Drsna namizna žaga

Altendorf F 45

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2011, Funkcionalnost: popolnoma funkcionalen, največja širina rezanja: 1.300 mm, premer žaginega lista: 500 mm, Oprema: dozator, TEHNIČNI PODATKI Dolžina dvojnega vozička: 3.000 mm Širina reza: 1.300 mm Pogonska moč: 5,5 kW Premer žaginega lista: 500 mm Kedpfexnx Hcox Ah Dodu Podaljšek mize: 840 mm OPREMA Enota za vretenje s 2 osmi Kotno-nagibno vodilo

Stanje: rabljeno, Leto izdelave: 1993, Sliding table length: 2800 mm Cutting width at rip fence: 1250 mm Cutting width at crosscut fence: 2800 mm Cutting depth: 145 mm Kjdpfxexp Rako Ah Dsdu Scoring unit: yes Saw blade height adjustment: electric Saw blade tilt adjustment: electric Rip fence adjustment: manual Saw blade angle display: digital Cutting height display: - Rip fence display: scale Crosscut fence display: scale Saw blade diameter: 450 mm Speeds: 4 Motor power: 5.5 kW Motor brake: yes – automatic Extraction connection: 80 mm and 120 mm Machine length: 3000 mm Machine width: 2200 mm Weight: 1000 kg

Stanje: rabljeno, Leto izdelave: 2018, Used machine Year of manufacture: 2018 Basic equipment: - Electrically powered height and tilt adjustment - 0-46° with automatic cutting height correction during tilting - Controls at eye level, swiveling - Double roller carriage, carriage length 3,000 mm - Parallel fence, manually adjustable via measuring scale, incl. manual fine adjustment, cutting width 1,000 mm - Mitre fence with fixed 90° position, manually adjustable via measuring scale up to 3,200 mm - Max. saw blade projection 150 mm - Max. saw blade diameter 450 mm - Drive power 4 kW (5.5 HP) at 4000 rpm - AKE tool clamping system for the main saw blade - Working height 91 cm Productivity equipment package: Motor 5.5 kW (7.5 HP) with VARIO F45 - Infinitely variable speed control from 2,000 to 6,000 rpm - Exact speed adaptation to the material increases cut quality and saw blade service life Kdodpfjxppv Rsx Ah Deu Extended cutting height for single-sided tilting - This option is for single-sided tilting with a large extraction hood for a max. saw blade diameter of 550 mm and a blade projection of max. 204 mm. - In combination with a scoring unit, the max. saw blade diameter is 500 mm or 179 mm cutting height. Only available with at least 5.5 kW (7.5 HP) drive power. Double-sided tilting! 3-axis scoring unit RAPIDO Plus - With electric height and lateral adjustment, programmable scorer blade height, quick lowering and raising, drive motor 0.75 kW (1 HP), 8,200 rpm. Retrofit only possible on machines prepared for scoring units. LED lighting - Highly energy-efficient LED technology marks the danger area around the scorer for good visibility. Double roller carriage with 3,000 mm carriage length Basic equipment Double roller carriage with carriage length 3,000 mm The Altendorf double roller carriage is renowned for its smoothness and precise running. It can be locked steplessly in any position. The large double rollers, precision-machined from hardened steel, keep the upper carriage absolutely true to the lower carriage along the respective hard-chrome plated guide rods. This running quality is maintained even after decades of use and contamination. The carriage construction is designed as a highly torsion-resistant and dimensionally stable multi-chamber system. The table surface is precisely planed and anodized. A hard-chrome plated round rod, positively fitted into the upper carriage, serves as a mount for the cross-slide and as an interface for various accessories. The entire unit requires minimal maintenance and no lubrication. Mitre cross fence DIGIT-L, crosscuts up to 3,500 mm - This ALTENDORF patented fence with integrated length compensation simplifies precise angle and mitre cutting in one operation. In both positions, the swiveling angle can be adjusted steplessly by 49° and is shown digitally. The play-free and robust fence flaps can be easily moved and set individually over the total range up to max. 3,500 mm. For crosscuts up to approx. 1700 mm, the stable telescopic arm with roller support takes over.

