Zobnik nakup rabljenega (518)

Stanje: zelo dobro (rabljeno), Leto izdelave: 2004, Funkcionalnost: popolnoma funkcionalen, CNC horizontal gear hobbing machine Details Max. gear diameter: 180 / 210 mm Max. module: 4.5 Largest permissible addendum circle diameter: 80 mm Working length: 170 mm Total length: 240 mm Mounting diameter: 32 mm Radial travel (X-axis): 100 mm Tangential travel (Y-axis): 160 mm Axial travel (Z-axis): 400 mm Tailstock: 350 Workpiece spindle bore: 63 mm External diameter: 160 mm Weight: 7,000 kg Fodpfx Afjqaf U Toljpb Description Gleason-Pfauter gear hobbing machine P210 L Automatic loading and unloading for series production.

Stanje: dober (rabljeno), Leto izdelave: 2002, Wheel diameter - max. 275 mm Wheel width 55 mm Module - max. 6 Module - min. 1 Control unit 840 C Siemens Total power requirement 100 kW Machine weight approx. 16.7 t Space requirement approx. 5.2 x 2.3 x 2.4 m Fpodpetumrpjfx Aflob

Stanje: zelo dobro (rabljeno), Leto izdelave: 1981, Funkcionalnost: popolnoma funkcionalen, skupna masa: 750 kg, skupna dolžina: 1.275 mm, skupna širina: 560 mm, skupna višina: 745 mm, prenosno razmerje: 160, vrtilni moment: 14.560 Nm, premer gredi: 125 mm, 1 kos industrijskega stožčasto-čelnega zobniškega prenosa od Proizvajalec: Penig DDR TGL: 21815 Tip: 10LA1-224/315 Stanje: iz skladiščne razprodaje (verjetno nikoli uporabljen) največji trajni navor: 14.560 Nm Prenosno razmerje: i = 160 : 1 Natančna vrednost prenosa: Izkoristek: 97% Prenesena moč pri: 1400 o/min-(8,7 o/min) = 13,5 kW 950 o/min-(5,9 o/min) = 9,0 kW 710 o/min-(4,4 o/min) = 6,8 kW Polnjenje z oljem: 85 kg Fjdpfsxtxphsx Afljpb Teža: 750 kg Premer gredi d1: 35 mm Premer gredi d2: 125 mm Višina gredi h1: 400 mm Skupna višina h2: 745 mm Dolžina: 1275 mm Širina: 560 mm (brez gredi) Na voljo tudi velike sklopke za gredi!

Stanje: zelo dobro (rabljeno), Leto izdelave: 2002, obratovalne ure: 49.220 h, Funkcionalnost: popolnoma funkcionalen, Prodaja se čudoviti stroj za odvalno rezkanje zobnikov LC 382. Stroj je bil strogo vzdrževan s strani podjetja LIEBHERR in zagotavlja najboljše tolerance. Največji premer obdelovanca: 500 mm Modul - maks. 10 Širina zobnika - maks. 350 mm Fpjdexlzr Njpfx Aflob Najmanjše število rezkanih zob: 4 Rezkalna glava - nagibna + / - 45° Obremenitev delovne mize: 18 kN

Stanje: zelo dobro (rabljeno), Leto izdelave: 2002, Premer kolesa - maks. 130 / 80 mm Širina kolesa 180 mm Modul - maks. 4 Modul - min. 0,5 Vretenaste hitrosti - brezstopenjsko 300 - 3000 obr/min Krmiljenje Siemens 840 D x-hod 200 mm y-hod 170 mm z-hod 250 mm Rezkalna glava - nagibna + / - 45° Premer mize 168 mm Luknja v mizi 65 mm Največja vpenjalna dolžina 245 mm Fodpfoxlug Hjx Afljpb Območje vrtenja mize 0 - 1000 obr/min Skupna potreba po moči 51 kW Teža stroja pribl. 9,2 t Prostor za postavitev pribl. 4,5 x 4,0 x 3,2 m

