Mikron Obdelovalni Centri - Navpično nakup rabljenega (8.231)

Stanje: rabljeno, Leto izdelave: 2013, x-axis travel: 1,135 mm y-axis travel: 1,050 mm z-axis travel: 750 mm Control system: Heidenhain iTNC 530 Spindle speed range (main spindle), max: 14,000 rpm Main spindle drive power: 19 kW Max. torque: 100 Nm Tool holder: HSK-A 63 Clamping area (table): 1,400 x 1,050 mm Max. table load: 2,500 kg Max. workpiece dimensions: 1,400 x 1,240 mm Max. workpiece height: 750 mm Number of tool stations: 30 positions Tool holder: HSK-A 63 Max. tool diameter: 80 mm Max. tool diameter with adjacent pockets free: 160 mm Max. tool length: 365 / 395 mm Max. tool weight: 8.0 kg Tool change time (chip-to-chip): 6.1 sec Max. feed rate: 40,000 mm/min Rapid traverse: 40 m/min Acceleration: 6 m/s² Feed force (X / Y / Z): 14 / 20 / 14 kN Total power consumption: 44 kVA Machine weight: approx. 14.4 t Space requirement: approx. 6.0 x 5.0 x 3.3 m Iedeyztyaopfx Aqujih CNC Vertical Machining Center DMG MORI SEIKI - DMU 105 monoBLOCK - Spindle hours: approx. 9,518h - Production package: (Chip conveyor, coolant system 600 l, paper band filter, internal coolant supply 40 bar / 23 l/min through spindle center) - Air Clear: Air curtain for viewing window

Stanje: rabljeno, Leto izdelave: 1987, Technical Details: X-axis travel: 760 mm Y-axis travel: 450 mm Z-axis travel: 500 mm Control system: Mazatrol CAM M-2 Tool magazine with: 30 tool positions (chain magazine) Spindle taper: ISO 40 Spindle speed: 28 – 4,500 rpm Infinitely variable feed rates: X/Y/Z: max. 2,000 mm/min Spindle torque: approx. 23 Nm Rapid traverse: X / Y: 24 m/min Z: 15 m/min Drilling capacity in steel (diameter): Ø 40 mm Table size: 500 x 1,150 mm Table load – central/maximum: 700 kp Total power requirement: 11 kW (24.4 kVA) Iedovc Avbjpfx Aquoih Machine weight approx.: 6.8 t Machine dimensions approx. LxWxH: 3.7 x 2.5 x 2.6 m Chip conveyor: L: 3.7 x W: 0.75 x H: 1.35 m Additional features: - ATC tool magazine for 30 tools up to Ø 100 mm x 330 mm, SK40 - Hinged belt chip conveyor Knoll-120S-1 with discharge height of 1,130 mm - Coolant tank with pump, 200-liter capacity, 30 l/min - Operation via control panel with 2,000 mm arm - Base plates

Stanje: rabljeno, številka stroja/vozila: 005521, Working area X-axis: 4000 mm Iiodpfevctlgsx Aqueh Working area Y-axis: 1400 mm Working table: With vacuum console supports Main spindle power: 15 kW Number of controlled axes: 4 axes Number of drilling spindles: 30 Number of tool positions: 24

Stanje: rabljeno, Leto izdelave: 2000, Brez minimalne cene – zagotovljen nakup po najvišji ponudbi! TEHNIČNE PODROBNOSTI Iedpfx Aqjz S Nizouoih Hodi Hod v smeri X: 1.200 mm Hod v smeri Y: 620 mm Hod v smeri Z: 520 mm Nadzor CNC-nadzor: Heidenhain TNC 410 Delovna miza Velikost mize: 1.550 × 600 mm Izvedba: neprekinjena miza za daljše obdelovance Obdelava z nihajnim sistemom: možna z ločilno steno Pomik in hitri pomik Območje pomika: 1–30.000 mm/min Hitri pomik: 45 m/min Vreteno in vpenjalna glava Število vrtljajev vretena: 40–8.000 vrt/min Vpenjalna glava: ISO 40 Menjalnik orodij Naprava za menjavo orodij: 30 položajev Podatki o moči Skupna potrebna moč: 20 kVA Teža stroja: pribl. 9 t Dimenzije Potreben prostor: pribl. 4,2 × 2,3 × 2,7 m OPREMA Neprekinjena delovna miza Ločilna stena za obdelavo z nihajnim sistemom 3 dodatne vpenjalne mize Naprava za menjavo orodij s 30 položaji CNC-nadzor Heidenhain TNC 410

