Pye nakup rabljenega (35)

Stanje: dober (rabljeno), Leto izdelave: 1994, Tlačna sila: 250 t Kodpfx Adjyvywuokedi Iztek: 360 mm Velikost mize: 1250 x 630 mm Premer mize: 250 mm Vpenjalna površina bata: 850 x 450 mm Vgradna višina: 800 mm Hod bata: do 500 mm Premer bata: 400/360 mm Hitrost bata navzdol: 200 mm/s Hitrost bata navzgor: 110 mm/s Skupna potreba po moči: 20,5 kW Približna masa stroja: 8 t

Stanje: rabljeno, Leto izdelave: 1985, Pressure: 40 t Stroke: 500 mm Throat depth: 360 mm Installation height: 1000 mm Table size: 630 x 500 mm Table height above floor: 1060 / 720 mm Ram area: 450 x 360 mm Downward speed: from 60 mm/s Upward speed: 300 mm/s Drive power: 7.5 kW Weight: 2.75 t Space requirement: approx. 1.0 x 1.8 x 3.05 m (LxWxH) Ksdpfevzxrpsx Adksdi Pass-through opening in table: 200 mm Approved only for use with secured tools or fixed guarding compliant with German accident prevention regulations (UVV) Equipped with oil-hydraulic drive, intermediate plate on table (height approx. 340 mm) Condition as is, without commissioning

Stanje: rabljeno, Leto izdelave: 1983, Technical Specifications: Press force: 160 t Throat depth: 360 mm Ram stroke (max.): 500 mm Distance table/ram: 800 mm Kdjdpeu Nfvusfx Adkoi Clamping plate on table: 1250 x 630 x 100 mm Pass-through openings in table: 4 x Ø 62 mm Ram speed forward: 200 mm/s Ram speed return: 125 mm/s Ram surface: 450 x 850 mm Borehole in ram: Ø 49 mm Height above floor: 810 mm Total power requirement: 17 kW Machine weight approx.: 7,200 kg Machine dimensions approx. (LxWxH): 2.1 x 1.4 x 3.4 m Manual counter i.O.

Stanje: rabljeno, Leto izdelave: 1991, Technical Details: Pressing force: 160 t Stroke: 500 mm Throat depth: 360 mm Maximum ram stroke: 500 mm Distance between table and ram: 800 mm Clamping plate on table: 1250 x 630 x 100 mm Pass-through openings in table: 4x D=62 mm Ram speed, forward: 200 mm/s Ram speed, return: 125 mm/s Ram area: 450 x 850 mm Kjdpfx Asw D Awmedkodi Pin hole in ram: 49 mm Height above floor level: 810 mm Total power requirement: 17 kW Machine weight approx.: 7200 kg Machine dimensions approx. (LxWxH): 2.1 x 1.4 x 3.4 m

Stanje: rabljeno, Technical details: Pressing force: 25 t Column width: 360 mm Stroke: 500 mm Installation height, table/ram top: 800 mm Throat depth: 360 mm Ram stroke: 500 mm Ram advance speed: 0.200 m/s Ram return speed: 0.45 m/s Table size: 630 x 500 x 71 mm Table opening: Ø 182 mm Ram clamping surface: 450 x 360 mm Pin hole in ram: Ø 32 x 72 mm Ram diameter: Ø 125 mm Height above floor: 710 mm Kedpeu U D I Rofx Adkedi Total power requirement: 12.5 kW Machine weight approx.: 2.4 t Machine dimensions (LxWxH) approx.: 1.7 x 1.1 x 2.95 m Operation via two-hand control panel (and one-hand operation in setup mode) Continuous and single stroke modes TÜV inspection valid until 05/2024 As is. *

Stanje: rabljeno, Technical details: Pressing force: 40 t Throat depth: 365 mm Distance table/ram: 800 mm Ram stroke – max.: 500 mm Ram return speed: 0.45 m/sec Ram advance speed: 0.10 m/sec Ram surface: 450 x 360 x 74 mm Table surface: 630 x 500 x 73 mm Passage hole in table: Ø 205 mm Ksdpfx Adou Nfuqskodi Table height above floor: 720 mm Total power requirement: 13.0 kW Machine weight approx.: 3.2 t Machine dimensions approx. LxWxH: 1.7 x 1.1 x 3.0 m Further technical features: -Braking time: 443 ms -Braking distance: 9 mm -Last machine inspection: May 2020, valid for 1 year

