Brezsredinski valjčni brusilni stroj

HERMINGHAUSEN Mikrosa SR 5

Stanje: dober (rabljeno), HERMINGHAUSEN SR40 III CNC Centerless Grinding Machine Nedpfegq Ddfox Abnoli

Leto izdelave: 1992, Stanje: rabljeno, Grinding height 50 mm Grinding width 120 mm Grinding wheel diameter 600 mm Total power requirement 85 kW Machine weight approx. 9500 kg D I S K U S CNC-controlled, vertical double-sided surface grinding machine with rotating workpiece infeed and IONIC measurement control. Type: DDS 600 III PRM - CNC Year of manufacture: 1992, No. 7924 --- Grinding wheel dimensions (each): 600 x 150 x 75 mm (H) Workpiece data: Grinding height approx. 1.5 – 50 mm Grinding width approx. 20 – 120 mm Vertical quill adjustment, each approx. 150 mm Infeed increment of grinding wheels via CNC: 0.0001 mm Workpiece transport device, continuously adjustable feed: 40 – 235 mm/sec Grinding wheel speed (each, 30 m/s): 191–955 rpm Grinding spindle drive, infinitely variable (each): 37 kW Total drive power approx. 85 kW / 380 V / 50 Hz Weight approx. 9,500 kg Accessories / Special Features • SIEMENS CNC control SINUMERIK 810 G with display for 4 axes (top and bottom infeed, dresser, and workpiece rotation), direct input of all grinding parameters, and • IONIC measurement control no. 17 A with 2 measuring probes for scanning the workpieces after the grinding cycle, triggers automatic infeed corrections for the grinding wheels; real-time measurement data on monitor for statistics, workpiece counting, etc. • Digital display of current (amperage) of the drive motors and grinding wheel speed • Gantry construction for increased stability and improved grinding accuracy • Rotary workpiece transport with continuously variable speed control as 4th axis • Position control system for monitoring the height position of the lower grinding wheel • 2 adjustable workpiece hold-downs each at the infeed and outfeed, with height monitoring, simple raw part stacking mechanism, finished parts removal via conveyor belt • Half-inclined, side-mounted grinding wheel dressing device with preprogrammable dressing cycles, integrated as CNC axis in the control system with safety shut-off • Large separate electrical cabinet, automatic central lubrication, high-performance pneumatic system • Large PROMATEC (F) coolant system with filtration unit and magnetic separator • Various grinding wheels, flanges, various table segments, transport discs, large dust extraction system, etc. Nodpfx Abjt Hw Naeneli This machine is particularly suitable for simultaneous, parallel surface grinding of workpieces in large series, such as punched parts, piston rings, hydraulic components, etc. Condition: good to very good – soon available for demonstration Delivery: ex stock – as inspected Payment: strictly net – upon receipt of invoice This offers a very rare opportunity in terms of both condition and price. If you require another grinding machine, especially from the manufacturer DISKUS, please send us your inquiry.

Stanje: pripravljen za uporabo (rabljen), Travel X/Y/Z: 1000mm/800mm/500mm, Spindle speed: 15,000 rpm, Tool holder: SK40, Tool stations: 30, Spindle power: 15 kW, Table dimensions X/Y: 1250mm/800mm, Max. table load: 1200kg. Machine dimensions X/Y: approx. 5000mm/3000mm, Weight: approx. 12,000kg. The machine has a spindle defect. Documentation is available. On-site inspection possible. Njdpfx Aeup Egxsbnoli

Stanje: dober (rabljeno), Brezsredinski brusilni stroj Nledpfx Aotrguvjbnsi

Stanje: rabljeno, Manufacturer: CINCINNATI Nlsdpfxewrpyke Abnei

Stanje: dober (rabljeno), GENERAL CHARACTERISTICS Maximum grinding diameter: 120 mm Grinding wheel width: 250 mm Minimum grinding diameter: 1 mm Regulating wheel diameter: 304 mm Grinding wheel diameter: 508 mm DIMENSIONS AND WEIGHT Height: 1,700 mm Width: 1,500 mm Length: 2,750 mm Weight: 4,000 kg ELECTRICAL SPECIFICATIONS Nlsdpfx Abjrpnf Asnoi Grinding head motor power: 15 kW Regulating wheel head motor power: 1.8 kW Hydraulic motor power: 1.1 kW Total installed power: 20 kW Voltage: 220/380 V

