Stroj za obojestransko lepljenje robov

IDM (SCM Group) Activa SB/1 (9900)

Stanje: rabljeno, Leto izdelave: 2005, Distance between centers: 3050 mm Center height: 280 mm Travel: Z-axis: 2800 mm X-axis: 400 mm U-axis: 160 mm W-axis: 160 mm Max. workpiece weight: 1000 kg Grinding wheel: Outer diameter (new): 1050 mm Max. width: 120 mm Bore: 304.8 mm Grinding wheel circumferential speed: 6-50 RPM Accessories: - Measuring system - Tailstock - Coolant unit - Documentation Hnjdpfx Aewz Rg Dsafep

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2019, potovalna razdalja osi X: 205 mm, pomik osi Y: 105 mm, pomik po osi Z: 560 mm, proizvajalec krmilnikov: SIEMENS, model krmilnika: SINUMERIK 828D, število osi: 4, This 4-axis DOOSAN LYNX 2100 LSY was manufactured in 2019. It features a Y-axis for multitasking operations, a 12-station turret with driven tools, and a hydraulic 3-jaw chuck. The machine is equipped with a bar feeder, enabling efficient series production. If you are looking for high-quality turning and milling capabilities, consider the DOOSAN LYNX 2100 LSY turn-mill center we have for sale. Contact us for more details. • Key Features: • Main spindle + sub spindle • Y-axis for multitasking machining • 12-station turret (24 indexing positions) • Live tooling (driven tools) • Tool interface: BMT45 • Workpiece clamping capacity (on the machine): • Hydraulic 3-jaw chuck: 170 mm • Scope of delivery: • Transport to customer • Installation and commissioning of the machine • Basic operator training (14 hours) • Main advantages: • Y-axis + sub spindle → full machining capability • Live tooling → turning and milling in one setup • Bar feeder → ideal for series production • Automated parts handling → increased productivity Additional Equipment • Bar feeder: Top Automazioni Fusion 350 (Ø20-50 mm, up to 3200 mm length) • Additional 3-jaw chuck: 135 mm • Collet chuck system, capacity 5-65 mm • Chip conveyor (belt, side discharge) • Parts catcher for sub spindle Hedpfx Aoy Epi Asafonp • Oil skimmer • High-pressure coolant system (5-7 bar, 20 µm filtration) • Automatic tool measurement • Spindle and axis load monitoring system • 3-color signal beacon • Parts handling arm (for unloading the sub spindle) • Tooling package: • 2x straight driven tool holders • 2x angled driven tool holders • 1x extended angle holder • 1x set of turning tool holders Technical Specification Counter Spindle: Yes Driven Tools: Yes

Stanje: rabljeno, Leto izdelave: 2016, obratovalne ure: 100 h, Funkcionalnost: popolnoma funkcionalen, število kartuš s črnilom: 4, MGI Meteor DP8700 XL Plus z iFoilom in podajalnikom za kuverte, zelo malo rabljen Hedpfx Aajxcup Njfonp

Stanje: rabljeno,

Stanje: rabljeno, Leto izdelave: 2006, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 1.060 mm, pomik osi Y: 610 mm, pomik po osi Z: 610 mm, model krmilnika: Ultimax, skupna višina: 2.800 mm, skupna dolžina: 2.200 mm, skupna širina: 2.400 mm, širina mize: 610 mm, dolžina mize: 1.270 mm, moč vretenovega motorja: 18.000 W, število vreten: 1, število mest v zalogovniku orodij: 24, Oprema: dokumentacija / priročnik, transportni trak za ostružke, 3 axes Hjdowtdzropfx Aafsnp Tool holder SK 40 Internal cooling 35 kVA approx. 7550 kg Comprehensive tool package available separately

Stanje: rabljeno, Leto izdelave: 2007, Funkcionalnost: popolnoma funkcionalen, Krmiljenje NCT104 (izdelano na Madžarskem) Mere mize: 1800 x 1800 mm Hsdeyvuh Iopfx Aafonp X-hod: 3500 mm Y-hod: 1200 mm Z-hod: 1500 mm W-hod: 570 mm Premer vretena: D130 mm Miza se vrti preko CNC programa Vpenjanje: SK50 Teža: 32.000 kg Dimenzije (DxŠxV): 6700 x 6000 x 4420 mm

