Sredinski stružnica in stružnica za vreteno

ELMAG SUPERTURN 550 / 125 Vario

Stanje: rabljeno, Leto izdelave: 2007, Turning diameter 300 mm Swing diameter over bed 430 mm Swing diameter over cross slide 300 mm Control SIEMENS, SINUMERIK 840 D Travel path - X 160 mm Travel path - Z 510 mm Maximum workpiece length 480 mm Main spindle bore 53 mm Main spindle speed 0 - 7000 rpm Spindle nose DIN 55026 A2-5 Spindle torque 100 Nm Main spindle motor 15 kW Sub-spindle bore 53 mm Sub-spindle speed 0 - 7000 rpm Spindle nose DIN 55026 A2-5 Spindle torque 100 Nm Sub-spindle motor 15 kW C-axis resolution 0.001° C-axis rapid traverse 1000 rpm Tool turret 1 x 12 stations Number of driven tool stations 12 Tool holder shank (DIN 69880) VDI 25 Speed of driven tools 0 - 8000 rpm Torque 16 Nm Power 4 kW Feed force X/Z-axis 4000 / 6000 N Rapid traverse X-axis 24 m/min Rapid traverse Z-axis 30 m/min Total power requirement 38 kVA Redpfswx R Rkox Ag Top Machine weight approx. 4 t Machine dimensions L x W x H 2.65 x 1.84 x 2.32 m Accessories: Collet chuck 173 E on main spindle, Collet chuck 163 E on sub-spindle, Bar loader manufacturer FMB, type turbo 3-36/3200 A, Year 2018 for bar diameters up to 36 mm and bar lengths up to 3200 mm Various tool holders for turret (no driven holders), Coolant system

Stanje: novo, Number of drawers: 8 pcs. Dimensions (L x W x H): 880 x 580 x 1000 mm Net weight: 156 kg Load capacity: 100 kg per drawer Robust tool cabinet with 8 lockable drawers. Drawer heights: 2 x 75 mm, 4 x 100 mm, 1 x 150 mm, and 1 x 200 mm Internal usable dimensions: 770 x 450 mm. Maximum load per drawer: 100 kg! Redpfx Agju Imf Io Tjp Fittings: - 32 x bins 75 x 75 mm - 16 x bins 75 x 150 mm - 8 x bins 150 x 150 mm - 12 x long dividers - 32 x short dividers - 1 x stacking plate

Stanje: dober (rabljeno), Leto izdelave: 1997, premer struženja nad prečnim suportom: 60 mm, izvrtina vretena: 24 mm, moč vretenovega motorja: 7.500 W, vrtljajska hitrost (min.): 30 obr/min, največja hitrost vrtenja: 5.000 obr/min, skupna višina: 1.660 mm, skupna dolžina: 1.700 mm, skupna širina: 1.240 mm, skupna masa: 1.420 kg, CNC stružnica s vpenjalnim tulečkovim vpenjalom F38 Največji stružni premer Ø 200 mm, pomiki X/Z 180/255 mm, revolverska glava SAUTER 8-pozicijska VDI20 (16x16 mm), vreteno 7,5 kW, vretenasti nos A2-4, hitrost vrtenja 30–5000 min⁻¹, premer prehoda palice Ø 32 mm, omejevalnik votlega vretena, krmilje FANUC Series T-20, priročniki Redovu Tvpspfx Ag Tep

Stanje: rabljeno, Premer vrtenja nad posteljo 280 mm Premer vrtenja nad suportom 160 mm Dolžina struženja 500 mm Višina konic 140 mm Razmak med konicami 500 mm Premer vretena 36 mm Hitrosti vretena 15 - 3550 vrt/min Glava vretena DIN 55022 Gr. 5 Pomiki – vzdolžno 0,008 - 0,560 mm/obr Pomiki – prečno 0,004 - 0,280 mm/obr Navoj – mm korak 0,2 - 12 mm Premer vodilnega vretena 24 mm Korak vodilnega vretena 6 mm Konica pinole MK 3 Hod pinole konjička 90 mm Prečni pomik konjička iz sredine 15 mm Skupna potrebna moč 2,2 kW Teža stroja pribl. 0,6 t - Stroj iz učne delavnice - Redox Ni Dkjpfx Ag Top Pribor: digitalno merjenje na 3 oseh, 3-čeljustna glava RÖHM 160 mmø, MULTIFIX glava Gr. A M-št. 4684

Stanje: pripravljen za uporabo (rabljen), Swing diameter over bed/cross slide: 570mm/420mm, turning diameter: 420mm, turning length: 635mm, X/Z travel: 220mm/635mm, spindle speed: 5,000 rpm, spindle bore: 79mm, max. bar diameter: 65mm. Tool stations: 12, driven tools: 6, tool holder: VDI 30, rapid traverse X/Z: 24m/30m/min. Machine dimensions X/Y/Z: approx. 3500mm/2500mm/2000mm, weight: approx. 4,500kg. An on-site inspection is possible. Rsdjv Uqcgopfx Ag Tsp

