Mali oglas
Avstrija
237 km
Upogibni stroj
HESSE by DURMAAD-Servo 40320
Pokliči
Stanje: novo, Condition: New
Delivery time: approx. 10 weeks from order
Country of origin: Turkey
Price: €159,300
Leasing rate: €3,010.77
Pressing force: 320 t
Bending length: 4,050 mm
Axes: Y1 / Y2 / X and R axis
Stroke: 365 mm
Distance between uprights: 3,600 mm
Throat depth in side frame: 410 mm
Installation height: 630 mm
Drive concept: hydraulic
Rapid traverse Y-axis: 160 mm/s
Working speed Y-axis: 10 mm/s
Return speed Y-axis: 160 mm/s
Backgauge travel X-axis: 650 mm
Backgauge speed X-axis: 500 mm/s
Backgauge travel R-axis: 250 mm
Table height: 900 mm
Table width: 154 mm
Length: 5,300 mm
Width: 1,910 mm
Height: 3,230 mm
Weight: 20,100 kg
ONE SERVOMOTOR AND PUMP PER CYLINDER
4 axes (Y1, Y2, X, and R)
CNC CONTROL SKY 22
- Full HD graphics display 21.5" with 2D and 3D visualization of the programmed workpiece
- Intuitive touch-screen operation (easy contour drawing with your finger)
- Operator-friendly dialog-based programming in either 2D or 3D mode
- 2D and 3D simulation of the bending process
- Automatic tool selection in 3D mode
- Automatic calculation of the blank length for sheet cutting
- Automatic bending sequence calculation
- Graphical product and tool memory
- Correction capabilities
- USB ports and Ethernet connection for import, backup, and program export
- Operating system Windows
- Import support for IGES, STEP, DXF files
Backgauge with servo drive on linear guides and ball screws
Backgauge finger blocks on double linear guides
CNC-controlled crowning
Upper tool 1010/A/75°, split and goosenecked
4-V die block 60x60 2009 (V= 16, 22, 35, and 50 mm)
Laser safety device Fiessler AKAS mounted on upper beam
Sheet support arms on linear guide
Equipment according to CE regulations
Oil filling
Operating manual in GERMAN or ENGLISH
Djdpeynm Atefx Ab Hskn
ADVANTAGES OF THIS DESIGN:
- Hydraulics operate only during ram movement
- Low energy consumption
- Low noise emissions
- High speed
Options:
Z1/Z2 axes
CNC control Delem DA-66 S
CNC control DELEM DA-69S 3D including PC software Profile-S with 3D file import capability
Mali oglas
Avstrija
237 km
Upogibni stroj
HESSE by DURMAAD-ES 2040
Pokliči
Stanje: novo, Condition: New
Delivery time: approx. 12–14 weeks from order
Country of origin: Turkey
Price: €74,800
Lease payment: €1,413.72/month
Pressing force: 40 tons
Bending length: 2,050 mm
Axes: Y1 / Y2 / X and R axes
Stroke: 200 mm
Distance between uprights: 1,700 mm
Throat depth (side frame): 350 mm
Installation height: 440 mm
Drive system: servo motor-driven spindle
Rapid traverse (Y axis): 180 mm/s
Working speed (Y axis): 10 mm/s
Return speed (Y axis): 115 mm/s
Backgauge travel range (X axis): 650 mm
Backgauge travel range (R axis): 250 mm
Table height: 1,000 mm
Motor power: 7.2 kW
Length: 2,600 mm
Dsdpjynm A Hsfx Ab Hskn
Width: 1,450 mm
Height: 2,650 mm
Weight: 4,400 kg
STANDARD EQUIPMENT:
- Servo-driven spindle drive
- 4 axes (Y1, Y2, X, and R)
- Color graphics controller DELEM DA-66S
• 17" color touchscreen
• 3D visualization in simulation and production
• Suitable for full Windows applications
• Compatible with Delem Modusys
• USB and peripheral interface
• User-specific application support
• Sensor, bending, and correction interface
- Servo-driven backgauge on linear guides and recirculating ball screws
- CNC-controlled crowning
- Upper tool 1010/A/75°, segmented and gooseneck
- 4-way die block 60x60 2009 (V=16, 22, 35, and 50 mm)
- Laser safety device Fiessler AKAS mounted on upper beam
- Sheet support arms on linear guides
- Equipment according to CE regulations
- Operating instructions in GERMAN or ENGLISH
ADVANTAGES OF THIS DESIGN:
- Higher productivity than conventional hydraulic press brakes due to virtually delay-free response to foot pedal signal
- Low energy consumption
- Compact spindle drive unit with a low number of individual components
- No hydraulic components
Options:
- Z1/Z2 axes
- CNC controller DELEM DA-69S 3D incl. PC software Profile-S with 3D file import capability
- Quick clamping lever for upper tool
Mali oglas
Avstrija
237 km
Upogibni stroj
HESSE by DURMAAD-Servo 40600
Pokliči
Stanje: novo, Condition: new
Delivery time: approx. 14 – 16 weeks from order
Country of origin: Turkey
Price: €252,800
Press force: 600 tons
Bending length: 4,050 mm
Axes: Y1 / Y2 / X and R axis
Stroke: 365 mm
Distance between uprights: 3,100 mm
Frame gap clearance: 410 mm
Installation height: 700 mm
Drive concept: hydraulic
Rapid traverse Y-axis: 160 mm/s
Working speed Y-axis: 10 mm/s
Return speed Y-axis: 160 mm/s
Backgauge travel X-axis: 650 mm
Backgauge speed X-axis: 500 mm/s
Backgauge travel R-axis: 250 mm
Table height: 900 mm
Table width: 154 mm
Oil tank: 280 l
Length: 5,750 mm
Width: 2,500 mm
Height: 4,000 mm
Weight: 40,500 kg
ONE SERVO MOTOR AND PUMP PER CYLINDER
