Scm Tech 99 L nakup rabljenega (579)

Stanje: rabljeno, SCM TECH 99 L CNC obdelovalni center z rezkalno enoto za ključavnice Stroj je DELOJOČ in pripravljen za demonstracijo Ijdpfx Ahsx H Nndo Aeik iz upokojitve/obrtne delavnice Na voljo na lokaciji mizarstva, kot videno

Stanje: rabljeno, SCM Tech 99L Machining Center Iijdpetxdqcefx Ah Aek Transport dimensions: 4,800 x 2,300 x 2,600 mm – Weight: 2,800 kg

Leto izdelave: 2025, Stanje: novo, Nova stroj Leto izdelave 2025 Oprema in tehnični podatki: L'invincibile SI X - FORMATNA KROŽNA ŽAGA Z DVOJNIM NAGIBOM LISTA 931201 Frekvenca 50 Hz 570348 Predrezalna enota z neodvisnim motorjem 570351 LED osvetlitev predrezalnega območja Iijdpfex Enrxsx Ah Ask 530130 "Full Support & Wireless" 570353 Podaljšek z valjčno progo na paralelni strani 080999 Prosto iz tovarne R01264 L'invincibile SI X izvedba CE 083202 Podstavek 109993 JEZIK STROJA: nemščina 930731 Volt 400 EU 080685 Dodatna embalaža 109999 Standardni varnostni predpisi Številka artikla: SI X Različica: R021401 Razpoložljivost: po dogovoru Lokacija: Flörsheim

Stanje: novo, Leto izdelave: 2024, Working width: 520 mm Cutterhead: Tersa Number of knives: 4 Joiner table length: 2300 mm Tiltable fence: yes Fold-up jointer tables: pneumatic Maximum planing thickness: 250 mm Thickness table height adjustment: electric with position control Planing thickness display: digital Feed speed: 5/8/12/18 m/min Infeed roller: steel Isdjvadxlepfx Ah Asik Outfeed roller: rubber Pressure beam: segmented Table rollers: no Motor power: 7.5 kW Motor brake: yes, automatic Extraction port: 160 mm Machine length: 2300 mm Machine width: 1100 mm Weight: 980 kg

Stanje: rabljeno, Leto izdelave: 2006, · Working area: 2,650 x 1,240 mm · Travel range X-Y: 2,995 x 1,385 mm · Z-axis travel: 200 mm · Clearance height: 180 mm The machine base structure is a monolithic design made of thick-walled steel. It is reinforced with welded triangular plates across the entire machine bed, providing exceptional stability. The use of the triangular shape with a broad base for load-bearing components is the key to long-lasting precision and stability. The layout of the machine allows the user to achieve optimal workflow while requiring minimal floor space. This design gives the processing unit a balanced and secure foundation with excellent load distribution. The moving aggregate carrier is constructed from a solid monoblock. It is positioned in the X direction on prismatically ground guides via recirculating ball carriages. The processing unit itself is mounted on this mobile carrier, also on prismatic, ground guides and recirculating ball carriages. Description of units and accessories (basic version) Drilling unit: Drill head with 12 + 6 spindles · 7 individually activatable vertical spindles in X · 5 individually activatable vertical spindles in Y Isdpex Iwc Sefx Ah Asik · 4 horizontal spindles in X (2+2) · 2 horizontal spindles in Y (1+1) · Speed: 4,000 rpm · Power: 2.2 kW · Grid: 32 mm · Drill holder: M10 with 11 mm locating shoulder Grooving saw unit in X: · Integrated in the drill head · Grooving saw blade up to max. 120 mm diameter Main milling unit (position 2): · Tool holder HSK 63F · Speed 1,500 – 24,000 rpm, steplessly via inverter · Motor power 4.4 kW (6 HP) from 12,000 rpm (S1) · Motor power 6.6 kW (9 HP) from 12,000 rpm (S6) · Right/left rotation · Ceramic bearings · Scope of delivery: 4 pcs. tool holders (right) without collet Tool changer R8L Automatic tool change system for 8 tools. Mounted on the rear aggregate carrier for rapid tool access. · Number of tool places: 8 · Max. tool diameter: 120 mm · Max. tool weight: 4.5 kg · Max. total tool weight: 22 kg · Holder for 1 angle gear · Moves in X-direction Horizontal milling unit (position 1): Horizontal unit with two opposing outputs for milling and grooving. · Speed 9,000 – 18,000 rpm steplessly via inverter · 1 output for collets 3–20 mm (ER32) · 1 output for saw/collet 3–12 mm (ER20) (For saw D=120 mm / bore 50 mm) · Motor power 3 kW (4 HP) · Max. milling diameter front: 20 mm · Max. milling length front: 110 mm · Max. milling diameter rear: 12 mm · Max. milling length rear: 80 mm · Max. saw blade diameter: 100 mm · Saw blade bore (ER32): 50 mm · Saw blade arbor diameter (ER20): 12 mm Work table The work table is designed to guarantee the operator maximum range of motion. The vacuum quick-clamping system provides maximum flexibility with precise positioning and optimal workpiece holding. · 6 rails, 1000 mm, continuously adjustable pneumatically in X · 12 vacuum cups, round, D = 110 mm, continuously adjustable in Y (2 pieces per rail) · 2 stops in X (1 left / 1 right) · 1 stop in Y per rail (total 6 pcs) · The retractable reference stops are CNC-controlled · Pendulum machining standard (2 working zones) --- Other clamping systems available as options --- Axis movement The drive system in X, Y, and Z axes operates via ground recirculating ball screws of the highest precision class. The ball recirculation...

