Kigo Oe
Kigo Oe iz Thessaloniki
Wir sind ein international tätiges Unternehmen und bauen individuelle Anlagen für den Bereich Oberflächentechnik. Wir bauen Pulver/ Naßlackanlagen, Galvanikanlagen, Abwassertechnik usw. nach Bedarf unserer Kunden. Sie können jederzeit unsere gebauten Anlagen besichtigen. Wir freuen uns darauf, Ihnen gute Qualität zu einem sehr attraktiven Preis anbieten zu können.
Unsere deutsche Vertretung:
Handelsagentur Klaus Benecke
Otto-Brenner-Str. 80
45549 Sprockhövel
G. Kiriakos Kourtzoglou
13 Km Thessaloniki Lagada 1
57200 Thessaloniki
Grčija
Griechenland
Trenutne ponudbe podobnih prodajalcev
mali oglas

615 km
Lakirnica s separatorjem vode
Wolmal
Wolmal
Klic
Stanje: novo, Leto izdelave: 2025, skupna dolžina: 1.500 mm, skupna višina: 1.900 mm, skupna širina: 1.300 mm, trajanje garancije: 12 meseci, 🧩 System built to customer specifications
All booths are manufactured to order and can be individually tailored to the customer's requirements – dimensions, blower performance, and configuration are freely selectable.
🟦 Paint booth with water curtain filtration
Professional paint booth with water curtain filtration, designed for the extraction of paint mist and paint particles during spray painting operations.
The system, featuring a water curtain and droplet separator, ensures effective air purification for a clean and safe working environment.
Thanks to its compact stainless steel construction, the booth is ideal for workshops and smaller paint facilities.
Robust, easy to clean, and resistant to chemical influences.
🔹 Technical specifications
- Usable space: 1300 × 1500 × 1900 mm (W × D × H)
- Water curtain, droplet separation
- Water pump: 1.1 kW
- Fan: 1.5 kW, air flow 7200 m³/h
- Chamber made of stainless steel
- Water tank with drainage
- Line voltage: 400 V / 50 Hz
🔸 Features & Benefits
- Effective wet filtration – clean air and safe working conditions
- Stainless steel construction – durable, corrosion-resistant, and easy to maintain
- Compact design – ideal for smaller spray painting areas
- Quiet, energy-efficient operation
Hnodoxl Akyjpfx Ah Deu
- Easy access to all maintenance elements
mali oglas

615 km
Avtomatska tristopenjska pralna naprava
Wolmal
Wolmal
Klic
Stanje: novo, Leto izdelave: 2025, skupna dolžina: 7.500 mm, skupna višina: 3.400 mm, skupna širina: 3.800 mm, trajanje garancije: 12 meseci, notranja dolžina: 7.000 mm, notranja širina: 1.500 mm, notranja višina: 2.200 mm, 🧩 System built according to customer specifications
This washing system is manufactured to order. We tailor the dimensions, number of process stages, heating output, pump configuration, and automation individually to the customer’s requirements.
🟦 Automatic 3-Stage Washing System – Modern Solution for Surface Preparation
State-of-the-art, fully automatic spray washing system for the pre-treatment of steel and aluminium components prior to powder coating or other surface processes.
The unit features separate process chambers, each optimized for a specific chemical medium, ensuring optimal cleaning and adhesion preparation.
Equipped with an overhead conveyor system, independent fluid circuits, and precise control of both temperature and process time, this system provides efficient, reproducible, and nearly maintenance-free cleaning.
Ideal for manufacturing businesses seeking a reliable, energy-efficient, and automated cleaning solution for metal parts.
Hjdpfoxlzihjx Ah Donu
🔹 Technical Data
- Usable space: 7000 × 1500 × 2200 mm (L × W × H)
- Overall dimensions: 7500 × 3800 × 3400 mm
- Overhead transport: 3 rails, 60×60×4 mm
- Batch-type (non-continuous) chamber
- 5-stage process
- Separate, closed fluid circuits
- Cleaning via high-pressure pumps and spray nozzles (side and top)
- 4 tanks:
* 2 heated and thermally insulated (for chemicals)
* 2 for water / DI water
- Tank volume: 2,500 L each
- Heating capacity: 2 × 36 kW (electrical)
- Total connected load: 90 kW
- 5 pumps × 3.0 kW, alternating operation
- Automatic transfer between washing stages
- Adjustable temperature and process time
- Mains voltage: 400 V / 50 Hz
🔸 Features & Benefits
- Precise and repeatable cleaning of steel and aluminium components
- Separate chambers and circuits – no cross-contamination
- Fully automated control and stage transition
- Adjustable temperature and process parameters
- Thermally insulated tanks for energy savings
- Can be integrated into paint shops or production lines
mali oglas

615 km
Polavtomatska naprava za prašno lakiranje
Wolmal
Wolmal
Klic
Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2025, obratovalne ure: 8 h, Funkcionalnost: popolnoma funkcionalen, skupna dolžina: 7.000 mm, skupna višina: 3.000 mm, skupna širina: 2.600 mm, trajanje garancije: 12 meseci, 🟦 Semi-Automatic Powder Coating System – Compact Container Solution
Modern semi-automatic powder coating system in container design, consisting of a spray booth, recirculation oven, and automatic conveyor system.
A compact and mobile solution for coating small metal parts – ready for operation anywhere after connection to power supply.
Ideal for manufacturing companies, workshops, and service providers looking for an efficient and flexible coating system.
🔹 Technical Data
RECIRCULATION OVEN
- Usable space: 4000 x 700 x 1300 mm (L x W x H)
- Heating output: 24 kW
- Motor: 2.5 kW, 1500 rpm
- Centrifugal fan: 4500 m³/h
Hsdpfx Aexlr Emeh Donu
- Thermal insulation: 150 mm
- Maximum temperature: 250°C
SPRAY BOOTH
- Usable space: 2000 x 600 x 1400 mm (L x W x H)
- Filter system:
* Motor: 2.2 kW, centrifugal fan 12,500 m³/h
* Two conical polyester filters L600
* Twist-in filter mounts
* Pneumatic filter cleaning with adjustable cycle
AUTOMATIC CONVEYOR SYSTEM
- Travel distance: 11,500 mm
- Hook spacing: 250 mm
- Number of hooks: 45 pcs
- Max. speed: 4 m/min
- Motor power: 0.75 kW
🔸 Features & Benefits
* Compact container design – easy transport and quick commissioning
* Minimal space requirements and low energy consumption
* Continuous process via automatic conveyor system
* Highly efficient filtration system
* Complete “plug & play” system – immediately ready for operation
mali oglas

