Weeke Venture 3 nakup rabljenega (73)

Leto izdelave: 2011, Stanje: pripravljen za uporabo (rabljen), Glavni pogon Število osi: 3 Ijdpfx Aox D Nvgjf Tstb Ta 3-osni stroj HOMAG WEEKE OPTIMAT BHX 500 je bil izdelan leta 2011. Ponaša se z robustnim CNC obdelovalnim centrom z delovnim območjem 2500 mm x 1300 mm, glavno elektro vreteno ima moč 6 kW, največja debelina obdelovanca pa je 80 mm. Vključuje 84 vrtalnih vreten in dvojni rezkalni vreteni, vsaka z močjo 6 kW pri 18.000 vrtljajih/min. Če želite kakovostne CNC zmogljivosti, razmislite o stroju HOMAG WEEKE OPTIMAT BHX 500, ki je na voljo za prodajo. Za več informacij nas kontaktirajte. Vrste uporabe CNC obdelava lesa

Stanje: rabljeno, številka stroja/vozila: 008176, Delovno območje os X: 3050 mm Delovno območje os Y: 1250 mm Itsdox A Hh Djpfx Af Tsb Moč glavnega vretena: 10 kW Število krmiljenih osi: 3 osi Število vrtalnih vreten: 25 Število orodnih mest: 4

Stanje: zelo dobro (rabljeno), Portal machine Movable table (workpiece), movable working head (horizontal workpiece) Control: Power Control, WoodWOP software Workpiece drive with no. 3 transport belts Minimum workpiece dimensions (X-Y-Z) mm: 250 x 100 x 12 Maximum workpiece dimensions (X-Y-Z) mm: 2500 x 1050 x 50 Chip conveyor belt Total connected load (kW): 60 WORKING UNITS (VERTICAL): Drilling units with vertical spindles: No. 6 Ijdpfxedg Itns Af Tjtb Independent vertical drilling spindles: No. 40 x 6 (total No. 240) Drill head power: No. 6 x 2.7 kW WORKING UNITS (HORIZONTAL): Drilling units with horizontal spindles: No. 4 (4 x 2.7 kW) Horizontal drilling spindles - right side: No. 13 x 2 (total No. 26) Horizontal drilling spindles - left side: No. 13 x 2 (total No. 26) High-pressure glue injection and dowel insertion nozzles (right side): No. 8 High-pressure glue injection and dowel insertion nozzles (left side): No. 8 Dowel magazine for automatic dowel feeding: No. 2

Stanje: generalkompletno obnovljen (rabljeno), PC control type Power Control Professional Software: woodWOP / TopDrill BST No. 2 throughfeed motorized conveyor belts (4 x kW [?]) No. 2 horizontal drilling supports (digital display of position data for axes) No. 1 drilling unit for each horizontal drilling support (1 x 1.5 kW) No. 21 spindles for each horizontal drilling unit Max. working width (mm): 2500 Min. working width (mm): 250 Isdpfodz Uk Tox Af Tetb No. 4 lower vertical drilling supports (digital display of position data for axes) No. 2 drilling units for each lower vertical drilling support (2 x 1.5 kW) Various spindles for each drilling unit of the lower drilling supports No. 2 upper vertical drilling supports (digital display of position data for axes) No. 2 drilling units for each upper vertical drilling support (2 x 1.5 kW) Various spindles for each drilling unit of the upper drilling supports No. 4 upper vertical workpiece clamps Chip conveyor belt Total connected load (kW): 36

Stanje: zelo dobro (rabljeno), CNC flexible automatic through-feed drilling machine (gantry type) with dowel insertion system. Movable panel (workpiece), movable working head (horizontal panel-workpiece). Control: Power Control, Software: WoodWOP. Integrated safety cabin for the machine. Workpiece feed with triple transport belt. Feed speed (m/min): 1 – 90 (approx.). Minimum workpiece dimensions (X-Y-Z) in mm: 250 x 100 x 12 Maximum workpiece dimensions (X-Y-Z) in mm: 3000 x 1400 x 60 Maximum axis travel (X-Y-Z) in mm: 3580 x 1838 x 125 Simultaneous machining of two workpieces possible (in Y-axis): 600 mm + 600 mm Total connected load (kW): 38 WORKING UNITS – TOP SIDE: Drilling unit with vertical spindles (Qty): 1 Itodpfx Aed Nvi Dof Tjb Independent vertical drilling spindles (Qty): 38 + 3 special Independent horizontal drilling spindles (Qty): 6 Grooving saw unit (for X-axis machining) blade diameter (mm): 100 Vertical main spindle (milling unit): 1 x SK 30 (vertical main spindle power kW 6) Automatic tool change system, carousel changer, positions: 3 WORKING UNITS – HORIZONTAL: Drilling unit with horizontal spindles (Qty): 2 Horizontal drilling spindles – right side (Qty): 13 + left side (Qty): 13 Glue injection nozzles and dowel insertion (right side): 2 + (left side): 2 Dowel magazine for automatic dowel insertion (Qty): 1

