Cnc Deljenjem Glavo nakup rabljenega (9.395)

Stanje: rabljeno, Leto izdelave: 1994, Lokacija skladišča: Nattheim Nledpfx Aowmm Nregxea

Stanje: rabljeno, Leto izdelave: 2021, Expozicijska enota (malo rabljena) Enota za rezanje mehkih materialov, kot so satovje, akustični elementi in tkanine, z nihajnimi gibi Možnosti obdelave: rezanje ravnih ali radialnih izrezov Tipična področja uporabe: • Tekstil: rezanje tkanin ali tekstilij (npr. usnje, klobučevina itd.) • Razrez satovja pri vratih, stopniščni gradnji, sejemski gradnji, gradnji avtodomov • Akustični elementi: rezanje poliestra, pene ali drugih zvočno absorpcijskih materialov • Letalstvo, ladjedelništvo, vesoljska industrija: rezanje satovja (honeycomb core) Tehnične specifikacije Največja vhodna hitrost vrtenja: 6.000 min-1 Največja izhodna hitrost vrtenja: 9.000 min-1 Prenos: 1 : 1,48 Največji navor: 8 Nm Dovoljena obratovalna temperatura: maks. 85°C Položaj nosilca navora glede na orodje: 360° Kot obdelave: 0° Št. izhodov za orodje: 1 / fiksno Mazanje: mast / polnjenje za celotno življenjsko dobo Amplituda: 4 mm Frekvenca: 150 Hz Lokacija skladišča: Garbsen. Nljdpfx Agsvvi Iqsxea

Stanje: rabljeno, Leto izdelave: 2021, Razstavni agregat (malo rabljen) Mazanje: mast Največja izhodna hitrost n2: 4.000 min⁻¹ Prenos (n1:n2): 1:0,8 Teža: cca 8 kg Priklop na stroj HSK F63 Oprijem orodja Uporabna širina 24 Lokacija skladišča: Garbsen Nlodpjvvi Iwsfx Agxja

Stanje: rabljeno, Leto izdelave: 2002, Obdelovalne mere (premer orodja 25 mm): X=3015 mm Y=1483 mm Z=325 mm Maks. hodilci: X=3268 mm Y=1483 mm Z=325 mm največja programska hitrost: X/Y = 75 m/min / Z = 30 m/min Orodni nosilec HSK 63F Vrtalna enota 7964, 14 vertikalnih vrtalnih vreten s 32 mm razdaljo (10 v x / 4 v y) Žagalna enota 7946, 3,6 kW, pnevmatsko vrtljivo za 90° Glodalna enota 7933, 9 kW Lesena C-os (vektorska os) Magazin za orodja (krožnik s 6 mesti) Ročna upravljalna naprava Laserska naprava (pozicioniranje sesalcev) PC upravljalna konzola z 17" monitorjem Operacijski sistem Windows 2000 Programska oprema: TwinCAM32 - office verzija Vakuumska črpalka 100 m³/h suhi tek Selektivne varnostne stopalne preproge (3-polno delitev) Lokacija zaloge: Nattheim Nedpfovvi Nbjx Agxola

Stanje: rabljeno, Leto izdelave: 2008, · Working area X-Y-Z: 3,660 x 1,550 x 130 mm · Travel length X-Y: 4,200 x 2,000 mm Description of Units and Accessories (Basic) The machine base is a monolithic design made from thick-walled steel. It is reinforced throughout the entire machine bed with welded triangular plates, which ensures exceptional rigidity. The use of a large-base triangular form in load-bearing components is key to ensuring lasting precision and stability. The machine layout allows an optimal workflow for the operator while requiring minimal space. This robust base offers the processing unit a balanced and secure foundation with excellent load distribution. The mobile gantry unit carrier is built from a solid monoblock. It moves in the X direction on prismatic, ground guides with recirculating ball carriages. Mounted on the mobile unit carrier, the processing unit also travels on prismatic, ground guides and recirculating ball carriages. Axis Movement: The drive system in the Y and Z axes utilizes precision-ground recirculating ball screws of the highest accuracy grade. The drive in the X-axis is by a backlash-free, preloaded precision rack and pinion system. This enables balanced load distribution during positioning. Such characteristics are essential for smooth operation, even in complex machining scenarios. Axis movement is powered by brushless AC servo motors, which provide excellent positioning speeds thanks to very short ramp times. The feedback systems are fully integrated into these motors, making the drive system entirely maintenance-free. · Rapid traverse in X: 40 m/min · Rapid traverse in Y: 60 m/min · Rapid traverse in Z: 22.5 m/min Vacuum System (Basic) · Vacuum pump: 100 cbm/h · Power: 2.5 kW · Max. negative pressure (connection): 0.9 bar Control System / Control Cabinet · Office PC or industrial PC (see options) · Basic NC Control: ESA-GV KVARA 6.0 · Cable remote controller with main functions ELECTRICAL/ELECTRONIC CNC CONTROL Universal is equipped with a powerful NC control. The integrated office PC provides the NC control with a unique level of familiarity: the software operates on Windows XP and allows fast and easy programming, which is also easy for inexperienced users to learn. The system is open, supporting connections for CD-ROM drive, sound card, barcode reader, modem, printer, scanning systems, etc. Installation of all network systems and any commonly available CAD programs is also possible. To save space, the control cabinet is located beneath the machine table, and the operator works from a separate, mobile control terminal that can be freely positioned. PROGRAMMING SYSTEM XILOG Software Features: - Import of DXF files Nlsdjvvi Nzspfx Agxja - Import of ASCII files - User interface in the operator's native language (available in I - GB - F - D - E) - Linear and circular interpolation in three axes, linear in space, spiral in the selected plane - Supported programming - Calculator for direct data transfer - Graphics and syntax help for drilling and milling operations - Parametric programming to perform identical panel processing on different p...

