Amada Ha 500 nakup rabljenega (212)

Stanje: rabljeno, Leto izdelave: 2007, Sheet width 3050 mm Sheet thickness 6.35 mm Itsdpfx Aexaaghjh Djn Sheet thickness for stainless steel (Niro) 4.00 mm Sheet thickness for aluminium 8.00 mm Hold-downs 10 units Cutting angle 0°40' - 2°20' Frame distance 3340 mm Working height 860 mm Table depth 575 mm Control GP 37W2 Strokes per minute 13 - 33 Max. pressure 315 bar Oil capacity 100 ltr. Total connected load 6.0 kW Machine weight approx. 6030 + 1850 kg well-maintained condition (!!) current new price incl. accessories approx. €110,000 special price on request - in checked condition - Machine video - ?v=3JUqSaaJkFQ Equipment: - robust CNC electro-hydraulic guillotine shear - AMADA CNC touch controller, front left ("GP 37W2") * Machine control incl. information display * Main display with 4x operating fields * Control / operation of all functions * max. 50 cutting programs with 15 sequences each - CNC electro-motorised backgauge * Traverse speed .. 100 mm/sec. - CNC electro-hydraulic adjustment of cutting angle - CNC electro-hydraulic clearance adjustment - Sighting device & cutting line illumination for scribe line viewing * Shearing according to optical scribe line - Manually adjustable table support plates incl. ball rollers * Grip recesses in the front support table - 2x freely movable foot switches - Operating manual + wiring diagram SPECIAL ACCESSORIES included: - Backgauge system with 3 stations + separate control unit: * STATION 1 - AMADA conveyor belt with pneumatic sheet lifting device * STATION 2 - AMADA conveyor belt with pneumatic scrap diverter * STATION 3 - AMADA stacking device with scissor-lift table unit - Wooden crate with spare blades - 1x AMADA extra-long side stop with support stand * Length approx. 3,000 mm - 2x AMADA extra-long front support arms

Stanje: zelo dobro (rabljeno), Leto izdelave: 2005, stiskalna sila: 50 t, Hydraulic press brake Make: AMADA Model: HFP 50-20 Year of manufacture: 2005 Technical specifications Manufacturer: AMADA Model: HFP 50-20 Year: 2005 Bending length: 2,090 mm Pressing force: 50 t Frame gap: 1,665 mm Stroke: 200 mm Throat depth: 400 mm Installation height: 470 mm Motor power: 6 kW Dimensions (approx.): L 2.95 x W 1.60 x H 2.45 m Weight (approx.): 4.8 t Equipment • CNC-controlled axes: Y1, Y2, X, R, Z1, Z2 Itjdstzcxpspfx Ah Don • FIESSLER safety light curtain at front • Amada upper tool clamping • 3D AMNC graphic CNC control • Rear safety guard (swiveling mesh doors) • Swiveling operator station – front left • Tools included: o Upper tool, straight, radius 0.8 mm, height 117 mm, length 2,000 mm o Lower tool, V10/88°, length 2,000 mm All information without guarantee. A powered demonstration is possible at any time in our showroom.

Leto izdelave: 2009, Stanje: pripravljen za uporabo (rabljen), Splošni podatki Teža stroja: 6030 kg Iedpfx Ahew N Tm Uo Dstn Glavni pogon Število osi: 8 Mediji Poraba električne energije: 15,2 A Ta 8-osna prečna stiskalnica AMADA HFE 80-25 L je bila izdelana leta 2009. Odlikuje jo nazivna stiskalna sila 800 kN, hod 320 mm in delovna hitrost med 1-10 mm/s. Stroj ima robusten okvir s skupno maso 6030 kg in dimenzijami, ki zagotavljajo stabilnost in natančnost pri delu. Če iščete visokokakovostne možnosti upogibanja, razmislite o stroju AMADA HFE 80-25 L, ki ga imamo na zalogi. Za več informacij nas kontaktirajte. Vrste uporabe Upogibanje

Stanje: rabljeno, Leto izdelave: 1995, Used notching machine by FIM (Amada branded) Model: Goal 204 Capacity: 200 x 200 x 4 mm Ijdpfx Ahjwr Aake Djtn 90-degree angle Year of manufacture: 1995

Stanje: rabljeno, Leto izdelave: 1995, obratovalne ure: 29.777 h, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 03670514, prebijalna sila: 30 t, skupna višina: 2.315 mm, skupna širina: 3.770 mm, skupna dolžina: 5.471 mm, najv. debelina pločevine: 6 mm, potovalna razdalja osi X: 1.830 mm, pomik osi Y: 1.525 mm, skupna masa: 14.000 kg, obremenitev mize: 120 kg, hitrost pomika os X: 50 m/min, hitrost podajanja osi Y: 50 m/min, Stanje in podrobnosti glejte slike. Video je na voljo, z veseljem pošljemo po e-pošti. Itsdjxb R Uxopfx Ah Den Veselimo se vaših cenovnih ponudb!