4 Axes (Y1, Y2, X and R)
CNC CONTROL SKY 22
- Full HD graphics display 21.5" with 2D and 3D visualization of the programmed workpiece
- Intuitive touch-screen operation (easy drawing of bend contours using your finger)
- User-friendly dialog programming, selectable in 2D or 3D mode
- 2D and 3D bending process simulation
- Automatic tool selection in 3D mode
- Automatic calculation of flat length for sheet metal cutting
- Automatic calculation of bending sequence
- Graphical product and tool storage
- Correction capability
- USB ports and Ethernet connection for import, backup, and program export
- Windows operating system
- Import support for IGES, STEP, DXF files
Servo-motor driven backgauge on linear guides and ball screws
Dkedeynmxnjpfx Ab Hon
Backgauge finger blocks on double linear guides
CNC-controlled crowning
Upper tool 1010/A/75°, segmented and offset
4-V die block 60x60 2009 (V= 16, 22, 35, and 50 mm)
Fiessler AKAS laser safety device mounted on upper beam
Sheet support arms on linear guides
Equipment according to CE regulations
Oil filling
Operating manual in GERMAN or ENGLISH
ADVANTAGES OF THIS DESIGN:
- Hydraulics run only during upper beam movement
- Low energy consumption
- Reduced noise emission
- High speed
PRICE FCA TURKEY
Options:
CNC control Delem DA-66 S
CNC control Delem DA-69S 3D including PC software Profile-S with 3D file import capability

Izvedite več zdaj
+44 20 806 810 84
+44 20 806 810 84
Objavite oglas zdaj
*na oglas/mesec
Mali oglas
Avstrija
237 km
Upogibni stroj
HESSE by DURMAAD-Servo 40400
Pokliči
Stanje: novo, Condition: New
Delivery time: approx. 12 - 14 weeks from order
Country of origin: Turkey
Price: €187,100
Leasing rate: €3,536.19
Press force: 400 tons
Bending length: 4050 mm
Axes: Y1 / Y2 / X and R axis
Stroke: 365 mm
Distance between uprights: 3400 mm
Throat depth (side frame): 410 mm
Installation height: 630 mm
Drive concept: hydraulic
Rapid traverse Y-axis: 160 mm/s
Working speed Y-axis: 10 mm/s
Return speed Y-axis: 160 mm/s
Backgauge travel X-axis: 650 mm
Backgauge speed X-axis: 500 mm/s
Backgauge travel R-axis: 250 mm
Table height: 900 mm
Table width: 154 mm
Motor: 2 x 11 kW
Length: 5750 mm
Width: 2110 mm
Height: 3450 mm
Weight: 27,780 kg
ONE SERVO MOTOR AND PUMP PER CYLINDER
4 axes (Y1, Y2, X and R)
CNC CONTROL SKY 22
- Full HD graphic display 21.5" with 2D and 3D visualization of the programmed workpiece
- Intuitive touch-screen operation (easily draw the bending contour by finger)
- User-friendly dialog-based programming, selectable in 2D or 3D mode
- 2D and 3D simulation of the bending process
- Automatic tool selection in 3D mode
- Automatic calculation of developed length for blank cutting
- Automatic bending sequence calculation
- Graphical product and tool storage
Dedpfswir A Aex Ab Hokn
- Correction capability
- USB ports and Ethernet connection for import, backup, and program transfer
- Windows operating system
- Import support for IGES, STEP, DXF files
Servo-driven backgauge on linear guides and ball screws
Backgauge finger blocks on double linear guides
CNC-controlled crowning
Upper tool 1010/A/75°, segmented and gooseneck
4-V die block 60x60 2009 (V= 16, 22, 35, and 50 mm)
Fiessler AKAS laser safety device mounted on the upper beam
Sheet support arms on linear guides
Equipment in accordance with CE regulations
Oil filling
Operating manual in GERMAN or ENGLISH
ADVANTAGES OF THIS DESIGN:
- Hydraulics operate only during upper beam movement
- Low energy consumption
- Low noise level
- High speed
PRICE FCA TURKEY
Options:
- CNC control Delem DA-66 S
- CNC control DELEM DA-69S 3D incl. PC software Profile-S with option to import 3D files
Mali oglas
Avstrija
237 km
Upogibni stroj
HESSE by DURMAAD-Servo 60400
Pokliči
Stanje: novo, Condition: New
Delivery time: approx. 4-6 months from order
Country of origin: Turkey
Price: €231,900
Pressing force: 400 tons
Bending length: 6050 mm
Axes: Y1 / Y2 / X and R axes
Stroke: 365 mm
Distance between uprights: 5100 mm
Dkodpfxswir Ave Ab Hen
Throat depth (side frame): 510 mm
Installation height: 630 mm
Drive concept: hydraulic
Rapid traverse Y-axis: 150 mm/s
Working speed Y-axis: 9 mm/s
Return speed Y-axis: 150 mm/s
Backgauge travel X-axis: 750 mm
Oil tank: 160 l
Length: 7500 mm
Width: 2110 mm
Height: 3810 mm
Weight: 34,600 kg
ONE SERVOMOTOR AND PUMP PER CYLINDER
4 axes (Y1, Y2, X and R)
CNC CONTROL SKY 22
- Full HD graphic display 21.5" with 2D and 3D representation of the programmed workpiece
- Intuitive touch-screen operation (simple drawing of the bending contour with your finger)
- User-friendly programming via dialog, selectable in 2D or 3D mode
- 2D and 3D simulation of the bending process
- Automatic tool selection in 3D mode
- Automatic calculation of flat length for sheet blank
- Automatic bending sequence calculation
