Center stružnica

CONTUR SJ-430/760 S

Stanje: novo, Leto izdelave: 2025, x-travel 580 mm y-travel 200 mm z-travel 340 mm Spindle speeds 115 - 1750 rpm Table area 1000 x 240 mm Tool holder ISO 40 Dedpfxetv Riao Anuocn Total power requirement 4.5 kW Machine weight approx. 820 kg Space requirement approx. 1290 x 1090 x 2170 mm Universal precision drilling and milling machine for horizontal and vertical milling operations with digital 3-axis position display DPA 31 Plus Description: - Heavy-duty, robust construction made from high-quality, vibration-absorbing cast iron - Oil-bath gearbox with ground and hardened gears - Coolant system - Halogen machine lamp with focused beam - Large, heavy-duty cross table, precision-machined surface with T-slots and adjustable gibs - Milling head tiltable ±45° - Clockwise/anticlockwise rotation - X-axis traverse optionally via handwheel or table feed unit - Automatic end-stop on the X-axis - Height-adjustable safety shield with microswitch to protect user from flying chips and parts for maximum safety Scope of delivery: - Keyed drill chuck 1 - 16 mm / B18 - Mounting arbor for drill chuck ISO40 / B18 - Horizontal milling spindle with counter bearing, for side and slab cutters Ø22 mm, Ø27 mm - Adapter ISO 40/MK3 - Adapter ISO 40/MK2 - Drawbar for vertical and horizontal use - T-slot nuts - Drift - Operating tools

Stanje: dober (rabljeno), Leto izdelave: 1998, Press force: 315.00 t Stroke: 500 mm Throat: 425 mm Daylight (table to ram, stroke up): 1,000 mm Table surface: 1,200 x 815 mm Table height above floor: 800 mm Ram surface: 1,100 x 700 mm Speed down: 48 mm/s Speed up: 330 mm/s Dedsv Rwu Uopfx Anuocn Working speed: 19 mm/s Oil volume: 1,600 l Power requirement: 82.0 kW Weight: 23.00 t Dimensions (W x D x H): 2.4 x 2.8 x 4.0 m Permitted for manual loading according to CE standard. Equipped with oil-hydraulic drive, controllable dependent on pressure/time and stroke, front light curtain (Sick), two-hand operation.

Stanje: dober (rabljeno), x-travel 400 mm y-travel 375 mm z-travel 250 mm Table size 205 x 800 mm T-slots 4 x 45/14 H7 Spindle speeds 50 - 3150 rpm Tool holder 40 ISO Quill stroke 50.0 mm Djdpfx Ansxl E Syeuscn Feeds X & Z axes 5.0 - 1000 mm/min Feed Y axis 5.0 - 670 mm/min Rapid traverse 2.4 / 1.6 m/min Control system Heidenhain Total power requirement 5.1 kW Weight 950 kg Dimensions (L x W x H) 1860 x 1790 x 1750 mm From a training workshop (vocational school) Well-maintained condition (!!) Equipment: - MAHO universal tool milling/drilling machine - HEIDENHAIN positioning/contouring control "TNC 135" * 3-axis manual input control * Programmable by machine operator * Practical and simple operation - Electro-motorised feeds on all axes (X/Z/Y) * X and Z axes: 5.0 - 1000 mm/min with rapid traverse 2.4 m/min * Y axis: 5.0 - 670 mm/min with rapid traverse 1.6 m/min - Swivelling milling head in both directions - Tilting T-slot universal table - Vertical clamping area - Infinitely variable spindle speed adjustment - Manually extendable quill - Hardened and ground guideways - Electro-hydraulic tool clamping - Coolant system - Front coolant drip tray - Operating manual

