: 8,450 mm - Machine length: 31,100 mm - Machining length: 11,000 mm - Passage width: 4,400 mm - Passage height from table surface to spindle nose of standard milling head: 3,000 mm Kodpfoyuptzex Aqqelt Table: - Table width: 3,450 mm - Total table length: 13,400 mm - Single table length: 6,200 mm - Total clamping area: 3,450 x 11,000 mm - Clamping area single table: 3,450 x 5,000 mm - Maximum permissible workpiece weight total table: max. 112 t - Maximum permissible workpiece weight single table: max. 80 t Crossbeam: - Travel: 2,000 mm Milling and drilling support: - Drive power for milling and drilling operations (spindle): 80 kW - Max. spindle speed: 2,500 rpm EQUIPMENT / ACCESSORIES: - 2 tables - 8 machining heads - Control system: SINUMERIK 880 - 2 x chip conveyors - Documentation - CE marking No guarantee for completeness or accuracy of technical specifications and equipment. Subject to prior sale. A detailed technical data sheet and further information on equipment available on request.

Stanje: novo, Leto izdelave: 2024, obratovalne ure: 50 h, številka stroja/vozila: 305, Available: February 2023 Control system: Osai X-axis: approx. 3,100 mm Y-axis: approx. 2,100 mm Z-axis: approx. 1,000 mm Kedpewwq Hcjfx Aqqolt A-axis: ± 115° C-axis: ± 360° Clamping Table Clamping surface: approx. 3,100 x 2,100 x 213 mm Aluminium with T-slots, crosswise every 250 mm Max. load: 1,000 kg evenly distributed over the entire surface 2-axis milling head ST7 Spindle power: 10 kW Spindle speed: max. 24,000 rpm Torque: 15.3 Nm Tool holder: HSK 63F Tool clamping: pneumatic Blow air / MQL: external Linear axis drives Feed rate X and Y axes: up to 50 m/min Feed rate Z axis: up to 30 m/min Colour Enclosure, gantry, control cabinet: light grey Z-slide and milling head: orange Additional equipment - 15-position tool changer - Control unit in separate, mobile console

Stanje: novo, Leto izdelave: 2025, številka stroja/vozila: 306, Initial commissioning: 2024 Control: Heidenhain TNC 640 incl. HR 520 handwheel X-axis: approx. 4,000 mm Y-axis: approx. 2,700 mm Z-axis: approx. 1,300 mm A-axis: ± 120° C-axis: ± 360° Clamping table Clamping area: approx. 4,000 x 2,500 x 213 mm Aluminum with T-slots crosswise every 250 mm Max. load: 1000 kg evenly distributed over the entire surface 2-axis milling head HS673 Ksdpovy Dugsfx Aqqolt Spindle power: 22 kW Spindle speed: max. 24,000 rpm Torque: 18 Nm Tool holder: HSK 63A Tool clamping: pneumatic Blow air / MQL: external Linear axes drives Feed rate X and Y axes: up to 60 m/min Feed rate Z axis: up to 40 m/min Color Enclosure, gantry, control cabinet: light grey Z-slide and milling head: orange Additional equipment - Work area cover - 16-position tool changer - Control on separate, mobile console Optional at extra charge: - Blum laser tool measurement - Renishaw RMP60 radio probe - Heidenhain remote diagnostics Pictures show an identical machine with slightly different equipment!