Stanje: rabljeno, Leto izdelave: 2020, CNC-CONTROLLED MACHINING CENTER WITH MULTIFUNCTION TABLE – WORK CELL VERSION X400 CELL Drilling and milling, made for you! This numerically controlled machining center comes equipped with a comprehensive range of milling/drilling tools to meet any requirements for processing wood and similar materials. - Highly efficient, equipped with drilling spindles at 8,000 rpm and the most robust spindle technology available on the market, offering more than 1,000 maintenance-free operating hours. - Superior and more comprehensively equipped: various configuration options via the multifunction table, allowing the machine to be optimally equipped according to specific requirements. - Easier and more intuitive programming, thanks to the integrated Maestro CNC CAD/CAM module. - User-friendly: The work table is always accessible, the control cabinet and vacuum pump are integrated, and in the PRO SPACE configuration, there are no safety barriers. Load-Bearing Structure The load-bearing structure consists of a particularly robust monolithic steel base, heavily ribbed and very rigid. The especially wide support surface was specially designed to provide the machine with maximum stability, ensuring lasting precision regardless of operating conditions, and does not require anchoring to the floor. The base forms a large and solid support for the moving gantry: the work unit is thus equipped with a balanced, stable, and highly resilient support, capable of withstanding even the most demanding stress loads, leading to improved performance quality and greater accuracy. The moving gantry is a solid single component anchored to both sides of the base and slides along prismatic guides with recirculating ball shoes of the highest quality. Dual motorization along the X-axis ensures top performance even under heavy-duty operating conditions. Movement of the lower mobile unit (X-axis) and the working unit along the beam of the mobile unit (Y-axis) is achieved via a helical rack and pinion drive. This provides greater tooth-on-tooth engagement, achieving higher acceleration as well as increased speed along the X and Y axes. Nsdpfxjvvi N Io Agxsla The specially designed helical gearing ensures reduced wear of mechanical components and quieter operation. The vertical Z-axis is driven by a recirculating ball screw, ensuring perfect balance under dynamic loads and allowing for strong acceleration and deceleration. The main milling unit is directly coupled to the Z-axis slide, ensuring the finest machining quality by eliminating vibrations. Movement along X-Y-Z axes is provided by brushless motors, powered by static inverters, delivering: - Reduced processing times thanks to improved acceleration - Greater positioning accuracy thanks to high-resolution encoders - No more reference point setup at machine startup due to absolute encoders - Eliminated general maintenance for the drive system since the brushless system contains no brushes Management of axis movements and general machine components is performed via an industrial NS module with digital D...