Stanje: zelo dobro (rabljeno), Leto izdelave: 2006, X-os 1.350 mm Y-os 1.150 mm Z-os 895 mm A-os +16 do -120 stopinj Iisdpezclk Sefx Aqush Rotacijska miza premer 1.100 x 1.000 mm Maks. dimenzija obdelovanca 1.000 x 1.000 x 500 mm Maks. obremenitev mize 1.600 kg Vpenjalni sistem HSK - A63 Menjalec orodij 46 pozicij Hitrost vretena 24.000 vrt/min Krmiljenje Heidenhain ITNC 530 Potreben prostor (vklj. z vrati) 5.605 x 4.290 x 3.159 mm Teža 12.500 kg Vključno z IKZ 40 bar Vključno z dokumentacijo

Stanje: rabljeno, Leto izdelave: 2012, x-hod: 1.035 mm y-hod: 560 mm z-hod: 510 mm CNC upravljalnik: HEIDENHAIN TNC620 Dimenzije mize: 1200 x 560 mm Največja obremenitev mize: 1000 kg Vreteno: SK 40 Število vrtljajev vretena: 10.000 U/min Pogonska moč vretena: 13 kW Neskončno nastavljiv pomik: 20.000 mm/min Hitri pomik: 25 m/min Orodniška izmenjevalna naprava: 20 pozicij Naprav za notranje hlajenje (IKZ): 20 bar Obratovalna napetost: 400 V Skupna priključna moč: 17 kVA Teža stroja: cca 4,1 t Potrebni prostor: cca 2,55 x 2,30 x 2,25 m Transportni trak za odrezke: 3,90 x 0,95 x 1,60 m - Tovarniška št.: 1539000377A - Delovni čas stroja: 21.689 h - Delovni čas vretena: 9.021 h Iiodpfjw A Spvsx Aqush - Krmiljenje: Heidenhain TNC 620 - elektronsko ročno kolo - Transportni trak za odrezke - IKZ 20 bar

Stanje: rabljeno, Leto izdelave: 2003, x-travel 1000 mm y-travel 800 mm z-travel 700 mm Control HEIDENHAIN iTNC 530 Total power requirement 50 kW Machine weight approx. 16 t Space requirement approx. m DEPO SPEED (Taiwan) Vertical gantry-type machining center with HEIDENHAIN CNC control Type 530 Type Speed 1008 Year of manufacture 2003 Table size 1,350 x 1,300 mm X-axis – cross-slide 1,000 mm Y-axis – crossbeam 800 mm Z-axis – vertical quill 700 mm Maximum table load approx. 8,000 kg Installation height under spindle approx. 800 mm Maximum workpiece dimensions approx. 1100 x 900 x 600 mm Spindle taper HSK-A 80 Spindle speeds, steplessly adjustable 30 – 14,000 rpm Rapid traverse/feed rates for X/Y/Z axis 20 / 24 m/min Acceleration in XYZ-axis 3.5 m/s² Feed drive torque 42 Nm Milling spindle torque 150 Nm Ijdpfx Aqst Hw Hrjueih Spindle drive 25/27 kW Total drive approx. 50 kW - 400 V - 50 Hz Weight approx. 16 t Accessories / Special equipment: • HEIDENHAIN CNC path control Type iTNC 530 with all essential subroutines, large monitor, and hand-held control unit • Tool magazine with 10 positions for tools max. 80x300x12 kg • Internal coolant supply and minimum quantity lubrication (likely also cooling air) Separate rotary and swivel table for mounting on the main table with its own tabletop approx. 400 mm x 400 mm, as 4th and 5th axis, Type DEPOTABLE RENISHAW laser measuring system for tool measurement or verification Touch probe by m&h for workpiece measurement with infrared transmitter • Separate control cabinet, spindle cooling, hydraulic unit, chip conveyor approx. 20 tool holders, dust extraction, full enclosure, etc. Condition: good – very good, extremely robust machine with high feed forces, high positioning accuracy, and stationary workpiece. Demonstrable under power and inspected by service technician Delivery: ex stock – as inspected Payment: strictly net – upon receipt of invoice We look forward to your order. A wide range of milling machines and machining centers of all types and sizes available from stock at any time!

