Dizelski viličarji

Linde H 50 D-02/600 EVO 3B Kabine STVO Klima

Stanje: zelo dobro (rabljeno), Leto izdelave: 2008, Weinig Unimat 500 Leto izdelave: 2008 Širina skobljanja: 260 mm Višina skobljanja: 120 mm Dolžina podajalne mize: 2.500 mm Pomik: 5 - 30 m/min Motor podajalnika: 4 kW Samodejno pozicioniranje leve in zgornje vretena Pozicije vreten Spodaj 7,5 kW Duodexdm Tvopfx Aflsl Desno ) Levo ) 11 kW Zgoraj 11 kW Spodaj 7,5 kW

Stanje: zelo dobro (rabljeno), Four-side planer WEINIG Unimat 500 Equipped with Memory System control, Three axes controlled from the operator panel (width, height, pressure beam position), Ribbed worktable, Cutterhead configuration and motor power: bottom head 7.5 kW, right and left heads 11 kW each, top head 11 kW, additional top head 5.5 kW, additional bottom head 5.5 kW, Maximum planing width: 230 mm, Maximum planing height: 120 mm, Fully adjustable spindles, Spindle diameter: 40 mm, Feed via Cardan shaft rollers with stepless speed adjustment, Central lubrication system, Djdpfx Afsw Dn I Rslsul Machine in original, very good condition. Everything operates as it should. Machine dimensions: Length: 470 cm, Width: 200 cm, Height: 200 cm. Approximate weight: 3,000 kg.

Stanje: rabljeno, Number of spindles: 6 pcs Working width: 230 mm Planing height: 120 mm Jointing table length: 2000 mm Feed motor: 4 kW Feed speed: 5–24 m/min 1 WEINIG Planing and Moulding Machine Unimat 23 E ----- 6 spindles (including 2 x right), reinforced motors, 8,000 rpm, ATS control system Machine will be cleaned and function-tested prior to delivery Working width: 20 – 230 mm Working height: 8 – 120 mm 1st spindle (bottom), 5.5 kW (motor replaced) ----- Diameter: 40 mm Speed: 6,000 rpm Tool circle: 125 – 180 mm Rabbetting device incl. tool Hardened table insert in front of 1st bottom spindle 2nd spindle (right), 12.1 kW (motor replaced) ----- Shared motor with left vertical spindle Diameter: 40 mm Speed: 8,000 rpm Tool circle: 112–250 mm Max. tool diameter behind fence: 203 mm Max. profiling depth: 35 mm Axial adjustment: 80 mm Dodpfxjxz Hh Us Afleul 3rd spindle (left) ----- Shared motor with 2nd spindle Diameter: 40 mm Speed: 8,000 rpm Tool circle: 112–200 mm Max. profiling depth: 35 mm Axial adjustment: 80 mm Pressure shoe in front of left spindle, incl. side pressure roller, spring-loaded 4th spindle (right), 8.3 kW (motor replaced) ----- Diameter: 40 mm Speed: 8,000 rpm Tool circle: 112–250 mm Max. tool diameter behind fence: 203 mm Max. profiling depth: 35 mm Axial adjustment: 80 mm 5th spindle (top), 7.5 kW ----- Diameter: 40 mm Speed: 8,000 rpm Tool circles: 112–200 mm Max. profiling depth: 35 mm Axial adjustment: 45 mm Split pressure shoe in front of top spindle, adjustable to tool circle and can be swung away from tool, spring-loaded 6th spindle (bottom), 4.0 kW ----- Diameter: 40 mm Speed: 6,000 rpm Tool circle: 112–250 mm Max. profiling depth: 15 mm Axial adjustment: 45 mm Spindles – general ----- All moulding spindles with high concentric accuracy Lubrication points for axial spindle movement Feed system ----- Motor with mechanical brake, 4 kW Mechanical feed infinitely adjustable from 5–24 m/min Infeed roller in front of 1st lower tool, pneumatically controlled up/down Durofer pointed tooth rollers (Weinig patent) with depth limiter and self-cleaning Adjustable feed roller travel relative to left spindle, axial 35 mm Electrical system ----- Operating voltage: 440 V (voltage range 380–420 volts), 50 Hz Machine base, tables, and fences ----- Jointing table 2.0 m long (incl. jointer guide) Manual Waxilit pump for table resin removal One driven rubber roller (spring-loaded in outfeed table) Two driven rollers in machine table, hardened Machine operation ----- Pressure shoe in front of top spindle with mechanical digital display Outfeed after top spindle with mechanical digital display ATS/system, automatic 2-axis positioning for spindle Nos. 3 and 5 Min. working height: 12 mm Electric height adjustment of top spindles and feed Central position of lubrication points on front of machine Electronic digital displays on spindle 3 and 5 (axial), spindle 6 (radial), spindle 4 (axial and radial) Safety and noise protection ----- Full safety enclosure Easy high...

