Stroj za brušenje profilov

ZIERSCH & BALTRUSCH Starline 2000

Stanje: zelo dobro (rabljeno), Leto izdelave: 2022, CNC ravnalni, profilni in globoki brusilni stroj ELB-Schliff smartLine BD15 KXT XC Krmiljenje: Xpress Cube Leto izdelave: 2022 Širina brušenja: 600 mm Dolžina brušenja: 1.500 mm Višina brušenja: 500 mm Premer brusnega koluta: 400 mm Obremenitev mize: 1.200 / 625 kg Pogon vretena: 10 – 52 kW Stožec vretena: 60 / 75 mm Območje vrtilnih hitrosti: 1.450 – 3.500 min⁻¹ Dodatna oprema Pgedpfeyk Tb Uox Agxok Tračni filtrirni sistem Sesalna naprava za hladilno meglo tip VMN-V12 Sistem za uravnoteženje Magnetna plošča

Stanje: dober (rabljeno), Funkcionalnost: popolnoma funkcionalen, Leto izdelave: 1990, številka stroja/vozila: 4ROLL, premer spodnjega valja: 470 mm, premer zgornjega valja: 470 mm, premer stranskega valja: 420 mm, premer valja: 470 mm, dolžina valja: 3.050 mm, delovna širina: 3.050 mm, delovna višina: 1.800 mm, najv. debelina pločevine: 50 mm, najv. debelina jeklene pločevine: 45 mm, maks. debelina aluminijaste pločevine: 45 mm, najv. debelina bakrene pločevine: 45 mm, skupna masa: 43.000 kg, skupna dolžina: 7.700 mm, skupna širina: 2.410 mm, skupna višina: 2.470 mm, moč: 37 kW (50,31 KM), vhodna napetost: 380 V, vrsta vhodnega toka: trifazni, delovna dolžina: 3.050 mm, Oprema: dokumentacija / priročnik, nujno zaustavitev, PLATEBIEGEMASCHINE FACCIN – 4-WALZEN HYDRAULISCH 3000 X 40 MM MODELL 4HCI3-35/30 BAUJAHR 1990 BLECHBIEGEWALZE MIT LINEARFÜHRUNGEN, DOPPEL-VORBLECHEN (DOUBLE PINCH) Maschine in gutem, funktionsfähigem Zustand Biegekapazität: - Blechbreite: 3000 mm - Walzstärke: 40 mm - Vorbiegeleistung: 35 mm Walzendurchmesser und Maße: - Nutzlänge: 3050 mm - Zentrale Ober-/Unterwalze: 470 mm - Seitenwalzen links/rechts: 420 mm Pjdpswb Scmjfx Agxsgk • Gehärtete Oberfläche aller 4 Hochleistungswalzen • 3 angetriebene Walzen mit Getriebe und Hydraulikmotor • Konisches Biegen möglich: Seitenwalzen schwenkbar (Kegelformung), Gegendruckrolle • Hydraulisch öffnender Stirnklappauswurf zum Entladen der fertigen Schale • Variable Walzgeschwindigkeit: hydraulisch schnell/langsam regelbar • Elektrisches Bedienpult auf Rollen mit zentralen Bedienelementen, Joysticks und drei Digitalanzeigen • Digitale Positionsanzeigen für Walzen, hohe Wiederholgenauigkeit beim Biegen und Vorbiegen • Hydrauliktank: 350 Liter – Elektroanschluss: 37 kW / 380 V / 50 Hz • Maschinenabmessungen: 7700 x 2410 x H 2470 mm – Gewicht: 43.000 kg

Leto izdelave: 1976, stanje: dober (rabljeno), Bandwidth: 300 - 1,350 mm Pgjdpfxsbh Ubws Agxjk Strip thickness: 0.35 - 3 mm Coil weight: 12.5 t Mandrel Ø: 508 mm