Leto izdelave: 1999, stanje: skoraj kot novo (rabljeno), Funkcionalnost: popolnoma funkcionalen, Manufacturer: Arthur Klink Year of manufacture: 1999 Type: Horizontal Broaching Machine Model: RIW 10x1600x400 Weight: 2,700 kg General / Technical Data: Horizontal hydraulic internal broaching machine in nearly new condition, equipped with a tool support system, ideal for the use of flat broaching tools. Broaching stroke: 1,600 mm Pulling force: 10,000 kg (100 kN) Mounting in drawbridge: Ø 85 mm cylindrical Through-hole in clamping table: Ø 100 mm Workpiece diameter: max. 400 mm (limited by tool pan housing) Cutting speed: hydraulically infinitely variable from 1.0 m/min to 9 m/min Return speed: hydraulically infinitely variable from 1 m/min to 24 m/min Machine footprint (W x D x H): approx. 6,400 mm x 1,450 mm x 1,600 mm (excluding work area) Power supply: 400 V, 50 Hz Connected load: 9 kW Equipment: • Machine features electric control for the broaching movement with both manual and automatic operation • Integrated coolant and cutting fluid system • Tool support system for flat broaching tools (no feed mechanism) Dcjdpfx Ansr A Hcbouon • Broaching slide with draw head mounting is equipped with flat guides on both sides Accessories: • 1 universal draw head for flat shanks from 3 mm up to max. 25 mm width and a maximum pulling force of 10 kN (10,000 kg) • Complete machine documentation, as well as CE declaration of conformity Remarks: The machine is ideal for producing keyways. Thanks to the combination of the machine's stable bed and the tool support system, it is particularly well suited for easy and fast use of flat broaching tools. The machine has seen very little use and is in like-new condition. The machine is available for inspection at our warehouse and is ready for demonstration under power. Our direct contact details, as well as further information about the machine, can be found in the attached PDF document.

Stanje: zelo dobro (rabljeno), Leto izdelave: 2020, potovalna razdalja osi X: 8.000 mm, pomik osi Y: 1.300 mm, pomik po osi Z: 2.500 mm, hitro pomikanje X-os: 35.000 m/min, hitri pomik os Y: 40.000 m/min, hitri pomik na osi Z: 40.000 m/min, skupna širina: 5.800 mm, skupna višina: 4.500 mm, skupna dolžina: 13.500 mm, dolžina mize: 10.000 mm, širina mize: 1.250 mm, Travelling column – high performance, precision, and metal removal capacity Linear RAM guide combined with HDS hydrostatic guidance ACD2 milling head with 5,000 rpm and 1,400 Nm torque Aitek ATC chain magazine with 60 positions, L = 400 and Ø 250, max. 35 kg Filtration with high-pressure coolant (IKZ) 15 bar Chip conveyor BLUM 3D touch probe Wide bed, linear guided in X-axis, traverse path W = 930 mm Rotary table drive prepared in control cabinet X-axis: 8,000 mm Y-axis: 1,300 mm Z-axis: 2,500 mm Table length: 10,000 mm Table width: 1,250 mm Spindle power: 40 kW Dodpfxeyr Dmds Anujcn Spindle speed: 5,000 rpm Tool holder: 40 ISO/Bt/Mk X-axis feed: 35,000 mm/min Y-axis feed: 40,000 mm/min Z-axis feed: 40,000 mm/min Milling head auto-index: 0.001 x 0.001 degrees Operating hours: 3,800 h Length: 13,500 mm Width: 5,800 mm Height: 4,500 mm Weight: 45,000 kg Please note: The information on this page has been compiled to the best of our knowledge and, where possible, obtained from the manufacturer. The information is provided in good faith, but accuracy cannot be guaranteed. Therefore, no representation or contractual conditions are implied. We recommend verifying all critical details.

