High Z Cnc nakup rabljenega (61.298)

Stanje: rabljeno, CNC Travelling Column Boring and Milling Machine ANAYAK Type HVM-3800-P Bed Type Milling Machine, design similar to a plate boring machine with fixed table Machine No.: M-20021203 Year of Manufacture: 2002 "Refurbished 2025" The machine will be workshop-refurbished in 2025 and can then be inspected at our warehouse in 37235 Hessisch Lichtenau. Travels: X: 3200 mm, Y: 1200 mm, Z: 1500 mm Table size: 3800 x 1200 mm T-slots: 8 x 22 mm, spacing 130 mm Table load max. 25 t (stationary table – almost unlimited load capacity) Spindle taper: ISO 50 (DIN69871-A) (pull stud DIN 69872-B) Spindle speed: 60–4000 rpm, stepless Feed rate: up to 10,000 mm/min, stepless Lrodpfsxcgtgjx Ab Toi Rapid traverse X + Y: 20 m/min Rapid traverse Z: 10 m/min Spindle drive: 22 / 30 kW Power supply: 400 Volt, 50 Hz, 50 kVA - Automatic 30-position tool changer - Spindle drive with 2 speed ranges - With automatic tool changer and tool magazine - Orthogonal milling head with hydromechanical tool clamping - Orthogonal milling head can be fully automatically swivelled in two 45° planes – B+C axis - Control: HEIDENHAIN iTNC 530, with electronic handwheel - Prepared for wireless measuring probe (probe and receiver not included) - Additional HF spindle 18,000 rpm – can be mounted - Free-standing control cabinet - Chip conveyor mounted between travelling column bed and machine table - 32,078 operating hours read - Coolant system - Freestanding hydraulic unit - Operating manual with circuit diagrams Machine footprint: L x W approx. 1000 x 700 cm Machine height: approx. 410 cm Weight (complete): approx. 33 t Good condition

Stanje: dober (rabljeno), Leto izdelave: 2007, Funkcionalnost: popolnoma funkcionalen, NAKAMURA WY250 SUPERMILL LATHE, YEAR 2007, FULLY OPERATIONAL WITH DOUBLE Y-AXIS - FANUC 31iA2 CONTROL - MAIN SPINDLE: 65mm BAR CAPACITY, 18KW POWER, ASA 6, 4500RPM - SUB SPINDLE: 51mm BAR CAPACITY, 11KW POWER, ASA 5, 5000RPM - LIVE TOOLING: 7KW POWER WITH 40Nm TORQUE ON BOTH TURRETS (SUPERMILL 65mm BORE) - Y-AXIS ON BOTH TURRETS (UPPER Y-TRAVEL +50/-50mm, LOWER Y-TRAVEL +20/-50mm) - PART CATCHER TYPE G - DISTANCE BETWEEN SPINDLE NOSES: 870mm - MAX TURNING DIAMETER: 225mm - RAPID TRAVERSE Z: 36m/min, X: 18m/min - OVERSIZED COOLANT TANK 500L WITH CHIP CONVEYOR - TURRET COOLANT PUMPS: GRUNDFOS CRK4-100/10, DOUBLE STAGE, 3-12 BAR WITH FILTERS - COOLANT JETS ABOVE SPINDLES - WASH AND AIR BLOW THROUGH SUB-SPINDLE - AUTO SHUTDOWN - 3-COLOR SIGNAL LIGHT - LOAD MONITOR ON NT NURSE AXES - IEMCA MASTER 880 BAR FEED, YEAR 2003 - SUPPLIED TOOLHOLDERS AND COLLET HOLDERS SET INCLUDES: With the machine: 4 external tool holders 4 twin-opposed tool holders for simultaneous mounting of 2 opposing tools 6 boring bar holders 1 H32 parting blade holder 4 radial driven tool holders (HEIMATEC) 4 axial driven tool holders Lrjdpfx Asyrb Tnsb Tei 1 Bellegrandi MSCNT70-A6” collet holder for BA and BD size 70 collets (with corresponding sleeves, main spindle side) 1 Bellegrandi MSCTNR70-A5” collet holder for BA size 70 collet (with spring ejector, sub-spindle side) Complete ‘Hand Jaw’ set (grippers) for parts ejector

