Mikron Haas Vertikalni Obdelovalni Center Cnc nakup rabljenega (21.183)

Stanje: zelo dobro (rabljeno), Leto izdelave: 2014, Funkcionalnost: popolnoma funkcionalen, Krmiljenje HAAS (LCD zaslon, intuitivno programiranje) Velikost mize 914 x 356 mm Nosilnost mize 680 kg X-hod 762 mm Y-hod 406 mm Z-hod 508 mm Hitrost vretena 12000 vrt/min Hitri pomiki X/Y/Z = 35,6 m/min Orodni magazin 24+1 položajev (ročni tip) Moč 22,4 kW Stožec vretena SK40 Teža stroja cca. 3630 kg Dimenzije (D x Š x V): 2500 x 2400 x 2600 mm Bdodpjy Ifbcjfx Agtob Dodatna oprema: - Električni ročni kolesi - Hladilni sistem - IKZ - Polž za odrezke - RENISHAW infrardeči sistem za merjenje orodja s sondo - Priprava za 4. os - Zaznavanje izpada električne energije - Dokumentacija stroja Stroj je v zelo dobrem stanju in še vedno priključen na elektriko. Kupljen je bil kot nov in uporabljen je bil v čisti in profesionalni delavnici.

Stanje: zelo dobro (rabljeno), Leto izdelave: 2010, obratovalne ure: 1.000 h, Funkcionalnost: popolnoma funkcionalen, Steuerung FANUC 0i-MD Tischgröße 1120 x 560 mm Max. Tischbelastung 750 kg Bsdpfxjy Id Tko Agtedb X-Verfahrweg 1020 mm Y-Verfahrweg 560 mm Z-Verfahrweg 600 mm Abstand Spindelnase-Tischebene 135 – 735 mm Drehzahl 60 – 8000 U/min Spindelkegel BT40 Werkzeugmagazin 20 Positionen (Schirmmagazin) Hauptantriebsleistung 7,5/11 kW Eilgang X/Y/Z 24/24/18 m/min Maschinenabmessungen (L x B x H) 2820 x 2530 x 2500 mm Maschinengewicht ca. 6000 kg Zubehör - Späneförderer - Arbeitsplatzbeleuchtung - Signalleuchte - Handrad - Füsse Die Maschine wurde auf eine Sondermaschine für automatische Fraesen und Saegen umgebaut aber das bezieht sich nur auf Seitebedeckungen. Somit kann man lange Stangen automatisch trennen und fraesen. Die kann aud normale zurückgebaut. Die Maschine wurde kaum benutzt und verfügt über 1000 Laufstunden. Noch unter Strom in Ungarn.

Stanje: dober (rabljeno), Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 820 mm, pomik po osi Z: 275 mm, hitro pomikanje X-os: 15 m/min, hitri pomik na osi Z: 15 m/min, model krmilnika: SIEMENS SINUMERIK, višina obdelovanca (maks.): 750 mm, premer obdelovanca (maks.): 680 mm, največja hitrost vretena: 3.500 obr/min, Oprema: transportni trak za ostružke, Prodamo univerzalni CNC stružni center (tokarka) češkega proizvajalca KOVOSVIT MAS PRIM S80i Gre za robusten stroj, namenjen preciznemu struženju, vrtanju in navojanju v enkoserijski in mali serijski proizvodnji. PRIM različica je opremljena s pogonskimi orodji (live tooling) in C-osjo, kar omogoča kompleksno obdelavo z enim prijemom. ŽMaks. hitrost vretena: do 3500 rpm Revolver: 12-pozicijski C-os: Da, omogoča struženje + rezkanje Krmilnik: Siemens Sinumerik 810D/840D Teža stroja: cca 6700 kg Ključne prednosti stroja Vsestranskost — zahvaljujoč C-osi in gnanim orodjem lahko izvaja struženje, rezkanje, vrtanje in navojanje v enem prijemu. Visoka ponovljivost — primeren za natančne dele iz jekla, litih materialov in nerjavnih jekel. Bdjdsy E Iikjpfx Agtsb Robustnost — težka konstrukcija in močno vreteno omogočata težko rezkanje in dolgotrajno obratovanje. Uporabnost — idealen za delavnice, ki potrebujejo en stroj za širok spekter obdelave (od enostavnih valjev do kompleksnih komponent z zobniki, luknjami itd.).

