Stroj za struženje švicarskega tipa

Miyano GN-3200W

Stanje: zelo dobro (rabljeno), Leto izdelave: 2000, Funkcionalnost: popolnoma funkcionalen, izvrtina vretena: 20 mm, največja hitrost vretena: 10.000 obr/min, prehod palice: 20 mm, Oprema: dokumentacija / priročnik, CNC stružnica z drsnim vretenom Citizen L520, leto 2000 krmiljenje: Cincom Mitsubishi Meldas, 7 osi (X1/Z1/Y1/C1/X2/Z2/C2) Maks. Ø palice: 20 mm, Maks. dolžina struženja: 205 mm, Lajdpfet St A Tox Abhei Glavno vreteno, maks. hitrost 10.000 obr/min, os C 0,001 stopinje, Protivreteno, maks. hitrost 10.000 obr/min, os C 0,001 stopinje, Nosilec orodja za skupaj 18 orodij (linearni nosilec orodja, čelna namestitev, zadnja obdelava), Pogonska orodja na glavnem vretenu FMB podajalnik palic Stroj deluje brez težav ali napak, možno ga je videti v proizvodnji in ga preizkusiti. Stroj ima vse knjige ter priročnik.

Stanje: rabljeno, TECHNICAL DATA - Number of axes: 4 - Number of spindles: 2 MAIN SPINDLE - Max. bar diameter: 12 mm - Max. machinable length: 135 mm - Spindle speed: 8,000 rpm - Spindle drive power: 2.2 kW - Minimum resolution C-axis: 0.001° SUB SPINDLE - Max. bar diameter: 12 mm - Travel distance Z: 120 mm - Spindle speed: 7,000 rpm BUSH HOLDER 1 - Number of positions: 5 FRONT TOOL POST - Number of positions: 3 BACK MACHINING Laodpeuhaw Iofx Abhei - Number of positions: 3 ELECTRICAL SUPPLY - Supply voltage: 400 V WEIGHT AND DIMENSIONS - Installation space required: 1500 x 770 mm - Machine weight: 1,400 kg ACCESSORIES - Control: Fanuc - 3-color status light - Driven guide bushing - Parts catcher - Parts ejector - Coolant tank - Electrical transformer

Stanje: rabljeno, TECHNICAL DATA - Number of axes: 5 - Number of spindles: 2 MAIN SPINDLE - Max. bar diameter: 20 [mm] - Max. machining length: 170 [mm] - Spindle speed: 10,000 [rpm] - Spindle drive power: 3.7 [kW] - Minimum C-axis resolution: 0.001 [degrees] SUB SPINDLE - Max. bar diameter: 20 [mm] - Spindle speed: 10,000 [rpm] - Spindle drive power: 2.2 [kW] - Minimum C-axis resolution: 1 [degree] - Number of bush holders: 1 - Number of positions: 8 - Number of driven positions: 3 Ljdpsuha Tvjfx Abhoai - Driven tool speed: 5,000 [rpm] FRONT TOOL POST - Number of positions: 4 BACK MACHINING - Number of positions: 7 ELECTRICAL SUPPLY - Supply voltage: 400 [V] - Total power consumption: 11 [kW] WEIGHT AND DIMENSIONS - Required space: 1640 x 1200 [mm] - Machine height: 1725 [mm] - Machine weight: 1950 [kg] OPERATING HOURS - Operating hours: 21,523 [h] ACCESSORIES - Control: Fanuc Oi-TD - Driven guide bushing - Parts removal unit - Parts conveyor belt - Parts ejector - Coolant tank - Bar feeder interface - Bar feeder: fedek - Fire extinguishing system * NB: Functional capability not guaranteed. Inspection by a qualified company on the buyer's behalf is recommended. - Electrical transformer

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2005, izvrtina vretena: 19 mm, TECHNICAL DATA - Number of axes: 7 - Number of spindles: 2 - Maximum machinable length: 200 [mm] - Spindle speed: 15,000 [rpm] - Spindle drive power: 3.7 [kW] - Minimum C-axis resolution: 0.001 [degrees] SUB SPINDLE - Maximum bar diameter: 16 [mm] - Z travel: 80 [mm] - Spindle speed: 10,000 [rpm] Ljdsw Rcamopfx Abhjai - Spindle drive power: 1.1 [kW] - Minimum C-axis resolution: 0.001 [degrees] TOOL TURRET 1 - Number of positions: 10 - Number of powered positions: 4 - Driven tool speed: 6,000 [rpm] FRONT ATTACHMENT - Number of positions: 4 BACKWORKING - Number of positions: 3 ELECTRICAL SUPPLY - Supply voltage: 200 [V] - Total power: 8 [kW] WEIGHT AND DIMENSIONS - Required space: 1,850 X 1,610 [mm] - Machine height: 1,050 [mm] - Machine weight: 2,050 [kg] ACCESSORIES - Control: Fanuc 31i - Driven guide bushing - Parts remover - Parts ejector - Coolant tank - Bar loader: IEMCA BOSS 332r - Electrical transformer

