Rezkalni stroj

Optimum OPTImill F 150

Stanje: rabljeno, Technical Details: Kodpju R A Dlefx Aczjnb Length: 750 mm Height: 800 mm Welding current: 120 Machine weight approx.: 180 kg Dimensions (L x W x H), Welding unit: 0.75 x 0.52 x 0.8 m Dimensions (L x W x H), Compressor: 1.2 x 0.5 x 0.9 m Plasma Cutting Machine Cutter: Manufacturer Jäckle, Year 2005 - Cutting capacity: 30 kVA - TIG / MMA welding - Cooling type: F - Incl. torch package, 6.0 meters - Incl. ground cable, 12.0 meters OPTIONALLY available for sale: Piston compressor: Manufacturer Schneider Type Universal 650-60D, Year 1993 - Filling capacity: 500 l/min - Flow rate: 616 l/min - Compression pressure: 10 bar - Max. power: 4 kW - Incl. compressed air hose, approx. 4 meters - Mobile on two wheels

Stanje: zelo dobro (rabljeno), Leto izdelave: 2013, obratovalne ure: 5.785 h, Okuma Genos L300e-MY stružniški center Leto izdelave: 2013 Knedpszat Tvsfx Aczeb Tehnične podrobnosti: Krmilnik: OSP P300L-R Premer struženja: 340 mm Dolžina struženja: 1020 mm Premer vretena: 65 mm Hitrost vretena: 25 - 3000 1/min Glavni motor vretena: 15/11 kW Pomik po osi X: 235 mm Pomik po osi Y: +50 / -50 mm Pomik po osi Z: 1074 mm Najmanjši indeksacijski kot C-osi glavnega vretena: 0,001° Število orodij v revolverski glavi: 12 Hitrost pogonskih orodij: 45 - 4500 1/min Število pogonskih orodij: 12 pozicij Orodni priključek: VDI40 Pogonski motor za pogonska orodja: 7/3,3 kW Podajalec materiala: SPACESAVER 2210 ( dolžina palice 1500 mm, premer do 67 mm ) Dimenzije stroja: 4370x2540x2490 mm Teža: 7500 kg Dodatna oprema / možnosti: - Podajalec palic SPACESAVER 2210 - Transporter za odrezke - Lovilec končnih izdelkov - Renishaw roka za merjenje orodij - Držala za pogonska orodja - Držala za statična orodja - Hidravlična glava - Čeljusti za glavo - Dokumentacija - Odsesovalec prahu

Stanje: rabljeno, Leto izdelave: 1991, Drilling capacity in steel (diameter): 50 mm Throat depth: 1100 mm Max. workpiece height: approx. 1000 mm Drilling capacity in cast iron: 60 mm Spindle taper: MT 5 Spindle speeds: 28 - 2500 rpm Feeds: 0.05 - 2 mm/rev Quill travel: 300 mm Distance base plate to spindle nose: 630 - 1380 mm Vertical arm adjustment: 750 mm Total power requirement: 6 kW Machine weight: approx. 4 t Machine dimensions (L x W x H): 2,740 x 1,140 x 2,590 mm - with tapping device - Knedpou Sblwsfx Aczeb Accessories: cube table (L x W x H = 550 x 550 x 550 mm), machine vice, coolant system

Stanje: zelo dobro (rabljeno), Leto izdelave: 1992, Funkcionalnost: popolnoma funkcionalen, Universal milling machine Deckel FP4M with 3-axis Heidenhain active digital readout – Excellent condition, CE compliant!!! Technical Specifications: >> Year of manufacture: 1992 Machine No. 2203-8449 >> Fixed angle table >> Spindle speed: 50 - 2500 rpm >> Feed rate: 8 – 630 mm/min >> Drive power: 3.7 / 4.4 kW >> Spindle brake Knedju Tuk Hopfx Aczob >> Rapid traverse: 1300 mm/min >> Travel X/Y/Z: 500/400/400 mm >> Vertical milling head adjustable on spindle carrier >> Vertical quill and horizontal quill - SK40 >> Vertical quill extendable 90 mm >> Hydraulic drawbar system >> Weight approx. 1600 kg Accessories and Equipment: >> 3-axis active Heidenhain digital readout >> Coolant system >> Chip tray >> Centralized electric lubrication unit >> Operating manual, spare parts diagrams About the machine: Offered is a Deckel FP4M Universal Milling Machine, active version, in excellent condition. The machine features minimal backlash and all feed screws move smoothly. Even at maximum spindle speeds, the milling machine runs smoothly. The machine is equipped with hydraulic tool clamping. This FP4M was only used occasionally in a government facility for training purposes. On this newer FP4 model, the feed rates on all three axes are steplessly adjustable, and the machine features rapid traverse in every axis. A major advantage is the active 3-axis digital readout. With the Heidenhain traverse control, you can enter dimensions that the machine will automatically position to. An oil change has been performed. Mechanically and electrically tested. The Heidenhain digital readout system makes operation easier and more precise. Take the opportunity to inspect and test the machine under power on site.