Stanje: kot nova (razstavni stroj), CNC Ultra-High Pressure Waterjet Cutting System SAME / Bogacki - 2515 BA 2D Lodpfxjgq Nqbj Ab Teri - Demonstration machine - Travel paths: 2,550 x 1,550 x 200 mm Control: BOSCH MTX Aquacut edition - CAD / CAM system - Operator PC with portable electronic handwheel includes High-pressure pump HB 50 includes Stainless steel worktable (2,700 x 1,700 mm) includes CE-compliant safety features (light barriers) includes Splash guard (see images) includes Abrasive container (250 kg) includes Allfi Abrasive cutting head includes Red light laser includes Drilling unit with 4mm diameter, ER 16 holder - Low operating hours

Stanje: zelo dobro (rabljeno), Leto izdelave: 2004, Funkcionalnost: popolnoma funkcionalen, Control system: GE FANUC 21i-TB Swing diameter: 533 mm Turning diameter: 340 mm Turning length: 355 mm X-axis travel: 209 mm Z-axis travel: 355 mm Spindle bore: Ø50.8 mm Spindle speed: 5,000 rpm Chuck max. Ø200 mm Turret: 12-station Rapid traverse: 30 m/min Drive power: 11 kW Spindle nose: A2-6 Tool holder: VDI30 C-axis: 0.001° (programmable) Dimensions (LxWxH): 2300 x 1700 x 1700 mm Weight: approx. 3,000 kg Equipment & Accessories: - Hydraulic chuck - Short bar loader EMT Super 80 - Manual Guide in FANUC software - Driven tool turret and C-axis - Tailstock - Parts catcher Lredpfx Aevw Uqajb Tei - Manuals Very good condition. The machine operates accurately.

Stanje: zelo dobro (rabljeno), Leto izdelave: 2022, obratovalne ure: 2.394 h, Funkcionalnost: popolnoma funkcionalen, HAAS control system Swing diameter: 641 mm Swing diameter over cross slide: 413 mm Max. turning diameter: 229 mm Max. turning length: 356 mm X-axis travel: 200 mm Y-axis travel: +/-50 mm Z-axis travel: 355 mm Max. bar capacity: 44 mm C-axis resolution: 0.01 degrees Spindle speed: 6,000 rpm Spindle nose: A2-5 Milling spindle speed: 6,000 rpm Ledpfowvf Thjx Ab Tjri Rapid traverse X/Y/Z: 30.5 / 12.7 / 30.5 m/min Drive power: 11 kW Revolver: 12-position Mounting: VDI30 Weight: 3,600 kg Dimensions (LxWxH): 3048 x 2108 x 1803 mm Accessories / Equipment: - Programmable C-axis - Y-axis - Driven tool turret (all positions) - Integrated tool measuring arm - Chip conveyor - 3-jaw chuck D160 mm - Tailstock The machine is in like-new condition and has seen very little use.

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2020, obratovalne ure: 250 h, Funkcionalnost: popolnoma funkcionalen, Control: NCT 201/15” touch screen + USB (Windows-based) Max. swing diameter over bed: 590 mm Max. swing diameter over cross slide: 340 mm Max. turning diameter: 300 mm Centre distance: 300 mm Chuck diameter: 8" Guideway type: Linear Travel paths X / Z / Y / W: 160 / 455 / - / 325 mm Rapid traverse speed X / Z / Y / W axis: 24 / 30 / - / 24 m/min MAIN SPINDLE: Max. speed: 3500 rpm Spindle nose: A2-6 Spindle bore: D75 mm Bar capacity: max. D60 mm Drive: Belt Lrjdpfxjx R Smkj Ab Tji Number of ranges: 1 Motor power: 15 kW Cooling: Air SUB SPINDLE: Max. speed: 3500 rpm Spindle nose: A2-5 Motor power: 6.9 kW Drive: Belt TOOLS: Tool changer: Tool stations: 12 Tool system: VDI30 Number of driven tool positions: 12 Max. driven tool speed: 4000 rpm DIMENSIONS: Footprint x Height: 2693 x 1810 x 1950 mm Net weight: 4230 kg BAR FEEDER: Type: BF1500 / DH65-LN Max. bar length: 1500 mm Max. bar diameter: D65 mm Weight approx. 333 kg Equipment, accessories: - Chip conveyor - Coolant system - Bar feeder - Discharge conveyor for finished parts - Sub spindle - C axis + driven tool turret - Tool holders - Manuals - CE marking - Foot pedals The machine has barely been used. It is powered up in Western Hungary and is available for inspection.

