Ekscentrični pritisk - enojni stolpec

HENSEL EBU H 40

Stanje: zelo dobro (rabljeno), Leto izdelave: 1967, Oprema: Lodpfxsl D N Hvo Al Njrk 1 vpenjalni dovod desno 1 ekscentrična stiskalnica 90 kN 2 ožji sani agregata 3 običajni sani agregata Delovno območje: Območje debeline žice: 0,5 - 3,5 mm Širina traku: maks. 32 mm Dovodna dolžina: maks. 170 mm Kapaciteta: maks. 250/min

Leto izdelave: 2004, stanje: pripravljen za uporabo (rabljen), A fully automatic Kasto band saw system is available. Cutting range at 90°: Round material: 530mm, Square material: 530mm x 530mm, Flat material: 530mm x 640mm. Saw blade length: 7675mm, saw blade width: 54mm, saw blade thickness: 1.6mm, cutting speed: 120m/min. Overall system dimensions (X/Y): approx. 18,000mm x 4,000mm. Weight: approx. 6,000kg. Includes roller conveyors. Documentation is available. On-site inspection is possible. Ljdpjv S E Edsfx Al Nork

Stanje: rabljeno, Leto izdelave: 2009, Cutting diameter: 15 – 560 mm Cutting range at 90 degrees: flat 560 x 630 mm Saw blade dimensions: 7,400 x 54 x 1.60 mm Control system: KASTO Material feed – single stroke: 900 mm Multiple feed length max.: 9,999 mm Minimum cut-off length: 6.00 mm Saw motor: 5.50 kW Cutting speed: 13 – 127 m/min Material support height: 700 mm Total power requirement: 12.00 kW Machine weight approx.: 6.00 t Space requirements approx.: 3.70 x 2.50 x H2.50 m Two-column automatic bandsaw with KASTO Compact Control; frequency-controlled saw drive; minimum quantity lubrication; swarf conveyor; powered infeed conveyor 6m + 3x short roller conveyors 1m each; outfeed conveyor 2m; machine can be inspected under power. Lrsdsvxwkfepfx Al Nsk

Stanje: novo, Saw blade diameter: 350 mm Cutting range at 90 degrees, round: 115 mm Cutting range at 90 degrees, square: 95 mm Cutting range at 90 degrees, rectangular: 180 x 95 mm Lrodpfsfg Rlcox Al Nok Working height: 925 mm Saw blade speeds: 15 - 90 rpm Total power requirement: 3.0 kW Machine weight approx.: 0.68 t Space requirements approx.: 0.8 x 1.0 x 1.85 m Electropneumatic, vertical, linear-guided automatic saw for use with HSS saw blades, designed for serial cuts from 60° left to 45° right on steel. The machine can also operate in semi-automatic mode. CNC automatic machine with multiprocessor and two axes controlled by the latest generation MEP controller, allowing the programming of up to 1000 different cutting programs—each with different cutting lengths and quantities—for the same material thickness.

Stanje: novo, Pressure: 25 t Throat depth: 200 mm Stroke: 4 - 80 mm Table surface: 520 x 400 mm Stroke rate: 160 strokes/min Ram surface: 160 x 160 mm Ram adjustment: 40 mm Ram bore: 32 H7 mm Throughhole in table: 200 x 150 mm Clamping plate: 500 x 380 x 60 mm Ledpfx Alob U Hwpj Njrk Total power requirement: 2.7 kW Machine weight approx.: 1.9 t Space requirement approx.: 1.3 x 1.0 x 1.85 m - Ortlinghaus pneumatic clutch/brake combination - Vogel central lubrication - Balluff cam controller - Height-adjustable table - Control cabinet with touchscreen - Foot switch

Stanje: dober (rabljeno), Leto izdelave: 2001, Gildemeister NEF 520 CNC Lathe TECHNICAL DATA Lrsdpfowftviox Al Njk Working Area Swing diameter over bed: 500 mm Swing diameter over cross slide: 290 mm Chuck diameter: 250 mm Cross slide travel: 260 mm Distance between centers: 850 / 1350 mm Main Spindle Spindle nose: DIN 55027 Size: 8 Spindle bore diameter: 70 mm Spindle taper: metric 80 Spindle diameter at front bearing: 120 mm Main Drive AC Drive power: 12 kW Max. torque: 920 Nm Speed range: 10 – 3000 rpm Gear stages: 2 Selectable speeds: Stepless Feed Drive X-axis feed force: 5000 N Z-axis feed force: 10000 N X-axis rapid traverse: 8 m/min Z-axis rapid traverse: 10 m/min Tool Holder Multifix; Size: C Tailstock Quill diameter: 80 mm Quill stroke: 180 mm Quill taper: MT5 Dimensions L x W x H: 2900 x 1953 x 1825 mm Weight: 2700 kg SCOPE OF DELIVERY Including (not limited to): - Gildemeister lathe - SMW Autoblok Hi-Grip high-precision chuck - Chuck jaws - Multifix tool post - Complete operating documentation - Full scope of supply as per photo documentation We accept no liability for the correctness, completeness or currentness of the information provided.