Stanje: zelo dobro (rabljeno), Leto izdelave: 2014, Initial commissioning: 2014 Control system: Heidenhain iTNC 530 HSCI incl. HR 520 handwheel Machine hours Machine power-on hours: approx. 90,000 h Spindle hours: approx. 38,000 h Current milling spindle hours: approx. 900 h Travel distances X-axis: approx. 2,500 mm Y-axis: approx. 3,000 mm Z-axis: approx. 1,250 mm A-axis: ± 110° C-axis: ± 300° Clamping table Clamping surface: approx. 2,500 x 3,250 x 600 mm 2-axis milling head VH30 Spindle power: 60 kW Spindle speed: max. 22,000 rpm Torque: 95 Nm Tool holder: HSK 63A Tool clamping: hydraulic Coolant supply: external and internal Drives linear axes Feed rate X/Y/Z-axis: up to 60 m/min Axis acceleration X/Y/Z-axis: up to 5 m/s² Connection data Connected load: 190 kVA Main fuse: approx. 315 A Dimensions, weights Space requirement machine with peripherals: approx. 10,000 x 8,000 x 5,650 mm Kjdpjwywciefx Aqqslt Total weight: approx. 63,000 kg Colour Enclosure, gantry, control cabinet: RAL 7035 light grey Milling head and applications: RAL 6038 luminous green Description: Additional equipment - Coolant supply with belt filtration system - 50-position chain tool changer - Workspace enclosure - Chip conveyor - LTA emulsion mist extraction system Optional at extra charge: - Renishaw RMP60 wireless measuring probe - BLUM Control NT Condition of the machine Fully functional, in excellent condition, and still under power for inspection! The photos are for illustration purposes and show a new machine of this type. Original photos will follow shortly!

Stanje: zelo dobro (rabljeno), Leto izdelave: 2012, Initial commissioning: 2012 Control: Heidenhain iTNC 530 incl. HR 420 handwheel X-axis: approx. 5,000 mm Y-axis: approx. 3,000 mm Z-axis: approx. 1,500 mm A-axis: ±110° C-axis: ±300° Clamping Table Clamping surface: approx. 5,700 x 3,000 x 300 mm 2-axis Milling Head VH20 Spindle power: 40 kW Spindle speed: max. 25,000 rpm Torque: 48 Nm Tool holder: HSK 63A Tool clamping: hydraulic Coolant supply: external and internal Blow air: external Linear Axis Drives Feed rate X, Y-axis: up to 50 m/min Feed rate Z-axis: up to 30 m/min Axis acceleration X, Y, Z: up to 2.5 m/s² Connection Data Connected load: 190 kVA Main fuse: approx. 315 A Dimensions, Weight Space requirement incl. peripherals: approx. 10,000 x 7,700 x 5,850 mm Total weight: approx. 63,000 kg Color Enclosure, gantry, control cabinet: RAL 7035 light grey Milling head and applications: RAL 6038 luminous green Kodsvy A Tnjpfx Aqqslt Additional Equipment - Coolant supply with belt filter system - 30-position chain tool changer - Work area enclosure - Chip conveyor, right side Optional for an additional charge: - BLUM laser Machine condition Fully functional, very good condition. Already dismantled and in storage.