Stanje: kot nova (razstavni stroj), Leto izdelave: 2024, obratovalne ure: 10 h, Funkcionalnost: popolnoma funkcionalen, SIEMENS 828D control with Shopturn, 17-inch touch screen Swing diameter over bed: 550 mm Maximum machining length: 428 mm Maximum machining diameter: 300 mm Spindle bore: 62 mm Bar machining capacity: 51 mm Spindle nose: A2-6 Spindle speed range: 35 - 5,000 rpm (motor spindle) X-axis travel: 210 mm Z-axis travel: 561 mm Tool changer for driven tools: 12 positions Tool changer locking: hydraulic Tool changer drive: servo Lrodpfx Aowbu T Usb Tji Tool change time: 0.2 seconds Tool holder: 25 x 25 mm Driven tool max. speed: 5,000 rpm Driven tool max. power: 5 kW Max. milling capacity (shank cutter): 16 mm Max. milling capacity (face mill): 50 mm Max. drilling capacity: 16 mm Max. thread cutting capacity: M16x2 Rapid traverse Z-axis: 30 m/min Rapid traverse X-axis: 30 m/min Positioning accuracy: 0.008 mm Repeatability: 0.003 mm Tailstock: optionally programmable tailstock Quill taper: Morse taper 4 Tailstock travel incl. quill stroke: 565 mm Hydraulic unit tank capacity: 20 liters Hydraulic unit pump capacity: 1.5 kW Hydraulic unit nominal pressure: 3.5 - 6 MPa Central lubrication tank capacity: 2 liters Central lubrication output: 25 W Coolant tank capacity: 130 liters Coolant pump output: 25 W Continuous motor power: 11 kW, 400 V, 50 Hz Short-term motor power (30 min): 15 kW, 400 V, 50 Hz Weight: 4,000 kg Dimensions: 2,600 x 1,685 x 1,768 mm Accessories, Equipment Coolant system, tool changer for 12 driven tools, 200 mm hydraulic power chuck, linear guides and ball screw from THK/Japan, Siemens 828D control, spindle cooling, chip conveyor, workpiece measurement, automatic tool length correction, bar feeder, air blow function for tool changer and lathe chuck, spindle, high-pressure cooling, oil skimmer, part catcher.

Stanje: nepreverjeno (rabljeno), Leto izdelave: 2002, Funkcionalnost: nepreverjeno, številka stroja/vozila: 23220702, premer brusilnega koluta: 300 mm, dolžina mize: 820 mm, širina mize: 350 mm, skupna masa: 3.500 kg, model krmilnika: SIEMENS SINUMERIK, Brez minimalne cene – zagotovljena prodaja najvišjemu ponudniku! Oddaja ponudbe zavezuje k pravočasnemu prevzemu med 04.05.26 in 07.05.26. TEHNIČNI PODATKI Območje brušenja: 600 x 350 x 375 mm Maks. premer brusnega koluta: 300 mm Dimenzije mize: 820 x 350 mm Dimenzije magneta: 600 x 350 mm PODROBNOSTI O STROJU Krmiljenje: SIEMENS SINUMERIK Obratovalna napetost: 3 x 400 V Ljdpfxoyr Nqne Ab Tsri Frekvenca: 50 Hz Nazivni tok: 35 A Priključna moč: 7 kW Dimenzije in teža Dimenzije (D x Š x V): 4.000 x 2.400 x 2.300 mm Teža: 3.500 kg OPREMA Vpenjalni magnet MPM uravnoteževalna naprava Zunanja referenca: 61

Stanje: dober (rabljeno), Leto izdelave: 2012, Stroj je v dobrem delovnem stanju. Lsdpfx Aeylx Hrob Tjri

