Dmt Kern Cnc Stružnica nakup rabljenega (10.553)

Stanje: dober (rabljeno), Leto izdelave: 2010, Horizontal bed - Prism/flat guideway hardened and ground Working area - Swing diameter over bed: 1000 mm - Swing diameter over cross slide: 700 mm - Cross slide travel (plan): 600 mm Main spindle drive - Digital AC motor – 60% duty cycle: 46 kW Gearbox - ZF planetary gearbox, 2 steps - Electrically shifted - Mounted outside the headstock Headstock - Spindle nose DIN 55026, size A11 - Spindle diameter in front bearing: 190 mm - Spindle bore: 132 mm - Spindle taper: metric 140 - Speed range: 1–1800 rpm Cross slide - Feed range transversal: 0.001–1000 mm/rev - Feed range longitudinal: 0.001–2000 mm/rev - Thread pitches: 0.01–999.9 mm - Rapid traverse transversal/longitudinal: 5/10 m/min - From center distance 4000 mm: 5/7 m/min Crsdpfxsr D Nmye Ahxob - Automatic central lubrication - Digital AC servo motors (transversal and longitudinal) Tailstock - Quill diameter: 125 mm - Quill stroke: 280 mm - Taper: MK 6 - Clamping on bed with clamping bolts - Quill operation and clamping: manual - Tailstock roller guide

Stanje: rabljeno, Leto izdelave: 2006, Swing diameter: 650 mm Turning length: 1,500 mm Total power requirement: 33 kW Centre distance: 1,500 mm Swing diameter over bed: 650 mm Swing diameter in recess: 670 mm Swing diameter over cross-slide: 260 mm Cross-slide travel: 380 mm Main drive Drive power AC motor - 40/60 /100% duty cycle: 33 / 27 / 22 kW Headstock Spindle bore diameter: 106 mm Spindle diameter at front bearing: 140 mm Speed range (constant V): 1 – 2,000 rpm Cross-slide Plan feed range: 0.001 – 1,000 mm/rev Optional plan feed range: up to 5,000 mm/rev Longitudinal feed and thread pitch range: 0.001 – 2,000 mm/rev Optional longitudinal feed and thread pitch range: up to 13,000 mm/rev Plan feed force: 9,000 N Longitudinal feed force: 12,000 N Automatic tool turret Number of tool stations: 12 with driven tool capability for 6 stations Toolholder system (DIN69880) VDI40 Equipment SIEMENS SINUMERIK 840D sl (Shop Turn with manual functions) Combined operator station C-axis with drilling, milling, and engraving cycles Remnant material detection and machining – during roughing and contour pocketing MULTIFIX C type tool post mounted at front Csdpey Ifaxjfx Ahxjrb Three-jaw chuck SMW AUTOBLOK: HI-GRIP HGF260-81-3 Oil mist filter for work area extraction: MAHLE LTA600

Stanje: dober (rabljeno), Leto izdelave: 1998, Premer vrtenja nad posteljo: 475 mm Premer vrtenja nad planskim vozičkom: 260 mm Prehod vozička v prečni smeri: 260 mm Razdalja med konicama: 1500 mm Pogonska moč: 22 kW Stopenjski menjalnik m = ročno / e = avtomatsko; 2 e Vretenasta glava DIN 55026 / DIN 55027 A6 / 6 Premer vretena v sprednjem ležaju: 115 mm Premer izvrtine vretena: 78 / 70 mm Območje vrtljajev (konstantni V): 1 - 3.000 vrt/min Območje pomika prečno: 1µ - 1.000 mm/obrat Območje vzdolžnega pomika in navojev: 1µ - 2.000 mm/obrat Hitri premik prečno/vzdolžno: 5 / 10 m/min Premer konjička: 70 mm Hod konjička: 120 mm Notranji konus konjička: 5 MK Stroj je namenjen za posamično in maloserijsko proizvodnjo od preprostih do najbolj zahtevnih kontur. Izstopa po: Codowgn Agopfx Ahxjrb --> Uporabniška prijaznost Natančnost Delovno območje