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2003, obratovalne ure: 15.000 h, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 2.500 mm, pomik osi Y: 1.100 mm, pomik po osi Z: 110 mm, hitro pomikanje X-os: 40.000 m/min, hitri pomik os Y: 40.000 m/min, hitri pomik na osi Z: 25.000 m/min, dolžina podajanja os X: 2.700 mm, dolžina pomika po osi Y: 1.200 mm, dolžina podajanja os Z: 180 mm, nazivna (navidezna) moč: 10 kVA, vrtilni moment: 24.000 Nm, proizvajalec krmilnikov: esa, model krmilnika: kvara 6, dolžina obdelovanca (maks.): 2.600 mm, širina obdelovanca (maks.): 1.100 mm, višina obdelovanca (maks.): 110 mm, Rezkalni agregat 6,6 kw HSK 63 F Menjava orodja 7 pozicij Hitra menjava orodja 4 pozicij Vrtalna glava 14 svedrov Pomagala za nakladanje težkih obdelovancev Žaga po osi X 3 KW Vakum črpalka 100m3/min Iiodpfxexvr Uco Ah Aek Delovna miza – dolžina: 2500 mm Delovna miza – širina: 1100 mm Minimalna hitrost vrtenja: 1500 obr/min Maksimalna hitrost vrtenja: 24000 obr/min Maksimalni hodi po X, Y, Z-osi: 2700 x 1300 x 250 mm Število rezkalnih vreten: 1 Moč motorja: 6,60 KW Skupna teža: 2700 kg Dimenzije stroja Dol. x Šir. x Viš.50000 x 2400 x 2500 mm Samo 14700 delavnih ur

Stanje: rabljeno, Ferwood-Kodex: RU0001071 - Zustand: Gebraucht - Kompatible Maschine: CNC SCM - Bei Interesse bieten wir einen Überholungsservice an, bitte kontaktieren Sie uns. Iijdpfx Aeu U D Ahsh Aok

Stanje: rabljeno, Leto izdelave: 2014, Price: On request Isdpfx Ahjx Hwhxs Ajik What are Presale items at Second Owner? Presale items are machines that we sell in their current condition ("as-is"). We have purchased these machines solely based on photos and sell them with the information provided in the listing. Unfortunately, we do not have any additional details, such as exact dimensions or machine specifications. Furthermore, these machines are often not yet in stock and have not been inspected by us. These machines are offered at attractive prices, meaning the prices are lower than usual, but the risk is entirely assumed by the buyer. Please review the information in the listing carefully before making a purchase. If you have any questions, please feel free to contact us! - Machine available from: 2026-03-30 - Year of manufacture: 2014 - Documentation available: No - CE certificate present: Yes - Serial number: AA1/017825 - Number of milling spindles [pcs]: 1 - Type of milling table: Beam table - Boring tool included: Yes - Tool changer stations [pcs]: 12 - CNC documentation available: USB stick Financial Information VAT: The stated price is excluding VAT VAT/Margin Scheme: VAT deductible for businesses Delivery and trade-in possible at any time for all items from the industrial sector Glenn Smeets