Stanje: rabljeno, Leto izdelave: 2008, · Working area X-Y-Z: 3,660 x 1,550 x 130 mm · Travel length X-Y: 4,200 x 2,000 mm Description of Units and Accessories (Basic) The base frame structure is a monolithic construction made from thick-walled steel. It is reinforced with welded triangular steel plates across the entire machine bed, resulting in exceptional stability. The triangle shape with a wide base used for load-bearing components is the secret to ensuring long-term precision and stability. The machine layout allows the user to achieve an optimized workflow while minimizing the required footprint. The base structure supports the machining unit with a balanced and secure foundation, offering particularly effective load distribution. The mobile gantry-style aggregate carrier is constructed as a solid monoblock. It is positioned in the X-axis on precision-ground prismatic guides via linear ball bearing carriages. On this carrier, the machining unit is also mounted on prismatic, ground guides and linear ball bearing carriages. Axis Motion: The drive system for the Y and Z axes uses precision-ground ball screws of the highest accuracy class. The X axis is driven by a backlash-free, preloaded precision rack and pinion system, ensuring balanced load distribution during positioning. This characteristic is essential to guarantee smooth motion, even in complex operations. All axis movements are performed by brushless AC servomotors. These deliver excellent positioning speeds due to their very short ramp-up times, and their measuring systems are fully integrated. These features make this type of drive completely maintenance-free. · Rapid traverse X: 40 m/min · Rapid traverse Y: 60 m/min · Rapid traverse Z: 22.5 m/min Vacuum System (Basic) · Vacuum pump: 100 cbm/h · Power: 2.5 kW · Max. vacuum (connection): 0.9 bar Control System / Control Cabinet · Office PC or Industrial PC (see options) · Basic NC Control: ESA-GV KVARA 6.0 Nljdjvvi Rfopfx Agxoa · Cable remote control unit with essential functions ELECTRICAL/ELECTRONIC CNC CONTROL The universal system is equipped with a powerful NC control. The integrated office PC brings a unique level of familiarity to the NC control: the software runs on Windows XP, allowing fast and easy programming, which can be quickly mastered even by inexperienced users. The system is open and accommodates the connection of CD-ROM drives, audio cards, barcode scanners, modem, printer, scan systems, etc. Installation of all standard network systems and all commercially available CAD programs is possible. To save space, the control cabinet is installed beneath the machine table; the operator works at a separate mobile terminal that can be freely positioned. PROGRAMMING SYSTEM XILOG Software features: - Import of DXF files - Import of ASCII files - User interface in the operator's native language (available in I, GB, F, D, E) - Linear and circular interpolation in three axes, spatially linear, spiral in the selected plane - Supported programming - Calculator for direct transfer of calculated data - Graphic and syntax aids for drilling and milling operations - Parametric programming to allow identical panel processing on different

Stanje: rabljeno, Leto izdelave: 1999, Lokacija skladišča: Nattheim Nlodpfx Asvvi Rxogxsa

Stanje: rabljeno, Leto izdelave: 2019, including tools CNC-CONTROLLED MACHINING CENTER morbidelli m100 Drilling and milling made for you! This numerically controlled machining center comes with a comprehensive array of milling and drilling tools to meet any woodworking requirement. - Highly efficient: equipped with drilling spindles running at 8,000 rpm and the industry's most robust spindle technology, offering over 1,000 maintenance-free operating hours. - Optimal and completely equipped: the suction cups can be individually configured on the TV FLEX worktable, allowing the machine to be tailored precisely to your needs. - Easy and intuitive programming thanks to integrated Cad-Cam MAESTRO CNC software. - User-friendly operation: the lowered machine frame provides easy access to the worktable at all times. The control cabinet and vacuum pump are integrated into the machine bed. In the PRO SPACE version, no additional protective infrastructure is required. Supporting structure Nsdjvvi Scspfx Agxela The supporting frame is made from an exceptionally sturdy, monolithic steel base, heavily ribbed and extremely robust. The extra-wide support surface is specially designed to give the machine maximum stability and to ensure constant precision under all working conditions. No floor anchoring is required. The base forms a large and solid support for the moving gantry. The machining unit is equipped with a balanced, stable, and highly durable support structure that withstands heavy loads, guaranteeing top-tier performance and superior accuracy. The moving gantry is made from a single, solid piece, anchored to the base, and runs on premium prismatic rails with ball-bearing carriages. The machining unit is attached to this and moves in the Y and Z axes, also on prismatic rails with ball-bearing carriages. The movement of the lower mobile unit (X axis) and the machining unit along the gantry (Y axis) is ensured by a rack-and-pinion drive with helical gears, resulting in greater tooth engagement for increased acceleration and higher speeds along the X and Y axes. The specially designed helical gearing reduces wear on mechanical parts and enables quieter operation. The vertical Z-axis is driven by a ball screw, which ensures perfect balance under dynamic load, as well as high acceleration and deceleration speeds. The main milling unit is directly coupled to the Z-axis carriage, providing extremely fine processing quality by eliminating vibrations. The X-Y-Z axis movements are driven by brushless motors powered by static inverters, which provide: - Shorter machining times thanks to improved acceleration - Greater positioning accuracy thanks to high-resolution encoders - No setup required upon machine start-up due to absolute encoders - Elimination of general maintenance work as the brushless system has no brushes The control and management of all axes and working elements is handled via e