Stanje: dober (rabljeno), Leto izdelave: 1992, Offer 23426 Technical Data: Knodpjrl Irvofx Aczjb - Cutting range at 90° round: 420 mm - flat: 635 x 290 mm - Cutting range at 45° round: 360 mm - flat: 420 x 300 mm - Saw band dimensions: 5200 x 32 x 1.1 mm - Infinitely variable cutting speeds: 18 to 108 m/min - Hydraulic lifting and lowering of the saw frame - Hydraulic material vice - Cutting pressure steplessly adjustable: 0 - 10 m/min - Total drive power: 400 V / 2.2 kW - Coolant system - Machine mounted on rotating chassis - Powered infeed roller conveyor: 4000 mm - Outfeed roller conveyor with length stop: 6000 mm - Space requirement approx. W 2500 x H 1400 x D 1100 mm - Machine weight approx. 950 kg - Roller conveyor weight approx. 2000 kg

Stanje: rabljeno, Leto izdelave: 1984, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 1.800 mm, pomik osi Y: 1.500 mm, pomik po osi Z: 2.000 mm, obremenitev mize: 5.000 kg, premer vretena: 110 mm, skupna višina: 3.800 mm, skupna dolžina: 5.000 mm, skupna širina: 3.000 mm, dolžina mize: 1.520 mm, širina mize: 1.225 mm, dolžina podajanja os X: 1.800 mm, dolžina pomika po osi Y: 1.500 mm, dolžina podajanja os Z: 2.000 mm, Nosilec orodja SK50, Heidenhain krmiljenje, stroj je pripravljen za prevzem in takoj pripravljen za uporabo. Kodpexga Tnsfx Aczonb

Stanje: novo, Leto izdelave: 2025, x-travel 580 mm y-travel 200 mm z-travel 340 mm Spindle speeds 115 - 1750 rpm Table area 1000 x 240 mm Tool holder ISO 40 Total power requirement 4.5 kW Machine weight approx. 820 kg Space requirement approx. 1290 x 1090 x 2170 mm Universal precision drilling and milling machine for horizontal and vertical milling operations with digital 3-axis position display DPA 31 Plus Description: - Heavy-duty, robust construction made from high-quality, vibration-absorbing cast iron - Oil-bath gearbox with ground and hardened gears - Coolant system - Halogen machine lamp with focused beam - Large, heavy-duty cross table, precision-machined surface with T-slots and adjustable gibs - Milling head tiltable ±45° - Clockwise/anticlockwise rotation - X-axis traverse optionally via handwheel or table feed unit - Automatic end-stop on the X-axis - Height-adjustable safety shield with microswitch to protect user from flying chips and parts for maximum safety Scope of delivery: - Keyed drill chuck 1 - 16 mm / B18 - Mounting arbor for drill chuck ISO40 / B18 - Horizontal milling spindle with counter bearing, for side and slab cutters Ø22 mm, Ø27 mm - Adapter ISO 40/MK3 Ksdpfstv Riaox Aczonb - Adapter ISO 40/MK2 - Drawbar for vertical and horizontal use - T-slot nuts - Drift - Operating tools

Stanje: rabljeno, TECHNICAL DATA - Number of spindles: 2 Ksdpsuhbnnjfx Aczsnb - Number of axes: 4 MAIN SPINDLE - Spindle nose: A2-8 - Spindle speed: 3,000 [rpm] - Max. bar capacity: 80 [mm] - Max. machining diameter: 300 [mm] - Max. swing over bed: 520 [mm] - Minimum C-axis resolution: 0.001 [degrees] SUB SPINDLE - Spindle speed: 6,000 [rpm] - Max. bar capacity: 53 [mm] - Minimum C-axis resolution: 0.001 [degrees] - Stroke: 520 [mm] TURRET - Number of positions: 12 - Travel X/Z: 230 / 460 [mm] - Driven tool speed: 4,500 [rpm] ELECTRICAL SUPPLY - Supply voltage: 400 [V] - Total power consumption: 22.5 [kVA] WEIGHT AND DIMENSIONS - Space requirements: 3,050 x 1,860 [mm] - Machine height: 1,850 [mm] - Machine weight: 5,500 [kg] ACCESSORIES - Control: OSP-P300L-R - Coolant tank * with high-pressure pump - Chip conveyor - Parts removal - Parts conveyor belt - Bar feeder: Top Automation FU352 - Fire extinguishing system * * NB: Functionality not guaranteed. Must be inspected by a qualified company appointed by the buyer.