Stanje: zelo dobro (rabljeno), Leto izdelave: 2000, Gear Grinding Machine CNC Control: SIEMENS 840C Max. external diameter: 1,500 mm Grinding length / Max. gear width (spur gears): 980 mm Module: 1.5 – 25 Fsdpfx Afou Aqi Hjlepb Base circle diameter: min. 80 mm Helix angle: 35° Table diameter: 1,000 mm Max. workpiece weight: 6,000 kg Grinding wheel power: 20 kW Profile corrections: max. 0.5 mm Lead corrections: max. 1 mm Tailstock height: 1,250 mm Axial slide travel (Z-axis): 1,000 mm Dimensions: 7,760 x 8,360 x 4,500 mm Weight: 42,000 kg

Stanje: zelo dobro (rabljeno), Leto izdelave: 2009, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 27506, Generalna obnova leta 2009 CNC rezkar za zobnike Pfauter PE 150 Serijska številka: 27 506 Leto izdelave: 1991 – generalna obnova 2009 Fpsdoxtpg Rspfx Afljb CNC krmilje: SINUMERIK 840 D

Stanje: dober (rabljeno), Servomotor, elektromotor, enosmerni motor, servo-prenosni motor, sinhronski motor -Proizvajalec: KEB, servo prenosni motor z zavoro -Tip: K23C TA3M V40 BP05 ER TW Fsdpfxsxt D Sbe Aflspb -Napetost: 400 V -Moč: 1,88 kW -Hitrost: 4500 min⁻¹ -Reduktor: i = 31,57 -Votla gred: Ø 30 x 120 mm -Razred zaščite: IP54 -Zavora: 4,5 Nm -Za tehnične podatke glejte fotografijo tipske ploščice -Dimenzije: 470/140H200 mm -Teža: 16 kg

Stanje: zelo dobro (rabljeno), Leto izdelave: 2007, Gleason Pfauter G130H CNC vertikalni stroj za ozubljanje z rezkarjem (hobbing) Krmiljenje: Siemens 840D Leto izdelave: 2007 Zmogljivost Največji premer obdelovanca: pribl. 130 mm Največja širina zobnika: pribl. 170 do 180 mm Največji modul: do modula 3 ali 4 (odvisno od konfiguracije) Najmanjši modul: pribl. modul 0,5 Glava za rezkar Moč rezkalne vretena: pribl. 11,5 do 14 kW Območje vrtljajev rezkalne vretena: pribl. 10 do 4000 min⁻¹ Zasuk glave rezkarja: pribl. ±45° Največji premer rezkarja: pribl. 100 mm Največja dolžina rezkarja: pribl. 240 do 317 mm Fpodpfsxxzqlsx Aflsb Pomik rezkalne glave (hob shift): pribl. 170 do 220 mm Pomiki osi Pomik osi X: pribl. 200 mm Pomik osi Y: pribl. 170 mm Pomik osi Z (aksialni pomik): pribl. 250 do 350 mm Delovno vreteno in miza Območje vrtljajev delovnega vretena: pribl. 0 do 1000 min⁻¹ Premer mize: pribl. 160 do 168 mm Vrtina mize: pribl. 65 mm Največja vpenjalna dolžina: pribl. 245 mm Hidravlično vpenjanje je vključeno pri večini enot Proces Obdelava z emulzijo (wet cutting) Zunanji zobniški rez Možna dva reza in posnemanje konusa ali kronanje zob (taper/crown hobbing) ISO 30 vreteno za rezkar Opcijsko avtomatski nakladalni sistemi Elektrika in splošno Teža stroja: 11 ton Tloris stroja z zaščitami: pribl. 3 x 3 m

Stanje: zelo dobro (rabljeno), Rezkalni stroj za zobnike LIEBHERR LC 282 CNC Specifikacije Proizvajalec: LIEBHERR Fpsdpfxjxgpqce Afljb Model: LC 282 CNC Stanje: Rabljeno Številka zaloge: Factory Največji premer: 280 mm Število vrtljajev orodja: 1200 rpm Modul: 7 Premer mize: 250 mm Število vrtljajev mize: 100/200 min Min-max razdalja med obdelovancem in rezkarjem: 30 - 300 mm Naklon glave: 45° Največji premer rezkarja: 160 mm Teža stroja: 12.000 kg

