Vodilno-/vlečno-vretena stružnica, premer struženja nad ležiščem 500–599 mm nakup rabljenega (130)

Stanje: novo, Parallel lathe with clutch and digital readout Fervi T085F10, featuring a mechanical clutch, 3-axis digital readout, and semi-Norton gearbox. Available with 2000 mm and 3000 mm center distances as well. EQUIPPED WITH MECHANICAL CLUTCH, 3-AXIS DIGITAL READOUT, AND SEMI-NORTON GEARBOX. FITTED WITH JOYSTICK FOR RAPID FEED ENGAGEMENT. BUILT ON A ONE-PIECE CAST IRON BASE. Technical data: - Center height: 280 mm - Max swing over bed: 560 mm - Max swing over carriage: 360 mm - Max swing in gap: 770 mm - Tool height: 32 mm - Distance between centers: 1000 mm - Spindle bore: 105 mm - Spindle mount: Camlock D1-8 - Spindle speeds (12): 36 - 1600 rpm - Longitudinal feeds: 0.063 - 2.52 mm/rev - Cross feeds: 0.027 - 1.07 mm/rev - Metric threads (22): 1 - 14 mm - Inch threads (26): 2 - 28 TPI - Tailstock taper: MT 5 - Motor: 400V 50/60 Hz, 7.5 kW - Coolant pump: 400V 50/60 Hz, 90 W - Dimensions: 2500 x 1400 x 1500 mm - Net weight: 2920 kg - Gross weight: 3555 kg Included accessories: - 3-jaw self-centering chuck Ø 320 mm with reversible jaws - 4-jaw independent chuck Ø 400 mm - Faceplate Ø 600 mm - Travelling steady - Fixed steady - MT 5 live center - Thread chasing dial - Leadscrew guard - Tool post guard - Spindle guard Kljdpsvbquisfx Abxeu - Rear splash guard - Quick-change tool post type C - LED lamp - Coolant system - Electro-mechanical foot brake - Quick-locking tailstock carriage - Carriage gears in oil bath - Adjustable leveling feet

Stanje: novo, Parallel lathe with clutch and digital readout Fervi T085F10 featuring mechanical clutch, 3-axis DRO, and semi-Norton gearbox. In stock, subject to prior sale. EQUIPPED WITH MECHANICAL CLUTCH, 3-AXIS DIGITAL READOUT, AND SEMI-NORTON GEARBOX. FITTED WITH JOYSTICK FOR ACTIVATION OF RAPID TRAVERSES. SINGLE-PIECE CAST IRON BASE. Technical data: - Center height: 385 mm - Maximum swing over bed: 770 mm - Maximum swing over saddle: 575 mm - Maximum swing in gap: 1050 mm - Tool height: 32 mm - Distance between centers: 1000 mm - Spindle bore: 105 mm Klodpevbqlhsfx Abxeu - Spindle mount: Camlock D1-8 - Spindle speeds (12): 36 – 1600 rpm - Longitudinal feed: 0.063 – 2.52 mm/rev - Cross feed: 0.027 – 1.07 mm/rev - Metric threads (22): 1 – 14 mm - Inch threads (26): 2 – 28 TPI - Tailstock taper: MT 5 - Motor: 400V 50/60 Hz 7.5 kW - Coolant pump: 400V 50/60 Hz 90 W - Dimensions: 2500 x 1550 x 1700 mm - Net weight: 3,250 kg - Gross weight: 3,250 kg Included accessories: - 3-jaw self-centering chuck, reversible jaws, Ø 320 mm - 4-jaw independent chuck, Ø 400 mm - Flange Ø 600 mm - Travelling steady - Fixed steady - Rotating tailstock center MT 5 - Threading dial - Leadscrew guard - Tool post guard - Chuck guard - Rear splash guard - Rapid-change tool post, type C - LED work light - Coolant system - Electro-mechanical foot brake - Quick-locking tailstock carriage - Oil-bath carriage gears - Adjustable leveling feet