Stanje: rabljeno, Leto izdelave: 2008, Oprema: CE označba, spodnje orodje, varnostna svetlobna zapora, zgornje orodje, AMADA HFE2204 Upogibni stroj Tlačna sila: 220 t Itjdpfow I Dmcsx Ah Don Dolžina upogiba: 4 m Zadnji prislon: 4-osni sistem prislona Sistem vpenjanja: Amada

Stanje: dober (rabljeno), Leto izdelave: 1991, Rezanje zmogljivost 4 mm, dolžina reza 2550 mm, motoriziran zadnji prislon, podporne roke 700 mm z merilom, nastavitev reže za rezanje, varovalo za prste, nožni pedal, pnevmatski držalec pločevine Itsdpfxsq Tqwro Ah Den

Stanje: dober (rabljeno), Funkcionalnost: popolnoma funkcionalen, Leto izdelave: 1999, obratovalne ure: 23.000 h, Rabljena upogibna stiskalnica AMADA Tip: HFB5025 Število osi: 8 Hod zadnjega prislona: 650 mm Itsdpfx Ajxb U Hljh Don Hod cilindra: 200 mm Osi: X1, X2, R1, R2, Z1, Z2, Y1, Y2 CNC: O2000 z 2D grafiko in USB čitalcem

Leto izdelave: 2010, Stanje: pripravljen za uporabo (rabljen), Splošni podatki Teža stroja: 21000 kg Krmilna enota Znamka: FANUC Model: n/a Glavni pogon Število osi: 3 Ijdpfx Aow N Tnrjh Detn Revolver Število postaj: 45 Dodatna oprema Potrebna moč: 27 kVA Raven hrupa: 91 dB (A) Ta 3-osni AMADA EMZ 3510 NT je bil izdelan leta 2010. Ima prebijalno kapaciteto 300 kN in vključuje 45 revolverskih postaj. S potrebo po moči 27 kVA in težo 21000 kg je ta CNC prebijalni stroj robusten in učinkovit. Če iščete visokokakovostno prebijanje, razmislite o stroju AMADA EMZ 3510 NT, ki ga imamo na voljo. Za več informacij o tem stroju nas kontaktirajte. Uporaba Prebijanje

Stanje: dober (rabljeno), Leto izdelave: 2005, Used 3 meter Amada CNC press brake Model: HFP 130 3 Iodjwz I Irepfx Ah Djtn Capacity: 3100 x 130 tons 8-axis (Y1, Y2, X1, X2, R1, R2, Z1 and Z2) Year of manufacture: 12-2005 Automatic Fiessler Alas laser system Euro-style tool clamping with quick-change adapters

Stanje: pripravljen za uporabo (rabljen), Funkcionalnost: popolnoma funkcionalen, Leto izdelave: 2002, upogibna sila (maks.): 220 t, delovna širina: 4.200 mm, hod: 350 mm, vgradna višina: 620 mm, višina mize: 960 mm, TECHNICAL DETAILS Press specifications Press force: 220 t Bending length: 4,200 mm Clearance between uprights: 3,760 mm Stroke: 350 mm Installation height: 620 mm Table width: 180 mm Table height: 960 mm Approach speed: 100 mm/s Control unit: AMADA OP 2000 Iodpfxjw Dcdto Ah Detn MACHINE DETAILS Connected load: 20 kW Approx. machine weight: 20,000 kg Operating hours: 8,444 h EQUIPMENT Backgauge type B Laser safety system Digital angle measurement system Digipro 2-finger kit Manual support system WILA Modufix system WILA hydraulic system