Stanje: generalkompletno obnovljen (rabljeno), Funkcionalnost: popolnoma funkcionalen, High-Utility Profile Milling and Thread Milling Machine ZFWVG 250x5000 / S7 • Thread milling • Gear hobbing • Longitudinal milling Maximum workpiece diameter over carriage: 250 mm Maximum workpiece diameter over bedways: 500 mm Workpiece spindle bore: 102 mm Tailstock quill stroke: 100 mm Main motor: 4.0 kW Cross axis feed motor (x): 4.3 kW Longitudinal axis feed motor (z): 3.8 kW Electrical equipment Operating voltage: 400 V Control voltage: 24 V Frequency: 50 Hz Programmable logic controller for fixed machine functions Total connected load: 9.5 kW Milling length: 5,000 mm Fpedpfx Afew Hquxsljb Required space: Length: 7,000 mm Width: 2,500 mm Height: 1,600 mm Net weight: 6,700 kg Standard accessories: • Standard thread milling attachment ApG • Maximum milling diameter: 150 mm • Internal taper of milling spindle: Morse 3 • Maximum profile with gear hobbing: Module 3 • Smallest to largest tooth count when gear hobbing: 4-50 Options: • Gear hobbing attachment ApFW Gear hobbing of parallel and helical profiles up to module 7 Maximum milling diameter: 150 mm Internal taper of milling spindle: Morse 4 • Heavy-duty thread milling attachment ApGS Gear hobbing of parallel and helical profiles up to module 5 Maximum milling diameter: 150 mm Internal taper of milling spindle: Morse 4

Stanje: zelo dobro (rabljeno), Leto izdelave: 1997, Premer zobnika - maks. 820 mm Širina zobnika 300 mm Modul - maks. 8 Modul - min. 0,5 Vpenjalna dolžina 865 mm Število zob 10 - 600 Kot spiralnosti - maks. +/- 30° Hitrost vrtenja 1100 - 2150 obr/min Premer brusnega kamna 280 - 400 mm Širina brusnega kamna 84 /104 mm Maksimalna teža obdelovanca 300 kg Fpsdowy H Ihepfx Afljb Teža stroja cca 11,5 t Potreben prostor cca 6,0 x 4,8 x 2,9 m Vključuje Reishauer AF filter, brusne kolute, prirobnice ...

Stanje: zelo dobro (rabljeno), Premer: 800 mm Modul: 10 Fodpfx Afsxv Sbpolopb

Stanje: rabljeno, Leto izdelave: 2006, Translation ratio max. 10:1 Number of teeth – min. 3 Number of teeth – max. 200 Tooth height 20 mm Tooth width max. 58 mm Grinding spindle speeds stepless up to 6,000 rpm Workpiece spindle speed 1,200 rpm Tool diameter max. 230 mm Tool diameter min. 69.85 mm X-axis 325 mm Y-axis 350 mm Z-axis 470 mm Fpjdpfxjvxwr Ao Afleb B-axis +90.1° / -1° Workpiece table - Ø 212.71 mm Control system SIN 840 D SIEMENS Total power requirement 75 kW Machine weight approx. 10,000 kg Space requirement approx. 6.10 x 4.40 x 3.30 m Coolant filter system Hoffmann HSF 100 V

Stanje: dober (rabljeno), Leto izdelave: 2006, Funkcionalnost: popolnoma funkcionalen, PRAWEMA 2005 204 HS-W Fpjdpfx Afsvm Efaeljb PRAWEMA 2006 SYNCHROFINE 205 HS

Stanje: rabljeno, The Klingelnberg GKP 90 bevel gear testing machine was designed as a universal machine and is used by manufacturers of gears and drive technology for noise and contact pattern testing of bevel and hypoid gears. Technical Data Diameter: 540 (400) mm Hypoid: ±50 mm Pinion spindle diameter: 90 mm Dimensions: 1,800 x 1,800 x 1,600 mm Machine weight: approx. 2,800 kg *Specifications and data are non-binding. Subject to prior sale. Special Features: This machine is intended for noise and contact pattern testing of bevel and hypoid gears of all types. By simulating operating conditions, applying different speeds, and changing load conditions for drive and coast sides, the optimal mounting distance for stationary operation can be determined. Fpsdsxpq Nlopfx Afljb • Digital actual value display for 2 axes • Stepless speed adjustment via frequency converter • Electrically interlocked and removable safety guard • Accessories – wide range of workpiece fixtures • Condition: very good