Stanje: zelo dobro (rabljeno), Leto izdelave: 2008, obratovalne ure: 82.500 h, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 5.000 mm, pomik osi Y: 3.000 mm, pomik po osi Z: 1.750 mm, hitrost pomika os X: 65 m/min, hitrost podajanja osi Y: 65 m/min, hitrost podajanja os Z: 65 m/min, največja hitrost vretena: 20.000 obr/min, hitro pomikanje X-os: 65 m/min, hitri pomik os Y: 65 m/min, hitri pomik na osi Z: 65 m/min, vrtilni moment: 63 Nm, skupna masa: 90.000 kg, Oprema: vrtilna hitrost brezstopenjsko nastavljiva, Commissioning: 2008 Control: Heidenhain iTNC 530 incl. HR420 handwheel X-axis: approx. 5,000 mm Y-axis: approx. 3,000 mm Z-axis: approx. 1,750 mm A-axis: -120 / +95° C-axis: ±360° Maximum workpiece dimensions 3,800 mm (X direction) 1,800 mm (Y direction) 1,150 mm (Z direction) 5-axis machining with a 300 mm long tool in a single setup (A-axis at 90° can be programmed). Machine on power: approx. 82,500 h Total spindle hours: approx. 36,500 h Clamping table No machine table included with the machine. Upon request, we are happy to offer a customized solution at extra cost. 2-axis fork-type milling head 5 Spindle power: 20 kW Spindle speed: max. 20,000 rpm Torque: max. 63 Nm Tool holder: HSK 63A Tool clamping: hydraulic Holding torque (clamped), A & C axes: 2,000 Nm Linear axes drives Feed rate X-, Y- and Z-axis: up to 65 m/min Axis acceleration X-, Y- and Z-axis: up to 5 m/s² Klsdpfxoxl R Hvs Aqqst Electrical data Voltage: 400 V Frequency: 50 Hz Power requirement: 130 kW Dimensions, weights Space requirement for machine without peripherals: approx. 7,500 x 8,500 x 6,600 mm Total weight: approx. 90,000 kg Colour Enclosure, gantry, control cabinet: RAL 7035 light grey Milling head and applications: RAL 5002 aquamarine blue Additional equipment - Minimum quantity lubrication - 50-position tool changer - Work area enclosure Optional at extra cost: - Renishaw RMP60 touch probe - BLUM LaserControl NT mini Machine condition Fully functional, in very good condition. Can be inspected under power until April 2026.

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2004, obratovalne ure: 42.832 h, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 3.000 mm, pomik osi Y: 2.100 mm, pomik po osi Z: 760 mm, model krmilnika: FANUC SERIES 18i MB, razmak između stupova: 2.300 mm, DÉTAILS TECHNIQUES Course X: 3 000 mm Course Y: 2 100 mm Course Z: 760 mm Distance entre colonnes : 2 300 mm Dimension de la table : 3 020 mm × 2 010 mm Charge maximale sur table : 10 000 kg Cône de broche : ISO-50 Vitesse de broche standard : 6 000 tr/min Diamètre max. outil / logement vide : 127 mm / 215 mm Longueur max. outil : 350 mm Poids max. outil : 20 kg Capacité changeur d’outils : 32 outils Avance rapide X : 20 000 mm/min Avance rapide Y : 15 000 mm/min Avance rapide Z : 15 000 mm/min Avance de coupe : env. 1 – 10 000 mm/min Kedpfx Aqeymxi Aoqolt DÉTAILS DE LA MACHINE Commande CNC : FANUC SERIES 18i MB Puissance moteur broche (continu / 30 min) : env. 22 / 26 kW Heures de fonctionnement avance : 42 832 h Heures de fonctionnement automatique : 53 246 h ÉQUIPEMENT Changeur automatique de tête (avec tête de fraisage angulaire) Palpeur RENISHAW

Stanje: zelo dobro (rabljeno), Leto izdelave: 2019, Os X 5.000 mm Os Y 3.000 mm Os Z 1.500 mm Velikost mize 5.000 x 2.500 mm Kljdpfxjx E S E Nj Aqqot Vpenjalo orodja HSK 63 Menjalec orodja 60 pozicij Krmiljenje HEIDENHAIN TNC 640 Vključno z notranjim hlajenjem (IKZ) 40 bar Vključno s simultano vilicasto glavo Vključno s popolno dokumentacijo