Stanje: rabljeno, Technical Specifications: Pressing force: 25 t Stroke: 500 mm Installation height: table/ram upper position: 800 mm Throat depth: 360 mm Ram stroke: 500 mm Ram speed, advance: 0.100 m/s Ram speed, return: 0.45 m/s Table dimensions: 630 x 500 x 75 mm Clearance in table: Ø 180 mm Ram clamping surface: 450 x 360 mm Ram bore (spindle hole): Ø 32 mm Height above floor: 710 mm Total power requirement: 8.75 kW Kedpfsvc Awxsx Adkodi Approx. machine weight: 2.2 t Approx. machine dimensions (LxWxH): 1.7 x 1.1 x 2.95 m Operation via two-hand control panel (and one-hand control in setup mode) Continuous and single stroke modes

Stanje: rabljeno, Leto izdelave: 1960, Technical Details: Kjdpfx Adju Nfudsksdi Pressure: 10 t Throat depth: 255 mm Ram stroke - max.: 400 mm Ram return speed: 0.180 m/sec Ram advance speed: 0.080 m/sec Installation height: table/ram, top: 630 mm Installation height: table/ram, bottom: 230 mm Table clamping area: 420 x 400 mm Passage opening in table: 220 mm Ram clamping area: 200 x 200 x 65 mm Total connected load: 1.6 kW Machine weight approx.: 1.1 t Machine dimensions approx. LxWxH: 1.1 x 0.5 x 2.1 m

Stanje: dober (rabljeno), Leto izdelave: 2012, Leto izdelave: 1979, vendar je bil stroj leta 2012 popolnoma generalno obnovljen po najnovejših UVV standardih Vgradna višina: 800 mm Hod batnice: 500 mm Izsev: 360 mm Nazivna sila: 400 kN Hidravlični tlak: 160 bar Obratovalne ure: 1356 Ksdpfxoydlx Sj Adkedi Ostalo: nova krmilna enota Pilz, električne sheme so na voljo Video o funkcionalnosti je na voljo

Stanje: dober (rabljeno), Maximum pressing force: 10 tons. Operating pressure: 16 MPa Cylinder stroke: 400 mm Downward speed: 100 mm/sec Speed up to: 450 mm/sec Power requirement: 5.2 kW Weight: 1.3 tons Ksdpfxsydlvks Adksdi Clamping table modified! Not the original table!

Stanje: rabljeno, Technical details: Piston diameter: Ø 160 mm Weight: 200 kg Dimensions: 0.6 x Ø 0.3 m Ksdou Nurfepfx Adksdi Draw cushion for a WMW Erfurt press PYE 160 Blank holding force: 50 metric tons (MP) Ejector force: 4 metric tons (MP) Stroke: up to 160 mm Flange diameter: Ø 280 mm Piston centering bore: M16, mounting holes: M24, Ø 118 mm Hydraulic connection: 2x 1 inch internal thread (i.D.)

Stanje: rabljeno, Technical Details: Kdodpovc Ax Nofx Adkji Pressing force: 100 t Installation height: Table/Ram top position: 800 mm Throat depth: 360 mm Ram stroke: 500 mm Ram advance speed: 200 mm/s Ram return speed: 200 mm/s Table size: 750 x 560 x 90 mm Passage in table: Ø 26 mm Ram mounting surface (W x D): 530 x 400 mm Pin hole in ram: Ø 50 mm Cylinder diameter: Ø 250 mm Height above floor: 720 mm Total power requirement: 17.0 kW Approx. machine weight: 5.5 t Approx. machine dimensions (L x W x H): 1.8 x 1.2 x 3.2 m

Stanje: generalkompletno obnovljen (rabljeno), Enostebrična hidravlična stiskalnica (generalno obnovljena) PYE 160 S1M Kdedpfoycl Hgjx Adkoi - Tlačna sila: 1600 kN - Vgradna višina: 800 mm - Hod: 500 mm - Hitrost: spuščanje 200 mm/s - Izbirna vlečna blazina: 630 kN, hod: 200 mm - Pogon: 17 kW - Dimenzije: 3500 x 2000 x 1200 mm - nov krmilni sistem, nova krmilna omara, svetlobna zavesa (1 takt, 2 takta, zaščita), nova hidravlika, - nova tesnila, barva po želji - nov UVV pregled

Stanje: generalkompletno obnovljen (rabljeno), Enostebrična hidravlična stiskalnica (generalno obnovljena) PYE 250 S1M z vlečno blazino - Stisna sila: 2500 kN - Vgradna višina: 800 mm Kdedjycl Evopfx Adkei - Hod: 500 mm - Hitrost: navzdol 200 mm/s - Vlečna blazina: 1000 kN, hod: 200 mm - Pogon: 20,5 kW - Dimenzije: 3500 x 2000 x 1200 mm - nova krmilna enota, nova krmilna omara, svetlobna zavesa (1 takt, 2 takta, zaščita), nova hidravlika, - nova tesnila - nov UVV pregled