Stanje: rabljeno, Leto izdelave: 1978, Maximum grinding diameter: 100 mm Regulating wheel width: 200 mm Maximum grinding wheel width: 200 mm Grinding diameter: 100 mm Grinding length: 250 mm Plunge depth: mm Working area: mm Njdpfx Abjt Hwtreneli Speed: m/min Bar lengths: mm Total power requirement: 25 kW Machine weight approx.: 4,500 kg Space requirement approx.: m K O E N I G & B A U E R Centerless grinding machine for plunge grinding Type: M 150 - 5, Year of manufacture: approx. 1978, # 73.918 Grinding range diameter, normal/maximum: 2 – 50 / 100 mm Max. workpiece length for through-feed grinding: approx. 250 mm Max. workpiece length for plunge grinding: approx. 200 mm Grinding wheel dimensions: diameter x width max.: 600 x 200 mm Regulating wheel dimensions: diameter x width max.: 300 x 200 mm Grinding wheel speed max.: 1,450 rpm or 35 m/sec Regulating wheel speed steplessly adjustable: 10 – 140 / 230 rpm Regulating wheel inclination: +3 / -5 degrees Stroke of both hydraulic dressing slides: approx. 200 mm Grinding wheel drive: approx. 18 kW Total drive: approx. 25 kW - 400 V – 50 Hz Weight: approx. 4,500 kg Accessories / Special equipment: • The machine is a centerless grinding machine specially equipped for plunge grinding cylindrical workpieces, with a manual infeed device for raw parts and a pneumatically controlled lifting device for finished parts. Removal of the workpiece is manual. • Currently installed is a workpiece support block with rail, corresponding to the workpiece diameter. • The regulating wheel slide is controlled by a hydraulic infeed device with automatic operation via a cam controller, plus fine adjustment via a stepper motor. • The grinding slide is stationary and only houses the hydraulic dressing device for the grinding wheel. • The lower regulating wheel slide can be swiveled up to 3° and carries the workpiece support block, allowing for easy correction of cylindricity errors. The upper regulating wheel support can also be tilted by plus/minus 5°. • Hydraulic dressing device mounted above the regulating wheel; hydraulic dressing device, tiltable for profiling shoulder profiles, behind the grinding wheel with template and stepper motor infeed for the dressing diamond, also for compensation, and equipped with a high-pressure coolant nozzle for grinding wheel flushing and diamond cooling. • The regulating wheel drive is infinitely adjustable, dressing speed 315 rpm, speed display included. • The control panel contains all functions like number of dressing cycles, number of workpieces, adjustable spark-out time, manual/automatic mode, etc. • Various grinding wheel flanges, lifting gear for wheel change, separate hydraulic unit and control cabinet, etc. • Currently no coolant unit installed. Condition: Good – under power and ready for demonstration, robust construction – ideal for grinding cumbersome workpieces.

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2008, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 30013012, 27.10 25 : Stroj deluje v serijski proizvodnji. Načrtovan izklop sredi leta 2026. Prosimo, navedite svojo ponudbeno ceno. Prodaja samo znotraj Evrope, vključno s Turčijo ----- Tehnični podatki glej prilogo. Brez embalaže; kakršnakoli garancijska pravica je izključena. Če želite napravo demontirati sami, nas o tem obvestite v svoji ponudbi. Za pravilnost tehničnih podatkov, za popolnost dodatne opreme in orodij, Njdsth Sc Hjpfx Abnjli kakor tudi za izpolnjevanje vseh varnostnih in okoljskih zahtev iz predpisov o preprečevanju nesreč, ne prevzemamo nobene odgovornosti.

Stanje: zelo dobro (rabljeno), Leto izdelave: 2012, DISKUS DDS 750 XR – Technische Daten Maschinentyp: Vertikale Doppelscheiben-Schleifmaschine Modell: DDS 750 XR Schleifscheibendurchmesser: 750 mm Maximale Schleifbreite (Durchlaufschleifen): 180 mm Maximale Materialstärke (Durchlaufschleifen): 30 mm Maximale Schleifbreite (Einstechschleifen): 300 mm Maximale Materialstärke (Einstechschleifen): 80 mm Schleifspindel 1 Leistung: 48 kW Schleifspindel 2 Leistung: 48 kW Maximale Umfangsgeschwindigkeit der Schleifscheibe: 63 m/s Kühlschmittelführung: Durch die Spindelmitte Werkstückzuführung: Drehteller Zuführgeschwindigkeit: 20 mm/min bis 240 mm/min Nlodpfx Aewwrqcobnsi Steuerung: Siemens 840 D CNC Gesamthöhe der Maschine: ca. 3.100 mm Gesamtgewicht: ca. 13.000 kg Stellfläche: Länge ca. 4.900 mm, Breite ca. 5.000 mm Konstruktionsmerkmale: Dreieckig-stabile Rahmenbauweise, Linearspindeln, 16 CNC-Achsen, Zentralschmierung, Kühlmittel-Filtration

Leto izdelave: 2013, Stanje: rabljeno, Technical details: Nlsdpfsixl Ahox Abnoi Swing diameter: 80 mm Workpiece length: 450 mm Machine weight approx.: 3500 kg
