Univerzalni rezkalni stroj

Rogi WM6336

Stanje: dober (rabljeno), Leto izdelave: 1956, Težki stružni stroj, stružnica, stružna klop, stružnica z vodilnim in gnanimi vreteni -Proizvajalec: Meuser, stružnica z vodilno in vijačno gredjo tip M3A Rjdpfxoh Uuzys Ad Tobt -Dolžina struženja: 1400 mm -Premer struženja nad posteljo: 550 mm -Premer struženja brez postelje: 800 mm -Premer struženja nad suportom: 300 mm -Premer vretena: Ø 58 mm -Število vrtljajev vretena: 15 - 810 obr/min -Tričeljustna vpenjalna glava: Röhm Ø 250 mm -Čelna plošča: 500 mm -Dodatki: vključno z nosilcem orodij/orodji glej slike -Konus konjička: MK5 -Dimenzije: 2770/1160/V1310 mm

Stanje: novo, Model designation Shark 332-1 CCS Rodpfjgvquwox Ad Tobt

Stanje: novo, Centre distance ----- 1500 mm Centre height ----- 230 mm Swing diameter ----- 460 mm Spindle bore ----- 80 mm Bed width ----- 336 mm Spindle speed ----- 25–1800 rpm Motor ----- 5.5 kW HEAVY-DUTY VERSION – WEIGHT 2650 KG Rbedpfx Adoh U Nzts Tjt INCLUDES * 3-axis digital readout brand SINO * Multifix TOOB2 quick-change tool post with 4 holders * 3-jaw chuck 250 mm * 4-jaw chuck 320 mm * Faceplate 350 mm * Fixed and travelling steady * LED work light and coolant system * Electric brake CE * Box with various tools

Stanje: novo, ELMAG INDUSTRIE 1000/230 HD Universal Gap Bed Lathe with Leadscrew and Feed Shaft 88173 Includes RÖHM chuck Includes 3-axis digital position display Includes quick-change tool post set, Multifix system Ready to operate: includes oil filling, cleaned of preservative (degreased), fully assembled, and tested Heavy-duty gap bed lathes, 5,500 watts: The quality of the INDUSTRIE 230 HD models is apparent from the moment you switch them on: barely audible drive noise. No vibrations even with heavy cutting depths. Indeed, the 230 HD models—at 2,635, 2,835, and 3,055 kg—are the heaviest in their class and, with their extremely robust construction, e.g. induction-hardened bed ways, are perfectly suited for heavy-duty and continuous operation. The 230 HD offers an extra-large spindle bore at 80 mm for working with bar stock up to 2 1/2" (76.1 mm) in diameter. A swing over cross slide of Ø 290 x 1,000, 1,500, or 2,000 mm and a maximum swing diameter of 460 or 700 mm meet virtually all demands in mechanical engineering, steel fabrication, plant construction, and toolmaking. Also features 12 spindle speeds, 170 longitudinal and cross feeds, and 150 leadscrew thread pitches for both metric and imperial threads. Standard equipment: - Digital position display included - RÖHM three-jaw chuck Ø 250 mm - Four-jaw independent chuck Ø 315 mm - Face plate Ø 350 mm - 2 fixed centering points - Live center MT 5 - Travelling steady - Fixed steady - 5-piece quick-change toolpost set, type MB - Thread dial indicator - Halogen machine lamp - Emergency stop button / no-voltage release - Chuck guard with safety interlock - Machine base / chip tray / splash guard - Tool kit / operation manual / CE Optional accessories: - Indexable insert turning tool set 25 x 25 mm, 7-piece - Indexable insert set, 7-piece for 25 x 25 mm turning tool set - 'Camlock' turning tool set 25 x 25 mm, 7-piece - Parting tool holder 25 x 25 mm, length 150 mm - Blade for parting tool holder 25 x 25 mm ADVANTAGES: - CE-compliant machines with highest level of safety and machine accuracy to DIN standards - Powerful and robust – suitable for commercial and industrial use - Integrated coolant tank and pump in machine base TECHNICAL DATA: Distance between centers 1000 mm Center height 230 mm Max swing over bed 460 mm Max swing over cross slide 290 mm Max swing without bridge 700 mm Bed width 340 mm Bridge length 200 mm Travel of cross slide 280 mm Travel of top slide 100 mm Max turning tool section 25x25 mm Chuck mount D1 - 8 Spindle fitting (turning spindle) MT 7 Spindle bore 80 mm Spindle speed range 25 - 1800 rpm Number of speed steps 12 Longitudinal feeds (170) 0.04 - 2.46 mm/rev Cross feeds (170) 0.02 - 1.23 mm/rev Metric thread pitches (24) 0.5 - 20 mm Metric module pitches (20) 0.25 - 10 mm Imperial threads, TPI (61) 1-5/8 - 72 TPI Imperial module threads, TPI (45) 3-1/4 - 96 TPI Lead screw pitch 6 mm Lead screw diameter 40 mm Tailstock taper MT 5 Tailstock diameter 75 mm Tailstock stroke 130 mm Main motor power 5500 W Coolant pump 40 W Power supply 400/50 V/Hz Total length 2310 mm Total height 1255 mm Weight 2635 kg Rodetw Dxkjpfx Ad Tebt