Stanje: zelo dobro (rabljeno), Leto izdelave: 2014, Vertikalni obdelovalni center Hurco VMX42i Leto: 2014 Krmiljenje: WinMax Bodpsyuc Nvjfx Agtjdb Vpenjalna površina mize: 1270 x 610 mm Obremenitev mize: 1750 kg Pomiki X-os: 1067 mm Y-os: 610 mm Z-os: 610 mm Nosilec orodja: SK 40 Maks. hitrost vretena: 12.000 obr/min Maks. moč vretena: 18 kW Izmenjevalec orodij: 30 mest Maks. premer orodja: 80/76 mm Dolžina orodja: 300 mm Teža stroja: 6850 kg Rezervoar za hladilno tekočino: 484 litrov Dodatki/možnosti: - Hlajenje skozi vreteno - Nosilci orodij - Dokumentacija - Daljinsko upravljanje - Transporter za odrezke Pod napetostjo v našem skladišču!

Stanje: rabljeno, Leto izdelave: 2016, Used machine Year of manufacture: 2016 Features and technical data: - Electrical system: 3x400V 50/60Hz - Gimbal-mounted 5-axis electrospindle 12 kW (S6) HSK F63 - 24,000 rpm - Ceramic bearings including liquid cooling with infinitely adjustable extraction hood – motorized control - Full rated power available at approx. 12,000 rpm - Speed range: 1,000 – 24,000 rpm - Drive: 3-phase high-frequency motor controlled via inverter - Rotation direction: right/left - 2 controlled compressed air connections - Interface for aggregates - Tool weight (rotating): 6 kg - Max. saw blade diameter: 350 mm - Spindle cooling: liquid cooling - Continuously adjustable extraction hood - Profit H350 16.30: Bodpfx Agoy Ih Rgetjdb CNC machining center in gantry design (without tooling) with digital drives (double-sided drive). The machine frame of the Profit H350 16.30 is made from thick-walled, electro-welded box-section steel. Internal ribbing ensures high rigidity. - Working area H350 16.30: Axis travel: X = 4,000 mm Y = 1,970 mm Z = 455 mm Working envelope: X = 3,000 mm Y = 1,500 mm Z = 150 mm clearance height Axis positioning speeds: Depend on the selected safety system (see layout). - Double-sided driven gantry portal - X-axis guide system: The portal drive for the X-axis is via a helical, crowned rack and pinion – this ensures maximum precision. The reduction gear guarantees excellent machining quality and repeat accuracy. The bearing arrangement uses encapsulated recirculating ball carriages running on hardened and ground linear guides. - Y-axis guide system: The bearing arrangement uses encapsulated recirculating ball carriages running on hardened and ground linear guides. The Y-axis is positioned via a ground recirculating ball screw. - Z-axis guide system: The bearing arrangement uses encapsulated recirculating ball carriages running on hardened and ground linear guides. The Z-axis is positioned via a ground recirculating ball screw. - Automatic central lubrication: Lubricant is precisely delivered to the guide carriages of the X, Y, and Z axes as well as to the recirculating ball screws in Y and Z. Lubrication is carried out automatically at set intervals. - 12-position linear tool changer mounted on the left side of the machine frame, including one pickup station for aggregates: The 12-position linear changer ensures minimum tool changing times and ample storage for milling tools. One aggregate station (see layout for possible configurations) Max. tool diameter: 250 mm Max. tool length: 240 mm - Drilling head DH 18 6H 1S: Vertical: 12 spindles (7 in X-direction, 5 in Y-direction) Horizontal: 6 spindles (4 in X-direction, 2 in Y-direction) Stroke = 70 mm Max. drill bit length = 70 mm, shank diameter = 10 mm All spindles individually driven and selectable 1 slot saw in X-direction Max. saw blade diameter 120 mm

Stanje: rabljeno, Leto izdelave: 2005, Used machine Year of manufacture: 2005 Features and Technical Data: - Base machine 555 - Processing dimensions for edge milling: - X = 3514 mm - Y = 1544 mm - Maximum processing dimensions: - X = 3868 mm - Y = 1746 mm - Z = 325 mm - Workpiece support with 8 consoles, pneumatically clamped - Drilling unit 7968: - 18 vertical drilling spindles with 32 mm pitch - 12 in X-axis and 6 in Y-axis - individually selectable - T-shape arrangement - max. drilling diameter 35 mm (depending on panel thickness) - spindle stroke: 70 mm - rotation direction: alternating clockwise/counterclockwise - speed: 4725 rpm, infinitely variable - 2 horizontal drilling units in X-direction, 1 horizontal drilling unit in Y-direction Bdjdjx Enpqopfx Agteb - Saw unit 7946: - Motor: 3.5 kW - 90° pneumatic swivel - speed: 5300 rpm - Tool holder A Ø = 200 mm, I Ø = 30 mm, B = max. 3.5 mm - sawing/grooving in X and Y directions - Milling unit 7935: - with 6 kW spindle, water-cooled - Milling unit 7982: - for mortise lock case milling - Tool changer 7996: - 18-position magazine (carousel) - Vacuum pump with 140 m³/h - Hand-held control device - PC control with TwinCAM WOP system - Siemens control Availability: short-term Storage location: 63934 Röllbach