Stanje: novo, Stanje: novo Dobavni rok: približno 4 mesece po naročilu Država izvora: Bolgarija Cena: 53.250 € Leasing obrok: 1.006,43 € Premer struženja nad posteljo: 500 mm Razdalja med konicama: 1.500 mm Višina konic: 250 mm Vrtina vretena: 75 mm Premer struženja nad prečnim sani: 0 mm Širina postelje: 400 mm Priključek vretena / DIN55027: 8 Stožec vretena: 80 MK Število stopenj brezstopenjskih vrtljajev vretena: 3 Brezstopenjski vrtljaji vretena: 25-100; 100-400; 500-2.000 min⁻¹ Število podajal: 120 Podaj v vzdolžni smeri: 0,04 - 12 mm/obrat Prečni podaj: 0,02 - 6 mm/obrat Metrski navoj – razpon: 0,5 - 120 mm Colski navoj – razpon: 60-1/4 navojev/" Navoj modul – razpon: Navoj DP – razpon: 240-1 Regulacijski hod prečnih sani: 315 mm Regulacijski hod zgornjih sani: 1 mm Premer pinole konjička: 90 mm Priključek konjička: 5 MK Hod pinole konjička: 2 mm Moč motorja: 11 kW Dolžina: 3.100 mm Širina: 1.250 mm Višina: 1.400 mm Teža: 2.800 kg Pogonski prenos z variabilnim menjalnikom (3 stopnje) 3-osni digitalni prikaz FAGOR z CSS (konstantna rezalna hitrost) Hitromenjalni držalo za orodje Amestra, sistem kot Multifix, vključno s 4 držali (3x pravokotna, 1 okrogla) 3-čeljustni vpenjalni tulec Bison 3204/DIN6350, Ø 250 mm Fiksni konus Vzdolžni omejevalnik za eno pozicijo Sistem za dovod hladilne tekočine Zadnja zaščitna plošča za ostružke po celotni dolžini Pokrov za vodilno in vijačno vreteno Zaščita za vpenjalni tulec Zaščita za držalo orodja Nastavljivi vijaki in plošče za niveliranje Konjiček s hitro vpenjalno ročico Strojna svetilka na nizko napetost Navodila za uporabo Oprema v skladu s ‘CE’ DRUGE DOLŽINE STRUŽENJA: Stružna dolžina 1.000 mm € 51.870,00 Kledpoyq Srfsfx Abxou Stružna dolžina 2.000 mm € 55.170,00 Stružna dolžina 3.000 mm € 59.620,00 Stružna dolžina 4.000 mm € 65.600,00 Stružna dolžina 5.000 mm € 81.110,00

Stanje: novo, Stanje: novo Dobavni rok: približno 4 mesece od naročila Država izvora: Bolgarija Cena: 46.970 € Leasing obrok: 897,13 € Premer struženja nad posteljo: 500 mm Razdalja med konicama: 1.500 mm Višina konice: 250 mm Premer vretena: 80 mm Premer struženja nad prečnim suportom: 0 mm Širina postelje: 400 mm Vpenjalna glava vretena / DIN55027: 8 Stožec vretena: 80 MK Število stopenj vrtenja: 21 Območje vrtljajev vretena: 20–2000 1/min Število pomikov: 120 Podolgovati pomik: 0,04–12 mm/obr Prečni pomik: 0,02–6 mm/obr Število navojnih stopenj: 64 Območje metričnega navoja: 0,5–120 mm Območje colskega navoja: 60–1/4'' navojev/'' Območje modularnega navoja: Območje DP navoja: 240–1 Območje prečnega suportnega pomika: 315 mm Območje zgornjega suportnega pomika: 1 mm Premer pinole konjička: 90 mm Stožec konjička: 5 MK Hod pinole konjička: 2 mm Moč motorja: 7,5 kW Dolžina: 3.100 mm Širina: 1.250 mm Višina: 1.400 mm Teža: 2.820 kg Pogon preko menjalnika 3-osni digitalni prikazovalnik Fagor Hitromenjalni nosilec orodja Amestra, sistem kot Multifix, vklj. 4 nosilce (3x pravokotni, 1x okrogel) 3-čeljustna vpenjalna glava Bison 3204/DIN6350, Ø 250 mm Fiksna centrirna konica Kodpfx Aewiq Rfebxelu Vzdolžni omejevalnik za eno pozicijo Hladilna naprava Zadnja zaščitna plošča po celotni dolžini za ostružke Pokrov vodilnega in povratnega vretena Zaščita za vpenjalno glavo Zaščita nosilca orodja Nastavljive noge in plošče Konjiček s hitro zatezno ročico Strojna svetilka z nizko napetostjo Navodila za uporabo Oprema skladna s “CE” DRUGE DOLŽINE STRUŽENJA: Stružna dolžina 1.000 mm 45.610,00 € Stružna dolžina 2.000 mm 49.010,00 € Stružna dolžina 3.000 mm 53.450,00 € Stružna dolžina 4.000 mm 59.360,00 € Stružna dolžina 5.000 mm 74.840,00 €