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2021, obratovalne ure: 1.200 h, Funkcionalnost: popolnoma funkcionalen, stružna dolžina: 2.000 mm, premer struženja: 1.100 mm, moč: 46 kW (62,54 KM), razdalja med središči: 2.000 mm, delovne ure: 1.200 h, Oprema: vrtilna hitrost brezstopenjsko nastavljiva, Na voljo je stružnica DMT CD1100 z upravljalnikom Heidenhain in samo 1200 delovnimi urami. Območje obdelave zajema premer vrtenja okoli 1100 mm nad ležiščem in okoli 800 mm nad planskim suportom. Nosilec za orodja je Multifix D1. Razdalja med konicama znaša 2000 mm. Glavni pogon vretena je motor z močjo 46 kW pri 60 % ED s dvema prestavnima stopnjama. Konjiček: - Premer pinole: 125 mm - Stožčasta nastavitev: 6 Mk Dobava: Osebni prevzem Plačilo: 100 % pred prevzemom z bančnim nakazilom takoj po izdanem računu Vsi podatki so nezavezujoči, vmesna prodaja pridržana. Crjdsxlza Hopfx Ahxsb Stroj se prodaja brez garancije in ostane v naši lasti do popolnega plačila.

Stanje: rabljeno, Leto izdelave: 2010, Tehnične podrobnosti: Premer struženja: 1000 / 700 mm Dolžina struženja: 3000 mm Hod prečnega vozička: 600 mm Premer struženja nad suportom: 700 mm Hitrost vrtenja: 1–1800 1/min Prestavni razredi: 2 Moč vretena: 46 (60 %) kW Vrtina vretena: 132 mm Hod pinole: 280 mm Maks. masa obdelovanca: 2.560 kg Skupna potrebna moč: 38 kW Teža stroja pribl.: 6 t Dimenzije pribl.: 5 x 2,6 x 1,9 m Ciklični stružni stroj, sistem držal orodij PARAT hidravlična vpenjalna glava SCHUNK ROTA NC 500-160, konjiček, transporter za ostružke * Crodpfxjr U Skho Ahxeb

Stanje: dober (rabljeno), Leto izdelave: 2009, 1 used CNC lathe Manufacturer: DMT/Kern Model: CD 480 x 3000 Year of manufacture: 2009 Control system: Manual Plus 620 Technical specifications: Center height: 230 mm Swing diameter over bed: 475 mm Distance between centers: 3000 mm Cross slide travel: 255 mm Spindle head: DIN 55026/6 Spindle bore: 82 mm Crodpeu A Ducofx Ahxeb Connected load: 30 kW Turret tool holder: VDI 40 Equipped with: - Turret - Hinged belt conveyor - Complete documentation available! The machine is fully operational and can be inspected under power on site!

Stanje: zelo dobro (rabljeno), Leto izdelave: 2021, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 6414.21, premer struženja nad prečnim suportom: 420 mm, izvrtina vretena: 64 mm, premer struženja: 420 mm, premer struženja nad ležiščem sani: 340 mm, premer struženja nad zgornjim sanežem: 210 mm, višina središča: 210 mm, širina na sredini: 1.000 mm, stružna dolžina: 1.000 mm, poteza s peresom: 140 mm, premer tulec: 60 mm, skupna dolžina: 2.150 mm, skupna širina: 1.150 mm, skupna višina: 1.700 mm, največja hitrost vretena: 4.000 obr/min, hitrost vretena (min.): 1 obr/min, največja hitrost vrtenja: 4.000 obr/min, vrtljajska hitrost (min.): 1 obr/min, Oprema: vrtilna hitrost brezstopenjsko nastavljiva, The machine is free of defects and has not required any repairs so far, with very low operating hours. Codpfxjwcdhde Ahxsrb The lathe can be operated both conventionally and via servo drives. The control system allows programming using DIN commands, making it ideally suited for small batch production and training purposes. Sale due to misjudgment of the required technology: we have a growing demand for a cycle lathe programmable via CAD/CAM. For type, model, year of manufacture, and operating hours, please refer to the photos/descriptions. Price: €50,000 (negotiable), compared to a new price of approx. €76,000. Transport of the machine is not included in the price and is subject to negotiation. The live center shown in most photos is not included in the offer, only the one listed in the accessories! Comprehensive accessories listed in the attached Word document. The machine is available for immediate sale.

