7 Vreteno štiristranskega skobeljnika

SK MACHINERY 907S

Stanje: rabljeno, Leto izdelave: 2018, Funkcionalnost: popolnoma funkcionalen, premer struženja: 1.000 mm, premer struženja nad ležiščem sani: 710 mm, stružna dolžina: 8.000 mm, Used Heavy-Duty Lathe with Extensive Steady Rest Equipment – Ideal for Pipe Machining and Long Rollers! Lredpfxov Tnttj Aamep This robust conventional lathe, featuring an impressive turning length of 8,000 mm, is specially designed for pipe processing applications. The well-thought-out machine concept allows the cutting tool to easily pass by the open steady rests – ideal for the precise machining of long, hollow workpieces. Technical highlights: • Swing over bed: 1,000 mm • Swing over cross slide: 710 mm • Center height: 900 mm • Turning length: 8,000 mm • Spindle bore: 155 mm • Machine weight: approx. 18.2 tons • Main drive: 30 kW with frequency inverter, infinitely variable Design advantages: • One-piece cast machine bed, artificially aged – for maximum stability and stress relief • 5 hardened and ground guideways for highest precision • Stepless longitudinal feed adjustment via ballscrew – no Norton or apron gearbox • Tailstock traversable by electric motor, hydraulically clamped • Manually adjustable cross slide with trapezoidal thread spindle • 4-position tool post, manually rotatable • Triple-guided compound slide – for extremely smooth operation Steady rests & pipe machining: • Various steady rests (fixed and travelling) available as options • Motorized steady rest carriage with hydraulic clamping • Tailstock quill adjustment conveniently accessible from the operator side • Travelling steady rests can be mounted on left or right as required Application: Thanks to its sophisticated design, the machine is ideally suited for light to medium machining tasks – especially for the precise finishing of pipes. The infinitely variable speed and feed adjustment offers maximum flexibility and operator comfort.

Stanje: generalkompletno obnovljen (rabljeno), Leto izdelave: 2009, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 30214501, stružna dolžina: 2.000 mm, skupna dolžina: 12.000 mm, WFL Millturn M60-G/2000 WORKING RANGE Centre distance mm 2000 Lredpsu Hl R Tofx Aamjp Swing diameter over cross slide mm 480 MAIN DRIVE AC drive with 2-speed gearbox Drive power 100% duty cycle kW 60 Max. spindle speed rpm 2600 Max. spindle torque 100% duty cycle Nm 2748 COUNTER SPINDLE DRIVE AC drive with 2-speed gearbox Drive power 100% duty cycle kW 40 Max. spindle speed rpm 3300 Max. spindle torque 100% duty cycle Nm 1830 TOOL CARRIER (Single tool carrier, turning-milling-drilling unit) AC drive, drive power 100% duty cycle kW 25 Max. spindle speed rpm 4000 Max. spindle torque 100% duty cycle Nm 300 Travel perpendicular to X/Z (Y-axis) mm 300 [-125/+175] Swivel angle of milling spindle (B-axis) ° -110/+90 Spindle nose for tools according to DIN 69893 HSK-A63 Spindle diameter at front bearing mm 100 DIMENSIONS Length (max. tool magazine with chip conveyor) m 11*12 Width/height m 4.2/3.5

Stanje: zelo dobro (rabljeno), Leto izdelave: 2007, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 635 mm, pomik osi Y: 510 mm, pomik po osi Z: 460 mm, proizvajalec krmilnikov: HEIDENHAIN, model krmilnika: iTNC 530, največja hitrost vretena: 10.000 obr/min, nos vretena: ISO 40, število mest v zalogovniku orodij: 30, Oprema: CE označba, dokumentacija / priročnik, transportni trak za ostružke, Vertikalni obdelovalni center DMG model DMC 635V Hodi: 635x510x460 mm Menjalnik orodij RANOM z 30 pozicijami Vreteno 10.000 RPM Lrodjxq E Daspfx Aamep Visokotlačno hlajenje preko vretena Transporter za ostružke Daljinsko upravljan ročni upravljalnik Heidenhain HR410

