130-tonska C-tip ekscentrična stiskalnica

CRONOSSTECH CECP 130

STANDARD EQUIPMENT

• Steel Structure Body
• Gear Assembly Operates in Sealed Oil Bath
• 4-Sided Bearing Alignment
• Nodular Cast Iron Connecting Rod and Main Bearings
• Crankshaft and Drive Shafts Manufactured from 4140 Tempered Steel
• Centralized Fully Automatic Grease Lubrication System
• Pneumatic Clutch and Brake System
• CE Safety Standards Compliant
• Double-Acting Safety Valve
• Manually Adjustable Stroke
• Photocell Safety Light Curtain
• PLC Control System
• Touchscreen LCD Panel (for 150-300 Ton Models)
• Dual-Hand Pedal Control System
• Mechanical Safety Clutch System
• Hydraulic Safety System (for 200-300 Ton Models)
• Emergency Reverse Motor Operation
• In Compliance with Occupational Safety Regulations
• Anti-Vibration Mounts
• CE Approved
• Model Range: 20 Tons to 300 Tons
• 24-Month Warranty
• Country of Origin: Turkey
Lodovtyvgepfx Agwjru

TECHNICAL DATA
CECP 130 C-TYPE MONOBLOCK FRAME
Capacity: 130 Ton
Throat Depth: mm
Table to Ram Distance: 475 mm
Ram Adjustment: 80 mm
Press Width: 1600 mm
Press Depth: 2000 mm
Press Height: 3000 mm
Table Center Hole Diameter: 220 mm
Table Dimensions: 750 x 1000 mm
Die Mounting Hole Diameter: 55 mm
Ram Surface Area: 350 x 550 mm
Table Height from Floor: mm
Stroke: 20 - 140 mm
Strokes per Minute: 45 spm
Motor Power: 7.5 kW
Motor Speed: 1400 rpm
Machine Weight: 6,000 kg

• As we are a manufacturer, technical specifications can be modified upon request.