Stanje: zelo dobro (rabljeno), Leto izdelave: 1990, Funkcionalnost: popolnoma funkcionalen, skupna višina: 3.200 mm, skupna širina: 1.200 mm, skupna dolžina: 1.900 mm, stiskalna sila: 100 t, širina mize: 750 mm, dolžina mize: 560 mm, obratovalna hitrost: 200 mm/s, skupna masa: 5.040 kg, hitrost vzvratne vožnje: 200 mm/s, širina plošče bata: 530 mm, dolžina plošče bata: 400 mm, hod: 500 mm, Oprema: dokumentacija / priročnik, Hidravlična stiskalnica PYE 100 S1M z izmetalcem.\nProizvajalec: Werkzeugmachinen GmbH Zeulenroda (Nemčija), leto 1990.\nParametri:\nMaksimalna stiskalna sila: 100 ton.\nDelovni tlak: 16 MPa.\nMaksimalna izmetalna sila: 40 ton.\nHod batnice izmetalca: 200 mm.\nZgornja miza: 530x400 mm.\nSpodnja miza: 750x560 mm.\nSvetla odprtina: 800 mm.\nHod cilindra: 500 mm.\nHitrost navzdol: 200 mm/s.\nHitrost navzgor: 200 mm/s.\nPotreba po moči: 17 kW.\nTeža: 5040 kg.\nVišina: 3200 mm, Dolžina: 1900 mm, Širina: 1200 mm. Kedpfxjygtzye Adksdi

Stanje: dober (rabljeno), Leto izdelave: 1995, For sale: Hydraulic press PYE-63S Kdjdpfx Asv Uxttedksi The price listed in the advertisement is the net price, to which VAT should be added.

Stanje: rabljeno, Leto izdelave: 2001, Tehnične podrobnosti: Tlak: 250 t Izteg: 360 mm Razdalja miza/bate: 800 mm Maks. hod bata: 500 mm Hitrost povratka bata: 390 mm/s Hitrost napredovanja bata: 450 mm/s Hidravlični tlak: 280 bar Priključna moč: 43 kW Delovna hitrost: 11....50 mm/s Kedpexna Uzefx Adkodi Obratovalni tlak: 20 MPa Skupna potrebna moč: 20,5 kW Teža stroja pribl.: 17 t Mere stroja pribl. D x Š x V: 3,9 x 1,9 x 4,0 m

Stanje: rabljeno, Tehnični podatki: Pritisk: 40 t Razmik med stebri: - mm Hod: 500 mm Kjdpfx Asw Smukedksdi Izmet: 360 mm Razdalja miza/bat: maks. 800 mm Vgradna višina: miza/bat zgoraj: 600 mm Hod bata: 500 mm Hitrost bata naprej: 0,100 m/s Hitrost bata nazaj: 0,450 m/s Velikost mize: 750 x 500 mm Prehod na mizi: 200 mm Vpenjalna površina bata: 360 x 450 x 72 mm Luknja za čep v batu: 40 x 75 mm Višina nad tlemi: 700 mm Skupna potrebna moč: 13 kW Približna masa stroja: 3,2 t Približne dimenzije stroja DxŠxV: 1,75 x 1,15 x 2,95 m

Stanje: rabljeno, Pressure: 160 t Throat depth: 360 mm Stroke: 500 mm Table size: 1250 x 630 mm Kjdpfxolp U Hge Adkedi Ram area: 1000 x 450 mm Table height: 1000 mm Installation height: 800 mm Machine weight: approx. 8 t Two-hand operation Foot pedal operation Rapid and working stroke Pressure and travel cut-off Drawing cushion

Stanje: rabljeno, Pressure 10 t Stroke 400 mm Downward speed from 200 mm/sec Kedped R Szuofx Adkodi Upward speed 450 mm/sec Max. distance table - ram 630 mm Total power requirement 8.5 kW Machine weight approx. 1.3 t Space requirement approx. ... m - without clamping plate - only approved for operations with closed tooling

Stanje: rabljeno, Leto izdelave: 1979, Pressure: 10 t Throat depth: 250 mm Stroke: 400 mm Downward speed: from 100 mm/sec Upward speed: 450 mm/sec Kodpfx Ajwbizyjdkjdi Max. distance table to ram: 630 mm Total power requirement: 5.2 kW Machine weight: approx. 1.3 t

