Rezkalni stroji - vertikalni nakup rabljenega (66)

Stanje: rabljeno, Technical Details: X travel: 880 mm y travel: 300 mm z travel: 900 mm W axis: 60 mm Ljdpou Ndfhjfx Acwert Spindle head swivels left and right: 60° Table clamping surface: 880 x 300 mm Machine weight approx.: 1200 kg Machine dimensions approx. LxWxH: 1.3 x 1.4 x 1.9 m including accessories

Stanje: novo, Leto izdelave: 2025, dolžina mize: 900 mm, širina mize: 450 mm, število vreten: 1, hitrost vretena (min.): 8.000 obr/min, obremenitev mize: 500 kg, VMC 650 CNC obdelovalni center, rezkalni stroj s CNC krmilnim sistemom Obdelovalni center VMC 650 je večnamenska oprema, ki omogoča izvajanje rezkanja, vrtanja, narezovanja navojev in struženja v avtomatskem načinu (če so te možnosti na voljo pri stroju). Rezkalni stroj VMC 650 je lahko opremljen z orodnim magazinom s 16 ali 24 postajami. Glede na želje kupca je lahko rezkalni stroj opremljen s CNC sistemom GSK, Siemens ali Fanuc. Opcijsko je možna tudi nadgradnja z Y-osnim pogonom. Kot zelo uporabno dodatno opremo priporočamo vgradnjo tračnega transporterja za odrezke (chip conveyor), ki vam bo prihranil čas pri delu s strojem. Tehnični podatki: Velikost delovne mize: 900 x 450 mm Največja teža obdelovanca: 500 kg Pomiki po oseh X/Y/Z: 800/450/500 mm Lredpfsxc I Dgsx Acwot Maksimalna razdalja med vretenom in površino mize: 120–620 mm Moč motorja: 5,5–7,5 kW Maksimalno število vrtljajev vretena: 8000 min⁻¹ Tip vretena: BT40 Natančnost pozicioniranja: ±0,008/300 mm Ponovljivost: ±0,005 mm Dimenzije stroja: 3000 x 2275 x 2550 mm Teža stroja: 4000 kg Po naročilu je možna tudi dobava CNC rezkalnih strojev oziroma obdelovalnih centrov z drugimi velikostmi miz: VMC 850 – miza 1000 x 500 mm VMC 855 – miza 1000 x 550 mm VMC 1060 – miza 1200 x 600 mm VMC 1160 – miza 1200 x 600 mm VMC 1275 – miza 1300 x 700 mm VMC 1370 – miza 1400 x 700 mm VMC 1580 – miza 1600 x 800 mm VMC 1680 – miza 1700 x 800 mm VMC 1890 – miza 2000 x 900 mm

Stanje: rabljeno, Leto izdelave: 1995, x-travel: 600 mm y-travel: 350 mm z-travel: 140 mm Table clamping surface: 700 x 300 mm Spindle taper: ISO 40 Spindle speeds: 100 - 4000 rpm Distance spindle center to column: 395 mm Distance spindle nose to table: min. 170 - max. 550 mm Control system: TNC 407 Milling feed rates: 3 + 2000 mm/min Rapid traverse: 5000 mm/min Spindle motor: 5.5 kW Total power requirement: 9 kW Machine weight: approx. 1.9 t Space requirements: approx. 2.5 x 1.8 x 2.2 m Ljdpfxstv Idxe Acwert Heidenhain control: TNC 407,

Stanje: dober (rabljeno), številka stroja/vozila: 630, z vrtljivo (za-stran premakljivo) vertikalno glavo Velikost mize 300 x 1.430 mm Pomiki mize: vzdolž (X-os) 1.000 mm navpično (Z-os) 520 mm prečno (Y-os) 360 mm Vgradna višina pod rezkalnim vretenom cca 500 mm Izteg rezkalnega vretena min./max. 350 mm Vpenjalo vretena SK 40 Obrati vretena 25 - 1.200 min⁻¹ Pomik/hitri pomik 12–900 mm/min Lrodebq Rugjpfx Acwst Pogon vretena ca. 3 kW Skupni pogon 3,4 kW – 380 V – 50 Hz Teža 2.400 kg

