Tračna Žaga nakup rabljenega (3.766)

Stanje: novo, skupna višina: 2.210 mm, največja širina rezanja: 1.000 mm, skupna masa: 7.000 kg, moč: 22 kW (29,91 KM), dolžina žaginega lista: 7.200 mm, The HTZ 1100 PRO is a fast, versatile band saw. Suitable for either production or quality oriented sawmills, who are looking at lowering their operation costs, while increasing quality of sawn wood and production. Available with Mebor’s innovative double cut system with automatic board removal. Key features: fast & precise servo controlled blade positioning (precision +/- 0,05 mm), all in one log manoeuvring for best recovery, able to split logs up to 900 mm in diameter, best performance in the price range. Mebor System®is our own system of horizontal band saws, which sets us apart from our competitors. With a Mebor band saw you will increase your productivity and yield, as well as decrease labour costs. Wood is unpredictable and for this reason Mebor band saws have a strong and robust construction. It guarantees reliability of functioning and minimises maintenance costs. Band saws adapted for your needs – for small and big sawmills.Every Mebor band saw is custom made ; therefore we supply each customer an optimal band saw for his needs. We will advise which model is most suitable for your needs and requirements. We will also adjust the configuration of the band saw; for example the distances between clamps according to the lengths of logs, equipment etc. Kjdpforllansx Af Noll Automatic board removing (Mebor System® ) We were the first to introduce the board removing system, which saves your time. After the band saw cuts a board, the board pusher pushes it off the band saw bed during the return of the band saw head. Simple and automatic, with no manual work. Automatic functioning - Mebor System®. It leads the operator during cutting. It provides important information, which helps him choose the optimal cutting for best output. Manual control is also available for less demanding users. Full log manoeuvring equipment is available for fast and effortless work. Precision of cutting is ensured by the solid construction and wide blades. All Mebor band saws are using wide blades (80-210 mm wide). The fact is that wide blades provide higher sawing speed, as well as better sawing precision. The high quality of your products will increase the satisfaction of your customers.

Stanje: rabljeno, Stabilna tračna žaga Pehaka za žaganje lesa in drugih materialov. Premer kolesa: 800 mm Motor: 3 kW Maksimalna višina prehoda: pribl. 350 mm Klsdpfx Afeyarwme Nsl

Stanje: rabljeno, Leto izdelave: 2021, LETO IZDELAVE 2021 GLAVNI MOTOR 60 KM (45 kW) Kljdpfxsyaplbo Af Nel VIŠINA REZA 120 MM ŠIRINA REZA 400 MM

Stanje: dober (rabljeno), Cutting diameter up to 270 mm Saw blade 2880 x 27 x 0.9 mm Various accessories MARCELS MASCHINEN CH Kedou Eqi Sopfx Af Noll

Stanje: rabljeno, Leto izdelave: 2000, 1 kos tračne žage za kovino, proizvajalec Müller, tip HBS 321 GC, letnik 2000, serijska številka 6692 Klsdpfjyaxm Ujx Af Njl

Stanje: rabljeno, Leto izdelave: 2014, Funkcionalnost: popolnoma funkcionalen, TRAČNA ŽAGA CENTAURO MOD. CO 700 - V SKLADU Z NORMAMI CE - LETO 2014 - Popolna z navodilom za uporabo in CE izjavo - V skladu z normami CE - Leto 2014 Klsdpfex Ruk Ejx Af Nol

Stanje: rabljeno, Leto izdelave: 2000, Funkcionalnost: popolnoma funkcionalen, širina mize: 975 mm, dolžina mize: 810 mm, TRAČNA RAZREZOVALNA ŽAGA MEBER MOD. SR900 - Dimenzije mize: 975x810mm - Motor: 11kW - Leto: 2000 (CE) - POPOLNA Z NAVODILOM Klsdpfsx Rt Aajx Af Nsl