Stanje: rabljeno, Leto izdelave: 2008, x-pomik 600 mm y-pomik 450 mm Ijdpfxox Iwg Ds Aqujih z-pomik 300 mm Hitrost vretena 42.000 min⁻¹ Po naši oceni je stroj v dobrem rabljenem stanju in si ga je mogoče po dogovoru ogledati pod napetostjo. Oprema: - Odsesavanje, proizvajalec Keller - Sistem palet, Röders RC 2 Prikazani dodatki, orodja in vpenjalni elementi so vključeni v dobavo samo, če je to navedeno v dodatnih informacijah. Pridržujemo si pravico do sprememb in napak v tehničnih podatkih ter do predprodaje!

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2002, - RABLJENO - 4-OSNI HORIZONTALNI OBDELOVALNI CENTER Z VEČPALETNIM SISTEMOM POMIK OSI X: 1000 mm POMIK OSI Y: 850 mm POMIK OSI Z: 750 mm Iodoyry Rrspfx Aquoih RAZDALJA VRETENO-MIZA: 50 - 900 mm HITRI POMIKI X-Y-Z: 30 m/min VRETENO: 15000 vrt./min; 30 kW; ISO 50 - BT PALETA: INDEKSIRNA; ŠT. 15; 630x630 mm HLADILNA TEKOČINA POD VISOKIM TLAKOM: 70 bar MAGAZIN ORODJA: VERIŽNI TIP; 225 POZICIJ MAKS. PREMER ORODJA: 120 mm MAKS. DOLŽINA ORODJA: 500 mm MAKS. TEŽA ORODJA: 27 kg KRMILNA ENOTA: FANUC 16i-M DODATKI: TRANSPORTER OSTRUŽKOV; NASTAVLJALEC ORODJA; MERILNA SOND

Stanje: rabljeno, Leto izdelave: 1998, Technical details: x-travel: 560 mm y-travel: 450 mm z-travel: 450 mm table size: 760 x 410 mm spindle speed range: 8,000 rpm Iiodpfx Ajwvblgoquoh Vertical machining centre

Stanje: rabljeno, Leto izdelave: 1998, x-hod 1050 mm y-hod 510 mm z-hod 560 mm Krmilnik Matzatrol Tip M Plus Velikost mize 1300x550 mm Obremenitev mize maks. 1,5 t Maks. teža obdelovanca 1500 kg Menjalnik orodij . Št. obratov . vrt/min Teža stroja ca. 8,9 t Potrebni prostor ca. . m Širina obdelovanca: maks - 550 mm Dolžina obdelovanca: maks - 1300 mm Ijdpfxszdca Te Aqusih Višina obdelovanca: maks - 600 mm Tehnični podatki so podatki proizvajalca ali uporabnika in so zato nezavezujoči. Vmesna prodaja pridržana; veljajo izključno naši splošni pogoji prodaje in poslovanja. O nas več kot 400 lastnih strojev na zalogi več kot 15.000 m² skladiščnih površin, kapaciteta dvigala 70 t več kot 10.000 artiklov dodatne opreme za vašo delavnico Če želite prodati stroje, proizvodne linije ali vaše podjetje, nas kontaktirajte. Dodatno ponudbo najdete na naši spletni strani. Ogledi so možni po dogovoru. Veselimo se vašega obiska. Vaša ekipa Markus Hirsch