Stanje: novo, Leto izdelave: 2024, Machining Centre VMC-1160-D Technical Specifications Type: Belt-driven BT40-8000 rpm Control Unit: FANUC 0i MF(5) Travels: - Max. X-axis travel: 1100 mm - Max. Y-axis travel: 610 mm - Max. Z-axis travel: 610 mm - Spindle nose to table distance: 150–760 mm Spindle: - Drive type: Belt drive - Spindle speed: 40-8000 rpm - Spindle taper: BT40 - Power: 11/18.5 kW - Torque: 52.5/118 Nm Work Table: - Size: 1200×600 mm - T-slots (size x number x pitch): 18x5x100 mm - Max. table load: 1000 kg Accuracy: - Positioning accuracy: 0.008 mm - Repeatability: 0.005 mm Tool Magazine: - Type: Drum-type - Max. tool dimensions (adjacent/adjacent empty/length): Φ78/Φ150/300 mm - Max. tool weight: 8 kg Other: - Air supply requirement: 0.65 Mpa - Power requirement: 25 kVA - Machine weight: 7000 kg - Dimensions (L x W x H): 2900x2800x3200 mm Transport We offer free loading of purchased machines and assistance with transport arrangements. Technical Consultation Our technicians support you in selecting the right machine and suitable accessories, based on technical drawings of the parts to be manufactured. The following services are included in the machine price: A 3-day training and machine installation: - Day 1, up to 8 hours: Installation and control unit training - Day 2, up to 8 hours: Independent operation of the machine under our technician’s supervision – enabling programming of specific details by the customer - Day 3, up to 8 hours: an additional training day to be used within 12 months if any operational questions arise Lrodpfx Acjvhck Newet Consultation by our specialists: - By phone: 7:30 am to 9:00 pm (Mon-Sat) – 8-hour package, valid for one year - Online: 7:30 am to 2:30 pm (Mon-Fri) – 8-hour package, to be used within 12 months Access to Otinus Academy courses - LibreCAD – 12 months’ access You also receive: - CAD drawing package Terms of cooperation - 12-month warranty period - The machine is brand new - Warranty and post-warranty service provided by the seller - The customer is responsible for the machine once it is unloaded and moved on their premises.

Leto izdelave: 1972, stanje: zelo dobro (rabljeno), številka stroja/vozila: 2995, Table clamping surface: 300 x 1100 mm Travel X-axis: 780 mm Ljdpfxeh I Du Uj Acwort Travel Y-axis: 250 mm Travel Z-axis: 410 mm Spindle taper: SK 40 Quill stroke: 100 mm Spindle speeds: 31.5 - 1400 rpm Feeds longitudinal and cross: 12.5 - 630 mm/min Feeds vertical: 6.3 - 315 mm/min Electrical connection: 380 V, 5.5 kW Required space: 1770 x 1500 x 2050 mm Weight: approx. 2200 kg

Stanje: novo, At variable speed, ISO 40. Powered cross table on all axes. 3-axis digital readout included. Base with chip tray. Coolant system. LED lamp. Mechanical speed indicator. Motorized axes with variable speed and rapid traverse. Manual pump guideway lubrication system. Milling capacity with insert cutter: 100 mm. Milling capacity: 35 mm. Ledpfx Aoh Im H Sscwjrt Drilling capacity in cast iron with pilot hole: 60 mm. Max drilling capacity in steel with pilot hole (S235JR): 24 mm. Spindle taper: ISO 40 DIN 2080. Quill: 86 mm. Spindle travel: 120 mm. Head tilt: +/- 45°. Vertical head rotation: +/- 90°. Head body rotation: +/- 180°. Vertical spindle speed: (2) 60 ÷ 500 | 500 ÷ 3600 rpm. Motor: 400 V 50 Hz 2.25 kW. Distance between spindle nose and table: 45 – 395 mm. Distance spindle axis – column: 215–450 mm. Table size: 1246 x 230 mm. Longitudinal table travel: 850 mm. Cross table travel: 310 mm. Max load capacity: 400 kg. Dimensions: 1680 x 1500 x 2100 h mm. Net weight: 1000 kg.