Stanje: zelo dobro (rabljeno), CATALOG NUMBER: 7556 Technical specifications: - Min / max working width: 20 / 240 mm - Min / max working height: 8 / 160 mm - Number of spindles: 4 1) Bottom horizontal: 240 mm, 5.5 kW 2) Right vertical: 160 mm, 5.5 kW 3) Left vertical: 160 mm, 5.5 kW 4) Top horizontal: 240 mm, 7.5 kW - All heads adjustable up/down, right/left - Spindle diameter: 40 mm – From the top: - 6 feed-in drive rollers, toothed (including 2 double rollers) - 2 feed-out drive rollers, rubber, smooth – From the bottom: - Side pressure before and after the roller in the lower table - Feed-in toothed, driven, swiveling roller before the first spindle in the lower table - 2 pneumatic side pressures - Feed-out driven roller, metal, smooth - All rollers pneumatically loaded - Infeed table length: 2180 mm - Table adjustable up/down - Central lubrication - Electric thickness setting - Lifting motor: 0.75 kW - Infinitely variable feed speed via inverter: 6–30 m/min - Feed motor: 3 kW - Feed on cardan shafts - Fully enclosed in soundproof cabin - Extraction port diameters: 4 x 150 mm - Dimensions (L/W/H): 3750 x 1750 x 1800 mm - Weight: 3300 kg Dedpfxsvyzn Re Afloul ADVANTAGES – 4-head configuration – Ideal for both wet and dry wood – Second-hand machine, excellent condition Net price: 75,900 PLN Net price: 18,070 EUR (depending on rate 4.2 EUR) (Prices may change with larger exchange rate fluctuations)

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 1991, Funkcionalnost: popolnoma funkcionalen, planing width 220 mm, 6 heads with universal configuration. Control from portable console. The machine is equipped with safety guards. Dsdpfjud Raxex Afleul

Stanje: rabljeno, Funkcionalnost: popolnoma funkcionalen, Leto izdelave: 2018, obratovalne ure: 9.902 h, nosilnost: 7.000 kg, dvižna višina: 4.490 mm, vrsta goriva: električni, tip droga: simpleks, gradbena višina: 3.050 mm, širina nosilnega okvirja vilic: 2.000 mm, dolžina vilic: 2.000 mm, lastna masa: 11.115 kg, skupna dolžina: 3.770 mm, vrsta pogona: Elektro, gradbena širina: 1.850 mm, Electric 4-wheel forklift Load center: 600 mm Fork width: 1501 mm Fork thickness: 60 mm Mast type: Standard Condition: Ready for operation and fully functional Technical condition: Very good Front tires type: Superelastic Duodsv Utmuopfx Afljl Front tires size: 8.25-15 Rear tires type: Superelastic Battery voltage: 80V Battery capacity: 1376Ah Battery year: 2018 Description: In addition to this Kalmar model, we have approx. 200 heavy-duty forklifts, compact forklifts, counterbalance forklifts, and sideloaders in stock at our warehouses in Hamburg and Gdansk. Visit our website – sago-online. Leasing and financing at attractive conditions are always available. We are also happy to purchase your used vehicle outright, even if you do not buy a vehicle from us. Our owner, Mr. Peter Sawitzki, will be pleased to give you detailed advice regarding this ECG70-6. P.S.: Our master forklift workshop specializes in repairs, maintenance, overhauls, and custom modifications for forklifts from 8 tons capacity upwards. We can also display your vehicle for commission sale at our premises upon request. Sideshift, fork positioner, Heater, full cabin, air conditioning, camera, wheelbase (front-rear) – 2450 mm