Stanje: zelo dobro (rabljeno), Leto izdelave: 2006, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 7213, Manufacturing Origin: Switzerland Net Weight: approx. 2550 kg Customs Tariff: 8458.11 20 Dimensions: 2000x1260x1950 mm TECHNICAL SPECIFICATIONS 10-Axis Machine – Standard Version 10 axes, 6 spindles: Axes and Spindle Designation - 1 sliding headstock: Z1, S1 - 2 independent vertical gang tools: X1Y1, S6 – X2Y2, S2 - 1 combined unit with 4 rotating spindles: X3Z3, S3 - 1 independent sub-spindle: Y4Z4, S4 - 1 independent counter-operation rotating axis: X4, S5 Bar feed position: right side of operator Machine axis height: 1100 mm Main spindle stroke: max. 255 mm Bar capacity: 1 to 16 mm Spindle speed: 12,000 rpm Spindle feed rate: max. 20 m/min Dedpfx Answ T Tcweuscn Bar capacity, min./max.: 13 mm / 16 mm Max. workpiece length: - Guide bush machining: 180 mm - Collet machining: 30 mm Sub-spindle speed: 12,000 rpm Main spindle drive power: 2.2 kW (continuous) / 3.7 kW (intermittent) Sub-spindle drive power: 1.5 kW (continuous) / 2.2 kW (intermittent) Clamping collet, type: F20 (No. 76-201) Guide bush: fixed / rotating Guide bush collet, type: Meister 605 Number of lateral tool stations, combined: - Fixed: 2 x 5 - Rotating: 3 + 3 Number of frontal tool stations, combined: - Fixed: 4 - Rotating: 3 Number of rear tool stations, combined: - Fixed: 3 + 3 - Rotating: 3 + 3 Tool section: 12x12 mm Standard rotating tool holder: ESX 20 Bar feeder: yes Part catcher: yes All technical data is provided without guarantee and subject to change and/or errors.

Leto izdelave: 1995, stanje: rabljeno, številka stroja/vozila: 18891, Tractive force: 10 t. Lift: 1000 mm Dcedpjbrcmkofx Anuon 3 clearing stations With chip conveyor + platform for above-floor installation and safety door.

Stanje: dober (rabljeno), Leto izdelave: 1997, Also available: CONQUEST T51 model The used HARDINGE CONQUEST T42L 3-axis CNC lathe is a robust and precise medium-sized slant bed CNC lathe with an approximate turning length of 700mm, a bar capacity of 42mm, and a 12-position automatic turret with live tooling. It features a FANUC 18-T CNC control with a color LCD screen and an RS232 serial interface for data transfer. Djdpfx Anjvtrc Sjuecn ASA 5″ spindle Max speed: 4,200 rpm Continuous C axis Spindle power: 20HP X-axis travel: 172mm Z-axis travel: 575mm Machine weight: 4,000 kg The machine comes complete with a 210mm AUTOBLOCK hydraulic chuck, tool presetting system, programmable tailstock, 2 live tool holders (1 axial and 1 radial), chip conveyor, a set of fixed and manual tool holders, and backup disk. Year of manufacture: 1997. CE compliant and in excellent condition.

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2021, Offered is a double-spindle pick-up lathe EMAG VSC 500 DUO. The machine is equipped with 2 independent work spindles and 2 EMAG turrets. Dcjdjt Du Tdepfx Anuen The machine allows for either simultaneous machining of 2 identical workpieces with the same operation, or sequential machining of one workpiece in two consecutive processes. Depending on requirements, the machine can be equipped with additional peripherals (chip conveyor, coolant system, external automation, etc.). CONTROL SYSTEM Siemens 840 Dsl TECHNICAL DATA Workpiece diameter: max. 440 mm Workpiece height: max. 250 mm Chuck diameter: 450 mm Swing diameter: 550 mm X-axis travel: 925 mm Z-axis travel: 400 mm TOOL CARRIERS 2x EMAG disc turrets, 12x CDI 68, with driven tools Price, delivery time, and machine configuration upon request.

