Gildemeister Nef 560 nakup rabljenega (243)

Stanje: dober (rabljeno), Leto izdelave: 1984, Funkcionalnost: popolnoma funkcionalen, Swing diameter over bed: 560 mm Swing diameter over cross slide: 250 mm Spindle bore: 65.3 mm Max. power: 15 kW Speeds: 11.2 – 2,240 rpm Centre distance: 1,000 mm Quill diameter: 80 mm Gedpfx Afsvn Rlzsqoil Quill taper: MT 5 Including chip conveyor Including complete documentation

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2013, obratovalne ure: 7.100 h, Funkcionalnost: popolnoma funkcionalen, stružna dolžina: 650 mm, premer struženja nad prečnim suportom: 350 mm, premer struženja: 385 mm, hitrost vretena (min.): 4.500 obr/min, izvrtina vretena: 67 mm, potovalna razdalja osi X: 255 mm, pomik po osi Z: 800 mm, For sale: Used DMG NEF400 V3 5th Generation ISM 2-axis universal lathe with C-axis. Travel distance: X: 255 mm Z: 800 mm Swing diameter over bed: 385 mm Giedpexzqnrsfx Afqjl Maximum swing: 350 mm Turning length: 650 mm Equipment: - Main spindle with integrated spindle motor - Speed: Max. 4,500 rpm - Drive power: 8.0 / 11.5 kW (100/40% duty cycle) - 12-position disc turret VDI30, 6 driven positions - C-axis and spindle brake (hydraulic) - Automatic tailstock, MK4 taper, Travel: 680 mm - CNC control Siemens 840D Solutionline with ERGOline Control, Sinumerik Operate, and ShopTurn 3G - Operating system: Linux - Technology cycle for applying alternating spindle speed for vibration-critical setups - Manual tool measurement system in work area - Hydraulic power unit - Coolant spray gun - Mechanical oil mist separator - Reinforced coolant pump, 12 bar, 23 l/min - Chip conveyor, discharge height 1,250 mm to the right - Bar machining package including: - Workpiece pick-up device with conveyor to the left for parts max. 65 mm diameter, 150 mm length, weight up to 3 kg - Hollow chucking device, draw tube inner diameter max. 67 mm - Interface for bar loader magazine - Foot switch for tailstock activation - Hydraulic 3-jaw chuck SMW-AUTOBLOK RMS sensor (Relocation Machine Security) Machine available immediately! Machine is ready for operation! We will load the machine for you! Transport can be arranged upon request!

Stanje: dober (rabljeno), Leto izdelave: 2006, Upravljanje MANUAL PLUS 4110 Giodpfx Ajx Tg T Refqjl

Stanje: rabljeno, Leto izdelave: 2006, Technical details: Swing diameter over bed: 500 mm Swing diameter over cross slide: 290 mm Turning length: 850 mm Distance between centers: 850 mm Longitudinal travel (Z axis): 900 mm Cross travel (X axis): 260 mm Control: Manuaplus 4110 Spindle speed: 10 - 3000 / 2x stepless rpm Spindle torque: 920 Nm Spindle bore: 70 mm Cross travel (X axis): 8 m/min Longitudinal travel (Z axis): 10 m/min Operating hours (machine on): approx. 34,600 h Tailstock taper ISO: MT 5 Tailstock quill stroke: 180 mm Total power requirement: 24 kVA Machine weight approx.: 5.2 t Machine dimensions approx. (LxWxH): 2.2 x 3.2 x 1.9 m Gjdpfowtct Hjx Afqeil Multifix toolholder size C 3-jaw chuck Ø 250 mm Chip tray Manual hour counter Live center in tailstock Operation via control panel and monitor Accessories: 4-jaw chuck Ø 250 mm with internal jaws Various chuck keys Machine lighting 8x leveling pads 4x wedge lifters Various pairs of jaws 1x steady rest Ø 100 mm, closed type