Stanje: generalkompletno obnovljen (rabljeno), Leto izdelave: 1984, Stružnica je bila leta 2025 retrofittana in je v popolnem stanju. Geometrijsko je bila obnovljena. Postelja je bila ponovno brušena, vsi vodila so bili ostrgani. Glava vretena in menjalniška omarica sta bila popolnoma razstavljena, očiščena in ponovno sestavljena. Vse je bilo odstranjeno iz starega laka in na novo prašno pobarvano. Priložen je merilni protokol. Teža stroja je 4000 kg. Originalna dokumentacija skupaj z obsežno dodatno opremo je priložena. Ena paleta z okoli 13 Multifix C nosilci z rezilnimi orodji je na voljo in je del ponudbe! Ksdpjyutluofx Abxslu

Stanje: dober (rabljeno), Swing diameter over bed: 380 mm Klsdpfx Abszd Hf Sjxeu Swing diameter over support: 250 mm Turning length: 600 mm Spindle speed: 90 - 1600 rpm Centre height: 200 mm Total power requirement: 4.2 kW Machine weight: approx. 1.3 t Space requirement: approx. 2.2 x 0.9 x 1.6 m

Stanje: zelo dobro (rabljeno), Leto izdelave: 2004, Please read the technical specifications in full. If you are considering this machine as an investment, we kindly request your complete credentials (including accurate telephone number and email address) prior to submitting an offer. We are offering an exceptionally high-quality precision lathe. In this class, it is likely the best German-built lathe ever made. BOEHRINGER Precision Lathe Model DUE 500 Year of manufacture: 2004 incl. CE + central lubrication Machine No.: T1022.2027-00 Centre height: 240 mm Swing diameter over bed: 500 mm Swing diameter over cross slide: 285 mm Centre distance: approx. 1,200 mm Effective turning length: approx. 1,000 mm Bar capacity: 62 mm Spindle nose: DIN 55027 Size 6 Spindle bore: 100 mm Drive power: 11 kW Max. torque: 2,000 Nm 24 spindle speeds: 11.2 – 2,240 rpm 60 cross feeds: 0.03 – 28 mm/rev 60 longitudinal feeds: 0.06 – 56 mm/rev Tailstock quill travel: 190 mm Tailstock taper: MK 5 Space requirement (L x W): approx. 4,000 x 1,525 mm Weight: approx. 4,300 kg Equipment: Kodpjw Rdthjfx Abxslu - 3-axis digital readout HEIDENHAIN - Central lubrication - Electrically interlocked chuck guard - Coolant system - Chip protection rear wall - Röhm power chuck T 250 mm incl. various jaws - Telescopic cover for leadscrew support to bed - Machine lamp - Multifix C + 4 toolholders - Live centre - Operating manual - Circuit diagram - Rapid traverse on longitudinal and cross slides Condition: The machine is in very good technical and visual condition. Backlash in cross slide approx. 0.3 mm, top slide approx. 0.15 mm Spindle taper runout approx. 0.006 mm Bed geometry: deviation of approx. 0.01 mm over 750 mm bed length (measured on flat guideway towards chuck using dial indicator) The following parts have been renewed: - Oil change - New hoses for central lubrication - New wipers - Key on engagement lever renewed - Pin for engagement lock renewed Net price, ex works loaded. Delivery with our own truck can be offered at extra cost.