Stanje: zelo dobro (rabljeno), Leto izdelave: 1991, Premer kolesa - maks. 10 - 330 mm Širina kolesa 180 mm Modul - maks. 7 Fpodpfsw I Hq Dex Aflob Modul - min. 0,5 Dolžina vpenjanja 420 mm Število zob 10 - 600 Nagibni kot - maks. +/- 45° Število obratov 1100 - 1900 vrt/min Premer brusnega koluta 280 - 350 mm Širina brusnega koluta 84 - 104 mm Teža stroja pribl. 5,1 t Potreben prostor pribl. 4,5 x 6,0 x 2,3 m

Stanje: rabljeno, Leto izdelave: 2002, Wheel diameter - max. 275 mm Module - max. 6 Module - min. 1.5 Control system SINUMERIK 840 C Gear width 5.5 mm Helix angle min. 0 / max. 60° Number of teeth - max. 120 Number of teeth - min. 5 Transmission ratio max. 1:10 Transmission ratio min. 1:1 Workpiece spindle speed max. 110 rpm Cutter head speeds 20 - 110 rpm Total power requirement 100 kW Machine weight approx. 16.7 t Space requirement approx. 5.20 x 2.30 x 2.40 m Integrated deburring unit U-axis / Q-spindle Fjdpfsvxwnwjx Aflspb Chip conveyor Coolant system Electrostatic air cleaner ELBARON No tools No workpiece clamping device

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2002, Funkcionalnost: popolnoma funkcionalen, največja hitrost vretena: 110 obr/min, premer kolesa: 275 mm, TECHNICAL DETAILS Max. Wheel Diameter: 275 mm Module Range: min. 1.5 / max. 6 Tooth Width: 5.5 mm Helix Angle: min. 0° / max. 60° Number of Teeth: min. 5 / max. 120 Fpodpsv Rc Srsfx Aflsb Transmission Ratio: min. 1:1 / max. 1:10 Drive & Control Control System: SINUMERIK 840 C Max. Workpiece Spindle Speed: 110 rpm Cutter Head Speeds: 20 - 110 rpm Total Power Requirement: 100 kW Machine Weight & Dimensions Machine Weight: approx. 16.7 t Space Requirement: approx. 5,200 x 2,300 x 2,400 mm EQUIPMENT - Deburring unit U-axis / Q-spindle - Chip conveyor - Coolant system - Electrostatic air cleaner ELBARON - No tools and no workpiece clamping device included

Stanje: rabljeno, Leto izdelave: 2002,

Stanje: rabljeno, Leto izdelave: 2007, Maximum transmission ratio: 10:1 Number of teeth - min. 3 Number of teeth - max. 200 Tooth height: 20 mm Maximum tooth width: 58 mm Minimum tool diameter: 69.85 mm Fpedevxwnqepfx Aflsb Maximum tool diameter: 230 mm X-axis travel: 325 mm Y-axis travel: 350 mm Z-axis travel: 470 mm Workpiece table - Ø 212.71 mm B-axis: +90.1 / -1° Control: FANUC 160i-MB Total power requirement: 75 kW Machine weight approx. 10,000 kg Space requirement approx. 6.10 x 4.40 x 3.30 m WAGURI With EWAB robot cell (KUKA robot) Without coolant filtration system Fire extinguishing system without CO2 bottles Cooling oil return with various pumps / collecting basin Automatic threading device for A1/B2 axes with measuring probe Clamping device for a pinion shaft External spindle oil cooler Extraction system "pinion shaft"

Stanje: rabljeno, Leto izdelave: 2005, Translation ratio max. 10:1 Number of teeth - min. 3 Number of teeth - max. 200 Tooth height 20 mm Tool diameter min. 69.85 mm Tooth width max. 58 mm Fedpfsvxwgmjx Aflepb Tool diameter max. 230 mm x-axis 325 mm y-axis 350 mm z-axis 470 mm Workpiece table - Ø 212.71 mm b-axis +90.1 / -1° Control SIN 840 D SIEMENS Total power requirement 75 kW Machine weight approx. 10,000 kg Space requirement approx. 6.10 x 4.40 x 3.30 m WAGURI with EWAB loading cell, year of construction 2012 (Linear loader) No coolant filtration system available.