Stanje: rabljeno, Lokacija skladišča: Nattheim Njdpfx Aswkirqogxsla

Stanje: rabljeno, Leto izdelave: 2009, automatic central lubrication milling unit 7833, 2-stage, 11 kW power, 1,000 - 24,000 rpm; 1 double drilling spindle in X direction; 1 integrated saw unit for sawing/grooving in X direction, traversing; tool changer 7892, 16-position linear pick-up changer, permanently installed on the right side of the machine; laser pointer set: 2 laser pointers for positioning the vacuum cups or referencing the workpiece contour; automatic console and vacuum cup positioning; 6 consoles incl. 3 vacuum cup mounts per console, incl. 1 vacuum cup 80x80 mm per mount; incl. 4 loading aids; additional processing zones at the front for 6 consoles; base unit pneumatic system for frame clamping system 7974 (6 consoles); 2D barcode scanner; video camera in the machining head; vacuum pump 140 m³/h; Vario tool change unit package consisting of: vector axis 7899 (C-axis) fully interpolating, 0-360° infinitely rotatable, incl. pneumatic tool changer 7890, single-position magazine, pick-up system, fixed installation in front of the machine frame on the left; tool changer 7894, 6-position pick-up magazine especially for Vario tool change tool holders, fixed installation in the left side of the machine frame, can be equipped with collet chucks Vario Grip KSJ F 40, 3 pcs. tool holders Vario Grip KSJ F 40 (for collets 2-20 mm ER32), 1 pc. saw blade adapter, 3 pcs. collets per customer selection, 1 pc. carbide circular saw blade max. 220 mm diameter. Nljdpfovvi Spex Agxsa Location: Nattheim

Stanje: rabljeno, Leto izdelave: 2007, Funkcionalnost: popolnoma funkcionalen, Krmiljenje HAAS Maksimalna dolžina struženja (Z-os): 610 mm Maksimalni premer struženja nad ležiščem: 262 mm Število CNC osi: 2 Pogonska moč: 14,7 kW Vector Drive Premer vretena: 51 mm Maksimalno število obratov glavnega vretena: 4000 obr/min Število revolverjev: 1 Število orodij v revolverju: 10 Vreteno: A2-6 Teža cca 4800 kg Dimenzije D x Š x V = 2600 x 1700 x 1800 mm Oprema - Odvajač ostružkov - Sistem hlajenja - Konjiček - Merilna roka za orodja - Hidravlična triosna vpenjalna glava - Nožna stikala Nljdpfey Du R Eex Agxsa - Signalna luč Stroj se prodaja zaradi likvidacije podjetja. Ni več priključen na elektriko.