Stanje: zelo dobro (rabljeno), Leto izdelave: 1997, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 1114.3705-24, Used CNC Lathe Manufacturer: Boehringer Model: VDF 250Cm Year of manufacture: 1997 VDF Boehringer 250C The machine features the following equipment: - 1000 mm turning length - Without tailstock - Driven tools - Special swivel chuck - Siemens 840C control The Boehringer VDF 250 Cm is a CNC lathe designed for chuck workpieces. It is distinguished by its robust construction and high-precision machining capabilities. Technical Data (Model Year 1997) Working Area: - Swing diameter over bed: 550 mm - Swing diameter over cross slide: 480 mm - X-axis travel: 405 mm - Z-axis travel: 1,099 mm - Maximum turning length: 1,000 mm (No) Tailstock: Lrjdpfxewlap As Aamop Tool Turret: - Number of stations: 12 - Tool holder: VDI 50 DIN 69880 - Driven tools: YES Spindle: - Spindle nose size: 8 DIN 55026 - Spindle bore: 103 mm - Max. chuck diameter: 315 mm - Max. drive power (50% duty cycle): 53 kW - Max. torque: 780 Nm - Speed range: 30–3,000 rpm Feeds: - Automatic feed rates: 1–10,000 mm/min - Rapid traverse speed: 10 m/min (X and Z axes) - Max. feed force: 15 kN Dimensions and Weight: - Machine dimensions (L × W × H): approx. 5,400 × 3,200 × 2,400 mm - Machine weight: approx. 11,000 kg Equipment: - Swiveling control panel - Hydraulic system by HYDROKRAFT - Coolant system with 600 l tank, max. pump pressure 5.5 bar, flow rate 60 l/min, pump power 1.1 kW - Chip conveyor with 325 l tank capacity, right-side discharge - 3-jaw power chuck - Oil mist extraction - Electrical cabinet with cooling unit and temperature controller by RITTAL Control: SIEMENS SINUMERIK 840 C Variants and Differences There are various versions of the VDF 250 series, such as the VDF 250 CU, which may be equipped with different controls (e.g., PHILIPS B2T) and technical specifications. Some models feature driven tools and a tailstock, while others are pure chuck machines designed without a tailstock. Conclusion The Boehringer VDF 250 Cm is a versatile CNC lathe known for its stability and precision. Its robust design and comprehensive features make it ideal for machining chuck parts in various production environments.

Stanje: rabljeno, Leto izdelave: 1998, obratovalne ure: 8.700 h, Funkcionalnost: popolnoma funkcionalen, Der gebrauchte 2-Achs CNC-Drehmaschine DAEWOO Lynx 200B ist eine robuste und schnelle CNC-Drehmaschine mit schrägem Bett und Flachführungen in kompakter Bauweise. Sie ist mit einer CNC-Steuerung FANUC 21-T mit LCD-Monitor, Baujahr 1998, gemäß CE-Norm ausgestattet. Hauptmerkmale: - Max. Umlaufdurchmesser über Bett: 460 mm - Max. Drehdurchmesser: 280 mm - Max. Drehlänge: 500 mm - Max. Stangendurchlass: 51 mm - Spindelaufnahme: ASA 6” - Spindel: max. Drehzahl 4.500 U/min - Spindelmotorleistung: 11 kW - Revolver: 10 Werkzeugplätze - Werkzeugabmessungen Dreh-/Bohrhalter: 25×25 / Ø40 mm - Reitstock: Pinolendurchmesser 65 mm, Pinolenhub 80 mm, MK4 - Maschinengewicht: 3.500 kg Lsdpfxsx Nqlis Aamjrp Zur Ausstattung gehören ein programmierbarer Reitstock mit automatischem Pinolenhub, Werkzeugvoreinstellung, ein hydraulisches 3-Backenfutter (wird anstelle des manuellen Futters geliefert) sowie Betriebs- und Wartungsanleitungen.