Stanje: nepreverjeno (rabljeno), Funkcionalnost: popolnoma funkcionalen, izvrtina vretena: 65 mm, premer struženja: 500 mm, moč: 10 kW (13,60 KM), Manufacturer: Werkzeugfabrik Budapest Model: EU500/1500 Klodpfx Abeqwlmqexsu Turning length: 1500 mm Swing diameter – over bed: 500 mm – over cross slide: 315 mm Cross slide rotation: 18 degrees Spindle speed range: 25–1250 rpm Main spindle bore: 65 mm Spindle through-hole: 63 mm Tailstock sleeve taper (metric): 72 Lathe center taper: Morse 5 Main motor power: 10 kW Mains voltage: 3-phase, 380V, 50Hz Machine length: 3400 mm Total machine width: 1210 mm Height: 1265 mm Machine weight: 3550 kg

Stanje: novo, Centre height: 250 mm Swing diameter over cross slide: 350 mm Swing diameter in gap: 695 mm Distance between centers: 1,500 mm Spindle nose: DIN 55029, Camlock, size 6 Bed width: 305 mm Cross slide travel: 272 mm Top slide travel: 155 mm Spindle bore: 80 mm Speed range, stepless: (3) 30 - 2,200 rpm Whitworth threads: (45) 2 - 72 TPI Metric threads: (39) 0.2 - 14 mm Diametral pitch threads: (21) 8 - 44 D.P.I Module threads: (18) 0.3 - 3.5 module Longitudinal feeds: 0.04 - 1.00 mm/rev Cross feeds: 0.02 - 0.50 mm/rev Motor power: 5.5 kW Dimensions (LxWxH), approx.: 2,900 x 1,175 x 2,040 mm Weight, approx.: 2,200 kg Features: - Toolmaker’s accuracy - Stepless speed control (3 headstock ranges) - Dynamically balanced main spindle - Rigid machine bed with hardened and ground guideways - One-piece cast iron base - Adjustable precision tapered roller bearings in main spindle - Easy-to-operate feed gearbox with wide feed range in fully enclosed oil bath - Low-maintenance central lubrication - Removable gap bridge - CE certified Equipment: Kledogt E Ilspfx Abxsu - 3-axis digital readout (resolution 0.005 mm) - Frequency inverter - Machine stand with high splash guard and integrated lighting - Front pull-out chip tray - 3-jaw chuck - Fixed steady rest - Travelling steady rest - Micrometer bed stop - Oil cooler - Two emergency stop buttons and foot pedal with electric braking system - Safety interlocked chuck guard, tool post guard, and lead & feed screw covers compliant with CE European safety standards - Coolant system - Fixed centre - Reducing sleeve for main spindle - Operating tools in toolbox

Stanje: novo, Made in Italy Machine in accordance with DIN 8606 Centre height: 260 mm Swing over bed: 520 mm Swing over cross slide: 300 mm Distance between centres: 1,500 mm Kjdjdvm Euspfx Abxelu Bed width: 400 mm Spindle bore: 82 mm Spindle nose: Camlock 8" Spindle speeds: (24) 9 - 1,600 rpm (option: 11 - 2,000 rpm) Motor power: 5.5 kW (option: 7.5 kW) Feed Z-axis: (93) 0.028 - 6.43 mm/rev Feed X-axis: (93) 0.012 - 2.73 mm/rev Thread cutting, metric: (54) 0.5 - 224 mm Thread cutting, Whitworth: (55) 72 - 1/8 TPI Thread cutting, module: (54) 0.5 - 112 mm Thread cutting, diametral pitch: (54) 64 - 1/4 D.P. Cross slide (LxW): 650 x 230 mm Cross slide travel: 340 mm Top slide (LxW): 350 x 150 mm Top slide travel: 150 mm Tailstock quill diameter: 85 mm Tailstock quill stroke: 200 mm Tailstock taper: MT 5 Weight: approx. 3,100 kg Features: - Tailstock movement pneumatically assisted - Acceptance report according to DIN 8605; precision lathe with increased accuracy - Mechanical double clutch - Electromagnetic brake - Rapid traverse for X and Z axis - Electrical equipment made from high-quality brand components, e.g. Siemens/Schneider - Manual lubrication of guideways via hand pump - Reducing sleeve - 2 fixed centres - All safety devices conform to CE standards: Chuck guard with plexiglass window, micro limit switch secured. Tool holder guard with plexiglass window. Rear splash guard over the entire length. Leadscrew and feed rod guards with light curtain (integrated into emergency stop circuit). Emergency stop button. - Chip container on wheels - Electric coolant device - Fixed steady rest - Travelling steady rest - Operating tools, acceptance report according to DIN, operating and maintenance manual, complete electrical installation, machine built to the latest CE standard.