Stanje: kot nova (razstavni stroj), Leto izdelave: 2023, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: AT1379, SPINNER TC600 with travel ranges X=275mm, Z=700mm in 45-degree slant bed design with hardened and ground slideways Configured as a SINGLE-SPINDLE LATHE with turret WITH driven tools WITH Y-axis INDEXING TURRET – WITH driven tool stations All tool positions driven, servo turret Turret indexing speed adjustable Turret tool mounting system: BMT45 Nledpfx Aoyk Al Asgxsa Number of tool stations in turret: 16 SPINDLE 1, version up to 4,000 rpm - 65mm As integrated motor spindle with water cooling With hydraulic hollow clamping cylinder, bar capacity 65mm Speed range 0-4,000 rpm, Pmax 34 kW / 325Nm POWER CHUCK by SMW-Autoblok D=250mm 3-jaw, model BHD Set of soft jaws, set of hardened top jaws COMPRESSED AIR BLOW-OFF NOZZLE spindle 1 CNC CLAMPING FORCE ADJUSTMENT on spindle 1 SPINDLE FLUSHING spindle 1 FOOT SWITCH CNC TAILSTOCK with integrated bearing Traversable as CNC axis in line with the main spindle. Tailstock force programmable. FOOT SWITCH for moving the tailstock quill during part loading DIRECT MEASURING SYSTEM in X-axis Control SIEMENS 840DE with the following basic configuration: - SPINNER SPIOS 24" touch control panel for I4.0 applications - Height-adjustable, rotatable, and tiltable control panel for optimal ergonomics - incl. engraving cycles - 24" LCD touchscreen with multi-touch functionality - User memory 2 GByte - 15 zero offset settings - 1 free USB port - Standard Ethernet interface SPINNER MULTI-CONTROL-WHEEL on the control panel All key setup functions integrated into one control element MULTIFUNCTIONAL HANDHELD OPERATOR UNIT with integrated display SHOPTURN, 4-axis machining, 3D SIMULATION, REMNANT DETECTION, DXF reader Energy-saving function incl. automatic machine shutdown CHIP CONVEYOR Hinged belt conveyor, discharge to the right, incl. integrated coolant tank and conveyor pump HIGH PRESSURE PUMP 15 bar CARTRIDGE FINE FILTER MEASURING PROBE for tool measurement in working area AUTOMATIC DOOR for working area Universal robot interface UNIROB STANDARD DOCUMENTATION GERMAN Consisting of machine manual and CNC handbooks Delivered in digital form on the control system. STANDARD TWO-COLOR PAINTWORK, light grey RAL7035 and blue grey RAL5008 Electrical configuration EUROPEAN STANDARD as follows: Operating voltage 3x400V +/-10% Mains frequency 50Hz (+/-2%) TN network (5 wire) Tool holder package Notes: The price includes warranty services only within Germany. For new and demonstration machines, the images shown are not necessarily of the specific machine but may be of similar models. Accessories such as clamping devices or tool holders are only included as far as listed in the technical description. Request a detailed factory quotation. Visit our factory near Munich or one of our showrooms. We may have other offers for similar machines. Interim sale expressly reserved.

Stanje: rabljeno, Leto izdelave: 2016, proizvajalec krmilnikov: Heidenhain / Siemens, model krmilnika: TNC620, Description: General: Designation: Automatic Profile Machining Centre AP-B 4000 Machining length: 4,000 mm Travel paths X/Y/Z: 4,100 / 420 / 300 mm Machine enclosure: Pneumatic machine hood, opens upwards Operation: Operator terminal movable along the machine length Control system: CNC control Heidenhain TNC 620 Additional control: Heidenhain handwheel HR130 Table specification: T-slot rails, size 16, mounted longitudinally to X-axis Support surface: 4,200 x 420 mm Nlsdpfx Asy Ea Huogxja Spindle: Motor power: 14 kW S1 / 19 kW S6 Motor cooling: Water with additive Speed range: 100 to 14,000 rpm Rated speed: 1,800 rpm Torque: 74 Nm S1 / 100 Nm S6 Drilling capacity in St 60/Aluminium: 25 mm / 30 mm Thread cutting in St 60/Aluminium: M20 / M30 Tool magazine: Tool holder: SK 40 Tool clamping system: Spring pack drawbar force 9 kN Design: 12-position disc magazine Tool change time: Approx. 10 sec Cooling: Designation: Coolant system (emulsion) Delivery rate: 40–60 l/min Tank capacity: 250 l Extras: Coolant rinsing pistol Accessories/Extras: Waste management: Chip tray with 4 drawers Safety: Pendulum operation with light barrier

Stanje: rabljeno, Leto izdelave: 2023, proizvajalec krmilnikov: Siemens, model krmilnika: 828D - ShopTurn, Opis: Glavna vretena: Glava: SAMCHULLY HS-12 (12 palcev) Maksimalna hitrost vretena: 3.000 obr/min. Vpenjalna čeljust: A2-8 Moč motorja (stalno/maks.): 18,5 kW / 26 kW Maks. premer struženja x dolžina struženja: 405 mm x 956 mm Nosilec orodja (X/Z): Število orodnih mest: 12x BMT65 Maks. premer rezkanja: 433 mm Hodi (X/Z): 245 mm / 1.040 mm Hitri pomik (X/Z): 24 m/min / 30 m/min Konjiček: Premer pinole: 110 mm Hod pinole: 100 mm Nljdpfsy Ea Hnjx Agxea Oprema/dodatki: Krmiljenje: SIEMENS 828D - ShopTurn Postelja: postelja pod kotom 45°, iz enega kosa Dodatna oprema: merilna tipala za orodja (preklopno) Zaščita pred trkom: revolver z zobčenikom Hirth Leto izdelave: 2023 Teža: 5.600 kg (po tipski tablici konfiguracije) Ravnanje z odrezki: transporter za odrezke Električni priključek: 380 V / 50/60 Hz / 42 kVA