- Graphical product and tool memory
- Correction options
- USB ports and Ethernet connection for import, backup, and program outsourcing
- Operating system: Windows
- Import support for IGES, STEP, DXF files
Servo motor-driven backgauge on linear guides and ball screws
Backgauge finger blocks on double linear guides
CNC-controlled crowning
Upper tool 1010/A/75°, segmented and goosenecked
4-way die block 60x60 2009 (V= 16, 22, 35 and 50 mm)
Laser safety device Fiessler AKAS mounted on upper beam
Sheet support arms on linear guides
Equipment according to CE regulations
Oil filling
Operating instructions in GERMAN or ENGLISH
ADVANTAGES OF THIS DESIGN:
- The hydraulics operate only during upper beam movement
- Low energy consumption
- Low noise level
- High speed
PRICE FCA TURKEY
Options:
- CNC control Delem DA-66 S
- CNC control DELEM DA-69S 3D incl. PC software Profile-S with 3D file import capability
Mali oglas
Avstrija
237 km
Upogibni stroj
HESSE by DURMAAD-Servo 30135
Pokliči
Stanje: novo, Condition: New
Delivery time: approx. 12 - 14 weeks after order
Country of origin: Turkey
Price: €98,300
Dedpewirr Refx Ab Hjkn
Leasing rate: €1,857.87
Pressing force: 135 t
Bending length: 3,050 mm
Axes: Y1 / Y2 / X and R axis
Stroke: 265 mm
Distance between uprights: 2,600 mm
Throat depth: 410 mm
Installation height: 530 mm
Drive system: hydraulic
Rapid traverse Y-axis: 200 mm/s
Working speed Y-axis: 10 mm/s
Return speed Y-axis: 200 mm/s
Backgauge travel X-axis: 650 mm
Backgauge speed X-axis: 500 mm/s
Backgauge travel R-axis: 250 mm
Table height: 900 mm
Table width: 104 mm
Length: 4,200 mm
Width: 1,680 mm
Height: 2,750 mm
Weight: 9,500 kg
ONE SERVO MOTOR AND PUMP PER CYLINDER
4 axes (Y1, Y2, X, and R)
CNC CONTROL SKY 22
- Full HD graphical display 21.5" with 2D and 3D visualization of the programmed workpiece
- Intuitive touch screen operation (easy finger drawing of bending contours)
- User-friendly dialog-based programming in either 2D or 3D mode
- 2D and 3D simulation of bending sequence
- Automatic tool selection in 3D mode
- Automatic calculation of flat length for sheet metal blank
- Automatic calculation of bending sequence
- Graphical product and tool memory
- Correction capability
- USB ports and Ethernet interface for import, backup, and program outsourcing
- Operating system: Windows
- Import support for IGES, STEP, DXF files
Servo-driven backgauge on linear guides and ball screws
Backgauge finger blocks on double linear guides
CNC-controlled crowning
Top tool 1010/A/75°, segmented and offset
4-V die block 60x60 2009 (V = 16, 22, 35, and 50 mm)
Laser safety device Fiessler AKAS mounted on the upper beam
Sheet supports on linear guides
Compliance with CE regulations
Oil filling
Operating instructions in GERMAN or ENGLISH
ADVANTAGES OF THIS DESIGN:
- Hydraulics operate only during upper beam movement
- Low energy consumption
- Low noise emissions
- High speed
Options:
Z1/Z2 axes
CNC controller Delem DA-66 S
CNC controller Delem DA-69S 3D incl. PC software Profile-S with 3D file import
Quick-clamping lever for the top tool
Mali oglas
Avstrija
237 km
Upogibni stroj
HESSE by DURMAAD-S 2060
Pokliči
Stanje: novo, Condition: New
Delivery time: approx. 10 weeks from order
Country of origin: Turkey
Price: €57,920
Leasing rate: €1,094.69
Pressing force: 60 t
Bending length: 2050 mm
Axes: 3 (Y1, Y2, X)
Stroke: 265 mm
Distance between uprights: 1700 mm
Throat depth: 450 mm
Installation height: 530 mm
Drive concept: hydraulic
Rapid approach speed Y-axis: 200 mm/s
Working speed Y-axis: 10 mm/s
Return speed Y-axis: 110 mm/s
Backgauge travel X-axis: 650 mm
Backgauge speed X-axis: 500 mm/s
Backgauge speed R-axis: 350 mm/s
Backgauge travel R-axis: 250 mm
Table height: 900 mm
Table width: 104 mm
Oil tank: 100 l
Motor: 7.5 kW
Length: 3200 mm
Width: 1550 mm
Height: 2850 mm
Weight: 5600 kg
Backgauge: 650 mm
3 axes (Y1, Y2, X)
CNC CONTROL DT-15
Dsdowirivepfx Ab Hokn
- 2D graphic display, 15"
- Intuitive touch-screen operation (simple drawing of bending contour with finger)
- User-friendly dialog programming
- Automatic calculation of bending sequences
- Automatic calculation of blank length for sheet cutting
- Graphical product and tool memory
- Correction options
- USB ports for backup and program transfer
- PC software so that programs can be created on a PC and then transferred to the machine via USB
Servo-driven backgauge on linear guides and ball screws
Backgauge finger blocks on double linear guides
CNC-controlled crowning
Upper tool 1010/A/75°, segmented and offset
4-V die block 60x60 2009 (V = 16, 22, 35 and 50 mm)
Laser safety device Fiessler AKAS mounted on upper beam
Sheet supports on linear guides
Equipment according to CE regulations
Oil filling included
Operating instructions in GERMAN or ENGLISH
ADVANTAGES OF THE AD-S SERIES:
- Increased stroke, installation height, and throat depth
