Lakirna oprema / pršilna stena, pršilne naprave

Wagner Wildcat / Finish 104 B Ex

Stanje: novo, Leto izdelave: 2024, SEMI-AUTOMATIC DRILLING SYSTEM “UNIBOHRFIX 50” With the UniBohrFix 50 drilling system, all types of profiles can be processed either against a stop or using the gripper. Drilling is carried out manually via a lever, while materials are automatically positioned to the next drilling point along the X-axis. You can easily process entire programs or use the stop plate for fast single-hole drilling. The system is suitable for workpieces up to 100 kg. The system also includes a minimum-quantity spray unit with holder and spray can. Technical data for the standard version can be found in the table. On request, all components of the system can be customized to your requirements. You can choose from different drilling machines, roller conveyors, positioning systems, and clamping vices. Plantec configures the system to perfectly meet your needs! BENEFITS - A series of holes is drilled automatically at precise intervals. - Operator errors are drastically reduced. - Programming is completed within minutes. - Excellent price-performance ratio. - Considerable reduction in manpower requirements. Kdjdpfsgwt Sljx Adiew Standard measurement lengths: 3,000 mm 6,000 mm Drilling machine: Unimax 2 T Spindle: MK2 Continuous drilling capacity: 18 mm Speed ranges: 100-2000 rpm, 200-4000 rpm Throat depth: 225 mm Spindle-table distance: 60-400 mm Adjustable clamping vice with digital linear readout Positioning length stop: PD-100e Control system for automatic positioning Positioning: Absolute or incremental (chain dimension) Easy-to-read LED display Carriage with DC servomotor Positioning accuracy: +/- 0.1 mm/m Stop arm with spring damping Stop plate with groove Memory control with 3,000 storage places Roller conveyors: RD-200/3 Load capacity: 200 kg/m Roller width: 290 mm Roller diameter: 40 / 50 mm Insert plates Bracing for stability Control cabinet Available options: - Minimum-quantity spray system with spray head and holder - Gripper for clamping material to the stop plate

Stanje: dober (rabljeno), Leto izdelave: 2004, skupna masa: 40.000 kg, stiskalna sila: 450 t, AXIAL 4100x450tn + Cybelec ModEva 10 + 5 axes (Y1, Y2, X, R, Z) + WILA CNC crowning table + WILA hydraulic punch and die clamping Bending length: 4,100 mm Press force: 450 tonnes Stroke: 365 mm Axes: 5 axes (Y1, Y2, X, R, Z) *Z axis (stops with double prismatic guide) Kdodpfx Aou Au U Tjdisw WILA hydraulic punch and die clamping WILA CNC crowning table Press brake speeds: Approach speed: 110 mm/sec Working speed: 8 mm/sec Return speed: 90 mm/sec Distance between uprights: 3,600 mm Throat depth: 410 mm Open height (between table and ram): 500 mm Pit depth: 975 mm CNC: Cybelec ModEva 10 (Control CPU replaced in September 2023) Safety Laser: DSP LASER - TX Weight: 40 tonnes Motor power: 30 kW

Leto izdelave: 2004, Stanje: rabljeno, številka stroja/vozila: 0201-220031, FICEP DZ 603 Drilling Line for Structural Steel Profiles The Ficep DZ 603 is a three-axis drilling line designed for processing structural profiles. This 3-axis drilling system is purpose-built for machining beams in steel construction. Steel profiles can be automatically drilled and center-punched on three axes (flange and web). CNC control by Mitrol featuring Arianna software enables programming of the drilling line. CAD data in DSTV or DXF format is converted by the CNC control into NC data, and the machine executes the machining program, positioning the axes as specified. A gripper measuring carriage positions the profile at the correct drilling location within the drilling unit. A 5-position automatic tool changer ensures rapid drill bit changes on each drilling axis. Robust rollers at both infeed and outfeed guarantee smooth transportation of the steel profiles. Technical Specifications Ficep DZ 603 Drilling Line: - Maximum profile height: 610 mm - Maximum flange width: 450 mm - Maximum processing length: 11,300 mm - CNC control: Mitrol ARIANNA - 3 drilling spindles suitable for HSS coolant channel drills Kdjdpjrr Tauefx Adiow - Spindle speed: 180 to 1000 RPM - Drilling diameter: min. ø 8 mm – max. ø 40 mm - Power of each drilling spindle: 7.5 kW The DZ603 drilling line is sold without a marking unit.