Stanje: rabljeno, Leto izdelave: 1999, Technical Details: X-axis travel: 3,500 mm Kodpfju Nc Emox Aqqelt Y-axis travel: 2,200 mm Z-axis travel: 1,200 mm C-axis: +/- 200° Control: Heidenhain TNC 426 Spindle speed (left rotation): max. 10,000 rpm Spindle speed (right rotation): max. 10,000 rpm Distance between columns: 2,500 mm Distance spindle / table (vertical): 1,230 mm Clamping area (table): 3,000 x 2,000 mm Table load capacity: 10 t Tool holder: HSK A 63 Feed rate (X/Y/Z): max. 20 m/min Compressed air: 8 bar Total power requirement: approx. 100 kW Machine weight approx.: 40,000 kg Machine dimensions: 18.0 x 6.0 x 5.8 m 5-Axis Gantry Milling Machine Milling spindle: Manufacturer Hauser, type HS 256A-01 Uni, max. speed 10,000 rpm, direct drive Milling head: Manufacturer Hamül, fork-type design, A-axis integrated, rotation angle +/- 110° Tool changer: Manufacturer Hamül, rotary indexing table with turntable design, for 32 tool positions Chip conveyors: 2 piece(s) hinge-belt conveyor, manufacturer DGS with water tank, insert length 8,500 mm Combined oil-water chiller unit by BKW, type DL 55V-2KK, output 2.41 l/min, for hydraulic oil and spindle cooling Coolant system: Belt filter, manufacturer DGS, type SBF 150 Operation: via operator console type Heidenhain LE 426 X-, Y-, and Z-axis with Heidenhain linear encoders Handheld operating device HR 410 Hydraulic weight compensation (Z-axis) Equipment: Enclosure (protective walls with windows and safety doors) Hydraulic system Work area lighting

Stanje: dober (rabljeno), Leto izdelave: 1999, potovalna razdalja osi X: 3.000 mm, pomik osi Y: 2.500 mm, pomik po osi Z: 1.150 mm,

Stanje: rabljeno, Leto izdelave: 2010, potovalna razdalja osi X: 3.020 mm, pomik osi Y: 1.520 mm, • Monobloková konstrukcija iz mehansko varjenega jekla in premično portalo iz jekla. Kodpfxjxxii As Aqqolt • Delovna hitrost do 18 m/min. • Delovna miza: fiksna, iz debelostenskih aluminijastih profilov. • Brušena vodila in prednapeti povratni krogelni ležaji. • Pogon preko preciznih krogelnih vreten na vseh treh oseh. • CNC krmiljenje CN7000 z zaslonom na dotik in Brushless servo motorji. • Na voljo v 5 velikostih za največjo prilagodljivost. • Opcija Z 350 za 3D aplikacije. • Kakovost in zmogljivost za dobro produktivnost. • Znana enostavnost uporabe. • Skladno z evropskimi varnostnimi direktivami. • Veliko možnosti dodatne opreme: brezkrtačni servo motorji, mikromazanje, avtomatska menjava orodja, vakuumska miza (s turbino ali vakuumsko črpalko), visoko-frekvenčna vretena, gravirne glave na dotik, četrta os.

Stanje: rabljeno, Leto izdelave: 1991, x-Pot 6200 mm y-Pot 1500 mm z-Pot 508 mm Krmiljenje Mazatrol Tip M 32 Višina obdelovanca 708 mm Izmenjevalec orodja 60 Vpenjalni stožec vretena ISO 50 Delovna površina mize 6200x750 mm Tehnični podatki so navedbe proizvajalca oz. lastnika. Zanje ne prevzemamo odgovornosti. Vmesna prodaja pridržana; veljajo izključno naši poslovni in prodajni pogoji. O nas več kot 400 lastnih strojev na zalogi več kot 15.000 m² skladiščnih površin, žerjavna zmogljivost 70 t več kot 10.000 artiklov dodatne opreme za vašo delavnico Kjdpfxeyqvdre Aqqslt Če želite prodati stroje, proizvodne linije ali vaše podjetje, se obrnite na nas. Druge ponudbe najdete na naši spletni strani. Ogled je možen po dogovoru. Veselimo se vašega obiska. Vaša Markus Hirsch ekipa

