Stroj za robno lepljenje

BRANDT O KDN 200 Ambition 1200

Stanje: rabljeno, BRANDT highflex 1440 edge bander Well equipped, Pre-milling units Glue application Pneumatic pre-cut guillotine Pressure rollers Finishing saws Top and bottom milling unit 2 x corner rounding units Profile scraper Flat scraper Polishing unit The machine features NC-controlled milling units and a pneumatic package Maximum workpiece height: 60 mm Maximum edge thickness (in rolls): 3 mm Feed speed max: 14 m/min The machine is fully operational and can be inspected prior to purchase. Ledsv H D S Sopfx Abbohb

Stanje: rabljeno, Leto izdelave: 2016, TECHNICAL DATA AXES Max. Workpiece Dimensions X-Y-Z mm: 3050 x 800 x 50 Min. Workpiece Dimensions X-Y-Z mm: 300 x 90 x 10 Working Area Drilling/Grooving mm: 0 x 800 / 0 x 800 X-Axis Stroke mm: 750 Max. Traverse Speed X-Y Axes m/min: 25 DRILLING UNIT Vertical Spindles: - Number: 7 (4X-4Y, one shared) Horizontal Spindles (along Y-axis): Lhjdpfx Abjvvi I Rebjb - Number: 2 (1+1) Horizontal Spindle (along X-axis): - Number: 1 Fixed Grooving Saw (Direction): X Saw Blade Diameter mm: 100 Max. Saw Blade Thickness mm: 5 Motor Power kW (HP): 1.5 (2) Spindle Speed rpm: 3350 Saw Blade Speed rpm: 4300 INSTALLATION Power Supply V (Hz): 380 / 400 (50/60) Installed Power kVA: 4.5 Compressed Air Requirement bar: 6 Compressed Air Consumption Nl/cycle: 90 Extraction Requirement m³/h: 1200 Extraction Air Speed m/sec: 20 Extraction Port Diameter mm: 80+80 F10L Drilling Unit Includes: - 7 independent vertical spindles - Drill holder D10 mm - Distance between spindles: 32 mm - 2 horizontal drilling heads: 1 in X direction with one drill, 1 double drilling head in Y direction (1 + 1 drill holder D10 mm) - Speed: 3350 rpm - 1 integrated saw unit in X (max. diameter 100 mm) - Saw blade speed: 4300 rpm - Motor power: 1.5 kW - Vertical pneumatic stroke per spindle: 70 mm - Horizontal pneumatic stroke of drilling unit Workpiece Positioning and Drive of the Working Unit A CNC-controlled vacuum suction cup clamps and positions the workpiece sequentially under the working unit during machining. Movement along the X and Y axes is via THK rails with transmission on reinforced toothed belts. Movement in the Z axis is pneumatic on ball bushing guides, with stops adjustable via the end position. Positioning of the working units is via DC motor technology and drives. CNC CONTROL The control system is specifically designed for use in drilling and milling machines. - CN - 7" color display with touchscreen - Alphanumeric keypad - Self-diagnosis and any faults or errors displayed in the operator's language Programming - Programmed via CN - Automatic optimization of drilling operations - Option for plate zero-point shift - Option to save and import drilling programs via USB dongle - Option to import drilling programs from external CAD-CAM software Configuration - User interface in the same language as the operating manual - Graphic display of aggregate configuration Vacuum Suction Cup "B-Power" vacuum suction cup with dual vacuum connection, recommended for highly porous panels (e.g., MDF light). Machine Operating Interface Software: Xilog Maestro USB Hardware and Software Requirements: - Operating system: Windows XP Professional (SP2), Windows Vista or Windows 7 - Processor: Intel compatible, 2GHz min.; multicore processor recommended - Memory: 1GB min., 2GB recommended - Free disk space: 5GB - Graphics card: OpenGL compatible (The package includes a DVD for installation and a USB key) Xilog Maestro Features Programming - Parametric, graphical programming - Supported programming with graphical and syntax aids for drilling operations - Ability to create and save machining macros Integrated Additional Functions - Self-diagnosis and error reporting in the operator's language - User interface in