Stanje: rabljeno, Leto izdelave: 2007, Technical details: X-axis travel: 1200 mm Y-axis travel: 600 mm Z-axis travel: 800 mm Spindle-to-table distance: 125 / 925 mm Control: Heidenhain iTNC 530 Spindle speed: 9000 rpm, stepless Spindle torque: max. 82 Nm Power-on hours: 43,363 h Spindle operating hours: 16,319 h Tool magazine: 24 positions Table size: 1250 x 630 mm (cross-slide table) Max. table load: 1000 kg Spindle taper: SK40 Spindle motor: 13 kW Feed rate (X/Y/Z): 40/40/30 m/min Rapid traverse (X/Y/Z): 40/40/30 m/min Feed force (X/Y/Z): 7/7/16 kN Interface: yes Total power requirement: 13 kW Machine weight approx.: 8.0 t Coolant system dimensions: approx. L: 1.25 x W: 0.7 x H: 1.56 m Iodpfx Asvithzequeih Machine dimensions approx. LxWxH: 2.4 x 3.0 x 3.3 m Main spindle: spindle head DIN 69871, SK 40/DIN 69871-A40 and drawbar DIN 69872 Drive technology via ball screw Equipment: Compact filter/high-pressure coolant system Knoll Chip conveyor/scraper belt conveyor 300 mm Tool change unit with disc magazine for 24 tools electronic handwheel Operation via Heidenhain control panel Accessories: AL plate 1200x600x45 mm with Ø 15 mm bores

Stanje: rabljeno, Leto izdelave: 1987, x-travel: 500 mm y-travel: 380 mm z-travel: 300 mm Control: FANUC Total connected load: 12 kW Machine weight approx.: 2,300 kg Space requirements approx.: m S T A M A (FANUC) Vertical 3-axis CNC machining center Model: MC 010 Year of manufacture: 1987 # KMH 010 1110 Working area: Longitudinal travel X-axis: 500 mm Vertical travel Z-axis: 300 mm Cross travel Y-axis: 380 mm Table size / working area: 650 x 380 mm Table load capacity approx.: 200 kg Installation height between table/spindle: 240–540 mm Distance to spindle center approx.: 350 mm Tool holder: SK 30 Spindle speeds: 1,500 – 6,000 rpm Feed rates / rapid traverse max.: up to 1,000–4,000 mm / 15 m/min Drilling/milling capacity in steel: 20 mm / 130 cm³ Milling capacity in aluminum: 500 cm³ AC main drive: approx. 3.7 / 5.5 kW Total drive power: approx. 12 kW – 380 V – 50 Hz Weight: approx. 2,300 kg Accessories / special equipment: • Original FANUC control with monitor, all modern subprograms, fault diagnostics, electronic handwheel, RS 232, easy and quick to program directly at the machine, and much more. • Vertical turret head with 10 tool stations, ISO 40, fast tool changeover time approx. 7 seconds chip-to-chip • Programmable rotary table mounted on the machine table (not an additional CNC axis), excellently suited as an indexing table, hydraulic, type RST 2 • Separate coolant unit • Various tool holders, some with tools Ideal machine for productive drilling, tapping and milling in steel and aluminum. Iedpfx Aqot Hw H Eeujih Condition: Good to very good – demonstration under power possible Delivery: Immediately from stock, loaded free onto truck Payment: Net – upon receipt of invoice We look forward to your order. We constantly stock a wide range of CNC machining centers of all types – please inquire for alternatives!

Stanje: rabljeno, Leto izdelave: 1997, x-axis travel 500 mm y-axis travel 350 mm z-axis travel 350 mm Total power requirement 15 kW Machine weight approx. 6 t Space requirement approx. [dimension not specified] Table size each 600 x 375 mm Milling slide travel longitudinal (X-axis) each 500 mm Iijdpfx Ast Hwqdoquoh Milling slide travel cross (Y-axis) 350 mm Milling slide travel vertical (Z-axis) 350 mm Installation height under vertical spindle 100/450 mm Overhang of vertical head 390 mm Spindle taper (69872) SK 40p Infinitely variable spindle speeds 20 – 10,000 rpm Drilling capacity in steel St 60 approx. 28 mm Milling capacity approx. 150 m³ Feed rate all 3 axes or rapid traverse max. 0 - 25,000 mm/min Spindle drive 6/9 kW CNC path control: SINUMERIK 840 C for 3 axes with monitor and all standard sub-programs and options, integrated in the operator panel 2 fixed tables set side by side, with T-slots, load capacity 2 x 400 kg automatic tool changer mounted above spindle head, with 36 tool positions, tool change time approx. 4.5 sec (chip-to-chip), various tools included Tool size: max. Ø 63/120 x 250 mm length, max. weight approx. 4 kg Complete all-round work area enclosure with sliding doors at the front and sides Coolant system 400 liters with chip conveyor, belt filter, and fine filter, also suitable for internal coolant supply through the tool (IKZ) 2 clamping fixtures each with 8 pieces 3-jaw chucks, pneumatically actuated, clamping diameter approx. 50 mm This is a very fast and flexible machining center for demanding milling and drilling operations in medium and large batch production. Condition: good to very good – can be demonstrated under power