Stanje: rabljeno, Leto izdelave: 2004, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: AL1/003895, potovalna razdalja osi X: 2.949 mm, pomik osi Y: 1.353 mm, vhodna napetost: 400 V, Working area: 2500 x 1240 mm Travel length Z-axis: 200 mm Clearance height: 180 mm Drilling unit: Drilling head with 10 + 4 spindles 6 individually selectable vertical spindles in X 4 individually selectable vertical spindles in Y 2 horizontal spindles in X (1+1) 2 horizontal spindles in Y (1+1) Iiedoxxik Hopfx Ah Aek Speed: 4000 rpm Power: 2.2 kW Grid: 32 mm Drill chuck: M10 with 11 mm fitting Extraction port: D=160 mm Milling spindle: Tool holder HSK 63F Speed: 1,500 – 24,000 rpm, infinitely variable via inverter Motor power: 6.6 kW (9 HP from 12,000 rpm (S1)) Right / left rotation Ceramic bearings Preparation for automatic angle head changer Grooving saw unit: Fixed in X-direction (longitudinal) Power: 2.2 kW (3 HP) Speed: 6,000 rpm Max. saw blade diameter: 160 mm Saw blade thickness: approx. 3.2–6 mm Saw blade bore: 30 mm Extraction port: D=200 mm Work table: 4 supports, 900 mm, stepless manual adjustment in X 12 round vacuum suction cups, D=110 mm, stepless adjustable in Y (2 pcs per support) 2 stops in X (1x left / 1x right) 1 stop in Y per support (total 6 pcs) Additional stop on right with roller conveyor for extending X-axis to 3,230 mm (2 clampings) Retractable reference stops are CNC controlled Pendulum processing (2 working zones) Further technical data: Total connected load max.: 16 kW Recommended fuse: 64 A Power supply: 400 V (50Hz) Compressed air: 7 bar System pressure: 10 bar Compressed air consumption: 150 nl/min Central extraction port with valve control: D=250 or D=300 mm Extraction speed: 30 m/sec Air consumption: 3400 m³/h Vacuum: 3000 Pascal Machine weight: approx. 2,700 kg Space requirement: approx. 6,400 x 2,970 mm Loading dimensions: 4,400 x 2,200 x 2,500 mm

Stanje: rabljeno, številka stroja/vozila: 008175, Delovno območje os X: 3100 mm Delovno območje os Y: 1300 mm Delovna površina: Z vakuumskimi konzolami Moč glavnega vretena: 8,5 kW Število nadzorovanih osi: 3 osi Število vrtalnih glav: 17 Število mest za orodje: 18 Iisdpjx A Tb Rsfx Ah Ask