Leto izdelave: 1996, Stanje: pripravljen za uporabo (rabljen),

Stanje: rabljeno, Leto izdelave: 1987, Drehdurchmesser max. 400 mm Drehlänge 1.000 mm Steuerung EPL 2 Umlaufdurchmesser über Bett 400 mm Umlaufdurchmesser über Planschlitten 225 mm Verfahrweg - x 260 mm Verfahrweg - z 1.040 mm Drehzahlbereich - Hauptspindel 20 - 4.000 min/-1 Antriebsleistung - Hauptspindel 11 kW Max. Drehmoment 75 Nm Spindelbohrung 72 mm Futterdurchmesser 185 mm Giedpfx Afox Sy Uroqel Spindelkopf 140H5 Spindeldurchmesser im vord. Lager 100 mm Anzahl der Werkzeugplätze 12 pos. Pinolendurchmesser 80 mm Pinolenhub 100 mm Reitstockaufnahme MK 4 Pinolendruck max. 800 daN Eilgang in X-und Z-Richtung 10 m/min Vorschubgeschwindigkeit x: 5 m/min. Vorschubgeschwindigkeit z: 5 m/min. Vorschubkraft x: 500 daN Vorschubkraft z: 800 daN Gesamtleistungsbedarf 29 kW Maschinengewicht ca. 4,0 t Raumbedarf ca. 4,6 x 2,1 x 2,0 m CNC - Drehmaschine GILDEMEISTER - NEF CT 40

Stanje: rabljeno, Leto izdelave: 2001, Funkcionalnost: popolnoma funkcionalen, širina na sredini: 1.000 mm, premer struženja nad ležiščem sani: 500 mm, For sale is a cycle-controlled lathe from Gildemeister, model NEF 520 K. The machine is fully functional; the guides show some wear but are still operational. Technical Specifications: Gildemeister Universal Lathe NEF 520K Year of manufacture: 2001 Control: Siemens Touch Panel Swing diameter over bed: 500 mm Swing diameter over cross slide: 290 mm Cross slide travel: 260 mm Centre distance: 1000 mm Drive power: 12 kW 1st gear range: 8 – 750 rpm 2nd gear range: 32 – 3000 rpm Quill diameter: 80 mm Quill taper: MK5 Quill stroke: 180 mm 3-jaw manual chuck: Ø250 mm Giedpfx Astrmrxefqol 4-jaw manual chuck: Ø250 mm Toolholder: Multifix size C Steady rest with jaws and rollers, guiding diameter: 10 – 115 mm On request and at extra cost, loading and transport can be arranged. All prices are subject to VAT. Inspection possible by appointment. Contact us—our team will be happy to assist you. Trade-in or exchange possible! Machinery Purchase / Sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MORE. Do you need a high-quality yet affordable metalworking machine for your production? Or do you want to sell yours?