Stanje: rabljeno, Leto izdelave: 2021, Numerical control MEGA 300 TS Panel height 60 mm PVC/ABS up to 3 mm Feed speed up to 22 m/min Electronically adjustable working height via CNC Motorized pressure belt with increased pressure Infeed system for small panels Panel support guide with electronic CNC adjustment Side roller conveyor with idle rollers for panel support Anti-adhesive unit Straightening unit with two electronically adjustable CNC motors Roll holder plate for delicate edges Edge magazine with 2 positions Gluing unit for EVA adhesive with glue tank and premelter Pressure roller group for straight profiles with electronically adjustable CNC pressure rollers Anti-adhesive group Milling unit with 2 motors and automatic tilt adjustment End trimming unit with 2 vertically stacked motors Hnodpfxot Hal De Aafsp Trimming/corner rounding group with 2 tilting motors electronically adjustable via CNC Corner rounding unit with 4 motors Edge scraper unit electronically adjustable via CNC Glue scraper unit Oscillating brush unit Hot air dryer unit

Stanje: zelo dobro (rabljeno), Portal machine Movable panel, movable working head (horizontal workpiece) Numerical control Power Control, WoodWOP software Safety cabin for the working head. Full machine safety enclosure Infeed table (workpiece support). Outfeed table (with conveyor belt) Workpiece feed using 3 conveyor belts (feed speed approx. max 130 m/min) Minimum workpiece dimensions (X-Y-Z) mm: 250 x 100 x 15 Maximum workpiece dimensions (X-Y-Z) mm: 2500 x 1050 x 60 Motorized conveyor belt for waste disposal Hnjdpfjgwbbqsx Aafjp Separate electrical and control cabinet. Total installed power (kW): 99 No. 2 WORKING UNITS (TOP) – (SERVO MOTOR X-Y-Z): No. 4 drilling units (4 x 2.3 kW) with 10 vertical spindles each (total vertical spindles: 40) No. 3 WORKING UNITS (BOTTOM) – (SERVO MOTOR X-Y-Z): No. 6 drilling units (6 x 2.3 kW) with 40 vertical spindles each (total vertical spindles: 240) No. 2 WORKING UNITS (HORIZONTAL): No. 2 drilling units with horizontal spindles No. 21 horizontal drilling spindles (right side) + No. 21 horizontal drilling spindles (left side) No. 8 glue injection nozzles and dowel insertion units (right side) No. 8 glue injection nozzles and dowel insertion units (left side) No. 2 dowel magazines for automatic dowel insertion OPTIONS: BARCODE (WIRELESS SCANNER)

Stanje: zelo dobro (rabljeno), Leto izdelave: 2008, Powdered sugar bagging machine MESPACK type H-180-FE, year 2008. Two-stage filling: first doser for half-fill, second doser completes the fill. Capacity: 50 sachets per minute. Hodpfjtn Rarsx Aafonp Cartoning machine OTOR SYSTEMS type FCR 214, capacity: 5 cartons of 10 sachets per minute. Year 2011.

Stanje: dober (rabljeno), Funkcionalnost: popolnoma funkcionalen, Leto izdelave: 2011, obratovalne ure: 31.411 h, TRUMPF Trumatic 3000 K03 Punch-Laser Combination Machine Hjdpsycuypofx Aafonp This punch-laser combination machine allows the flexibility of laser cutting to be combined with the advantages of punching. The simultaneous application of these two cutting technologies opens up numerous new possibilities: even complex sheet metal components can be produced. Technical Data - Punching force: 165 kN - Maximum sheet size (X, Y): 2500 mm x 1250 mm - Maximum sheet thickness: 3 mm - Maximum tool diameter: 76.2 mm - Maximum forming height: 25 mm - Maximum bending length: 55 mm - Chipless thread forming: M2.5 to M8 - Laser power: 2000 W - Number of tool stations: 18 - Tool change time (per tool): 3.9 s - Tool change time (for MultiTool): 2.2 s - Positional accuracy: ± 0.1 mm - Repeat accuracy: ±0.03 mm For optimum surface quality of the sheet metal components, the machine is equipped with a brush table and rollers around the forming tools. The MultiTool tool holders can accommodate up to 180 different forming tools. Thanks to shorter production cycles and lower energy consumption, the laser-punch combination machine enables lower part costs compared to flatbed laser cutting systems, ensuring greater economic efficiency. This equipment is ideal for the efficient, high-volume production of complex sheet metal parts. The laser cutting head allows for the cutting of intricate shapes, creates high-quality edges, and can be used when the required profile punching tool is not available.
