Žage HSS za poševno rezkanje

EYAN Chamfering

Stanje: rabljeno, Leto izdelave: 2013, Technical Details: Csdpjtv Sdfjfx Afnjgp Turning diameter: 38 mm Item: CNC Turning Machine Make: Hanwha Model: STL38H Year of manufacture: 2013 Control: Siemens 840SL for 8 axes Main spindle: Max. turning diameter: 38 mm; spindle bore max. 42 mm; max. speed: 6,500 rpm Max. power: 23 kW; C-axis with 0.001° increments; Z1 travel: 320 mm; synchronous running guide bush unit; guide bush type: JBS or SL38; collet type: 173E / F48 Sub spindle: Max. pick-off diameter: 38 mm; max. speed: 6,500 rpm Max. power: 23 kW; C-axis with 0.001° increments; Z2 travel: 320 mm; collet type: 171E / F42 Turret: Max. speed: 6,000 rpm Max. power: 2.6 kW; servo axes: X2, Y2, Z2; stroke [mm]: X2 = 115, Y2 = 100, Z2 = 120 Bar feeder: FMB Turbo 5-55 High-pressure unit: SFB-301 eco 150 bar Please contact us for further information and pictures via email (at) or *

Leto izdelave: 2012, stanje: dober (rabljeno), Muratec MW120 GT naprodaj Rabljeno, v odličnem stanju. Ogled stroja je možen po dogovoru. Dostava je odgovornost kupca, po potrebi pa lahko pomagamo pri pakiranju in nakladanju. Dobava: EXW Székesfehérvár Cjdpfsifi D Tjx Afnegp

Stanje: rabljeno, Leto izdelave: 2007, Double-spindle machining center in 5-axis configuration (on both sides) Travel paths X/Y/Z = 600/600(975)/500 mm Number of spindles: 2 Spindle distance: 600 mm Rapid traverse: 45 m/min Spindle speed up to: 17,500 rpm Drive power: 38 kW Tool magazine: 2 x 72 tool pockets Tool holder: HSK 63 CNC control: Siemens 840D 1 x tool breakage control 2 x clamping bridge supports H75 mm 2 x clamping bridges for 5th axis Coolant system Knoll, 70 bar 1 x chip conveyor KB1000 1 x drilling head indexing unit 2 x tool length measuring system 2 x upgrade kit for torsion compensation A-/U-axis Cgodpfxotgu Ixe Afnjp

Stanje: rabljeno, Leto izdelave: 2000, Premer struženja . mm Dolžina struženja . mm Krmiljenje 2x 840 D Dodatna oprema: sistem za hlajenje Transporter ostružkov: da kW Nazivni tok generatorja 95,00 A Priključna moč 65,00 kW Na voljo so 3 stroji Nakladalni sistem: Cgedpfxoqn A Rno Afnjp ? Inventarna številka: 21214 ? Oznaka stroja: Avtomatizacija Promot za 21223 ? Leto izdelave: 1999 x2 / 2000 x1 ? Krmiljenje: Siemens Sinumerik 840D Powerline ? Podatki o električni oskrbi: ? Obratovalna napetost: 10,00 kW ? Nazivni tok: 18,00 A ? Rezerva: 25,00 A 2x 1999 / 1x 2000

Stanje: zelo dobro (rabljeno), HSS saw blade grinding machine VOLLMER model CMS 10M Cgjdpfx Afoi Hchdenep

Stanje: generalkompletno obnovljen (rabljeno), številka stroja/vozila: 1500/R, Loading device with test forces 1–187.5 kg - Brinell: 15.625 / 31.25 / 62.5 / 187.5 - Rockwell: HRA / HRB / HRC Scope of delivery: - Hardness testing device - Matte screen - Fresnel lens - Vertical illuminator - Threaded spindle with adjustment mechanism - Lighting unit - 70X objective - Evaluation unit - Ball holder with 2.5 mm ball for Brinell - 120° diamond cone for Rockwell - Flat test table Ø80 mm - Prism support Ø80 mm - Power cable Cgsdpsdb E Tfjfx Afnjp Optional: - BVMS software (see 3-rath.de)