Stanje: generalkompletno obnovljen (rabljeno), Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 475 mm, pomik osi Y: 600 mm, pomik po osi Z: 400 mm, teža obdelovanca (maks.): 200 kg, največja hitrost vrtenja: 42.000 obr/min, premer mize: 450 mm, 5-Axis Röders Tec RXP800DS - Fully Refurbished - The machine is completely overhauled, inspected, and measured in our facility. The machine once again meets original factory tolerances! Working Area: - X-axis: 475 mm - Y-axis: 600 mm - Z-axis: 400 mm - Clearance Height: 500 mm Tool Changer: 52 positions Spindle: HSK40E, max. 42,000 rpm Tool Measurement Laser for tool calibration Handheld Control Unit Minimum Quantity Lubrication Prepared for extraction system (e.g. for graphite machining) Spindle Compensation Precision Package CNC Control: Röders RMS6, latest version Lrodpevvlmcjfx Al Nsk The machine can be viewed in operational condition at any time. For more information about the type and scope of our refurbished machines, please visit our website or our Hüttmann YouTube channel.

Stanje: novo, Leto izdelave: 2025, Tlačna peskalna kabina DSK 11.11.30. Peskalni prostor: širina 1050 mm, globina 1050 mm, višina 955 mm. 1 TÜV-preizkušen tlačni rezervoar 30 l s stožčastim iztočnim lijakom. 1 ventil za doziranje peskalnega sredstva s pnevmatskim uravnavanjem količine. 1 vgrajen zapiralni stožec z vodilno cevjo. 1 priključek za stisnjen zrak s pnevmatskim zapornim ventilom in iztokom za krmilni zrak. 1 regulator tlaka za nastavitev peskalnega tlaka. 1 peskalna cev DN19. 1 ročnik z bor-karbidno Venturi šobo 8 mm. 1 par peskalnih rokavic. Električno nastavljiva višina kabine za ergonomičen položaj telesa. Shranjevanje višinskih položajev v spominu za 3 nastavitve. Filter za odpraševanje 2000 m³/h 2,2 kW. Lodpfx Alsga Ehbe Njrk

Stanje: novo, Leto izdelave: 2025, Stroji po meri, prilagojeni vašim proizvodnim potrebam. Naši stroji po meri so natančno zasnovani in izdelani tako, da ustrezajo edinstvenim zahtevam vaših proizvodnih procesov. Ne glede na to, ali se osredotočate na dodelavo, odstranjevanje oksida ali zaobljanje robov, ti stroji zagotavljajo izjemno natančnost in zmogljivost. Dodelava: Dosezite gladko, visokokakovostno površinsko obdelavo različnih materialov ter zagotovite stalno profesionalen in sijoč videz. Odstranjevanje oksida: Učinkovito odstranite površinske okside in tako zagotovite čisto, neonesnaženo površino – ključno za nadaljnjo obdelavo ali nanašanje premazov. Zaobljanje robov: Natančno zaoblite robove po želenem radiju ter s tem izboljšate varnost in kakovost končnega izdelka. Možnosti prilagoditev: Lredpfx Aljhq Dbxe Nsk Vsak stroj je posebej prilagojen vašim zahtevam in omogoča fleksibilnost pri: Hitrosti obdelave: Nastavljiva prilagoditev hitrosti glede na potrebe vaše proizvodnje. Posebne funkcije: Možne opcije med drugim vključujejo sisteme za odsesavanje prahu in dimov, nastavljive pritiske ter programsko krmiljene konfiguracije za optimizacijo proizvodnega procesa. Zgrajeno za vzdržljivost. Naši stroji po meri so izdelani za dolgo življenjsko dobo in zanesljivo delovanje tudi ob dolgotrajnih proizvodnih ciklih. Primerni za manjše projekte ali serijsko industrijsko proizvodnjo, zagotavljajo vrhunske rezultate leto za letom.

Stanje: zelo dobro (rabljeno), Funkcionalnost: popolnoma funkcionalen, Leto izdelave: 1984, Load capacity: max. 300 kg Lsdpfx Aef S I I Hsl Nsrk Reel plate diameter: 1,000 mm Maximum outer coil diameter: 900 mm Inner coil diameter: 240 - 560 mm Maximum coil width: 180 mm