Stanje: generalkompletno obnovljen (rabljeno), Leto izdelave: 2022, Funkcionalnost: popolnoma funkcionalen, Premer struženja nad ležiščem: 540 mm Dolžina struženja: 1.500 mm Premer struženja v izrezu: 580 mm Delovna pot spodnjega suport mesta maks. cca: 415 mm Premik zgornjega suporta maks. cca: 140 mm Območje vrtljajev: 0 - 1.800 /min Premer glavnega vretena: 135 mm Vreteno odprtina: 68 mm Premer notranjega stožca: 83 mm Širina ležišča: 403 mm Opremljen z: Trivestenski vpenjalni pribor FORKARDT F250 Trio-osni digitalni prikaz FAGOR Fiksna luneta Zaščita vpenjalnega pribora Kadilni pladenj Nosilec orodij: 6 kosov nosilcev dlet, 1 kos nosilec za vpenjalno tulec Kodpfx Abszfnd Ssxslu Hladilna naprava

Stanje: novo, WORKING AREA – TURNING – - Max. swing diameter: 520 mm - Max. turning diameter: 260 mm - Max. workpiece length: 1500 mm MAIN SPINDLE - Spindle bore: 78 mm - Speed range from: 20 rpm Ksdpfx Absfcqtdexjlu - Speed range to: 2000 rpm - Number of gear stages: 12 - Spindle diameter: 78 mm LEAD AND FEED SCREW - Longitudinal feeds (z) from: 0.05 mm/rev - Longitudinal feeds (z) to: 0.82 mm/rev - Cross feeds (x) from: 0.02 mm/rev - Cross feeds (x) to: 0.4 mm/rev - Lead screw pitch: 6 mm TAILSTOCK - Quill diameter: 68 mm - Quill taper: MT 4 ELECTRICAL CONNECTION DATA - Total power consumption: 5.5 kW DIMENSIONS / WEIGHT - Total weight approx.: 1810 kg The machine is available with centre distances from 760 mm up to 2000 mm. Machine with 1500 mm centre distance in stock at A-6500 Landeck with the following options: - Article no. 5200 B Tool post head B, Multifi type (without tool holder) - Article no. 6405 DA3A-520-1500 Digital position indicator ARBAH (Made in EU) for SJ-520/1500S, incl. counter, 3 scales, stand, covers, and installation - Article no. 5300 3544-250-8 3-jaw chuck BISON, steel body Ø 250 mm, Camlock D8, with hard, one-piece stepped jaws We will gladly send you a non-binding quotation with your desired specifications. --> For descriptions as well as details on standard and special features, please refer to the PDF file.

Stanje: rabljeno, Vzvratni stružnica WMW NILES tip DLZ 500 IV L 1000 Med konicama: 1000 mm Maks. Ø nad posteljo: 500 mm Maks. Ø nad sedlom: 300 mm Premer vretena: Ø 50 mm Hitrost vretena: od 28 do 1400 vrt/min Tri-čeljustna glava: Ø 200 mm Navojne možnosti: metrični + Whitworth Konjiček: CM4 Samodejna pomika: prečna + vzdolžna + hitra Oljna črpalka Napetost: 380 V Kljdpfjzdt Sljx Abxsu Dimenzije (D x Š x V): 3000 x 1400 x 1500 mm Teža: pribl. 2,5 t

Stanje: rabljeno, Torno paralelo CAZENEUVE modelo HB 575 Distancia entre puntos: 2000 mm Diámetro máximo sobre bancada: 575 mm Diámetro máximo sobre carro: 300 mm Diámetro del husillo: Ø 51 mm Velocidad de rotación: de 20 a 1600 rpm Torreta TRIPAN 411 Plato de 3 garras Ø 200 mm Motor del husillo: 15 CV Roscados: Métricos + Whitworth Contrapunto CM5 Depósito de lubricante Bomba de lubricante Se suministra con 3 portaherramientas TRIPAN Tensión: 380 V Kedszdr U Sspfx Abxolu Longitud: 3500 mm Ancho con depósito: 1500 mm Altura total: 1400 mm Peso: aprox. 3 T