Leto izdelave: 1990, stanje: pripravljen za uporabo (rabljen), Višina konice: 230 mm, razdalja med konicama: 1500 mm, premer vrtenja nad ležiščem/na prečnem suportu: 475 mm/260 mm, največja teža obdelovanca: 500 kg, premer vretena: 1000 mm, vretenina izvrtina: 62,5 mm, največji premer vpenjalne glave: 250 mm, pomik X/Z: 1330 mm/280 mm, hitri pomik X/Z: 8 m/4 m/min, število vrtljajev: 3150 U/min. Dimenzije stroja X/Y/Z: ca. 3400 mm/2000 mm/1600 mm, teža: ca. 3300 kg, krmiljenje: Bosch CC 200T. Dokumentacija je na voljo. Možen je ogled na lokaciji. Crjdpfoxx Ufpjx Ahxjb

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 1999, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 71, stružna dolžina: 360 mm, premer struženja: 440 mm, največja hitrost vretena: 5.000 obr/min, prehod palice: 45 mm, model krmilnika: Fanuc 18iTA, TEHNIČNI PODATKI Premer struženja: 440 mm Dolžina struženja: 360 mm Hitrost vretena: 50 - 5.000 vrt./min na obeh vretenih Prehod palice: 45 mm Vretenasti nos: ASA A2-5 C-os: 0,001 na obeh vretenih PODATKI O STROJU Krmiljenje: Fanuc 18iTA Zgornji revolver: 12 pogonjenih postaj Spodnji revolver: 12 pogonjenih postaj Glavno vreteno: 11 / 7,5 kW Proti vreteno: 7,5 / 5,5 kW Csdpfx Ahoy E Hpioxsrb OPREMA Transporter za odrezke Naprava za pobiranje obdelovancev Vmesnik za avtomatski podajnik palic Avtomatski podajnik palic: LNS Mini-Sprint S2 42/3M

Stanje: rabljeno, Leto izdelave: 1992, Condition: used Year of manufacture: 1992 Stock number: 010190 Delivery time: immediate, subject to prior sale Price: €19,800 Quantity in stock: 1 Swing diameter over bed: 320 mm Distance between centers: 650 mm Center height: 160 mm Spindle bore: 40 mm Swing diameter over cross slide: 192 mm Bed width: 205 mm Spindle mount / DIN55027: Size 5 Spindle taper: 5 MT Number of spindle speed steps: 16 Spindle speed range: 48 – 2500 rpm Number of feeds: 24 Longitudinal feed: 0.02 – 0.63 mm/rev Cross feed: 0.006 – 0.2 mm/rev Metric thread range: 0.25 – 8 mm Module thread range: 0.2 – 4 Cross slide travel: 150 mm Top slide travel: 100 mm Tailstock quill diameter: 40 mm Tailstock taper: 3 MT Tailstock quill stroke: 85 mm Motor: 2.4 / 3 kW Length: 1582 mm Width: 715 mm Height: 1245 mm Cedpfx Aeyycwxohxerb Weight: 680 kg Equipment: - 3-axis digital readout Heidenhain - NEW Röhm 3-jaw chuck Dm. 160 mm with internal and external jaws - Quick-change toolholder with 1 rectangular and 1 round insert - Quick-release collet chuck with various collets ranging from Dm. 1 – 27 mm - Roller centers - Drill chuck - Chuck guard - Leadscrew and feed shaft safety cover - Motor brake - Coolant system - Machine feet - Operating manual in German

Stanje: dober (rabljeno), Leto izdelave: 2008, obratovalne ure: 5.763 h, Funkcionalnost: popolnoma funkcionalen, premer struženja nad prečnim suportom: 85 mm, stružna dolžina: 300 mm, izvrtina vretena: 25 mm, največja hitrost vretena: 6.300 obr/min, hitrost vretena (min.): 60 obr/min, skupna višina: 1.900 mm, skupna dolžina: 1.700 mm, skupna širina: 1.300 mm, skupna masa: 1.400 kg, Oprema: dokumentacija / priročnik, vrtilna hitrost brezstopenjsko nastavljiva, EMCO EMCOTURN E25 CNC stružnica s Siemens krmilnikom Stanje: Zelo dobro ohranjena, popolnoma delujoča Lokacija zaloge: Gradec Proizvajalec/model: EMCO EMCOTURN E25 Krmiljenje: Siemens Credpfx Aheyxvwijxeb Letnik: 2008 SLIKE/VIDEO POSNETKI: Za dodatne slike in videoposnetke stroja v delovanju nas kontaktirajte Tehnični podatki: Delovno območje: X-hod: 100 mm Z-hod: 300 mm Revolver za orodje: 12 postaj Premer struženja: Ø 85 mm Polmer vrtenja: 225 mm Vretenina izvrtina: Ø 25,5 mm Hitrost: Min.: 60 obr/min Maks.: 6300 obr/min Črpalka hladilne tekočine: Da Teža stroja: 1400 kg Dimenzije: Dolžina: 1700 mm Širina: 1300 mm Višina: 1900 mm Kontakt: Za termin ogleda ali ponudbo nas kontaktirajte!