Stanje: rabljeno, TECHNICAL DATA - Number of axes: 4 MAIN SPINDLE - Spindle nose: A2-6" - Spindle drive power: 11/15 [kW] - Torque: 51/110 [Nm] - Spindle speed: 4500 [rpm] - Max. bar diameter: 66 [mm] - Max. machining diameter: 340 [mm] - Max. diameter over bed: 400 [mm] - Max. main spindle chuck diameter: 190 [mm] - Minimum C-axis resolution: 0.001 [degrees] TURRET Cgjdevzt Hbspfx Afnjp - Number of positions: 12 - Number of driven positions: 12 - X/Z traverse path: 227.5 [mm] - Y traverse path: +/- 41 [mm] - Driven tools speed: 6000 [rpm] - Driven tools power: 3.7/5.5 [kW] ELECTRICAL SUPPLY - Supply voltage: 400 [V] - Total connected load: 21 [kW] WEIGHT AND DIMENSIONS - Footprint: 2000 x 1600 [mm] - Machine height: 1850 [mm] - Machine weight: 4300 [kg] EQUIPMENT - Control system: Fanuc - Interface: Ethernet / RS232 / USB / PCMCIA - Coolant tank - Chip conveyor - Oil mist extraction: DONALDSON - Tool probe - Parts removal device - Parts conveyor belt - Fire extinguishing system*: SIEMENS * Note: Functional capability not guaranteed. To be checked by a qualified company commissioned by the buyer. - Number of driven tool holders: 2 - Number of fixed tool holders: 4 - Collet chuck: EROWA

Stanje: generalkompletno obnovljen (rabljeno), REKORD 400 MODIFIED WITH TANK AND COOLING SYSTEM SHARPENING MACHINE FOR TUNGSTEN CARBIDE AND HSS CIRCULAR SAWS (FULLY OIL-BASED OPERATION) FEATURES Grinding wheel diameter: 150 mm Grinding wheel motor: 1 HP Cedpfxoh A N R Sj Afnjgp 0.25 HP feed motor for grinding carriage Cooling system indicator (Oil bath) Electronic cam reading system (SLOW CONTROLLED BACK FINISHING) Magnifier lamp (FOR SMALL TEETH) Sharpening speed electronically adjustable via potentiometer Manual bevel angle adjustment using scale rod No. 1 copy wheel No. 1 diamond wheel, diameter 150 x 4 - 60° No. 1 bakelite wheel for HSS Minimum blade diameter: 30 mm (with small blade holder on request) Maximum blade diameter: 400 mm

Stanje: dober (rabljeno), TECHNICAL DATA AXES Rapid traverse X, Y: 15,000 mm/min Rapid traverse A, B: 15,000 mm/min Rapid traverse Z1, Z2, E: 18,000 mm/min Rapid traverse C: 90,000°/min Minimum input increment: 0.001 mm Minimum input increment, C-axis: 0.001° MACHINING CAPACITY Max. turning diameter: 20 mm Max. spindle stroke: 205 mm Max. drilling capacity: Stationary: 14 mm; Driven: 8 mm Max. tapping capacity: Stationary: M10 x P1.5; Driven: M6 x P1.0 MAIN SPINDLE Spindle speed: 500 – 10,000 rpm Drive: Spindle drive Main spindle motor: 3.7 / 5.5 kW Main spindle bore: 26 mm SUB SPINDLE Max. clamping diameter: 20 mm Max. part length for forward ejection: 150 mm Max. unclamping length: 75 mm Cgjdju Uic Tjpfx Afnjp Spindle speed: 500 – 10,000 rpm Sub spindle motor: 2.2 / 3.7 kW Indexing angle: 1°, 15° CONFIGURATION Operating mode: Right-handed Dimensions: 2,700 x 1,400 x 2,400 mm Weight: 3,400 kg SCOPE OF DELIVERY Includes (not exhaustive): Control: Fanuc Fire extinguishing system: Siemens Oil mist separator: Donaldson Transformer Hydraulic unit Parts conveyor Chip conveyor Bar feeder: LNS Tool holder Exact scope of delivery as per photos We do not guarantee the correctness, completeness or currentness of the information provided.

Stanje: rabljeno, Leto izdelave: 2011, premer struženja: 170 mm, izvrtina vretena: 42 mm, Machine très bien entretenue et complète Nakamura-Tome WT 100 avec embarreur Iemca. Données techniques : Commande : Fanuc 31i-A Diamètre de tournage : 170 mm Longueur de tournage : 503 mm Cgodpex N S Hzefx Afnop Alésage de broche : 42 mm Nez de broche : A2-5 Nez de contre-broche : A2-5 Vitesse de rotation de la broche principale : 6 000 tr/min Vitesse de rotation de la contre-broche : 6 000 tr/min Course X1 et X2 : 135 mm Course Y1 : +/- 31 mm Course Z1 et Z2 : 503 mm Axe C broche principale : 0,001° Axe C contre-broche : 0,001° Tourelle : 2x 12 positions (24 index) Type d’outil : BMT 44 Embarreur : Iemca Boss 525E (année : 2011) Poids de la machine : 5 650 kg. Nous comprenons que vous puissiez souhaiter des informations complémentaires sur cette machine ou venir la voir en fonctionnement dans nos locaux. N'hésitez pas à nous contacter. Nous sommes à votre disposition.