Stanje: novo, Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, pritisk: 6 letvica, trajanje garancije: 60 meseci, notranja širina: 5.000 mm, notranja dolžina: 10.000 mm, notranja višina: 5.000 mm, filtrirna površina: 250 m², volumenski pretok: 16 m³/h, Oprema: dokumentacija / priročnik, osvetlitev, Blast house *up to 5 years warranty* for all blasting media, constructed from a steel frame/insulated panels, with filtration system, recirculating air system, abrasive recycling, 200l pressure blasting pot with automatic refilling, blast hose with dead-man control, breathing air system, LED lighting, wall cladding with 70 shore 4mm fabric-reinforced rubber, sweeping pit with bucket elevator. Abrasive return via sweeping pit with bucket elevator, optionally upgradable to cross screw conveyor with metering hood spanning the full width as a sweeping pit or as a complete flat conveyor floor. Workpiece transport upgradeable: blast trolley with rail track, crane system, roof crane opening, etc. For glass bead blasting of stainless steel, upgradeable with appropriate magnetic drawer or electrically driven magnetic drum separator. Kdsdeu Ey Dlopfx Adiow For blasting with two different blasting media (ferrous and mineral), upgradeable with magnetic drum separator, final demagnetization stage, and second air sifter for media separation and cleaning. Safety features: emergency lighting with battery backup, emergency stop switches inside the cabin and outside, inspection window to blast chamber, gate/door end switches, dead-man control, pressure vessel quick venting. Warranty up to 5 years on selected components. 50 years of experience and more than 3,000 systems built in blast room engineering.

Stanje: novo, Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: SAPI Jumbo, pritisk: 12 letvica, skupna širina: 3.087 mm, skupna višina: 2.078 mm, skupna dolžina: 3.692 mm, skupna masa: 3.000 kg, notranja širina: 2.340 mm, notranja dolžina: 3.520 mm, notranja višina: 2.500 mm, teža obdelovanca (maks.): 500 kg, filtrirna površina: 20 m², Oprema: osvetlitev, Učinkovita in pripravljena JUMBO peskalna kabina Ta JUMBO peskalna kabina, popolnoma sestavljena in prehoden model, ponuja celovito rešitev za učinkovito peskanje. Opremljena z dvema LED svetilkama, zagotavlja optimalno osvetlitev delovnega območja. Dvokrilna vrata omogočajo enostaven dostop in rokovanje z večjimi obdelovanci, medtem ko zaščitna gumijasta obloga v notranjosti preprečuje obrabo in podaljšuje življenjsko dobo kabine. Za filtracijo zraka in zmanjšanje prahu je kabina opremljena z visokozmogljivim kartušnim filtrom in udarno ločevalno enoto, kar zagotavlja čisto delovno okolje. Ploski transportni sistem v tleh, pokrit z rešetko, omogoča samodejno vračanje abraziva, medtem ko električni pogonski sistem zagotavlja nemoteno delovanje. Poleg tega je kabina opremljena z dvigalom z vedri in visokozmogljivim sistemom za reciklažo abraziva, ki omogoča učinkovito obdelavo in ponovno uporabo peskalnega materiala. 38-litrski tlačni peskalni kotel zagotavlja zadostno kapaciteto za daljše delovne cikle. V kompletu so tudi 10-metrska peskalna cev in trpežna šoba iz borovega karbida, ki zagotavlja optimalne rezultate peskanja. Idealna rešitev za profesionalno peskanje Ta peskalna kabina je popolna rešitev za podjetja, ki potrebujejo zanesljiv in učinkovit sistem za peskalne operacije. ✔ Možne dodatne opcije, kot so nakladalni vozički, na zahtevo. Kjdpeukdfpefx Adiodw ✔ Dovod stisnjenega zraka, električne energije in montaža morajo biti zagotovljeni na lokaciji. Če ste zainteresirani ali imate vprašanja, nas kontaktirajte kadarkoli!