Stanje: rabljeno, Leto izdelave: 2005, Machine d'occasion Année de fabrication : 2005 Équipement et données techniques : Machine à consoles (6 pièces) Courses : X = 3490 mm Y = 1690 mm Z = 205 mm Dimensions d'usinage : X = 3050 mm Y = (dimension de fraisage max. - rayon de l'outil) 1345 mm Z = 150 mm Tête de perçage TF 20 Puissance : 2,2 kW 8 broches verticales, entraxe 32 mm en X 6 broches verticales, entraxe 32 mm en Y 2+2 broches horizontales en X 1+1 broches horizontales en Y avec lame à rainurer intégrée 120 mm avec électrobroche 9,2 kW avec attachement ISO-30 avec axe C avec agrégat angulaire avec changeur d'outils 12 positions avec emplacement de changement d'outil pour agrégat angulaire avec pompe à vide 80–100 m³/h Puissance totale installée : 16 kW Air comprimé : 6 bar Consommation d'air : 210 NL/m Bouche d'aspiration : 250 mm Débit d'aspiration : 5300 m³/h Vitesse d'aspiration : 30 m/sec Dimensions : 5940 x 3800 x 2510 mm Poids : 3700 kg Disponibilité : à convenir Bsdpfjy Ih Rmox Agtedb Lieu : 63934 Röllbach

Stanje: rabljeno, Leto izdelave: 2011, AXES Working area X-Y-Z axes * mm: 3050-1300-180 Workpiece length in pendulum operation mm: 1390 Stroke X-Y-Z axes mm: 3460-1735-250 Max. traverse speed X-Y axes m/min: 60 WORK TABLE Number of workpiece supports and vacuum suction pads: 6 / 2 standard type Standard end stops / position: 1 / rear Vacuum pump m³/h: 90/108 DRILLING UNIT Vertical spindles std./number/speed rpm: 12 (8X-5Y) / 4000 Horizontal spindles std./number/speed rpm: 6 (4X-2Y) / 4000 Integrated grooving / saw unit in X Ømm/rpm: 120 / 6000 Motor power kW (hp): 2.2 (3) Bsdpfx Ajyymz Ujgtsdb ELECTROSPINDLE Motor power std. / opt. (S6) kW (hp): 7.5 (10) / 11 (15) Max. speed rpm: 24,000 Tool changer, traveling with the support in X: 4 positions, pneumatic INSTALLATION Installed power KVA: 23–28.5 Compressed air requirement Nl/min: 450 Extraction air requirement m³/h: 1900+1900 (3400) Required extraction air speed m/sec: 30 Extraction port diameter mm: 150+150 (200) Machine weight kg: 3000 * X Distance between stops – Y cutter center as reference; Z workpiece passage GENERAL FEATURES CNC-controlled drilling and milling center in frame design with work table equipped with adjustable workpiece supports and vacuum suction pads, suitable for: - Vertical drilling on the panel surface - Horizontal drilling on all four panel sides - Groove milling with disc cutter in the X direction - General milling operations Self-supporting structure and work table: Steel welded frame construction with the control cabinet integrated into the machine frame. Available in two different lengths and with standard workpiece supports or optionally different support carriers. Box-type construction made from cold-rolled steel with internal reinforcement ribs, protective covers with component group consisting of a drilling head with vertical and horizontal spindles, integrated grooving and saw unit, and an SCM electrospindle with quick-change tool system type HSK 63 F. Travel paths of the portal and support carrier: Movement in the X, Y, and Z axes takes place on linear prismatic recirculating ball guides with preloaded bearings. Movement transmission of the X-axis (moving stand) is via a preloaded, backlash-free rack-and-pinion drive with helical gears. Movement of the support carrier in Y and Z directions is via preloaded ball screws. Positioning of the working units and machine functions is managed by "brushless" AC servomotors and digital drives. CNC CONTROL UNIT The control unit consists of a numerical control for milling and drilling machines and a connected PC with a graphical user interface "XILOG PLUS". - PC-Office operating system Windows XP - Color LCD screen 17" - QWERTY keyboard - Swivelling control panel - Machine interface software Xilog Plus Xilog Plus features: Programming - Parametric, graphical and ISO programming - Import of DXF and ASCII files - Straight line or circular interpolation in three axes, linear in space, spiral on the chosen plane - Assisted programming with graphical and syntax help for drilling and milling operations - Automatic optimization of drilling operations and tool change cycles - Possibility to shift panel zero point for drilling on inclined or curved panel edges - Full compatibility with CAD/CAM Routocam (SCM) – AlphaCam Integrated additional features - Calculator for direct data transfer - S

