Stružnica-konvencionalno-elektronska

SCHAERER A2200

Stanje: novo, Article: Welding Positioner 50 kg Type: KT-50 without chuck Max. load: 50 kg horizontal Max. load: 25 kg vertical Rotational speed: 1–7.5 rpm Rotation direction: left and right Turntable speed: manually adjustable Turntable diameter: 315 mm Turntable height: 375 mm Turntable tilting angle: 0–90° Motor power (operating): 0.08 kW Motor power (standby): N/A Dimensions: 430 x 430 x 375 mm Weight: approx. 38 kg Power supply: AC 110V / 220V 50/60Hz Pedpfx Adebambreysgg Price does not include quick-release chuck and height-adjustable workbench Surcharge for quick-release chuck: €195 Packaging and shipping within Germany: approx. €80

Stanje: rabljeno, Leto izdelave: 1985, Swing diameter over bed: 810 mm Maximum swing diameter over cross slide: 560 mm Distance between centers: 00 mm Bed width: 480 mm Cross slide travel: 400 mm Top slide travel: 180 mm Turning tool shank cross-section: 32 x 25 mm Drive power: 22 kW Spindle torque: 30 Nm Spindle nose size: 11, DIN 55027 Spindle diameter at front bearing: 152.4 mm Spindle bore: 106 mm Speed range: 9 - 1800 rpm Number of speeds: 24 Longitudinal feed: 0.092 - mm/rev Cross feed: 0.046 - mm/rev Metric threads: 0.5 - 112 mm Inch threads: 1/4 - 56 TPI (G/1") Thread module: mm Thread DP: 1 - 224 pitch Tailstock quill diameter: 115 mm Quill stroke: 225 mm Quill taper: MK 6 Workpiece weight between centers, max.: 00 kg Workpiece weight, max. (unsupported): 750 kg Röhm 3-jaw chuck, Ø ... Machine dimensions approx.: 4600 x 1900 x 1600 mm Weight approx.: 4300 kg Number of feed and thread pitches: 99 Pedpfoxn Ty Rsx Adyjgg Distance between centers: 00 mm Accessories: - 3-axis digital readout - Mobile chip guard along the entire length (plexiglass) - Coolant system - Rapid traverse in Z and X axes - Multifix toolholder, size C, with 6 interchangeable cartridges - Bed stop with micrometer adjustment - Fixed steady rest - 300 mm - Taper sleeve for main spindle MK 6 - Live center (cone center) MK 6 Bed guideways in very good condition!

Stanje: rabljeno, Technical Details: Pgodpjwc A Snefx Adysg Grinding length: 12,000 mm Grinding width: 2,800 mm Workpiece height: 2,510 mm Max. workpiece weight: 24,000 kg Table area: 11,990 x 2,500 mm Clearance between columns: 2,820 mm Crossbeam adjustment: 2,510 mm Table feed: 1 - 40 m/min Total power requirement: 110 kW Approx. machine weight: 151 t Approx. space required: 32.5 x 9 x 6.73 m The machine is in very good condition and suitable for grinding with the highest precision! In 2022, mechanical components were refurbished by WALDRICH COBURG for approx. EUR 600,000. Equipped with SIEMENS 840 D CNC control 1 universal grinding support, 22 kW Swiveling grinding spindle +/- 110° Peripheral grinding wheel dimension: Ø 700 x 130 mm Vertical adjustment: 1,000 mm with dressing device 1 peripheral grinding support, 30 kW Grinding wheel dimension: Ø 600 x 150 mm Vertical adjustment: 230 mm with dressing device Coolant and filter unit Various grinding wheel mounts

Stanje: rabljeno, Leto izdelave: 1995, premer struženja nad ležiščem sani: 500 mm, Universal lathe Make: ZMM, Model 500 Year: 1995 Technical Data Manufacturer: ZMM Sliven Model: Universal 500 Year of manufacture: 1995 Centre distance: 1000 mm Swing diameter over bed:500 mm Spindle bore: 73 mm Dimensions (LxWxH): 2.7 x 1.2 x 1.8 m Weight approx.: 3100 kg Equipment • 3-jaw chuck Röhm ZS 350 mm • Quick-change toolpost Pedpowudhuefx Adysgg • Live centre • Coolant pump • Machine lamp All information is without guarantee. A powered demonstration is possible at any time in our showroom.

