Krüsi Maschinenbau AG Krüsimatic G2

Krüsimatic G2 Joinery Center – Used, Fully Refurbished

Condition & Refurbishment
The machine has been completely overhauled by Krüsi Maschinenbau AG. It receives a new control system, regulators, servo motors, and wiring – including a 12-month warranty on mechanics and new components.

Technical Data
• Maximum timber passage: 200 x 320 mm
• Infeed length: 10,000 mm
• Outfeed length: 10,000 mm
• Supply voltage: 3 x 400 V / 50 Hz
• Protection: 3 x 63 A (site-provided)
• Pneumatic pressure: ≥ 8 bar
• Air consumption: 10–15 m³/h
• Machine control: IST Software / Abb3d
• Interface: BTL compatible

Processing Units
Gantry 1:
• 5-axis saw unit (angle-limited)
• 4-axis milling unit with 5-position spindle head (horizontal) + marker
• 4-axis notching unit with 2-position spindle head (vertical)
• Drilling unit with two horizontal tool holders
• Chain mortising unit
Gantry 2:
• Two chalet milling motors (vertical)
• Two chalet milling motors (horizontal)
• Two drilling units (horizontal)
• Grooving unit (horizontal & vertical)

Accessories
• Comprehensive tool package included
Codpswb Ev Hefx Agtjrh
• Two compressed air tanks for gantry weight compensation

The ideal opportunity for carpentry shops, timber construction companies, and joinery centers relying on reliability and precision – with a factory warranty.