Stanje: zelo dobro (rabljeno), Portal machine Movable panel, movable working head (horizontal workpiece) Numerical control Power Control, WoodWOP software Safety cabin for the working head. Full machine safety enclosure Infeed table (workpiece support). Outfeed table (with conveyor belt) Workpiece feed using 3 conveyor belts (feed speed approx. max 130 m/min) Minimum workpiece dimensions (X-Y-Z) mm: 250 x 100 x 15 Maximum workpiece dimensions (X-Y-Z) mm: 2500 x 1050 x 60 Motorized conveyor belt for waste disposal Separate electrical and control cabinet. Total installed power (kW): 99 No. 2 WORKING UNITS (TOP) – (SERVO MOTOR X-Y-Z): No. 4 drilling units (4 x 2.3 kW) with 10 vertical spindles each (total vertical spindles: 40) No. 3 WORKING UNITS (BOTTOM) – (SERVO MOTOR X-Y-Z): Iodpfxegwbbqo Af Tjtb No. 6 drilling units (6 x 2.3 kW) with 40 vertical spindles each (total vertical spindles: 240) No. 2 WORKING UNITS (HORIZONTAL): No. 2 drilling units with horizontal spindles No. 21 horizontal drilling spindles (right side) + No. 21 horizontal drilling spindles (left side) No. 8 glue injection nozzles and dowel insertion units (right side) No. 8 glue injection nozzles and dowel insertion units (left side) No. 2 dowel magazines for automatic dowel insertion OPTIONS: BARCODE (WIRELESS SCANNER)

Stanje: zelo dobro (rabljeno), Leto izdelave: 2021, CNC Flexible Gantry Machine Horizontal Throughfeed Table Control System: Power Contro Open powerTouch, Software: WoodWOP (TAPIO Ready) Infeed Table (panel support) + Outfeed Table (panel support) Panel feed via 3 transport belts Min. workpiece dimensions (X-Y-Z): 250 x 100 x 12 mm Max. workpiece dimensions (X-Y-Z): 2500 x 1050 x 60 mm Special lateral guiding system for workpieces with "sensitive" edges Ijdsx Aqi Espfx Af Tetb 3 upper vertical pressure devices Powered conveyor belt for waste disposal Integrated electrical and control cabinet Total installed power: approx. 47 kW OPTIONAL: Wireless barcode scanner 2 WORKING UNITS (TOP) – (SERVO MOTOR for X-Y-Z axis): 4 V15 drilling heads (4 x 2.3 kW) each with 15 vertical spindles (total of 60 upper spindles) 3 WORKING UNITS (BOTTOM) – (SERVO MOTOR for X-Y-Z axis): 6 V32 drilling heads (6 x 2.3 kW) each with 32 vertical spindles (total of 192 lower spindles) 2 WORKING UNITS (HORIZONTAL): 2 H21 drilling heads (2 x 2.3 kW) with horizontal spindles 21 horizontal drilling spindles (right) + 21 horizontal drilling spindles (left)

Stanje: zelo dobro (rabljeno), AUTOMATIC MULTI-BORER "WEEKE" Machine can be integrated in line with other machines Control: Power Control Software: WoodWop (TOPDRILL BST 500) Transport belts (qty): 2 (feed speed adjustable) Horizontal drilling supports (qty): 2 Drilling units per horizontal support (qty): 2 Itedpfx Aoh Ryhnef Tjb Spindles per horizontal drilling unit (qty): 11 Max. working width (mm): 3000 Min. working width (mm): 250 Lower vertical drilling supports (qty): 6 Drilling units per lower vertical support (qty): 2 Spindles per drilling unit of lower supports (qty): various Upper vertical drilling supports (qty): 2 Drilling units per upper vertical support (qty): 2 Spindles per drilling unit of upper supports (qty): 2 Upper vertical workpiece clamps (qty): 6 Chip conveyor belt Digital display of positioning data (axis) Total connected load (kW): 26