Stanje: dober (rabljeno), Leto izdelave: 1989, obratovalne ure: 64.136 h, Centre height: 350 mm Turning length: 1000 mm Gijdpfx Afjvr Eh Eeqsl Max. swing diameter over bed/ways cover: 600 mm Max. swing diameter over cross slide: 360 mm Spindle bore: 107 mm Speed range: 16 – 3,150 rpm Feed range, longitudinal and facing: 0.5 – 5,000 mm/min Rapid traverse, longitudinal + facing: 9 m/min Main drive: 30 kW Machine dimensions with chip conveyor (L x W x H): 5,400 x 2,200 x 2,000 mm Weight: 6,400 kg Accessories / Special Features: • CNC control GILDEMEISTER EPL 2 with TFT screen General Description: CNC manual input control system with program input via function and numeric keypad. All information is entered in dialogue with the screen. Integrated menu navigation and plain text display of all functions. Control keyboard, screen, and handwheel are housed in a separate chip protection cover. The EPL control offers the following features: Programs can be entered and edited directly by the operator via the EPL control without manual program preparation. NC programs in ISO/EIA format can be entered, output, or directly input manually via the serial interface RS 232. Machining cycles: Turning cycles for longitudinal, facing, and contour turning, including stock allowance. Thread cutting. Undercuts as per DIN 509 Form E and F and DIN 76, grinding allowance programmable. Axial and radial grooves according to DIN 471 and 472, including bottom finishing. Radii 90° and chamfers 45°. Automatic cutter radius compensation for cycles, undercuts, grooves, radius, and chamfering. Programming: Block-oriented, metric/inch, diameter in absolute input, radius in incremental input, full circle programming, subprogram technique, skip levels for program sections. Zero offset. Operating mode selection via menu. Program input and output: Menu-guided dialogue with operator prompts or direct dialogue. • Hydraulic 3-jaw chuck Ø 315 mm with hollow spindle Ø 80 mm • Hinged belt chip conveyor • 12-station VDI 40 turret, 6 standard tool stations + 6 driven tool stations • Coolant system • RS 232 interface • Electronic handwheel • Electric footswitch for 3-jaw chuck and tailstock quill • Lighting • 12 pcs. various standard tool holders (details to be discussed on site) Overhauled servo drive for main spindle, 06/2025 Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Stanje: zelo dobro (rabljeno), Leto izdelave: 2008, Funkcionalnost: popolnoma funkcionalen, TECHNICAL SPECIFICATIONS: CNC: Siemens 840D powerline _ Working Area - Maximum turning diameter over bed: 400 mm - Maximum turning diameter over cross slide: 270 mm - Turning length: 650 mm Gsdpox Ihn Esfx Afqoil - Cross travel (X): 220 mm - Longitudinal travel (Z): 700 mm _ Main Spindle - Spindle head Ø according to DIN 55026 A (outer bolt circle): A6 - Spindle Ø in front bearing: 90 mm - Spindle bore: 65 mm - Taper in spindle nose: metric 72 (MT5) - Drive power 40/100% duty cycle: 15/12 kW - Max. torque 100% duty cycle: 400/320 Nm - Spindle speed: 4,000 rpm _ Cross Slide X/Z - Cross travel X: 220 mm - Longitudinal travel Z: 700 mm - Ball screw X/Z (diameter x pitch): 32×5 mm - Rapid traverse speed X/Z: 15 m/min - Feed force X/Z: 3/6 kN _ Tool Turret - Number of tool stations, direct mount: 8 - Tool shank cross-section: 20×20 mm - Tool disk wrench opening: 220 mm - Boring bar shank diameter: 25 mm _ Tailstock - Maximum quill force: 680 daN - Centre: MT 4 - Quill diameter: 65 mm - Quill stroke (hydraulically actuated): 40 mm _ Coolant System - Capacity: 500 l - Pump power: 1.20 kW - Flow rate: 37 l/min - Pressure: 1.9 bar - Tank capacity: 25 l _ Electrical Requirements - Connected load: 22 kVA - Operating voltage: 400 V - Frequency: 50 Hz - Protection (slow-blow/VDE 0100) required: 35 A - Voltage fluctuation at 400 V: +6% / −10% _ Dimensions and Weight - Dimensions (L×W×H, incl. chip conveyor): 2,100 × 1,750 × 1,710 mm - Machine weight (without chip conveyor): approx. 2,800 kg _ Year of manufacture: 2008

Stanje: delavnici obnovljeno (rabljeno), Leto izdelave: 2003, Univerzalni stružnica GILDEMEISTER NEF 320 K S krmilnikom Siemens SINUMERIK 810 DE (SIMATIC PANEL TOUCH SCREEN) Leto izdelave: 2003 Vretenina odprtina: 52 mm Razdalja med konicami: 750 mm Obhodni premer nad posteljo: 320 mm Obhodni premer nad prečnim suportom: 150 mm Gedpfexn Ar Aox Afqoil Prečni pomik: 185 mm Območje vrtljajev: 14 – 3550 min⁻¹ brezstopenjsko S sledečo opremo: Drsna zaščita z notranjo osvetlitvijo Multifix nosilec orodja z 2 vložkoma 3-čeljustna glava SCHUNK ROTA plus Ø 200 mm 2 kompleta mehkih čeljusti Naprava za dovajanje hladilne tekočine Pištola za izpiranje ostružkov 6 strojevih nog Navodila za uporabo Stroj je v zelo dobrem stanju!!