Stanje: rabljeno, Leto izdelave: 2008, premer struženja: 275 mm, izvrtina vretena: 80 mm, največja hitrost vretena: 4.000 obr/min, potovalna razdalja osi X: 260 mm, pomik po osi Z: 1.345 mm, skupna višina: 2.232 mm, skupna dolžina: 4.339 mm, skupna širina: 2.232 mm, skupna masa: 7.600 kg, Oprema: dokumentacija / priročnik, Mori Seiki NL 2500 SY / 1250 CNC stružnica z Y-osjo, gnanimi orodji in drugo glavno vreteno CNC krmilje MSX-850-III (Mitsubishi 720 BM) Premer struženja 275 / 366 mm Premer izvrtine vretena 80 mm Lhsdpexnmzhsfx Abbsb Hitrost vrtenja vretena 4000 min⁻¹ Glavni vretenski motor 18,5/15 kW Pomik X-osi 260 mm Pomik Y-osi +50 / -50 mm Pomik Z-osi: 1345 mm Pomik W-osi (protiprimež od glavnega vretena) 1275 mm Min. indeksiranje C-osi glavnega vretena 0,001° Število orodij v revolverju 12x Število gnanih orodij 12x Orodni konus BMT Podajalnik palic LNS Quick Load Servo III Vreteno gnana orodja 6000 min⁻¹ Za vsa vprašanja o stroju ali za dogovor o ogledu nas prosimo kontaktirajte po telefonu ali elektronski pošti. Vabimo vas, da si ogledate tudi naše druge oglase in pridobite celovit pregled nad našo zalogo.

Stanje: rabljeno, Working width: 1350 mm Number of sanding units: 2 pcs. Maximum workpiece thickness: 160 mm Sanding belt dimensions: 1370 x 2150 mm Feed motor: 0.75 HP Unitek Excel LC 1370 2N RKRT MODEL: Excel 2NRKRT 2-BELT MACHINE 1ST BELT: ROLLER 2ND BELT: COMBINATION UNIT (ROLLER/PAD) SUITABLE FOR SOLID WOOD, VENEER, AND INTERMEDIATE COATING SANDING - Usable WORKING WIDTH: 1350 mm - SANDING BELT LENGTH: 1370 x 2150 mm - MAX. WORKPIECE THICKNESS: 160 mm - STEEL CALIBRATING ROLLER: 180 mm - Rubber-coated SANDING ROLLER: 180 mm Lhodpfxsrmucxs Abbob - SANDING PAD WIDTH: 50 mm - BELT MOTOR POWER: 14.7 kW - BELT SPEED: 18/16 m/s - FEED MOTOR POWER: 0.75 HP - Continuously adjustable feed conveyor with variable speed: 4–20 m/min - HEIGHT ADJUSTMENT MOTOR: 0.33 HP - Mechanical BELT OSCILLATION: ECO GEAR PATENT SYSTEM - 1 PC. DRUM BRAKE for belt stop - Swiveling ROLLER for belt tensioning - 3 pcs. PRESSURE ROLLERS with rubber coating - EMERGENCY STOP STRIP at the infeed - ELECTRONIC DISPLAY for workpiece thickness - 2 pcs. ROLLER CONVEYORS, each with 2 rollers at infeed and outfeed - AUTOMATIC CENTRING OF FEED CONVEYOR - 1 EXTRACTION CONNECTION, 160 mm diameter - AUTOMATIC TABLE POSITIONING IMPORTANT: New patented belt oscillation system 1. No valves 2. No photo sensors 3. Not sensitive to dust 4. Energy-saving and environmentally friendly system Since 2008, the machine model with this system has operated continuously without lateral belt tracking issues! - Unitek steel calibrating roller (same for all models) - Unitek flexible pressure shoe before and after the roller (same for all machines with 1 roller) - Unitek grit compensation with mechanical grid-set, 6 positions (per pc., same for all models) - Unitek electronic segmented sanding pad with 24 segments (sanding width: 1350 mm) - Unitek belt motor upgrade to 18.4 kW instead of 14.7 kW (per motor) - Unitek surcharge for 2nd motor: 14.7 kW (for Excel 2-belt only) - Unitek automatic table lowering in case of emergency stop (same for all models) - Unitek surcharge for frequency-controlled feed speed - Unitek surcharge for infeed or outfeed conveyor with 4 rollers (same for all models) - Price per roller conveyor - Unitek electronic control of machine functions with 12'' touchscreen (same for all models) Automatic workpiece sensing with feed motor control ----- Machine price for the above configuration on request! ----- Optional items at extra cost: Surcharge for 3-belt machine (roller-roller-pad, Mod. 049): EUR 8,390.00 Freight cost: EUR 1,300.00 Installation and user training: EUR 1,300.00 ----- All prices are net plus 19% statutory VAT. ----- (Technical data according to manufacturer's information – no liability assumed!)