Stanje: rabljeno, Leto izdelave: 2007, Workspace: 2780 x 1140 mm (vertical milling), 2500 x 950 mm (horizontal drilling). Travel X-Y: 2980 x 1271 mm. Z-axis travel: 200 mm. Clearance height: 180 mm. The base structure is a monolithic design made of thick-walled steel, reinforced throughout the entire machine bed by fully welded triangular plates, resulting in extreme rigidity. The triangle shape with a wide base, used for all load-bearing components, is the secret to ensuring lasting precision and stability. The machine layout provides the operator with an optimal workflow while requiring minimal space. This base structure offers the machining unit a balanced and secure foundation with outstanding load distribution. The mobile aggregate support is constructed as a solid monoblock. It travels along the X-axis on precision-ground linear guides by means of recirculating ball bearing carriages. The machining unit is mounted to the mobile support via precision-ground linear guides and ball bearing carriages as well. Description of aggregates and standard accessories: Drilling unit: Drilling head with 10 + 4 spindles · 6 individually selectable vertical spindles in X · 4 individually selectable vertical spindles in Y · 2 horizontal spindles in X (1+1) · 2 horizontal spindles in Y (1+1) · Speed: 4,000 rpm · Power: 2.2 kW · Pitch: 32 mm · Chuck: M10 with 11 mm locating pin · Extraction port: D = 160 mm Vertical milling unit (Position 2) · Tool holder: HSK 63F · Speed: 1,500 - 24,000 rpm, variably adjustable via inverter · Motor output: 4.4 kW (6 HP) from 12,000 rpm (S1) · Clockwise / counterclockwise rotation · Ceramic bearings · Delivery includes: 4 tool holders (right), without collets Tool changer · Side-mounted tool magazine for 7 tools (TR7), fully enclosed to protect against chips · 7 tool stations for HSK 63F holders in sequence · Max. tool diameter: D = 120 mm · Max. weight per holder: 4.5 kg · Max. total tool weight: 20 kg (TR7) · Angle heads can be accommodated Horizontal milling unit (Position 1) Horizontal unit with two opposing outputs for milling and grooving. · Speed: 9,000 - 18,000 rpm, stepless via inverter · 1 output for collet 3-20 mm (ER 32) · 1 output for saw/collet 3-12 mm (ER20) (for saw blade D = 120 mm / bore 50 mm) · Motor output: 3 kW (4 HP) · Max. tool diameter, front milling: 20 mm · Max. tool length, front milling: 110 mm · Max. tool diameter, rear milling: 12 mm · Max. tool length, rear milling: 80 mm · Max. saw blade diameter: 100 mm · Saw blade bore (ER 32): 50 mm · Saw blade spindle diameter (ER 20): 12 mm Worktable Iiodpfx Ahsw Aifzj Aek The worktable is designed to guarantee the operator maximum freedom of movement. The quick vacuum clamping system ensures maximum flexibility for precise positioning and optimal holding of workpieces. · 4 supports, 900 mm, infinitely variable adjustment in X · 8 round vacuum pods D = 110 mm, infinitely adjustable in Y (2 per support) · 2 stops in X (1 left / 1 right) · 1 stop in Y per support (total: 6) · The retractable reference stops are CNC-controlled · Supplied: 4 plug-in adapters for suction pads · Standard feature: pendulum (dual-zone) operation Axis movement The drive system in X, Y, and Z uses ground recirculating ball screws of the highest precision class. The X-axis ball screw is positioned exactly along the centerline...

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2011, obratovalne ure: 13.802 h, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: PRATIX Z2-27, potovalna razdalja osi X: 2.700 mm, pomik osi Y: 1.300 mm, pomik po osi Z: 180 mm, hitro pomikanje X-os: 60 m/min, hitri pomik os Y: 60 m/min, skupna masa: 2.000 kg, hitrost vretena (min.): 24.000 obr/min, število mest v zalogovniku orodij: 10, vhodna napetost: 400 V, vrsta vhodnega toka: trifazni, Oprema: dokumentacija / priročnik, vrtilna hitrost brezstopenjsko nastavljiva, Opis TEHNIČNI PODATKI PRATIX Z2-27 OS Uporabno obdelovalno območje X-Y-Z * 2.700-1.300-180 mm Hod osi X-Y-Z 3.060-1.735-250 mm Vektorska hitrost X-Y 60 m/min DELOVNA MIZA Tip MF aluminijasta raster miza 1.225 - 2.750 Vakuumska črpalka Becker 250m3 BURILNA SKUPINA F12 Vertikalni svedri Št.-obr/min 12 (7X-5Y) – 4.000 FREZALNI MOTOR Iiodpsxgdc Hjfx Ah Aok Moč kW (KM) 7,5(10) Min - max hitrost vrtenja obr/min 1.500 – 24.000 Magazin orodij v mizi Št. pozicij 10 pozicij Nameščena moč KVA 23÷28,5 Skupna teža stroja 2.800Kg Cena brez DDV in orodja

Stanje: rabljeno, Ferwood Code: RU0001121 - Condition: Used - Compatible Machine: CNC SCM - If interested, we offer refurbishment services; please contact us. Iijdpfxsu U D N Us Ah Ajk