Stanje: zelo dobro (rabljeno), Leto izdelave: 2008, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 16380, CNC avtomatski stružnica CITIZEN CINCOM L-20 VIII z avtomatskim podajalcem Fedek STM-326, letnik 2008. Stroj popolnoma upravljan s strani Citizen. Z geometrijskim protokolom. Lodpew T Stzjfx Abheai

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2021, obratovalne ure: 808 h, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: P20512, stružna dolžina: 200 mm, največja hitrost vretena: 12.000 obr/min, premer struženja: 16 mm, največja hitrost protivretena: 12.000 obr/min, število mest v zalogovniku orodij: 36, CNC automatic lathe with only 808 spindle hours! Equipped with a bar feeder and additional accessories! TECHNICAL DETAILS Max. turning diameter: 16 mm Max. turning length: 200 mm Max. drilling diameter: 10 mm Max. drilling diameter, sub spindle: 8 mm Main spindle speed max.: 12,000 rpm Sub spindle speed max.: 12,000 rpm Spindle bore: 20 mm Tool size: 10 mm Main spindle tool holder: FC261-M Sub spindle tool holder: WF0660-M Tool stations: 36 Rapid traverses Rapid traverse all axes (except X2, Y2, Y3 & B): 32 m/min Rapid traverse X2 axis: 16 m/min Rapid traverse Y2 axis: 8 m/min Rapid traverse Y3 axis: 32 m/min MACHINE DETAILS Weight: 2,950 kg Ljdpfjw Raxmex Abhoai Operating hours Spindle hours: 808 h  Power-on hours: 2,635 h EQUIPMENT - Mueller CL1 high-pressure pump - FOX WS 2-1000 mist separator - Minimag 20 bar feeder - Microconic MASA ultra-precision collet for sub spindle Note: The machine has minor sheet metal damage, but only to the outer covers (see photos). The machine is fully functional without limitations.

Stanje: dober (rabljeno), Leto izdelave: 2007, obratovalne ure: 27.896 h, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 2101-0171, premer struženja: 20 mm, največja hitrost vrtenja: 10.000 obr/min, vrtilni moment: 14 Nm, TECHNICAL DATA Lodpfxow Em Dmo Abhsai Max. turning diameter: 20 mm Tool body diameter: 20 mm Spindle positioning resolution: 0.1° Main spindle Rated power: 3.7 kW Power: 5.5 kW Torque: 14 Nm Rated torque: 9.4 Nm Speed: 10,000 rpm Axis Data Linear axis Z1 / X1 / Z1 – Travel: 80 / 35 / 240 mm Linear axis Z1 / X1 / Z1 – Max. feed rate: 40 m/min Linear axis Z1 / X1 / Z1 – Max. acceleration: 10 m/s² Linear axis Z1 / X1 / Z1 – Nominal force: 1,250 N Linear axis Z2 / X2 – Travel: 180 / 230 mm Linear axis Z2 / X2 – Max. feed rate: 40 m/min Linear axis Z2 / X2 – Max. acceleration: 10 m/s² Linear axis Z2 / X2 – Nominal force: 1,250 N Tool holder Number of fixed tools (internal): 6 Diameter: 20 mm Number of fixed tools (external): 4 Tool shank size: 12 × 12 mm Number of driven tools: 4 Collet type: ESX 16 MACHINE DETAILS CNC control: Fanuc 16iT Machine dimensions (L × W × H): 2,275 × 1,300 × 1,760 mm Weight: 2,600 kg Connected load: 21 kVA Power-on hours: 85,620 h Program run time: 27,896 h EQUIPMENT - CNC control: Fanuc 16iT - Bar feeder FMB Turbo 3-36 / 4200 / A, year of manufacture 2007 - Coolant tank with chip conveyor - Central lubrication - Handheld control device - Documentation available