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2010, Haas Multigrind CB CNC brusilni stroj z več osmi, 12-postajni, krmiljenje Siemens Sinumerik 840D, avtomatsko nalaganje / razlaganje, industrijska filtracijska enota zraka LTA, (leto izdelave 2010) Tehnični podatki: Brusilna vretena (z dvema izhodoma vretena) Vmesnik – stožec ø 31,75 mm Psdpfx Agov Igg Iexegk Moč 100% / 40 % ED – 11,5 / 14,5 kW Standardna hitrost vrtenja – 8.000 vrt/min Opcija: en izhod vretena Vmesnik – HSK 50E Moč – 100% / 40% ED – 11,5 / 14,5 kW Standardna hitrost vrtenja – 8.000 vrt/min Opcija: en izhod vretena Vmesnik – HSK 50E Moč 100% / 40% ED – 11 / 12 kW Standardna hitrost vrtenja – 18.000 vrt/min Opcija: en izhod vretena Vmesnik – HSK 80E Moč 100% / 40% ED – 30/30 kW Standardna hitrost vrtenja – 8.000 vrt/min Opcija: visoko frekvenčno vreteno – na zahtevo Delovna miza Vpenjalna površina – 1000 x 500 mm Število, razmak in širina T-utorov – 9 / 50 / 12H7 mm Delovno območje X-os – 700 mm (opcija) 1000 mm (opcija) 1200 mm Y-os – 410 mm Z-os – 500 mm C-os – kot vrtenja 320° Opcija: X3 – pomožna os delovno območje – 400 mm Merilni sistem in pomik Ločljivost linearnih osi – 0,0005 mm Hitri pomik linearnih osi – 30.000 mm/min Ločljivost rotacijskih osi – 0,001° Hitrost vrtenja C-osi – 400 vrt/min Rotacijska os (A-os) Standardna višina konice – 175 mm Hitrost vrtenja kot vreteno – 2.600 vrt/min Standardni vmesnik – ISO SK 50 / centriranje 70H5 Opcijsko – HSK 100 / 80 / 63 / 50 Izmenjevalec orodij (opcija) HSK50E Število orodij / premer orodij Notranji segment – 5 / 300 mm do 9 / 100 mm Zunanji segment – 7 / 300 mm do 16 / 100 mm HSK80E Število orodij / premer orodij Notranji segment – 5 / 300 mm do 8 / 100 mm Zunanji segment – 7 / 300 mm do 14 / 100 mm Dimenzije obdelovanca Premer – 340 mm Dolžina – 550 mm Dolžina med konicama – 500 mm Električni priklop Obratovalna napetost 400V / 50 Hz, varovano na 80 A Krmilnik Siemens Sinumerik 840 DSL Pnevmatski sistem Delovni tlak – 6 – 10 bar Teža Skupna teža glede na opremo – 10.000 kg ali več Zahteva po tlorisu Dolžina x širina (standard) – 3.227 x 2.700 mm Višina med obratovanjem – 3.550 mm Višina z opcijo hladilnih šob – 3.810 mm (min. višina hale 4.100 mm)

Stanje: rabljeno, Leto izdelave: 1983, Technical Specifications: Press force: 160 t Throat depth: 360 mm Pgjdpfx Agju Nfvusxok Ram stroke (max.): 500 mm Distance table/ram: 800 mm Clamping plate on table: 1250 x 630 x 100 mm Pass-through openings in table: 4 x Ø 62 mm Ram speed forward: 200 mm/s Ram speed return: 125 mm/s Ram surface: 450 x 850 mm Borehole in ram: Ø 49 mm Height above floor: 810 mm Total power requirement: 17 kW Machine weight approx.: 7,200 kg Machine dimensions approx. (LxWxH): 2.1 x 1.4 x 3.4 m Manual counter i.O.

Stanje: rabljeno, Leto izdelave: 1969, Grinding height: 60 mm Psdpfxst Hw N Ho Agxsgk Grinding width: 120 mm Grinding wheel diameter: 600 mm Grinding length: [mm not specified] Workpiece height: 60 mm Total power requirement: 50 kW Machine weight: approx. 7,000 kg Space requirement: [not specified] DISKUS vertical double-sided surface grinding machine in C-frame design with rotary table workpiece feed Model: DDS 600 CRA Year of manufacture: 1969 S/N: 6672 Grinding wheels – diameter x bore each: 600 x 150 mm Grinding wheel height approx.: 60 mm Workpiece transport disc external diameter: 810 mm Workpiece: Max. grinding height x grinding width: approx. 60 x 120 mm Spindle adjustment vertically, each approx.: 150 mm Hydraulic infeed impulses for depth feed: 0.0025 – 0.05 mm Outer diameter of transport disc: approx. 810 mm Rotary table feed rate steplessly adjustable: 14 – 145 mm/s Grinding wheel speed each approx. (24 m/s)/765 rpm Grinding spindle drive each: 22 kW Total drive approx.: 50 kW / 380 V / 50 Hz Machine weight: approx. 7,000 kg Accessories / Special features • Workpiece rotary table device for round transport discs with corresponding cut-outs for inserting components and with automatic discharge of finished parts onto a chute into a transport box. • IONIC measuring control No. 9 So with probe for measuring ground workpiece height and, if required, with automatic hydraulic grinding wheel infeed. • Stepless speed adjustment of the rotary device depending on the grinding dimension and workpiece. • Manual grinding wheel adjustment via corresponding buttons • Hydraulically pivoting dressing unit (RA) between both grinding wheels for simultaneous dressing of both grinding wheels with appropriate compensation and automatic return to the effective workpiece thickness after dressing = high time savings, can be triggered manually as well as via timer • Ampere counters for both grinding spindle drives * Central lubrication system, • Mechanical height check of parts with automatic machine shutdown in case of overheight • Separate control cabinet, separate hydraulic unit, separate large belt filter system, various grinding wheels, various transport discs, etc. This machine is particularly suitable for the simultaneous plane-parallel grinding of workpieces in high-volume production. For example: shims, piston rings, hydraulic components, watch parts, stamped parts, etc. Condition: good – soon ready for demonstration Delivery: ex stock – as inspected Payment: net – upon receipt of invoice