Stanje: rabljeno, Leto izdelave: 2013, skupna višina: 2.240 mm, skupna dolžina: 5.240 mm, skupna širina: 2.500 mm, Unladen weight: 2,700 kg Price: On request - Year of manufacture: 2013 - Documentation available: Yes - CE marking present: Yes - CE certificate available: No - Serial number: AA1/017355 - Number of milling spindles [pcs.]: 1 Isdpfx Ahownii Ro Aoik - Milling spindle 1: - Number of controlled axes [pcs.]: 3 - Max. spindle speed [rpm]: 24,000 - Main motor power [kW]: 9.5 - Drilling unit available: No - Horizontal drilling spindles [pcs.]: 6 - Vertical drilling spindles [pcs.]: 12 - Saw unit available: Yes - System/software: SCM Maestro - Working area X [mm]: 3,050 - Working area Y [mm]: 1,250 - Z-axis stroke [mm]: 1,810 - Y-axis max. stroke [mm]: 1,550 - Voltage [V]: 400 - Power consumption [A]: 31 - Transport dimensions: 5,240 mm x 2,500 mm x 2,244 mm (L x W x H) - Transport weight [kg]: 2,700 - Number of transport packages: 1 Financial information VAT: The stated price is exclusive of VAT VAT/Margin taxation: VAT deductible for businesses Delivery and trade-in possible at any time for all industrial equipment Glenn Smeets

Stanje: rabljeno, Leto izdelave: 2011, Funkcionalnost: popolnoma funkcionalen, Ponujamo vam rabljeni CNC obdelovalni center SCM Tech Z2, proizveden leta 2011 in trenutno lociran v Belgiji. Ta stroj za obdelavo lesa ima delovno območje 2700 x 1300 mm, visokohitrostno vreteno s hitrostjo do 24.000 vrt/min ter motor z močjo 7,5 kW, kar zagotavlja natančnost in učinkovitost pri najrazličnejših lesarskih aplikacijah. Ijdpfxexq Hpds Ah Asik Prednosti: Veliko delovno območje. Visoka hitrost vretena. Vsestranska zmogljivost vrtanja in rezkanja. Fleksibilnost pri uporabi in menjavi orodij.

Stanje: rabljeno, Leto izdelave: 2004, Funkcionalnost: popolnoma funkcionalen, moč vretenovega motorja: 6.600 W, število mest v zalogovniku orodij: 7, 3-OSNI STROJ PUMPA ZRAKA 100 M3 Iodpfxewhvwnj Ah Aeik SNAGA MOTORA ELEKTROSPINDLE 6,6 kW ISO 30 prihvat Glodalo + Agregat Pila Broj svrdla (horizontalni + vertikalni) 10 + 4 Spremnik alata 7 komada Automatsko podmazivanje - NE MONITOR 15" SOFTWARE XILOG PLUS Koristi WINDOWS XP Stroj radi kod Prodavatelja, video stroja u radu dostupan na e-mail zahtjev

Stanje: dober (rabljeno), Leto izdelave: 2006, obratovalne ure: 14.000 h, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: AL1/004511, potovalna razdalja osi X: 2.800 mm, pomik osi Y: 1.250 mm, pomik po osi Z: 180 mm, hitro pomikanje X-os: 40.000 m/min, hitri pomik os Y: 40.000 m/min, hitri pomik na osi Z: 25.000 m/min, dolžina podajanja os X: 2.800 mm, dolžina pomika po osi Y: 1.250 mm, dolžina podajanja os Z: 110 mm, nazivna (navidezna) moč: 11 kVA, proizvajalec krmilnikov: ESA, model krmilnika: KVARA 6, dolžina obdelovanca (maks.): 2.900 mm, širina obdelovanca (maks.): 1.250 mm, višina obdelovanca (maks.): 110 mm, skupna višina: 2.700 mm, skupna dolžina: 5.500 mm, skupna širina: 2.500 mm, širina mize: 1.250 mm, višina mize: 900 mm, dolžina mize: 2.750 mm, Working dimension X 2.900mm Working dimension Y 1.240 mm Working dimension Z 180 mm Number of milling spindles 1 Main motor power 6.6 kW Rotation speed max 18.000 rpm Torque support Tool clamping system HSK-F63 Tool changer positions 8 Vertical drilling spindles 12 Horizontal drilling spindles in X 4 Horizontal drilling spindles in Y 2 Groove saw in X-direction Lock recess milling aggregate double-sided Angular head 0-360+0-90 deg. Vector axis Iijdpfx Aswh I Nvoh Ask Cantilever machine Machine table Pod and rail table Number of consoles 6 Vacuum pump Number of vacuum pumps 1 Capacity vacuum pump 100 m³/h Safety device Bumper Interface for .dxf data Control PC control Software SCM XILOG Conformity marking CE mark