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2001, AMADA EUROPE 245 Turret Punch Press Technical Specifications: - CNC control: FANUC 18 i-P - Punching force: 20 tons - Max. punching format without repositioning and with 31-station turret: 1020 x 1290 mm (Y-10; Y1010 T2XX; Y-50; Y970 T3XX) - Max. sheet size with repositioning: 1020 x 2540 mm - Max. sheet size with repositioning + 1 rotation (optional): 1500 x 2540 mm - Max. sheet thickness on ball table: 6 mm - Max. sheet thickness on brush table: 3 mm - Max. permissible sheet weight: 100 kg - Punching accuracy: ±0.1 mm - Positioning accuracy: ±0.07 mm - Number of pneumatic clamps: 2 Itjdpfx Ahohvaaae Don - Number of simultaneously controlled axes: 3 (X, Y, C) - Turret rotation speed: 25 rpm - Punch rate, 25.4 mm pitch, 6.5 mm stroke: 220 strokes/min - Nibbling, 1 mm pitch, 6.5 mm stroke: 480 strokes/min - Minimum programmable increment: 0.001 mm - Number of tool stations: 31, including 3 index stations - Max. tool diameter: 88.9 mm - Index stations: 2 x 1 1/4", 1 x 2" - Max. sheet thickness for index station: 3 mm - Ram: hydraulic - Lower dead point of ram: 4 programmable positions - Working table size: X=600 mm, Y=400 mm - Memory capacity: 64 Kb (~63 programs) - Graphic display: 10.4" LCD - Stopping time: 295 ms - Air pressure: 5 kg/cm² (bar) - Air consumption: 250 Nl/min - Oil capacity: 160 L - Light curtain (3 beams): EU standard - Installed power: 27 kW - Machine dimensions: L=4460 mm, W=2750 mm, H=2130 mm - Transport dimensions: L=4820 mm, W=2500 mm, H=2414 mm - Weight of AMADA EUROPE 245: 10,000 kg - Operating hours: 35,000 h Year of manufacture: 2000.12, installation: 2001 Single owner, service book with complete machine history, machine in perfect condition, worked on thin sheets only. Start-up warranty included. Operator training included in the price. Contact person: Robert +48 500 114 006 Best regards

Stanje: rabljeno, TECHNICAL DATA - Number of axes: 2 MAIN SPINDLE Isdpfx Ahowdafbo Dotn - Spindle speed: 8,000 rpm - Spindle drive power: 2.2 / 3.7 kW - Max. machinable diameter: 60 x 60 mm RIGHT UPPER TURRET - Travel X/Z: 300 x 285 mm ELECTRICAL SUPPLY - Supply voltage: 200 V - Total power consumption: 10 kVA WEIGHT AND DIMENSIONS - Required space: 1,400 x 1,575 mm - Machine height: 1,670 mm - Machine weight: 1,650 kg MACHINE HOURS - Power-on hours: 68,992 h - Operating hours: 15,107 h ACCESSORIES - Control: Fanuc 0i-TD - Coolant tank - Parts removal - Loading cell - Electric transformer

Stanje: zelo dobro (rabljeno), Leto izdelave: 2011, Pressure: 170 t Iodpfx Asw Efagjh Dstn Bending length: 3000 mm Distance between uprights: 2700 mm Table width: 180 mm Table length: 3170 mm Throat depth: 470 mm Stroke: 200 mm Number of hydraulic cylinders: 2 pcs. Total power requirement: 15 kW Machine weight: approx. 12 t Space requirements: approx. 4000 x 2000 x 2900 mm This AMADA HFE M2 1703 press brake is in good condition and can be inspected under power at the seller's premises by appointment. The press brake is sold without tools.

Leto izdelave: 2019, obratovalne ure: 8.531 h, Stanje: pripravljen za uporabo (rabljen), Krmilna enota Znamka: AMADA Model: AMNC3i Splošni podatki Širina: 6212 mm Globina: 5436 mm Višina: 2342 mm Teža stroja: 21000 kg Orodja Število postaj: 45 Dodatna oprema Itjdpfsw N Tm Iex Ah Djn Robot za pobiranje delov Ta AMADA EMZ 3612 M2 je bila izdelana leta 2019. Ponaša se s prebijalno silo 30 ton in lahko obdela pločevino do dimenzij 3000x1500 mm z maksimalno debelino 4,5 mm. Vključuje 45 orodnih postaj in robota za pobiranje delov. Dimenzije so Š=6212 mm, D=5436 mm, V=2342 mm. Če iščete visokokakovostne prebijalne zmogljivosti, razmislite o stroju AMADA EMZ 3612 M2, ki ga imamo na voljo za prodajo. Kontaktirajte nas za več informacij. Vrsta uporabe Prebijanje

