Sredinski stružnica in stružnica za vreteno

OPTIMUM D 360x1000 DPA

Stanje: zelo dobro (rabljeno), Leto izdelave: 2017, Weiler Primus VCD (2017) precizni stružnica Proizvajalec: Weiler Tip: Primus VCD precizni stružnica Leto izdelave: 2017 Stanje: rabljeno, zelo dobro, kot novo, novo vzdrževanje po tovarniških specifikacijah z zapisnikom o prevzemu Obseg dobave: Ksdox Nkdxepfx Aacowu - Dokumentacija

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 1995, x-hod 300 mm y-hod 200 mm z-hod 350 mm Površina stola za stezanje 700 x 270 mm Konus prihvata glavnog vretena ISO 40 Broj obrtaja 8: 150 - 1660 o/min Raspon obrtaja - horizontalno 8: 110 - 1230 o/min Posmici 8: 25 - 285 mm/min Težina 900 kg Hod pinole 60 mm Ukupna potrebna snaga 3,7 kW Dimenzije D-Š-V 1,3 x 1,38 x 1,65 m Univerzalna alatna glodalica sa 2-osnom digitalnom indikacijom i zakretnom vertikalnom glavom sa pinolom, fiksnim i zakretnim stolom, udarnim uređajem sa brojem hodova 43, 59, 84 u minuti, automatskim posmicima i brzim hodovima u sva tri pravca. Mašina je vrlo malo korišćena, iz servisne radionice, tačnost je odlična! Nova cena cca € 24.000. Naša cena je specijalan fiksni iznos! Radi se o polovnom predmetu, prodaja isključuje bilo kakvu garanciju. SKLADIŠNI DILER SA IZLOŽBENOM HALOM OD 1600 m². Kjdpsvxllkefx Aacswu

Stanje: novo, H-TYPE 969 – Stroj s cilindrično roko za ekstremne šivalne aplikacije v različici PURE Durkopp Adler 967-100080 PURE Ksdpfoyay N Dox Aacswu

Stanje: rabljeno, Leto izdelave: 2003, Travel X: 930 mm Travel Y: 400 mm Travel Z: 406 mm Spindle speed: 9–6,750 rpm Table size: 1,370 x 254 mm Quill stroke: 127 mm Quill feed: (3) 0.04; 0.08; 0.15 mm/rev Drilling capacity in steel: 32 mm Feed range: 19–890 (X) mm/min Spindle taper: SK 40 Column overhang: 200–680 mm Total power requirement: 4 kVA Machine weight approx.: 1.15 t Space requirement approx.: 1.5 x 1.45 x 2.2 m Product Information: “Multifunction Milling Machine Optimill MF 4 Vario—Tool Milling Machine with Variable Speed” Optimill MF 4 Vario—multifunctional drilling-milling machines designed for professional applications. Electronically stepless drive control with frequency inverter “made in Germany” and digital 3-axis position display DPA 21. Heavy, robust design made of high-quality Meehanite cast iron. High concentricity accuracy with tapered roller bearings, measured at less than 0.01 mm in the quill. Automatic quill feed. Forward/reverse rotation for thread cutting. X- and Y-axes feature adjustable dovetail guideways. Coolant system. Y-axis with flat guideway. Large Y-axis travel of 400 mm. Motorized table height adjustment with rapid traverse on Z-axis. Equipment details: - Frequency inverter quality made in the EU - Drilling-milling head, tiltable ±45°, overhang 200–680 mm, spindle speeds - Stepless speed control with extra-wide speed range - Adjustable drilling depth stop with millimeter scale, easily readable on front - Safety screen, height-adjustable and generously dimensioned - Cross table: massive, large, precisely surface-machined - Motorized table height adjustment on Z-axis - Adjustable limit stops - OPTI control panel: integrated control console - Integrated digital position display DPA 21 with speed display - X-axis : motorized table feed, stepless speed control, rapid feed, forward/reverse Technical Data: Product length: 1,500 mm Product width/depth: 1,450 mm Product height: 2,200 mm Net weight: 1,150 kg Total power connection: 4 kW Electrical voltage: 400 V Phases: 3~ Network frequency: 50 Hz Max. face mill diameter: 100 mm Max. shank cutter diameter: 20 mm Vertical spindle reach: 200–680 mm Vertical spindle taper: ISO 40 DIN 2080 Vertical spindle speed range: 8 steps Vertical spindle speed control: electronically adjustable Horizontal table length: 1,370 mm Horizontal table width: 254 mm Kedst U Rm Ispfx Aacewu Vertical spindle to table min.: 40 mm Vertical spindle to table max.: 446 mm Horizontal table T-slot size: 16 mm Number of T-slots: 3 T-slot spacing: 63 mm Horizontal table max. load: 275 kg Vertical spindle motor power (normal mode): 3 kW Coolant pump motor power: 100 W Manual X-axis travel: 930 mm Manual Y-axis travel: 400 mm Manual Z-axis travel: 406 mm Automatic X-axis travel: 850 mm Automatic Z-axis travel: 350 mm Drilling capacity steel (S235JR): 32 mm Continuous drilling capacity steel (S235JR): 28 mm Vertical spindle drilling head swivel range Z-X plane: ±45° Vertical spindle quill stroke: 127 mm Vertical spindle quill feed: 0.04/0.08/0.15 mm/rev

