Namizni vrtalnik

FLOTT TB18 Plus (NEU ab Werk)

Stanje: dober (rabljeno), Leto izdelave: 1956, Heavy-duty lathe, lathe, engine lathe, geared head lathe, screw-cutting lathe Hsdpfx Ahetzf N Re Hsnt - Manufacturer: Weisser, Geared Head Lathe Type PF200 - Turning length: 1340 mm - Swing over bed: 420 mm - Swing over cross slide: 240 mm - Spindle bore: Ø 41 mm - Spindle speeds: 31.5 - 1400 rpm - Three-jaw chuck: Röhm Ø 250 mm - Accessories: included, see photos - Tailstock taper: MT4 - Drive motor: 2.5/3.5 kW - Dimensions: 2670/1000/H1230 mm - Weight: 1450 kg

Stanje: dober (rabljeno), Leto izdelave: 2009, Funkcionalnost: popolnoma funkcionalen, CNC Lathe TRAUB TNX 65/42 Year of Manufacture: 2009 Control System: Traub TX 8i-s TECHNICAL DATA - Number of spindles: 2 - Number of axes: 12 - Number of turret heads: 2 MAIN SPINDLE - Spindle nose: A2-6 - Spindle drive power: 24 kW - Spindle speed: 5,000 rpm - Max. bar diameter: 65 mm - Max. main spindle chuck diameter: 175 mm - Minimum C-axis resolution: 0.001° SUB SPINDLE - Spindle nose: A2-5 - Spindle drive power: 28 kW - Spindle speed: 7,000 rpm - Max. bar diameter: 42 mm - Minimum C-axis resolution: 0.001° - Travel distance: 700 mm LEFT UPPER TURRET - Number of positions: 10 - Number of driven positions: 10 - Travel X/Z: 175 / 650 mm - Travel Y: +/- 40 mm - Tool type: VDI 30 - Driven tool speed: 6,000 rpm - Driven tool power: 5.5 kW RIGHT LOWER TURRET - Number of positions: 10 - Number of driven positions: 10 - Travel X/Z: 175 / 650 mm - Travel Y: +/- 40 mm - Tool type: VDI 30 - Driven tool speed: 6,000 rpm Hnjdpfx Ajyw H Szeh Hst - Driven tool power: 5.5 kW ELECTRICAL SUPPLY - Supply voltage: 400 V - Total power consumption: 95 kW WEIGHT AND DIMENSIONS - Footprint: 5,450 x 2,318 mm - Machine height: 2,258 mm - Machine weight: 10,000 kg New spindle installed since 04/26 ACCESSORIES - 3-color status lamp - Coolant tank: RESY * with high-pressure pump * with paper filter - Chip conveyor - Parts ejector - Parts belt conveyor

Stanje: rabljeno, TECHNICAL DATA - Max. bar diameter: 12.7 [mm] - Main spindle stroke (fixed/driven guide bushing): 130/80 [mm] - Spindle power: 4 [kW] - Rotational speed: 12,000 [rpm] - Upper turret: 6 positions - Lower turret: 6 positions - Number of driven positions on turret: 6 - Max. diameter in sub-spindle: 12.7 [mm] - Sub-spindle rotational speed: 12,000 [rpm] - Dimensions: 2850 x 1100 x 1480 [mm] - Operating hours: 12,408 [h] - Main spindle hours: 9,400 [h] EQUIPMENT - CNC control TRAUB TX 8i - Bar feeder LNS Alpha ST 320 - C axis on main spindle and sub-spindle - Brake for main spindle and sub-spindle - Parts catcher with conveyor belt - Fire protection system - Coolant tank with pump and chiller unit - Chip conveyor Hnedpfsuhav Djx Ah Hst - Various fixed and driven tool holders