Stanje: dober (rabljeno), Clamping plate with T-slots, plate field, welding table, plate boring mill, T-slot plate. -T-slot plate: Clamping plate with support ribs and double-sided table extension -Clamping surface: total 6000 x 2600 mm -Height: 295 mm Rodpfxondzx Ue Ad Tjbt -Table extension: 300 mm on both sides -Slot width: 30 mm -Slot spacing: 500 mm -Transport dimensions: Extension dismantled on one side, 6000/2300/H590 mm -Weight: 10,000 kg

Stanje: novo, Centre distance ----- 1000 mm Centre height ----- 230 mm Swing diameter ----- 460 mm Spindle bore ----- 80 mm Bed width ----- 336 mm Spindle speed ----- 25-1800 rpm Motor ----- 5.5 kW HEAVY-DUTY MODEL - WEIGHT 2400 KG INCLUDES * 3-axis digital readout by SINO * Multifix type TOOB2 quick-change tool post with 4 tool holders * 3-jaw chuck 250 mm * 4-jaw chuck 320 mm Rbedpfx Asga Tz Uod Tot * Face plate 350 mm * Fixed and travelling steady * LED work lamp and coolant system * Electric brake CE * Toolbox with various tools

Stanje: dober (rabljeno), Vpenjalna plošča s T-utorom in križno mizo, ploščno polje, varilna miza, plošča za vrtalni stroj, T-utorna plošča, izmenjevalnik palet - Količina: na voljo je še ena 2. plošča ID21153 Rjdpfjd Ehflsx Ad Tobt - Širina: 1465 mm - Dolžina: 4930 mm - Delovna višina: 860 mm - Debelina plošče: 35 mm - Višina plošče: 315 mm - Plošča z ojačevalnimi rebri - Širina utora: 51 mm - Razmik utorov: 292 mm - Transportne dimenzije: 4930/1640/V860 mm - Teža: 6155 kg

Stanje: rabljeno, Leto izdelave: 1994, x-travel / mm Rodpfxev T Ntho Ad Tobt y-travel / mm z-travel / mm Total power requirement 2.3 kW including hydraulic vice

Stanje: rabljeno, Leto izdelave: 2015, Technical details: Swing diameter over bed: 420 mm Swing diameter over support: 255 mm Turning length: 1000 mm Swing diameter in gap: 580 mm Centre height: 205 mm Spindle bore: 52 mm Speed range: 30 - 550 / 550 - 3000 rpm (frequency controlled) / 2-step gearbox Feed rate (longitudinal): 0.05 - 1.7 mm/rev Feed rate (cross): 0.025 - 0.85 mm/rev Tailstock quill taper: MT 4 Tailstock quill travel: 120 mm Total power requirement: 5.5 kW Rbedpsvaxi Eefx Ad Tjt Machine weight approx.: 1.5 t Dimensions (LxWxH) approx.: 2.1 x 1.1 x 1.5 m Thread cutting possible, e.g. metric and inch threads Stepless speed control 3-axis position display Sino SPSG-3V 3-jaw chuck NOLEX Ø 200 mm Multifix quick-change tool post size B Chuck guard (monitored) Chip guard Machine lighting Coolant system Accessories: 2x Multifix quick-change tool holders (1x fitted)

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2019, obratovalne ure: 100 h, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: F9B192402, dolžina podajanja os X: 450 mm, dolžina pomika po osi Y: 350 mm, dolžina podajanja os Z: 400 mm, največja hitrost vretena: 5.000 obr/min, hod vretena: 80 mm, hitro pomikanje X-os: 5 m/min, hitri pomik os Y: 5 m/min, hitri pomik na osi Z: 5 m/min, skupna višina: 1.990 mm, skupna širina: 2.030 mm, skupna dolžina: 1.980 mm, širina mize: 270 mm, dolžina mize: 400 mm, vrsta vhodnega toka: trifazni, največja hitrost vrtenja: 5.000 obr/min, vrtljajska hitrost (min.): 10 obr/min, obremenitev mize: 450 kg, skupna masa: 2.270 kg, vhodna napetost: 400 V, teža obdelovanca (maks.): 450 kg, vhodni tok: 16 A, vhodna frekvenca: 50 Hz, Oprema: CE označba, dokumentacija / priročnik, vrtilna hitrost brezstopenjsko nastavljiva, EMCOMAT FB-450 MC with Sinumerik 828D Path Control with “Manual Machine” Universal tool milling and drilling machine equipped with Sinumerik 828D path control and hydraulic tool clamping Working area X450/Y350/Z400mm Drive power 7/10 kW Speed range from 10–5000 rpm Feed rate from 10–5000 mm/min Rapid traverse up to 5000 mm/min Machinist’s precision as per DIN 8615 Tool holder: DIN 69871 SK40 Includes: • Linear guides • Ball screw spindles • Vertical milling head, swivels +/-90°, with 80mm quill travel • Swivel-out device for vertical head • Hydraulic tool clamping • Coolant system • LED machine lamp • Fixed angle table 800x400mm • Work area guard incl. chip tray • Automatic central lubrication • Operating tools • Documentation • Machining with open door (Operating Mode 3) • Controlled and manual operation modes combined in one machine • Sinumerik 828D path control incl. control package for 3 axes with ball screws and servo motors, Rjdpfxsxapdcj Ad Tebt Process cycles with graphical user support: Drilling cycles for drilling, deep drilling, reaming, tapping (with length compensation) on bolt circles and linear hole patterns, rectangular and circular pockets, slot milling cycle, facing cycles, etc., USB interface