Stanje: dober (rabljeno), Leto izdelave: 2002, Réf. : 10442 Fabricant : LIEBHERR Type : LC 122 Année de fabrication : 2002 Type de commande : CNC Commande : LIEBHERR PC NC Emplacement en stock : Halberstadt Pays d'origine : Allemagne Diamètre maxi. de fraise-mère : 90 mm Diamètre de la table : 145 mm Module maxi. : 3 mm Nombre minimal de dents usinables : 4 Angle d'inclinaison de la tête de fraisage : +/- 45° Précision de résolution : 0,1 degré Lredjym Nbcjpfx Ab Tei Charge admissible sur la table pièce : 17 kN Vitesse de rotation de la fraise : 450 - 4 500 tr/min Tension d’alimentation : 400 V Tension de commande : 24 V Fréquence : 50 Hz Courant nominal max. : 55 A Fusible en ligne : 63 A Diamètre maxi. d’usinage pignons droits/côniques : 125 mm Largeur maxi. d’usinage pignons droits/côniques : 250 mm (axial) Course de broche : 180 mm Largeur maxi. de la fraise : 200 mm Informations complémentaires : Température ambiante : +12°.....+40° Niveau sonore en fonctionnement : 78 dB (A) Désignation de la tête de fraisage : Tête de fraisage motorisée Axe pièce : vertical Montant : mobile Table : fixe Procédé d’usinage : fraisage par générateur axial en avalant ou en opposition La machine peut être vue sous tension sur rendez-vous.

Stanje: rabljeno, Horizontal machining center with dual pallet changer STEINEL type BFZ 5 with CNC control SIEMENS Sinumerik 810 M Serial No. 34 Year of manufacture: 1988 Travel X: 500 mm, Y: 400 mm, Z: 320 mm Clamping surface, table size: 500 x 400 mm Tool holder: ISO 40 Spindle speed: max. 6300 rpm, infinitely variable Main spindle drive: 12 kW Power supply: 380 Volt, 50 Hz, 30 kVA - Tool changer with 24 tool positions - Pallet changer with 2 stations - Interface for data transfer - Coolant system with chip conveyor Required space (L x W x H): 4100 x 2500 x 2650 mm Weight: approx. 8 tons Ledpfxsutuyij Ab Tjri Good condition Transport dimensions: Machine L x W x H: 3200 x 2500 x 2650 mm, approx. 7.5 tons Chip conveyor L x W x H: 3500 x 1100 x 2100 mm, approx. 600 kg

Stanje: rabljeno, Leto izdelave: 1987, Premer vrtenja: 400 mm Dolžina struženja: 600 mm Premer nihanja: 600 mm Vrtina vretena: 73 mm Tehnični podatki so navedeni po podatkih proizvajalca oziroma upravljavca in zato za nas niso zavezujoči. Pridržujemo si pravico do vmesne prodaje; izključno veljajo naši splošni pogoji poslovanja in prodaje. Lodpfxoyutrus Ab Teri O nas več kot 400 lastnih strojev na zalogi več kot 15.000 m² skladiščnih površin, kapaciteta žerjava 70 t več kot 10.000 kosov dodatne opreme za vašo delavnico Če želite prodati stroje, proizvodne linije ali vaše podjetje, nas kontaktirajte. Dodatne ponudbe najdete na naši spletni strani. Ogledi so možni po dogovoru. Veselimo se vašega obiska. Ekipa Markus Hirsch

Stanje: rabljeno, 4-axis CNC drilling and milling machine IXION type 30 CNC W VMC, machining center Year of manufacture approx. 1997, machine overhauled in 2020 Travels: X: 600 mm, Y: 350 mm, Z: 600 mm Table size: 800 x 400 mm T-slot spacing: 75 mm Table load capacity: 300 kg Spindle taper: SK 40 (drawbar DIN 69872 A) Spindle speed: 20–5000 rpm Max. spindle torque: 150 Nm Max. spindle nose to table distance: 660 mm Feed rate X, Y, and Z: 0 – 5000 mm/min, stepless Rapid traverse X, Y, and Z: 15,000 mm/min Tool change time: approx. 5 sec Chip-to-chip tool change time: approx. 7.5 sec Milling capacity in St 60: 150 ccm/min Drilling capacity in St 60: 35 mm Thread cutting capacity in St 60: M24 Spindle motor power: 5 kW (10 kW at 25% duty cycle) Power supply: 400 Volt, 50 Hz - CNC control: Heidenhain TNC 415 with 12" TFT display Lredpou Tln Njfx Ab Tsi - Electronic handwheel - RS 232 interface - 12-position tool changer - Hydro-mechanical tool clamping - Rotary axis as dividing attachment on the table = 4th axis, MECATECNICA type DCN 250-8, 3-jaw chuck Ø 200 mm Rotation speed approx. 25 rpm, transmission ratio 1:180 - Cabin lighting via 2x halogen spotlights - Chip conveyor with coolant pump - Control cabinet fixed to the machine Transport dimensions: Length 320 cm x Width 230 cm x Height 300 cm Machine footprint with chip conveyor (L x W x H): 3200 x 3100 x 3000 mm Machine weight: 3,100 kg Chip conveyor weight: approx. 200 kg Good condition