Stanje: novo, At variable speed, ISO 40. Powered cross table on all axes. 3-axis digital readout included. Base with chip tray. Coolant system. LED lamp. Mechanical speed indicator. Motorized axes with variable speed and rapid traverse. Manual pump guideway lubrication system. Milling capacity with insert cutter: 100 mm. Milling capacity: 35 mm. Drilling capacity in cast iron with pilot hole: 60 mm. Max drilling capacity in steel with pilot hole (S235JR): 24 mm. Spindle taper: ISO 40 DIN 2080. Quill: 86 mm. Spindle travel: 120 mm. Head tilt: +/- 45°. Vertical head rotation: +/- 90°. Head body rotation: +/- 180°. Vertical spindle speed: (2) 60 ÷ 500 | 500 ÷ 3600 rpm. Motor: 400 V 50 Hz 2.25 kW. Distance between spindle nose and table: 45 – 395 mm. Distance spindle axis – column: 215–450 mm. Table size: 1246 x 230 mm. Longitudinal table travel: 850 mm. Cross table travel: 310 mm. Max load capacity: 400 kg. Dimensions: Kjdpfx Aaoh Im H Socowu 1680 x 1500 x 2100 h mm. Net weight: 1000 kg.

Stanje: dober (rabljeno), Leto izdelave: 1979, Model building milling machine, universal model milling machine, milling machine, universal milling machine, tool milling machine, drilling and milling machine, model making mill Kwsdpfxsnzpx Re Aacou -Manufacturer: Zimmermann, Universal Milling Machine Type FZ 1 with extensive accessories -Rotatable cross table: 490 x 400 mm -Traverse paths: X/Y/Z 320/385/430 mm -Spindle taper: SK30 -Drive power: 1.1 kW -Speeds: 560 to 14,000 rpm, 8 steps -Accessories: included, see photos -Dimensions: 1000/680/H1970 mm -Weight: 477 kg

Stanje: zelo dobro (rabljeno), Knuth UFM 2 univerzalna rezkalna naprava Tehnične specifikacije Potovalna razdalja X-os (ročno) 800 mm Potovalna razdalja X-os 750 mm Potovalna razdalja Y-os 300 mm Potovalna razdalja Z-os 400 mm Velikost mize 1320x320 mm T-utori 5x14x63 mm Podajalne hitrosti Podajalna razdalja Y-os (8) 20 - 360 mm/min Podajalna razdalja Z-os 600 mm/min Hitrost vretena (12) 58 - 1800 min-1 Stožec navpičnega vretena SK 40 Razdalja med konico vretena in mizo 0 - 400 mm Kedpfx Aonfu Rioacswu Zasuk glave 45° Stožec vodoravnega vretena SK 50 Pogon Glavna moč motorja 4 kW Moč motorja na osi Z 0,75 kW Moč napajalnega motorja 0,55 kW Moč motorja hladilne črpalke 0,09 kW Zmogljivost hladilne črpalke 25 l/min Dimenzije in teža Dimenzije 1900x1720x1750 mm Teža 2100 kg Financiranje preko naše banke je prav tako mogoče. komplett-konzept.leasingo.de Druge nove in rabljene artikle najdete v naši spletni trgovini! Mednarodni stroški poštnine na zahtevo!