Stanje: rabljeno, Leto izdelave: 2009, x-travel 800 mm Iijdpfx Aqowtr Eljuoh y-travel 500 mm z-travel 500 mm Control Siemens

Stanje: rabljeno, Leto izdelave: 2001, Technical Details: X travel: 630 mm Y travel: 560 mm Z travel: 560 mm C axis: Table 360° B axis: Spindle - right: 90° / left: 10° manual Control: Heidenhain TNC 430 MillPlusM Table size: 1000 x 600 mm Table load: 400 kg Tool holder: SK 40 Spindle speed: 20 – 12,000 rpm Feed rates, stepless: X/Y/Z = 20 – 10,000 mm/min Tool magazine: 2 magazines Tool magazine with: 12 places per magazine Spindle operating hours: 21,212 h Power-on hours: 49,845 h Total power requirement: 20.6 kW Machine weight approx.: 6.7 t Machine dimensions approx. LxWxH: 3.0 x 2.0 x 2.15 m Equipment: - AC motors for X/Y and Z axes Iijdpfxsu Idgco Aqueh - Tool clamping hydraulically/mechanically - Swarf conveyor with separator (screw conveyor) - Stand-alone indexing device Ø 300mm with hand control for B-axis table tilt -10° / +95° and C-axis table rotation 360° (not interpolatable, selection electrically via Nikken hand control) - Coolant system 8 m³/h (dimensions: L: 1.1 x W: 0.54 x H: 1.2 m) - Hand control unit - 24 tool positions, holders 1/6/7/18/21 broken! - Spindle can be manually swiveled from Y-axis from -10° to 90° - Indexing device "rotary table" separately programmable (external), tilting range manual 0–90°, own control! In good condition.

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 1985, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 05.14, potovalna razdalja osi X: 410 mm, pomik osi Y: 240 mm, pomik po osi Z: 330 mm, največja hitrost vretena: 2.240 obr/min, hitrost vretena (min.): 50 obr/min, skupna višina: 1.560 mm, skupna širina: 1.230 mm, skupna dolžina: 1.330 mm, dolžina mize: 630 mm, največja hitrost vrtenja: 2.240 obr/min, vrtljajska hitrost (min.): 50 obr/min, skupna masa: 1.000 kg, vhodna napetost: 400 V, Oprema: dokumentacija / priročnik, Mikron WF 2S – letnik izdelave 1985 Lastnost Tehnični podatki Proizvajalec Mikron, Švica Tip WF 2S Letnik izdelave 1985 Vrsta stroja Univerzalni orodjarni rezkalni stroj Os X približno 420 mm Os Y približno 250 mm Os Z približno 335–340 mm Velikost mize približno 700 × 250 mm Vretenčna priključna matica ISO 40 Število stopenj vrtljajev vretena 12 Območje vrtljajev 50–2.240 vrt/min Poti približno 8–400 mm/min Hitri pomik približno 1.400 mm/min Glavni motor 1,2 / 1,8 kW, dvostopenjski Pomožni motor za podajanje približno 0,55 kW Črpalka za hladilno tekočino približno 0,1 kW Iiedpfez Ix Drox Aquoh Teža približno 770 kg z navpično glavo/naklonjeno mizo; glede na opremo do približno 1.000 kg Kazalnik pozicije pogosto Heidenhain, glede na opremo Te vrednosti so navedene tudi pri trenutni ponudbi stroja WF 2S iz Švice, vključno z gibom 420 × 250 × 335/340 mm, 50–2.240 vrt/min in vretenčnim motorjem 1,2/1,8 kW. Na voljo so priročniki, električna shema in navodila za programiranje.