Stanje: rabljeno, Leto izdelave: 2015, Funkcionalnost: popolnoma funkcionalen, Travel X: 290 mm Travel Z: 560 mm Travel W: 640 mm Travel Y: ±55 mm Main Spindle Main spindle power: 28 kW Main spindle torque: 242 Nm Spindle nose: A2-6 Bar capacity: 64 mm Max. swing diameter: 508 mm Chuck diameter: 203 mm Spindle speed: 4,500 rpm Feeds Njdpfoy Dgfbex Agxsla X-axis feed rate: 24 m/min Z-axis feed rate: 30 m/min W-axis feed rate: 30 m/min Y-axis feed rate: 12 m/min Turret Turret: 12 stations Tool holder: VDI40 Max. boring bar diameter: 40 mm Shank cross-section: 25×25 mm Driven Tools Driven tool speed: 4,000 rpm Driven tool power: 5.4 kW Driven tool torque: 24 Nm Indexing time: 0.16 s Sub-spindle Max. sub-spindle speed: 6,000 rpm Sub-spindle torque: 70 Nm MACHINE DETAILS Electrical connection values: 66 kVA / 95 A / 400 V Compressed air connection values: 7 bar / 150 l/min Weight: 7,000 kg Operating Hours Total power-on hours: 60,496 h Spindle hours: 19,299 h EQUIPMENT IRCO/Breuning SIMAG 80.1-2R-3000 bar feeder Various channels Chip conveyor Tool setter t Transformer Cooling unit Coolant tray Fixed and driven tool holders Spare main spindle (not refurbished) Various collet chucks, size 65 Documentation (circuit diagrams, operator’s manual, etc.)

Leto izdelave: 2007, stanje: pripravljen za uporabo (rabljen), - RABLJEN - 8-OSNI CNC STRUŽNIK Z REZKALNO GLAVO, SPODNJO REVOLVERSKO GLAVO IN PROTIVRETENOM RAZDALJA MED SREDIŠČI: 210 - 1290 mm MAKSIMALNA DOLŽINA STRUŽENJA: 1090 mm MAKSIMALNI PREMER STRUŽENJA: 245 mm PREMER PALICE: 65 mm VRETENO: 11-15 kW; 221,5 Nm PROTIVRETENO: 6000 vrt/min; 7,5 - 11 kW GLAVA: HSK A63 ; 3,7 - 5,5 kW HOD OSI X1: 455 mm HOD OSI X2: 222,5 mm HOD OSI Y1: ± 70 mm HOD OSI Y2: +20 -50 mm HOD OSI Z1: 1090 mm HOD OSI Z2: 1005 mm HOD OSI B: 1080 mm HITRI POMIKI X-Y-Z: 16 - 6-16 - 40 m/min GONJENA REVOLVERSKA GLAVA: 12 + 12 POZICIJ; 6000 vrt/min; 3,7 - 7,5 kW VISOKOTLAČNO HLADILNO SREDSTVO: 25 Bar Krmilna enota: FANUC 31i-A Nledpfxoxppnms Agxoa PODAJNIK PALIC: LNS Mod. Hydrobar Sprint S3 TEŽA: 16.000 kg SKUPNE DIMENZIJE: 5551 x 2925 x 2755 mm DODATNA OPREMA: VISOKOTLAČNO HLADILNO SREDSTVO; TRANSPORTER OSTRUŽKOV; TRANSPORTER ZA OBDELOVANCE