Stanje: nepreverjeno (rabljeno), Leto izdelave: 2000, Funkcionalnost: nepreverjeno, številka stroja/vozila: 2259, potovalna razdalja osi X: 6.000 mm, pomik osi Y: 3.500 mm, pomik po osi Z: 1.900 mm, največja hitrost vrtenja: 24.000 obr/min, model krmilnika: Siemens 840D, Brez minimalne cene – zagotovljena prodaja najvišji ponudbi! TEHNIČNI PODATKI Pomik X-os: 6.000 mm Pomik Y-os: 3.500 mm Pomik Z-os: 1.900 mm b-os: +/- 110° c-os: 360° Hitrost vrtenja: 24.000 min⁻¹ Vreteno: HSK 63 Motor vretena: 25 kW Velikost mize: 6.000 mm x 2.500 mm (razpored lukenj 22H7 / M16) Kljdpfxsyv A Dks Aqqst Pomik X + Y: 30.000 mm/min Pomik Z: 28.000 mm/min Hitri pomik: 30.000 mm/min PODROBNOSTI STROJA Krmiljenje: Siemens 840D Izmenjevalec orodij: 40 orodij OPREMA Vreteno: Fischer (tip MFWS 1709/30, 2 kosa) Rezkalna glava: Forest Line (tip: vilicasta glava, b-os nagib +/- 110°, c-os vrtljiv 360°) Richter transporter za odrezke (strgalo transporter) Blum merjenje orodja Postaja za odlaganje rezkalne glave (2 kosa)

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2004, Funkcionalnost: popolnoma funkcionalen, PORTAL MILLING MACHINE WITH ROTARY-TILTING TABLE EQUIPPED WITH SELCA 4060 PD CNC CONTROL X-AXIS TRAVEL: 1,600 mm Y-AXIS TRAVEL: 2,000 + 500 mm for tool change Z-AXIS TRAVEL: 900 mm ROTARY-TILTING TABLE SIZE (C-AXIS): 1,200 x 1,200 mm Klsdpfst I Tuzex Aqqet MAXIMUM LOAD CAPACITY: 2,000 kg T-SLOTS: No. 9 slots, 18 mm width Distance between columns: 1,550 mm Electrospindle power S1: 28 kW at 3,000 rpm 24-position automatic tool changer Numerical control: SELCA type 4060 PD Electrical cabinet cooling unit (AIRC) Tool cooling system: “spray mist” type (SPR) Laser system for tool integrity and measurement control

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2008, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 3.000 mm, pomik osi Y: 6.000 mm, pomik po osi Z: 1.250 mm, največja hitrost vretena: 12.000 obr/min, model krmilnika: Heidenhain iTNC530 mit Handrad, Stroj s 4. osjo kot zasučno osjo & redno vzdrževanje s strani proizvajalca! TEHNIČNI PODATKI Delovna območja Os X: 3.000 mm Os Y: 6.000 mm Os Z: 1.250 mm Glava za rezkanje, os A: krmiljeno zasučna Kjdpfx Aqjxvx U Asqolt Rezkalno vreteno Moč vretena: 4,4 kW Hitrost vretena: 12.000 min⁻¹ Vpenjanje orodja: 78/8 prirobnica Menjava orodja: ročna z navojno matico Pogoni linearnih osi Premična hitrost osi X, Y, Z: do 20 m/min Pospešek osi X, Y, Z: do 1,5 m/s² PODROBNOSTI O STROJU Krmiljenje: Heidenhain iTNC530 z ročnim kolesom Priključna moč: cca 25 kW Predvarovalka: 42 A Dimenzije & teža Potrebni prostor stroja: cca 5.500 x 9.000 x 4.500 mm Skupna teža: 9.600 kg OPREMA Možnost predelave na visoko frekvenčno vreteno Pomembno: Miza in na fotografijah prikazana lesena plošča nista vključeni v obseg dobave.

