Ekscentrične stiskalnice, enostebrične, 25–54 t nakup rabljenega (83)

Stanje: rabljeno, Leto izdelave: 1969, Pressing force: 50 t Throat depth: 260 mm Stroke: 8 - 120 mm Strokes per minute: 100 Distance between table and ram, large stroke at top, upper adjustment: 410 mm Table surface: 650 x 500 mm Dodpfx Aaovzxr Nj Hjcr Table opening: 250 x 180 mm Table height above floor: 740 - 980 mm Table adjustable: 240 mm Ram surface: 400 x 180 mm Ram adjustment: 70 mm Drive power: 2.2 kW Weight: 2.3 t Space requirements (W x D x H): 1.2 x 1.4 x 2.3 m Permitted only with safety tooling or fixed guarding according to German accident prevention regulations (UVV) Equipped with motor, wrap-spring clutch, mechanical overload protection in the ram, manual stroke adjustment, manual ram adjustment, adjustable table Sold as is, ex location, NOT commissioned Commissioning available on request (in current condition)

Stanje: zelo dobro (rabljeno), Pressure: 50 t Throat depth: 245 mm Stroke: 14 / 90 mm Ram adjustment: 75 mm Table height adjustment: 150 mm Strokes per minute: 42/85 Table surface: 700 x 490 mm Ram surface: 400 x 230 mm Ram bore diameter: 40 mm Total power requirement: 4 kW Machine weight: approx. 3.41 t Space requirements: approx. 0.8 x 1.75 x 2.1 m The machine has been partially overhauled in-house as follows: - Disassembly, cleaning, and inspection - Table re-milled - New paint in light grey / gentian blue, ram assembly in orange - Shaft crack test performed - Ortlinghaus KBK and auxiliary brake disassembled, cleaned, inspected, seals replaced - Additional air reservoir Dcodpfstrhf Aex Aa Her - New control cabinet with safety controls and touchscreen display - New machine wiring - New Vogel central lubrication system with piping (previously manual lubrication points) - New Herion press safety valve + maintenance unit - New Balluff cam controller - New two-hand control panel - New foot switch - Current accident prevention inspection (UVV) with brake time measurement - Machine is safe for hand-fed operation

Stanje: rabljeno, Ruska izdelava, Djdpfx Aaexbf Sfe Hocr Maks. tlačna sila: 25 t Velikost mize: 550 x 400 mm

Stanje: zelo dobro (rabljeno), Leto izdelave: 1987, Funkcionalnost: popolnoma funkcionalen, višina mize: 360 mm, širina mize: 810 mm, stiskalna sila: 45 t, Manufacturer: AIDA Model: NC1-45 Press force: 45 t Year of manufacture: 08/1987 Dcodpfx Aaou Dkc Aj Her Stroke length: 80 mm Shut height (adjustable): 240–300 mm Table dimensions: 810 x 360 mm Ram dimensions: 410 x 340 mm Electrical supply: 3x200 V (Japanese standard), 5.5 kW Net weight: 3,300 kg Dimensions (L x W x H): 980 x 1,480 x 2,275 mm

Stanje: dober (rabljeno), Leto izdelave: 1976, Funkcionalnost: popolnoma funkcionalen, Technical data: Dcodpfx Ajxxbmyea Hor Capacity 40 tons 2 ram speeds 57 + 86 strokes/min Throat depth 250 mm . Further specifications as per offer. . Delivery includes a newly conducted press inspection with a new inspection certificate. .

Stanje: dober (rabljeno), Leto izdelave: 1999, 1 rabljena ekscentrična stiskalnica znamke Ambold, tip PEEV 40/2 Pritisk: 40 t Izvleček: 225 mm Hod: 8 – 84 mm Površina mize: 580 x 450 mm Nastavitev bata: 55 mm Število hodov: 130 hodov/min Površina bata: 185 x 180 mm Luknja v batu: 40 mm Prehodna odprtina v mizi: 210 x 170 mm Vpenjalna plošča: 570 x 450 mm Skupna potrebna moč: 3,5 kW Dcsdpfx Aaexvqlto Her Teža stroja: pribl. 2,7 t Dimenzije: pribl. 1,4 x 1,1 x 2,1 m