Stanje: rabljeno, Leto izdelave: 2020, CNC-CONTROLLED MACHINING CENTER WITH MULTIFUNCTION TABLE morbidelli x200 The Drilling and Milling Solution Made for You! The numerically controlled machining center is equipped with a comprehensive range of tools for milling and drilling, designed to meet any requirement in the processing of wood and similar materials. Ø High-performance with boring spindles running at 8,000 RPM, featuring the hardest spindle technology available on the market, offering over 1,000 hours of maintenance-free operation. Ø Better and richer equipment, featuring various configuration options thanks to the multifunction table, allowing the machine to be optimally set up according to the specific requirements. Ø Easier and more intuitive programming due to the integrated CAD/CAM module "MAESTRO CNC". Ø User-friendly: the worktable is accessible at all times, the control cabinet and vacuum pump are integrated, and with the PRO SPACE configuration there are no safety barriers. Supporting structure: The supporting structure consists of a particularly robust monolithic steel base, heavily ribbed and highly rigid; the especially wide bearing surface is purpose-designed to provide the machine with stability, ensuring lasting precision regardless of operating conditions, and the machine does not require floor anchoring. The base forms a large and solid support for the mobile gantry: the working unit thus benefits from a balanced, stable, and durable support that withstands even the highest stresses, ensuring higher-quality performance and greater accuracy. The mobile gantry is made from a solid single piece, anchored on both sides of the base, and runs on top-quality prismatic guides with recirculating ball carriages. Dual drive on the X-axis guarantees top performance even under heavy-duty conditions. Movement of the lower mobile unit (X-axis) and the working unit along the gantry (Y-axis) is achieved via helical rack-and-pinion transmission, delivering higher tooth engagement for increased acceleration and greater speed along the X and Y axes. The specially designed helical gearing reduces wear on mechanical components and ensures quieter operation. The vertical Z-axis is driven by a recirculating ball screw, ensuring perfect balance under dynamic loads and supporting strong accelerations and decelerations. The main milling unit is directly attached to the Z-axis carriage, ensuring top-quality finishing by entirely eliminating vibrations. Movements along the X-Y-Z axes are executed with brushless motors powered by static inverters, offering: - Reduced processing times due to improved acceleration - Greater positioning accuracy through high-resolution encoders - Zero setup referencing required on machine start-up thanks to absolute encoders - Elimination of general maintenance operations, as the brushless system is free of brushes. The management of axis movements and all machine elements is handled via an industrial NS module with digital data transmission. Nsdpfx Agjywvldsxola

Stanje: rabljeno, Leto izdelave: 2007, Face plate diameter: 2,500 mm Max. swing diameter over bed: 2,700 mm Turning height: 2,500 mm Control: Siemens 840D CNC Max. workpiece weight: 30 t Workpiece diameter: 2,500 mm Crossrail travel: every 100 mm up to 1,200 mm Ram stroke: 1,500 mm Ram cross-section: 250 x 250 mm Travelling speed: 8 m/min Max. vertical feed rate: 6,000 mm/min Max. cross feed rate: 8,000 mm/min Table speed: 180 rpm Tool change time: 1 min Cutting speed: 140 m/min Nsdpfx Aoy Dvlwjgxjla Cutting depth: 14 mm Main drive power: 100 kW Machine weight: approx. 47 t Space required: approx. 12.5 x 8.0 x 6.7 m Equipment/Accessories: - Crossrail adjustable in 100 mm increments including locking - 2 rams, each with 250 x 250 mm cross-section, 1,500 mm stroke - Both rams traversable over the center (by 100 mm each), i.e., both ball screws offset with collision protection - ZF gearbox for main drive AC 100 kW / S1 Siemens, speed 0–180 rpm - 2 tool changers, 16 stations each - Max. tool weight: 50 kg; max. 800 kg in tool changer - 2 Renishaw touch probes for zero point setting - Renishaw touch probe for workpiece measurement

Stanje: novo, Leto izdelave: 2026, Funkcionalnost: popolnoma funkcionalen, The GWDress-250 smartline is the intelligent solution for precise dressing of grinding wheels up to a diameter of 250 mm. Thanks to selectable manual or automatic control, dressing processes can be flexibly and highly efficiently configured. Performance Data: - Rotary and feed axes, CNC-controlled - Diamond grinding spindle: HSK-50 or per customer request (e.g., SK-40, Perfect Arbor, etc.) - Max. dresser wheel diameter: ø300 mm - Max. dresser wheel width: 20 mm - Max. grinding wheel diameter: up to ø250 mm - Grinding wheel speed: 0–1500 rpm (infinitely variable) - Range of motion, left/right: 135 mm - Range of motion, forward/backward: 135 mm - Dresser wheel dimensions (silicon carbide): ø180x10xΨ32 mm - Approx. 98 degrees traversable on both sides - Dresser wheel speed: 0–2800 rpm (infinitely variable) - Dresser wheel oscillation frequency: 0–50 cycles/min (infinitely variable) - Dresser wheel oscillation length: 0–50 mm (adjustable) - X, Y axis optical scale system: 0.001 mm - Capabilities: Profile dressing, disc pack dressing - Connection: 380V, 50Hz, total power approx. 1.5 kW - DXF import included Njdpfx Aow E E S Aogxela - Camera system with live transmission to a 23" monitor included - Latest software generation GWDress-Studio with automatic AI measurement included - Country of origin: Austria