Stanje: rabljeno, Paralelni stružnica MULLER & PESANT Razdalja med konicama: 2500 mm Največji Ø nad posteljo: 520 mm Največji Ø nad sani: 280 mm Največji premer v izkopani postelji: 700 mm Premer vretena: Ø 56 mm Hitrost vretena: od 12,5 do 1000 vrt/min TRIPAN revolverska glava Tročeljustna vpenjalna glava Ø 250 mm Konjiček CM4 Samodejna podajalna vzdolžna in prečna Črpalka za mazanje Napetost: 380 V Dimenzije (D x Š x V): 4000 x 1500 x 1600 mm Teža: cca 3,5 t Kjdjzdrzfopfx Abxslu

Stanje: rabljeno, Leto izdelave: 1951, številka stroja/vozila: 6886, Swing diameter over bed: 500 mm Swing diameter over cross slide: 300 mm Swing diameter in gap: 760 mm Turning length: 1100 mm Centre height: 250 mm Feed rates - cross: 0.023 - 0.32 mm/rev Feed rates - longitudinal: 0.07 - 1.0 mm/rev Leadscrew pitch: 4 / 12 settings Spindle bore: 65 mm Spindle speed: 13 - 600 rpm Thread cutting - metric pitch: 0.5 - 84 mm Thread cutting - imperial: 0.375 - 14 TPI Tailstock quill travel: 200 mm Kledpfx Abecxxq Usxou Total power requirement: 3 kW Machine weight approx.: 2.7 t Space requirements approx.: 2.8 x 1.2 x 1.25 m with longitudinal and cross feed, 3-jaw chuck Ø 380 mm; swing diameter over bed without bridge 760 mm;

Stanje: rabljeno, številka stroja/vozila: 33548, Swing diameter over bed: 533 mm Swing diameter over carriage: 340 mm Turning length: 2000 mm Centre height: 270 mm Swing diameter in gap: 720 mm Spindle bore: 80 mm Number of spindle speeds: 12 Speed range: 25 - 1500 rpm Feeds: 76 Cross slide travel: 110 mm Quill travel: 360 mm Spindle taper: MT 4 Bed width: 370 mm Kodjcxxucepfx Abxjlu Approx. machine weight: 2.87 t Approx. required space: 4.1 x 0.95 m

Stanje: dober (rabljeno), ZMM SLIVEN CU 400 Vodilno in vlačno vreteno stružnica 3-osni digitalni prikaz MITUTOYO Maksimalna dolžina struženja 2.000 mm Višina konic 250 mm Premer skozi vreteno 60 mm Oprema: Trivrata univerzalna vpenjalna glava 250 mm Vsa ostala dodatna oprema, vidna na slikah in v videu, ni vključena v obseg dobave in tako ni del te prodaje. Obseg dobave vključuje le tista dodatna oprema, ki je izrecno navedena tukaj, v potrditvi naročila in na računu. FCA (fca nakladanje na tovornjak) D-32457 Porta Westfalica izključno embaliranje Dobavni rok takoj Vmesna prodaja pridržana / takojšnje plačilo ob sklenitvi nakupa Klsdpfx Abezfza Tjxou

Stanje: rabljeno, Leto izdelave: 1972, Turning length / mm Spindle speed / rpm Centre height / mm LÖW Universal Lathe V 1000 Details Model: V 1000 Machine no.: HO 1026 Centre height over flat bed: 500 mm Swing diameter over bed: 1,000 mm Bed length: 6,200 mm Turning length: 4,000 mm Spindle bore: 104 mm Klodpfjzcgi Njx Abxou Faceplate diameter: 900 mm Max. workpiece weight between centres: 5,000 kg Max. workpiece weight with 1 steady rest: 6,000 kg Max. workpiece weight with 2 steady rests: 7,100 kg Includes documentation Machine dimensions: 7800 x 1800 mm

Stanje: dober (rabljeno), Delovno območje Višina konic: 400 mm Razdalja med konicami: 5000 mm Premer vrtenja nad ležiščem: 840 mm Premer vrtenja nad suportom: 530 mm Klsdpfxey Ug U Ds Abxsu Vrtljaji vretena: 14,6 – 1250 min⁻¹ Pogonska moč: 18,5 kW Dimenzije: 8,0 × 1,9 × 1,7 m Teža ca. 6,3 – 8,2 t