1.000 km
Montaža prašnega lakiranja
Esteepowdercoating line
Esteepowdercoating line
Klic
Stanje: pripravljen za uporabo (rabljen), Avtomatska linija za prašno lakiranje
Ni potrebe po temeljih, vse je nameščeno na tleh = enostavna demontaža
Oprema je še na lokaciji.
Oglejte si video.
Maksimalne mere obdelovanca:
Dolžina: 6200 mm
Širina: 850 mm
Višina: 2750 mm
Linijo sestavljajo:
Pripravljalna cona:
Ogrevana in izolirana razmaščevalna postaja
- 7 rezervoarjev
- mere rezervoarja: 4800 x 700 x 3000 mm
Cona prašnega lakiranja:
Chain Power prosti transportni trak (Van Herwijnen BV)
- Maks. 1500 kg na dva kavlja
Hjdpfx Aexg Udneh Djnu
Hidravlična nagibna miza
Estee praškarska kabina (6200 mm)
- 2 Gema ITW robota, vsaka enota ima 2 šobe
Plinska peč za utrjevanje
Rekuperacijski in ciklonski filtrirni sistem
mali oglas

1.234 km
Linija za prašno barvanje
SARTHE
SARTHE
Klic
Stanje: rabljeno, Ligne de peinture en poudre
Comprend :
- Cabine de peinture revêtue de polyester, capacité intérieure 3x1m
- Dotée d’une porte extérieure pour peinture.
- Dimensions de la porte pour l’entrée/sortie des pièces sur carrousel : X
- Dimensions de la fenêtre latérale pour peinture : X
Hnedexgnpkopfx Ah Dju
- Four de séchage 3x1m
- Marque : SART
- Modèle : HE
- Puissance : 18 000W
- Pistolet pour peinture en poudre
- Marque : X
- Modèle : X
- Carrousel avec chariots à rouleaux pour circulation des pièces (env. 20 mètres)
- Cyclone pour la recirculation de l’air avec poudre (Bleu)
- Filtre à poussière avec variateur Telemecanique
- Compresseur à piston insonorisé d’occasion NUAIR + Sécheur HERTZ
- Compresseur à piston insonorisé Nuair, modèle AIRSIL 2, 5,5ch, réservoir 270L, 640L/min, 952 heures d’utilisation, année 2020.
- Sécheur d’air Hertz, modèle HRD 40, monophasé 220V
*Installation démontée et stockée dans nos locaux. Livrée en l’état.
mali oglas

812 km
Avtomatska prašna lakirnica
Mogielnicki
Mogielnicki
Klic
Stanje: zelo dobro (rabljeno), Leto izdelave: 2017, obratovalne ure: 8.073 h, Funkcionalnost: popolnoma funkcionalen, skupna dolžina: 22.450 mm, skupna višina: 5.000 mm, skupna širina: 15.100 mm, vrsta vhodnega toka: trifazni, potreba po zraku: 58 m³/h, višina obdelovanca (maks.): 1.200 mm, dolžina obdelovanca (maks.): 1.200 mm, gorivo: dizel, Oprema: osvetlitev, For sale: a complete, fully functional, automatic powder coating line by Mogielnicki. Year of manufacture: 2017. In excellent condition, only 8,073 operating hours. Complete documentation available.
Equipment includes:
1. Five-stage spray washer
2. Tunnel dryer
3. Automatic cyclone spray booth with platforms for manual touch-up (4x Gema automatic guns, 2x Gema manual guns)
4. Powder coating polymerization oven
5. Overhead conveyor system
6. Double demineralization station
Maximum workpiece dimensions:
Hsdpfxexfgv He Ah Djnu
1200x500x1200 mm (L x W x H)
Media requirements:
1. Electric power
Installed capacity – 99 kW
2. Heating oil
During equipment warm-up – 77 l/h
During continuous operation – 47 l/h
3. Mains water
During continuous operation – 200 l/h
4. Compressed air – 58 m3/h (6 bar)
Required space: 22.5 m x 15 m x 5 m
Price: EUR 162,000 net, VAT invoice available.
Price does not include relocation; we can provide contact to a relocation service provider.
Testing on site possible.
Please get in touch for more information.
mali oglas

999 km
Oprema za prah
EmotechHangbaan transportsysteem
EmotechHangbaan transportsysteem
Klic
Stanje: rabljeno, Funkcionalnost: popolnoma funkcionalen, Transportni sistemi za linijo prašnega lakiranja.
Skupna dolžina približno 75 m.
Hjdpfx Asxaz Ersh Dsnu
Inštalacija je skrbno razstavljena.
Na voljo je video delovanja.
380V
S frekvenčnim pretvornikom.
*Pozor: ponudba se nanaša samo na transportni sistem.
mali oglas

677 km
Tovarna praška
Kigo O.E.CO-3200
Kigo O.E.CO-3200
Klic
Stanje: rabljeno, Leto izdelave: 2020, obratovalne ure: 500 h, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 300120-03-DE, skupna dolžina: 4.170 mm, skupna višina: 2.318 mm, skupna širina: 2.374 mm, moč: 54 kW (73,42 KM), notranja dolžina: 3.200 mm, notranja širina: 2.000 mm, notranja višina: 1.920 mm, poraba energije: 54 kWh, Sistem za prašno lakiranje z naslednjimi komponentami:
Hedpow Tcpaofx Ah Donu
- Peč
- Odsesavanje
- Wagner pištola
- Barve
mali oglas

654 km
Naprava za prašno lakiranje / prašna naprava
Morgenstern / CSF / GEMA / Ramseier
Morgenstern / CSF / GEMA / Ramseier
Klic
Stanje: dober (rabljeno), Leto izdelave: 1990, Funkcionalnost: popolnoma funkcionalen, All conveyor technology is from CSF. The control system for all plant components, including visualization, all switch cabinets, all frequency converters, as well as many other components, has been completely renewed over the last 5-7 years. The plant was decommissioned in Q1-2025 but can be restarted at any time if required. All plant components are on standby and can be immediately put into operation and demonstrated to potential buyers. The plant features one manual and two automatic booths. Parts up to a total size of 7000x2300x800 mm can be coated in any of the booths. A complete description can be provided upon request. Price on request!
Hjdpfxsw Ek Nts Ah Denu
mali oglas