Leto izdelave: 1990, Stanje: pripravljen za uporabo (rabljen), Na voljo je CNC stružnica Gildemeister. Premer vrtenja nad ležiščem/vozičkom: 600 mm / 360 mm, dimenzije ležišča X/Y: 350 mm / 450 mm, dolžina vozička: 620 mm, širina vozička: 250 mm, pot vozička: 1100 mm, premer vpenjalne glave: 315 mm, premer vretena: 107 mm, premer osi vretena: 140 mm, moč vretena: 30 kW, navor: 950 Nm, število vrtljajev: 3150 obr/min, hitro premikanje X/Z: 10 m/min / 5 m/min. Premer konjička: 100 mm, hod konjička: 180 mm, maks. pritisk konjička: 1200 daN, dolžina struženja: 1000 mm. Mere stroja X/Y/Z: cca. 4350 mm / 2050 mm / 2000 mm, teža: cca. 6400 kg, delovnih ur: 49811 h. Na voljo je dokumentacija. Možen je ogled na lokaciji. Gisdpfx Aox R Duajfqsl

Stanje: rabljeno, Leto izdelave: 1996, Swing diameter over bed: 710 mm Swing diameter over cross slide: 420 mm Turning length: 2000 mm Control system: Manual Plus 3110 Heidenhain Spindle bore: 92 mm Main spindle speeds: 16 - 1800 rpm Cross slide travel: 385 mm Spindle nose according to DIN 55027 - size 11 Spindle diameter at front bearing: 140 mm Drive power at 100% duty cycle: 22.00 kW Gedexxmiyopfx Afqjil Spindle torque at 100% duty cycle: 2750 Nm Feed rate X/Z axis: 1 - 5000 mm/min Rapid traverse X axis: 6.00 m/min Rapid traverse Z axis: 8.00 m/min Tailstock quill taper: MK 5 Quill stroke: 210 mm Quill diameter: 110 mm Total power requirement: 40.00 kW Machine weight approx.: 5.60 t Space requirement approx.: 5.00 x 3.00 x H2.50 m With chip conveyor

Stanje: dober (rabljeno), Leto izdelave: 2007, obratovalne ure: 14.029 h, Funkcionalnost: popolnoma funkcionalen, premer struženja nad prečnim suportom: 270 mm, stružna dolžina: 650 mm, premer struženja: 400 mm, izvrtina vretena: 65 mm, največja hitrost vretena: 4.000 obr/min, For sale is a CNC lathe from the manufacturer Gildemeister, model NEF 400. The machine is in good condition, immediately ready for operation, and fully functional. Technical specifications: Year of manufacture: 2007 Control unit: Heidenhain CNC Pilot 4290 Operating hours: 14,029 h X-axis (cross travel): approx. 220 mm Z-axis (longitudinal travel): approx. 700 mm Max. turning diameter: approx. 400 mm Max. swing diameter over bed: 400 mm Max. swing diameter over cross slide: 270 mm Max. turning length: 650 mm Spindle bore: 65 mm Speed range: 0 – 4,000 rpm Drive power (100% / 40% duty cycle): 12/15 kW Max. torque: 400 Nm Number of tool positions: typically 8 Toolholder: VDI 30 Tailstock travel: 680 mm Tailstock quill: MK 4 Clamping force: approx. 6.8 kN (hydraulic) Space requirements (L x W x H): approx. 2.5 x 1.7 x 1.8 m Machine weight: approx. 2.8 t Chip conveyor is included in the offer. Accessories such as toolholders are not included in the offer but can be offered separately. Gsdpfewig R Iex Afqsil Transport and loading can be organized across Europe at additional cost, upon request. All prices are plus VAT. Inspection possible by prior appointment. Please contact us, our team will be happy to assist you. Trade-in or exchange possible! Machinery purchase / sales BUYING / SELLING OF PRODUCTION & METALWORKING MACHINES, AND MUCH MORE. Do you need a high-quality yet affordable metalworking machine for your production? Or would you like to sell yours? For further information or contact options, please visit our website.