Stanje: novo, Discover our selection of robust and precise conventional lathes Are you looking for a reliable lathe to boost your productivity? Experience precision and performance with our new range of conventional lathes, complete with extensive accessories. Our machines offer turning diameters from 400–1000 mm and turning lengths up to 10 metres, and are also available as cycle-controlled variants. With various models, you have limitless possibilities. Many machines are in stock and available at short notice! Explore our comprehensive range of special accessories, such as hollow spindles, infinitely variable spindle speeds, Siemens controls, and much more—making your lathe even more versatile. Whether for complex workpieces or demanding applications, our machines always provide the best results. Rely on our many years of experience and let’s optimise your machining processes together. Invest in quality and precision—contact us today! Here is a selection of STOCK MACHINES (see images); on request, we are happy to offer other models or custom-built machines: TECHNICAL SPECIFICATIONS: DLZ Series including BAFA subsidy of 15% and more! Swing over bed: 400–1000 mm Turning length: 1000/1500/2000/3000 mm Spindle bore: 80 (optionally 105) mm Workpiece weight up to 2 t Spindle speed up to 2800 rpm ACCESSORIES: Digital readout, 3-jaw chuck, faceplate, Multifix toolholder, and much more. Extensive SPECIAL ACCESSORIES such as stepless spindle speed, steady rests, larger spindle bores, etc. to make the machine even more productive: CURRENTLY AVAILABLE NEW MACHINES with warranty and BAFA subsidy, e.g. - SDM 850: swing over bed 850 mm, turning length 3 m - DLZ 325: swing over bed 650 mm, turning length 2 and 3 m - DLZ 250: swing over bed 500 mm, turning length 1 and 1.5 m - DLZ 200: swing over bed 400 mm, turning length Further models (including cycle control) available on request. Contact us now and discover the world of innovative turning technology! Our services for you: • Consultation and solutions directly at your site Kledjd Afn Iopfx Abxou • Organisation of transport for your machine to your facility • Delivery, installation, commissioning, and handover ready for operation • Financing and review of grant opportunities through KFW and BAFA, among others.

Stanje: novo, Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, premer struženja nad prečnim suportom: 360 mm, izvrtina vretena: 105 mm, premer struženja: 500 mm, širina na sredini: 1.500 mm, največja hitrost vrtenja: 1.600 obr/min, New conventional lathe DLZ 560x2000 with extensive accessories. Technical Main Data: Max. turning diameter over bed: mm Ø500 Max. turning diameter over cross slide: mm Ø310 Max. swing diameter in gap: mm Ø720 Bed width: mm 405 Max. workpiece length (between centers): mm 1500 Max. turnable length: mm 1350 Effective gap length: mm 230 Spindle: Spindle nose: D8 Spindle bore: mm Ø80 Spindle taper: M.T. No. 7 / Metric Ø113 1:20 Spindle speed (steps): 12 steps Spindle speed range: rpm 36–1600 For further specifications, please refer to the attachment. Main Features: - Complete price including 2-axis position display (SINO – General importer in Germany), installed, and powerful 7.5 kW drive Kjdpjyak Evefx Abxslu - Heavily ribbed machine bed absorbs vibrations, even during roughing operations - Very wide guideways, induction-hardened and ground, for long service life with high accuracy. Max. workpiece weight up to 500 kg. - Electrically interlocked chuck guard - Equipped with adjustable micrometer stop and overload clutch - Hardened and ground gears with oil-circulating lubrication system for powerful and quiet spindle drive - Precision main spindle bearings ensure high concentricity and accuracy - Clearly arranged and ergonomically designed controls - Single-lever feed selection for cross, longitudinal, and rapid feed (X/Z-axis) on the carriage - Precise gear stage selection for spindle speed and feed rates - Fine-graduated selection for feed rates and thread pitches - Main spindle gearbox with electromagnetic clutch - Key electrical components from top European brands, e.g. Telemechanique - Extensive standard equipment including Multifix toolholder, chuck, faceplate, 3-axis digital readout, steady rests, and much more - All machines are tested by our service technicians before delivery Further models (including ones with cycle control) available on request. Contact us now and discover the world of innovative turning technology! Our service for you: • Consultation and solution finding at your location • Organization of transport of your machine to your factory • Installation, assembly, commissioning, and handover ready for operation • Financing and review of funding opportunities through KFW, BAFA, and more.