464 km
Oprema za prah
NYS Equipments Co., Ltd.
NYS Equipments Co., Ltd.
Klic
Stanje: rabljeno, Leto izdelave: 2014, Funkcionalnost: popolnoma funkcionalen, višina obdelovanca (maks.): 1.500 mm, dolžina obdelovanca (maks.): 7.000 mm, Linija za elektrostatsko praškasto plastificiranje aluminijskih profila – gotovo nova, potpuno ispravna i odmah dostupna za preuzimanje
Hsdewvaaispfx Ah Djnu
Na prodaju je kompletna automatska linija za praškasto plastificiranje renomiranog proizvođača NYS Equipments Co., Ltd., minimalno korištena i u odličnom tehničkom stanju. Linija se trenutno nalazi u komercijalnoj upotrebi i spremna je za rad. Idealna je za obradu aluminijskih profila maksimalnih dimenzija 7.000 x 300 x 1.500 mm (D x Š x V), s kapacitetom do 15 nosača/sat.
Glavne tehničke karakteristike:
✅ Proces: automatsko elektrostatsko nanošenje praška s 16 automatskih i 4 ručna Corona pištolja
✅ Peć za polimerizaciju: plinsko grijanje (RIELLO), kapacitet 700.000 kcal/h, PID regulacija temperature s preciznošću ±2 °C, unutarnje dimenzije 11,1 x 7,8 x 2,59 m
✅ Sušara: plinsko grijanje, kapacitet 200.000 kcal/h, unutarnje dimenzije 8,0 x 1,5 x 2,3 m
✅ Transportni sustav: dvostruki lanac, razmak između nosača 2.250 mm, motor pogona 3,75 kW, automatska regulacija brzine (0–6 m/min), sustav automatskog podmazivanja
✅ Sustav za recikliranje praška: ciklon + after-filter s automatskim vibracijskim sitom, ventilator kapaciteta do 19.263 m3/h, filtracija putem 24 long fiber filtera, automatsko čišćenje reverznim zrakom
✅ Upravljanje: PLC s touch-screen komandnim panelom; potpuni nadzor i kontrola procesa (kretanje transportera, temperatura peći, reciklaža)
Dodatne prednosti:
– Linija spremna za preuzimanje prema načelu „viđeno-kupljeno” (as is, where it is)
– Mogućnost probnog rada i obuke osoblja prije preuzimanja
– Demontaža i transport nisu uključeni u cijenu, ali ih je moguće organizirati na licu mjesta
Cijena: 100.000 €
mali oglas

498 km
Tovarna praška
Mogielnicki I spolkaManuelle Pulveranlage
Mogielnicki I spolkaManuelle Pulveranlage
Klic
Stanje: novo, Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, teža obdelovanca (maks.): 250 kg, Manual powder coating system, suitable for coating gas cylinders.
Hsdpfx Aswhbvpjh Dsnu
mali oglas

359 km
Oprema za prah
Surfin TechnologyNORDSON Encore HD
Surfin TechnologyNORDSON Encore HD
Klic
Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2021, Funkcionalnost: popolnoma funkcionalen, skupna dolžina: 44.860 mm, skupna višina: 5.250 mm, skupna širina: 17.100 mm, vrsta vhodnega toka: trifazni, teža obdelovanca (maks.): 80 kg, vhodna frekvenca: 50 Hz, ogrevalna zmogljivost: 350 kW (475,87 KM), priključek za stisnjen zrak: 8 letvica, višina obdelovanca (maks.): 2.000 mm, dolžina obdelovanca (maks.): 800 mm, razmak između stupova: 3.000 mm, gorivo: gospodinjski plin H, izolacijski material: PUR, debelina izolacije: 80 mm, širina obdelovanca (maks.): 800 mm, Oprema: kabina, osvetlitev, Naprodaj je aplikacijski del praškovne lakirnice iz leta 2021. Aplikacijska tehnika NORDSON ENCORE HD, napajalne kaskade z napetostjo do 100 kV, krmilni sistem POWDER PILOT, dozirni center SPECTRUM HD II, lakirne pištole ENCORE HD (16 kosov) + 2 ročni pištoli, črpalka tipa HDLV (18 kosov).
Hnsdpfx Ahewhbnle Dou
mali oglas

445 km
Linija za prašno lakiranje je končana
PulveranlagePulverbeschichtung
PulveranlagePulverbeschichtung
Klic
Stanje: novo, Leto izdelave: 2025, Powder Coating – The perfect layer for lasting protection.
Powder coating is a highly effective and widely adopted method for applying a protective and decorative finish to various types of surfaces. It is a dry finishing process in which a fine powder composed of resins, pigments, and additives is applied to a substrate. The powder is electrostatically charged, ensuring uniform adhesion to the surface and forming an even coating.
To achieve optimum adhesion and durability, the substrate is thoroughly cleaned and prepared beforehand. Oils, dirt, and other contaminants are removed to ensure a clean surface. This step is essential to ensure effective bonding of the powder with the substrate, resulting in a robust and long-lasting coating.
A typical powder coating system consists of several components and devices required for the application and curing of powder coatings.
Powder spray booth and spray area
The booth provides a controlled environment for the application process and ensures uniform powder distribution.
Powder coating gun
A powder coating gun is used to apply the powder coating to the workpiece.
Hedpfx Aowf Dpgjh Denu
Powder supply system
The powder supply system comprises a hopper or container for storing the coating material. It typically includes equipment such as powder pumps, feed hoses, and powder sieves to convey powder from storage to the spray gun.
Pretreatment equipment
Pretreatment systems prepare the substrate prior to powder coating application. This may involve processes such as cleaning, degreasing, rinsing, and surface treatment to ensure optimal adhesion and durability of the finish.
Curing oven
A curing oven is a vital component of a powder coating plant. It is used to heat the coated substrate to the appropriate temperature, allowing the powder coating to melt, flow, and cure into a durable surface. The oven commonly features a conveyor or racks to transport coated parts through the curing chamber.
Exhaust system
An extraction system is installed to remove excess powder, fumes, or volatile compounds generated during the coating process. It helps maintain a clean and safe working environment for personnel and prevents the accumulation of powder particles in the air.
mali oglas