Stanje: delavnici obnovljeno (rabljeno), reinforced cast iron table, tiltable Kljdpfx Afov Dg A Uo Nsl balanced cast iron flywheels precise upper & lower blade guides Table dimensions approx. 680 x 580 mm Cast iron flywheel diameter 600 mm Max. cutting height 340 mm Max. cutting width approx. 540 mm Three-phase motor approx. 2.2 kW, 50 Hz, 400 V

Stanje: novo, Band saw in compliance with European safety regulations, complete with: - Reinforced grey cast iron table, tiltable - Balanced cast iron flywheels Kledpfodibw Ajx Af Njl - Telescopic blade guard with rack and pinion - Blade tension indicator - Precise upper and lower blade guides - Cleaning brush on the lower flywheel - Sturdy aluminium fences - Max. saw blade width: 16 mm - Extraction below the table, mounted on the machine stand - Micro safety switches on the machine doors Work table dimensions: 600 x 520 mm Work table height: 900 mm Flywheel diameter (cast iron): 450 mm Flywheel speed: 700 rpm Max. cutting height: 300 mm Max. cutting width: 440 mm Min./Max. blade length: 3690 / 3742 mm Min./Max. blade dimensions: 6 x 0.5 / 25 x 0.5 mm Three-phase motor: 3.0 kW, 50 Hz, 400 V Extraction hood diameter: 120 mm

Stanje: zelo dobro (rabljeno), Leto izdelave: 2017, Funkcionalnost: popolnoma funkcionalen, Kasto KASTOwin A 3.3 popolnoma avtomatska tračna žaga za kovino (2017) Proizvajalec: Kasto Tip: KASTOwin A 3.3 tračna žaga za kovino Leto izdelave: 2017 Klodpfoyab Uujx Af Nel Stanje: rabljeno, pod napetostjo Dodatne informacije na zahtevo. Obseg reza: 330 mm Obseg reza [V x Š]: 330 x 350 mm Večkratni podajalnik: 9.999 mm Mere žagalnega traku: 5.090 x 34 x 1,1 mm Hitrost reza, brezstopenjska: 12 – 150 m/min Motor žage, frekvenčno reguliran: 4,0 kW Višina materiala na podpori: 700 mm Dolžina: 1.350 mm Širina: 2.380 mm Višina: 1.850 mm Teža: 2.200 kg

Stanje: rabljeno, Leto izdelave: 2008, Cutting diameter / mm Saw blade length / mm Cutting width / mm incl. roller conveyor 4000x500x850mm Sawing diameter (round): 260mm Sawing diameter (square): 260mm Sawing diameter (rectangular): 300 x 260mm Saw blade dimensions: 4200 x 34 x 1.1 mm - High-performance automatic band saw, heavy-duty, hydraulic production band saw - Parallel sawing feed system in profile guide rails - Mitsubishi NC program control E1032 for preselection of 90 programs, each with individual quantity and corresponding cut length - Mitsubishi PLC control - Equipped with Siko incremental encoder - Material feed with ball screw, 950 mm per stroke, any desired cut length from 3 mm to 9999 mm - Hydraulic material clamping with long-stroke cylinder, opening on both sides Klodpfx Aowm Rqtof Nel - Material clamping with double vise before and after the saw blade - Minimum remnant length in automatic mode: 90 mm - Maximum cut length in automatic mode: unlimited - Material support height: 850 mm - Net weight: 2,300 kg - Dimensions (W x H x D): 2580 x 2000 x 2000 mm

Stanje: novo, Leto izdelave: 2024, Razpon rezanja okroglega jekla pri 45°: 108 mm, Obseg rezanja okroglega jekla pri 90°: 108 mm, največja višina reza: 150 mm, BERG+SCHMID Double Mitre Band Saw GBS 218 Eco AutoCut Cutting Speed: 25-80 m/min • Mitre cuts left up to 60° • For cutting steel, stainless steel, and aluminum profiles • Quick-action vice with rapid clamping device a. • Integrated blade tension control b. • Carbide blade guide c. • Electric coolant system • Machine base (supplied disassembled) Ksdpot I R Edofx Af Nsll The AutoCut system consists of: • Hydraulic cylinder, feed control, spring package, end switch, enabling three operating modes: 1. Automatic lowering of the saw frame via hydraulic cylinder with steplessly adjustable feed control valve and limit switch at the end of the cut 2. Rapid descent of the saw frame from rest position to the workpiece, then switches to normal feed rate 3. Manual operation – hydraulic cylinder functions as a brake cylinder Saw blade dimensions: 2455x27x0.9mm Additional accessories such as saw blades, roller conveyors, length stops, minimum quantity lubrication, etc. available on request! Delivery time: ex stock Waiblingen Beinstein

