Sredinski stružnica in stružnica za vreteno

Strunguri SNA 560x2000

Stanje: dober (rabljeno), Funkcionalnost: popolnoma funkcionalen, Rabljeni stružnica TOS SUI 50 - 1500 s številnimi dodatki naprodaj Prodamo robusten in natančen stružnica TOS SUI 50 - 1500 – idealen za delavnice, obdelavo kovin in izkušene mojstre. 🔹 Razdalja med konicami: 1500 mm 🔹 Premer struženja nad posteljo: 500 mm 🔹 Hitrost vretena: 14 – 2240 vrt/min 🔹 Vrtina vretena: 56 mm 🔹 Dimenzije (DxŠxV): 3000 x 1300 x 1500 mm 🔹 Teža: približno 2,9 tone ✅ Stroj je rabljen, a tehnično v dobrem stanju in takoj pripravljen za uporabo. 📍 Lokacija: Werdau 📅 Možen ogled – preprosto se dogovorite za termin! Za več informacij pišite ali pokličite. Hsdpfswu Dn Isx Af Tsng

Stanje: rabljeno, Leto izdelave: 2000, Technical Details: Swing diameter over bed: 600 mm Swing diameter over cross slide: 260 mm Turning length: 610 mm Cross travel (X-axis): 160 mm Longitudinal travel (Z-axis): 610 mm Control: Siemens 810D Spindle speed: 1 – 6300 rpm, stepless Spindle torque: 86 Nm Spindle bore: Ø 42 mm Spindle nose diameter in front bearing: Ø 80 mm Feed drive AC: X/Z: 5000 / 7000 N Rapid traverse X/Z: 16 / 20 m/min Tool turret – number of stations: 12 / VDI 30 Tailstock quill: ISO MK4 Tailstock quill travel: 500 mm stroke Main spindle power: 7.5 kW (100% duty: 11 kW) Electrical specification – voltage/frequency: 3/PE ~400V and 50/60Hz Total power consumption: 20 kVA (11 kW) Machine weight approx.: 4.0 t Machine dimensions approx. LxWxH: 3.0 x 2.0 x 2.1 m The CNC lathe features a C-axis. Distance main spindle – tailstock: 805 mm Hydraulic power chuck Röhm Ø 160 mm (without jaws), max. speed 7,500 rpm Tailstock with live center Tool turret (12 positions available for driven tools) Currently, 8 tool holders installed in the magazine, of which 4 pieces with collet chuck Coolant system, coolant supply via the tool turret Control cabinet with Rittal cooling unit type SK3393100 Workpiece collection tray Machine lighting Hnsdpfeu Ixwiex Af Tsg Accessories: 1x driven tool In standard condition.

Stanje: novo, Leto izdelave: 2025, Centre height: 250 mm Spindle bore: 103 mm Centre distance: 1,000 mm Swing over bed: 500 mm Swing in gap: 710 mm Swing over cross slide: 300 mm Speed range: 9 - 1,600 rpm (24 steps) Spindle nose: DIN 55029 Camlock D1-8 Longitudinal feed range: 0.028 - 6.43 mm/rev; 93 steps Cross feed range: 0.012 - 2.73 mm/rev; 93 steps Metric threads: 0.5 - 224 mm; 48 steps Inch threads: 72 - 1/8 TPI; 49 steps Module threads: 0.5 - 112 mm; 42 steps Diametral pitch threads: 56 - 1/4 DP; 42 steps Quill diameter: 75 mm Quill travel: 150 mm Quill taper: Morse taper 5 Motor power: 7.5 kW Weight: 2,750.00 kg Hnjdpfx Ajd I A Dhjf Tjg Dimensions: 2,500 x 1,100 x 1,380 mm

Stanje: dober (rabljeno), Leto izdelave: 1986, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 01093.01-808, Rabljeni stružni stroj L&Z, proizvajalec: VDF BÖHRINGER, tip: DUE 630, letnik izdelave: 1986, številka stroja: 01093.01.-808. Dolžina struženja: 3000 mm, premer struženja: 630 mm. Vključno z 2 podpornimi lunetami, čeljustnim vpenjalom, plansko ploščo in nosilcem Multifix. Hedpfx Aoxd Df Njf Teng

Stanje: rabljeno, Leto izdelave: 1987, Technical specifications: Swing diameter over bed: 500 mm Swing diameter over cross slide: 280 mm Turning length: 1500 mm Distance between centers: 1500 mm Swing diameter in gap: 730 mm Spindle bore: 65 mm Hnjdpfx Asu Ixznef Tsg Spindle speed range: 25–1250 / 32–1600 / 36–1800 rpm, 18 steps Feed rate: 0.05 – 8.5 mm/rev Rapid traverse x-axis: 4 m/min Rapid traverse y-axis: 1.26 m/min Tailstock quill taper: MT 5 Tailstock quill stroke: 200 mm Total connected load: approx. 8.2 kW Machine weight approx.: 2.5 t Machine dimensions (L x W x H): approx. 3.2 x 1.3 x 1.5 m Thread cutting possible Cross slide travel 300 mm, feed 0.015 – 2.8 mm (end position clutch not functional, manual shut-off required) Top slide with 4-way toolpost Steel faceplate Ø 705 mm with offset threaded holes