674 km
Tovarna praška
ProtonMiniPB-Mat4
ProtonMiniPB-Mat4
Klic
Stanje: novo, ⭐⭐⭐⭐⭐ (5.0)
⚡️ Top Service ⚡️ Fast Delivery ⚡️ Excellent Support!
✈️ Shipping costs apply – shipping available on request.✈️
Fast delivery: Only 4 weeks after receipt of payment!
✅✅✅Energy efficiency class A+++✅✅✅
PROFESSIONAL POWDER COATING HAS NEVER BEEN THIS EASY!
The Mini-PB-MAT 4 is the perfect solution for beginners! This powerful system enables efficient, cost-effective and high-quality coating of car rims and smaller workpieces – with minimal effort!
* Your net price for commercial customers: €26,830.00
* Powder booth filter included in the scope of delivery.
* Brand-new professional industrial product
PROTON QUALITY THAT CONVINCES!
✅ Plug & Play system – Delivered fully assembled, ready for immediate operation!
✅ 100% European manufacturing – No Chinese imports, but top-quality production to European standards!
✅ Modular & expandable – Additional options for more performance and flexibility!
Hnsdpfxjwc Ep As Ah Deu
Take advantage of this limited-time offer before it's too late!
➖➖➖➖➖
✳️Maintain your liquidity! We offer a variety of financing options to ensure your investment has the greatest chance of success. Contact us today to learn more about our hire purchase, warranty, or leasing programs.
➖➖➖➖➖
✨✨Buy directly from the manufacturer and secure price and quality advantages!✨✨
➖➖➖➖➖
☘️Environmentally friendly☘️⚡️Green energy⚡️☘️
Powder oven + Powder booth + Powder coating gun + Transport cart for curing oven
Complete starter package - ⭐ MiniPB-MAT4 ⭐
⭐ Powder oven with electric heating - MATOVENB-151830
✔️ Internal dimensions: 3000 mm L * 1500 mm W * 1800 mm H
✔️ Electric heating capacity: 42 kW/h
✔️ Blower: 3,000 m3/h 80mm SS
✔️ Recirculation fan power: 1.5 [kW/h]
✔️ Total: 45 kW/h ± 10%
✔️ Digital temperature control, infinitely adjustable up to 220°C
✔️ Sandwich panels: Interior: 1.2 mm galvanized steel, Exterior: 1.2 mm powder-coated steel
✔️ Curing temperature, curing time, and exhaust fan function are adjustable
✔️ Audible signal at the end of the curing time
✔️ Insulated door with special locking mechanisms
✔️ Insulation: 150 mm (50 mm rock wool and 100 mm fiberglass)
✔️ Control panel: 1
*Our powder coating ovens are suitable for ceiling rail systems. If you would like to use this option, please contact our sales team. The oven housing for the ceiling rail system differs slightly from the standard version. The ovens can be operated with a floor-guided transport cart and also with a ceiling rail system simultaneously.
⭐ Powder booth - MATBOOTH.FT-04
✔️ Internal dimensions: 2600 mm L * 1800 mm D * 1450 mm - 2220 mm H
✔️ 4 polyester filters
✔️ Ø325 * 725 mm filter dimensions
✔️ Automatic filter cleaning system (cleaning time adjustable)
✔️ Powder recovery container: 30 liters
✔️ 360-degree rotatable and mobile suspension device
✔️ 1 pc 3 kW exhaust fan – 3500 m3/h
✔️ Control panel: 1
✔️ Lighting
⭐ Powder coating gun – STRONG ELITE MULTICOLOR
Effortlessly coat with all powder colors, coat complex shapes with outstanding efficiency and quality, and do so even in the most challenging environments.
Request now – Get your business ready for the future!
⭐Follow us for new campaigns⭐
☀️ 2-YEAR WARRANTY ☀️
mali oglas

674 km
Tovarna praška
ProtonMiniPB-Mat3
ProtonMiniPB-Mat3
Klic
Stanje: novo, ⭐⭐⭐⭐⭐ (5.0)
⚡️ Top service ⚡️ Fast delivery ⚡️ Excellent support!
✈️ Shipping costs not included – shipping available on request.✈️
Fast delivery: Only 4 weeks after receipt of payment!
✅✅✅Energy Class A+++✅✅✅
PROFESSIONAL POWDER COATING HAS NEVER BEEN THIS EASY!
The Mini-PB-MAT 3 is the perfect solution for beginners! This high-performance system enables efficient, cost-effective, and high-quality coating of car rims and smaller workpieces – all with minimal effort!
* Your net price for commercial customers: €25,180.00
* Powder cabin filter included in the scope of delivery.
* Brand new professional industrial product
PROTON QUALITY THAT CONVINCES!
✅ Plug & Play system – Delivered fully assembled, ready for immediate use!
✅ 100% European manufacturing – No Chinese goods, but top quality according to European standards!
✅ Modular & expandable – Additional options for greater performance and flexibility!
➖➖➖➖➖
✳️Maintain your liquidity! We offer you a range of financing models to ensure your investment has the best chances of success. Contact us today to learn more about our hire purchase, warranty, or leasing programs.
➖➖➖➖➖
✨✨Buy directly from the manufacturer and secure price and quality advantages!✨✨
Benefit from Proton's 40 years of experience in surface coating technologies.
➖➖➖➖➖
☘️Environmentally friendly☘️⚡️Green energy⚡️☘️
Powder oven + powder booth + powder gun + transport trolley for curing oven
Complete starter package – ⭐ MiniPB-MAT3 ⭐
Hnsdpfxswc Epvo Ah Dou
⭐ Powder oven with electric heating – MATOVENB-151824
✔️ Internal dimensions: 2400 mm L * 1500 mm W * 1800 mm H
✔️ Electric heating capacity: 36 kW/h
✔️ Blower: 3,000 m3/h 80mmSS
✔️ Recirculation fan power: 1.5 [kW/h]
✔️ Total 38 kW/h ± 10%
✔️ Digital temperature control, infinitely adjustable up to 220°C
✔️ Sandwich panels: Inside 1.2 mm galvanized steel, Outside 1.2 mm powder-coated steel
✔️ Curing temperature, curing time, and exhaust fan function adjustable
✔️ Audible signal at end of curing cycle
✔️ Insulated door with special locking systems
✔️ Insulation: 150 mm (50 mm mineral wool and 100 mm fiberglass)
✔️ Control panel: 1
*Our powder coating ovens are suitable for ceiling rail systems. If you would like this option, please contact our sales team. The housing design of ovens with a ceiling rail differs slightly from the standard version. The ovens can be operated with both a floor-guided transport trolley and a ceiling rail system at the same time.
⭐ Powder booth – MATBOOTH.FT-03
✔️ Internal dimensions: 1500 mm L * 1200 mm D * 1450 mm – 2220 mm H
✔️ 3 polyester filters
✔️ Ø325 * 725 mm filter size.
✔️ Automatic filter cleaning system (adjustable cleaning interval)
✔️ Powder recovery container: 30 L.
✔️ 360-degree rotating and movable hanging device.
✔️ 1 pc 3 kW extraction fan – 3500 m3/h
✔️ Control panel: 1
✔️ Lighting
⭐ Powder coating gun – STRONG ELITE MULTICOLOR
Effortlessly coat with any powder colour, apply coatings to complex geometries with excellent efficiency and quality, even in the most challenging environments.
Enquire now – Make your business fit for the future!
⭐ Follow us for new campaigns ⭐
☀️ 2-YEAR WARRANTY ☀️
mali oglas

