Swap box

BDF Wechselkoffer Wechselbrücke mit Portaltüren 7,45 m

Leto izdelave: 1997, stanje: zelo dobro (rabljeno), A used, very well-maintained cold circular saw from EISELE equipped with a 370mm circular saw blade, infinitely variable hydro-pneumatic feed, pneumatic material clamping, coolant system, and documentation. Speed: 17/34 rpm Cutting capacity: Round 90°/45° right/left/30° right: 130/130/105mm Square 90°/45° right/left/30° right: 120x120/100x100/90x90mm Rectangle 90°/45° right/left/30° right: 200x100/140x100/100x100mm Pneumatic connection: 7 bar Working height: 900mm Machine dimensions (W x D x H): 865 x 1332 x 2175mm Weight: 460kg For further technical data, please refer to the PDF document. Cedpfokfp D Tex Ag Eohd Technical data and dimensions: Subject to change and errors.

Stanje: rabljeno, Leto izdelave: 1979, Technical details: Grinding diameter min/max: Mounting: Ø 200 x 32 mm Spindle speed: 3000 rpm Total power requirement: approx. 1.2 kW Machine weight approx.: 0.24 t Machine dimensions (LxWxH): approx. 0.7 x 0.9 x 1.6 m The grinding spindle is equipped with two hand levers: - Left working area: Manual grinding device for small shank drills, grinding wheel currently Ø 120 x 30 mm; mounting Ø 32 mm; speed 3000 rpm; with grinding rest - Right working area: Pivoting device for tapered shank drills; cup grinding wheel currently Ø 160 x 30 mm; mounting Ø 32 mm; speed 3000 rpm Cutting angle for two-fluted drills max. 180° and for three-fluted drills 120° Chodsu Ng Ncepfx Ag Eed Relief angle: 5°–9°; Drill Ø 8–40 mm, possible grinding types include: standard grind, cross-point grind, centering grind, spiral grind, step drill grind Machine lighting available

Stanje: novo, Z-MaT CNC/Cycle Lathe FTL660-2000mm, Control: Siemens 828D Shop Turn, 15" Touchscreen Flat bed with linear roller guides and telescopic cover Hydraulic 3-jaw chuck, 380 mm diameter Max. swing over bed: Ø700 mm Max. workpiece length: 1800 mm (with chuck) Max. turning diameter over cross slide: Ø480 mm Spindle Spindle bore: Ø120 mm Max. bar capacity: Ø110 mm Spindle nose: A2-11 Max. spindle speed: 1000 rpm Spindle power: 22/30 kW Tooling 12-position servo turret Tailstock Hydraulic tailstock MK5 Quill travel: 100 mm Tailstock travel: 1850 mm (manual) Axes X-axis travel: 370 mm Z-axis travel: 2000 mm Rapid traverse X/Z: 15/15 m/min Bed type/Guideways: Box bed with linear roller guides Bed width: 600 mm Accessories: Manual steady rest 110-260 mm Overall dimensions (L×W×H): 4.5 x 1.96 x 2.1 m Weight (approx.): 6.4 t The machine will be exhibited at EMO Hall 12/D10 and will be immediately available thereafter. Csdpfxowwt Trs Ag Eohd Further sizes of this series can be found in the PDF.

Stanje: rabljeno, Leto izdelave: 1993, Sinumerik 805 Control Spindle Speed: 45 – 6000 rpm Full Bore Diameter: / 0 Machine Weight: approx. 20 t Machine Type: Deep Hole Drilling Machine Model / Type: TB 2 15 30001KT Year of Manufacture: 1993 Manufacturer: Loch Machine Serial Number: 221-3000-2093 Machine Weight: approx. 20,000 kg Machine Footprint: Width = approx. 3,800 mm Length = approx. 13,500 mm Height = approx. 3,100 mm Drilling Length: approx. 3,500 mm Drilling Capacity: 45 mm (drilling) / 80 mm (counterboring) Spindle Speed Range: 45 – 6,000 rpm Control: Siemens Sinumerik 805 Hamül – Coordinate Table Type: KT 8.5 – 10.10 Clamping Surface: approx. 1,100 mm x 980 mm Travel Y-Axis: approx. 800 mm Travel X-Axis: approx. 500 mm 7 Clamping T-slots: 18 mm Special Equipment: 1 piece Fibroplan NC Rotary Table Type: NC 1.05 Permissible Transport Load (horizontal): 2,500 kg With Forkardt F 630 Manual Chuck The NC rotary table can be adjusted longitudinally and transversely to the fixture table manually and is hydraulically clamped. 1 piece Chip Centrifuge Type: VZ5A by CEPA Drum Capacity: 80 liters Max. Load Weight: 100 kg Chedpjvvx Hiofx Ag Ejd Drum Diameter: 600 mm Speed: 1,000 rpm 1 piece Auxiliary Pump for Large Drill Diameters 1 piece Bosch Radial Piston Pump No. Suitable for lip drills (internal cooling, chips are conveyed outward) Suitable for BTA drills with screw-on heads (internal cooling, chips are conveyed inward)

Stanje: pripravljen za uporabo (rabljen), Swing diameter over bed/cross slide: 530mm/280mm, centre height: 264mm, centre distance: 2000mm, bed width: 370mm, spindle speed: 2000rpm, spindle bore: 80mm, tool shank dimensions X/Y: 25mm/25mm, cross slide travel: 300mm, quill diameter: 65mm, quill stroke: 180mm, repeat accuracy: mm. The machine has an electrical issue at the tool head. Documentation available. On-site inspection is possible. Csdsv Amrtjpfx Ag Eehd

Stanje: rabljeno, Swing diameter / mm Total power requirement / kW Machine weight approx. / t Centre height: approx. 500 mm Dimensions Length: 1300 mm Width: 300 mm Height: 560 mm Cjdpfx Ageia Rrko Eshd Weight: 265 kg

Stanje: dober (rabljeno), 3-jaw power chuck with locking pin RÖHM Duro 400 Diameter: 400 mm Codpfxjwxprto Ag Eshd Spindle mount: DIN 55027 size 11 Weight: approx. 105 kg Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Stanje: dober (rabljeno), Leto izdelave: 1989, Rezervoar za stisnjen zrak, tlačna posoda, tlačni rezervoar, zračni kotel, tlačni kotel, kompresorski rezervoar Chodpeqva Nnofx Ag Esd - Tlačna posoda: rezervoar za stisnjen zrak na premičnem podvozju - Prostornina rezervoarja: 250 litrov - Delovni tlak: maks. 30 bar - Položaj: ležeče na transportnem ogrodju - Dimenzije: 2000/550/V1010 mm - Teža: 363 kg

Leto izdelave: 1980, stanje: dober (rabljeno), Travelling Clamping Table Manufacturer: WAGNER Model: FE4000 Year: 1980 Travel distance: 4,000 mm Table surface: 4,000 mm x 1,400 mm Chsdpfx Aeg Uf I Asg Esd Feed rate: 8 - 2,500 mm/min Rapid traverse: 4 m/min Max. load capacity: 12,500 kg Weight approx. 12,000 kg In good condition. Hydraulic clamping and worm drive

Stanje: rabljeno, 7 Spannzangengrößen: 7-9-10-12-16-18-20 mm Cedpfx Ajbn Rpijg Eshd