Stanje: rabljeno, Leto izdelave: 2007, x-gib 1350 mm y-gib 560 mm z-gib 510 mm Krmilni sistem Heidenhain iTNC 530 Skupna potrebna moč 13 kW Masa stroja približno 5 t CNC obdelovalni center DMG DECKEL MAHO DMC 1035 V Letnik izdelave 2007 Krmilni sistem Heidenhain TNC 530 Hodi: X 1350 mm Y 560 mm Z 510 mm Vpenjalni sistem SK 40 (ni priloženih orodij/vpenjal) Število vrtljajev 10.000 min Rešetasta plošča in vpenjalne klešče niso priložene. Iodpfx Ajzlb Dfsquoih

Stanje: rabljeno, Leto izdelave: 2000, Tehnične podrobnosti: Pomik po osi x: 500 mm Pomik po osi y: 400 mm Pomik po osi z: 400 mm Os b: ročno pozicionirana ° Os c: ročno pozicionirana Krmiljenje: Heidenhain TNC 124 Orodni magazin: ne, ni mest Vpenjalni stožec: SK40 Hitrost vretena: 4500 obr/min Brezstopenjske pomične hitrosti X/Y/Z: maks. 14.000 mm/min Hitri pomik: 5,0 m/min Velikost mize: 700 x 500 mm Skupna priključna moč: 17 kVA Teža stroja pribl.: 2,91 t Dimenzije stroja pribl. D x Š x V: 2,0 x 2,0 x 2,5 m CNC univerzalni vertikalni rezkalni stroj Isdpfx Aqju Idffeuoih Stroj ima 5 osi. B- in C-os sta ročno pozicionirani z merilnim sistemom. B-os – nagib mize -10° / +95°, C-os – vrtenje mize 360° (ni interpolabilno, ročno izbirno preko krmiljenja). Hladilni sistem (brez črpalke). Upravljanje preko vrtljivega izmeničnega nosilca. vklj.

Stanje: zelo dobro (rabljeno), Leto izdelave: 2013, x-hod 1000 mm y-hod 550 mm z-hod 500 mm CNC-krmiljenje Fanuc Oi-MD Velikost mize 1.100 x 500 mm maks. obremenitev mize 700 kg Vpenjalni stožec ISO BT-40 Hitrost vretena 10.000 min⁻¹ Podajalna hitrost brezstopenjsko 24.000 mm/min Hitri pomik 36/36/30 m/min Pogonska moč - motor vretena 15/11 kW Menjalec orodij 24 Hladilni sistem IKZ 20 bar Obratovalna napetost 400 V Iodpfsxvdtwex Aqujih Skupna priključna moč 30 kVA Teža stroja cca 6,5 t Prostorske zahteve cca 3,35 x 2,20 x 2,67 m Transportni trak za odrezke 2,40 x 1,50 x 1,40 m Filtrirna naprava 0,90 x 1,40 x 1,30 m Transformator 0,60 x 0,55 x 0,55 m - Serijska št.: M281361B5N D - Delovni čas stroja: 21.011 h - z NC-delnim aparat KITAGAWA (klic preko M-ukaza) - Krmiljenje: FANUC Oi-MD - IKZ 20 bar - Transportni trak za odrezke

Stanje: rabljeno, Leto izdelave: 1997, x-travel 800 mm y-travel 400 mm Iodpfx Ajt Hwx Isqueih z-travel 350 mm Total power requirement 40 kW Machine weight approx. 8 t Space requirement approx. m CNC-controlled vertical machining center for bar processing. For 5-axis machining of complex shapes at any angle with maximum productivity and precision, Type MC 530 SM Year of manufacture 1997, #530 1195 TECHNICAL DATA: Bar diameter / profile size x max. length: 60 x 800 mm (!) Milling slide travel longitudinal X-axis: 800 mm Milling slide travel transverse Y-axis: 400 mm Milling head travel vertical Z-axis: 350 mm Workpiece axis rotation/swivel: 360° / 120° Mounting height under vertical spindle approx.: 300 mm Spindle taper: HSK 63 Spindle speeds continuously variable: 36 – 10,500 rpm Feed rates, all 3 axes: 1 – 10,000 mm/min Rapid traverse: 40,000 mm/min Spindle drive: 14 to 32 kW Total drive: 40 kW - 380 V - 50 Hz Weight approx.: 8 t Accessories / Special equipment: CNC path control FANUC type 16 MB, for all 5 axes with monitor and direct input, various subprograms, tool corrections, tool monitoring, parallel programming, 3-D and helical interpolation, and much more. IRCO bar loading magazine mounted on the left of the machine, for up to 10 bars with a diameter of 60 mm. Mounted CNC rotary/swiveling unit with collet chuck system for holding bar stock in combination with hydraulic tailstock as counter support. Automatic tool magazine with 42 tool stations, Ø 100 x 200 mm length. Tools also with internal coolant (IKZ), with separate tool data management, chip-to-chip 4 sec. Tool breakage monitoring via laser light barrier, etc. Pneumatically retractable finished part catcher between workpiece head and tailstock; conveyor belt for parts removal without opening the work area. Fully enclosed work area, chip conveyor installed, but without coolant supply (central provision). Thread cutting possible without compensating chuck, no toolholders included. Very robust machine.