Stanje: zelo dobro (rabljeno), CATALOGUE NUMBER 7731 - Maximum main saw blade diameter without scorer: 400 mm - Maximum main saw blade diameter with scorer: 350 mm - Cutting height with 400 mm blade: 110 mm - Electric height and angle adjustment of the blade - Electronic angle display - Spindle diameter: 30 mm - Scoring unit diameter: 120 mm - Electric adjustment of scorer: up/down, left/right - With sliding table - Cutting length on sliding table: 2900 mm - Clamping bar: 1480 mm - Sliding table guidance on steel rods - Cutting width at the rip fence: 1350 mm - With side table - Main motor: 5.5 kW - Scorer motor: 0.75 kW - Electric brake - 4 rotation speeds: 3000/4000/5000/6000 rpm - Electronic speed display - Extraction nozzle diameter: 90, 120 mm - Table dimensions with extension and widening: 2060 x 1410 mm - Saw blade guard - Dimensions (L x W x H): 3150 x 3650 x 1550 mm - Weight: 1155 kg ADVANTAGES – German-made – Electric adjustment of blade and scorer – With scorer – Clamping bar Kodpfjxa Elpox Ah Dedu – Not repainted – Used saw, in very good condition Net price: 33,900 PLN Net price: 7,980 EUR (based on exchange rate 4.25 EUR) (Prices may vary with significant exchange rate fluctuations)

Stanje: delavnici obnovljeno (rabljeno), Leto izdelave: 2020, Funkcionalnost: popolnoma funkcionalen, dolžina rezanja (maks.): 3.400 mm, širina reza pri vzporednem vodilu: 1.300 mm, premer žaginega lista: 450 mm, dolžina mize: 840 mm, moč: 5 kW (6,80 KM), Oprema: dozator, osvetlitev, vrtilna hitrost brezstopenjsko nastavljiva, Rabljeni stroj GM010.0303 Leto izdelave: 2020 F45 ElmoDrive Višina stroja 910 mm Upravljanje na višini oči Obojestranski nagib (+/- 46°) Maks. premer žaginega lista 450 mm Motor 5,0 kW (7,5 KM) VARIO 2-osni utorni žagin list z vključenim parkirnim položajem Ksdow Im I Aepfx Ah Dedu LED osvetlitev Podaljšek mizne plošče 840 mm Dvojni valjčni voziček, dolžina vozička 3400 mm Digitalni kotni prislon DIGIT L CNC vzporedni prislon 1300 mm Laserski prikazovalnik reza

Stanje: novo, Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, dolžina rezanja (maks.): 3.105 mm, največja širina rezanja: 1.300 mm, širina reza pri vzporednem vodilu: 1.300 mm, višina reza z zareznim rezilom (max.): 150 mm, premer žaginega lista: 450 mm, vrsta nastavitve višine: električni, višina mize: 910 mm, vrtljajska hitrost (min.): 3.000 obr/min, največja hitrost vrtenja: 5.000 obr/min, vrsta vhodnega toka: trifazni, vhodna napetost: 400 V, trajanje garancije: 12 meseci, moč: 7,5 kW (10,20 KM), Altendorf F45 Pro Drive Stroj je nov in konfiguriran kot sledi: Delovna višina: 910 mm Dolžina pomične mize: 3200 mm Krmilna plošča v višini oči za udobno upravljanje Višina reza: 150 mm z 450 mm žaginim listom Glavni motor: 7,5 kW s tremi hitrostmi vrtenja; z AKE sistemom za menjavo žaginih listov Dvoosna predrezovalna enota z varnostno LED lučko na območju predreza za večjo varnost in prepoznavnost delovanja enote Gumba za vklop/izklop glavnega motorja in predrezovalne enote na pomični mizi za priročen zagon stroja Vogalni prečni prislon, razširljiv do 3500 mm, z korekcijo kota Širina reza: 1300 mm s CNC, programiranje preko zaslona Gobjxaudhskr A Tq Djkc (brez konteksta ni prevedeno) Motorizirano dviganje, spuščanje in nagibanje (0–46°) glavnega žaginega lista z avtomatsko korekcijo višine reza pri nagibu Kdedpfx Aoxaudhjh Deu Altendorf F45 je že dolgo priznan kot vodilni model med pomičnimi krožnimi žagami in nenehno postavlja najvišje standarde kakovosti v tem razredu strojev.