Stanje: rabljeno, Leto izdelave: 1977, Druck 050 t Ausladung 255 mm Hub 8 - 120 mm Hubzahl 115 /min Entfernung Tisch/Stößel, gr. Hub oben, Verst. oben 380 mm Tischfläche 640 x 500 mm Djdpfsvzxr Ajx Aa Hecr Durchfallöffnung im Tisch 250 x 180 mm Tischhöhe über Flur 710 - 930 mm Tisch verstellbar 220 mm Stößelfläche 550 x 170 mm Stößelverstellung 70 mm Antriebsleistung 4,0 kW Gewicht 3,1 t Raumbedarf (BxTxH) 1,5 x 1,5 x 2,3 m Baujahr 1951 - umgebaut 1977 Nur zugelassen für sicheres Werkzeug oder feste Abschirmung gemäß den deutschen Unfallverhütungsvorschriften (UVV) mit Fußbedienung mit Motor, mechanischer Überlastsicherung im Stößel, manueller Hubverstellung, manueller Stößelverstellung, verstellbarem Tisch, Hand-Zentralschmierung, Fußbedienung wie steht und liegt, OHNE in Betrieb nehmen Preis für in Betrieb nehmen (in gegebenem Zustand) auf Anfrage

Stanje: rabljeno, Leto izdelave: 1987, Pressure 25 t Outreach mm Stroke mm Table surface 500 x 340 mm Through opening in table 250 x 210 mm Ram surface 345 x 230 mm Frame gap 250 mm Total power requirement kW Machine weight approx. t Space requirement approx. m - Air clutch - Ross press safety valve - Balluff cam switch gear - Maintenance unit Dodpfju Dn Sbex Aa Hocr - Automatic electric lubrication with flow grease - Accumulator tank for clutch - Ram with rupture plate - Prepared for ejector - Pilz PLC control - Approved for manual loading and unloading operations

Stanje: zelo dobro (rabljeno), Leto izdelave: 1991, Funkcionalnost: popolnoma funkcionalen, skupna masa: 19.000 kg, stiskalna sila: 160 t, vrsta nastavitve višine: električni, moč: 11 kW (14,96 KM), vhodna napetost: 200 V, Oprema: dokumentacija / priročnik, varnostna svetlobna zapora, Manufacturer: AIDA Model: NC2-160 Pressing force: 160 t Year of manufacture: approx. 1991 Stroke length: 130 mm Dodpfou D Dhxox Aa Hjcr Shut height (adjustable): 285–335 mm Table dimensions: 1900 x 600 mm Ram dimensions: 1360 x 585 mm Electrical rating: 3x200V (!!), 15 kW – Japanese standard Net weight: 19,000 kg Dimensions: 2140 x 2210 x 3175 mm Automatic lubrication system. Optionally available with decoiler and straightening machine.

Stanje: rabljeno, Leto izdelave: 1968, Pressure: 50 t Throat depth: 250 mm Stroke: 8 - 120 mm Strokes per minute: 115 Distance table/ram, max. stroke up, adjustment up: 420 mm Table surface: 645 x 510 mm Pass-through opening in table: 250 x 180 mm Table height above floor: 700 - 930 mm Table adjustable: 230 mm Ram area: 220 x 185 mm Ram adjustment: 70 mm Dcsdovzxriopfx Aa Hsr Drive power: 3.0 kW Weight: 3.0 t Space requirements (W x D x H): 1.1 x 1.8 x 2.4 m Only approved for use with safe tools or fixed guards in accordance with German accident prevention regulations (UVV) With motor, mechanical overload protection in the ram, manual stroke adjustment, manual ram adjustment, adjustable table, foot operation As is, as seen, WITHOUT commissioning Price for commissioning (in given condition) on request

Stanje: novo, Pressure: 40 t Throat depth: 225 mm Stroke: 8–84 mm Dcsdeb U Hwmepfx Aa Hor Table size: 580 x 450 mm Ram adjustment: 55 mm Strokes per minute: 130 spm Ram surface: 185 x 180 mm Ram bore: 40 H7 mm Passage opening in table: 210 x 170 mm T-slots: 22 mm Clamping plate: 570 x 450 x 65 mm Total power requirement: 3.5 kW Machine weight approx.: 2.7 t Space requirement approx.: 1.4 x 1.1 x 2.1 m - Pneumatic clutch-brake combination Ortlinghaus - Central lubrication system Vogel - Cam controller Balluff - Height-adjustable table - Control cabinet with touchscreen - Foot switch

Stanje: dober (rabljeno), Funkcionalnost: popolnoma funkcionalen, DIGÉP SD25 tilting round press, eccentric press machine 25t Manufacturer: DIGÉP Model: SD-25 Table: 380 x 515 mm Stroke length: 10–90 mm Dcedpfxotrww Ee Aa Hor Weight approx. 1.9 t