Stanje: dober (rabljeno), GENERAL CHARACTERISTICS Maximum grinding diameter: 120 mm Grinding wheel width: 250 mm Minimum grinding diameter: 1 mm Regulating wheel diameter: 304 mm Grinding wheel diameter: 508 mm DIMENSIONS AND WEIGHT Height: 1,700 mm Width: 1,500 mm Length: 2,750 mm Weight: 4,000 kg ELECTRICAL SPECIFICATIONS Grinding head motor power: 15 kW Regulating wheel head motor power: 1.8 kW Ledpfx Aorpnf Aeamsrp Hydraulic motor power: 1.1 kW Total installed power: 20 kW Voltage: 220/380 V

Stanje: dober (rabljeno), skupna širina: 3.500 mm, skupna dolžina: 19.000 mm, skupna višina: 2.100 mm, teža obdelovanca (maks.): 6.000 kg, premer brušenja: 850 mm, dolžina brušenja: 6.000 mm, višina središča: 425 mm, Cilindrični brusni stroj Schmaltz - RM 82/6000 MACH-ID 9492 Proizvajalec: Schmaltz Tip: RM 82/6000 Višina konic: 425 mm Premer brušenja Ø: 850 mm Dolžina brušenja: 6000 mm Dimenzija brusnega kamna: 1100 x 80 x 560 mm Hitrost vrtenja brusnega kamna: 700 o/min Zasuk mize: -5 do +5° Lrodpfx Ajy Dr Eajamop Konjiček: 160 x 100 Mk Dolžina: 19.000 mm Širina: 3.500 mm Višina: 2.100 mm Teža: 31.000 kg Prosimo, upoštevajte: Informacije na tej strani so bile pridobljene po najboljšem vedenju in vestno s strani nas ter, kolikor je mogoče, s strani proizvajalca. Informacije so podane v dobri veri, vendar za njihovo točnost ne moremo jamčiti. Posledično te informacije ne pomenijo zagotovila ali pogodbenih pogojev. Priporočamo, da preverite vse pomembne podrobnosti.

Stanje: zelo dobro (rabljeno), Leto izdelave: 2006, obratovalne ure: 53.244 h, Funkcionalnost: popolnoma funkcionalen, Tehnični podatki – Gleason Phoenix II 600HC (CNC-hipoidni zobčarski stroj) Delovno območje Maks. premer obdelovanca Ø 600 mm Maks. globina zoba 24,6 mm Maks. širina zobnika 110 mm Število zob 1–300 Velikost rezalne glave za čelno rezkanje (FM) 18" premer Velikost rezalne glave za valjčno rezkanje (FH) 210 mm polmer Maks. hitrost rezalne vretena 600 min⁻¹ Delovno vreteno Premer stožca spredaj Ø 203 mm Premer stožčaste izvrtine Ø 181 mm Globina izvrtine 884 mm Maks. hitrost delovnega vretena 600 min⁻¹ Dimenzije in teža Zahtevan prostor D × Š × V 4,4 × 3,5 × 3,5 m (vklj. periferija) Teža stroja 26.000 kg Priključni podatki Skupna priključna moč 139 kVA Predvarovalka 200 A Obratovalna napetost 400 V Lsdexwzu Ispfx Aamorp Omrežna frekvenca 50 Hz Krmilna napetost 24 V DC

Stanje: zelo dobro (rabljeno), Leto izdelave: 2015, obratovalne ure: 9.564 h, Funkcionalnost: popolnoma funkcionalen, CNC FANUC 31i-MODEL B5 TOOL PRESETTER Lsdowayv Espfx Aamjrp No. 2 SELF-CENTERING CHUCKS No. 7 HSK TOOLS

Leto izdelave: 1997, stanje: pripravljen za uporabo (rabljen), Travel X/Y/Z: 1300mm/1100mm/1000mm, table size X/Y: 800mm/800mm, number of pallets: 14, max. table load: 2200kg, table indexing: 0.001°. Spindle speed: 7000rpm, spindle power: 50HP, tool magazine: 80. Dimensions X/Y/Z: approx. 7000mm/3400mm/3800mm, weight: approx. 24000kg. An on-site inspection is possible. Ledotx Dn Uepfx Aamsrp