Stanje: rabljeno, Leto izdelave: 2009, Vertikalni obdelovalni center Spinner VC 1460 Leto: 2009 Krmiljenje: Siemens 840D-SL Bdsdex Ew Hrjpfx Agtjb Dolžina mize: 1620 mm Širina mize: 610 mm X: 1460 mm Y: 610 mm Z: 500 mm Stožec vretena: ISO40 Maksimalna hitrost: 12.000 rpm Maksimalna obremenitev mize: 800 kg Število pozicij v zalogovniku orodij: 32 Teža stroja: 9300 kg Dodatki/možnosti: hladilnik vretena dovod za odrezke držala za orodje primeži dokumentacija rezervoar za hladilno tekočino hlajenje skozi vreteno Stroj je pod napetostjo v našem skladišču!

Stanje: rabljeno, Leto izdelave: 2008, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 2.500 mm, pomik osi Y: 1.000 mm, pomik po osi Z: 770 mm, hitro pomikanje X-os: 30 m/min, hitri pomik os Y: 30 m/min, hitri pomik na osi Z: 30 m/min, Hedelius C100 s polno opremo: Notranje dovajanje hladilne tekočine, Bdjdpfey D A Dgsx Agtjb Notranji zrak, Zunanji zrak, Zunanja voda, 3D merilna tipalka, Lasersko merjenje orodja, Vreteno HSK63 18000 obr./min, Magazin za 40 orodij X2500mm Y1000mm Z770mm Ohišje z avtomatsko streho Heidenhain krmilje 530 Odsesovalni sistem Absolent (brez vzdrževanja)

Stanje: zelo dobro (rabljeno), Leto izdelave: 2019, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 2.160 mm, pomik osi Y: 762 mm, pomik po osi Z: 650 mm, hitro pomikanje X-os: 24 m/min, hitri pomik os Y: 24 m/min, hitri pomik na osi Z: 24 m/min, vrtilni moment: 118 Nm, proizvajalec krmilnikov: FANUC, model krmilnika: FANUC I SERIES, največja hitrost vretena: 12.000 obr/min, nos vretena: BT40, število mest v zalogovniku orodij: 30, Oprema: transportni trak za ostružke, CNC rezkalni stroj srednjih dimenzij, namenjen tako za grobo kot tudi za fino obdelavo. Zmogljiv motor v kombinaciji z visoko togostjo in visoko natančnim osnovnim vretenom omogoča velike odvzeme materiala in visoko preciznost. Stroj predstavlja primerno rešitev za širok spekter zahtev v proizvodnji, še posebej v orodjarstvu. Stroj se prodaja v kompletu z opremo opisano v oglasu. Je dobro ohranjen in redno vzdrževan. Bdedpfxoy Dtlzj Agtob -10,4" zaslon -vreteno 12.000 vrt/min, 28 kW, 159,3 Nm - 200mm povišan steber Z-osi -BT40 -magazin za 30 orodij -hlajenje skozi vreteno (18 bar) -pobiralec olja iz emulzije- s trakom -ethernet priključek -pištola za hladilno tekočino -zaznavanje loma orodja - z visečo iglo -avtomatska vrata -predpriprava za priklop robota -priprava za 4. os -rotacijska miza GSA CNC 400-R -podpora GSA TSA-320S -hidravlični agregat 200bar 2x(3A+B) -predpriprava za hidravliko delilnika 2x(3A+B) -kontrola naseda kosa -senzor nivoja emulzije -transporter odrezkov LNS MH500 -predpriprava za centralno odsesovanje oljne megle