Stanje: novo, Leto izdelave: 2026, številka stroja/vozila: 2103 XXXXXX, The FPS 300M, successor to the DECKEL FP1. Based on our many years of service experience, we decided to develop and manufacture our own milling machines. The FPS 300M is a conventional milling machine, perfectly suited for both training and production. Control 3 axes – FPS Aktiv – digital display Knodpfeh I Nqwsx Aczeb Spindle speed 40 – 2000 rpm, geometrically stepped direct-drive gearbox with 16 gear stages for maximum torque and milling performance Feed 5 to 500 mm/min, continuously adjustable Rapid traverse 1.5 m/min Quill Extendable quill, vertical 60 mm SK40 with M16 drawbar thread, optional: with DECKEL saw thread S20 x 2 Axes X/Y/Z 300/160/340 mm Table Rigid angle table 600 x 210 mm Equipment • Vertical and horizontal spindle • Milling head manually tiltable +/- 90° Options • Z-axis bellows • Chip tray • Machine lamp • Central lubrication • Universal table • Rotary table • Slotting head • Dividing attachment • Counter-support • etc. Further technical data can be found in the attached data sheet.

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2022, največja hitrost vretena: 4.500 obr/min, potovalna razdalja osi X: 205 mm, pomik po osi Z: 340 mm, moč vretenovega motorja: 15.000 W, skupna višina: 1.693 mm, skupna širina: 1.595 mm, proizvajalec krmilnikov: FANUC, model krmilnika: 0i-F Plus, največja dolžina izdelka: 2.350 mm, število osi: 3, Ta naprava DN SOLUTIONS LYNX 2100MB je bila izdelana leta 2022. Stanje je kot novo, gre za razstavni eksponat. Opremljena je z maksimalno hitrostjo vretena 4.500 vrt/min in možnostjo uporabe vpenjalne glave do velikosti 8" (204 mm). Stroj ima 12-postajno orodniško glavo in kapaciteto za obdelavo palic s premerom 65 mm. Če iščete visokokakovostne rešitve za struženje, razmislite o horizontalnem stružnem stroju DN SOLUTIONS LYNX 2100MB, ki ga ponujamo v prodajo. Za več podrobnosti nas kontaktirajte. • Kot novo, razstavni eksponat • Možna velikost vpenjalne glave: 8" (204) – vpenjalna glava ni vključena v dobavo • Kapaciteta za obdelavo palic: 65 mm • Število mest na orodniški glavi: 12 • Vmesnik orodniške glave: BMT 45 • Tip vodila: linearno vodilo • Hladilni sistem: črpalka za hladilno tekočino, 7 barov • Izvedba: kompaktno visokozmogljivo stružno središče, zasnovano za prihranek prostora • Produktivnost: kratki časi neaktivnosti; orodniška glava z vmesnikom BMT • Uporaba: primerno za proizvodnjo majhnih delov z visoko natančnostjo Dodatna oprema • Vmesnik za podajalnik palic • Transportni sistem za струžnice • Naprava za zbiranje delov • Menjalnik orodja (električni) • Ločilo olja • Trikratna signalna luč • Na voljo po želji: transportni sistem za струžnice (tekoči trak). Cena na zahtevo • Stroj je dobavljen s standardnim osnovnim paketom: popolnoma opremljena orodniška glava, vključno z osnovno montažo. Na voljo po želji: • 2 kos. zunanji držalo za stružna orodja BMT45 20x20, enojno (500-0665) • 1 kos. držalo za ploska stružna orodja BMT45 20x20, levo/desno (500-0668) • 1 kos. zunanji držalo za stružna orodja BMT45 20x20, dvojno, levo (500-0675) • 1 kos. držalo za orodja za rezanje BMT45 20x20, enojno (500-0671) • 2 kos. držalo za notranja orodja za rezanje BMT45 Ø32, enojno, levo (500-0680) • 1 kos. držalo za notranja orodja za rezanje BMT45 Ø20, trojno (500-0678) • 1 kos. pokrov IK (500-0642) • 1 kos. komplet reducirnih puš • 1 kos. komplet reducirnih puš za vrtanje • 1 kos. komplet reducirnih puš za U-vrtanje • 1 kos. komplet reducirnih puš, zunanji premer 32, notranji premer 20/25 (500-0710) • 1 kos. adapter PRECI-FLEX PRECI-FLEX ER20 (BMT 45P) (500-0524) • 2 kos. ukrivljena, zunanja hladilna orodja Eppinger-AGW • 2 kos. ravna, zunanja hladilna orodja Eppinger-AGW Tehnične specifikacije Kedpfx Acoyrt E Nezonb Nasprotno vreteno: ne Pogon orodij: da