Stanje: rabljeno, Leto izdelave: 1986, Tlak 160 t Izvesek 360 mm Hod 500 mm Hitrost dol 200 mm/s Kdodpfx Adev Rgwxokei Hitrost gor 125 mm/s Najv. razdalja miza - bat 1000 mm Površina mize 900 x 630 mm Površina bata 850 x 450 mm Vpenjalni zatič premer x globina 50 H7 / 85 mm Skupna moč 17 kW Teža stroja pribl. 7 t Potrebni prostor pribl. D x Š x V 1,25 x 2,2 x 3,45 m

Stanje: generalkompletno obnovljen (rabljeno), RETROFIT Complete Pressing force: 1600 kN Installation height: 800 mm Stroke: 500 mm Table: 900 x 630 mm Ram: 750 x 450 mm Throat depth: 360 mm Downward speed: 200 mm Upward speed: 125 mm Machine height: approx. 3,500 mm Weight: approx. 7,000 kg Connection: 17 kW - A complete retrofit kit for unrestricted manual loading and unloading in accordance with EU Conformity and implementation of equipment in line with CE regulations,  New control cabinet with certified dual-channel electronic PLC safety control system from Siemens (1512SP F or 1515F) for process control, featuring an integrated operator panel for the following operating modes: setup with two-hand operation, single stroke with two-hand operation, and foot control (only in combination with BWS); manual lever operation is no longer possible, Kodew S Uazopfx Adkjdi  Hydraulic safety block for monitoring the closing movement on the main cylinder,  Position-monitored directional control valve for upward and downward movement of the main cylinder ram,  Two-hand control unit with dual-channel monitoring of the two-hand synchronization at the press table (incl. 5m cable),  Replacement of the main and control pump motors,  Replacement of the main cylinder seals,  Fine filter with contamination indicator,  The press features an electronic stroke measurement system (including teach-in function and current ram position display). This eliminates the need for a mechanical cam switch assembly. Main control panel integrated in the control cabinet (mounted on the right side of the machine) o 12" touch panel o Operating buttons and switches for modes and drives o USB interface for data exchange - Light curtain Option: Drawing cushion

Stanje: dober (rabljeno), Leto izdelave: 1988, številka stroja/vozila: 053-019/35, Offer 24591 Technical specifications: - Max. pressing force: 25 t - Max. ram stroke: 500 mm - Stroke speed: 0 – 40 mm/s - Return speed: 0 – 200 mm/min - Installation height: 800 mm - Throat depth to centre of ram: 360 mm - Ram clamping area: 440 x 360 mm - Ram clamping pin: 40 mm - Table size: 630 x 500 mm - Table height above floor: 710 mm - Drawing force: 10 t - Max. drawing depth: 160 mm - Drive: 400 V / 4 kW - Space requirements (approx.): W 800 x H 2720 x D 1150 mm - Weight (approx.): 2500 kg Kdodpfx Aewd Nybsdkei

Stanje: zelo dobro (rabljeno), Leto izdelave: 1984, skupna višina: 34.500 mm, vgradna višina: 800 mm, skupna širina: 12.500 mm, skupna dolžina: 22.000 mm, globina grla: 800 mm, stiskalna sila: 160 t, širina mize: 900 mm, dolžina mize: 630 mm, obratovalna hitrost: 200 mm/s, skupna masa: 7.000 kg, hitrost vzvratne vožnje: 125 mm/s, širina plošče bata: 700 mm, dolžina plošče bata: 450 mm, vrsta vhodnega toka: trifazni, hod: 500 mm, obratovalni tlak: 160 letvica, pritisk: 250 letvica, kapaciteta rezervoarja za olje: 500 l, moč: 17 kW (23,11 KM), Hidravlična stiskalnica PYE 160 S/1M. Leto izdelave 1984. Proizvajalec VEB Wema Zeulenroda (Nemčija). Stroj po generalnem servisu. Tehnični podatki: Največja stiskalna sila 160 ton. Delovni tlak 16 MPa. Zgornja miza 700 x 450 mm. Spodnja miza 900 x 630 mm. Svetla višina 800 mm. Hod cilindra 500 mm. Hitrost spuščanja 200 mm/s. Hitrost dviganja 125 mm/s. Potrebna moč 17 kW. Količina olja v rezervoarju 500 l. Teža 7000 kg. Višina 3450 mm, dolžina 2200 mm, širina 1250 mm. Stroj v zelo dobrem stanju. Ogled in preizkus delovanja stroja je možen. Kdsdpfsqy E I Rex Adkoi