Stanje: dober (rabljeno), Leto izdelave: 2008, Funkcionalnost: popolnoma funkcionalen, Stroj je v dobrem tehničnem stanju, po predhodnem dogovoru možnost preizkusa. Vrtanje z vretenom preko vlečne cevi 103 mm, vpenjalna glava 315 mm, vpenjanje 100 mm, podajalnik materiala Samsys Multi 3000, odstranjevalnik obdelovancev, izmetalec ostružkov, konjiček /neuporabljen, deaktiviran/, revolverska glava za 12 orodij, Največji premer za obdelavo: 17,0″, Največja dolžina za obdelavo: 26,2″, Največja kapaciteta palice: 3,0″, Zamah preko postelje: 30,0″, Pomik po osi X: 11,3″, Pomik po osi Z: 34,0″, Hitri pomik osi X: 710 IPM, Hitri pomik osi Z: 710 IPM, Glava vretena: A2-6, Vrtina vretena: 3,50″, Število obratov vretena: 0 – 3400 min⁻¹, Motor vretena: 30 HP, Kapaciteta revolverske glave: 12 postaj, Čas indeksiranja glave: 1 sekunda. Na voljo 2 kosa. Natančnost: stotinke milimetra. Nsdpfey Hi Drox Agxela

Stanje: dober (rabljeno), Leto izdelave: 2019, V dobrem tehničnem stanju in popolnoma funkcionalen. Leto izdelave 2019 - maks. premer struženja 220 mm (za standardni revolver) - maks. dolžina struženja 356 mm - vpenjalni premer nad ležiščem 641 mm - vpenjalni premer nad prečnim saneh 413 mm - pomiki osi X/Z – 200 / 356 mm - hitri pomiki osi X/Z – 30,5 m/min - velikost vretena A2-5 - maks. moč 11,2 kW, pogon vretena Vector Drive - maks. navor 102 Nm - maks. hitrost vretena 6.000 /min - prehod skozi vreteno za material v palicah 44 mm - avtomatska hidravlična vpenjalna glava 165 mm - 12-pozicijska revolverska glava VDI40 (opcijsko BOT ali Hibrid) - opcija pogona orodij in C-os vretena - rezervoar hladilne tekočine 114 l s črpalko - električni priključek 3x400 V/50 Hz, 14 kVA Nlodoy Hgvxjpfx Agxja - teža stroja 3.450 kg

Stanje: rabljeno, številka stroja/vozila: 008088, Delovno območje os X: 3700 mm Delovno območje os Y: 2100 mm Delovna površina: nesting miza Moč glavnega vretena: 9 kW Število krmiljenih osi: 4 osi Število vrtalnih vreten: 31 Nlsdpfsx A Hbqjx Agxja Število mest za orodja: 14

Stanje: rabljeno, Leto izdelave: 2014, Použit stroj Leto izdelave: 2014 Oprema in tehnični podatki: - Delovno območje X: 3.740 mm - Delovno območje Y: 1.570 mm - Delovno območje Z: 350 mm - 4. os: prisotna - 5. os: 5-osno vreteno, motor 12 kW - z dodatno blokado C-osi - Mesta za menjavo orodja: 24 s ploščnim menjalcem; 10 na levi strani stroja - Vertikalna vrtalna vretena: 12 - Strojna miza: konzolna miza Nljdpfxex Hllxo Agxoa - Avtomatika pozicioniranja mize: prisotna - 6 delovnih podpor tipa e-motion - Poseben sistem vpenjanja za okvirje - Programska oprema: FORMAT 4 WOOD FLASH, TPA ALBATROS - 2 delovni polji za nihajno obdelavo - z avtomatskim centralnim mazalnim sistemom - z mobilnim upravljalnim pultom in PC monitorjem - s klimatsko napravo za elektro omaro - z vakuumsko črpalko 90 m³/h - z ročnim upravljalnikom - Vključeno: 12 vpenjal za okvirje, 8 velikih in 4 srednje vakuumske priseske Razpoložljivost: takoj Lokacija: Röllbach

Stanje: zelo dobro (rabljeno), Leto izdelave: 2013, Rabljena avtomatska tračna žaga MEP SHARK 310 CNC HS Dimenzije rezila: 4640x34x1,1mm Nljdpfx Aoyyuxnsgxea Variabilna rezalna hitrost rezila: 15-115m/min Kapaciteta reza: okroglo 310mm , kvadrat 310x310 Avtomatski napenjalec lista Avtomatski odstranjevalec opilkov Dodatna oprema: vertikalni primež Teža stroja: 2200kg Stroj je v odličnem stanju in bo v celoti prgledan in servisiran.