Stanje: rabljeno, Leto izdelave: 1976, Technical Details: Table surface: 1300 x 190 mm Speed range: 60 - 4000 rpm, infinitely variable Feed, infinitely variable quill: 0.06 / 0.12 / 0.24 mm/rev Vertical quill travel: 140 mm Spindle taper: SK 40 Spindle head swivels left and right: 90° and 45° Total power requirement: 3.0 kW Machine weight approx.: 1620 kg Machine dimensions LxWxH: 2.7 x 2.3 x 2.4 m Milling machine with universal milling head Spindle rotation right/left Lodpfxsu Sq Ems Acwort Table specifications: X/Y/Z travel: 860/380/460 mm Feed X/Y/Z: 40 - 400 mm/min, stepless Rapid traverse: 400 mm/min Max. workpiece weight: 30 kg Equipment: 3-axis digital readout Mitutoyo with extension arm Machine lighting Coolant tank with pump Adjustable feed on X and Y axes Including accessories as shown in the picture

Stanje: delavnici obnovljeno (rabljeno), Leto izdelave: 1997, Funkcionalnost: popolnoma funkcionalen, Obdelovalni stroj je bil podvržen generalnemu remontu, ki je zajemal popravilo mehanskega in električnega dela ter nastavitve geometrije v skladu s tehničnimi pogoji prevzema (WOT) in standardom EN. Stroj je prilagojen minimalnim zahtevam glede varnosti in zdravja pri delu. Osnovni tehnični podatki: - delovna površina mize: 400x1600 mm - vretenasta konusna glava: ISO 50 - vzdolžni pomik: ročno/mehansko 1150/1120 mm - prečni pomik: ročno/mehansko 370/345 mm - vertikalni pomik: ročno/mehansko 430/400 mm - največji kot vrtenja navpične glave: +/- 45 stopinj - obseg hitrosti vretena: najmanj 28 vrt/min, največ 1400 vrt/min - glavni motor: 11 kW Rezkalni stroj ima mehansko vpenjalo orodij, ki omogoča samodejno vpenjanje orodij v stroj. Stroj je opremljen s centralnim sistemom za mazanje in optičnimi linijami (merilnimi lističi) za digitalno odčitavanje položaja v treh oseh. Lrjdpfxjurvl Ro Acwot Stroj je pripravljen za ogled v osrednji Poljski.

Stanje: rabljeno, Tehnične podrobnosti: Pomik v smeri X: 762 mm Pomik v smeri Y: 382 mm Pomik v smeri Z: 419 mm Vpenjalo orodja: SK 40 Površina mize: 1070 x 230 mm Hitrostno območje: 60 - 4.200 min⁻¹ Neprekinjeno nastavljiv pomik: 0,038/0,073/0,120 v 3 stopnjah mm/min Hod vretena: 120 mm Vpenjanje vretena: ISO 40 Lodpfxova Evfe Acwort Vretenasta glava, vrtljiva levo in desno: 90° Približna masa stroja: 1600 kg Mere stroja D x Š x V: 1,8 x 1,5 x 2,15 m Stroj se trenutno nahaja v tehničnem oddelku.

Stanje: rabljeno, Leto izdelave: 1989, Technical details: X-axis travel: 300 mm Y-axis travel: 300 mm Z-axis travel: 400 mm Control system: Contour 3 path control Spindle taper ISO: SK 40 Spindle head swivels left and right: 90° Quill travel: 60 mm Speed range: 40 - 4000 rpm / 21 steps Feed rate: 2 - 3600 mm/min Rapid traverse speed: 4000 mm/min Table size: 620 x 390 mm Clamping table: angle table (mm) Table load capacity: 0.45 t Total power requirement: 12.5 kVA Machine weight approx.: 1400 kg Machine dimensions approx. (LxWxH): 1.5 x 2.1 x 2.0 m Control cabinet dimensions: 1.8 x 0.8 x 1.1 m Equipment: - Operation via Grundig electronic operator panel with pendant arm Lsdpfju Nc Twjx Acwert - Coolant system with pump - Handheld control unit with handwheel - Machine lighting The machine can be demonstrated under power. i.D.