Stanje: zelo dobro (rabljeno), Leto izdelave: 2007, Tehnični podatki: Višina konice: 500 mm Premer struženja: 1090 mm Premer struženja nad saneh: 690 mm Razdalja med konicama: 1500 mm Obrati: 6 – 1250 obr/min Premer vretena: 155 mm Digitalni prikaz položaja: SONY Širina postelje: 700 mm Orodje – vpenjalni stožec: MK 6 Moč motorja: 30 kW Oznaka CE Dimenzije (D x Š x V): pribl. 3500 x 1750 x 1900 mm Teža: pribl. 7,5 t Oprema: Centralno mazanje Hnodpfx Afoxlgmfs Teg Naprava za hlajenje Zadnji ščit pred brizganjem 3-čeljustni vpenjalni tulec 500 mm 4-čeljustni vpenjalni tulec 800 mm Prodajalec ne odgovarja za tipkarske ali prenosne napake. Stroj je glede na starost v ustreznem stanju glede izgleda, tehnike in obrabe; rabljeni stroji se prodajajo brez kakršnegakoli jamstva.

Stanje: dober (rabljeno), Leto izdelave: 1956, Heavy-duty lathe, lathe, engine lathe, geared head lathe, screw-cutting lathe - Manufacturer: Weisser, Geared Head Lathe Type PF200 - Turning length: 1340 mm - Swing over bed: 420 mm - Swing over cross slide: 240 mm - Spindle bore: Ø 41 mm - Spindle speeds: 31.5 - 1400 rpm - Three-jaw chuck: Röhm Ø 250 mm - Accessories: included, see photos - Tailstock taper: MT4 - Drive motor: 2.5/3.5 kW - Dimensions: 2670/1000/H1230 mm Hedotzf N Ropfx Af Teng - Weight: 1450 kg

Stanje: rabljeno, Leto izdelave: 1995, premer struženja nad ležiščem sani: 500 mm, Universal lathe Make: ZMM, Model 500 Year: 1995 Technical Data Manufacturer: ZMM Sliven Model: Universal 500 Year of manufacture: 1995 Centre distance: 1000 mm Swing diameter over bed:500 mm Spindle bore: 73 mm Dimensions (LxWxH): 2.7 x 1.2 x 1.8 m Weight approx.: 3100 kg Hedpfx Aswudhujf Tong Equipment • 3-jaw chuck Röhm ZS 350 mm • Quick-change toolpost • Live centre • Coolant pump • Machine lamp All information is without guarantee. A powered demonstration is possible at any time in our showroom.

Stanje: rabljeno, Leto izdelave: 1976, Technical Details: Hnjdpfx Afjva Erto Tjg Swing diameter over bed: 340 mm Swing diameter over cross slide: 190 mm Turning length: 800 mm Turning length: facing = 140 mm / cross = 120 mm Centre height over bed: 170 mm Spindle bore: Ø 40 mm Spindle speed range: 25 - 2000 RPM / 20 steps Feeds: longitudinal: 0.028 - 1.0 mm/rev / cross: 0.012 - 0.44 mm/rev Tailstock quill taper: MT3 Tailstock quill travel: 120 mm Total power requirement: 3.0 kW Machine weight approx.: 1.1 t Machine dimensions approx. LxWxH: 2.0 x 0.8 x 1.4 m Thread cutting possible: Metric, Whitworth, and module threads Equipment: - 2-way measuring system VISUCONT - 3-jaw chuck Ø 205 mm with internal clamping jaws - Multifix quick-change tool post - Foot brake - Coolant pump (delivery line exclusive)

Stanje: zelo dobro (rabljeno), Leto izdelave: 2005, Basic information: Year of manufacture: 2005 Dimensions (LxWxH): 7580x4360x5120 mm Weight: 6000 kg Operating voltage: 400/415V 50Hz Power consumption: 20 kW Output at 20g/l: 1600 kg/h Touch screen control panel Hsdpferfn Rvox Af Tsng Feeding hopper with screw conveyor Complete documentation available in both paper and electronic forms (electrical schematics, CE conformity certificate, operating manual) Condition: very good (machine clean and well-maintained, used exclusively for expanding white polystyrene) For an additional fee, we can arrange transport as well as installation and commissioning of the machine by our technicians at a location specified by the customer.