Stanje: rabljeno, CNC Lathe DMG MORI SEIKI – GILDEMEISTER Type CTX 310 ecoline Machine No. 8044001846E Year of manufacture: 2013 CNC Control: SIEMENS Sinumerik 840D sl Swing diameter over bed cover: 330 mm Swing diameter over cross slide cover: 260 mm Center height max.: 190 mm Distance between centers max.: 580 mm Turning diameter max.: 200 mm Longitudinal travel (Z-axis) max.: 450 mm Cross travel (X-axis) max.: 160 mm Bar capacity through draw tube: 51 mm Bar capacity at front bearing: 100 mm Spindle speed max.: 5000 rpm Feed rate X and Z: mm/min. Rapid traverse X-axis: 30 m/min. Rapid traverse Z-axis: 30 m/min. Feed force X and Z: 4500 Nm Lrsdpfoyk Hrgox Ab Tji Tool turret: 12 stations Driven tool stations: 6 stations Tool holder: cylindrical VDI 30 mm Spindle drive motor power at 100% duty cycle: max. 11 kW Spindle drive motor power at 40% duty cycle: max. 16.5 kW Power supply: 400 Volt, 50 Hz, 21 kVA - CNC control SIEMENS Sinumerik 840D sl, system software NCU V04.04+SP02+HF02 - Controlled C4-axis (chuck position) and C1-axis for tool turret - 3-jaw power chuck AUTOGRIP Ø 210 mm with 1 set of hard jaws and 15 sets of soft jaws - Hydraulic hollow chuck AUTOGRIP - Clamping pressure adjustment to regulate clamping force - Tool turret SAUTER, type 0.5.901.020 with 12 stations (6 of which are driven) - 20 tool holders VDI 30 - Tailstock MK 4 - Indirect measuring system via rotary encoder - Chip conveyor with integrated coolant system - Workpiece remaining time display and piece counter (large display on the machine enclosure) - Control cabinet cooling unit - 9716 total operating hours (main switch on), of which 3322 spindle hours according to the counter - Operating instructions and manuals Machine footprint with chip conveyor (L x W x H): 4500 x 2600 x 2050 mm Base machine footprint (L x W x H): 2900 x 2150 x 2050 mm (3200 kg) Chip conveyor footprint (L x W x H): 3350 x 850 x 1650 mm (500 kg) Weight: approx. 4 tons Very good condition.

Stanje: zelo dobro (rabljeno), Leto izdelave: 2014, stružna dolžina: 700 mm, potovalna razdalja osi X: 205 mm, pomik po osi Z: 700 mm, moč vretenovega motorja: 22.000 W, skupna višina: 2.800 mm, skupna dolžina: 6.000 mm, skupna širina: 3.900 mm, skupna masa: 9.800 kg, Complete machining with double spindle, upper and lower turret Kitagawa 3-jaw chuck left and right Tool holders with driven tools, both axial and radial Large jaw cabinet with inserts Lrsdpfjyn Em Rex Ab Tji OGL gantry loader with approx. 10 kg load capacity Chip conveyor Paper band filtration system with pressure tank Max. turning diameter: 400mm X-axis travel: 205mm Z-axis travel: 700mm Spindle bore: 62mm Spindle speed: 6000 RPM Spindle power: 22kW Sub-spindle speed: 6000 RPM Sub-spindle through hole: 62mm Sub-spindle power: 15kW Tool changer: 16 positions Driven tool speed: 6000 RPM Lower turret positions: 16 Driven tool speed: 6000 RPM Driven tool power: 7kW Chip conveyor: yes Tool Eye: yes Length: 6000mm Width: 3900mm Height: 2800mm Weight: 9800kg Please note: The information on this page has been obtained to the best of our knowledge and, where possible, from the manufacturer. The information is provided in good faith, however, accuracy cannot be guaranteed. Accordingly, this does not constitute representation or contract terms. We recommend that you verify all key details yourself.