Stanje: novo, DESCRIPTION DM100 Z2C - Performs edge rounding and removes sharp burrs on both the inner and outer edges of steel, stainless steel, or aluminum parts after laser, shear, or punch separation of metal parts, from sizes of 50 x 50 mm up to 1100 x 100 mm. The first station processes the products with a contact roller (approx. 55° Shore) using an abrasive belt, removing heavy burrs in the initial step. The second station processes the products with two pairs of counter-rotating cross belts—from above and below. The cross belts round both the inner and outer edges of the parts to be processed. A major advantage is the deburring of products with protective surface film, as only the edges are processed without damaging the film. Technical Data – DM1100 Z2C: Working capacity (Ø mm): 1100 x 100 Number of belt stations (Z): 1 Kdjdpfod Ixadox Adiew Number of cross-belt stations: 2 Abrasive belt dimensions (mm): 1100 x 2200 Abrasive belt speed (m/s): 8–22 Cross belt speed (m/s): 2–8 Feed speed (m/s): 0.6–3.2 Abrasive belt motor per head (kW): 18.5 Cross belt motor (kW) (2x): 3 Feed motor (kW) (3x): 0.18 Total power (kW): 33 Power consumption (A): 62 Extraction connection per head (Ø mm): 150 + 185 Dimensions (mm): 3600 x 2330 x 2350 Weight (kg): 5000

Leto izdelave: 2009, Stanje: dober (rabljeno), Platen magazijn - SHEET METAL STORAGE SYSTEM - geautomatiseerde opslagssystemen voor plaatmateriaal Systeemtype: ..... STOPA TOWER Mono SF Bouwjaar: ..... 2009 Staalconstructie rek – Steel structure: ..... Enkelvoudige toren – Single tower Aantal opslagplaatsen – Number of pallet locations: ..... 18 stuks / 18 pieces Max. beladingshoogte per pallet – Material stack height: ..... 90 mm Max. draagvermogen per cassette – Load per cassette: ..... 5000 kg Cassette-afmeting – Cassette size: ..... 6000 x 2000 mm Totale bouwhoogte – Total height: ..... 5590 mm Totale lengte – Total length: ..... 7640 mm Maximale breedte opslagsysteem – Total width storage system: ..... 5700 mm Systeemcomponenten – Components: Regalbediengerät (RBG) – Picker crane: Hefsnelheid: ..... max. 12 m/min Duw-/treksnelheid: ..... max. 6 m/min Elektrische aansluiting / vermogen – Electrics/ power: Spanning / frequentie – Voltage / frequency: ..... 400 V / 50Hz Stuurspanning – Control voltage: ..... 24 V Ksdpforyvmdex Adiodw Stroom – Current: ..... 44 Ampère Actief vermogen – Active power: ..... 24 kW Schijnbaar vermogen – Apparent power: ..... 30 kVA Systeem is professioneel gedemonteerd door Duitse monteurs, op voorraad en direct gereed voor transport.

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2013, Funkcionalnost: popolnoma funkcionalen, skupna višina: 7.385 mm, skupna širina: 1.471 mm, skupna dolžina: 3.275 mm, 8 Kardex Megamat RS 350 vertical carousels in excellent condition. Ksdsv Svmrjpfx Adiodw The system comprises 8 units manufactured between 2013 and 2018. Available in three height options: 7,185 mm, 7,384 mm, and 7,585 mm. Each vertical carousel is equipped with 34, 35, or 36 trays. For further details or enquiries, please do not hesitate to contact us.