Stanje: kot nova (razstavni stroj), Leto izdelave: 2025, Spindle tiltable: No Height adjustment: Handwheel Tilting adjustment: - Milling jaw adjustment: manual Lhedpfx Aogzlpkebbob Height display: mechanical counter Tilt angle display: - Milling fence display: mechanical counter Milling spindle diameter: 30 mm Speeds: 3000, 4500, 6000, 7000, 10000 Motor power: 7 kW Motor brake: Yes, automatic Extraction connection: 2 x 120mm Machine length: 2599mm Machine depth: 900mm Weight: 655kg

Stanje: novo, Leto izdelave: 2024, Funkcionalnost: popolnoma funkcionalen, hitrost pomika os X: 9 m/min, višina obdelovanca (maks.): 50 mm, največja debelina roba: 5 mm, trajanje garancije: 12 meseci, HOLZ-HER robni lepilni stroj ARTEA 1020 Stroj na zalogi – možna vmesna prodaja Leto izdelave 2024 - Osnovni stroj 1020 - Upravljanje Edge Control BC15, vklj. Vi.Se. (Visual Setting) - LED osvetlitev stroja - Pripravljalna rezkalna enota - GluJet za PUR / EVA vključno z rezervoarjem - Rezkanje - Profilni strgalnik - Površinski strgalnik - Polirna enota Lsdpfxjxpgv Uj Abbohb

Stanje: dober (rabljeno), Tračna žaga linija za velike hlode 1. Transporter za hlode 2. Vmesna skladiščna miza za hlode s podajalnikom za posamezne kose 3. Transporter za hlode z usmerjanjem in centriranjem, vključno z obračalnikom 4. Söderhamn AKE 245A dvostranska reducirna tračna žaga (ARI z 6-rezilnimi glavami) Lhsdpfjikvlisx Abbeb 5. Odbiralnik desk z obračalnikom blokov 6. Bočni prenos blokov 7. Dovod blokov 8. ARI BKR-600 9. ARI DS-75 večlistna žaga 10. Obrezovalna linija z ARI KT-52 obrezovalno žago Cena: 2.100.000 SEK, v obstoječem stanju na lokaciji. Linija je popolna, vendar niso vsi transporterji v pritličju. Vključen je sekalnik Bruks 1503M. Električne omare niso pod napetostjo (ni PLC programske opreme). Demontažo in nakladanje lahko izvede UJ Trading AB. Žaga se nahaja na Švedskem.

Leto izdelave: 2022, Stanje: novo, Altendorf WA 6 Manual height adjustment, Double roller carriage, length 2000 mm Scoring unit, tiltable, Extension table, Mitre fence, automatic brake, can be lowered below table height ----- Technical data ----- Tilting range: 0 - 45°, Lhedpfx Abjihahmjbsb Cutting width at rip fence: 1,000 mm, Maximum cutting height: 87 mm, Maximum saw blade diameter: 315 mm, Mitre fence tilting range: up to 49°, Speeds: 4,200 rpm, Main motor power: 5.5 HP / 4 kW, Scoring motor power: 0.5 HP / 0.37 kW, Working table height: 910 mm, Extraction port diameter: each 1 x 100 / 50 mm, Weight: 450 kg Large extraction hood Location: Available from stock 54634 Bitburg - immediately available - Location: Available from stock 54634 Bitburg - free loaded - - immediately available -

Stanje: rabljeno, Leto izdelave: 1985, Edge thickness: 0.4 - 12 mm Workpiece thickness: 10 - 55 mm Minimum workpiece length: 160 mm Minimum workpiece width: 65 mm Feed rate: 13 m/min Pneumatic connection: 7 bar Total length: 5220 mm Weight: 1950 kg Heated pot with Quickmelt – hot-melt adhesive granulate Glue roller rotation for both synchronous and counter rotation Edge magazine for PVC rolls and strip edges Motorized upper pressure adjustment Pneumatically actuated pressure rollers Swiveling control panel at machine infeed All processing units are position-controlled — meaning all workpiece-actuated limit switches are omitted End trimming Milling combination for chamfer/radius milling with 2 swiveling units (1 unit with combination cutter for radius/straight, 2nd unit with chamfer cutter), with pneumatic adjustment Lhsdpfx Aec Tmygebbob Scraper with pneumatic adjustment Buffing Central lubrication for chain conveyor Quick-change glue container Digital counters Electronic frequency converter with integrated motor brake Edge monitoring with fault display Infrared heater CE compliant Note on used machines: • Technical data and intermediate sale subject to change without notice. • Quoted prices are ex-works and include loading. • Machines have been cleaned and function-tested. • All machines are sold as inspected, without any guarantee or warranty. Buyers are welcome to inspect machines at the site. • Special agreements are only valid in written form. (Inquiries will only be answered if you provide your address and telephone number!)

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 1974, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 74-4-10, Panel Saw ALTENDORF F90, Year of Manufacture 1974 Machine No.: 74-4-10 Manufacturer: Altendorf, Germany Lhjdpfxsipvrbj Abbob Saw stroke (mm): 2600 Cutting width (mm): 1,300 Max. cutting height (mm): 130 Max. saw blade diameter: 400 mm Main motor: 5.5 kW With scorer unit 4 speed settings Saw blade height adjustment: manual Approx. weight (kg): 780 Technical specifications subject to change