Stanje: rabljeno, Premer struženja 260 mm Dolžina struženja 280 mm Krmiljenje OSP500 Število krmiljenih osi - 2 Premer nihanja nad ležiščem mm Ø 450 Rjdpfxjwm Rrdo Ag Tjp Premer nihanja nad suportom mm Ø 350 Premer nihanja nad prečnim suportom mm Ø 300 Največji premer struženja × dolžina mm Ø 260 × 280 Premer vretena mm Ø 100 Vpenjalni nastavek vretena - JIS A2-6 Konus vretena mm Ø 70 × 1/10 Prehod vretena mm Ø 62 Območje števila vrtljajev vretena U/min 35 – 4.000 Pomik Z-osi mm 320 Hitri pomik Z-osi mm/min 20.000 Pomik X-osi mm 155 Hitri pomik X-osi mm/min 15.000 Tip revolverja - V Število orodij - 8 (opcijsko 12) Velikost orodja za zunanjo obdelavo mm n 25 Velikost orodja za notranjo obdelavo mm Ø 40

Stanje: dober (rabljeno), Leto izdelave: 2004, Swing diameter over bed Ø 320 mm Swing diameter over cross slide 150 mm Turning length 750 mm Spindle bore 52 mm Spindle power 16 kW Quill diameter 60 mm Quill stroke 140 mm Spindle taper 4 MT Spindle speed 3000 rpm Rjdpfxjwu Dq Aj Ag Tep Feed rate X-axis 1000 mm/min Feed rate Z-axis 2000 mm/min

Stanje: generalkompletno obnovljen (rabljeno), Leto izdelave: 1988, - Completely overhauled in 2022 - Heidenhain TNC320 CNC control system - CNC or manual control possible - Movable vertical milling head with extendable spindle - Counter bearing for long milling arbors - Hydraulic tool clamping - Automatic gear transmission - Automatic clamping on X, Y, and Z axes - Automatic central lubrication - Coolant system - Direct path measurement - Collision protection coupling on Y and Z axes - Year of manufacture: 1988 - Includes tool holders, drilling/milling tools & tool trolley Specifications Working area: - X-axis (longitudinal): 485 mm - Y-axis (cross): 385 mm - Z-axis (vertical): 380 mm - Quill stroke (vertical): 80 mm - Vertical milling head manually adjustable on spindle carrier: 150 mm Main drive: - Pole-changing three-phase brake motor: gear transmission with forward/reverse - Power: 3.7 / 4.4 kW - Work spindle speeds: 63 - 3150 rpm (18 steps) - Step increment: 1.25 - Tool holder: SK40 (M16) - Tool clamping: disc spring assembly - Tool release: hydraulic Feed drive: - X-axis: 1 DC motor - Y & Z axes: 1 DC motor - Ball screw spindles: all axes - Feed rate: 2 - 3000 mm/min (programmable) - Rapid traverse X/Y/Z-axis: 3000 mm/min Table slide: - Number of T-slots: 4 - T-slot width: 14H7 mm - T-slot spacing: 63 mm - Permissible load: approx. 600 kg Installation: - Footprint (including safety area): approx. 2300 x 2500 mm - Machine weight incl. vertical milling head and angle table: approx. 1830 kg - Operating voltage: 400 V - Total connected load: 12.5 kVA - Floor load: 3000 kg/m² Rodswhk Ubjpfx Ag Tsp

Stanje: rabljeno, Workpiece weight: 100 kg Workpiece length: 1000 mm Redpfx Agjv Nq Swj Tep Diameter: 500 mm Centre height: 280 mm Total power requirement: 2.5 kW Machine weight approx.: 1 t Space requirement approx.: 1.6 x 1 x 1.6 m

Stanje: rabljeno, Leto izdelave: 1990, x-travel 400 mm y-travel 330 mm z-travel 350 mm Total power requirement 6.3 kW Machine weight approx. 2 t Space requirement approx. 7.36 m² O F F E R Rodpfst Hxbwox Ag Tjp We can offer you, subject to prior sale and errors, ex-stock on a non-binding basis: H E R M L E CNC-controlled Universal Tool Milling Machine with 4th axis Model UWF 600 CNC ( HDH TNC 355 ) Year of manufacture 1990 # 8637 Table travels: longitudinal X 400 mm vertical Z 350 mm Cross travel Y 330 mm Table size 630 x 335 mm Spindle taper SK 40 Spindle speeds in 3 ranges Vertical / Horizontal 40 – 6,000 rpm Quill stroke Vertical 63 mm Feeds, infinitely variable 1 – 2,000 mm/min Feed force 4,800 N Rapid traverse 5,000 mm/min Spindle drive 3.5 kW Total connected load 6.3 kW - 380 V - 50 Hz Weight 2,000 kg Accessories / Special equipment • HEIDENHAIN 4-axis contour control Type TNC 355 with graphics and various subprograms, mobile electronic handwheel • Fixed angular table installed, fitted with CNC dividing head by HOFMANN with RÖHM three-jaw chuck 160 mm dia., center height approx. 125 mm, possibly also tiltable. Resolution 0.001° (dividing head can also be removed!) • Vertical head easily swivels away for use of the horizontal spindle • Hydraulic tool clamping in the V-spindle, 5 various arbor holders • Free-standing control cabinet, free-standing coolant facility • Central lubrication, ampere meter, etc. An ideal machine for toolmaking and electrode production Condition: good – ready for demonstration, HDH control computer was replaced Delivery: ex-stock – as inspected Payment: strictly net – upon receipt of invoice Further conventional and CNC milling machines by DECKEL, MAHO, MIKRON or HERMLE as well as other renowned manufacturers available from stock! Please contact us.