Stanje: rabljeno, Leto izdelave: 2008, Funkcionalnost: popolnoma funkcionalen, Oprema: dokumentacija / priročnik, vrtilna hitrost brezstopenjsko nastavljiva, Stružnica DMG Gildemeister Tip: NEF 600 Gijdpfjx Ivz Tsx Afqel CNC: DMG Siemens 840D Powerline Leto: 2008 Glavne tehnične značilnosti Obdelovalne zmogljivosti: Največji premer vrtenja: 600 mm (nad posteljo stroja). Razdalja med konicama: približno 1.200 mm do 1.250 mm, odvisno od konfiguracije. Premer obdelave nad prečnim drsnikom: 410 mm. Vreteno: Hitrost vrtenja: do 3.000 o/min. Premer vretena: 90 mm. Moč motorja (40/100 % ED): 24 kW / 18 kW (nekatere različice do 36,5 kW). Osi in orodje: Revolver: običajno 8 pozicij (VDI 40). Hodi (X / Z): 320 mm / 1.250 mm. Hitri pomiki: 15 m/min. Dimenzije in teža: Skupna teža: približno 5.000 kg (brez transportnega traku za ostružke). Približne mere: 3,6 x 2,1 x 1,9 m.

Stanje: rabljeno, Leto izdelave: 1999, Krmiljenje Heidenhain. Razdalja med konicama: 1400 mm. Teža stroja: cca 3,6 t. Ročni koles je v okvari. Gjdpfx Afow Syd Seqoil

Stanje: delavnici obnovljeno (rabljeno), Leto izdelave: 2002, Ciklično vodeni stružnica GILDEMEISTER NEF 320 Z upravljalnikom MANUAL PLUS 4110 Leto izdelave: 2002 Vrtina vretena: 50,8 mm Razdalja med konicama: 750 mm Premer nad ležiščem: 320 mm Premer nad sani: 150 mm Višina konice: 160 mm Območje vrtljajev: 10 – 4000 vrt/min brezstopenjsko Z naslednjo dodatno opremo: Zaščitni drsni pokrov z notranjo osvetlitvijo Držalo za orodje Multifix z 2 vložkoma Tročeljustna glava Schunk ROTA – S plus Ø 200 mm 2 kompleta mehkih čeljusti ICP programsko določanje konture Gijdpfxoxn Apbe Afqol Konjiček z izvlečno vrtalno pušo Posoda za odrezke Naprava za dovajanje hladilne tekočine Pištola za izpiranje odrezkov 6 kos strojevnih nogic Navodila za uporabo

Stanje: dober (rabljeno), Leto izdelave: 1999, obratovalne ure: 42.733 h, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 01500001111, stružna dolžina: 1.500 mm, premer struženja: 500 mm, izvrtina vretena: 70 mm, največja hitrost vretena: 2.800 obr/min, hitrost vretena (min.): 8 obr/min, skupna masa: 3.200 kg, Generalno prenovljeno s strani Gildemeister Bielefeld leta 2010 Premer struženja 500 mm Premer nad prečnim suportom Ø 290 mm Dolžina struženja 1.500 mm Območje vrtljajev 8 - 2.800 min⁻¹ s tremi stopnjami menjalnika Vretenina odprtina cca Ø 70 mm Gsdpfxexx Uqro Afqeil Trivpenjalno vpenjalo Ø 250 mm proizvajalca Röhm Konjiček pinola MK4