674 km
Tovarna praška
ProtonMiniPB-Mat2
ProtonMiniPB-Mat2
Klic
Stanje: novo, ⭐⭐⭐⭐⭐ (5.0)
⚡️ Top Service ⚡️ Fast Delivery ⚡️ Excellent Support!
✈️ Additional shipping costs – Shipping available on request.✈️
Fast delivery: Only 4 weeks after receipt of payment!
✅✅✅Energy Class A+++✅✅✅
PROFESSIONAL POWDER COATING HAS NEVER BEEN SO EASY!
Mini-PB-MAT 2 is the perfect solution for beginners! This powerful system allows for efficient, cost-effective, and high-quality coating of car rims and smaller workpieces – with minimal effort!
* Your net price for business customers: 17,380.00 Euro
* Powder cabin filter included in the scope of delivery.
* Brand new professional industrial product
PROTON QUALITY THAT CONVINCES!
✅ Plug & Play system – Delivered fully assembled, ready for immediate use!
✅ 100% European manufacturing – No Chinese goods, but top quality according to European standards!
✅ Modular & expandable – Additional options for more power and flexibility!
Take advantage of this limited offer before it’s too late!
➖➖➖➖➖
✳️Maintain your liquidity! We offer a range of financing models to ensure your investment has the best chance of success. Contact us today to learn more about our hire-purchase, warranty, or leasing programs.
➖➖➖➖➖
✨✨Buy directly from the manufacturer and secure the price and quality advantage!✨✨
Benefit from Proton’s 40 years of experience in surface coating technologies.
➖➖➖➖➖
☘️Environmentally friendly☘️⚡️Green energy⚡️☘️
Powder oven + powder cabin + powder gun + transport trolley for curing oven
Complete starter package - ⭐ MiniPB-MAT2 ⭐
⭐ Powder oven with electric heating - MATOVENB-101610
✔️ Internal dimensions: 1000 mm L * 1000 mm W * 1600 mm H
✔️ Electric heating output: 18 kW/h
✔️ Fan: 1,500 m3/h 80mmSS
✔️ Circulation fan output: 0.75 [kW/h]
Hnsdpjwc En Eofx Ah Dju
✔️ Total 19.5 kW/h ±10%
✔️ Digital temperature control, infinitely adjustable up to 220°C
✔️ Sandwich panels Inside: 1.2 mm galvanized steel, Outside: 1.2 mm powder coated steel
✔️ Curing temperature, curing time, and exhaust fan function adjustable
✔️ Signal sound at the end of curing time
✔️ Insulated door with special locking systems
✔️ Insulation: 150 mm (50 mm mineral wool and 100 mm fiberglass)
✔️ Control panel: 1
There are hanging rails inside the oven. Your workpieces can be positioned in the oven with the help of hanging brackets. A double-deck transport trolley can be ordered on request.
⭐ Powder cabin - MATBOOTH.FT-02
✔️ Internal dimensions: 1500 mm L * 1200 mm D * 1450 mm - 2220 mm H
✔️ 2 polyester filters
✔️ Filter dimensions: Ø325 * 725 mm.
✔️ Automatic filter cleaning system (adjustable cleaning time)
✔️ Powder recovery container: 30 L
✔️ 360-degree rotatable and mobile suspension device.
✔️ 1 pc 2.2 kW extraction fan – 2800 m3/h
✔️ Control panel: 1
✔️ Lighting
⭐ Powder coating gun – STRONG ELITE MULTICOLOR
Effortlessly coat with all powder colors, coat complex geometries with outstanding efficiency and quality, even in the most challenging environments.
Request your quote now – Make your business future-ready!
⭐Follow us for new campaigns⭐
☀️ 2 YEARS WARRANTY ☀️
☀️All of our machines have CE certificates, and ATEX certificates are available for the necessary machines.☀️
mali oglas

674 km
Sistemi praškastega lakiranja
PROTONAutomatische Pulverbeschichtungsanlage
PROTONAutomatische Pulverbeschichtungsanlage
Klic
Stanje: novo, Leto izdelave: 2025, ✅ Discover our fully automatic powder coating systems for maximum production capacity!
Professional powder coating is essential for creating durable, corrosion-resistant, and visually appealing metal surfaces.
If you need to coat large quantities with maximum efficiency in your operation, our fully automatic powder coating lines are the ideal solution.
🔧 Proton Maschinenbau GmbH offers intelligent, fully integrated system solutions for cost-effective and consistently high-quality production.
_____
🔍 Technology that convinces – Overview of our system technology:
✅ Spray pre-treatment line in tunnel design
✅ Drying ovens (available in U, M, or L configurations)
✅ Fully automatic powder coating booth
– PVC floor for easy cleaning and quick color changes
– Available enclosure options: stainless steel, powder-coated sheet steel, or PVC
Hnsdpfx Ahjwbh Npo Dsu
– ATEX-certified lighting units
– Pneumatic floor cleaning system
✅ Automatic painting robots (available as 1-, 2-, or 3-axis models)
✅ Automatic powder coating guns
✅ Centralized powder coating station
✅ Monocyclone jet pulse filter unit (adapted to booth size)
✅ Curing ovens (U, M, or L configuration selectable)
✅ Conveyor systems (single-track or power & free system)
✅ Central control panel with touchscreen (starting from 7" display size)
_____
🎨 Custom enclosure colors at no extra charge!
Choose from two modern color variants for our machine enclosures:
Yellow-White or Anthracite-White – tailored to your corporate design or aesthetic preferences.
Our customers can select either combination at no additional cost.
_____
🎯 Why choose a powder coating system from Proton?
✔️ Modular and scalable to your requirements
✔️ Custom layout planning for your site
✔️ Maximum automation thanks to numerous options
✔️ Compliance with European standards (CE, ATEX)
✔️ Energy-efficient and low maintenance
_____
💡 Configure your system now!
Use our powder coating configurator on our website to assemble your custom system.
Once configured, our engineering team will develop a tailored concept to meet your requirements.
_____
Proton Maschinenbau GmbH – Superior engineering. High performance. Trusted worldwide.
mali oglas