Stanje: rabljeno, used ERHARD+SPIESS vertical band saw, model HK 3C with combined filing attachment. Throat depth: 300 mm with Ideal band welding unit. Klodpfewkuytsx Af Nel Saw blade / band length: approx. 2,800 mm, width 3-10 mm Clearance: 200 mm Cutting speed: 9-800 m/min, adjustable in steps Drive: 1,400 / 2,800 rpm Table tilt adjustment: right/left 15° each, forward/backward 10° each Filing machine: stroke approx. 0-120 mm, max. workpiece thickness 80 mm, strokes/minute 75-300 incl. 5 file holders with 5 different file shapes Delivery time: ex stock, the machine can be inspected by appointment in 713334 Waiblingen Beinstein.

Stanje: novo, Mitre pásu: 2950x27x0,9 mm 2 rýchlosti rezania: 36/72 m/min Šírka zveráku: 285 mm Rezné rozmery pri 90 stupňoch: - Kruhové: 250 mm - Štvorcové: 230 mm - Ploché: 280x200 mm Rezné rozmery pri 45 stupňoch: - Kruhové: 190 mm - Štvorcové: 180 mm Klodpfxsh Dmh Hj Af Nel - Ploché: 180x180 mm Rezné rozmery pri 60 stupňoch: - Kruhové: 120 mm - Štvorcové: 110 mm - Ploché: 110x110 mm Celkový príkon: 1,5/1,8 kW Hmotnosť: 375 kg Rozmery: 1700x1000x1650 mm Vybavenie: - S poloautomatickým spúšťaním ramena - Systém CUT CONTROL umožňuje poloautomatické spúšťanie pílového oblúka vlastnou hmotnosťou pílového rámu - Rýchlosť spúšťania je plynule nastaviteľná. Jednotlivé rezy je možné vykonávať s rovnomerným posuvom

Stanje: rabljeno, Leto izdelave: 2007, Funkcionalnost: popolnoma funkcionalen, Rabljena tračna žaga Beka Mak BMSO450, letnik 2007 Kljdpfxox Rbv Ie Af Nel

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 1972, Funkcionalnost: popolnoma funkcionalen, Steel and Metal Bandsaw / Manufacturer: MÖSSNER REKORD / Type: SSF 801 / Year of manufacture: 1972 TECHNICAL DATA: - Wheel diameter: 800 mm - Throat depth: 785 mm - Max. cutting height: 720 mm - Work table: tiltable to both sides Swivel range: right approx. 45°, left approx. 10° - Saw blade length: min. 5,650 mm, max. 5,800 mm - Saw blade width: 10 / 20 mm - Infinitely variable cutting speeds: 15 - 940 m/min in 3 cutting speed ranges: I: 15 - 79 m/min II: 67 - 305 m/min III: 207 - 940 m/min IV Rapid traverse: 4,000 m/min Kodpfx Aovx Hugsf Njll - Drive: 11 kW - Power supply unit: 500 V, 50 Hz - Machine weight: approx. 2.3 t - Space requirement (W x H x D): approx. 1.6 x 2.9 x 1.9 m Options / Accessories: - Fusion cutting: For fusion cutting of steel sheets of any strength and hardness up to a cutting height of approx. 25–30 mm, the machine is equipped with a direct rapid traverse with a cutting speed of 3,000 or optionally 4,000 m/min. - File band attachment - Belt grinding attachment - Circular cutting device: The circular cutting device is mounted on the guide arm directly above the clamping plate. This allows circular saw cuts with a radius of 40–290 mm to be made. - Saw blade selection Min. cutting radii: Radius: Blade width: 6 mm 3 mm 10 mm 4 mm 17 mm 6 mm 30 mm 8 mm 45 mm 10 mm 140 mm 16 mm The number of teeth on the saw blade depends on the material type and thickness to be cut. Steel: 5–20 mm thickness 14 TPI over 20 mm 8–10 TPI under 5 mm 18–22 TPI Cast iron: 5–20 mm 10–14 TPI over 20 mm 6–8 TPI Brass, copper, zinc: over 5 mm 8–10 TPI under 5 mm 10–14 TPI Aluminium and plastics: over 5 mm 7–10 TPI Fusion cuts: 8–14 TPI - Saw guides The machine is equipped with 2 different saw guides: * 1x precision band saw guide with replaceable, carbide-tipped, ground and lapped guide inserts for 4, 6, 8, and 10 mm blade widths. * 1 set of guide rollers for 20 mm blade width for processing metals and plastics at higher cutting speeds and for fusion cuts. No guarantee for completeness or accuracy of technical specifications and equipment. Subject to prior sale.