Stanje: rabljeno, Micro welding head unit, spot welding system with welding head, inverter power source, I/O module, welding inverter MIYACHI PECO / AMADA WELD TECH GmbH, Type ISQ20 Compact ISQ-AC/DC-AWS-EXT-250A 22kVA + PECO F160S Year of manufacture: 2011 The system consists of the following components: - Welding inverter MIYACHI PECO Type ISQ20 Compact ISQ-AC/DC-AWS-EXT-250A 22kVA with MFT1 control panel - External welding transformer MIYACHI PECO (mounted on welding head frame) - External interface module MIYACHI PECO Type ISQ-MG - Spot welding head MIYACHI PECO Type F160S, 25 mm stroke with Heidenhain measuring system - Connection cables Itedpfspy Uzysx Ah Den Mains voltage: 3x 400 V AC Mains frequency: 50/60 Hz Connected load: 22 kVA Welding current types: AC / DC Output power: max. 10 kA Output frequency: 1 - 10 kHz Welding time: max. 640 ms/pulse Current measurement: external toroidal coil Control panel: MFT1 (stand-alone, detachable control device) Analog input: pressure sensor for proportional valve Analog output: proportional valve control Interface: RS232 Protection class: IP30 - Fault control and process monitoring - Monitoring of current, voltage, power, and energy - Test impulse for part recognition - Program memory for 99 programs Inverter dimensions W x H x D: 216 x 420 x 560 mm Inverter weight: approx. 21 kg Spot welding head MIYACHI PECO F160S Rated capacity: max. 5 kA Electrode stroke: 25 mm Closing stroke: pneumatic - Adjustable force initiation from 1.2 to 550 N - Heidenhain displacement measuring system Welding unit with 5 pneumatic cylinders and Festo valve manifold Type CPX Welding head mounted on horizontal guide rail and can be shifted 20 mm via pneumatic cylinder. 3 pneumatic cylinders available for workpiece clamping (2 with 46 mm stroke, 1 with 20 mm stroke). Projection distance of welding tip: 300 mm Welding tip height above floor: 315 mm Welding unit dimensions W x H x D: 410 x 760 x 700 mm Welding unit weight: 75 kg Total weight: 100 kg 2 almost identical units available, price per complete unit

Stanje: rabljeno, Have we piqued your interest? Isdpfx Aew Eiproh Dstn Then feel free to register on our homepage – we look forward to hearing from you! Your Maschinen Besmann Team For sale is an Amada Promecam GTH 420. This machine was manufactured in France. Due to its compact size, it is also suitable for smaller workshops. Amada Promecam 420 GTH Guillotine Shear Manufacturer: Amada Model: Promecam 420 GTH Condition: Used Cutting length: 2000 mm Material thickness: 4 mm (steel) Backgauge: electric, 750 mm Motor power: 5.5 kW Weight: approx. 3300 kg

Stanje: zelo dobro (rabljeno), Leto izdelave: 2013, 1. AMADA FLC-3015 AJ Laser Cutting Machine with Automatic Material Loading and Unloading System Travel Type (X and Y Axes): Moving Optical System Control Type: Simultaneous X, Y, Z Axes; plus B and CF Axes Cutting Range: X Axis: 3070 mm Y Axis: 1550 mm Z Axis: 100 mm Cutting Speed (X and Y Axes): 0 – 120 m/min Maximum Material Weight: 920 kg Drive Type (X, Y, Z Axes): Linear Drive Table Height: 940 mm Machine Dimensions (excluding peripherals): L x W x H: 6043 x 2900 x 2350 mm Net Weight: 11,200 kg Year of Manufacture: 2013 2. Laser Resonator: Model – AJ2000 Nominal Power: 2,000 W Resonator Dimensions L x W x H: 1760 x 1210 x 1530 mm Weight: 800 kg Itsdsihb Tzjpfx Ah Djn 3. Filtration Unit: Herding DELTAComp 1500-8/9 SB 7.5 kW Weight: 1,200 kg 4. Loader: LKI MP Flexit 7 kW Weight: 4,300 kg Operating Hours “Powered”: 46,000 Cutting Head Hours: 24,000 Machine is regularly serviced, in excellent working condition with no defects or faults. High-performance unit, delivering consistently high processing speeds. Features multiple proprietary Amada solutions for excellent parameters, precision and durability. Contact: Robert +48 500 114 006 Best regards,

