Namizni vrtalni stroj

TOS VARNSDORF WHQ 13 ( 4 mt )

Stanje: zelo dobro (rabljeno), Leto izdelave: 1997, Visoko zmogljiv 3-posteljni CNC stružni stroj Proizvajalec: Gurutzpe – Španija Tip: B 1400/3 x 8000 Leto izdelave: 1997 Krmiljenje: NUM Največji premer vrtenja nad posteljo: 1420 mm Višina konice: 710 mm Največji premer struženja nad sani: 1150 mm Največja dolžina struženja: 8000 mm Moč vretena vpenjalne glave: 75 KM Hitrost vretena vpenjalne glave: do 600 min⁻¹ (4-stopenjski menjalnik) Navor vpenjalne glave: 16000 Nm Hitri pomik X/Z: 5000 mm/min Pomik osi X: 850 mm Pomik z 8000 mm Revolver z avtomatsko menjavo 4 pozicij Največja teža obdelovanca brez lunet: 14.000 kg z 1 luneto: 17.000 kg, z 2 lunetama: 19.000 kg Kdjdjw Snu Ejpfx Agkew Oprema stroja: – 1 x premična luneta – 2 x fiksni luneti – 1 x transporter za odrezke

Stanje: nepreverjeno (rabljeno), Faceplate diameter: 3000 mm Swing diameter without side support: 3500 mm Swing diameter with side support: 3300 mm Turning height under tool: 2560 mm Max. workpiece height: 2750 mm Ram stroke (vertical): 1500 mm Ram stroke (horizontal): 1800 mm Side support travel: 2320 mm Cross rail travel: 2100 mm Kdodevyy Txjpfx Agkjw Max. workpiece weight: 20 tons Total weight: approx. 75 tons Right support CNC controlled

Stanje: zelo dobro (rabljeno), Leto izdelave: 2013, Commissioning: 2013 Control system: Heidenhain iTNC 530 incl. HR 520 handwheel Machine hours Machine powered on: approx. 40,700 h Spindle hours: approx. 17,100 h Ksdpfx Agewa T Hkjkedw Spindle hours current milling spindle: approx. 150 h Travel distances X axis: approx. 2,500 mm Y axis: approx. 3,000 mm Z axis: approx. 1,250 mm A axis: ± 110° C axis: ± 300° Clamping table Clamping surface: approx. 2,500 x 3,250 x 400 mm 2-axis milling head VH30 Spindle power: 60 kW Spindle speed: max. 22,000 rpm Torque: 95 Nm Tool holder: HSK 63A Tool clamping: hydraulic Coolant supply: external and internal Drives linear axes Feed rate X/Y/Z axis: up to 60 m/min Axis acceleration X/Y/Z: up to 5 m/s² The machine is currently set to the following basic values due to insufficient available power on site! Feed rate X/Y axis: up to 40 m/min Feed rate Z axis: up to 30 m/min Axis acceleration X/Y/Z: up to 2.5 m/s² Electrical data Connected load: 190 kVa Main fuse: approx. 315 A The machine can be reset to its original values at any time, provided sufficient power supply is available. Current reduced connection values: Connected load: 130 kVa Main fuse: approx. 250 A Dimensions, weight Required space for machine with peripherals: approx. 10,000 x 8,000 x 5,650 mm Total weight: approx. 63,000 kg Colour Enclosure, gantry, control cabinet: RAL 7035 light grey Milling head and applications: RAL 6038 luminous green Description: Additional equipment: - Coolant supply with belt filter system - 50-position chain tool changer - Work area enclosure - Chip conveyor - LTA emulsion mist extraction system Options available at extra cost: - Renishaw RMP60 radio probing system - BLUM Control NT Condition of the machine Fully functional, in very good condition. Already dismantled and stored.