- Higher approach and return speed of upper beam
- Higher backgauge speed
- Backgauge fingers on double instead of single linear guides
- More options available, e.g.: additional backgauge axes (e.g. Z1/Z2, Delta X, up to 6 axes), bending aids, laser angle measurement system, tandem version, other CNC controls …
OPTIONS:
R-Axis
R/Z1/Z2 axes
DBend, 3D CAD/CAM import and simulation software (step, iges, and dxf file import)
CNC control SKY22
CNC control Delem DA66 S
CNC control DELEM DA-69S 3D incl. PC software Profile-S with 3D file import capability
Quick-release clamps for the upper tool
Mali oglas
Avstrija
237 km
Upogibni stroj
HESSE by DURMAAD-Servo 60320
Pokliči
Stanje: novo, Condition new
Delivery time approx. 14-16 weeks from order
Country of origin Turkey
Price €202,100
Lease rate €3,869.08
Pressing force 320 t
Bending length 6050 mm
Axes Y1 / Y2 / X and R axis
Stroke 365 mm
Distance between uprights 5100 mm
Throat depth (side frame) 450 mm
Djdpfxswirgne Ab Hekn
Installation height 630 mm
Drive concept hydraulic
Rapid traverse Y-axis 160 mm/s
Working speed Y-axis 10 mm/s
Return speed Y-axis 160 mm/s
Backgauge travel X-axis 650 mm
Backgauge speed X-axis 500 mm/s
Backgauge stroke R-axis 250 mm
Table height 1100 mm
Table width 154 mm
Oil tank 160 l
Length 7500 mm
Width 1910 mm
Height 3350 mm
Weight 29000 kg
ONE SERVOMOTOR AND PUMP PER CYLINDER
4 axes (Y1, Y2, X, and R)
CNC CONTROL SKY 22
- Full HD graphics display 21.5" with 2D and 3D representation of programmed workpiece
- Intuitive touch-screen operation (easy contour drawing by finger)
- User-friendly programming via dialog, selectable in 2D or 3D mode
- 2D and 3D simulation of the bending sequence
- Automatic tool selection in 3D mode
- Automatic calculation of flat length for sheet metal blanks
- Automatic bending sequence calculation
- Graphical product and tool memory
- Correction options
- USB ports and Ethernet for import, backup and program outsourcing
- Windows operating system
- Import support for IGES, STEP, DXF files
Servo-driven backgauge on linear guides and ball screws
Backgauge finger blocks on double linear guides
CNC-controlled crowning
Upper tool 1010/A/75°, segmented and offset
4-V die set 60x60 2009 (V = 16, 22, 35 and 50 mm)
Fiessler AKAS laser safety device mounted on upper beam
Sheet support arms on linear guide
Equipment in compliance with CE regulations
Oil filling
Operating manual in GERMAN or ENGLISH
ADVANTAGES OF THIS DESIGN:
- Hydraulics only operate during ram movement
- Low energy consumption
- Low noise emissions
- High speed
PRICE FCA TURKEY
Options:
CNC control Delem DA-66 S
CNC control DELEM DA-69S 3D incl. PC software Profile-S with 3D file import capability
Mali oglas
Avstrija
237 km
Upogibni stroj
HESSE by DURMAAD-S 40320
Pokliči
Stanje: novo, Condition: new
Delivery time: approx. 10 weeks from order date
Country of origin: Turkey
Price: €123,713
Leasing rate: €2,338.18
Pressing force: 320 t
Bending length: 4,050 mm
Axes: Y1 / Y2 / X Axis
Stroke: 365 mm
Distance between uprights: 3,600 mm
Throat depth (side stand): 450 mm
Installation height: 630 mm
Drive system: hydraulic
Rapid traverse Y axis: 160 mm/s
Working speed Y axis: 10 mm/s
Return speed Y axis: 140 mm/s
Backgauge speed X axis: 500 mm/s
Backgauge speed R axis: 350 mm/s
Backgauge travel R axis: 250 mm
Table height: 900 mm
Table width: 154 mm
Oil tank: 250 l
Motor power: 18.5 kW
Length: 5,250 mm
Width: 1,770 mm
Height: 2,850 mm
Weight: 20,000 kg
Standard equipment:
- 3 axes (Y1, Y2, X)
- CNC control DT-15
- 15" 2D graphic display
- Intuitive touchscreen operation (simple drawing of bending contour with finger)
- User-friendly dialog programming
- Automatic bend sequence calculation
- Automatic calculation of flat length for sheet metal blank
- Graphic product and tool memory
- Correction function
- USB connections for backup and program transfer
- PC software for program creation on PC and transfer to machine via USB
Dsdewirfqepfx Ab Hskn
- Servo-driven backgauge on linear guides and ball screws
- Backgauge finger blocks on double linear guides
- CNC-controlled crowning
- Upper tool 1010/A/75°, segmented and offset
- 4-V die block 60x60 2009 (V = 16, 22, 35 and 50 mm)
- Fiessler AKAS laser safety device mounted on upper beam
- Sheet support arms on linear guides
- Equipment according to CE standards
- Oil filling
- Operating manual in GERMAN or ENGLISH
Advantages of the AD-S series:
- Increased stroke, installation height, and throat depth
- Higher approach and return speed of the upper beam
- Higher backgauge speed
- Backgauge fingers on double instead of single linear guides
- More options available, e.g.: additional backgauge axes (e.g. Z1/Z2, Delta X, up to 6 axes), bending aids, laser angle measuring system, tandem configuration, alternative CNC controls, etc.