Stanje: rabljeno, Leto izdelave: 1991, Tehnične podrobnosti: x-hod: 1050 mm y-hod: 600 mm z-hod: 650 mm Razpon obratov: 40 - 1720 / 12 stopenj U/min Vpenjalo vretena: SK 50 Glava vretena nagibna levo in desno: 90° desno/levo in 45° = 360° Razdalja od čela vretena do mize: 0 - 600 mm Površina mize: 1700 x 470 mm Podajalnik brezstopenjski: X/Y = 15 - 625 + Z = 7,5 - 312 mm Hitri pomik Z-os: 1250 mm/min. Hitri pomik X/Y: 2500 mm/min. Skupna priključna moč: 11,1 kW Teža stroja približno: 2500 kg Dimenzije stroja D x Š x V: pribl. 2,45 x 2,0 x 2,85 m Oprema: Avtomatika preko krmiljenja z ekscentričnimi odmiki Centralno mazanje z univerzalno rezkalno glavo Huron Sistem za hlajenje Upravljalna plošča Nastavljive noge stroja Ljdpfx Aova Hd Rjcwert Dodatna oprema: Strojni primež (širina čeljusti 120 mm)

Stanje: novo, Hans Schreiner drilling and milling machine with 90° swiveling gearbox head and stepless speed adjustment, designed for commercial use. Equipped with halogen lamp and coolant system. Delivered without oil filling! Technical data: Spindle taper: MT 4 Motor output (S1): 1.5 kW, 400 V Weight: 310 kg Table dimensions: 800 x 240 mm Max. clamping height: 400 mm Speeds: 100–530 and 530–2600 rpm Max. drilling capacity (steel): 45 mm Table travel: X = 500 mm, Y = 175 mm Optional special equipment: Drill chuck, keyless drill chuck, milling cutters and tools Ledpevrv Ngsfx Acwsrt Base frame with coolant tray

Stanje: novo, Hans Schreiner Drilling and Milling Machine with 90° Swiveling Gear Head for Industrial Applications. Price without stand! Includes halogen lamp and coolant system Without oil filling! Technical Specifications: Spindle taper: MT 4 Motor output S1: 1.5 kW, 400 V Weight: 310 kg Lsdpovrv I Njfx Acwjrt Table dimensions: 800 x 240 mm Max. clamping height: 680 mm Speeds: 6, from 80 to 1575 rpm (80/150/260/450/900/1575 rpm) Max. drilling capacity in steel: 40 mm Table travel: X = 585 mm, Y = 205 mm Optional special equipment: Drill chuck, keyless drill chuck, cutters and tools 2-speed motor Stand with coolant tray

Stanje: novo, Hans Schreiner drilling and milling machine for industrial applications. With automatic quill feed and drill chuck. No oil filling! Lodpjvrv I Asfx Acwjrt Technical specifications: Spindle taper: MT 4 Motor output (S1): 1.1 kW, 400 V Table dimensions: 730 x 210 mm Max. clamping height: 700 mm Speeds: 12, from 80 to 2500 rpm Table travel: 500 x 205 mm Weight: 470 kg

Stanje: rabljeno, Leto izdelave: 1995, Technical Details: X-axis travel: 500 mm Y-axis travel: 200 mm Z-axis travel: 300 mm Spindle mount ISO: SK 40 Swiveling spindle head left and right: 45° each Speed range: 45...2000 rpm Spindle head: Table to spindle center distance: max. 300 mm Spindle nose to table distance: max. 300 mm Feed: 16...800 mm/min in 18 steps Clamping surface of table: 1000 x 165 mm Table swiveling to both sides: yes (degrees) Control voltage: 380 V Total power requirement: 4.6 kW Machine weight approx.: 1,540 kg Machine dimensions approx. LxWxH: 1.5 x 1.5 x 1.6 m Lredpou Ndfusfx Acwjt The milling beam is adjustable by 580 mm. Outreach min./max.: 250/800 mm