Stanje: zelo dobro (rabljeno), 3-axis (X-Y-Z) CNC-controlled "FLEXIBLE" MACHINING CENTER Moving table (workpiece), stationary operating head – Horizontal table (workpiece) Control unit: PowerControl (woodWOP software) Operator head safety enclosure Itedolkdpmspfx Af Teb 2x safety interlock workpiece clamping chucks in the working area WEEKE pre-positioning unit – for faster positioning of workpieces in machines with clamp grippers. Support table (workpiece support) at infeed – outfeed table (with conveyor belt) Includes automatic panel pusher Minimum workpiece dimensions (X-Y-Z) mm: 200 x 70 x 8 (2 x 4 mm) Maximum workpiece dimensions (X-Y-Z) mm: 2500 x 1000 (option 1300) x 80 (2 x 40 mm) Two workpieces can be machined simultaneously (in the Z-axis) Separate electrical and control cabinet UPPER MACHINING UNITS: 2V32, 2H8X/Y2, N2 X-Y90, F2-ETP-6 kW 23 independent vertical drilling spindles (drill head output 2.3 kW) 5 independent horizontal drilling spindles (4 in X + 1 in Y) 1 grooving saw unit (swivels 90° in X-Y direction), blade diameter 125 mm 1 vertical main spindle (milling unit) ETP (vertical main spindle output 6 kW) LOWER MACHINING UNITS: 23 independent vertical drilling spindles (drill head output 2.3 kW) 5 independent horizontal drilling spindles (4 in X + 1 in Y) 1 grooving saw unit (swivels 90° in X-Y direction), blade diameter 125 mm 1 vertical main spindle (milling unit) ETP (vertical main spindle output 6 kW)

Stanje: generalkompletno obnovljen (rabljeno), PC control (Power Control) Software No. 2 motorised through-feed conveyor belts No. 2 horizontal drilling supports (digital display of the position data for axes) No. 2 drilling units for each horizontal drilling support (1 x 1.5 kW) No. 11 spindles for each horizontal drilling unit Maximum working width (mm): 3000 Minimum working width (mm): 250 Itjdpfevhcbzsx Af Teb No. 6 lower vertical drilling supports (digital display of the position data for axes) No. 2 drilling units for each lower vertical drilling support (2 x 1.5 kW) No. 11 spindles for each drilling unit on the lower drilling supports No. 2 upper vertical drilling supports (digital display of the position data for axes) No. 2 drilling units for each upper vertical drilling support (2 x 1.5 kW) No. 11 spindles for each drilling unit on the upper drilling supports No. 6 upper vertical workpiece clamps Chip conveyor belt Total connected load (kW): 50 / 60 (approx.)

Stanje: zelo dobro (rabljeno), COMPLETE FOUR-SIDE SIZING AND EDGE BANDING LINE, max. working width 2500 mm, equipped with automatic loading and stacking system, consisting of the following machines: X04004A) Loading gantry (with 2 loading stations) “BARGSTEDT” TBH 500/D/30/14 X04004B) Workpiece turning device (90° LONGITUDINAL-TRANSVERSE) “HOMAG” Model TDR31/25/12 X04004C) Splitting saw (Splitter) “HOMAG” Model FPR620/04/15/PS/LQ (for final cutting) X04004D) Separation station “BARGSTEDT” X04004E) Double-sided sizing and edge banding machine “HOMAG” Model KFR 620/19/QA/25 X04004F) 1st boring machine “WEEKE” Model BST 500 D X04004G) 2nd boring machine “WEEKE” Model BST 500 D X04004H) Workpiece turning device (90° TRANSVERSE-LONGITUDINAL) “HOMAG” Model TDR 51/25/12 X04004I) Motorized transfer conveyor “HOMAG” TR 10/70/12 X04004L) Splitting saw (Splitter) “HOMAG” Model FPR620/04/15/PS/LQ (for final cutting) Iodslikvhjpfx Af Tetb X04004M) Stacking gantry (with 2 unloading stations) “BARGSTEDT” Model TSP 420/40/30/12 BA