Stanje: zelo dobro (rabljeno), Leto izdelave: 2020, Največji premer struženja 550 mm, vrtljaj nad posteljo 950 mm, Lredpoywuibefx Ab Tei vrtljaj nad prečnim suportom 715 mm, hitrost vretena 3.500 rpm, os Y +80/-60 mm, razdalja med centri 898 mm, hitrost rezkanja 12.000 rpm, glavna kapaciteta vretena za palice 78 mm, 16-postajna revolverska glava, moc vretena 40/25 kW, krmilje Fanuc serije I, glavni 3-čeljustni vpenjalni tulec, merilec orodij, transporter odrezkov,

Stanje: rabljeno, CNC Tool Milling Machine MIKRON Type WF 40C/3M with Heidenhain TNC 310 CNC path control Machine no. 440911 Year of manufacture: approx. 1985, Overhauled and control system retrofit in 11/2000 Travel paths X: 600 mm Y: 600 mm Z: 460 mm Table size 900 x 550 mm Spindle taper ISO 40 Distance spindle nose - table max. 520 mm Spindle speed 31.5 - 3150 rpm, 21 steps Feed rate 1 - 2000 mm/min. Rapid traverse speed X and Y = 5000 mm/min.; Z = 4000 mm/min. Quill stroke 100 mm Main spindle drive 4 and 5 kW Mains connection 400 Volt, 50 Hz, 10.5 kW, 25 Amp. - Heidenhain TNC 310 CNC path control, NC software: 286140 07, PLC software: MIKR1 - Spindle speed via 21 gearbox steps - Vertical milling head swivels right and left - Hydro-mechanical tool clamping vertical and horizontal - Central lubrication - Electronic handwheel - 62,815 operating hours (readout) - Control cabinet fixed to the machine rear - Coolant system in machine base - Swiveling operator panel - Electrical diagram, operator's manual for the control system available Lsdsw A Af Iopfx Ab Tjri Required space (L x W x H) 2300 x 2000 x 2150 mm Weight 2900 kg Good condition

Stanje: zelo dobro (rabljeno), Max. turning diameter: 20 mm Max. turning length: 320 mm Lsdpfommdacox Ab Tsri Spindle bore: 24 mm Spindle speeds: 200–10,000 rpm Turret with 10 positions, all driven LNS bar feeder Various accessories MARCELS MASCHINEN AG

Stanje: rabljeno, Leto izdelave: 2005, Obratovalni premer 290 mm Obratovalna dolžina 300 mm Lredpeyb S Ihefx Ab Tsi Krmiljenje Heidenhain Premer vrtenja nad ležiščem 380 mm Skupna potrebna moč --- kW Teža stroja ca. --- t Potreben prostor ca. --- m Gildemeister CTX 2100 - 2005 s C-osjo

Stanje: rabljeno, Leto izdelave: 2010, Technical details: Spindle bore: 92 mm Turning length: 1000 mm Z-axis: min.: 404 mm; max.: 1130 mm Cross travel (X-axis): min./max.: 15 / 335 mm Control: Sinumerik SL840D Spindle torque: 2500 Nm Tool turret: 12 axial tools Operating pressure: 6.0 bar Rapid traverse: 20 m/min Total power requirement: 88 kVA Machine dimensions approx. (LxWxH): approx. 4.45 x m Bar loader dimensions (LxWxH): approx. L: 5.7 x W: 2.65 x H: 2.4 m Lathe with bar loader Ledpowf Nraefx Ab Tsri - SL 840D control with NCU Software 2.6, System Software 1.4, Shop Turn Software 6.4, with orientable C-axis, without driven tools - Chuck KNCS 260-72, SMW Autoblok - Clamping force generator via VNK-200/86 clamping cylinder / SMW Autoblok - Measuring system by Heidenhain - Sauter VDI50 disk turret, electric drive Bar Loader Master 80HF, Type 33LL: - Bar stock dimension min./max.: Ø 20mm / 80mm - Minimum workpiece length: 33-38-43 up to 1000mm - Maximum workpiece length: 33 - 3300mm / 38 - 3800mm / 43 - 4300mm - Feed speed (adjustable) 150mm/sec, return speed (adjustable) 950mm/sec - Max. remnant length: Ø 8+65mm = 400mm / Ø 66+80mm = 250mm - Min. remnant 120mm Chip conveyor/hinged belt by Richter, Type SP 450/63 - Discharge height = 1000mm, discharge side right Accessories: - Various VDI 50 tool holders - Measuring adapter SK50-> VDI 50 - Power chuck Hainbuch Toplus Kombi Axial-pull GR100 - Various sleeves, guide jaws for bar loader Ø 20 - 75mm i.d.