Stanje: rabljeno, potovalna razdalja osi X: 2.000 mm, pomik osi Y: 1.400 mm, pomik po osi Z: 1.250 mm, premer vretena: 110 mm, HOD OSI X 2000 MM HOD OSI Y (VERTIKALNO) 1400 MM HOD OSI Z (STEBER): 1250 MM HOD OSI W (VRETENO) 710 MM MIZA 1400 X 1600 MM Nosilnost mize: 8000 kg OBRATI VRETENA 10 - 2000 RPM PRITRDITEV VRETENA ISO 50 HITRI POMIK X Y Z 10000 MM/MIN Pgjdpfx Adox Da Sljyog CNC HEIDENHAIN TNC 426 MENJALNIK ORODIJ ZA 60 POZICIJ

Stanje: rabljeno, Leto izdelave: 2011, Premer struženja 460 mm Dolžina struženja 795 mm Pgodpfxoxwzfye Adyog Krmiljenje MORI SEIKI M730 BM Premer premera nad prečnim suportom 590/360 mm Premer prehoda vretena 80 mm Pomiki X/Z: 260/795 mm Delovne ure 19.552 h Čas rezanja 10.704 h Motor vretena 18,5 kW Skupna priključna moč 40 kVA Teža stroja cca 6,4 t Dimenzije cca 3.994 x 3.056 x 2.187 m DMG MORI Dodatna oprema: Vpenjalna glava Ø250 mm. Vpenjalna glava za podvreteno Ø170 mm. Nosilec HAINBUCH Transporter za odrezke Odsesovalna naprava Podajalnik palic Hydrafeed Multiservo mod. MSV Največja dolžina palice 1.600 mm Aksialni nosilec obdelovanca Odlično stanje, ogled možen pod napetostjo.

Stanje: dober (rabljeno), Funkcionalnost: popolnoma funkcionalen, premer struženja: 655 mm, premer struženja nad ležiščem sani: 655 mm, stružna dolžina: 5.000 mm, Premer vrtenja nad ležiščem 655 mm Premer vrtenja nad podporo 390 mm Dolžina struženja 5000 mm Vretenova odprtina 82 mm Hitrost vretena 9-1120 vrt/min Pomik 0,049-3 mm/obr. Skupna priključna moč 12 kW Pgsdpfx Ajw N D T Sedyeg

Leto izdelave: 1981, Stanje: pripravljen za uporabo (rabljen), Working width: 2500 mm, max. sheet thickness: 20 mm, lateral cylinder support device with three adjustable support rollers and conical bending device, machine designed for interchangeable top rolls down to min. Ø 450 mm, machine overhauled in 2009, factory inspection in 2012. Pgedpfxenvfdbj Adyog

Stanje: dober (rabljeno), Funkcionalnost: popolnoma funkcionalen, Leto izdelave: 1989, število valjev: 3, Premer zgornjega valja 280 mm, 12 mm predupogib, zmogljivost 18 mm (3x premer zgornjega valja). Teža 7.100 kg. Pjdpfxowtp Hao Adyegg

Stanje: dober (rabljeno), Leto izdelave: 2017, Sahinler 4R HSS 20-280 Hidravlični 4-valjni stroj za krivljenje pločevine – Leto 2017. Pgsdpfxoxau D Is Adyjg Dolžina upogibanja 2050 mm. Maksimalna zmogljivost upogibanja – mehko jeklo 20 mm. Premer zgornjega valja 280 mm, premer spodnjega valja 280 mm, premer stranskih valjev 220 mm. Hitrost upogibanja 1,5 / 5 m/min. Moč motorja 16 kW.