Stanje: zelo dobro (rabljeno), Swing diameter over bed 212 mm Distance between centers 750 mm Spindle speeds 10–4,000 rpm Control: HEIDENHAIN Manual Plus Various accessories Gijdpfoud Nb Isx Afqol MARCELS MASCHINEN CH

Stanje: rabljeno, Leto izdelave: 1999, Swing diameter 500 mm Turning length 1500 mm Control system Manual Plus Spindle bore diameter 70 mm Speed range 8 - 2800 rpm Number of gearbox stages 3 Max. swing diameter over cross slide 290 mm Spindle nose DIN 55027 Size 8 Toolholder type C Tailstock quill stroke 180 mm Machine weight approx. 3.2 t Dimensions (L x W x H) 3.0 x 1.8 x 1.8 m Machine description: This machine is suitable for turning chuck and shaft workpieces. Standard grades of steel, cast iron, copper, aluminium, brass, gunmetal, and machinable plastics can be machined on this lathe. --> N.E.F. plus concept The machine is supplied as standard with the following equipment: - Cycle control - AC main drive - Compound slide with AC drive and control panel - Tailstock with manual clamping and centering sleeve - Coolant supply - Manual chip guards - Chuck guard - Quick-change toolpost Hahn & Kolb Multifix C - Reduction bush for the spindle Accessories as per images: - 2 steady rests - Various chuck jaws - Hahn & Kolb Multifix type C - Assorted turning tool holders Technical data: Working area: - Swing over bed: 500 mm - Swing over cross slide: 285 mm - Chuck Ø 250 (315) mm Giedpsub Amlofx Afqel - Cross slide: 260 mm - Distance between centers: 1000/1500 mm Spindle: - Spindle nose DIN 55027: size 8 - Spindle bore diameter: 70 mm - Spindle nose hollow taper: 80 metric - Spindle diameter at front bearing:

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2000, obratovalne ure: 60.334 h, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 01510000031, izvrtina vretena: 70 mm, stružna dolžina: 1.350 mm, premer struženja: 500 mm, širina na sredini: 1.350 mm, največja hitrost vretena: 3.000 obr/min, Brez minimalne cene – zagotovljena prodaja najvišji ponudbi! Rok plačila stroja je 20.11.2025! Oddaja ponudbe vas zavezuje k pravočasnemu prevzemu med 01.12.2025 in 05.12.2025! TEHNIČNI PODATKI Dolžina struženja: 1.350 mm Premer struženja: 500 mm Premer obrata nad prečnim suportom: 290 mm Premer obrata nad ležiščem: 500 mm Premer vpenjalne glave: 250 mm Maks. hitrost vretena: 3.000 min⁻¹ Premik prečne osi: 260 mm Razdalja med konicama: 1.350 mm Godpfjxm Slcsx Afqsil Glava vretena: 8 Premer vretenine: 70 mm PODATKI O STROJU Krmiljenje: HEIDENHAIN Dimenzije in teža Dimenzije (D x Š x V): 3.000 x 1.800 x 1.700 mm Skupna teža: 4.000 kg Električni podatki Tip vhodnega toka: trifazni Obratovalna napetost: 400 V Frekvenca: 50 Hz Nazivni tok: 25 A Priključek: 14 kVA Delovne ure: 60.334 h

Stanje: rabljeno, Leto izdelave: 2001, Premer vpenjalne glave 250 mm Obratovalni premer nad posteljo 500 mm Obratovalni premer nad saneh 290 mm Razdalja med konicami 850 / 1350 mm Krmiljenje Heidenhain Teža stroja pribl. 2.700 t Dimenzije pribl. 2.900 x 1.953 x 1.825 m Veliko dodatne opreme Gjdpfx Aow Syc Isfqeil Dva luneta Menjalnik izven funkcije