Stanje: zelo dobro (rabljeno), Leto izdelave: 2021, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 1.050 mm, pomik osi Y: 570 mm, pomik po osi Z: 510 mm, hitro pomikanje X-os: 36 m/min, hitri pomik os Y: 36 m/min, hitri pomik na osi Z: 30 m/min, vrtilni moment: 118 Nm, proizvajalec krmilnikov: FANUC, model krmilnika: FANUC I SERIES, največja hitrost vretena: 12.000 obr/min, razdalja od mize do središča vretena: 150 mm, nos vretena: BT40, število mest v zalogovniku orodij: 30, Oprema: transportni trak za ostružke, CNC rezkalni stroj srednjih dimenzij, namenjen tako za grobo kot tudi za fino obdelavo. Zmogljiv motor v kombinaciji z visoko togostjo in visoko natančnim osnovnim vretenom omogoča velike odvzeme materiala in visoko preciznost. Stroj predstavlja primerno rešitev za širok spekter zahtev v proizvodnji, še posebej v orodjarstvu. Stroj se prodaja v kompletu z opremo opisano v oglasu. Je dobro ohranjen in redno vzdrževan. -15" zaslon -2MB spomina - 1000 stavkov -vreteno 12.000 vrt/min, 18,5 kW, 118 Nm -BT40 -magazin za 30 orodij -hlajenje skozi vreteno (12 bar) -pobiralec olja iz emulzije- s trakom -ethernet priključek -pištola za hladilno tekočino -hlajenje matice na vretenu osi -zaznavanje loma orodja v magazinu -avtomatska vrata -predpriprava za priklop robota -predpriprava za 4. os -rotacijska miza Hiwin RCV 250 Bdodpfx Agjy Dr A Eetsb -podpora HIWIN RTS 250 -hidravlični agregat 200bar 2A+B -predpriprava za hidravliko delilnika (3x olje, 2x zrak) -kontrola naseda kosa -senzor nivoja emulzije -transporter odrezkov LNS MH500 -predpriprava za centralno odsesovanje oljne megle

Stanje: rabljeno, Leto izdelave: 2011, Base Machine M800 X5 TV 1 WORKING AREA X: 5,020 mm Y: 1,830 mm Z: 675 mm Clearance height: 300 mm (from 50 mm suction cup height) MACHINE STRUCTURE The base structure is a monolithic construction made of thick-walled steel. It is reinforced across the entire machine bed with welded components, ensuring extreme stability. The large-base table design is the secret to guaranteeing long-term precision and stability. The machine’s layout allows the operator optimal workflow with minimal space requirements. The moving gantry carrier is built from a solid monoblock. It is positioned in the X-direction on prismatic ground guides with recirculating ball carriages. The working unit is mounted on this mobile aggregate carrier, also using prismatic ground guides and recirculating ball carriages. AXIS MOVEMENT All axes move on large-section prism linear guides and recirculating ball carriages with a large contact area, ensuring optimal gliding even at the highest speeds and accelerations. The precise and rapid positioning of the moving gantry (X-axis) is achieved via slanted-tooth rack-and-pinion drive. Large-cross-section recirculating ball screws guarantee the precise positioning of the working unit along the moving gantry (Y- and Z-axes). Top-quality drives and brushless motors govern perfect mechanical dynamics and maximum positioning accuracy. Maximum axis speeds: · X-axis = 90 m/min · Y-axis = 90 m/min · Z-axis = 30 m/min Safety device with bumper and light barrier 1 Bumpers with sensors are installed around the mobile support, and a light curtain system is mounted in front of the machine. If the operator enters the active zone, the X-axis travel speed is reduced to 25 m/min without stopping the machine. This system allows workpieces to be loaded during pendulum operation, without the access restrictions typical with foot mat systems. This prevents unwanted interruptions of the machining cycle and allows greater freedom of movement around the work table. CE certificate for the safety system 1 Safety guard fence 1 Side and rear protective fencing Automatic central lubrication controlled by CNC 1 Lubrication of the X, Y, and Z axes is regulated by the CNC control at regular intervals, without manual intervention on the machine. Central extraction port 1 All individual extraction ports of the processing units are combined into a central port. Various slide gates within the port are controlled via NC, reducing the required extraction air flow. Chip conveyor 1 Maxi - 5 axis electrospindle 11 kW HSK-63 "Prisma K 1 5-axis electrospindle rated for 11 kW at 20,000 rpm in S1 (100% ED) Speed: max. 20,000 rpm Left/right rotation Liquid cooling Tool interface HSK 63F 18 kW inverter, stepless, constant power output Max. rotation: B-axis = 200° (+-100°) C-axis = 650° Bedexy Tmnspfx Agtjdb Thanks to the non-orthogonal axes, complex horizontal positioning in limited working areas is possible. This enables the machining of complex geometries without the risk of collisions.