Stanje: zelo dobro (rabljeno), PC control Power Control Software TOPDRILL BST 500 No. 2 pass-through motorized conveyor belts No. 2 horizontal drilling supports (digital position display for axes) No. 1 drilling unit for each horizontal drilling support (1 x 1.5 kW) No. 21 spindles for each horizontal drilling unit Max. working width (mm): 2500 Min. working width (mm): 250 Ijdpfx Ajivawpsf Totb No. 4 lower vertical drilling supports (digital position display for axes) No. 2 drilling units for each lower vertical drilling support (2 x 1.5 kW) No. 11 spindles for each drilling unit of the lower supports No. 4 upper vertical workpiece clamps Chip removal conveyor belt Total connected load (kW): 20

Stanje: rabljeno, številka stroja/vozila: 008205, Delovno območje os X: 4250 mm Delovno območje os Y: 1320 mm Delovna površina: z vakuumskimi konzolnimi nosilci Itsdpfx Afox A Th Rj Teb Moč glavnega vretena: 11 kW Število krmiljenih osi: 4 osi Število vrtalnih vreten: 31 Število mest za orodja: 22

Stanje: rabljeno, številka stroja/vozila: 008170, Delovno območje os X: 4300 mm Delovno območje os Y: 2250 mm Itsdpfx Aox A Tcuof Tsb Delovna površina: nesting miza Moč glavnega vretena: 9 kW Število krmiljenih osi: 4 osi Število vrtalnih vreten: 12 Število mest za orodje: 14

Stanje: rabljeno, številka stroja/vozila: 007601, Working area X-axis: 4320 mm Iodpfx Aeu N Skfjf Tetb Working area Y-axis: 2245 mm Working surface: nesting table Main spindle power: 9 kW Number of controlled axes: 3 axes Number of drilling spindles: 16 Number of tool stations: 8

Stanje: rabljeno, številka stroja/vozila: 006351, Delovno območje os X: 4250 mm Delovno območje os Y: 1250 mm Delovna površina: z vakuumskimi nosilci Moč glavnega vretena: 15 kW Število krmiljenih osi: 4 osi Število vrtalnih vreten: 31 Itjdpfx Aewcyflef Teb Število mest za orodja: 36

Stanje: rabljeno, številka stroja/vozila: 006157, Max. panel width: 1000 mm Max. panel length: 2500 mm Itedopl Hvdspfx Af Teb Number of units: 5 Number of units: 1 Positioning via NC control: yes Lateral horizontal groups: yes

Stanje: rabljeno, številka stroja/vozila: 005289, Delovno območje os X: 7400 mm Delovno območje os Y: 1550 mm Delovna površina: Nesting miza Moč glavnega vretena: 11 kW Število kontroliranih osi: 4 osi Število vrtalnih vreten: 10 Itodpewcyacjfx Af Tsb Število mest za orodja: 14

Stanje: rabljeno, številka stroja/vozila: 006158, Max. panel width: 1000 mm Max. panel length: 2500 mm Number of injectors: 14 Itsdpfx Aoiwptusf Teb Positioning via NC control: yes

Stanje: dober (rabljeno), CNC machining centre WEEKE OPTIMAT BHX 500 Including material handling system "IgeL-ROBOT" Workpiece support below Workpiece support above Workpiece length: min. 250 mm - max. 2500 mm Workpiece width: min. 70 mm - max. 1000 mm Workpiece thickness: min. 4 mm – max. 80 mm Workpiece stacking: max. 2 pieces Vector speed: X-axis (collets) = 138 m/min; Y-axis = 80 m/min; Z-axis = 50 m/min Equipped with: VERTICAL DRILLING UNIT 2 V 21 HIGH SPEED 7500 Itjdpfxjtd Uufe Af Teb HORIZONTAL DRILLING UNIT 2H4X/2Y GROOVE SAW UNIT N2 X-Y 90 MILLING UNIT F2-ETP-6 KW Barcode reader manufacturer: Datalogic Material handling system "IGEL-ROBOT".