Stanje: delavnici obnovljeno (rabljeno), Leto izdelave: 2005, Cycle-controlled lathe GILDEMEISTER NEF 520 Godpsuda Tnefx Afqsil With MANUAL PLUS 4110 control system Year of manufacture: 2005 Spindle bore: 70 mm Distance between centers: 1000 mm Swing over bed: 500 mm Swing over cross slide: 290 mm Center height: 250 mm Speed range: 10 – 3050 rpm, stepless Comes with the following accessories: Sliding guard with interior lighting 8-station Sauter turret VDI 30 with powered tools 10 pcs. VDI 30 tool holders 2 pcs. driven tools VDI 30 Coolant system 3-jaw chuck SCHUNK ROTA Ø 250 mm ICP contour programming Tailstock with extendable quill Chip tray Operating manuals

Stanje: dober (rabljeno), Leto izdelave: 2001, Gildemeister NEF 520 CNC Lathe TECHNICAL DATA Working Area Swing diameter over bed: 500 mm Swing diameter over cross slide: 290 mm Chuck diameter: 250 mm Cross slide travel: 260 mm Distance between centers: 850 / 1350 mm Main Spindle Spindle nose: DIN 55027 Size: 8 Spindle bore diameter: 70 mm Spindle taper: metric 80 Spindle diameter at front bearing: 120 mm Main Drive AC Drive power: 12 kW Max. torque: 920 Nm Speed range: 10 – 3000 rpm Gear stages: 2 Selectable speeds: Stepless Feed Drive X-axis feed force: 5000 N Z-axis feed force: 10000 N X-axis rapid traverse: 8 m/min Z-axis rapid traverse: 10 m/min Tool Holder Multifix; Size: C Tailstock Quill diameter: 80 mm Quill stroke: 180 mm Quill taper: MT5 Dimensions L x W x H: 2900 x 1953 x 1825 mm Weight: 2700 kg SCOPE OF DELIVERY Including (not limited to): Gisdpfx Aowftviefqel - Gildemeister lathe - SMW Autoblok Hi-Grip high-precision chuck - Chuck jaws - Multifix tool post - Complete operating documentation - Full scope of supply as per photo documentation We accept no liability for the correctness, completeness or currentness of the information provided.

Stanje: rabljeno, Leto izdelave: 2002, stružna dolžina: 1.000 mm, • Obseg vrtenja nad ležiščem: 520 mm • Obseg vrtenja nad vozičkom: 290 mm • Dolžina struženja: 1000 mm • Premer rotacijske plošče: 250 mm • Hitrost vretena: 3000 vrt/min • Moč vretena: 14 kW Giodpfx Afox I Nwhsqsl • Prehod vretena: 70 mm • Multifix revolver za orodje • Izteg konjička: 180 mm • Premer konjička: 80 mm • Krmiljenje Heidenhain • Teža stroja: 2,5 t

Stanje: zelo dobro (rabljeno), Leto izdelave: 2010, obratovalne ure: 3.624 h, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 398 mm, pomik po osi Z: 1.250 mm, največja hitrost vrtenja: 3.000 obr/min, Ponujamo dobro ohranjen stroj Gildemeister NEF 600 z Heidenhain krmiljenjem. Upoštevajte, da bo kupec odstranil trivrati vpenjalni glavi. Stroj se prodaja brez trivratega vpenjala. Tehnični podatki: Premer struženja: 600 mm Dolžina struženja: 1190 mm Glavno vreteno: Območje hitrosti – glavno vreteno: 0 – 3.000 min⁻¹ Pogonska moč – glavno vreteno: 39,4 / 27,5 kW Najv. navor: 430 Nm Premer vretena pri prednjem ležaju: 100 mm Premer luknje vretena: 90 mm Najv. premer palice: 75 mm Revolver glava: Število orodnih postaj: 12 poz. - VDI 40 Pomiki: X-os: 398 mm Z-os: 1250 mm Konjiček: Gijdpfx Asxrg S Ijfqol Pomik konjička: 1150 mm