Stanje: rabljeno, Leto izdelave: 2016, Delovno polje: X=3300 mm Y=1280 mm Z=150 mm Višina prehoda Upravljalni terminal: 24" barvni LED zaslon Ročni terminal za upravljanje hitrosti osi Programska oprema: "Woodflash" Vakuumska črpalka 90 m³/h/50 Hz oziroma 108 m³/h/60 Hz Rezkalno vreteno 12 kW HSK F63 (12.000 vrt./min) 12-pozicijski linearni menjalec orodja na levi strani stroja + pick-up prostor Vrtalna glava DH 16 4H 2S: 12 navpičnih vreten 4 vodoravna vretena 2 utorni žagi Lokacija skladišča: Nattheim Bodpexy Tlwsfx Agtjdb

Stanje: zelo dobro (rabljeno), Leto izdelave: 2005, Hedelius RS 60 K - 2000 Leto izdelave 2005 Bjdpfx Agoy H D S Detedb Krmiljenje: - Heidenhain iTNC 530 - Elektronski ročni upravljalnik Glavno vreteno: - SK40 - Maks. hitrost vretena 15000 vrt./min Pomiki: - X – 2000 mm (775 + 600) mm, Y – 620 mm, Z – 520 mm Miza: - Vpenjalna površina, fiksna miza 1200 x 600 mm (levi del delovnega prostora) - NC vrtljiva nagibna miza (desni del delovnega prostora) - NC vrtljiva nagibna miza 360° vrtljiva / nagibna +15 / -95 ° Hlajenje: - 20 bar IKZ - Transportni trak za ostružke Odvod: - Separator emulzijskih hlapov Dobavni rok: - Takoj

Stanje: rabljeno, Leto izdelave: 2012, AVIA VMC 650 – Vertical Machining Center - Spindle Taper: ISO 40 - X/Y/Z Travel: 650 / 540 / 620 mm The AVIA VMC 650 vertical machining center is specifically designed for the production of small to medium batch sizes. With a maximum workpiece weight of 700 kg, even heavier parts can be machined without any issues. Rapid traverse speeds of 25 m/min in the X, Y, and Z axes ensure high machine efficiency. A spindle speed of up to 10,000 rpm ensures excellent surface finishes across a wide range of material types. - Heidenhain iTNC 530 HSCI CNC Controller - Tool changer with 24 positions - Chip auger conveyor - Year of manufacture: 2012 Technical Specifications Table: - Table size: 800 x 540 mm - T-slots (size/spacing/number): 18 mm / 100 mm / 5 - Max. workpiece weight: 700 kg Spindle: - Type: Cartridge - Tool interface: ISO 40 as per PN-92/M-55085/01 (DIN 69871A) - Pull stud according to: ISO 7388/2 Type B - Distance spindle nose/table min./max.: 150 / 770 mm - Max. spindle speed: 50 – 10,000 rpm - Motor power (S6-40% duty cycle): 11.5 kW - Motor power (continuous load): 7.5 kW Tool Magazine: Bdodpfx Agjy Dg Hfetjb - Number of tools: 24 - Max. tool diameter: 80 mm - Max. tool length: 300 mm - Max. tool weight: 7 kg - Tool change time: 6.0 s Travel Range: - Max. X-axis travel: 650 mm - Max. Y-axis travel: 540 mm - Max. Z-axis travel: 620 mm Accuracy (according to ISO 230-2): - Positioning accuracy: ± 0.005 mm - Repeatability: 0.005 mm Rapid Traverse: - Rapid traverse X/Y/Z axes: 25 / 25 / 25 m/min Compressed Air Requirement: - Supply pressure: 0.6 MPa - Air flow rate: 0.2 m³/min - Air quality: Class 5 as per DIN ISO 8573-1 Electrical Data: - Power supply (continuous operation): 3x 400 V / 50 Hz / 40 kVA - Drives and motors: Heidenhain Dimensions: - Front cabin door width: 770 mm - Machine dimensions (W x H x D): 2560 x 2705 x 2722 mm - Machine weight: 4135 kg