Stanje: rabljeno, Leto izdelave: 2006, Technical details: X travel: 800 mm Y travel: 800 mm Z travel: 800 mm Spindle speed: 12,000 rpm Tool holder: SK 50 Control system: SIEMENS 840D ShopMill Tool changer: 240 positions Pallet size: 630 x 630 mm Spindle: 52 kW / 430 Nm Total power requirement: 87 kVA Machine weight approx.: 15 t Horizontal machining center with pallet storage, NC rotary table, Double pallet changer, High-pressure coolant system 40 bar, Preparation for Renishaw MP 10 infrared probe (without probe), Mechanical tool breakage monitoring, Minimum quantity lubrication (MQL), Through-spindle air blast, Pedpfxspumdce Agxsgk Electronic oil mist extraction, Electronic handwheel, TRANSMIT function, Accuracy package, BA 4, Laminated safety glass pane right side door, Including FASTEMS FPC 1000 pallet system for a total of 14 pallets, including setup station, shelf handling device, master computer, and 10 pallets Approx. 98,500 operating hours, main switch ON Approx. 45,500 spindle hours

Stanje: dober (rabljeno), Leto izdelave: 2000, CNC Surface and Profile Grinding Machine Manufacturer: Ziersch & Baltrusch Model: PROFITLINE ZB 62 NC Pgedpfx Agefrbckjxok Year of manufacture: 2000 Grinding area: 600 x 270 mm Electromagnetic chuck with continuous crosswise pole division Dimensions: 600 x 200 mm, pole pitch = 4 mm Wet grinding system with automatic paper band filter, machine tray included. Complete machine documentation available.

Stanje: rabljeno, Leto izdelave: 2011, Press force approx.: 360 kN Bending length approx.: 1,020 mm Clear column passage approx.: 932 mm Usable installation height approx.: 295 mm Throat depth: 150 mm Working speed: 25 mm/s Approach speed: 220 mm/s Control: TASC 6000 Machine operating hours: 41,422 h Press beam runtime: 4,713 h Length: 1,805 mm Width: 1,330 mm Height: 2,380 mm Machine weight approx.: 2,600 kg Standard Equipment Machine - Sturdy machine frame - Optimized press beam - High-dynamic electromechanical direct drive (torque motor) - Inductive linear measuring system with temperature compensation - Control cabinet climate control Pgjdpfoyrf Dkex Agxsk - Ergonomic machine design Backgauge System - Rear stop system - Stop fingers Control - TRUMPF TASC 6000 integrated - Numeric workshop programming - Windows XPe, Pentium M with 1.1 GHz clock speed - 1 GB RAM memory - 15-inch touch screen - Network capable - Teleservice Safety - Sideward swiveling safety doors - Rear safety hood - 2-button foot pedal for both standing and seated operation Ergonomics - Comfort support table (front) - Comfort footrest - Front workspace lighting (LED) - Swivel-mounted control unit - 1 storage console and 2 document trays Productivity Package - Safety device BendGuard (with block laser) - Graphical workshop programming - Automatic tool clamps Additional Equipment Extended backgauge system - 6-axis rear stop system Automation

Stanje: novo, Bernardo Universal Lathe Titan 660 x 2000 Technical Specifications Centre distance: 2,000 mm Centre height: 330 mm Swing diameter over bed: 660 mm Swing diameter over gap: 900 mm Swing diameter over cross slide: 460 mm Bed width: 400 mm Spindle bore: 105 mm Spindle mount: DIN 55029, D1-8 Speed range (16): 25 – 1,600 rpm Longitudinal feed range (25): 0.044 – 1.48 mm/rev Cross feed range (25): 0.022 – 0.740 mm/rev Metric threads (54): 0.45 – 120 mm Inch threads (54): 7/16 – 80 TPI Quill diameter: 90 mm Quill travel: 235 mm Quill taper: MT 5 Motor power: 7.5 kW (10.0 HP) Machine dimensions (W x D x H): 3,630 x 1,200 x 1,520 mm Weight: approx. 2,900 kg Features Versatile applications in general engineering, production, single-part manufacturing, etc. Central, easy-to-use control for feeds and threads using leadscrew and feed shaft Prism bed made of cast iron, induction-hardened and precision-ground Modern main spindle bearing with precision angular contact roller bearings Hardened and ground gears and shafts, including in the feed gearbox Rapid traverse for longitudinal and cross feeds as standard to reduce idle times Large spindle bore (105 mm) for workpieces with large diameters Smooth start via mechanical multi-disc clutch Electromechanical foot brake for reduced idle times Excellent cutting performance even for facing operations The machine bed is reinforced with sturdy ribs to increase rigidity and minimize vibration influences Pgedpfxefbbx Rj Agxek Scope of delivery 3-axis digital readout ES-12 V with LCD display Slip clutch Rapid traverse longitudinal and cross LED machine light 3-jaw steel chuck PO3-315 mm / D8 Faceplate 450 mm Fixed steady rest – max. dia. 180 mm Travelling steady rest – max. dia. 120 mm 2 centre points Motor with magnetic brake according to CE standards Foot pedal with brake function according to CE Initial fill with Shell Tellus 46 Coolant system Quick-change tool post with 4 holders Protection device for quick-change tool post Change gears Reducing sleeve Chip guard Cable routing via energy chain Operating tools