Stanje: rabljeno, Leto izdelave: 1962, Tlak 025 t Iztegnitev 200 mm Hod 8 - 80 mm Število hodov 180 /min Razdalja med mizo in batom, velik hod zgoraj, nastavitev zgoraj 330 mm Površina mize 550 x 400 mm Preboj na mizi 60 mm Višina mize nad tlemi 800 mm Prehod med stenami korpusa 200 mm Površina bata 355 x 220 mm Nastavitev bata 50 mm Pogon 2,7 kW Teža 2,5 t Prostorska zahteva (ŠxDxV) 1,2 x 1,8 x 2,4 m Uporaba dovoljena le s varnim orodjem ali fiksno zaščito v skladu z nemškimi smernicami za varstvo pri delu (UVV) s motorjem, pnevmatsko sklopko, mehanskim omejevalnikom preobremenitve v batu, ročno nastavitvijo hoda, ročno nastavitvijo bata, nagibljiv, ročno centralno mazanje, dvoročno in nožno upravljanje Djdpfx Aaevuudno Hjcr kot stoji in leži, BREZ zagona Cena za zagon (v danem stanju) na zahtevo

Stanje: novo, Pressure: 25 t Throat depth: 200 mm Stroke: 4 - 80 mm Table surface: 520 x 400 mm Stroke rate: 160 strokes/min Ram surface: 160 x 160 mm Ram adjustment: 40 mm Ram bore: 32 H7 mm Throughhole in table: 200 x 150 mm Clamping plate: 500 x 380 x 60 mm Total power requirement: 2.7 kW Machine weight approx.: 1.9 t Space requirement approx.: 1.3 x 1.0 x 1.85 m - Ortlinghaus pneumatic clutch/brake combination - Vogel central lubrication - Balluff cam controller - Height-adjustable table - Control cabinet with touchscreen Djdpfx Aaeb U Hwpo Hscr - Foot switch

Stanje: zelo dobro (rabljeno), Leto izdelave: 1990, moč: 5,5 kW (7,48 KM), Pressing force: 40 tons Table size: 630x380 mm Stroke length: 270 mm Pedal operation. Dcodpfx Aslkfzzsa Hsr Flywheel diameter: 800 mm

Stanje: rabljeno, Leto izdelave: 1978, Pressure 050 t Outreach 250 mm Stroke 8 - 120 mm Strokes per minute 100 Distance table/ram, max. stroke up, adjustment up 400 mm Table size 650 x 515 mm Pass-through opening in table 115 mm Table height above floor 790 - 1020 mm Table adjustable 230 mm Dsdpfx Aajvut E Ds Hscr Ram surface 390 x 180 mm Ram adjustment 70 mm Drive power 2.0 kW Weight 2.6 t Space requirements (W x D x H) 1.1 x 1.4 x 2.2 m Approved only for use with safety tooling or fixed guards in accordance with German accident prevention regulations (UVV) Comes with motor, flywheel clutch, mechanical overload protection in the ram, manual stroke adjustment, manual ram adjustment, adjustable table, foot operation Can be inspected under power at our warehouse

Leto izdelave: 1977, Stanje: rabljeno, Pressure: 40 t Outreach: - mm Dsdpfxob U Hxfj Aa Hscr Stroke: 8 - 90 mm Table dimensions: 630 x 430 mm Ram adjustment: 60 mm Maximum stroke rate: 65 strokes/min Total power requirement: kW Machine weight approx.: 2,480 kg Space requirement approx.: m - Gear drive - Tiltable - Table clamping plate - Mechanical overload protection in the ram (shear plate) - Pneumatic clutch

Stanje: rabljeno, Leto izdelave: 1983, Pressing force: 63 t Outreach: 315 mm Stroke: 10 - 105 mm Stroke rate: 71 - 140 strokes/min Ram adjustment: 70 mm Table dimensions: 800 x 620 mm Ram dimensions: 450 x 280 mm Total power requirement: kW Dcodpfx Aasumm S Dj Hor Machine weight approx. 5,850 kg Space requirement approx. 1.425 x 1.79 x 2.55 m - Table clamping plate

Stanje: novo, Pressure: 25 t Throat depth: 200 mm Stroke: 4 - 80 mm Table size: 520 x 400 mm Strokes per minute: 160 spm Continuous operating capacity: 1370 Nm Single stroke capacity: 2740 Nm Stroke adjustment: 4 - 80 mm Ram adjustment: 40 mm Ram surface: 160 x 160 mm Table through-hole: 200 x 150 mm Clamping plate: 500 x 380 x 60 mm Table through-hole: 80 mm Machine weight approx. 1.9 t - Ortlinghaus hydraulic clutch-brake combination - Vogel central lubrication system - Balluff cam controller Dcodsb U Hwnspfx Aa Hjr - Height-adjustable table - Control cabinet with touchscreen - Foot switch