Stanje: dober (rabljeno), Leto izdelave: 2011,

Stanje: dober (rabljeno), Leto izdelave: 2010, obratovalne ure: 78.572 h, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 550 mm, pomik osi Y: 410 mm, pomik po osi Z: 450 mm, proizvajalec krmilnikov: Fanuc, skupna masa: 12.000 kg, Special Equipment for the Machine 1. Expansion of the tool magazine from the standard 30 tools to 210 tools, incl. preparation for up to 240 tools 1. Pallet rotary storage for 10 pallets, incl. setup station Number of pallets: 10 Pallet size: Ø 130 mm Pallet interface: Capto C6 Max. workpiece size: Ø 250 x H 250 mm Max. workpiece weight: 40 kg Pallet clamping force: 22.5 kN 1. HSC main spindle, 40 – 20,000 rpm with motor 7.5/11 kW Max. spindle torque: 70 Nm up to 1,500 rpm Including weekly timer to start warm-up cycle and automatic machine shut-off 1. Spindle interface: HSK 63A 1. Direct linear measuring system (Heidenhain) on X, Y, and Z axes, supplied with purge air 1. KNOLL coolant system, consisting of: - Hinged belt chip conveyor with lift pump and chip discharge to operator side - Coolant supply through the spindle with coolant pump KTS25-50T, capacity 24 l/min at 70 bar, 5.5 kW - Coolant pressure switchable in 3 stages - External cooling with coolant pump, capacity 100 l/min at 1.4 bar - Coolant shower with pump, capacity 100 l/min at 1.4 bar - Compact filter KF200, filtration performance 200 l/min System overall dimensions (L x W x H): approx. 1.8 x 1.1 x 1.0 m Bdjdpfx Ajy Hrtcogtjb Tank capacity: approx. 1,400 liters 1. Coolant chiller VWK 90 – D emulsion Cooling capacity: 11.5 kW Ambient temperature up to 42°C Refrigerant: R407c 1. Coolant spray gun in the working area, incl. pump and electrical installation 2. Spiral chip conveyors 1. TEBARON mechanical air filter TEB/BV2 for extraction of emulsions, oil mist, and smoke, consisting of: - 3-stage pre-filter package - HEPA filter according to DIN EN 603335-2-69 with BIA test certificate, particle separation efficiency > 99.995% for particles ≥ 0.3μ Meets requirements for application category K1/K2 (carcinogenic substances and pathogens) as well as dust class H. 1. Single support with base plate for ISI air filter TEB/BV2 1. RENISHAW OMP 60 measuring probe for automatic workpiece zero setting and measurement, can be loaded into the spindle via the tool changer, incl. EASY PROBE SOFTWARE - Pressure sensor for tool length measurement and tool breakage monitoring Special accessories for the control system: - Increase of workpiece coordinate systems from 6 to 54 - Coordinate system rotation G68/G69 - Chamfering and rounding of corners - Automatic zero point tracking - Resume at contour - Extension of macro variables from standard 100 – 149, 500 – 549 to 100 – 199, 500 – 999 - IZ2/150NF HSC precision control for simultaneous 5-axis machining, consisting of: - Fast Data Server function - High-Speed Precision Contour Control - Nano smoothing - Dynamic zero point tracking with up to 8 available zero points (G54.2) - TCPC (Tool Center Point Control) for 5-axis simultaneous milling (G43.4/G49) - Swivel cycle enables machining on an inclined working plane (G68.2/G53.1/G69)

Stanje: rabljeno, Leto izdelave: 2005, Delovno območje: X=2970 mm / Y=1725 mm. Hitrosti pomika osi: X=60, Y=45, Z=25 m/min. Teža: 3200 kg. Lokacija skladišča: Nattheim. Bdedpfx Agsw Dcccotsb

Stanje: rabljeno, Leto izdelave: 2007, Pomik osi: X=4400 mm, Y=2195 mm, Z=440 mm Delovno polje v X=3650 mm, Y=1560 mm Prehodnost: 330 mm Elektrovreteno SCM Power 2000 Visokohitrostno rezkalno vreteno z močjo 13 kW Rotacijska os Vector (C-os) Ventilator za čiščenje orodja na rezkalni enoti Vpenjanje orodja HSK 63 F Hitrost vrtenja 600 – 24.000 1/min brezstopenjsko preko inverterja Moč motorja 8,5 kW Nosilci orodja: 6 kos Menjalnik orodja: Rapid 12 (12 mest) Vakuumska črpalka 250 m³/h / 5,5 kW Maks. vakuum: 0,9 bar Referenčni prisloni na straneh mize Vrtalni agregat z 11 vreteni (7 vertikalnih / 4 horizontalni) Krmiljenje: NUM serija 1000 Uporabniški vmesnik: XILOG Plus PC Office Hardware WINDOWS XP Professional Skupna priključna moč: max. 27,5 kW Teža: 5200 kg Skladišče: Nattheim Bjdpjw Dcb Sjfx Agtedb

Stanje: dober (rabljeno), Leto izdelave: 2016, Funkcionalnost: popolnoma funkcionalen, Krmiljenje MAX5 DSM (2 x 19" zaslona) Velikost mize 762 x 406 mm Bdjdpfx Agjy Du I Rsteb X-hod 660 mm Y-hod 406 mm Z-hod 508 mm Hitrost vretena 10 – 12.000 min⁻¹ Magazin orodij 20 pozicij Vpenjalo SK40 Hitri pomiki X/Y/Z 28 m/min Moč 9,4/11 kW Tloris 2000 x 1800 x 2600 mm Teža stroja 2850 kg Oprema - Opcije programske opreme: 3D, DXF, AVG (realistična grafika), žepi/otoki, funkcija rampe, sinhrono rezanje navojev, orodna in materialna baza, NCPP in ISNC (makro-ISO-kodno programiranje), Ultimotion, sinhrono rezanje navojev - Električni ročni kolešček - Sistem za hlajenje - Transportni polž za odrezke - Signalna luč - Noge za stroj