Stanje: novo, Leto izdelave: 2026, Strugalno-režeči stroj CORMAK PT265 je profesionalni stroj, zasnovan za intenzivno in natančno obdelavo masivnega lesa in lesnih materialov. Nova različica tega stroja ponuja inovativen sistem povezanih miz, ki znatno poveča učinkovitost dela in odpravlja napake pri nastavitvi, ki so značilne za starejše rešitve. Z močjo motorja 2,6 kW in stabilno konstrukcijo je PT265 zanesljivo orodje za mizarje, obrtnike in proizvodne delavnice. Glavne prednosti stroja: * Nov sistem povezanih miz – stalna kalibracija podajalne in sprejemne mize odpravlja napake in poveča natančnost. * Stabilna, litena konstrukcija – 170 kg lastne teže minimizira vibracije in poveča varnost. * Motor z nazivno močjo S6: 2,6 kW – zagotavlja gladko in učinkovito obdelavo trdih vrst lesa. * Enostavna preureditev iz stroja za ravnanje na stroj za režečenje – hitro preklapljanje načina delovanja skrajša čas obdelave. * Tri rezila HSS – natančno rezanje in visoka kakovost obdelane površine. * Stroj za ravnanje s širino delovne površine 265 mm – velika delovna površina omogoča obdelavo širokih elementov. Konstrukcija in tehnologija: CORMARK PT265 je sodoben stroj za režečenje lesa, ki temelji na robustni, ojačani konstrukciji z litimi elementi. Delovne mize so brušene in ustrezno uravnotežene, kar zagotavlja ponovljivost in natančnost. Novi sistem miz omogoča sinhrono nastavitev višine – enkrat nastavljena višina mize ne zahteva ponovne kalibracije pri spreminjanju debeline režečenja. Osrednja postavitev mize stroja za režečenje na stebru zagotavlja enakomerno vodljenje materiala brez odstopanj. Gumijaste nogice dodatno zmanjšujejo vibracije, kar vpliva na vzdržljivost komponent in kakovost obdelave. Natančnost in učinkovitost delovanja: Dcedpfxovxhzno Anuon Z motorjem 2,6 kW (S6) stroj ponuja visoko učinkovitost ob ohranjanju stabilnosti parametrov, tudi pri obdelavi trdih vrst lesa. Rezilni valj s premerom 75 mm s tremi rezili in hitrostjo 4000 vrt/min zagotavlja idealno gladko površino materiala. Natančna skala omogoča natančno nastavitev višine mize. Aluminijasto vodilo (700 x 150 mm) z nastavljivim kotom v območju 90–45° omogoča natančno ravnanje materiala pod različnimi koti. Standardna oprema: * Rezilni valj s tremi rezili HSS * Aluminijasto vodilo 700 x 150 mm * Skaliran gumb za nastavitev višine mize * Zaščita rezilnega valja * Vgrajena priključek za odsesavanje Ø100 mm * Gumijaste nogice proti vibracijam Tehnični podatki: * Premer rezilnega valja [mm] 75 * Hitrost rezilnega valja [vrt/min] 4000 * Premer odsesalne priključnice [mm] 100 * Kot nagiba vodila [°] 90 - 45 * Število rezil 3 * Dolžina valja [mm] 262 * Dimenzije rezila [mm] 250x25x3 * Maksimalna širina stroja za ravnanje [mm] 265 * Maksimalna širina stroja za režečenje [mm] 265 * Maksimalna višina režečenja [mm] 180 * Maksimalna globina režečenja [mm] 3 * Maksimalna globina režečenja (stroj za ravnanje) [mm] 2,5 * Hitrost podajanja stroja za režečenje [m/min] 6 * Dimenzije vodila [mm] 700 x 150 * Dimenzije stroja (d x š x v) [mm] 1080 x 269 x 1000 * Teža [kg] 170 * Nazivna moč motorja S6: 2,6 kW * Napetost 400 V * Navodila (DTR) * CE deklaracija da