Options:
- R axis
- R/Z1/Z2 axes
- DBend, 3D CAD/CAM import and simulation software (step, iges, and dxf file import)
- CNC control SKY22
- CNC control Delem DA66 S
- CNC control DELEM DA-69S 3D incl. PC software Profile-S with 3D file import capability
Mali oglas
Avstrija
237 km
Upogibni stroj
HESSE by DURMAAD-S 60220
Pokliči
Stanje: novo, Condition: New
Delivery time: approx. 14 - 16 weeks from order
Country of origin: Turkey
Price: €137,900
Leasing rate: €2,606.31
Press force: 220 t
Bending length: 6050 mm
Axes: Y1 / Y2 / X axis
Stroke: 265 mm
Distance between uprights: 5100 mm
Throat depth: 450 mm
Installation height: 530 mm
Drive system: hydraulic
Rapid traverse Y-axis: 160 mm/s
Working speed Y-axis: 10 mm/s
Return speed Y-axis: 140 mm/s
Backgauge speed X-axis: 500 mm/s
Backgauge speed R-axis: 350 mm/s
Backgauge travel range R-axis: 250 mm
Table height: 1050 mm
Table width: 154 mm
Oil tank: 250 l
Motor: 22 kW
Length: 7500 mm
Width: 1770 mm
Height: 3350 mm
Weight: 20,800 kg
3 axes (Y1, Y2, X)
CNC control: DT-15
- 15" 2D graphic display
- Intuitive touch-screen operation (easily draw bending contours with your finger)
- Operator-friendly dialog programming
- Automatic bending sequence calculation
- Automatic calculation of blank length for sheet metal cutting
- Graphical product and tool storage
- Correction functionality
- USB ports for backup and program export
- PC software allows programs to be written on PC and then transferred to the machine via USB
Servo-driven backgauge on linear guides and ball screws
Backgauge fingers on double linear guides
CNC-controlled crowning
Upper tool 1010/A/75°, sectioned and offset
4-V die block 60x60 2009 (V= 16, 22, 35, and 50 mm)
Laser safety device Fiessler AKAS mounted on upper beam
Sheet support arms on linear guides
Equipment in accordance with CE regulations
Oil filled
Operating manual in GERMAN or ENGLISH
ADVANTAGES OF THE AD-S:
- Increased stroke, installation height, and throat depth
- Higher approach and return speeds of upper beam
- Higher backgauge speed
- Backgauge fingers on double rather than single linear guides
- More options available, e.g., additional backgauge axes (e.g. Z1/Z2, Delta X, up to 6 axes), bending aids, laser angle measurement system, tandem configuration, alternative CNC controls, etc.
PRICE FCA TURKEY
Options:
R-axis
R/Z1/Z2-axes
DBend, 3D CAD/CAM import and simulation software (step, iges, and dxf file import)
CNC control SKY22
CNC control Delem DA66 S
DA-69S 3D incl. PC software Profile-S with 3D file import capability
Dkodpfowiq R Sox Ab Hon
Quick-clamping lever for upper tool
Mali oglas
Avstrija
237 km
Upogibni stroj
HESSE by DURMAAD-S 30220
Pokliči
Stanje: novo, Condition: new
Delivery time: approx. 10 weeks from order
Country of origin: Turkey
Price: €88,113
Leasing rate: €1,665.34
Pressing force: 220 t
Bending length: 3,050 mm
Dkedpfxowiqude Ab Hen
Axes: Y1 / Y2 / X axis
Stroke: 265 mm
Distance between uprights: 2,600 mm
Throat depth: 450 mm (side frame)
Installation height: 530 mm
Drive system: hydraulic
Rapid traverse Y-axis: 140 mm/s
Working speed Y-axis: 10 mm/s
Return speed Y-axis: 140 mm/s
Backgauge speed X-axis: 500 mm/s
Backgauge speed R-axis: 350 mm/s
Backgauge travel R-axis: 250 mm
Table height: 900 mm
Table width: 104 mm
Oil tank: 250 l
Motor power: 22 kW
Length: 4,250 mm
Width: 1,770 mm
Height: 3,000 mm
Weight: 12,600 kg
Standard equipment:
– 3 axes (Y1, Y2, X)
– CNC control DT-15
- 2D graphic display 15”
- Intuitive touch-screen operation (easy drawing of bending contour with finger)
- User-friendly dialog-based programming
- Automatic bending sequence calculation
- Automatic calculation of developed length for sheet cutting
- Graphic product and tool memory
- Correction options
- USB ports for backup and program transfer
- PC software allowing programs to be written on PC and then transferred to the machine via USB
– Servo-driven backgauge on linear guides and ballscrews
– Backgauge finger blocks on double linear guides
– CNC-controlled crowning
– Upper tool 1010/A/75°, segmented and offset
– 4-V die block 60x60 2009 (V = 16, 22, 35, and 50 mm)
– Laser safety device Fiessler AKAS mounted on upper beam
– Sheet support arms on linear guides
– Equipment according to CE directives
– Oil filling
– Operating manual in GERMAN or ENGLISH
ADVANTAGES OF THE AD-S SERIES:
– Greater stroke, installation height, and throat depth
– Higher approach and return speeds of the upper beam
– Increased backgauge speed
– Backgauge fingers mounted on double, not single, linear guides
– More available options, e.g., additional backgauge axes (such as Z1/Z2, Delta X, up to 6 axes), bending aids, laser angle measurement system, tandem configuration, alternative CNC controls, etc.
OPTIONS:
– R-axis
– R/Z1/Z2 axes
– CNC control Delem DA66 S
– CNC control DELEM DA-69S 3D incl. PC software Profile-S with import function for 3D files
– Hydraulic or pneumatic tool clamping for Euro or Wila tooling
Mali oglas
Freilassing
244 km
Rezkalni stroj
DECKEL MAHODMU 50 T
Pokliči
Stanje: dober (rabljeno), Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 500 mm, pomik osi Y: 400 mm, pomik po osi Z: 400 mm, hitrost pomika os X: 10 m/min, hitrost podajanja osi Y: 10 m/min, hitrost podajanja os Z: 10 m/min, največja hitrost vretena: 9.000 obr/min, hitrost vretena (min.): 20 obr/min, hitro pomikanje X-os: 12 m/min, hitri pomik os Y: 12 m/min, hitri pomik na osi Z: 12 m/min, širina mize: 500 mm, dolžina mize: 700 mm, največja hitrost vrtenja: 9.000 obr/min, vrtljajska hitrost (min.): 20 obr/min, obremenitev mize: 200 kg, skupna masa: 3.500 kg, teža obdelovanca (maks.): 6 kg, potrebna širina: 2.300 mm, zahteva za prostor dolžina: 2.300 mm, potrebna višina: 2.000 mm, Naprodaj:
Deckel MAHO DMU 50 T.