Stanje: zelo dobro (rabljeno), Leto izdelave: 2015, Krmiljenje MITSUBISHI M 700 Prehod palice 37,5 mm 2 x 12-pozicijski revolver z gnanimi orodji 2 x C-os Codpfx Aey I Dilshxorb 2 x Y-os Glavno / protivretensko vreteno FMB polnilnik palic turbo 3-36 Sistem za pripravo hladilne tekočine Knoll KF 10 Transportni trak za odrezke Renishaw merilna sonda Lovilec delov Transportni trak za končne izdelke Zračni filter 2 x vpenjalna glava za vpenjalne tule Nosilci orodja in vpenjalne tule

Stanje: dober (rabljeno), Leto izdelave: 2009, Funkcionalnost: popolnoma funkcionalen, CNC Lathe TRAUB TNX 65/42 Year of Manufacture: 2009 Control System: Traub TX 8i-s TECHNICAL DATA - Number of spindles: 2 - Number of axes: 12 - Number of turret heads: 2 MAIN SPINDLE - Spindle nose: A2-6 - Spindle drive power: 24 kW - Spindle speed: 5,000 rpm - Max. bar diameter: 65 mm - Max. main spindle chuck diameter: 175 mm - Minimum C-axis resolution: 0.001° SUB SPINDLE - Spindle nose: A2-5 - Spindle drive power: 28 kW - Spindle speed: 7,000 rpm - Max. bar diameter: 42 mm - Minimum C-axis resolution: 0.001° Cedpfxoyw H Sze Ahxsrb - Travel distance: 700 mm LEFT UPPER TURRET - Number of positions: 10 - Number of driven positions: 10 - Travel X/Z: 175 / 650 mm - Travel Y: +/- 40 mm - Tool type: VDI 30 - Driven tool speed: 6,000 rpm - Driven tool power: 5.5 kW RIGHT LOWER TURRET - Number of positions: 10 - Number of driven positions: 10 - Travel X/Z: 175 / 650 mm - Travel Y: +/- 40 mm - Tool type: VDI 30 - Driven tool speed: 6,000 rpm - Driven tool power: 5.5 kW ELECTRICAL SUPPLY - Supply voltage: 400 V - Total power consumption: 95 kW WEIGHT AND DIMENSIONS - Footprint: 5,450 x 2,318 mm - Machine height: 2,258 mm - Machine weight: 10,000 kg New spindle installed since 04/26 ACCESSORIES - 3-color status lamp - Coolant tank: RESY * with high-pressure pump * with paper filter - Chip conveyor - Parts ejector - Parts belt conveyor

Stanje: zelo dobro (rabljeno), Leto izdelave: 2018, obratovalne ure: 15.845 h, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: S6E182501, izvrtina vretena: 65 mm, največja hitrost vretena: 5.000 obr/min, moč vretenovega motorja: 22 W, Stroj je zelo dobro ohranjen, 90% proizvodnje v uporabi ene osebe. Servisiran po priporočilih proizvajalca. Csdpfx Aheyvtugsxjrb

Stanje: dober (rabljeno), Leto izdelave: 2015, Funkcionalnost: popolnoma funkcionalen, stružna dolžina: 230 mm, premer struženja: 400 mm, Fanuc CNC krmiljenje Na obeh vretenih je vgrajeno po eno 3-čeljustno vpenjalo 2x 12-pozicijska revolverska glava Transporter za ostružke Codpoy Ni Ezjfx Ahxsrb Naprava za hlajenje Tehnični podatki: Premer nihanja: 500 mm Maks. premer struženja: 400 mm Maks. dolžina struženja: 230 mm X-pomik: 220 mm Z-pomik: 230 mm Maks. hitrost vrtenja vretena: 2000 min⁻¹ Število orodij v revolverju: 2x 12 Hitri pomik x, z: 30, 30 m/min Pogonska moč vretena: 18,5/15 kW Teža cca: 9400 kg Tehnični podatki, dodatki in opis stroja niso zavezujoči.

