Ekscentrični tisk

Betz EZL 300

Stanje: rabljeno, Leto izdelave: 2006, Funkcionalnost: popolnoma funkcionalen, stružna dolžina: 780 mm, premer struženja: 270 mm, moč vretenovega motorja: 15 W, potovalna razdalja osi X: 195 mm, pomik osi Y: 120 mm, pomik po osi Z: 780 mm, CNC Lathe Nakamura-Tome WT-300 Year of manufacture: 2006 CNC Control: FANUC Series 18i-TB Machine weight: 12,000 kg Machine dimensions: Length: 5,230 mm Width: 2,500 mm Height: 2,300 mm Machining capacity: Max swing diameter on upper/lower turret: Ø 310 mm (both upper and lower) Distance between spindles (min - max): 120 mm – 1,200 mm Max turning diameter main spindle / sub-spindle: Ø 270 mm Max turning length: 780 mm Bar capacity main spindle / sub-spindle: Ø 65 mm Axis travels: Axis X1 / X2: 195 mm Axis Y: 120 mm (±60 mm) Axis Z1 / Z2: 780 mm Axis B: 850 mm Axis C: 360° (continuous) Main spindle and sub-spindle: Spindle speed: 50 – 4,500 rpm Spindle nose: ASA A2-6 Chuck diameter: Ø 225 mm Minimum programmable C-axis increment: 0.001° Spindle motor power (cont./30 min): 11/15 kW (both spindles) Turret No.1 & No.2 (identical): Tool positions (static / driven): 24 positions (12 driven) Driven tool speed: 3,600 rpm Driven tool motor power: 3.7 / 5.5 kW Turning / boring tool dimensions: 25×25 mm / Ø 32 mm Rapid traverses: Axis X1 / X2 / Y: 16,000 mm/min Axis Z1 / Z2: 24,000 mm/min Axis B: 36,000 mm/min Dledpfxewx Hicj Aa Hea Axis C: 100 rpm Axis B: 27,000 mm/min Included accessories: LNS MOVE bar feeder (2,300 mm length capacity) Chip conveyor Coolant collection tank with wash pump High-pressure pump with external coolant tank Various fixed and driven toolholders Tool presetting arm with dual RENISHAW probe heads Part unloading arm Manuals, electrical diagrams and CE Declaration

Stanje: rabljeno, Leto izdelave: 2006, Proizvajalec: Weinig Model: Unimat Super 4 Leto izdelave: 2006 Štiristranski skobeljni stroj Proizvajalec: WEINIG obnovljen Model: UNIMAT SUPER 4 z avtomatsko mehanizacijo kratkih obdelovancev EM15 - Leto izdelave: 2006 Tehnične specifikacije - Delovna širina: največ 150 mm - Delovna širina: najmanj 25 mm - Delovna višina: največ 50 mm - Delovna višina: najmanj 15 mm - Število vreten: 3 - Moč zgornjega vretena: 22 kW - Moč spodnjega vretena: 11 kW - Hitrost vrtenja vretena: največ 7.000 min⁻¹ - Premer vretena: 40 mm - Dolžina mize: 2.000 mm - Največja hitrost podajanja: 24 m/min Dledpfx Aeqprk Tsa Hja - Neprestano nastavljivo podajanje - Poseben motor za vsako vreteno - Kardansko gnano podajanje valjev - Podajanje iz zalogovnika - Motorni pomik višine skobljanja - Avtomatska mazalna črpalka - WEINIG čelni rezkar - WEINIG EM 15 - Skupna priključna moč: 45 kW

Stanje: zelo dobro (rabljeno), Leto izdelave: 2001, Leto izdelave: 2001 X - 548,6 mm, Y - 408,9 mm, Z - 459,7 mm Moč - 5,6 kW Obrati - 15.000 rpm Avtomatski menjalec orodja (ATC) - 30 Miza - 599,4 mm x 378,5 mm Dsdpfx Asgx Aafoa Hola Konus - BT40 Krmiljenje - CNC (Yasnac J300) Teža stroja: 4 tone Dimenzije stroja: 7' x 8' x 9'

Leto izdelave: 1990, Stanje: rabljeno, Pressure: 75 t Outreach: 300 mm Stroke: 8 – 110 mm Table surface: 750 x 600 mm Ram adjustment: 75 mm Ram surface: 430 x 230 mm Through-hole in table: 250 x 150 mm Pin hole in ram: 40 mm Stroke rate: 60 + 90 strokes/min Machine weight: approx. 4.4 t Total power requirement: 4.5 – 6.8 kW Space requirement: approx. 1.95 x 1.1 x 2.35 m Distance table/ram with stroke down, ram down: 19 mm Distance table/ram with stroke up, ram up: 380 mm Equipment: - With hydraulic clutch-brake combination, new hydraulics and oil cooler - With gear train in oil bath - Fixed table prepared for mounting of tool change consoles - 2 roller strips in the table - Mechanical overload protection in ram (shear plate) The following works are carried out on the machine / Partial overhaul: - Machine completely disassembled, inspected, seals replaced, defective parts exchanged, etc. - Machine repainted - New Balluff cam switch Dodpod Nl E Usfx Aa Hsla - New hydraulic unit with oil cooler for clutch - New Vogel central lubrication system - New control cabinet with touch panel and ABB safety control - Current UVV safety inspection with brake time measurement