Stanje: generalkompletno obnovljen (rabljeno), Leto izdelave: 2012, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: AA1/016854, 3-AXIS DRILLING & MILLING CENTER Brand: SCM Model: TECH Z2 Ref. R0410.01 Serial number: AA1/016854 Year: 2012 (Photos taken prior to overhaul, functional testing & cleaning) MACHINING CAPACITIES: - Maximum workpiece height (thickness): 160 mm - Maximum workpiece length: 2700 mm In twin station mode: 1210 mm Ijdpfev Tzrvjx Ah Aeik - Maximum workpiece width: 1300 mm Motions: - X axis travel: 3060 mm, Y axis: 1735 mm, Z axis: 250 mm - Maximum traverse speeds (vectorial): 60 m/min MACHINE CONFIGURATION: - 6 beams with pneumatic clamping for vacuum pods, e.g. 120x120 or 55x120 mm - Automatic lubrication unit - Spindle aggregates as follows: (X-axis movement by rack and pinion, Y-axis by ball screw; high precision linear guides with automatic lubrication) • Milling/Routing unit, 11 kW (15 HP): - Spindle speed 1500 - 24000 rpm, variable speed, clockwise/counter-clockwise - Tool holder interface: HSK63F, ER32 collet - Onboard magazine for 8 tools - Perimeter dust extraction hood • 18-spindle drilling unit: - 12 independent vertical spindles (8 in X direction, 5 in Y direction) - 6 horizontal spindles (4 in X, 2 in Y) - Center distance between spindles 32 mm for M10/Ø11 mm drill bits - Rotation speed 4000 rpm - Pneumatic vertical stroke 60 mm - Perimeter dust extraction hood • Integrated grooving saw-milling group: - Blade Ø120 mm, thickness 6 mm - Speed 6000 rpm - Pneumatic vertical stroke 60 mm • Mobile operator panel on support arm with control PC: – Operating System: Windows XP – 17" LCD screen – Ethernet connection – Machine interface software: Xilog and Maestro OTHER FEATURES: - Main electrical supply: 400V, 3-phase+N+PE, 50Hz, IN37A - Electrospindle motor: 12 kW - Drilling/grooving motor: 2.2 kW - 1 vacuum pump 2.4 kW: 90-108 m3/h - Pneumatic supply >=7 bar - Extraction: Extraction ports: 2x Ø150 mm (1 port Ø200 mm using installed splitter) Recommended extraction: 30 m/s – 3400 m3/h - CE compliant machine with safety area and light curtain safety barrier Operating dimensions with safety area: see documentation extracts Transport dimensions: to be specified during equipment preparation Estimated total weight: 2200 kg Machine supplied with instruction manual and software, spare parts list, electrical and pneumatic diagrams. Please contact us for the supply of consumables, accessories, and/or extraction systems. Machine overhauled, brought up to compliance, with quality control and dynamic functional testing. Supplied with 3-month warranty & statement of CE compliance. Available from stock (subject to prior sale). Price ex works. Delivery and additional services on request.

Stanje: rabljeno, Leto izdelave: 2007, used, top specification including new outfeed rollers with Tersa cutterblock large planing height Manufacturer: SCM Model: S630 E-L'invincibile Year of manufacture: 2007 Machine No.: AB/184684 GS tested CE type certified GS wood dust tested Motor power: reinforced 7.5 kW Planing width: approx. 630 mm Planing height: approx. 300 mm Table feed rollers: 2 adjustable Segmented pressure bar Segmented infeed roller Rubber outfeed rollers: 2x new Feed speed up to 20 m/min, stepless Number of knives: 4 automatic motor brake Knife system: Tersa reversible knives digital display for planing height electric height adjustment dust extraction port: 160 mm Space requirement: approx. 1400 x 1000 x 1200 mm Iodpfxewqg R De Ah Aeik Weight: approx. 1000 kg Location: 97447 Gerolzhofen; free loaded, unpacked Handover in as-inspected condition, without guarantee or warranty.