Leto izdelave: 2001.
Stroj je opremljen s priljubljenim in zmogljivim Heidenhain MillPlus / 3D krmiljenjem,
vzdrževan v delavnici in takoj pripravljen za uporabo.
Osnovni 3-osni stroj z ročno vrtljivo mizo (3+2 osi).
Na voljo od 21. tedna.
Možnost ogleda pod napetostjo na lokaciji blizu Salzburga v Avstriji.
Dsdpfx Ajy Raf Ueb Hekn
Stanje: Zelo dobro (nizko število delovnih ur za starost)
Vključno z dodatno opremo.
Teža stroja: 3.500 kg
Mali oglas
Prevalje
44 km
Namizni vrtalni stroj
TOSWRD 150Q
Pokliči
Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2008, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 6.000 mm, pomik osi Y: 4.000 mm, premer vretena: 150 mm, Machine under power. Including documentation.
Including dismalting and loading on the trucks or containers.
Dksdpfx Abey U T A Ij Hsn
Mali oglas
Fumane (Verona)
326 km
Rabljeni stroj za pranje steklenic Aesse Service LINE6, letnik 2018
A Esse ServiceLINE6
Pokliči
Stanje: rabljeno, Leto izdelave: 2018, številka stroja/vozila: SCIAC44, Used Bottle Washer Aesse Service LINE6, year of manufacture 2018
This machine offers a reliable and robust solution for industrial bottling plants. Aesse Service manufactured this model in 2018 to ensure high performance with optimal energy efficiency while maintaining the quality of the washing processes. Although the machine has already been in use, it was only operated very sparingly, which has preserved its excellent condition. It is currently in storage; the LINE6 is designed for standard 0.75 L glass containers and operates at a capacity of 900 bottles per hour (BPH).
Dodpfxjvhcpls Ab Hokn
Technical specifications of the Aesse Service bottle washer
The used Aesse Service LINE6 bottle washer, year 2018, delivers consistent output with an energy consumption of 2 kW. Additionally, the machine is powered via high voltage (HV) 400 V AC ±10 % with neutral and earth conductors, while a low voltage (LV) of 24 V DC ±10 % supplies the control circuits. The machine thus supports a frequency range of 50 to 60 Hz, making it versatile for use across different industrial standards.
Pneumatic system
The machine requires compressed air supply of 6 bar and consumes 500 liters per minute to operate effectively. This consistent air stream enables precise washing cycles, which is crucial for bottling lines, as the regularity of the air supply directly impacts product quality. Moreover, the stable air flow ensures long-term reliable performance.
Dimensions and weight
Thanks to its compact design, the used Aesse Service LINE6 bottle washer, manufactured in 2018, can be easily integrated even in tight workspaces. For this reason, the machine measures 1300 x 1300 x 1600 mm (L x W x H) and has a dry weight—that is, without fluids or filled lines—of between 300 and 500 kg. The moderate weight simplifies transport and installation, making the LINE6 model practical and versatile for a variety of industrial applications.
Container capacity
The used Aesse Service LINE6 bottle washer, manufactured in 2018, processes bottles with capacities from at least 0.5 liters up to a maximum of 1.5 liters, providing high flexibility in production. This range particularly covers common formats in the beverage industry and meets a wide variety of washing requirements.
Bottle diameter and height
In addition, the machine can accommodate bottles with diameters from 55 mm to 115 mm. This flexibility allows safe retention of various glass containers during the washing process. Bottle heights from 160 mm to 345 mm are also supported. Companies benefit from the ability to handle different formats without frequently changing equipment.
Performance and reliability
The washer offers durable performance thanks to its robust construction and advanced design. Furthermore, its design minimizes routine maintenance effort, which is essential for continuous operation in industrial bottling lines. Since this machine has only been minimally used, this further contributes to its reliability. With a performance of 900 BPH, the model...
Mali oglas
Avstrija
287 km
Stroj za vrtanje in vbijanje vložkov Ganner Index Logic
GannomatIndex Logic 130 Typ 471L130
Pokliči
Stanje: rabljeno, Leto izdelave: 2014, Used machine
Year of manufacture: 2014
Features and technical data:
Complete in standard configuration with:
- Support with linear guide consisting of:
1 pc. single-spindle horizontal drilling unit, 0.65 kW motor, 70 mm stroke
Tool speed selectable via operator software (3000/5000/8000 rpm)
1 pc. blow-off, gluing, and dowel insertion station for dowels Ø 8 mm, dowel length 25-50 mm
- Fully automatic, electronically controlled central lubrication
- X-axis CNC controlled, with working length 1300 mm, max. traverse speed 105 m/min
- Z-axis manually adjustable via mechanical digital counter, position on support table 5-40 mm
- Dowel insertion projection adjustable from 7-20 mm via mechanical digital counter; drilling depth from 0-35 mm (with drill bit length GL 70 mm) is automatically set with insertion projection
- Closed glue system with 6 bar glue pressure via glue nozzle, for glues with viscosity 150 to 350 mPas
- Glue quantity infinitely adjustable via operator software
- Selector switch GLUE/WATER for rinsing the glue system, each with:
1 stainless steel container for 7.5 kg glue and 7.5 l water
- Control lamp for glue level indicator in the glue container
- 1 pc. left side stop, 1 pc. right side stop, and 1 pc. center stop (all removable)
- 4 pcs. start buttons for individual operation with 1-4 workpieces
- 4 pcs. pneumatic inclined clamping cylinders 10° for workpiece thicknesses up to max. 80 mm, workpiece length (Y) min. 70 mm
- 1 pc. extraction hood, connection Ø 80 mm
1 pc. TCT control unit with:
Integrated industrial PC, incl. Beckhoff TWINCAT Soft PLC, operating temperature range 0-50°C,
15" capacitive TFT industrial touchscreen display, operating system: WINDOWS 7
- Programming via menu-guided user software, freely programmable drilling distances with absolute, relative, or grid dimensions, automatic workpiece mirroring and process optimization, 4 work fields assignable with different programs, graphic workpiece display, parametric programming, zero-point shifting, programmable job lists, error diagnosis in plain text
Options:
1 Electronic, optical glue monitoring system G.I.C. (Glue Insert Control) for 1 pc. glue nozzle
1 Z-axis with CNC-controlled, dynamic positioning for height adjustment
of drilling and dowel insertion station (programmable from 5-40 mm)
Traverse speed max. 30 mm/sec.