Stanje: rabljeno, Leto izdelave: 2016, X-hod 1.020 mm Y-hod 700 mm Z-hod 500 mm Krmilnik Siemens 828D Dimenzije mize 1.050 x 700 mm Hitrost vretena 15.000 obr/min Vpenjanje orodja BBT-40 Iodpjyw Tm Esfx Aquoih Po naši oceni je stroj v dobrem rabljenem stanju in ga je mogoče po dogovoru ogledati pod elektriko. Pribor, prikazana orodja in vpenjalna sredstva so vključena v dobavo le, če je to navedeno v dodatnih informacijah. Pridržujemo si pravico do sprememb in napak v tehničnih podatkih ter do predhodne prodaje!

Stanje: rabljeno, Leto izdelave: 2007, x-pot 760 mm y-pot 510 mm z-pot 610 mm površina za namestitev na mizo 1.020 x 510 mm nadzorni sistem WINMAX hitrost vrtenja vretena 12.000 vrt/min motor vretena 13,5 kW Isdpfx Ajznnc Tequeih kapaciteta skladišča 24 kosov vpenjalni sistem SK 40 notranji dovod hladilne tekočine 20 bar hitri pomik 35/35/30 m/min masa stroja približno 5,0 t rabljeno vertikalno obdelovalno središče s 4. osjo - dvojni menjalnik orodij - notranji dovod hladilne tekočine s kartušnim filtrom - hladilnik za olje vretena - zunanji ročni krmilnik

Stanje: zelo dobro (rabljeno), Leto izdelave: 2002, Hod poti: 600 x 450 x 450 mm Velikost mize: 850 x 530 mm Vpenjalna glava vretena: HSK63 Število vrtljajev vretena: -20.000 vrt/min Menjalnik orodij: 30 položajev Krmilnik: HEIDENHAIN iTNC 530 3D tipalo za merjenje Merjenje orodja: RENISHAW TS27R Nadzor za odkrivanje zloma orodja Naprava za merjenje dolžine in premera orodja Ijdpfx Ajzwt Hcsquoih Različna dodatna oprema MARCELS MASCHINEN CH

Stanje: rabljeno, Leto izdelave: 1998, x-hod 1.020 mm y-hod 510 mm Iijdpfx Aoy Apcyequeh z-hod 510 mm Krmiljenje MSC 501 Fanuc Pritrdilna površina mize (APC) 1.200 x 480 mm maks. nosilnost mize (APC) 550 kg Območje vrtljajev - rezkanje 10.000 min⁻¹ Pogonska moč - vreteno za rezkanje 22 / 18,5 kW Vpenjalo orodja BT 40 Število orodij 30 pozicij maks. premer orodja 80 mm maks. premer orodja pri prosti sosednji reži 125 mm maks. dolžina orodja 300 mm maks. masa orodja 8 kg Hitri pomik 32 m/min Podajalna hitrost 1 ~ 16.000 mm/min Tippeed feed 0 ~ 1.260 mm/min Premer ležaja vretena 85 mm Skupna potrebna moč 59,5 kVA Teža stroja pribl. 6,9 t Mere pribl. 3,9 x 2,7 x 2,9 m CNC obdelovalni center - vertikalni MORI SEIKI - SV 500 B/40 - Vpenjala NISO vključena v dobavo.