Stanje: novo, Leto izdelave: 2026, Funkcionalnost: popolnoma funkcionalen, izvrtina vretena: 80 mm, premer struženja: 560 mm, širina na sredini: 2.000 mm, new CNC cycle lathe ZDM 560 x 2000 with Siemens 828D ShopTurn 2. Short description of the machine The ZDM 560 x 2000 is a robust and versatile flat-bed CNC cycle lathe suitable for flexible production, maintenance, and training applications. It combines the benefits of conventional lathes with modern CNC control technology. Thanks to the Siemens 828D ShopTurn control, programming is simple and intuitive. The machine is particularly suitable for single parts and small batch production, and is available from stock at short notice. 3. Technical specifications ZDM 560Z Swing diameter over bed (mm): 560 Swing diameter with 6-station tool turret (mm): 420 Max. workpiece length (mm): 2000 Max. turning length (mm): 1900 Max. turning length with 6-station turret (mm): 1735 Max. workpiece diameter over cross slide (mm): 330 X-axis travel (mm): 320 Z-axis travel (mm): 1970 Rapid traverse X/Z (m/min): 8/10 Spindle mount: A2-8 Spindle bore (mm): 80 Klodpoqwqiajfx Abxou Spindle nose taper: MT7 Spindle speed (rpm) with manual chuck: 27-135 55-270 160-805 325-1630 Gear stages: 4-stage Tool shank (mm): 32x32 Tailstock quill diameter (mm): 75 Tailstock quill stroke (mm): 150 Tailstock quill taper: MT5 Main motor (kW): 7.5 Net weight (kg): 4100 Machine dimensions LxWxH (mm): 3000×1250x1580 4. Standard equipment • Siemens SINUMERIK 828D ShopTurn • 80 mm spindle bore • 250 mm 3-jaw chuck • Manual tailstock • Coolant and lubrication system • Fully enclosed guarding • LED working lamp • CE conformity 5. Equipment of stock machine • Chip conveyor for 2000 mm machine • 6-station electric tool turret • Steady rests (60–190 mm and 150–280 mm) • Teach-in control panel with handwheels and joystick Further accessories available on request 6. Special features / advantages • Easy operation thanks to ShopTurn • High flexibility for single parts and small series production • Robust cast construction • Large spindle bore for bar machining • Immediately available – no delivery time risk 7. Scope of delivery Machine including standard and special equipment as listed above, operational and ready for use. 8. Delivery time Available at short notice from stock Stockstadt.

Stanje: novo, Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, izvrtina vretena: 105 mm, premer struženja: 560 mm, premer struženja nad ležiščem sani: 360 mm, stružna dolžina: 2.000 mm, največja hitrost vretena: 1.600 obr/min, DLZ 560 – Conventional Precision Lathe The DLZ 560 is a robust and versatile lathe designed for demanding applications in mechanical engineering and metalworking. Max. swing over bed: Ø 560 mm Max. swing over cross slide: Ø 360 mm Spindle bore: Ø 105 mm Spindle speed range: 36 – 1600 rpm (12 steps) Distance between centers: 2000 mm Klsdexdnd Aspfx Abxju Motor power: 7.5 kW Machine weight: approx. 2,900 kg Thanks to its heavily ribbed Meehanite cast bed, the machine offers high stability and excellent vibration damping. Wide, hardened and ground guideways ensure long-lasting precision even when machining heavy workpieces up to 500 kg. The extensive standard equipment includes, among others: Multifix tool post, 325 mm three-jaw chuck, 400 mm faceplate, fixed and travelling steadies, 2-axis digital readout, as well as a coolant and lubrication system, and much more. Also available with stepless spindle speed control! The DLZ 560 impresses with high accuracy, operator-friendly design and versatility – ideal for single-part and small-batch production in tool and mechanical engineering. The machine will be available from the end of December. Image for reference only.

Stanje: zelo dobro (rabljeno), Leto izdelave: 1979, Premer struženja nad posteljo 480 mm Premer struženja nad suportom 295 mm Dolžina struženja 1000 mm Vretenova odprtina 56 mm Teža stroja cca 1,8 t Ksdpfxjyiu T Ao Abxolu Prostorske mere cca 1,4 x 0,8 x 1,6 m