Stanje: pripravljen za uporabo (rabljen), Schiess 80 DF Type: 80 DF 700/900-550/280 Originele CNC-machine van Schiess (geen omgebouwde conventionele machine) Volledig hydrostatisch systeem Gelaste kolomconstructie Siemens-aandrijfmotor Uitgerust met een inspectielift om het werkstuk van bovenaf te bekijken Kdedpfx Agjv Rwdpjksw Machine met zeer hoge maatvastheid/tolerantie Tafeldiameter: 7.000 mm Maximale werkstukdiameter: 9.000 mm Maximale tafelbelasting: 315 ton Toerentalbereik: 0,25 – 25 omw/min Maximaal rotatiekoppel: 63.000 kgm Maximale snijkracht met uitgeschoven ram tot 900 mm: 12.500 kg Gereedschapskop kan van -40° tot +40° zwenken Vermogen: 125 kW Tafelgewicht: 71 ton Ramsectie: 380 x 380 mm Horizontale ramverplaatsing vanaf middelpunt tafel: 5.640 mm Verticale ramverplaatsing: 2.800 mm Maximale hoogte onder de traverse: 5.547 mm Horizontale verplaatsing van de traverse: 4.700 mm Uitgerust met een automatische 3-positie gereedschapswisselaar Totaal gewicht van de machine: 260 ton Unieke eigenschap: de hoofdkolom kan in 3 verschillende posities worden geconfigureerd: 1 - voor maximale zwenkdiameter van 9.000 mm (huidige afstelling) 2 - voor maximale zwenkdiameter van 10.500 mm 3 - voor maximale zwenkdiameter van 13.100 mm Dit wordt bereikt door de hoofdkolom te verplaatsen/herpositioneren op het funderingsframe.

Stanje: rabljeno, Leto izdelave: 2008, X-axis travel: 1,850 mm Y-axis travel: 1,400 mm Z-axis travel: 720/905 mm Control system: SIEMENS SL 840 D Spindle speeds: 15,000 rpm B-axis: -20 / +120° Tool holder: HSK-A63 Tool magazine with 45 positions Maximum tool length: 365 mm Tool diameter with adjacent positions occupied: 90 mm Tool diameter with free adjacent positions: 130 mm NC rotary table: 1,600 mm Kedpfxevxwuwo Agkodw T-slots: 12 Slot width: 18H12 Slot spacing: 100 mm Table load capacity max.: 3,000 kg Table rotation speed max.: 30 rpm Total power requirement: 89 kW Machine weight approx.: 26 t Space requirement approx.: 7.00 x 6.20 x 4.15 m 5-axis machining center with Siemens SINUMERIK 840D control, BLUM Laser, Renishaw, RotoClear, fire extinguishing system, 2x electronic handwheel, Steptec spindle, spindle oil cooler, ICS (internal coolant supply), high-pressure pump, Bürener coolant band filter system, chip conveyor. Machine can be inspected under power.

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2002, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 2.000 mm, pomik osi Y: 800 mm, pomik po osi Z: 800 mm, širina mize: 700 mm, dolžina mize: 2.000 mm, Control: HEIDENHAIN TNC-426 X-axis travel: 2000 mm Y-axis travel: 800 mm Kdjdpfx Ajvfr Hbegkjw Z-axis travel: 800 mm Taper: ISO 50 Speed range: 20 – 3000 rpm Spindle power: 17 kW

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2010, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 9.000 mm, pomik osi Y: 4.000 mm, pomik po osi Z: 1.000 mm, FREZALNI / VRTALNI STROJ S PREMIČNO KOLOMNO CME TEHNIČNE LASTNOSTI CME - MOŽEN OGLED V OBRATOVANJU Znamka: CME Model: MB 9000 Leto: 2007 CNC: Siemens Sinumerik 840D Os X: 9000 mm Kdsdpfx Agsu R Rk Hskew Os Y (vertikalno): 4000 mm Os Z: 1000 mm Os W (Ø 150 mm): 700 mm 2 rotacijsko-translacijski mizi (Linearna pot: 2000 mm) 2500 x 2500 mm, nosilnost 25 t Heidenhain optične letev na vseh oseh Neposredna glava Zamenjava orodja, 90 mest ZF menjalnik Notranje hlajenje Odvzemanje ostružkov