Stanje: rabljeno, Leto izdelave: 2004, BIGLIA B 470 YSM LATHE LATHE WITH Y AXIS SUBSPINDLE No. 02 MOTORIZED TURRETS Fanuc 18i-TB CNC CAPACITY: Max bar machining diameter, spindle/subspindle mm 68/45 Max chucking diameter, spindle/subspindle mm 200/160 Max machining length, spindle/subspindle mm 300/200 Max swing diameter, spindle/subspindle mm 200/160 Bar capacity, spindle mm 65 SPINDLE: Variable spindle speed range, spindle/subspindle rpm 100-4000/100-4000 Spindle nose, spindle/subspindle ASA 6''/ASA 5'' Spindle bore, spindle/subspindle mm 80/56 Spindle motor power (50%) kW 22-26/5.7-7.5 UPPER/LOWER TURRET: Number of live tool positions 12 Variable speed range: rpm 100-3000 Motor power: kW 1.1-3.7 (25%) Crsdpfxoy Ndx As Ahxsb AXES: X axis travel, spindle/subspindle mm 160/158 Z axis travel, spindle/subspindle mm 390/240 Y axis travel, spindle mm 100 (40-60) B axis travel, subspindle mm 420 CONTROLLED C AXIS: Minimum programmable value 0.001 degrees DIMENSIONS: Overall dimensions with chip conveyor mm 4107x2128x2204h EQUIPPED WITH: - Chip conveyor

Stanje: dober (rabljeno), Leto izdelave: 2000, 4-bed flatbed (the 2 outer beds for Z-carriage; 2 inner beds for tailstock) with traversable Z-carriage on the 2 outer guides; distance 1160 mm on inner guides for tailstock 700 mm Bed length: 5300 mm Centre distance (turning length between chuck height and centres): 3000 mm Centre height: 800 mm Cedpfx Ahjd D Nxkjxsrb Swing diameter over bed: 1600 mm Swing diameter over cross slide (between centres): 1400 mm Swing diameter over carriage: 1200 mm Bed width outer guide: 1160 mm Guide width for tailstock (center): 700 mm Bed welded; stress relieved by WIAP substitute annealing process and vibration damped according to the patented WIAP® VDSF® process (Pat.Nr. 68433; Reg.4230130.30; PCT/CH95-00108; PCT/CH95-00108, PCT/CH95-1072, PCT/CH95-1073) Guide surfaces ground; guides replaceable without bed disassembly 1.2 Headstock / Main drive - fixed-mounted Number of headstocks: 1 Spindle measuring system: digital / linear Axis position monitoring: none; as round axis Spindle bore: 112 mm Spindle nose: A15 DIN 55021 Main spindle motor: 100% duty cycle, 46 kW, 305 Nm Motor 1PH7184 2NE, Power module 6SN112-1AA00-0FA 3-speed gearbox mounted behind the headstock Automated, programmable gearbox via M function Gear stage 1: 5.6-120 RPM Gear stage 2: 16-360 RPM Gear stage 3: 45-800 RPM Torque stage 1 (100%): 15236 Nm Torque stage 2 (100%): 5290 Nm Torque stage 3 (100%): 1904 Nm Max speed: 800 RPM 1.3 Longitudinal and cross slide Qty: 1 each Number of cross slides: 1 Number of longitudinal slides: digital/linear Axis measuring system on the motor: Balluf Axis position monitoring (3-switch-pack): 2000 RPM Axis drive Z-feed motor: 27 Nm, 1005 mm 2 X slides independently traversable Max inner distance, coupling via M function X slide 1: 4-fold turret, and X slide 2 with driven turret Feed force: 27 kN Max feed/rapid feed Z: 6000 mm Feed type: backlash-free ball screw Z-axis travel: 3020 mm Rapid traverse Z-axis (designed for 10 m/min): 6 m/min* Axis drive X-feed motor: 1FT5076 18/22 Nm, 2000 RPM Feed force: 15 kN Max feed/rapid feed X: 6000 mm Feed type: backlash-free ball screw X-axis travel: 850 mm Rapid traverse X-axis: 10 m/min 1.3a Tailstock Manually adjustable, air-assisted for easy movement Vibration damped with taper for tailstock centre Quill diameter: 200 mm Quill stroke: 200 mm Auxiliary towing device available with Z-slide Clamping with nut & lever / ring nut with various threads around the circumference; repositionable 1.4 Guides All guides are on ground surfaces and resin-bonded Dimensions: 90 x 50 mm Steel guide hardness: approx. HRC 55 - 60 Counter guides with plastic coating Automatic central lubrication with electronic monitoring Heavy units are air-assisted for smooth movement and contamination protection, using WIAP® Press-Air process 1.5 Tool turret with driven tools Tool turret: Baruffaldi TOER 320 Type: K18.0320.12041.B Number of positions: 8 Cylinder shank diameter: VDI 60 Turret disc diameter (outer): 570 mm Turret disc diameter (VDI 60): 476 mm Disc thickness: 95 mm Driven tools: 4