Stanje: rabljeno, Leto izdelave: 2000, Pozicija obsega: Lrodjym Sp Nspfx Ab Tji (1) CNC stroj za globinsko valjanje Tehnične podrobnosti: Največja dolžina 920 mm, največji radij protiuteži (odvisno od hoda in širine ležaja) 195 - 270 mm, največ 8 glavnih + 6 ojnicnih ležajev, min/maks premer glavnega ležaja 33 - 88 mm, min/maks premer ojnicnega ležaja 30 - 84 mm, največja širina ležaja 18,5 mm, največji hod 140 mm, CNC SIEMENS SINUMERIK 840D, 400V 50Hz 35kVA, teža 13 t.

Stanje: rabljeno, Premer vrtenja 280 mm Dolžina vrtenja 800 mm Krmiljenje Siemens Tip 840 D Hitrost vrtenja 4000 obr/min Premer kroženja 320 mm Trivpenjalni vpenjalni vrtljivi vpenjalni Forckrath 250 mm Stroj je bil obnovljen Tehnični podatki so navedeni po podatkih proizvajalca oz. uporabnika, zato zanje ne prevzemamo odgovornosti. Pridržujemo si pravico do predhodne prodaje; veljajo izključno naši splošni pogoji poslovanja in prodaje. O nas več kot 400 lastnih strojev na zalogi več kot 15.000 m² skladiščne površine, zmogljivost žerjava 70 t več kot 10.000 kosov dodatne opreme za vašo delavnico Če želite prodati stroje, proizvodne linije ali vaš obrat, Lrodpfjyqv Epjx Ab Toi nas kontaktirajte. Dodatne ponudbe najdete na naši spletni strani. Ogledi so možni po dogovoru. Veselimo se vašega obiska. Vaša ekipa Markus Hirsch