Leto izdelave: 1999, Stanje: potreben popravila (rabljeno), številka stroja/vozila: AL 1 / 99, Connection: 9.0 kW, 400 V Compressed air connection: 6 bar Iiedpfx Asiiy E Toh Ask Extraction: 1 x 160 mm, 3400 m³/h, 30 m/sec Compressed air consumption: 200 NL/min Drilling spindles: 9 units / 3000 rpm Grooving cutter: 1 unit / 6000 rpm Milling spindle: 1 unit / 16000 rpm Dimensions (LxWxH): 4050 x 2050 x 1900 mm Weight: approx. 1500 kg Max. panel thickness: 55 mm

Stanje: delavnici obnovljeno (rabljeno), 3-AXIS BORING & MILLING CENTER WITH FIXED ANGLE DRIVE AND DUAL HORIZONTAL SPINDLES Iodpjw E Hb Sefx Ah Aoik Brand: SCM Model: TECH Z 2 27 C Year: 2007 (Machine offered in functional, refurbished condition, without warranty) TECHNICAL SPECIFICATIONS: - Machining surfaces: Between side stops in X: 2,650 mm Electro-spindle travel in X: 2,903 mm Electro-spindle travel in Y: 1,240 mm Vertical boring heads travel in Y: 1,018 mm - Max. panel size for dual-position machining: 1,180 mm - Max. panel thickness: 180 mm - X-Y axes vector speed: 54 m/min - Z-axis speed: 11.5 m/min - Z-axis travel: 200 mm - Main motor power: 2.2 kW (3 hp) - Spindle speed: 4,000 rpm - Spindle nose: M10 - Machine weight: approx. 2,800 kg COMPONENTS: MACHINING TABLE 4 beams for vacuum pod supports L=1,000 mm (for round automatic pods with aluminum body), 2 per beam 2 additional universal supports H=25 mm 4 vacuum pod supports for contouring VACUUM PUMP, capacity = 100 m³/h Centralized extraction conveyor Centralized automatic lubrication for X & Y axes Pneumatic loading support device for tables L=1,000 mm MILLING: HSK 63 electrospindle with upgraded 7.5 kW power - Spindle speed 1,500/24,000 rpm, controlled by inverter - CW and CCW rotation selectable via CNC - (1) HSK 63 cone with straight toolholder included - Collet nut not included (tools excluded) Rear tool changer magazine, 8 positions: R8L - Can hold 8 tools, each Ø120 mm max - Each toolholder pocket supports up to 4.5 kg - Max. combined weight: tools + toolholders in R8L magazine: 22 kg 2-OUTLET HORIZONTAL UNIT for MILLING and GROOVING: - Spindle speed: 9,000/18,000 rpm - Motor power: 3 kW (4 hp) - Front milling tool: Ø20 mm max - Usable length (front): 110 mm - Rear milling tool: Ø12 mm max - Usable length (rear): 80 mm - Saw blade: Ø100 mm BORING: 12 independent spindles for vertical boring (7 along X, 5 along Y) 3 independent heads with 2 spindles each for horizontal boring: * 2 heads in "X" direction (64 mm center distance) * 1 head in "Y" direction INTEGRATED OPERATING UNIT for FIXED saw blade, for grooving in X direction - Saw blade speed: 4,000 rpm - Motor power: 2.2 kW - Saw blade: Ø120 mm max - Compressed air consumption: 150 nl/min - Extraction port: Ø160 mm PC-OFFICE (Hardware configuration) - Windows XP operating system - 15" CRT color monitor - QWERTY keyboard - INTEL CELERON 2 GHz Processor - 40 Gb hard disk - 128 Mb RAM - 3.5" floppy disk drive 1.44 Mb - 52x CD-ROM drive (Machine offered in functional, refurbished condition, without warranty)