Leto izdelave: 1974, Stanje: rabljeno, Druck: 340 t Hubweg: 200 mm Tischgröße unten: 100 x 800 mm Abstand oben/unten: – offen 510 mm (Lichte Weite) Dledj Du Uwspfx Aa Hea – geschlossen 310 mm Neue Hydraulik- und Elektroanlage

Stanje: rabljeno, Leto izdelave: 2004, Technical details: Screw diameter: 105 mm Shot weight in polystyrene: 4727 g/PS Clamping force: 2300 kN Platen size: 2830 x 2400 mm Opening stroke: 3700 mm Mold height: 1100-1800 mm Injection volume: 5195 cm³ Max. injection pressure: 2296 bar Dimensions: 14.2 x 4.15 x 2.84 m Total weight: 143 t Tie bar spacing: 2000 x 1600 mm Robot system, core pulls, hot runner controller - The machine is in very good condition - Complete set of cutters also available - Including a conveyor belt and robot systems (Model 2012) Dodpfetrbcbsx Aa Hjla

Leto izdelave: 1999, Stanje: rabljeno, Press force 630 t Passage width 1390 mm Stroke 400 mm Dsdpjlp U R Sofx Aa Hola Table area 1390x1250 mm Total power requirement 75 kW Machine weight approx. 36 t Space requirements approx. WxDxH 3200x2800x4000 mm Rapid traverse - Working stroke Pressure and stroke cut-off Ram locking

Leto izdelave: 2007, Stanje: zelo dobro (rabljeno), TOP CONDITION - OVERHAULED IN 2022! Year of manufacture: 2007 Table size: 3000 x 1500 x 100 mm Power: 4000 W Control unit: Mazatrol Preview with LAN/USB Includes chiller Includes linear drives on all axes Includes programming software Includes training Includes commissioning Includes fast piercing Includes ball transfer table Includes 4-position head change magazine Includes 2 cutting heads Includes 10-position automatic nozzle changer Mild steel: up to 24 mm Stainless steel: up to 15 mm oxide-free Designed for high-pressure cutting up to 20 bar No foundation required! Regularly maintained Djdpfx Aaohturve Hjla Optional: Automatic loading and unloading with Mazak CELL510 INCLUDING warranty / commissioning / training

Leto izdelave: 1990, Stanje: nepreverjeno (rabljeno), Pressure: 125 tons (2 x 63) Infinitely adjustable working speed: 0–10 mm/sec Return speed: 20 mm/sec Clearance between uprights: 950 x 550 mm Table surface area, front access: 950 x 820 mm Table surface area, side loading: 1220 x 550 mm Ram surface area: see table dimensions Maximum installation height: 700 mm Stroke: 500 mm Dodpfx Aasgy Hzps Hsla Weight: 5,500 kg Height: 2,900 mm Drive power: 18.5 kW 2 hydraulic cylinders with precision synchronous control Infinitely adjustable electronic stroke limitation

Stanje: generalkompletno obnovljen (rabljeno), Leto izdelave: 2004, merilno območje os X: 900 mm, merilno območje osi Y: 2.000 mm, merilno območje os Z: 600 mm, Mitutoyo koordinatna merilna naprava Crysta Apex C9206 Merilna območja: 900x2000x600 mm Merilna negotovost: 1,7 + 3L/1000 µm Strojni pokrov (Y-os) poškodovan oz. ponovno izdelan (za doplačilo), mehanika v redu. Dedpfx Aajf S Tmvs Hela Merilna programska oprema MCOSMOS-1 V3.5 z rabljenim W10 računalnikom ali po izbiri za doplačilo: - Mitutoyo MCOSMOS 4.2 Geopak + MCAT100S ali novo - EasyCMM I++ strežnik in Inca Professional Merilna glava Renishaw PH10T po izbiri z merilno tipalo: - Renishaw TP200 - Renishaw TP20 po želji za doplačilo: - Skenirna tipalka SP25M s PH10M - Menjalna omara za tipala - Nov PH10M+ in TP200 (nadgradnja) - Nov Windows 11 računalnik - MCOSMOS offline licenca MCAT1000P - Bilz pnevmatsko dušenje vibracij Po želji montaža in kalibracija (potni stroški se dodatno obračunajo) Vključno s 3-mesečno garancijo (brez potnih stroškov)