Stanje: rabljeno, Leto izdelave: 2024, Optimum Optisaw SD500AV - Variable Band Saw with Siemens Inverter Used band saw with signs of wear Heavy-duty industrial design Quiet operation Manual or semi-automatic operation Infinitely variable saw band speed from 20–80 m/min High cutting accuracy due to vibration-free operation Mitre adjustment -45° to 60° by swivelling the entire saw bow Supplied as standard with a high-quality bi-metal saw blade Microswitch for automatic cut-off Coolant pump Ball-bearing saw band guide with carbide inserts for optimal cutting results Easy adjustment of feed descent speed via flow control valve on the control panel Large, hydraulic quick-release vice, self-closing, laterally adjustable Pressure gauge for correct saw blade tension Clearly arranged control panel Functionality in Semi-Automatic Mode Closing the vice and activating the motor Lowering the saw bow for cutting Stopping the motor and returning the saw bow to the starting position Dimensions and Weights Length approx. 2129 mm Width/depth approx. 1046 mm Height approx. 1687 mm Weight approx. 645 kg Electrical Data Rated output (motor power) 3 kW Hydraulic pump motor power 1.4 kW Coolant pump motor power 0.1 kW Total connected load 3.8 kW Supply voltage 400 V Mains frequency 50 Hz Machine Data Saw band speed(s) 20 – 80 m/min Saw band length 3770 mm Saw band width 34 mm Kjdpfx Ajx Dzv Esf Njll Saw band thickness 1.1 mm Cutting angle range -45° to 60° Manual operation Hydraulic, via push button Semi-automatic operation Automatic Data Generation Real-Time Yes Data Storage Location On the device Data Access Via wireless interfaces Cutting Capacities 0° round (solid material) 355 mm 0° square (solid material) 300 mm 0° rectangle vertical (solid) 300 x 490 mm -45° round (solid material) 290 mm -45° square (solid material) 250 mm -45° rectangle vertical (solid) 250 x 250 mm +45° round (solid material) 350 mm +45° square (solid material) 290 mm +45° rectangle vertical (solid) 290 x 340 mm +60° round (solid material) 230 mm +60° square (solid material) 180 mm +60° rectangle vertical (solid) 180 x 220 mm Cutting Range Explanation: Cutting range determined using aluminium due to the weight of the saw bow. May vary and possibly be reduced depending on the material processed (not the cutting capacity).