Stanje: novo, Leto izdelave: 2018, Funkcionalnost: popolnoma funkcionalen, Standard technical specifications: Swing diameter over bed: 580 mm Swing diameter over carriage: 470 mm Max. machinable diameter: 360 mm Max. workpiece length: 250 mm Travel (X axis): 260 mm Travel (Z axis): 350 mm Travel (Y axis): 100 mm (+/-50 mm) C axis: 360° (0.001° incremental) Spindle speed: 50-6,000 rpm Spindle nose: JIS A2-6 Spindle bore diameter: Ø62 mm Front spindle bearing diameter: Ø100 mm Turret type: M-V12 Number of tool stations: 12 Tool size: 20x20 mm Tool shank diameter: Ø32 mm Tool change time: 0.1 sec Driven tool speed: 45-6,000 rpm Rapid traverse (X): 25 m/min Rapid traverse (Z): 30 m/min Rapid traverse (Y): 12.5 m/min Main motor power (15 min/continuous): 11/7.5 kW (PREX) Driven tool motor power: 5.5/3.7 kW (PREX) Machine dimensions (L x W x H): 2,020 x 1,734 x 2,250 mm Machine weight: 4,050 kg Control: OSP P300L Standard specification: 1 OKUMA CNC Lathe Model LB2000 EXII MYC with OSP-P300L CNC controller including CE mark & EMC 1 set ‘European Standard Specification’ 1-1. V12 radial turret head 1 set 1-2. Spindle 1 set (1) Spindle speed, 50-6,000 rpm (1 set) (2) Spindle motor Prex 11/7.5 kW (1 set) (3) Spindle nose: JIS A2-6; bore Ø62 mm (1 set) (4) C-axis control, 360 degrees (0.001° incremental) (1 set) (5) SR1146 hydraulic cylinder for chuck (1 set) 1-3. MT4 tailstock 1-4. Double-acting foot pedal for chuck and tailstock side 2 sets 1-5. Driven tool motor, PREX 5.5/3.5 kW (2 min continuous) 1 set 1-6. Driven tool speed, 45 - 6,000 rpm 1 set 1-7. Work area lighting 1 set 1-8. Full enclosure 1 set 1-9. Chip tray 1 set 1-10. Door interlock 1 set 1-11. Lubrication monitoring 1 set 1-12. Automatic chuck open/close on main spindle 1 set 1-13. Air blast for chips 1 set 1-14. Base bolts 1 set 1-15. Tool setter 1 set 1-16. CE marking 1 set 1-17. IEC standard compliance 1 set 1-18. Transformer 1 set 1-19. Coolant system with 250W pump 1 set 1-20. OSP-P300L CNC control with 15” color touchscreen monitor 1 set 1-21. OSP-P300L Advanced One Touch IGF-M-E kit specification (1 set) * Multitasking machines coordinate conversion (1 set) Crjdpfey H H Afex Ahxsb * Multitasking machines profile generation (1 set) * Advanced One Touch IGF (graphical programming assistant, dialogue-based programming interface) (1 set) * Real 3D simulation (1 set) * Cycle time checking (1 set) * Load monitor (1 set) * NC operation monitor (1 set) * Cycle time reduction function (1 set) * Hi-Cut Pro (machining-related servo optimization) (1 set) * Variable spindle speed control (1 set) 1-22. 2-level status indicator lamp 1 set 1-23. Program storage 2GB 1 set 1-24. Operating memory: 2MB 1 set 1-25. Spindle orientation, electric 1 set 1-26. Inch/metric switching 1 set 1-27. Ball screw pitch error compensation on X/Z axes 1 set 1-28. Workpiece ejection monitoring 1 set 1-29. Lifting lugs 1 set 1-33. TAS-C thermal compensation on machine frame 6” chuck Chip conveyor