674 km
Tovarna praška
ProtonMinipb-Mat
ProtonMinipb-Mat
Klic
Stanje: novo, Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, ⭐⭐⭐⭐⭐ (5.0)
⚡️ Top Service ⚡️ Fast Delivery ⚡️ Excellent Support!
✈️ Price includes shipping within Germany – No additional transport costs!
✈️ Fast Delivery: Only 4 weeks after receipt of payment!
PROFESSIONAL POWDER COATING HAS NEVER BEEN THIS EASY!
Are you looking to expand your business and enter the world of professional powder coating? The Mini-PB-MAT is the perfect solution for beginners! This high-performance system enables efficient, cost-effective, and high-quality coating of car rims and smaller workpieces – all with minimal effort!
✨UNBEATABLE PROMOTION – ONLY UNTIL THE END OF APRIL!✨
Instead of €25,500 now only €16,765 PLUS VAT.
Take advantage of this limited offer before it's too late!
* For an additional shipping cost of €750 we deliver throughout Europe. For all other countries worldwide, please inquire about the shipping price difference.
* Brand new professional industrial product
Hsdpfxsv Rb E Ds Ah Djnu
PROTON QUALITY THAT CONVINCES!
✅ Plug & Play system – Delivered fully assembled, ready for immediate use!
✅ 100% European manufacturing – No Chinese imports, only top quality according to European standards!
✅ Modular & expandable – Additional options for increased performance and flexibility!
✅ All spare parts included – Long-term use with no hidden extra costs!
✳️Maintain your liquidity! We offer you a variety of financing models to ensure your investment receives the highest chance of success. Contact us today to learn more about our hire-purchase, warranty, or leasing programs.✳️
✨✨Buy directly from the manufacturer and secure price and quality advantages!✨✨
☘️Environmentally friendly☘️⚡️Green energy⚡️☘️
Powder Oven + Powder Coating Booth + Powder Coating Gun
Complete Starter Package - MiniPB-MAT
⭐ Powder Oven with Electric Heating
✔️ Internal dimensions: 1000 mm L * 1000 mm W * 1000 mm H
✔️ Electric heating power: 12 kW/h
✔️ Blower: 1,500 m3/h 80mmSS
✔️ Recirculation fan performance: 0.75 kW/h
✔️ Total: 14 kW/h ± 10%
✔️ Digital temperature control, continuously adjustable up to 220°C
✔️ Sandwich panels: Interior: 1.2 mm galvanized steel, Exterior: 1.2 mm powder-coated steel
✔️ Curing temperature, curing time and exhaust fan function can be adjusted
✔️ A signal sounds at the end of curing time
✔️ Insulated door with special locking systems
✔️ Insulation: 150 mm (50 mm rock wool and 100 mm glass fiber)
✔️ Control panel: 1
⭐ Powder Coating Booth
✔️ Internal dimensions: 1200 mm L * 1200 mm W * 1450 mm - 2220 mm H
✔️ 1 polyester filter
✔️ Ø325 * 725 mm filter size
✔️ Automatic filter cleaning system (adjustable cleaning time)
✔️ Powder recovery container: 30 L
✔️ 360-degree rotatable and movable hanging device
✔️ 1 pc 1.5 kW extraction fan – 2500 m3/h
✔️ Control panel: 1
✔️ Lighting
⭐ Powder Coating Gun – STRONG ELITE MULTICOLOR
Effortlessly coat with all powder types, tackle complex geometries with outstanding efficiency and quality, even in the toughest environments.
Inquire now – Get your business ready for the future!
☀️ 2-YEAR WARRANTY ☀️
☀️We have CE certificates for all our machines and ATEX certificates for all required machines.☀️
Options (for oven, spray booth) available at extra charge. All devices/machines are new, not used.
mali oglas

1.273 km
OPREMA ZA PRAŠNO LABIRANJE
VOGAMAKINAVG1E-VN
VOGAMAKINAVG1E-VN
Klic
Stanje: novo, Leto izdelave: 2025, VG1E-VN MANUEL HIZLI RENK DEĞİŞİMLİ TOZ BOYA KAPLAMA SİSTEMİ
Bu toz boya kaplama sistemi, gün içinde sık renk değişimleri gerektiren uygulamalar için tasarlanmıştır. Ekipman, kullanım kolaylığı için tekerlekli bir şasi üzerine montelidir.
Toz boya, doğrudan toz kutusundan emilir ve bu sayede hızlı renk değişimi sağlanır. Toz kutusu titreşimli tabla üzerine yerleştirilir; emiş borusu, kutudaki toz boyanın akışkanlaşmasını sağlar, etkin karışımı garanti eder ve toz boya, emiş borusuna bağlı enjektör aracılığıyla homojen şekilde tabancaya gönderilir.
TEKNİK ÖZELLİKLER
Giriş voltajı : 220V 50Hz
Hava ihtiyacı : 350 lt/dk
Giriş basıncı : 6 bar
Titreşim motoru : 220V 25W
Brüt ağırlık : 55 kg
VG4 KONTROL ÜNİTESİ ve MANUEL TOZ BOYA TABANCASI
VM manuel toz boya tabancası tamamen demonte edilebilir yapıdadır. Ergonomik tabanca sapı, operatöre rahat kullanım sunar ve uzun uygulamalarda yorgunluğu önler. Yüksek voltaj kaskadı uzun ömürlüdür; sızdırmaz yapısı toza karşı koruma sağlar ve bu alandaki riskleri minimuma indirir. Başlık ve meme tasarımı, uygulama sırasında mükemmel polarizasyon ve yüzeyde homojen kaplama sunar.
Tabancanın arkasındaki dokunmatik elektronik panel, kullanım sırasında büyük kolaylık sağlar. Dijital kontrol ünitesiyle, hassas ayarlar dokunmatik panelden yapılabilir.
Hsdpfx Ahsvv N Tyo Dsnu
TEKNİK ÖZELLİKLER
Tabanca Tipi : Korona Sistemi
Polarma : Negatif
Kaskad giriş voltajı : 0-10,5V DC
Çıkış voltajı : 100 kV
Çıkış akımı : 0-150 μA
Toz çıkış (3,5 bar) : 500 g/dk
Koruma sınıfı : IP 54
Voltaj kablo uzunluğu : 5 m
Toz hortumu uzunluğu : 5 m
Tabanca ağırlığı (brüt): 450 g
Çalışma sıcaklığı : -20~50°C
Nozul : Yassı jet veya Ø16-20-24 mm deflektör
mali oglas