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2001, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 5.100 mm, pomik osi Y: 2.400 mm, višina obdelovanca (maks.): 300 mm, število mest v zalogovniku orodij: 12, TECHNICAL DETAILS Working Area Working area: 5,100 x 2,400 mm Workpiece thickness: 300 mm Spindle and Tool Changer Electrospindle: 1 unit, 10 HP, HSK Tool magazine: 12 positions, carousel type, mounted on Z-carriage Drilling Head Vertical spindles (independent): 7 Preparation for horizontal spindle in X-direction: 1 independent spindle with dual output (pre-installed) Vacuum Vacuum pumps: 3 units Capacity per pump: 250 m³/h Unloading Unloading system: automatic with steel mesh conveyor belt EQUIPMENT - 10 HP HSK electrospindle - Tool magazine with 12 positions, carousel type on Z-carriage - Drilling head with 7 vertical spindles - Preparation for horizontal X-axis drilling spindle with dual output - 3 vacuum pumps, each with 250 m³/h capacity - Automatic unloading system with steel mesh conveyor belt - CE safety standard Iiodpfxswmczqs Ah Ask

Stanje: rabljeno, Leto izdelave: 2014, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 1.800 mm, pomik osi Y: 3.000 mm, pomik po osi Z: 700 mm, dolžina obdelovanca (maks.): 2.900 mm, skupna višina: 3.000 mm, skupna dolžina: 5.000 mm, skupna širina: 2.500 mm, širina mize: 1.400 mm, višina mize: 400 mm, dolžina mize: 1.800 mm, skupna masa: 5.200 kg, največja hitrost vretena: 18.000 obr/min, moč vretenovega motorja: 7.400 W, nos vretena: 4, število vreten: 2, vhodna napetost: 380 V, vrsta vhodnega toka: trifazni, Oprema: dokumentacija / priročnik, CNC stroj z dvema mizama in eno glavo, ki nosi dve vreteni, vsako s po dvema rotacijskima orodjema (skupaj 4 orodja). Mizi lahko delujeta neodvisno za večjo hitrost ali sinhrono kot ena dolga miza (2900 mm). Skupaj je na voljo 6 prijemal, ki jih lahko namestite po želji. Prijemala so primerna za obdelovance do 100x100 mm. Pri delu na dveh mizah je največja dolžina kosa na vsaki 1400 mm. Priložena je tudi odstranljiva vakuumska miza z zmogljivo vakuumsko črpalko. Stroj je v delujočem stanju in še vedno obratuje v naši tovarni. Iisdpfx Ajxyh Dheh Aok Priložena je CAM programska oprema „TCAS“.

Stanje: rabljeno, Leto izdelave: 2010, 5-axis machining center with nesting table Numerical control with OSAI software Axis travel (X, Y, Z) mm: 4950, 2050, 1000 Working area on X-axis mm: 4250 Working area on Y-axis mm: 1560 Working area on Z-axis mm: 800 FT multifunctional full-area nesting work table no. 1 PRISMA 5-axis electrospindle, 12 kW (16 HP), 900 – 24,000 rpm, rotation directions SX / DX Automatic tool changer with 12 positions, HSK-F 63 type taper * No. 12 tools diameter 80 mm * No. 6 tools diameter 160 mm * Max. tool diameter mm: 250 * Maximum weight per tool: 4 kg * Maximum weight in the magazine: 24 kg Drilling head with 9 spindles arranged as follows: - No. 5 vertical spindles - No. 4 horizontal star spindles * Spindle pitch mm: 32 Iijdpfx Ahswdvr Rj Ajk * Rotation speed rpm: 4000 * Motor power kW: 2.2 Safety and protection system with light barriers and safety fencing Automatic lubrication system Air conditioning for the control cabinet No. 2 vacuum pumps, each with 250 m³/h Accessories and tools available separately Overall dimensions mm: 7865 x 4200 x 4000 TECHNICAL DETAILS MUST BE VERIFIED

Stanje: dober (rabljeno), Leto izdelave: 1991, maximum planing width 520 mm maximum planing height 200 mm 4-knife cutterblock slotted table lips Iiodpfjiwi Ezex Ah Aek electric height adjustment with mobility kit with knife setting gauge