Stanje: rabljeno, Leto izdelave: 2015, obratovalne ure: 24.952 h, CMZ TA 20 Y-400 Oscillationa peste pat / sanie: 760 / 600 mm Diametru maxim de strunjire: 460 mm Distanța ax – set roți: 473 mm Deplasări X / Y / Z / B: 310 / +70 / −50 / 640 / 640 mm Avans rapid X / Z / B: 30 m/min Avans rapid Y: 15 m/min Broșă principală: Viteză maximă: 4.000 rpm Putere: 22 / 15 kW la 366 / 286 Nm Crjdpfx Ajymc U Ashxsb Rulment exterior/interior: 150 / 100 mm Alezaj ax: 73 mm Trecere bară: 66 mm Diametru mandrină: 210 mm Contra-punct: Cursă: 400 mm Revistă port-scula: 12 posturi, toate acționate Viteză maximă: 12.000 rpm Putere: 11,3 / 8,1 kW Cuplu max.: 75 Nm Control CNC: FANUC 32i TB Tensiune: 400 V / 50 Hz Putere instalată: 45 kVA Dimensiuni: aprox. L x l x h 2,5 x 1,8 x 2,1 m Greutate: aprox. 6 t Ore funcționare: aprox. 24.952 ore Livrare: Încărcător bare IEMCA KID 80/16, an 2018 Unitate răcire

Stanje: rabljeno, Leto izdelave: 2019, obratovalne ure: 14.129 h, CMZ TA 20 YS-640 Swing over bed / slide: 760 / 600 mm Maximum turning diameter: 460 mm Distance from main to sub spindle: 649 mm Axis travel X / Y / Z / B: 310 / +70 / −50 / 640 mm Rapid traverse X / Z / B: 30 m/min Rapid traverse Y: 15 m/min Main spindle: Maximum speed: 4,000 rpm Power: 22 / 15 kW at 366 / 286 Nm Bearing diameter outside / inside: 150 / 100 mm Spindle bore: 73 mm Bar capacity: 66 mm Chuck diameter: 210 mm Turret: 12 stations, all with drive Maximum speed: 12,000 rpm Power: 11.3 / 8.1 kW Max. torque: 75 Nm Csdpfx Asymc Sbohxerb Sub spindle: Maximum speed: 4,500 rpm Power: 14 / 8 kW at 292 / 153 Nm Bearing diameter outside / inside: 150 / 100 mm Spindle bore: 61 mm Bar capacity: 52 mm Chuck diameter: 175 mm CNC control: FANUC 32i TB Voltage: 400 V / 50 Hz Connected load: 45 kVA Dimensions: approx. L x W x H 2.5 x 1.8 x 2.1 m Weight: approx. 6.3 t Operating hours: approx. 14,129 hours Scope of delivery: Bar feeder BREUNING IRCO SiMag 80.1-R-3000 II, year of manufacture 2015 Coolant unit

Stanje: rabljeno, Leto izdelave: 2015, obratovalne ure: 21.934 h, CMZ TC 35 Y-800 Prehod čez posteljo / prehod čez suport: 920 / 745 mm Največji premer struženja: 550 mm Razdalja med vretenom in končno enoto: 866 mm Pomiki X / Y / Z / B: 310 / +80 / −60 / 800 / 803 mm Hitri pomik X / Z / B: 30 m/min Hitri pomik Y-osi: 15 m/min Glavno vreteno: Največje število obratov: 3.000 min⁻¹ Moč: 45 / 39 kW pri 1.500 / 1.273 Nm Ležaji zunaj / znotraj: 240 / 160 mm Cjdpfx Ahjymc Trjxsrb Vrtina vretena: 106 mm Prehod za palice: 95 mm Premer vpenjalne glave: 315 mm Konjiček: Premer / hod pinole: 110 / 150 mm Pomik pinole: 800 mm Revolverska glava: 12 postaj, vse pogonske Največje število obratov: 4.000 min⁻¹ Moč: 16 kW Maks. navor: 75 Nm CNC krmilje: FANUC 32i TB Napetost: 400 V / 50 Hz Priključna moč: 65 kVA Dimenzije (D x Š x V): pribl. 3 x 2 x 2,2 m Teža: pribl. 8,3 t Obratovalne ure: pribl. 21.934 ur Obseg dobave: Podajalnik palic BREUNING IRCO ILS-MUK 10016-II, letnik 2015 Enota za hladilno sredstvo