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2011, število osi: 3, Glavni pogon Število osi: 3 Itodpfx Afex D D Ttj Tsb Ta 3-osni CNC obdelovalni center Weeke Optimat BHP Vantage 24M je bil izdelan leta 2011. Robustni CNC obdelovalni center ponuja natančnost in učinkovitost za raznolike obdelovalne naloge. Razmislite o nakupu tega CNC obdelovalnega centra Weeke Optimat BHP Vantage 24M. Kontaktirajte nas za več informacij. Vrste uporabe CNC obdelava lesa

Leto izdelave: 2000, Stanje: pripravljen za uporabo (rabljen), Glavni pogon Iodex D D T Hspfx Af Tjtb Število osi: 4 Ta štiriosni Weeke Optimat BP 145 je bil izdelan leta 2000. Robusten CNC obdelovalni center nudi napredne možnosti za natančno in učinkovito obdelavo. Idealno za vse, ki iščejo zanesljiv rabljen stroj za povečanje svoje proizvodnje. Kontaktirajte nas za več informacij. Vrste uporabe CNC obdelava lesa

Stanje: dober (rabljeno), Leto izdelave: 2008, Funkcionalnost: popolnoma funkcionalen, We offer for sale: WEEKE (Homag Drilling Systems) – OPTIMAT BHC 200 – High-Precision CNC Machining Center Technical Specifications: • Year of manufacture: 2008 GUIDEWAY AND DRIVE TECHNOLOGY • Dust-protected linear guide rail system • Rack and pinion drive in the X-axis, with ball screw drives in the Y- and Z-axes • Axis travel: - Y = 1822 mm - Z1 = 300 mm - Z2 = 185 mm • Worktable: - X = 5250 mm (length) - Y = 1250 mm (width) - Z = 100 mm (thickness) Optimat BHC200 • Control system: HOMAG PowerControl/woodWOP • Features: o Automatic tool changer o Multi-spindle drilling head o Integrated vacuum table for secure workpiece clamping Iodpfx Aowx Iidsf Tstb o Capable of machining wood, plastics, and light metals • Condition: Good; very well maintained, serviced regularly / last service 03/25 • 10/2022 – Machine modernization: - New industrial PC / Siemens Industrial Computer - woodWOP 8 / Windows 10 upgrade Advantages of the HOMAG BHC200: • Precise and efficient machining of a wide range of materials • Ideal for joineries, furniture manufacturers, and custom production • Reliable performance, even for demanding projects Scope of delivery: • Machine + Industrial PC • Operating manual • CE SAFETY AND PROTECTION FEATURES - Protective fence on the side and rear - Three-part safety tread mat at the front enables placement of workpieces in the non-active work area Inspection and test run on site are welcome! Disassembly and transport to be organized by the buyer

Stanje: zelo dobro (rabljeno), Funkcionalnost: popolnoma funkcionalen, Glavna moč motorja: 12 kW Podpora navora = da 4. os - C-os 5. os - vmesnik agregata Sistem vpenjanja orodja - HSK-F63 Pozicije izmenjevalca orodij - 14 Število zamenljivih enot - 3 Vertikalna vrtalna vretena - 19 Horizontalno X - 4 Horizontalno Y - 2 Rezkar za utore - vrtljiv za 90° Vakuumska črpalka - da Varnostna naprava - varnostna preproga Upravljanje - Homag Power Control PC st Programska oprema - Homag Woodwop 5.0 Teža - 4.500 kg CE označevanje - da Potreben prostor Dolžina = 6580 mm Širina = 4580 mm Dve vrsti zabaud Iedpfx Ajya Ak Djf Tstb Pomožna naprava za menjavo orodja Pomožna podpora za obdelovanec

Stanje: zelo dobro (rabljeno), Leto izdelave: 2008, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 3.250 mm, pomik osi Y: 1.250 mm, pomik po osi Z: 125 mm, največja hitrost vrtenja: 24.000 obr/min, Glavna moč motorja: 12 kW Podpora navora = da 4. os – C os 5. os – vmesnik agregata Sistem vpenjanja orodja – HSK-F63 Pozicije menjalca orodij – 14 Število zamenljivih enot – 3 Vertikalna vrtalna vretena – 19 Horizontalna X – 4 Horizontalna Y – 2 Rezkar za utore – 90° vrtljiv Vakuumska črpalka – da Varnostna naprava – varnostna preproga Krmiljenje – Homag Power Control PC st Programska oprema – Homag Woodwop 5.0 Teža – 4.500 kg CE certifikat – da Itjdpoya Aimofx Af Tjb Potreben prostor Dolžina = 6580 Širina = 4580 Dve vrsti ustavljal Pomožna naprava za menjavo orodij Pomožna podpora za obdelovance