Stanje: zelo dobro (rabljeno), Leto izdelave: 1986, Used, in good condition Manufacturer: Altendorf Model: F45 Year of manufacture: 1986 Machine no.: 86-4-143 GS-certified Motor: 5.5 kW Carriage length: approx. 2500 mm Cutting width: approx. 800 mm Tilting up to 45° Saw blade diameter: 450 mm Parallelogram guard Mitre gauge Extraction connection: D 80 mm and 120 mm Space requirement: approx. 2500 mm x 1600 mm x 1500 mm Weight: approx. 1000 kg Stock location: arriving at warehouse 54634 Bitburg Free loaded, unpacked Kdjdswhgd Sspfx Ah Dsu Sale as inspected, in current condition Without warranty or guarantee

Stanje: rabljeno, Leto izdelave: 1993, Carriage length: 2,800 mm Cutting width at rip fence: 1,250 mm Cutting width at crosscut fence: 3,200 mm Cutting height at 0°: 150 mm Cutting height at 45°: 145 mm Scoring unit: no Saw blade height adjustment: hydraulic Saw blade tilting adjustment: hydraulic Rip fence adjustment: manual Saw blade angle display: digital Cutting height display: - Rip fence display: scale Crosscut fence scale: scale Saw blade diameter: 450 mm Speeds: 3,000 / 4,000 / 5,000 / 6,000 Motor power: 5.5 kW Current consumption: 11.5 A Motor brake: yes Extraction port: 80 mm / 120 mm Kjdpfoxp N U Tjx Ah Dodu Machine length: 3,300 mm Machine width: 2,000 mm Weight: 1,100 kg

Stanje: rabljeno, Leto izdelave: 2024, Funkcionalnost: popolnoma funkcionalen, največja širina rezanja: 1.000 mm, največja višina reza: 154 mm, premer žaginega lista: 450 mm, skupna masa: 1.200 kg, vrtljajska hitrost (min.): 3.000 obr/min, največja hitrost vrtenja: 5.000 obr/min, vhodna napetost: 400 V, vrtilni razpon: 45 °, vhodna frekvenca: 50 Hz, moč: 7,35 kW (9,99 KM), Oprema: dozator, motorna zavora, s krmilno enoto Prodrive predrezovalnik z LED osvetlitvijo s CNC vzporednim prislonom merilni prislon je digitalno berljiv podaljšava namizne plošče: 840 mm digitalni kotno-poševni prislon višina stroja: 910 mm dvoosni predrezovalni agregat z nagibom samodejna korekcija mere na vzporednem in kotnem prislonu ob nagibu žagalne enote enostavno umerjanje osi diagnostika stroja, števec delovnih ur, USB vmesnik ohod zadnjega vnosa mere (Funkcija "Nazaj") 99 programov za shranjevanje rezov Druge tehnične podrobnosti priključek za odsesavanje: 120 / 80 mm razširitvena miza: 1200 mm Kjdpsxl Ti Tsfx Ah Djdu število vrtljajev: 3000 / 4000 / 5000 vrt/min formatna pomična miza: 3200 mm električna nastavitev višine električna nastavitev kota zaščitna naprava: zgornji ščitnik

Stanje: rabljeno, Leto izdelave: 2006, Dolžina sani: 3000 mm Širina reza pri vzdolžnem prislonu: 1000 mm Širina reza pri prečnem prislonu: 3200 mm Globina reza: 154 mm Predrezilo: da Višinsko nastavljanje žaginega lista: električno / pozicijsko upravljanje Nagibno nastavljanje žaginega lista: električno / pozicijsko upravljanje Nastavitev vzdolžnega prislona: električna / pozicijsko upravljanje Nastavitev prečnega prislona: ročna Prikaz kota žaginega lista: digitalni prikaz Kedsxp Radspfx Ah Dedu Prikaz globine reza: digitalni prikaz Prikaz vzdolžnega prislona: digitalni prikaz Prikaz prečnega merila: skala Prečno merilo z funkcijo za poševni rez: da Premer žaginega lista: 450 mm Hitrosti vrtenja: variabilna Moč motorja: 5,5 kW Priključek za odsesavanje: 80 in 120 mm Dolžina stroja: 3200 mm Širina stroja: 2200 mm Teža: 1200 kg