Stanje: rabljeno, Leto izdelave: 2001, Swing diameter 290 mm Turning length 850 mm Max. turning diameter over bed 600 mm CNC control Siemens Type 840 D Spindle bore 103 mm Spindle speed 3000 rpm Driven tools 3000 rpm Rapid traverse – grinding spindle 25 m/min Total power requirement 65 kW Machine weight approx. 11 t Serial no. 1130.2011-30 Equipment: Main spindle / counter spindle 2 power chucks 2 tool turrets C-axis Ljdpfxsyqv Auo Ab Tori Enclosure Chip conveyor Coolant system 22 bar Offer price without tooling Optional accessories available: 106 tool holders for internal and external machining, 20 driven tools (including 10 angle tools) The technical data are manufacturer’s or operator’s specifications and therefore non-binding for us. We reserve the right to prior sale; only our terms and conditions apply. About us: Over 400 of our own machines in stock Over 15,000 m² warehouse area, crane capacity 70 t More than 10,000 accessory items for your workshop If you are looking to sell machines, production lines or your business, please contact us. For more offers, visit our website. Inspections are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Stanje: rabljeno, Leto izdelave: 2011, Offer: High-Precision and Versatile Punching/Nibbling Machine Boschert Compact 500 CNC Z (Year 2011) – Ideal for Flexible Sheet Metal Processing! We are offering a powerful and reliable punching/nibbling machine from the renowned manufacturer Boschert, featuring advanced equipment and exceptional precision. This machine is the ideal solution for a wide range of punching and nibbling tasks – from single pieces to large-scale production runs. Standout Features: • Manufacturer: Boschert • Model: Compact 500 500 x 1000 CNC Z • Year of manufacture: 2011 • Intuitive CNC Control: Multi-axis Ladob control with graphical user interface for easy programming and visualization of machining processes. • Extended working area for greater flexibility: o X-axis: 0 - 2000 mm (enables machining of long workpieces) o Y-axis: 0 - 750 mm (provides ample space for wide sheets) • Ultra-Fast Tool Change: Trumpf quick-change tool system for minimal downtime and maximum productivity. Lrodpfex Uxtfsx Ab Tsi • Universal Tool Compatibility: Fully compatible with the entire Trumpf tool range – reduce your tooling costs and expand your possibilities. • Secure and Precise Material Handling: o Collet clamping: Ensures a firm hold on the workpiece during processing. o Non-contact repositioning up to 9999 mm: High-precision repositioning device with 2 sheet hold-downs for efficient machining of extremely long sheets without position loss. • Outstanding Dynamics and Precision: o Maximum positioning speed: 60 m/min for rapid processing cycles. o Infinitely adjustable feeds: Optimal tuning of processing speed to both material and application. o Highest positioning accuracy: ± 0.05 mm for perfect results with every workpiece. • Robust and Durable Design: o Y-axis drive: Dual ballscrew-driven guide carriages on both the left and right side of the machine table provide maximum stability and torsional rigidity. o X-axis drive: Ballscrew and four linear recirculating ball carriage guides ensure precise and low-friction movement. • Special Equipment for Small Parts: Stop plate (L-plate) for secure machining of small parts that can no longer be safely held by the collets—maximum flexibility and minimal scrap. Condition: The machine is in very good, well-maintained condition and has been serviced regularly. It is immediately operational and provides excellent performance for your sheet metal processing needs.

Stanje: zelo dobro (rabljeno), Leto izdelave: 1996, Grinding length: 600 mm Grinding width: 0 mm Total power requirement: 7.5 kW OFFER Lredpfx Abox Haryo Tei We can offer you – subject to prior sale and errors excepted – the following, available from stock: GEIBEL & HOTZ CNC Horizontal Surface & Profile Grinding Machine Model: FS 6-Z CNC Year of manufacture: 1996 Maximum grinding length (table longitudinal travel 660 mm): 600 mm Maximum grinding width (cross travel max. 360 mm): 0 mm Maximum grinding height under wheel: approx. 375 mm Distance table – spindle centre min / max: 140 / 525 mm Standard magnetic chuck size: 600 x 0 mm Table clamping area: 820 x 0 mm Maximum table load: 400 kg Table speed: m/min Cross movement / table stroke: 3 - 40 mm Rapid cross/vertical feed: 5 m/min Grinding wheel dimensions: 300 x 50 x 76.2 mm Grinding spindle speeds, adjustable: 1,000 – 3,000 rpm Grinding spindle drive approx.: 7.5 kW Total drive approx.: 15 kW – 400 V – 50 Hz Weight approx.: 2,600 kg Accessories / Special equipment: • SIEMENS CNC Control type 840 D with comprehensive GEIBEL&HOTZ grinding software, user-friendly interface, text and graphic support, easy programming even for complex grinding wheel contours and fast linking of grinding operations • All standard grinding programs and cycles such as surface and multi-surface grinding with roughing – finishing – sparking out – return, plunge grinding, automatic dressing with compensation, etc. • Electronic handwheel for 3 axes • Table movement via toothed belt drive, allowing both very high and very low table speeds, ideal for profile grinding • Dressing device with swing diamond, mounted on left side of table, with automatic dressing cycle, compensation, and for profile dressing as well • Fixed dresser with interchangeable mounting, left side of table • Mounted sine table permanent electro-magnetic chuck approx. 600 x 200 mm, fine-pole • Wet grinding unit with separate band filter coolant filtration • Separate electrical cabinet, work lamp, various accessories, operating manuals Condition: Good to very good condition! Suitable for all grinding applications! Please click here for a video of the machine: Delivery: Ex stock, immediately available, FCA Metzingen Payment: Net – upon receipt of invoice Always a large selection of grinding machines in stock – please let us know your requirements!