Leto izdelave: 2023, Stanje: zelo dobro (rabljeno), Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 001-2023, Trakasta žaga na prodaju – Kompletna dokumentacija priložena, sa svim papirima za mašinu, uključujući direktne kontakte tehničkog osoblja proizvođača. Uključena oprema: - Sistem za dovod trupaca (vidljiv na videu) - 2 potpuno nova visokokvalitetna lista - 2 seta uređaja za oštrenje lista Mogućnosti sečenja: - Opseg prečnika za sečenje: 9 – 32 cm Kodpfx Afsxz Smvj Njll - Mogućnost rezanja rolni do 60 cm dužine (medicinske rolne) - Dostupna opcija za nadogradnju za istovremeno sečenje 2 trupca - Približno 20 rezova u minuti - Kontrola lista i sečenja - Automatsko oštrenje lista - Podesiva dužina oštrenja - Podesiva frekvencija oštrenja (posle koliko rezova) - Podesiva brzina sečenja za sve rezove - Prvi i poslednji rez mogu se individualno usporiti ili ubrzati - Brzina lista je podesiva - Mi radimo sa mašinom na 40% brzine i nikada nismo morali ići više - Podesiva startna tačka pokretnog stola - Svaki pojedinačni rez može se konfigurisati zasebno - Vodilice lista izrađene od visokokvalitetnih ležajeva - Širina lista: 9 cm - Debljina lista: 1,2 mm - Pokazivač zategnutosti lista - Podesiv ugao točka za list Kvalitet izrade mašine: - Izrađena od visokokvalitetnih komponenti i pouzdanih mehaničkih delova

Stanje: novo, Working range approx. 360 mm Working range, quadrant: 360 x 360 mm Working range, bundles (W x H): 180–280 x 50–160 mm Cutting speed: 20–100 m/min (stepless adjustment) Saw blade dimensions: 4,420 mm x 34 mm x 1.1 mm Saw blade tension: hydraulic Multiple feed: 500 mm Drive power: 3.7 kW Machine dimensions (L x W): 2,500 x 2,200 mm Machine weight: 2,300 kg Standard equipment - Hydraulically controlled full-stroke double vice clamping system - Drive via IE3 motor with frequency inverter (PMSM, equivalent to IE4) - User-friendly NC touchscreen control with high-end system (NCIII CONTROL) - Display of feed speed on HMI (10" HMI screen) - Automatic chip conveyor - Automatic shuttle feed - IC-board control for all electrical and hydraulic functions - Floating pendulum vice - Split front vice - Stepless speed control via inverter - Hydraulic blade tensioning - Roller bearings with hydraulically controlled carbide blade guiding system Klsdpfeqrqvhjx Af Nsl - Automatic workpiece height adjustment by quick-start sensor - Preset cut counter with auto shut-off - Bundle cutting nesting device (hold-down clamp) - Power-driven blade cleaning brush - Saw blade monitoring for standstill and blade breakage - Washing hose for machine cleaning - Work lamp - Roller table, 2 m length - One M42 bimetal saw blade - One set of tools and toolbox

Stanje: novo, Working range approx. 360 mm Working range, quadrant: 360 x 360 mm Working range, bundles (W x H): 180 - 280 x 50 - 160 mm Cutting speed: 20 - 100 m/min (infinitely variable) Saw band dimensions: 4,420 mm x 34 mm x 1.1 mm Saw blade tension: hydraulic Multiple feed: 500 mm Drive power: 3.7 kW Machine dimensions (L x W): 2,500 x 2,200 mm Machine weight: 2,300 kg Standard equipment - Hydraulically controlled full-stroke double-vice clamping system - Drive by IE3 motor with frequency inverter (PMSM, equivalent to IE4) - User-friendly PC control with touch screen - Display of feed speed on HMI (10" HMI screen) - Automatic chip conveyor - Automatic shuttle feed - IC-board control for all electrical and hydraulic functions - Floating pendulum vise - Split front vise Ksdpfx Aewhli Hof Noll - Infinitely variable speed control via inverter - Hydraulic blade tension - Roller bearings with hydraulically controlled carbide blade guide system - Automatic work height control via quick-start sensor - Preset cut counter with automatic shut-off - Nesting device for bundle cutting (hold-down) - Powered blade cleaning brush - Saw band monitoring for standstill and band breakage - Cleaning hose for machine cleaning - Work light - Roller table, 2 m length - One M42 bi-metal saw blade - One set of tools and toolbox - Full enclosure