Stanje: rabljeno, Leto izdelave: 2007, Funkcionalnost: popolnoma funkcionalen, Krmiljenje HAAS Maksimalna dolžina struženja (Z-os): 610 mm Maksimalni premer struženja nad ležiščem: 262 mm Število CNC osi: 2 Pogonska moč: 14,7 kW Vector Drive Premer vretena: 51 mm Maksimalno število obratov glavnega vretena: 4000 obr/min Število revolverjev: 1 Število orodij v revolverju: 10 Vreteno: A2-6 Teža cca 4800 kg Dimenzije D x Š x V = 2600 x 1700 x 1800 mm Oprema Crodpfx Aoy Du R Ejhxob - Odvajač ostružkov - Sistem hlajenja - Konjiček - Merilna roka za orodja - Hidravlična triosna vpenjalna glava - Nožna stikala - Signalna luč Stroj se prodaja zaradi likvidacije podjetja. Ni več priključen na elektriko.

Stanje: zelo dobro (rabljeno), Leto izdelave: 2007, Krmiljenje Siemens C 200 – 4D Premer struženja: 100 mm Cjdpfx Ahsy Hxtcjxorb Dolžina struženja: 280 mm 8-pozicijski revolver z gnanimi orodji 6-pozicijski revolver z gnanimi orodji Obratno število vretena: 6000 min-1 Maks. prehod palice: 60 mm Zadnja vrtalna enota za 5 postaj Transporter odrezkov Knoll Hladilni sistem

Stanje: zelo dobro (rabljeno), Leto izdelave: 2008, TECHNICAL DATA Clamping Units Collet machine with main and sub spindle: 26 mm Max. turning length with workpiece gripper: 67 mm Maximum part length: Max. 300 mm / Ø 26 Credpfx Ahjwqz Haexeb Clamping cylinder L/R spindle: Stationary Max. drilling diameter L/R spindle: Ø 12.00 mm Max. thread diameter L/R spindle: M8 Spindle Motor power: VAC 2.2/3.7 kW Spindle speed range L/R spindle: 80 ~ 8,000 rpm L spindle travel Z1 axis: 70.00 mm R spindle travel X2 axis: 180.00 mm R spindle travel Z2 axis: 238.00 mm Tool Slide Tool slide: Vertical linear slide Number of tool stations: 16.00 Number of tool stations slide 1: 6/4 Tool shank size: 16.00 mm Internal tool holder diameter: Ø 20.00 mm X1 axis travel: 135.00 mm Y1 axis travel: 260.00 mm Number of turning tools (L spindle) X-/Y-unit: 2/2 (Usable for L/R spindle) Z-unit: 2+2 Speed range: 100 ~ 4,000 rpm Rotary tool motor: 0.5 kW / 0.5 kW Driven tools max. drill diameter: 8.00 mm Rotary tool motor max. tapping diameter: M6 Tool Slide 2 Tool slide: Vertical linear slide Number of tool stations: 7.00 Number of tool stations slide 2: 3/4 Tool shank size: 16.00 mm Internal tool holder diameter: Ø 20.00 mm Y2 axis travel: 215.00 mm Machine Dimensions Machine height: 1,670.00 mm Floor space (W x D): 2,320 mm × 1,335 mm Machine weight: 3,000.00 kg SCOPE OF SUPPLY Includes, among others (list not exhaustive): Miyano BX-26S CNC lathe (Year of construction: 2008) Tool holders (see photo of the machine interior) Fire extinguishing system Control for high-frequency spindle High-frequency spindle Chip conveyor Oil mist separator Exact scope of supply according to photo documentation No guarantee is given for the correctness, completeness, or timeliness of the information provided.

Stanje: dober (rabljeno), Leto izdelave: 2008, Colchester Harrison Alpha 1400U CNC Lathe Footprint: 1.7 x 3.1 m Height: approx. 1,500 mm Weight: 3,200 kg Cjdpfx Ajrnkdyjhxerb Equipment: Electrically interlocked chuck guard, full enclosure, 100-litre coolant tank and pump, fully extendable chip tray, machine lighting Turning length: 1,250 mm Swing diameter: 400 mm Centre distance: 1,250 mm Spindle bore: 54 mm Turret, number of tool positions: 8 Tool size: Standard: 20 x 20 mm Boring bar: 32 mm No guarantee is given for the correctness, completeness, or currentness of the information.