7.861 km
Oprema za prah za pesek in mikro prah
Mingyuan Powder production equipment1.83X11m Micro Powder Ball Grinding Mill
Mingyuan Powder production equipment1.83X11m Micro Powder Ball Grinding Mill
Klic
Stanje: novo, Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, Kroglični mlin z zračnim separatorjem: Najboljša oprema za obdelavo prahu
V industriji proizvodnje prahu sta natančnost, učinkovitost in prilagodljivost ključnega pomena. Ne glede na to, ali proizvajate ultrafine praške za visokotehnološke aplikacije ali grobe materiale za vsakodnevne proizvode, kombinacija krogličnega mlina z zračnim separatorjem zagotavlja neprekosljivo zmogljivost. Ta dinamični par ponuja celovito rešitev za industrije, kot so kemija, keramika, premazi, plastika in farmacija.
V nadaljevanju je predstavljena oprema krogličnega mlina z zračnim separatorjem, njene uporabe in ključne prednosti.
Splošna predstavitev krogličnega mlina z zračnim separatorjem
Kroglični mlin z zračnim separatorjem je napreden sistem za mletje in klasifikacijo, namenjen učinkoviti in kakovostni proizvodnji prahu. Sestavljen je iz dveh glavnih komponent:
1. Kroglični mlin: Valjasta mletvena naprava, napolnjena z brusnimi mediji (npr. jeklenimi kroglami), ki obratuje z vrtenjem okoli lastne osi. Surovina se znotraj mlina zmanjša na manjše delce s pomočjo udarcev in trenja.
2. Zračni separator: Naprava, ki s pomočjo zračnega toka ločuje delce po velikosti. Fini delci se odvedejo, grobi pa se vračajo v mlin za dodatno mletje.
Kombinacija obeh komponent tvori zaprto-zankarsko rešitev, ki zagotavlja stalno porazdelitev delcev, visoko učinkovitost in minimalne izgube materiala.
Hodpfx Ahsvlwkxj Djnu
Uporaba krogličnega mlina z zračnim separatorjem
Kroglični mlin z zračnim separatorjem je vsestranska rešitev, uporabljena v številnih panogah za obdelavo različnih materialov. Ključne uporabe:
1. Priprava mineralov
Sistem se pogosto uporablja za proizvodnjo mineralov, kot so kalcijev karbonat, kremen, glinenca in talk. Ti fino zmleti minerali so bistveni za keramiko, premaze, plastiko in gumo.
2. Cement in gradbeni materiali
Cement in drugi gradbeni materiali zahtevajo natančno kontrolo velikosti delcev za optimalno delovanje. Kroglični mlin z zračnim separatorjem zagotavlja enotnost in povečuje kakovost gradbenih materialov.
3. Kemikalije in farmacija
Fini prahovi igrajo ključno vlogo v kemični in farmacevtski industriji. Za učinkovine (API) in industrijske kemikalije sistem zagotavlja konstantno kakovost, ki je potrebna za ta namen.
4. Barve, premazi in pigmenti
Za proizvodnjo barv in premazov so potrebni ultrafini prahovi za doseganje gladkih površin in živih barv. Naprava za mletje s klasifikacijo ustvarja visoko kakovostne praške za vrhunske rezultate.
5. Prehrana in kmetijstvo
Živilski praški, kot so aditivi, konzervansi, ter kmetijski proizvodi, npr. gnojila, se lahko učinkovito predelujejo s tem sistemom, v skladu s strogimi regulativnimi zahtevami.
Industrije, ki koristijo kroglični mlin z zračnim separatorjem
Številne industrije se zanašajo na ta sistem za pridobivanje finih prahov s specifičnimi lastnostmi:
- Keramika: Proizvodnja visokočistih prahov za ploščice, izolatorje in napredno keramiko.
- Guma in plastika: Polnila in aditivi za večjo trpežnost in zmogljivost.
- Farmacija: Zagotavlja enotno velikost delcev za API-je in pomožne snovi.
- Gradbeništvo: Materiali za beton, omete in druge aplikacije.
mali oglas

138 km
Tovarna praška
Knipl
Knipl
Klic
Stanje: dober (rabljeno), Leto izdelave: 2011, Funkcionalnost: popolnoma funkcionalen, skupna višina: 4.000 mm, notranja dolžina: 6.500 mm, notranja širina: 1.500 mm, notranja višina: 2.200 mm, višina obdelovanca (maks.): 2.200 mm, dolžina obdelovanca (maks.): 6.500 mm, Oprema: kabina, Powder coating plant with workpiece dimensions L6500mm, W1500mm, H2200mm
Hjdpsvdlfzefx Ah Donu
New price approx. €800,000.-
mali oglas

858 km
Smodnišnica - transportni sistem
KM Industrieservice
KM Industrieservice
Klic
Stanje: novo, As a leading manufacturer of surface treatment systems, we offer you an almost limitless portfolio for powder coating applications. At our location in 47669 Wachtendonk, we turn your individual requirements into reality and produce your desired system concept.
Hedpfouqygvox Ah Donu
Thanks to our in-house production of nearly all components, we are highly flexible and can respond precisely to your needs. With us, you receive not only your ideal powder coating system – we also provide you with comprehensive user expertise to assist you with all questions related to surface technology.
Every item offered here is custom-made specifically for you. Whether you have large or small projects – we deliver complete systems from a single source, entirely based on your specifications.
We look forward to hearing from you and implementing your ideas together!
We offer:
- Lift-lowering stations for one or more rails (also available with final inspection lighting)
- Cross traverses, manual or electric
- Combination unit: cross traverse with lift/lowering function
- Complete conveyor system including parking sections and product carriers
- Power and Free conveyor systems
- Manual or automatic, chain-driven continuous conveyors
- Planning, design, and installation included
Take your powder coating to the next level of efficiency – we support you with optimal planning and implementation.
mali oglas