Leto izdelave: 2025, Stanje: novo, Vzdrževanju prijazna naprava za odstranjevanje prahu, posebej razvita za agresiven peskalni prah z predkomoro in udarnim ločevalnikom, popolnoma sestavljena iz: a) 1 kos kartušnega suhega filtra, tip PF 1.4.B62.00 5000 m³/h (na voljo tudi druge velikosti) Sestava iz robustnega, vakuumsko tesnega 3 mm jeklenega ohišja, razdeljenega na surovi zračni prostor s filtrirnimi kartušami, filter s predkomoro in udarnim ločevalnikom ter čistim zračnim prostorom s čiščenjem filtrov s stisnjenim zrakom, vsak s posebnimi servisnimi vrati Easy Open. Kdsdpfx Adelxyhfoisw Lijak za zbiranje prahu z režnim ventilom za odstranjevanje prahu z uporabo Big Bag vreč. Magnetni ventil s prikazom diferenčnega tlaka za optimalno nastavitev čiščenja filtrirnih kartuš. Servisna vrata kot nihajna vrata za enostavno vzdrževanje.

Leto izdelave: 2025, Stanje: novo, ⭐⭐⭐⭐⭐ (5.0) 58 Reviews ⚡️ Top Service ⚡️ Fast Delivery ⚡️ Excellent Support! ✈️ Shipping available: 30-day delivery ✈️ ✅✅✅ Energy Class A+++ ✅✅✅ PLUS VAT & SHIPPING* ►►Buy Now◄◄ ✳️Maintain your liquidity! We offer a range of financing options to ensure your investment has the greatest chance for success. Contact us today to learn more about our hire purchase, warranty, or leasing programs.✳️ ➖➖➖➖➖ Kdedpfxjghf R Ue Adijw ►►►⌛⏰ FASTEST delivery times❗ ⌛⏰►►► ✨✨ Buy directly from the manufacturer and benefit from better prices and quality! ✨✨ Benefit from 40 years of Proton’s expertise in surface coating technologies. ➖➖➖➖➖ ☘️ Environmentally friendly ☘️⚡️ Green Energy ⚡️☘️ ⭐ Powder Curing Oven with Gas or Diesel Heating - BOXLINE 15-3025 ✔️ Internal dimensions: 1500*3000*2100 mm ✔️ External dimensions: 1780*4000*2500 mm ✔️ Volume: 9 m³ ✔️ Heating capacity: 90,300 Kcal/h ✔️ Circulating air flow (fan): 6,800 [m³/h] ✔️ Circulating fan power: 2.2 [kW/h] ✔️ Digital temperature control, continuously adjustable up to 220°C ✔️ Sandwich panels: Interior 1 mm galvanized steel, Exterior 1 mm powder-coated steel ✔️ Adjustable air outlets and air duct channels for uniform air distribution ✔️ Adjustable curing temperature, curing time, and exhaust fan operation ✔️ Audible signal at the end of curing time ✔️ Insulated door with special locking systems ✔️ Insulation: 140 mm mineral wool. Walls: 140 mm (50 mm rock wool + 100 mm glass fiber) ✔️ Heating method: Indirect heating ✳️Operating Principle✳️ This oven is designed for heating parts coated with powder paint. The coating polymerizes at approx. 200°C (depending on the type of powder used) and forms a film on the metal surface. Temperature control is performed by a control unit, which receives signals from a temperature sensor inside the oven. ✳️Oven Body✳️ The body of the polymerization oven consists of thermally insulated panels, vertically interlocked and sealed with heat-resistant compound. Conveyor gaps at the oven door channels can be provided as required. Optional double swing doors are available. ✳️Heat Exchanger✳️ The heat exchanger is installed on the side of the polymerization oven housing. Its internal design and materials allow the chamber temperature to be raised up to 230°C and maintain acceptable temperature differentials at various locations. Heat exchanger made from 3 mm thick AISI310 grade STAINLESS STEEL. ✳️Recirculation Fans✳️ Air circulation inside the oven is accomplished by four recirculation fans with insulated chassis. Wing-type air impellers are commonly used. ✳️Digital Fully Electronic Temperature Controller✳️ ✳️Exhaust Fan✳️ Used for extracting and discharging gases produced during powder polymerization in the oven. If required, the exhaust fan can run continuously after a certain period or be activated automatically at intervals. ⭐Follow us for new campaigns⭐ ☀️ 2 YEARS WARRANTY ☀️