Stanje: rabljeno, Leto izdelave: 1975, Technical Details: Swing diameter over bed: 400 mm Swing diameter over carriage: 220 mm Turning length: 1100 mm Centre height: 180 mm Spindle bore: Ø 45 mm Speed range: 31.5 - 1,400 rpm / 12 steps Feed range x-axis: longitudinal: 0.08 - 1.10 m/min Feed range y-axis: cross: 0.028 - 0.40 m/min Tailstock quill taper: MT4 Tailstock quill travel: 200 mm Total power requirement: 4.0 kW Machine weight approx.: 1.7 t Kodpou Ix E Hsfx Aacewu Machine dimensions (LxWxH) approx.: 2.5 x 1.1 x 1.4 m Equipment: - Three-jaw chuck Ø 250 mm manufacturer Forkardt with exchangeable jaws - Multifix tool post - Coolant system with pump - Chuck guard - Chip tray - Splash guard Accessories: - Chuck key - Tool holder - 2 gears

Stanje: novo, TC 165 x 750V Image shows MIOTAL® TC 180 x 1000 Centre distance: 750 mm Centre height: 165 mm Swing over bed: Ø 330 mm Bed width: 190 mm Cross slide travel: 160 mm Top slide travel: 90 mm Spindle mount: DIN 55029 (Camlock) D1-4 Spindle bore: Ø 40 mm Max. chuck diameter: Ø 200 mm Spindle speed, stepless: 30 - 2,000 rpm Mechanical gearbox stages: 3 Motor power: 2.2 kW Longitudinal feed Z: (40) 0.044 - 1.96 mm/rev Cross feed X: (40) 0.022 - 0.98 mm/rev Metric threads: (32) 0.4 - 7.0 mm Inch threads: (32) 4 - 56 TPI Module threads: (32) 0.4 - 7.0 Diametral threads: (32) 7.5 - 112 Tailstock quill diameter: Ø 40 mm Tailstock quill taper: MT 3 Quill stroke: 100 mm Lateral offset: ± 10 mm Weight, approx.: 650 kg Features: - Inspection certificate to DIN standards - Precise, hardened and ground guideways - Robust headstock with oil circulation lubrication, precision spindle bearings, gears hardened and ground for long-lasting quality - Electromagnetic spindle brake (TC), frequency inverter with electric braking system (V models) - Torsion-resistant Meehanite cast iron beds, stress-relieved and extensively ribbed for maximum smoothness - Electrical equipment by SIEMENS/SCHNEIDER - Overload protection for feed gearbox - Pulse pushbutton for main spindle - CE / IEC as well as German documentation and German service Standard equipment (included accessories): - Machine stand with splash guard back panel - 3-jaw chuck - 4-way toolpost - Foot pedal with mechanical brake - Coolant system - Chuck guard and spindle guard in compliance with European CE safety standards - 1 fixed centre for main spindle - 1 fixed centre MT3 - 1 test report - Safety guards and electrical equipment according to CE - Reducing sleeve for main spindle operating tool Available options for this lathe: Kwsdpfjir Igwex Aacou - 3-axis digital display - Multifix quick-change toolpost system Also available as a geared head variant.

Stanje: novo, Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, Tischgröße 800 x 240 mm Arbeitsfläche 730 x 210 mm „T“-Nutgröße auf dem Tisch 14 (M12) Drehzahlbereich 75 – 3200 U/min Bohrkapazität im Guss 45 mm Bohrleistung in Stahl 32 mm Längsbewegung (X) 560 mm Querbewegung (Y) 190 mm Vertikaler Verfahrweg (Z) 350 mm Werkzeughalter ISO40/Morze 4 Spindel-Säulen-Abstand 460 mm Abstand zwischen Spindelnase und Tischoberfläche: 445 mm Spindelhub 120 mm Gesamthöhe der Maschine in oberer Z-Position: 1450 mm Die Spindel ist im Bereich von +/-90° verstellbar Antriebsleistung 1,1/1,5 / 400 V Maschinengewicht 480 kg Abmessungen: 1280 x 960 x 2100 mm Kjdpfx Aajxz D Npecowu Zubehör: - Gewindeschneidfunktion - 3-achsiges Anzeigersystem - Y+Z-Achsenabdeckungen - ISO40 Bohrfutteradapter - Eingebauter digitaler Tiefenmesser - Automatischer stufenloser Vorschub und Eilgang auf der X-Achse - Motorisiertes Heben und Senken des Spindelstochs - Halogenlampe - Maschinenfuß aus Guss Die Maschine ist fabrikneu und war nie in Produktion.