Stanje: rabljeno, Leto izdelave: 2005, Swing diameter: 275 mm Turning length: 900 mm Control: TRAUB TX8i Spindle bore: 65 mm Drive power 100% duty cycle: 25.20 kW Drive power 40% duty cycle: 30.20 kW Torque at 40% / 100% duty cycle: 180 / 135 Nm Spindle speeds - stepless: 1 - 5,000 rpm Spindle diameter at front bearing: 110 mm C-axis: 1 - 500 rpm Tool carrier No. 1 X-axis: 290 mm Y-axis: 165 mm Z-axis: 600/950 mm B-axis: 360° Rapid traverse X/Y/Z: 18 / 18 / 30 m/min Feed force X/Y/Z: 10 / 10 / 7 kN Number of tools: 2x2 + 2x2 Number of driven tools: 2x2 + 2x2 mm Tool speeds: 8,000 / 2,000 rpm Drive power 25% duty cycle: 5.80 kW Torque at 25% duty cycle: 4x18.6 / 4x74 Nm Tool holder: TRAUB Ø60 Tool carrier No.2 / No.3 / No.4 X-axis: 170 mm Z-axis: 600/950 mm Y-axis: +/- 60 mm Rapid traverse X/Y/Z: 18 / 15 / 30 m/min Feed force X/Y/Z: 10 / 10 / 7 kN Tool turret - number of stations: 10 Number of driven tools: 10 mm Tool speeds: 1 - 6,000 rpm Drive power 25% duty cycle: 5.80 kW Torque at 25% duty cycle: 18.60 Nm Tool holder: DIN 69880 Ø40x63 Bar loading magazine: DNH61 / 3000 Bar lengths: 1,000 - 3,200 mm Bar diameter: 18 - 63 mm Hexagon max.: 45 mm Total connected load: 95.00 kW Machine weight approx.: 16.00 t Space requirement approx.: 10.00 x 3.50 x H3.00 m With TRAUB TX8i control, main and counter spindle with C-axis, 3 pcs. turret tool carriers, 1 pc. vertical tool carrier with B-axis, Hnedpjw E Nnbsfx Ah Het extraction system, chip conveyor, coolant unit with coalescence separator. Bar loader: TRAUB Stamag DNH61 / 3000 2 pcs. 3-jaw chucks SMW KNCS-N 170-43 2 pcs. HAINBUCH Spanntop chucks 40 pcs. various static tool holders 6 pcs. various driven tool holders Spare parts package Machine can be inspected under power.

Stanje: dober (rabljeno), Nosilec orodja VDI 30 Hodpfx Ahjww Hluj Hont

Leto izdelave: 2023, stanje: pripravljen za uporabo (rabljen), Na voljo je nerabljeno CNC-obdelovalno središče Traub z nasprotno vreteno za struženje in frezanja, skupaj z dodatno opremo. Vrste vretena 1/2: D76/D76, največja dolžina struženja: 900 mm, največji premer obdelovanca: 76 mm, število nosilcev orodja: 3, upravljanje: Traub TX8i-s V8. Premer glavnega vretena: 76 mm, velikost konusa: 6, votel vpenjalni valj: D76/20, delitev: 2,5°, območje vpenjalnega tlaka: 8 bar - 75 bar. Premer nasprotnega vretena: 76 mm, velikost konusa: 6, votel vpenjalni valj: D76/20, delitev: 2,5°, območje vpenjalnega tlaka: 8 bar - 75 bar. Nosilec orodja zgoraj: osi: X/Y/Z, postaje: 12. Nosilec orodja spodaj levo: osi: X/Y/Z, postaje: 12. Nosilec orodja spodaj desno: osi: X/Y/Z, postaje: 12. Vključno s sistemom za odsesavanje in filtriranje meglic Isi Elbaron RON4DHEC, posebej izdelanim krožnim transportnim trakom, tekočim transportnim trakom za žagovino Bürener, sistemom za hlajenje in mazanje Bürener Eco-Fluid (600 l), hladilno napravo, hladilnikom za sistem za hlajenje in mazanje, sistemom za rokovanje z obdelovanci Traub WH, različnimi prijemali in pari prijemalov, IoT ter programsko opremo za upravljanje in nadzor. Ta stroj ni bil nikoli uporabljen in je zato v popolnem stanju. Dokumentacija je na voljo. Možen je ogled na licu mesta. Hsdjzkvkqjpfx Ah Hsnt