Stanje: rabljeno, Leto izdelave: 2018, Startech CN MAIN FEATURES Flexible and individually configured production combined with speed and precision. Drilling from above with reference to the top side of the panel enables absolutely precise machining. Numerical control with 7" color display: simple and intuitive. TECHNICAL DATA Startech CN AXES Max. workpiece dimensions X-Y-Z mm: 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm: 300 x 90 x 10 Working area drilling/grooving mm: 0 x 800 / 0 x 800 X-axis travel mm: 750 Max. traversing speed X-Y axes m/min: 25 DRILLING UNIT Vertical spindles Quantity: 7 (4X-4Y, one in common) Horizontal spindles (along Y-axis) Quantity: 2 (1+1) Horizontal spindles (along X-axis) Quantity: 1 Fixed grooving saw (direction) X Diameter of grooving saw mm: 100 Max. thickness grooving saw mm: 5 Motor power kW (HP): 1.5 (2) Spindle speed rpm: 3350 Saw blade speed rpm: 4300 INSTALLATION Power supply V (Hz): 380 / 400 (50 / 60) Installed power KVA: 4.5 Compressed air requirement bar: 6 Air consumption Nl/cycle: 90 Extraction requirement m³/h: 1200 Extraction air velocity m/sec: 20 Extraction nozzle diameter mm: 120 GENERAL FEATURES Universal CNC drilling machine with a worktable featuring a fixed gantry and movable workpiece for the following operations: - Vertical drilling on the panel surface - Horizontal drilling on all four workpiece sides - Grooving operations with integrated grooving saw in 'X' direction Self-supporting construction: Machine base made of steel tubular structure providing a large base for accommodating the worktable. The structure is positioned on 3 self-leveling feet. The electrical cabinet is integrated into the machine frame. Medium bakelite support table "Easy Motion": - an MDF sector for carrying out through drilling, which can be automatically swung away for horizontal drilling - an infeed roller to facilitate panel feeding - a rear roller conveyor to assist smooth panel movement - left and right stops - a central aligner with manual adjustment It is necessary to use the left and right stops to horizontally drill the two opposite panel sides in the 'X' direction. Panel positioning along the X-axis by means of suction. Carriage assembly: This is a gantry structure made of steel tube. The main working unit is installed on the gantry. F10L drilling unit Includes: - 7 independent vertical spindles - Drill holder D10 mm - Distance between spindles 32 mm - 2 horizontal drill heads, 1 in X direction with one drill, 1 double drill head in Y direction (1+1 drill holder D10 mm) - Speed 3350 rpm - 1 integrated saw unit in X (max. diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic stroke per spindle 70 mm - Horizontal pneumatic stroke of drill unit Positioning of workpiece and movement of working unit: A CNC-controlled suction unit clamps the workpiece and positions it sequentially under the working unit during machining. Movement in X and Y axes is via THK guides with transmission on reinforced toothed racks. Movement in the Z axis is pneumatic on "ball-bushing" guides, with adjustable positioning at the stop. Positioning of the work units is performed using state-of-the-art technology and drives. - CONTROL: The control system has been specifically developed for industrial applications. Bsdovwbp Aspfx Agtsdb

Stanje: rabljeno, Leto izdelave: 2011, Obdelovalna velikost v X-smeri: 2770 mm Obdelovalna velikost v Y-smeri: 1220 mm Obdelovalna debelina (Z-mera): 80 mm Zasnova stroja: portalni stroj Moč glavnega vretena: 11,0 kW Hitrost glavnega vretena: 1500 - 24.000 obr/min Vektorsko vodeno vreteno: Da Vpenjalni sistem: HSK 63 F Hlajenje vretena: zračno hlajenje Bdedsvvi Htepfx Agteb Število osi: 3 Menjalec orodij: Da, kos Število mest za menjavo orodij: 10 kos Pisalniška tipkovnica: Da Miška: Da Programski sistem: Xilog Plus DXF vmesnik: Da Možna spletna povezava: Da CD-ROM pogon: Da Izvedba mize: rešetkasta miza Ustavljalni sistem: ustavljalni valj Število vakuumskih črpalk: 1 Moč vakuumske črpalke: 250 m³/h Zavarovanje: varnostne pohodljive preproge Lokacija skladišča: Sonnefeld

Stanje: rabljeno, Leto izdelave: 2004, Lokacija skladišča: Nattheim Bdsdevvi Hyopfx Agteb

Stanje: rabljeno, Leto izdelave: 1994, Lokacija skladišča: Nattheim Bdsdpowmm Nrofx Agtsb