Stanje: zelo dobro (rabljeno), Delilna žaga ACM BS 940 RS3 s centrirnikom Premer koles: 940 mm Dimenzije rezalnih trakov: min. 6580x90x0,9 mm / max. 6670x90x0,9 mm Nagib mize: 0-20° Avtomatski centrirnik Podajalnik ARTIGLIO RSA 80 Hitrost podajanja nastavljiva z variatorjem Moč motorja: 11 kW Tehnična dokumentacija Teža: 1100 kg Klsdpfx Ajxanvwsf Nsl Zunanje dimenzije žage: 1660x1720x2900 mm

Stanje: rabljeno, Leto izdelave: 2007, številka stroja/vozila: 0102-240014, This Voortman VB1050 bandsaw is designed for efficient cutting of structural steel profiles up to a maximum profile size of 1000 mm and a profile length of 19,200 mm. This CNC-controlled Voortman VB 1050 bandsaw features a mitre adjustment to the left/right, a length measuring carriage, and roller conveyors at both the infeed and outfeed sides for material handling. Working Areas: - At a 90° cut, the working area is 500 mm x 1,130 mm - At a +/- 45° mitre cut, the working area is 500 mm x 725 mm - At a +/- 60° mitre cut, the cutting area is 500 mm x 470 mm Equipped with a saw blade measuring 9,550 x 54 x 1.6 mm, the bandsaw enables precise cuts. The machine weight without accessories is approximately 8,500 kg. Kljdpfxsr Hrrls Af Nsl A Vacon 110 CNC control is used for programming the Voortman VB1050. An outstanding feature of the Voortman VB series is the movable saw table, where the saw blade and cutting area move in sync. This ensures that the saw blade never cuts into the table and allows for stepless rotation for precision cuts. During mitre cuts, the table automatically lowers to allow free rotation to the next angle. For recommissioning, a new safety system must be procured and implemented in accordance with local requirements (hardware & software; not included in the scope of supply!).

Stanje: dober (rabljeno), Leto izdelave: 2004, Funkcionalnost: popolnoma funkcionalen, dolžina tračnega lista: 5.700 mm, največja višina reza: 400 mm, stepless cutting speed hydraulic material clamping automatic feed chip conveyor coolant system roller conveyor Technical Data: Cutting range round: 400 mm Cutting range square: 400 x 400 mm Multiple feed: 20,000 mm Cutting speed: 20-110 m/min Saw band dimensions: 5700 x 41 x 1.3 mm Drive capacity: 8 kW Kjdpfotzkdgsx Af Nsll Machine weight approx.: 2,700 kg Technical data, accessories and machine description are not binding.

Stanje: dober (rabljeno), Leto izdelave: 2015, Funkcionalnost: popolnoma funkcionalen, Razpon rezanja okroglega jekla pri 45°: 260 mm, največja višina reza: 320 mm, Infinitely variable cutting speed Kjdpfewvi Agsx Af Nell Hydraulic material clamping Automatic feed unit Coolant system Roller conveyor Manually swiveling saw frame for miter cuts Technical Data: Cutting range round 0°: 320 mm Cutting range square 0°: 350 x 320 mm Cutting range round 45°: 260 mm Cutting range square 45°: 250 x 180 mm Cutting speed: 20–100 m/min Saw band dimensions: 3660 x 27 x 0.9 mm Drive power: 3.9 kW Machine weight approx.: 1825 kg Technical data, accessories, and machine description are not binding.

Stanje: novo, Leto izdelave: 2014, Funkcionalnost: popolnoma funkcionalen, dolžina tračnega lista: 4.780 mm, Polavtomatska tračna žaga za dvojne poševne reze za rezanje pod kotom levo in desno do 60°. Tehnični podatki: - Pogon žage 3,0 kW - Hitrost rezanja 20-120 m/min - Delovna višina pribl. 760 mm - Dimenzije žaginega traku 4780x34x1,1 mm Območja reza: Kodpfxox U Augs Af Njll 90° Ø 350 ali 510 x 350 mm 45° Ø 350 ali 415 x 100 mm 60° Ø 270 ali 280 x 100 mm