445 km
Sistem za Prašno Lakiranje
SAPI GmbH PulverbeschichtungsanlageKomplettsystem für industrielle
SAPI GmbH PulverbeschichtungsanlageKomplettsystem für industrielle
Klic
Stanje: novo, SAPI Praškasto Barvanje
Popolna prevleka za dolgo zaščito.
Praškasto barvanje je zelo učinkovita in široko uporabljena metoda za nanašanje zaščitne in dekorativne površine na različne vrste substratov. Gre za suhi postopek, pri katerem se fina prah, sestavljena iz smol, pigmentov in dodatkov, nanese na substrat. Prah je elektrostatično napolnjen, zato se enakomerno oprime površine in ustvari enakomerno prevleko.
Za dosego optimalne oprijemljivosti in trajnosti se substrat najprej temeljito očisti in pripravi. Olja, umazanija in druge nečistoče se odstranijo, da se zagotovi čista površina. To je ključnega pomena, da se prah učinkovito poveže s substratom in ustvari trdno in dolgo obstojno prevleko.
Komponente Praškastega Barvnega Sistema
Tipičen sistem praškastega barvanja je sestavljen iz več komponent in naprav, potrebnih za nanašanje in strjevanje praškaste prevleke.
Kabina za Pršenje in Območje Pršenja
Kabina zagotavlja čisto okolje za postopek nanašanja in zagotavlja enakomerno porazdelitev praška. 🎨
Pištola za Praškasto Barvanje
Pištola za praškasto barvanje se uporablja za nanašanje praškaste prevleke na delovni kos. 💨
Sistem za Napajanje s Praškom
Sistem za napajanje s praškom je sestavljen iz lijaka ali posode, v kateri je shranjen material za praškasto barvanje. Običajno vključuje naprave, kot so črpalke za prah, dovodne cevi in sita, ki prah prenašajo iz skladišča do pištole za pršenje. 🔄
Hsdpfxsun Sd Uj Ah Djnu
Napravite za Predobdelavo
Sistemi za predobdelavo se uporabljajo za pripravo substrata pred nanašanjem praškaste prevleke. To lahko vključuje postopke, kot so čiščenje, razmaščevanje, izpiranje in obdelava površine, da se zagotovi dobra oprijemljivost in trajnost prevleke. 🧼
Peč za Strjevanje
Peč za strjevanje je ključna komponenta praškastega barvnega sistema. Uporablja se za segrevanje prevlečenega substrata na ustrezno temperaturo, da se prah stopi, tekoče preide in strdi v trajno površino. Peč običajno vključuje sistem za transport ali police, ki prenašajo prevlečene dele skozi peč. 🔥
Sistem za Odsesavanje
V sistemu je nameščen sistem za odsesavanje, ki odstranjuje odvečni prah, pare ali hlapne spojine, ki nastanejo med postopkom nanašanja prevleke. Pomaga pri ohranjanju čistega in varnega delovnega okolja za osebje in preprečuje kopičenje prahovih delcev v zraku. 🌬️
Iščete rešitev za Praškasto Barvanje?
Iščete prilagojeno rešitev za praškasto barvanje?
Specializirani smo za zagotavljanje rešitev za praškasto barvanje, ki so prilagojene vašim specifičnim potrebam. Ne glede na to, ali imate specifične zahteve glede barve, kompleksnih zasnov ali težkih substratov, je naš izkušen tim pripravljen zagotoviti izjemne rezultate. 💡
Kontaktirajte nas še danes, da se pogovorimo o vaših potrebah in nam dovolite, da razvijemo prilagojeno rešitev za praškasto barvanje. 📞
Kontaktirajte nas še danes!
mali oglas

810 km
Avtomatski sistem za prašno barvanje
Handelsagentur Klaus BeneckeDurchlaufanlage Taktverfahren automat.
Handelsagentur Klaus BeneckeDurchlaufanlage Taktverfahren automat.
Klic
Stanje: novo, Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, skupna dolžina: 30.000 mm, skupna višina: 4.300 mm, skupna širina: 6.500 mm, teža obdelovanca (maks.): 100 kg, temperatura: 220 °C, ogrevalna zmogljivost: 80 kW (108,77 KM), višina obdelovanca (maks.): 1.200 mm, dolžina obdelovanca (maks.): 2.500 mm, izolacijski material: Mineralwolle 75 kg/m³, debelina izolacije: 150 mm, širina obdelovanca (maks.): 800 mm, The continuous processing system consists of the following components:
- Chemical pre-treatment via spraying
- Dryer
- Powder coating system
- Powder curing oven
- Conveyor technology (indexing mode)
Hnjdpfx Ajum Ufloh Deu
- Electrical control system
mali oglas

810 km
Sistem za prah s predobdelavo 3 cone
Handelsagentur Klaus BeneckeDurchlaufanlage halbautomatisch
Handelsagentur Klaus BeneckeDurchlaufanlage halbautomatisch
Klic
Stanje: novo, Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, moč: 88 kW (119,65 KM), temperatura: 220 °C, ogrevalna zmogljivost: 30 kW (40,79 KM), višina obdelovanca (maks.): 1.500 mm, dolžina obdelovanca (maks.): 500 mm, izolacijski material: Steinwolle, debelina izolacije: 150 mm, širina obdelovanca (maks.): 500 mm, Scope of delivery:
1. Chemical pre-treatment by spraying (in intermittent operation)
2. Dryer
3. Powder coating system
4. Powder curing oven
5. Conveyor system, semi-automatic
6. Electrical control system
Hall / Footprint
System footprint max. 12,000 x 6,500 mm
Hall floor: Industrial concrete floor
Hnodpsulwg Nofx Ah Dou
Workpiece sizes
Max. part dimensions: L = 500 mm, H = 1,500 mm, W = 500 mm
Part spectrum: Steel
Conveyor system
P&F chain conveyor in intermittent operation, semi-automatic
Pre-treatment
Chemical
Supply requirements
Electricity: On-site supply (max. 88 kW)
Gas: On-site supply
Compressed air: On-site supply
Water: On-site supply
Specification
System type: Intermittent operation system
Conveying speed: 3.2 meters / min
Stroke length per cycle: L = 1,600 mm
Cycle movement time: Tm = 1.6 meters : 3.2 meters/min = 0.5 minute
Cycle standstill time: Ts = 8.5–12 minutes
Total cycle time: Tt = Tm + Ts = 9–12.5 min
Electrical energy: Total power 88 kW
Min. average consumption: 60 kWh
Max. average consumption: 70 kWh