Stanje: rabljeno, Leto izdelave: 1986, Pressure: 40 t Throat depth: 265 mm Stroke: 8 - 95 mm Table dimensions: 660 x 520 mm Ram dimensions: 400 x 250 mm Ram adjustment: 80 mm Strokes per minute: 70 - 142 spm Total power requirement: kW (not specified) Machine weight approx.: 4,500 kg Dcjdpfx Aaeumm Sqo Hjr Space requirement approx.: 1.245 x 1.585 x 2.37 m - Table clamping plate

Stanje: novo, Pressure: 40 t Throat depth: 225 mm Stroke: 8–84 mm Dsdpfx Aaob U Hwts Hocr Table size: 580 x 450 mm Ram adjustment: 55 mm Strokes per minute: 130 spm Ram surface: 185 x 180 mm Ram bore: 40 H7 mm Through-hole in table: 210 x 170 mm T-slots: 22 Clamping plate: 570 x 450 x 65 mm Total connected load: 3.5 kW Machine weight approx.: 2.7 t Space requirement approx.: 1.4 x 1.1 x 2.1 m - Hydraulic clutch-brake combination - Central lubrication (Vogel) - Cam control (Balluff) - Control cabinet with touchscreen - Height-adjustable table - Foot switch

Stanje: rabljeno, Tlak 25 t Doseg 200 mm Hod 4 - 80 mm Število hodov 150 hod/min Nastavitev bata 85 mm Razdalja miza/bat 300 mm Vpenjalna površina mize 600 x 410 mm Prebojna odprtina v mizi 210 mm Luknja za čep (globina x premer) 80 x 40 mm Skupna potrebna moč 1,5 kW Teža stroja pribl. 1,7 t - fiksna miza - z vpenjalno ploščo - nihajni elementi (4 kosi) - nožno stikalo - hidravlična sklopka - CE oznaka Stroj bo v naši hiši delno obnovljen, kot sledi: - demontiran, očiščen in tehnično popolnoma pregledan Dodjxu Nqlopfx Aa Hecr - novo barvanje - nova elektro omara z zaslonom na dotik - aktualen preskus stiskalnice

Stanje: rabljeno, Leto izdelave: 1983, Press force 25 t Throat depth 225 mm Stroke 8 - 85 mm Table dimensions 560 x 450 mm Dcodpjumm Swjfx Aa Hjr Ram dimensions 360 x 220 mm Ram adjustment 55 mm Strokes per minute 80 - 160 spm Total power requirement kW Machine weight approx. 2,500 kg Space requirement approx. 1,135 x 1,365 x 2,145 m - Clamping plate for the table

Stanje: rabljeno, Pressure: 40 t Throat depth: 225 mm Stroke: 8 - 84 mm Table area: 580 x 450 mm Ram adjustment: 55 mm Stroke rate: 130 strokes/min Ram area: 185 x 180 mm Ram bore: 40 mm Dedpfx Aewxfmtoa Hocr Passage opening in table: 210 x 170 mm Clamping plate: 570 x 450 mm Total power requirement: 3.5 kW Machine weight: approx. 2.7 t Space requirement: approx. 1.4 x 1.1 x 2.1 m - Pneumatic clutch (Ambold) - Separate clamping plate - Press safety valve - Two-hand control panel - Balluff cam switchgear - Foot switch - Control cabinet with ABB safety control and touchscreen display

Stanje: rabljeno, Leto izdelave: 2007, Pressure: 125 t Stroke: 12 - 140 mm Shut height with max. stroke up and ram adjustment up: 495 mm Ram adjustment: 100 mm Ram surface: 800 x 400 mm Table surface: 1000 x 720 mm Clamping plate: 990 x 670 mm Clamping plate thickness: 80 mm Total power requirement: 70 A Machine weight approx.: 11 t Space requirement approx. (W x D x H): 2770 x 2520 x 2950 mm - Equipped with hydraulically actuated multi-plate wet clutch and spring-loaded safety brake - Hydraulic overload protection - Hydraulic connecting rod clamping - Motorized ram height adjustment - Semi-automatic stroke adjustment - Ram weight compensation - Manual TDC adjustment - Belt drive - Press force measuring device - Pendant control panel - Reversible control (return motion) - Electric stroke counter - Electric preset counter Dcedpfx Aaoxx A Dto Her - Electronic cam switchgear - Clamping plate - Two-hand control console, swivellable and height-adjustable - Operating hours counter - 1 set of vibration-damping elements - With feed unit The press will be technically overhauled at our facility and will receive a current safety inspection.