Stanje: rabljeno, TECHNICAL DATA - Number of axles: 2 Itodpjwdadwjfx Ah Don MAIN SPINDLE - Spindle speed: 8,000 rpm - Spindle drive power: 2.2 / 3.7 kW - Max. machinable diameter: 60 x 60 mm RIGHT UPPER TURRET - Travel X/Z: 300 x 285 mm ELECTRICAL SUPPLY - Supply voltage: 200 V - Total connected load: 10 kVA WEIGHT AND DIMENSIONS - Required floor space: 1,400 x 1,575 mm - Machine height: 1,670 mm - Machine weight: 1,650 kg MACHINE OPERATING HOURS - Power-on hours: 73,669 h - Operating hours: 29,854 h EQUIPMENT - Control: Fanuc 0i-TD - Coolant tank - Parts removal - Loading cell

Stanje: dober (rabljeno), Funkcionalnost: popolnoma funkcionalen, Leto izdelave: 1992, obratovalne ure: 7.906 h, številka stroja/vozila: H21025, vrsta upravljanja: ročni, upogibna sila (maks.): 170 t, skupna masa: 12.500 kg, Prodajamo upogibni stroj EX-SBB Itodpfx Asw Im U Ajh Den

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2005, Splošni podatki Teža stroja: 11600 kg Krmilna enota Znamka: AMADA Glavni pogon Tlačna sila: 1700kN Hod: 200mm Ta upogibni stroj AMADA HFE170-3 je bil izdelan leta 2005. Odlikuje ga največja tlačna sila 1700kN in hod do 200mm. Tehta 11600kg in deluje na 400 Voltov, 50 Hz z predvideno močjo 16,5kW. Za več informacij o stroju nas kontaktirajte. Vrste uporabe Ijdpfexcztbsx Ah Detn Upogibanje

Stanje: zelo dobro (rabljeno), Amada GPX 630 guillotine shear manufactured in France Manufacturer: Amada Itsdpfow Eipfjx Ah Dsn Model: GPX 630 Condition: used Maximum cutting length: 3050 mm Mild steel capacity: 6.35 mm NC backgauge: 1000 mm Number of hold-downs: 16 Machine dimensions: 3750 x 2000 x 1850 mm Weight: approx. 6500 kg Scope of delivery: Amada GPX 630 guillotine shear

Stanje: rabljeno, TECHNICAL DATA - Number of axes: 2 MAIN SPINDLE - Spindle speed: 6000 [rpm] - Spindle drive power: 3.7 / 5.5 [kW] - Max. machinable diameter: 100 x 100 [mm] RIGHT UPPER TURRET HEAD - Travel X/Z: 480 x 285 [mm] ELECTRICAL SUPPLY - Supply voltage: 200 [V] - Total connected load: 15 [kVA] WEIGHT AND DIMENSIONS - Required space: 1400 x 1725 [mm] - Machine height: 1670 [mm] - Machine weight: 1750 [kg] MACHINE HOURS - Power-on hours: 61826 [h] Itedpfx Aswdafhsh Don EQUIPMENT - Control: Fanuc 21i-TD - Coolant tank - Chip conveyor - Parts removal - Loading cell - Electrical transformer

Leto izdelave: 2001, Stanje: pripravljen za uporabo (rabljen), Splošni podatki Teža stroja: 9.200 kg Krmilna enota Znamka: AMADA Glavni pogon Tlačna sila: 200 kN Hod: 1.350 mm Dodatna oprema Itodpfx Aswacb Reh Djn Ob stroju sta 2 omari za orodje. Ta stroj AMADA Vipros 255 je bil izdelan leta 2001. Gre za rabljeni stroj za prebijanje in upogibanje, idealen za tiste, ki želijo izboljšati svoje zmogljivosti obdelave kovin. Za več informacij o stroju nas kontaktirajte. Tipi uporabe Prebijanje

Stanje: rabljeno, TECHNICAL SPECIFICATIONS - Number of Axles: 2 MAIN SPINDLE - Spindle Speed: 8,000 rpm - Spindle Drive Power: 2.2 / 3.7 kW - Max. Machinable Diameter: 50 x 40 mm RIGHT UPPER TURRET - Travel X/Z: 220 x 220 mm - Rapid Traverse Speed: 15 m/min ELECTRICAL SUPPLY - Supply Voltage: 200 V - Total Power Consumption: 11 kVA WEIGHT AND DIMENSIONS - Required Floor Space: 1880 x 1390 mm - Machine Height: 1600 mm - Machine Weight: 1,600 kg Isdpfx Aewdad Rjh Detn MACHINE HOURS - Operating Hours: 18,941 h EQUIPMENT - Control: Fanuc 21i-TD - Coolant Tank - Part Removal - Loading Cell - Electrical Transformer