Stanje: zelo dobro (rabljeno), Leto izdelave: 2001, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 6.000 mm, pomik osi Y: 2.700 mm, pomik po osi Z: 1.250 mm, največja hitrost vretena: 24.000 obr/min, obremenitev mize: 15.000 kg, The submission of a bid obligates the buyer to collect the item within the specified period, no later than 27.11.2025! The machine can still be viewed under power until calendar week 47. The new spindle was installed in 2025! Additionally, the tool changer was retrofitted in 2025. The control unit was upgraded in 2014! TECHNICAL DETAILS Kledpjxr U Drefx Aqqst Working Areas X-axis: 6,000 mm Y-axis: 2,700 mm Z-axis: 1,250 mm Clamping Table Table dimensions (L x W x H): 6,600 x 2,740 x 520 mm Table load capacity: max. 15,000 kg T-slots and spacing: 10 x 22H8 / 255 mm Spindle Spindle power: 10 kW Spindle speed: 24,000 rpm Tool interface: HSK 63F Tool clamping: pneumatic Torque: 8.7 (S1) and 10.5 (S6) Nm Suitable materials: wood, plastic, aluminum Linear Axes Drives Rapid traverse speed X, Y, Z axes: max. 20 m/min Axis acceleration: max. 1.5 m/s² MACHINE DETAILS Control: Heidenhain iTNC530 with electronic handwheel Connection Data Power requirement: 28 kW Pre-fuse: 63 A Dimensions & Weight Machine footprint: 10,000 x 5,000 x 4,500 mm Total weight: 28,000 kg EQUIPMENT Double-sided enclosure with two doors 6-position tool changer

Stanje: rabljeno, Leto izdelave: 1994, X-travel 7000 mm y-travel 3500 mm z-travel 1000 mm Serial number 14908 Control Siemens Sinumerik 880 Clamping table 2 units Clamping table 3000x2500 mm Spindle power 42 kW Max. speed 4000 rpm Tool changer for 128 tools Tool holder SK50 Clamping surface 6800x2500 mm Column clearance 3200 mm Table load 20 t Universal angular milling head Straight head Extended straight head Coupled clamping surface 6800x2500 mm Max. table load per table 10 t Coupled 20 t The technical data are provided by the manufacturer or operator and are therefore non-binding for us. Interim sale reserved; only our terms and conditions of business and sale apply. About us: Over 400 machines in stock More than 15,000 m² of storage space, crane capacity 70 t Over 10,000 accessories for your workshop If you wish to sell machines, production lines or your company, please contact us. Find more offers on our website. Inspections are possible by appointment. We look forward to your visit. Kedpfsyqvqlox Aqqjlt Your Markus Hirsch Team

Stanje: dober (rabljeno), Leto izdelave: 2010, Funkcionalnost: popolnoma funkcionalen, Unisign Uniport 6000 Year of manufacture: 2010 / Commissioned: 2011 Control system: Siemens 840 D Travel distances: X = 10,000 mm, Y = 1,500 mm Extended spindle slide stroke: Z = 1,000 mm Increased clearance height: 1,000 mm Clearance width: 1,500 mm Main drive: 36 kW, n = 6,000 rpm, 720 Nm 2-stage gearbox 1:4 Taper: SK 50 Machining capacity in C45: Core drilling D=120mm, Thread tapping M55, Milling 100cm³/min Gantry construction with movable portal bridge and stationary clamping table. Clamping table equipped with crosswise clamping beams at 750 mm intervals. Standard platen fields omitted. Hydraulic clamping system with clamping bridges for axle machining incl. hydraulic unit Angular drilling & milling head, n = 4,000 rpm, SK50 High accuracy and stability due to Hirth coupling Automatic tool change into the angular head Measuring probe RWP20.50-M Pendulum operation Safety fence with light curtains, Sick brand Clamping table with crosswise clamping beams every 750 mm Tool chain magazine on portal column with 30 pockets Machine cooling system Water/air heat exchanger integrated in control cabinet Unisign remote diagnostics for Siemens Sinumerik 840 D Makrolon curtains on both sides of the portal bridge, motorized height adjustment Partition wall with inspection window Kodpfoymb Eaex Aqqslt Chip conveyor with hinged belt design Mounting and alignment elements