Stanje: rabljeno, TECHNICAL DATA - Number of spindles: 2 - Number of axes: 9 - Number of turret heads: 2 MAIN SPINDLE - Spindle drive power: 6.7 / 10.7 [kW] - Spindle speed: 8000 [rpm] Hnsdpfx Asypxqrjh Hst - Max. bar diameter: 32 [mm] - Travel Z: 305 [mm] - Minimum C-axis resolution: 0.001 [degrees] SUB SPINDLE - Spindle drive power: 3.7 / 5.5 [kW] - Spindle speed: 6400 [rpm] - Max. bar diameter: 30 [mm] - Minimum C-axis resolution: 0.001 [degrees] - Travel X: 140 [mm] - Travel Z: 300 [mm] TURRET 1 - Number of positions: 10 - Number of live positions: 10 - Driven tool speed: 12,000 [rpm] - Driven tool power: 3.4 [kW] - Travel X/Z: 140/300 [mm] - Travel Y: -40/+25 [mm] TURRET 2 - Number of positions: 10 - Number of live positions: 10 - Driven tool speed: 12,000 [rpm] - Driven tool power: 3.4 [kW] - Travel X/Z: 140/320 [mm] - Travel Y: -25/+40 [mm] ELECTRICAL SUPPLY - Total power: 28 [kW] WEIGHT AND DIMENSIONS - Required floor space: 3870 x 1670 [mm] - Machine height: 2500 [mm] - Machine weight: 6000 [kg] OPERATING HOURS - Power-on hours: 23240 [h] - Operating hours: 19500 [h] ACCESSORIES - Control system: Traub TX 8i-p - 3-colour status lamp - Coolant tank: 500 [l] * with high-pressure pump: 3, 8, 20 [bar] * with paper filter - Chip conveyor - Workpiece removal - Parts conveyor belt - Bar feeder preparation

Stanje: rabljeno, Leto izdelave: 2024, New: Yes Hnsdpfx Ajx I Dtdjh Hjt Color: Red Working width: 180 cm

Stanje: rabljeno, Leto izdelave: 2009, Tehnične podrobnosti: Hodsw Dud Ejpfx Ah Hsnt Premer struženja: 270 - 300 mm Dolžina struženja: 710 mm Skupna potrebna moč: 43 kW Teža stroja pribl.: 8,5 t Potreben prostor pribl.: 3,16 x 2,15 x 2,15 m Pri stroju niso priloženi ne vpenjalna glava ne orodja – stroj je bil v originalu kupljen brez te dodatne opreme. G300 ima osi X, Z, Y, C, SP, pogonjena orodja. Možen je uporabi podajalnika palic, vendar ta ni priložen stroju.

Stanje: rabljeno, Leto izdelave: 2011, proizvajalec krmilnikov: Mitsubishi, model krmilnika: TX8i-s, _____ Opis: Glavna vretena: Tehnologija: Vreteno z motorjem Število vrtljajev: 5.000 vrt/min Moč: 22,6 kW Navor: 180 Nm Premer vretena: 65 mm Naprava za vpenjanje obdelovanca: Vpenjalna glava, Hainbuch Spanntop Kombi Axfix, velikost 65 Proti-vreteno: Tehnologija: Vreteno z motorjem Število vrtljajev: 5.000 vrt/min Moč: 22,6 kW Navor: 180 Nm Naprava za vpenjanje obdelovanca: Vpenjalna glava, Hainbuch Spanntop Kombi Axfix, velikost 65 Izmetnik: Hidravlični, z možnostjo izpiranja Nosilec orodja I (X/Y/Z): Tehnologija: Revolver s 10 postajami Namestitev orodja: VDI30 Pogon orodja: 6.000 vrt/min, 5,5 kW, 17,5 Nm Pot giba v X/Y/Z: 175/80/650 mm Hitrost giba v X/Y/Z: 20/20/40 m/min Nosilec orodja II (X/Y/Z): Tehnologija: Revolver s 10 postajami Namestitev orodja: VDI30 Pogon orodja: 6.000 vrt/min, 5,5 kW, 17,5 Nm Pot giba v X/Y/Z: 175/80/650 mm Hitrost giba v X/Y/Z: 20/20/40 m/min Nosilec orodja III (X/Y/Z): Tehnologija: Revolver s 10 postajami Namestitev orodja: VDI30 Pogon orodja: 6.000 vrt/min, 5,5 kW, 17,5 Nm Pot giba v X/Y/Z: 175/80/650 mm Hitrost giba v X/Y/Z: 20/20/40 m/min Hnjdpfszr Dd Ujx Ah Het Oprema/dodatna oprema: Upravljanje z odrezki: Transporter za odrezke Upravljanje s hladilom: IKZ sistem s filtrom iz papirnate traku in visokim tlakom, 80 bar Kontrola temperature hladila: Priprava za priključitev zunanjega hladilnega sistema, Deltatherm Dovod surovega materiala: Avtomatski podajalnik kratkih palic, FMB SL 80S Odstranjevanje končnih izdelkov: Portalni sistem za dvigovanje izdelkov (krmiljen z NC), s tekočim trakom Sesalnik za oljne hlape: Elektrostatični separator, LTA AC3001 Dodatna oprema: Različni rabljeni fiksni nosilci orodja