Stanje: delavnici obnovljeno (rabljeno), Leto izdelave: 1991, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 27604, dolžina pomika po osi Y: 170 mm, dolžina podajanja os Z: 200 mm, premer mize: 160 mm, največja hitrost vretena: 600 obr/min, TECHNICAL DETAILS X-axis: 150 mm Y-axis: 170 mm Z-axis: 200 mm Swivel angle: -150/30° Milling unit Max. hob diameter: 130 mm Max. hob length (shank-type cutter): 220 mm Max. module: 3 Cutter length: max. 220 mm Cutter speeds: stepless up to 600 rpm Cutter arbor diameter: 32 mm Table Table diameter: 160 mm Table bore diameter: 63 mm Fedpfev Rdwijx Aflopb Control & Retrofit Control: SINUMERIK 840 D SIEMENS Retrofit: Sinumerik 840 D / Windows XP Pro in 2010 MACHINE DETAILS Total power requirement: approx. 20 kW Machine weight: approx. 10,500 kg Space requirement: approx. 6.8 x 3.7 x 2.85 m

Stanje: dober (rabljeno), Leto izdelave: 2007, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 986003, hitrost brusnega kolesa: 6.000 obr/min, premer orodja: 230 mm, potovalna razdalja osi X: 325 mm, pomik osi Y: 350 mm, pomik po osi Z: 470 mm, TECHNICAL DETAILS Max. transmission ratio: 10:1 Number of teeth: 3 - 200 Tooth height: 20 mm Max. tooth width: 58 mm Control system: SIN 840 D SIEMENS Axes Fsdpfx Asv Rcn Hsflepb X-axis: 325 mm Y-axis: 350 mm Z-axis: 470 mm B-axis: +90.1° / -1° Spindle Grinding spindle speeds: stepless up to 6,000 rpm Workpiece spindle speed: 1,200 rpm Tool Max. tool diameter: 230 mm Min. tool diameter: 69.85 mm Table diameter: 212.71 mm MACHINE DETAILS Total power requirement: 75 kW Machine weight: approx. 10,000 kg Space required: approx. 6.10 m x 4.40 m x 3.30 m Transport dimensions (Machine): 4 x 2.5 x 2.85 m / 11 t Transport dimensions (Water tank): 3.55 x 2.41 x 2.5 m / 1.8 t Transport dimensions (Cooler): 1.5 x 0.8 x 1.1 m / 0.2 t Transport dimensions (Covers): 2.5 x 1.1 x 0.8 m / 0.25 t EQUIPMENT - Coolant filtration system Hoffmann HSF 100 V

Stanje: dober (rabljeno), Leto izdelave: 2001, obratovalne ure: 31.789 h, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 291545, potovalna razdalja osi X: 70 mm, pomik osi Y: 200 mm, pomik po osi Z: 200 mm, premer zobnika: 500 mm, kot vijačnice: 90 °, 3-axis CNC testing machine for fully automatic hard and soft testing of spiral and hypoid bevel gears with an axis angle of 90° TECHNICAL DETAILS Bevel gear analysis: ROTEC T50 GA2 Paint unit: Binks X-axis travel: ±70 mm Y-axis travel: 200 mm Z-axis travel: 200 mm CNC control: GE FANUC Series 160i-M Fsdpfx Ajvrd T Toflspb Technical Specifications Gear diameter: max. 500 mm Pinion diameter: max. 400 mm Ring gear diameter: max. 500 mm Axis angle: 90° Speeds R speed range: 0 – 3,000 rpm T speed range: 0 – 5,000 rpm MACHINE DETAILS Rated power: 30 kVA Machine weight: approx. 6.2 t Space requirements: approx. 3.2 m x 2.5 m x 2.3 m