1 single-spindle vertical drilling unit from above, 0.65 kW,
(3000/5000/8000 rpm), position (Y) manually adjustable via mechanical digital counter from 5-40 mm, max. drilling depth (Z) 30 mm (with drill bit length GL 57 mm)
Workpiece thickness (Z) max. 50 mm, workpiece length (Y) min. 130 mm
(incl. drilling depth compensation, e.g. for Häfele Minifix)
4 vertical inclined clamping cylinders 10° with mount, additionally
1 keyboard with mount
Availability: by arrangement; currently being overhauled at the Ganner factory
Dkodoy Ih Skepfx Ab Hsn
Location: Austria
Mali oglas
Grüsch
415 km
Stroj za oblikovanje zobnikov
LORENZS7 / 1000
Pokliči
Stanje: rabljeno, Leto izdelave: 1977, Premer kolesa - maks. 1000 mm
Širina kolesa 180 mm
Modul - maks. 7
Modul - min. 0,5
Hod bata - min. 16 mm
Hod bata - maks. 180 mm
Izvrtina mize 160 mm
Skupna potrebna moč 4 kW
Dodpfxeyb S H Dj Ab Hokn
Teža stroja pribl. 5,2 t
Mali oglas
Grüsch
415 km
Preizkuševalni stroj za zobnike
KLINGELNBERGPNC 30
Pokliči
Stanje: rabljeno, Leto izdelave: 1991, Premer kolesa - maks. --- mm
Širina kolesa --- mm
Dkjdpfx Asya Eqajb Hon
Modul - maks. ---
Modul - min. ---
Krmilnik ---
Skupna zahtevana moč --- kW
Teža stroja ca. --- t
Potreben prostor ca. --- m
Mali oglas
Kuchl
214 km
Kombiniran stroj
Jolly300 M3
Pokliči
Stanje: dober (rabljeno), Naprodaj je rabljeni Jolly 4-v-1 kombinirani stroj z dolžino reza 900 mm. Stroj je v dobrem stanju, naše strokovno osebje ga je obnovilo in pregledalo.
Tehnični podatki:
- Dolžina reza: 900 mm
- Širina reza: 1900 mm
- Višina reza: 73 mm
- 2 hitrosti rezkanja
- Širina skobljanja: 300 mm
Dedpfxsy U Iqaj Ab Hekn
- Dolžina ravnalne površine: 1430 mm
- Maksimalna višina prehoda: 205 mm
- 3 motori
Stroj se nahaja na naslovu A-5431 Kuchl in si ga lahko ogledate kadar koli med našim delovnim časom. Vmesna prodaja pridržana!
Sorodni izrazi: kombinirani stroj, večnamenski stroj, skobeljni stroj, debelinka, debelinarka, krožna žaga
Referenca: R-Y00ZA
Mali oglas
Spatenhof
94 km
Stroj za oblaganje robov
HOLZ-HERUNO 1303 + PU
Pokliči
Stanje: rabljeno, Holz Her UNO 1303 + PU
Debelina robnega traku 0,4 - 3 mm (6 mm)
Upravljalna plošča s preklopnimi stikali za nastavitev agregatov
Samodejni robni magazin za rolo in trak
Postaja za nanašanje lepila: patroni + PU lepljenje
Obdelovalna višina 6-55 mm
Pnevmatski pritiskalni agregat
Kapp agregat za rolo in trak do 3 mm (6 mm) debeline
Z možnostjo nastavitve kota kappa žag od 0-10°
Rezkalni agregat, rezkanje v ravnino, radij rezkanje, posnetje - 15°
Vlečno rezkalo za posnetje in radije
Končni vlečni rezkalni agregat
Stroj je PREVERJEN in v ODLIČNEM STANJU iz zelo vzdrževane obrtne delavnice
Stroj je priključen v razstavnem centru in pripravljen za predstavitev
Na zalogi v Liebochu
Dedpfjy Tuylex Ab Hokn
Mali oglas
Spatenhof
94 km
širokopasovni brusilni stroj
KündigEnorm Primo TOP
Pokliči
Stanje: rabljeno, Kündig ENORM PRIMO – TOP
Dkedpfx Aey Tutrob Hjn
STROJ S KONSTANTNO MIZO / avtomatska nastavitev glave
Avtomatski stroj za kalibracijo in fino brušenje z širokim trakom
Kombinirana enota kontaktni valj in pnevmatična brusilna blazina
Enormatic
Digitalni prikaz debeline za debelino obdelovanca
Moč motorja pogona traku približno 9 kW
Višina kontaktnega valja brezstopenjsko nastavljiva glede na zrnatost
Vhodna in izhodna miza z valjčnimi nosilci
Delovna širina 1100 mm
Hitrost podajanja 2,5 - 15 m/min
Stroj bo DELAVNIŠKO OBNOVLJEN
Na zalogi Lieboch
Mali oglas
Gussago
380 km
ORT LE60 - MS stroj za lappanje
ORTLE60 - ms lapping
Pokliči
Stanje: rabljeno, ORT LE60 valjčna polirno-lapirna stroj (valjanje). Stroj je na naši zalogi, priključen na elektriko. Možnost preizkusnega zagona. Nudimo lahko "know-how". Mimu Werkzeugmaschinen.