Stanje: rabljeno, Leto izdelave: 1980, Wheel diameter – max. 2,500 mm Wheel width 1,200 mm Module – max. 32 Module – min. 3 Total power requirement 25 kW Machine weight approx. 60 t Space requirement approx. m Year of manufacture: 1980 Overhauled: 1990 Wheel Ø min./max.: 180 – 2,500 mm Module: 3 – 32 Maximum helix angle: 10 – 35 ° Wheel width for spur gearing: 1,200 mm Stroke length approx.: 100 – 1,200 mm Stroke rate: 80 – 350 strokes/min Adjustability of stroke position: 300 mm Stroke speed: 4–40 m/min Max. workpiece weight approx.: 18,000 kg Max. number of teeth: 16 – 576 Table size Ø x bore: 1,400 x 500 mm Grinding wheel Ø approx.: 500 mm Grinding wheel peripheral speed: 34 m/s Total drive approx.: 25 kW – 380 V – 50 Hz Weight approx.: 15 t Accessories / Special equipment: - Hydrostatic guides on the grinding slide, table, and all other guideways - Complete grinding room enclosure with sliding doors Ksdpfet Hwqqox Agkodw - Automatic grinding process with multiple passes, settings for roughing, semi-finishing, fine finishing, and automatic dressing cycle after a preset number of teeth - Profile correction possible via appropriate dressing and additional movement of the grinding slide (height and flank crowning) - Approx. 50 change gears, inclination display device - Large coolant system with belt filter and oil mist extraction - Separate control cabinet, separate hydraulic unit, separate oil cooling unit

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2000, Funkcionalnost: popolnoma funkcionalen, GEBRAUCHTE Taiwan Takisawa EX-108 Hochleistungs-2-Achsen-CNC-Drehmaschine Seriennummer: CA11E80453, Baujahr 2000 HINWEIS: Dies ist das 2-Achsen-Modell EX108, nicht das 3-Achsen-Modell EX308. • Schwere Schrägbett-Gusskonstruktion • Fanuc 21iT CNC-Steuerung • 4-fach schwere Linearführungen • Hochgeschwindigkeits-Servorevolver • Werkzeug-Einstellvorrichtung • 8" 3-Backen-Hohlspannzylinder hydr. Spannfutter • Stückzähler • Werkzeughalter im Lieferumfang enthalten Max. Umlaufdurchmesser über Bett: 400 mm Max. Umlaufdurchmesser über Planschieber: 320 mm Spitzenweite: 645 mm Standard Drehdurchmesser: 216 mm Kdedpjt E Hvgefx Agkjw Max. Drehdurchmesser: 320 mm Max. Drehlänge: 530 mm Stangendurchlass: 52 mm X-Achse Verfahrweg: 180 mm Z-Achse Verfahrweg: 530 mm Spindeldrehzahlen: 60 – 4000 U/min Spindelnase: A2 – 6 Spindelbohrung: 63 mm Revolverkopf: 12 Stationen Reitstockverfahrweg: 435 mm Reitstockpinolenhub: 100 mm Reitstockpinolenaufnahme: MK 5 Eilgang (X & Z): 20 & 24 m/min Handvorschub (X & Z): 0 – 1260 mm/min Spindelmotor: 7,5 / 11 kW Elektrik: 415V, 3PH, 50HZ Aufstellfläche: 2240 mm x 1645 mm Maschinengewicht: 4300 kg

Stanje: dober (rabljeno), Parallel lathe Tovaglieri Used, from educational (school) environment. Excellent condition. Centre height: 180 mm. Kdodokt U E Iopfx Agkow Distance between centres: 700 mm. Spindle bore: 45 mm. Supplied accessories included. No. 4 units available, subject to prior sale.