Dksdezbx Dcjpfx Ab Hjn
Znak zaupanja
Prodajalci, certificirani pri Machineseeker

Mali oglas
Kamnik
31 km
Stroj za oblaganje robov
SCM StefaniSolution HD R4
Pokliči
Stanje: zelo dobro (rabljeno), Leto izdelave: 2011, številka stroja/vozila: AH/005553, Funkcionalnost: popolnoma funkcionalen, SCM Stefani Solution HD Edgebander
Heavy-duty industrial edgebanding machine for high-capacity production.
Main Specifications:
• Panel thickness: max 60 mm
• Edge thickness: 0.4 - 3 mm (Solid wood up to [12] mm)
• Feed speed: up to 25 m/min
• Glue system: [EVA / PUR]
• Working Units (Configuration):
• Pre-milling unit
• Gluing unit with pressure rollers
• End-trimming unit
• Top/Bottom trimming unit (rough & fine)
• Corner rounding unit
• Radius edge scraper
• Glue scraper
• Buffing unit
Machine Condition:
Dsdpfey Uxxhsx Ab Hekn
• Excellent working condition.
• Regularly maintained.
• Available for inspection and testing under power.
Mali oglas
Frasdorf
276 km
Polirni stroj
Maschinenfabrik Spandau
Pokliči
Stanje: rabljeno, Funkcionalnost: popolnoma funkcionalen, Polirni stoj
Dkedpfx Aozccxajb Hsn
Premer polirnega koluta 300 mm
Širina 40 mm
Mali oglas
Zona Industriale Greithwald
273 km
Stroj za izdelavo upognjenih komponent
WafiosBMZ 42
Pokliči
Stanje: rabljeno, Leto izdelave: 2009, obratovalne ure: 67.500 h, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 2.7681.023, Prodaje se CNC stroj za savijanje cijevi WAFIOS BMZ 42, godina proizvodnje 2009. Na prodaju je numerički upravljani stroj za savijanje cijevi renomiranog proizvođača WAFIOS, model BMZ 42. Stroj je korišten u proizvodnji i pogodan je za preciznu serijsku izradu savijenih dijelova od žice i cijevi. Tehnički podaci: proizvođač WAFIOS, tip BMZ 42, godina proizvodnje 2009, serijski broj 2.7681.023, radnih sati cca 67500 h, lokacija Sjeverna Italija, pokrajina Bolzano. Stroj ima robusnu konstrukciju i trenutno je još uvijek u funkciji i koristi se za kompleksne aplikacije savijanja cijevi u automobilskoj industriji. Postrojenje se prodaje kompletno sa zaštitnim oklopom. Stanje rabljeno, stroj u proizvodnji, dodatne informacije o stanju i priboru na zahtjev. Isporuka stroja u viđenom stanju uključuje dostupnu dokumentaciju. Pregled moguć po dogovoru, utovar osiguran. U slučaju interesa kontaktirati. Cijena po dogovoru.
Dkodpszb U Tgsfx Ab Hon
Mali oglas
Oberham
252 km
Laserski varilni stroj
CraftweldCraft-Laser 1500 S
Pokliči
Stanje: kot nova (razstavni stroj), Leto izdelave: 2024, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: A32404019520, vrsta vhodnega toka: trifazni, vhodna napetost: 230 V, skupna masa: 53 kg, vrsta hlajenja: zrak, laserska moč: 1.500 W, dolžina gredi: 1.080 mm, neprekinjena moč: 1.500 kW (2.039,43 KM), Oprema: Na voljo je tipska ploščica, dokumentacija / priročnik, zaščita za glavo, Operation
- Simplest operation thanks to synergy characteristic curves
- Achieve a finished weld in just three steps. Automatic adjustment of power, wire feed, oscillation width, oscillation frequency, laser frequency, PWM, hot start, etc.
- High-resolution display ensures optimum readability of all relevant parameters. Integrated help function provides greater understanding of the adjustment options
- Fully integrated control in the wire feeder case – operation via the machine or the wire feeder as desired
Technical Features
- High-performance laser cells combined with gas-cooled torches ensure maximum power and focus stability
- 2-in-1 machine: Welding and cleaning – laser cleaning is perfect for paint removal, derusting, and descaling
- Optional: Dual wire feed
Safety
- Dual-channel emergency stop system
- Dual-channel safety interface for access monitoring (door contact switch)
- Key switch to prevent unauthorized use
- Dual-channel fiber break detection and monitored QBH connection
- Safety instructions as well as manual laser release activation required at every start
- Dual-pressure button prevents unintentional laser activation
- Suitable for heavy-duty applications
Dkjdpfsyuvktsx Ab Hjn
Advantages of Laser Welding over Conventional Welding Methods
- Minimal distortion, incredibly fast, exceptionally high quality (even with very thin materials < 1 mm)
- Consumes approx. 70% less energy
- Quick and easy to learn
- High process reliability
- Massive time savings with significantly reduced post-processing
- One of the lightest torches on the market at approx. 680 g
- Dual-channel safety loop for maximum safety
Advantages of the Craft-Laser
- Laser cleaning with up to 100 mm scan width and autofocus
- 2-in-1 machine: Welding and cleaning
- Full synergy – no more parameter lists
- Service-friendly – no more tedious shipping required
Olajšamo vam iskanje: "drugi stroj"
Nove ponudbe prejmete takoj in brezplačno po e-pošti.
Iskalno nalogo lahko kadar koli preprosto končate.
Rabljeni Drugi Stroj (29.935)
Zdaj preiščite celoten Machineseeker z več kot 200.000 rabljenimi stroji.Brskajte po najbolj priljubljenih poimenovanjih strojev:

Izvedite več zdaj
+44 20 806 810 84
+44 20 806 810 84
Objavite oglas zdaj
*na oglas/mesec
